TP-Link WBS210 Installation Manual

Outdoor wireless base station
Hide thumbs Also See for WBS210:
Table of Contents

Advertisement

Quick Links

See also: Installation Manual
COPYRIGHT & TRADEMARKS
Specifications are subject to change without notice.
is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands
and product names are trademarks or registered trademarks of their respective holders.
Installation Guide
No part of the specifications may be reproduced in any form or by any means or
used to make any derivative such as translation, transformation, or adaptation
without permission from TP-LINK TECHNOLOGIES CO., LTD. Copyright © 2015 TP-LINK
TECHNOLOGIES CO., LTD. All rights reserved.
WBS210 / WBS510
Website: http://www.tp-link.com
O u tdoor Wi re l e s s Ba se S t at i on
Tel: +86 755 26504400
E-mail: support@tp-link.com
7106505975 REV2.0.1

Advertisement

Table of Contents
loading

Related Manuals for TP-Link WBS210

Summary of Contents for TP-Link WBS210

  • Page 1 COPYRIGHT & TRADEMARKS Specifications are subject to change without notice. is a registered trademark of TP-LINK TECHNOLOGIES CO., LTD. Other brands and product names are trademarks or registered trademarks of their respective holders. Installation Guide No part of the specifications may be reproduced in any form or by any means or used to make any derivative such as translation, transformation, or adaptation without permission from TP-LINK TECHNOLOGIES CO., LTD.

  • Page 2: Table Of Contents

    Contents Overview Hardware Installation Connect cables Mount Antenna Power On Lightning and ESD Protection Configuration with PharOS Log in to the PharOS Configure the Base Station Specification...

  • Page 3: Overview

    Overview TP-LINK's Outdoor Wireless Base Stations of the Pharos series products are designed for outdoor wireless network solutions, aiming at long-distance transmission and large coverage of wireless network. Package Contents Passive PoE Adapter Waterproof Rubber Insert Power Cord Installation Guide...

  • Page 4: Panel Layout

    Panel Layout The panel of Base Station Chain1 Chain0 RESET LAN1 LAN0(POE IN) Grounding Terminal Shielded Ethernet Shielded Ethernet Port LAN1 Port LAN0(POE IN) LED Explanation On: The Base Station is powered on. On: The port is connected but not active. Flashing: The port is transmitting data.

  • Page 5: Hardware Installation

    Press and hold for 8 seconds to reset the Base Station to its factory defaults. Hardware Installation The Outdoor Wireless Base Stations require external antenna that corresponds to your network environment. It is recommended to buy and use TP-LINK’s matching antennas. Recommended TP-LINK's Matching Antenna Type Antenna Dish Antenna TL-ANT2424MD (2.4GHz)

  • Page 6: Connect Cables

    Connect Cables Firmly grasp the rear of the interface cover and pull it downward. Use an adequate Ethernet cable to connect the LAN0 (POE IN) port. The length of cable is up to 60m for steady power supply. Shielded CAT5e (or above) cable with an integrated ground wire is recommended.

  • Page 7: Mount Antenna

    Mount Antenna Mount the Base Station on an antenna with a suitable mounting bracket or on a pole for the antenna without the mounting bracket. Option1: Mounting the Base Station on an Antenna Sector antenna is used as a demonstration below. Align the mounting tabs on the back of the Base Station with the four slots of the mounting bracket.
  • Page 8 Option 2: Mounting the Base Station on a Pole Loosen and completely remove the end of the metal strap by turning the captive screw counterclockwise with a flathead screwdriver. Lead the end of the metal strap through the back of the Base Station. Position the Base Station and wrap the metal strap around the pole.

  • Page 9: Power On

    Power On Connect the Base Station to a Power over Ethernet (PoE) adapter as follows: Connect the Ethernet cable from the Base Station to the POE port of the PoE adapter. Connect an Ethernet cable from your LAN device (a computer, router or switch) to the LAN port on the PoE adapter.

  • Page 10: Lightning And Esd Protection

    Lightning and ESD Protection Proper grounding is extremely important for outdoor devices. There are two effective techniques for grounding the Base Station. Option Use a shielded CAT5e (or above) cable with an integrated grounding wire for connection. Option If you have the standard CAT5e cable for the connection, use a separate grounding cable to connect the grounding Terminal (GND) to earth ground.

  • Page 11: Configuration With Pharos

    Configuration with PharOS Based on your network needs, this section will guide you through the Base Station configuration using PharOS, a web-based management system that allows you to do more specific configurations. Log in to the PharOS Before accessing the PharOS Web Interface, you need to assign a static IP address 192.168.0.X (X ranges between 2 and 253, e.g.

  • Page 12: Configure The Base Station

    Enter admin for both User Name and Password, then select the Language from the drop-down list. Read and agree the terms of use, then click Login. Change the default User Name and Password to protect your Base Station. Let’s start configuring the Base Staion. For subsequent logins, use the new username and password.
  • Page 13 Configure the Client 1. Log in to PharOS and go to the Quick Setup page. 2. Operation Mode: Select Client and click Next. 3. LAN Settings: Change the IP Address to 192.168.0.X (X ranges between 2 and 253), the same subnet with the access point, and click Next.

  • Page 14: Specification

    -30 ~ 70 (-22 ~158 ) ℃ ℃ ℉ ℉ Operating Humidity 10% ~ 90% Certi cation CE, FCC, RoHS, IP65 802.11 Standards 11b/g/n (WBS210) 11a/n (WBS510) 1. Estimation is based on copper grounding cable and shielded CAT5e(or above) cable with an integrated grounding wire.

  • Page 15: Faq

    Strength LEDs flash. What is Pharos MAXtream? Pharos MAXtream is a proprietary protocol developed on the basis of Time Division Multiple Access (TDMA) by TP-LINK. The MAXtream technology has the following advantages: Eliminates hidden node collisions & improves channel efficiency.
  • Page 16 How can I use Spectrum Analysis to find the appropriate channel for the devices? Log in to PharOS, click Spectrum Analysis in the tools drop-down list, a window will pop up to remind you that all wireless connections will be lost during spectrum analysis. Click Yes to continue to the Spectrum Analysis page.

  • Page 17: Fcc Statement

    FCC STATEMENT This equipment has been tested and found to comply with the limits for a Class A digital device, pursuant to part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference when the equipment is operated in a commercial environment. This equipment generates, uses, and can radiate radio frequency energy and, if not installed and used in accordance with the instruction manual, may cause harmful interference to radio communications.
  • Page 18 NCC Notice & BSMI Notice 注意！ 依據 低功率電波輻射性電機管理辦法 第十二條 經型式認證合格之低功率射頻電機，非經許可，公司、商號或使用者 均不得擅自變更頻率、加大功率或變更原設計之特性或功能。 第十四條 低功率射頻電機之使用不得影響飛航安全及干擾合法通行；經發現有 干擾現象時，應立即停用，並改善至無干擾時方得繼續使用。前項合法通信， 指依電信規定作業之無線電信。低功率射頻電機需忍受合法通信或工業、科學 以及醫療用電波輻射性電機設備之干擾。 減少電磁波影響，請妥適使用。 安全諮詢及注意事項 請使用原裝電源供應器或只能按照本產品注明的電源類型使用本產品。 ●清潔本產品之前請先拔掉電源線。請勿使用液體、噴霧清潔劑或濕布進行清潔。 ●注意防潮，請勿將水或其他液體潑灑到本產品上。 ●插槽與開口供通風使用，以確保本產品的操作可靠並防止過熱，請勿堵塞或覆 蓋開口。 ●請勿將本產品置放於靠近熱源的地方。除非有正常的通風，否則不可放在密閉 位置中。 ●請不要私自打開機殼，不要嘗試自行維修本產品，請由授權的專業人士進行此 項工作。 此為甲類資訊技術設備，于居住環境中使用時，可能會造成射頻擾動，在此種 情況下，使用者會被要求採取某些適當的對策。 This product can be used in the following countries: AT / BG / BY / CA / CZ / DE / DK / EE / ES / FI / FR / GB / GR / HU / IE / IT LT / LV / MT / NL / NO / PL / PT / RO / RU / SE / SG / SK / TR / UA / US...
