Ford 2002 Excursion Owner's Manual page 206

Roadside emergencies
Fuse/Relay
Location
40
41
42
43
44
45
46
47
48
101
102
103
104
105
106
107
108
109
110
111
112
113
114
115
116
601
602
210
211
212
206
Fuse Amp Passenger Compartment Fuse
Rating
20A* Fuel pump
10A* Instrument cluster
15A* Delayed accessory
10A* Fog lamps
10A* PATS module, transceiver
10A* Ignition switch Run/ Start feed
10A* Left-hand lowbeam
10A* Right-hand lowbeam
10A* Rear wiper motor
30A** Trailer tow electric brake
30A** Door locks/Body security module
50A** Ignition switch
40A** Heated backlite
30A** Injector driver module
30A** Front wiper main
40A** Front blower motor
40A** Auxiliary blower motor
30A** Heated seats
50A** Ignition switch
30A** 4WD/Shift on the fly
30A** Left-hand power seats
30A** Starter motor
30A** Right-hand power seats
20A** Trailer tow battery charge
30A** Ignition switch
30A** Door window motors
60A** 4-Wheel Anti-Lock Brake System
(4WABS) module
— Not used
— Not used
— Not used
Panel Description
