CDX-R3300/R3300T
SERVICE MANUAL
Ver 1.0 2003. 12
• The tuner and CD sections have no adjustments.
CD player section
Signal-to-noise ratio
120 dB
Frequency response
10 – 20,000 Hz
Wow and flutter
Below measurable limit
Tuner section
FM
Tuning range
87.5 – 108.0 MHz
Aerial terminal
External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Usable sensitivity
9 dBf
Selectivity
75 dB at 400 kHz
Signal-to-noise ratio
67 dB (stereo),
69 dB (mono)
Harmonic distortion at 1 kHz
0.5% (stereo),
0.3% (mono)
Separation
35 dB at 1 kHz
Frequency response
30 – 15,000 Hz
MW/LW (CDX-R3300)
Tuning range
MW: 531 – 1,602 kHz
LW: 153 – 279 kHz
Aerial terminal
External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity
MW: 30 µV
LW: 40 µV
AM (CDX-R3300T)
Tuning range
531 – 1,602 kHz
Aerial terminal
External aerial connector
Intermediate frequency 10.7 MHz/450 kHz
Sensitivity
AM: 30 µV
Sony Corporation
9-961-432-01
2003L04-1
e Vehicle Company
© 2003. 12
Published by Sony Engineering Corporation
Photo: CDX-R3300
Model Name Using Similar Mechanism
CD Drive Mechanism Type
Optical Pick-up Name
SPECIFICATIONS
Power amplifier section
Outputs
Speaker impedance
Maximum power output 50 W × 4 (at 4 ohms) (CDX-R3300)
General
Outputs
Inputs
Tone controls
FM/MW/LW COMPACT DISC PLAYER
FM/AM COMPACT DISC PLAYER
AEP Model
UK Model
E Model
NEW
MG-611MA-186//Q
KSS1000E
Speaker outputs
(sure seal connectors)
4 – 8 ohms
52 W × 4 (at 4 ohms) (CDX-R3300T)
Audio outputs terminal
(rear/sub switchable)
Power aerial relay control terminal
Power amplifier control terminal
Telephone ATT control terminal (CDX-R3300)
Remote controller input terminal
Aerial input terminal
Low: ±10 dB at 60 Hz (XPLOD)
Mid: ±10 dB at 1 kHz (XPLOD)
High: ±10 dB at 10 kHz (XPLOD)
– Continued on next page –
CDX-R3300
CDX-R3300T
CDX-R3300
CDX-R3300T
1
