User Guide
Software Requirements:
1. Pentium Processor 100 MHz or higher
2. 16 MB RAM
3. Windows 95 OSR2.0 or OSR2.1 with USB Support Installed, Win98
4. Sound card
5. USB host hub connector
6. 8 MB disk space
System Checks:
1. Verify that you have a USB port. This port will be located on the back of your PC.
a. See Figure 1. Note your PC may have only one USB port
2. If a USB port is not supplied then you can not use the Audio Management Software to control your ADA305
speaker system, although you can still use the ADA305 speaker system to hear exceptional quality sound.

Software Installation:

1. Start Windows.
2. Insert the ADA305 Installation CD into your CD-ROM drive.
3. Connect the "Square" end of the USB Cable to the ADA305 subwoofer.
4. Connect the "Flat" end of the USB Cable to the PC's USB port.
5. Windows should display "New hardware found" message.
6. If Windows does not display the New hardware found message, please do the following.
a. Type x:\Setup.exe where x: is you CD-ROM drive letter.
i)
Right click on "My Computer."
ii) Select "Properties" from the Popup Menu.
ii) Click the Device Manager Tab
ii) Locate the item "Universal serial bus controller."
1. If you are using Windows 95 OSR2.0 or higher and can not locate this item, you need to install the
USB supplement. If you do not have the USB supplement, you may be able to obtain it from your system
manuafacturer. If you are unable to obtain the USB supplement, you may upgrade to Windows 98
which includes support for USB peripherals.
2. If you are using Windows 98, then Windows 98 is not installed correctly or you may need to contact
your system manufacturer about enabling the USB ports on your system.
b. Click Ok.
c. Follow the on screen prompts.
d. The PC should restart, upon restarting you should receive the New hardware found message,
then continue with step 7.
Altec Lansing
Computer Speaker System
ADA305 — Version 1.30
GUI (Graphic User Interface)
Installation/User Manual
USB Port 1
USB Port 2
Figure 1
