JBL EON515XT/230 Technical Manual

Technical Manual
JBL EON515XT/230

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• System Power Rating:
• Frequency Response:
• Frequency Range:
• Maximum SPL Output:
• Mic Input Gain:
• Line Input Gain
• Input Impedance:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Baffle/Grille Assembly:
• Low Frequency
Transducer:
• DC Resistance:
• High Frequency
Transducer:
• DC Resistance:
PACKAGE
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
625W (525 + 100)
42 Hz – 18 kHz (± 3 dB)
39 Hz – 20kHz (-10 dB)
132 dB
-Infinity to +40 dBu
-Infinity to +4 dBu (+18 dBu maximum
input level)
14k ohms
1.7 kHz
445873-001
265F-1 380 mm (15 in) Different-
ial Drive ® integated woofer with dual
2" voice coils
1.35 ohm ±10%
2414H 37.5 mm (1 in ) annular poly
mer diaphragm, neodymium com-
pression driver
3.60 ohm ± 0.2%
Warranty 59660
Owners Manual
445387-002
Filler, Side (2)
445385-001
Fillers, Top & Bottom (2)
44538-001
Bag
322591-001
19 x 16 x 42 LG
Outer Carton
445389-001
Carton
445386-001
Cord, AC, Line CEE 7/7
425-00000-00 120V
425-00000-01 230V
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test: 0.2V Input, 50 Hz to 20 kHz
B. L.F. Aural Sweep Test:
C. H.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, High Freq
2414H
(342423-002X)
- +
GRN/BLK
BLU
BLU/BLK
(SEE SCHEMATIC PAGE)
3.5V Input,10 Hz to 300 Hz
0.75V Input, 500 Hz to 1.5 kHz
673 x 406 x 368 mm D
(26.5 x 16 x 14.5 in D)
42.5 lbs. (19.2 kg)
Driver, Low Freq.
265F-1
(363837-001X)
Cone Repl
C2R265-1
- +
GRN
Amplifier Assembly
Wire Harness Assembly
364836-001
07-12
