JBL EON518S/230 Technical Manual

Technical Manual
JBL EON518S/230

SPECIFICATIONS

ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Systen Power Rating:
• Frequency Response:
• Frequency Range:
• Input Gain:
• Input Impedance:
• Maximum SPL:
• Crossover Frequency:
SYSTEM COMPONENTS:
• Cabinet
• Baffle/Grille Assembly:
• Low Frequency
Transducer:
• DC Resistance:
• Input Connectors:
PACKAGE
Top / Bottom Inner, (2)
364817-001
PKG, Microfoam
49790P
20" x18" sheets
Carton
364816-001
Cord, AC, Line
425-00000-00 120V
425-00000-01 230V
JBL Incorporated, 8500 Balboa Boulevard, P.O. Box 2200, Northridge, California 91329 U.S.A.
500W continuous, 1000W peak
42 Hz –100 Hz (±3 dB)
36 Hz -130 Hz (-10 dB)
- infinity to +4 dBu
Nominal 20K ohms (balanced)
129 dB, 1 watt @ 1 meter
120 Hz (HPF switchable on outputs)
Enclosure (Not for Sale)
441958-001
268G, 460 mm (18 in) Differential
Drive® integated woofer with dual
voice coils, 4 ohm impedance
2.60 ohm ±10%
Balanced XLRs with loop through
Warranty 59660
Owner's Manual
364822-001
(Available on
web-site only)
SYSTEM COMPONENTS:
(CONT'D)
• XLR Pin Assignments:
• Suspension/ Mounting:
AURAL SWEEP TEST SPECIFICATIONS:
A. System Aural Sweep Test:
B. L.F. Aural Sweep Test:
PHYSICAL SPECIFICATIONS:
• Enclosure Dimensions:
• Shipping Weight:
WARRANTY INFORMATION:
• Refer to Warranty Statement packed with each product.
WIRING DIAGRAM
Driver, Low Freq.
268G
(364481-001X)
Cone Repl
C4R268
-
BLK
Amplifier Assembly
(stereo) to balance XLR satellite
outputs. 1/4" Speaker level input
Pin 2 (+), Pin 3 (-), Pin 1 (GND)
36 mm pole socket on the top
500mV Input, 20 Hz to 500 Hz
Sweep Duration: 5 seconds
3.5V Input, 10 Hz to 300 Hz
617 x 569 x 652 mm D
(24.3 x 22.4 x 25.7 in D)
65 lb (29.5 kg.)
+
RED
12-12
