SERVICE MANUAL
Servicing should be performed by only trained and qualified service personnel.
Contents
Safety Instructions . . . . . . . . . . . . . . . . . . 2
Service Adjustments . . . . . . . . . . . . . 3 - 4
Power Failure Circuit . . . . . . . . . . . . . . . . 5
Mechanical Disassemblies . . . . . . . . . 6 - 7
Chassis Electrical Parts List . . . . . . . 8 - 23
Cabinet Parts List . . . . . . . . . . . . . . . . . . 24
Locations . . . . . . . . . . . . . . . . . . . 25 - 26
Troubleshooting Flow Charts . . . . . 38 - 40
Control Port Functions . . . . . . . . . . 41 - 42
Schematic Notes . . . . . . . . . . . . . . . . . . . 43
Pin Layouts. . . . . . . . . . . . . . . . . . . . . . . . 44
Capacitor and Resistor Codes . . . . . . . . 45
Schematic Diagrams . . . . . . . . . . . . 48 - 49
DP37647, N4PH, PRODUCT CODE 113004304
with a double "Z" is a registered trademark
of Sanyo Manufacturing Corporation.
Remote Control Digital
Color Television
FILE NO.
DP37647
ORIGINAL VERSION
Chassis No. P37647-04
NOTE: Match the Chassis No. on
the unit's back cover with
the Chassis No. in the
Service Manual.
If the Original Version
Service Manual Chassis
No. does not match the
unit's, additional Service
Literature is required. You
must refer to "Notices" to the
Original Service Manual
prior to servicing the unit.

Specifications

Power Rating . . . . . . . . . . . . . . . . . . . . . . . . 120VAC
Antenna Input Impedance . . . . . . . . . . . . . . . . . 75Ω
Receiving Channel . . . . . . . . . . . . . . . . 2 - 13 (VHF),
01, 14-94, 95-125 (CATV)
Remote Ready . . . . . . . . . . 32 Key Remote Control
Sound Output . . . . . . . . . . . . . . . . . . . . . . 5.0 W/CH
Intermediate Frequency
Picture IF Carrier . . . . . . . . . . . . . . . . . . 45.75MHz
Sound IF Carrier . . . . . . . . . . . . . . . . . . 41.25MHz
Color Sub Carrier . . . . . . . . . . . . . . . . . 42.17MHz
Cabinet Dimensions
Width . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 939mm
Height . . . . . . . . . . . . . . . . . . . . . . . . . . . . 697mm
Depth including base . . . . . . . . . . . . . . . . 219mm
REFERENCE No.
(U.S.A.)
(CANADA)
175W, 1.7A (Max)
UHF/VHF/CATV
Digital
14 - 69 (UHF),
1-99 (Digital)
SM
780156-01
