Page 2: Table Of Contents
Table of contents Introduction Congratulations Safety and environment protection Symbol glossary Instrument cluster Warning and control lights Gauges Entertainment systems AM/FM stereo cassette (CD changer compatible) AM/FM stereo with CD Rear seat controls CD changer Climate controls Manual heating and air conditioning Electronic automatic temperature control Lights Headlamps...
Page 3 Table of contents Seating and safety restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Transmission operation Vehicle loading Trailer towing Recreational towing Roadside emergencies Hazard flasher switch Fuses and relays Changing tires Jump starting Wrecker towing Customer assistance The dispute settlement board Utilizing the mediation/arbitration Getting assistance outside the U.S.
Page 5: Introduction
State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 6: Safety And Environment Protection
Introduction Fuel pump shut-off switch In the event of an accident the safety switch will automatically cut off the fuel supply to the engine. The switch can also be activated through sudden vibration (e.g. collision when parking). To reset the switch, refer to the Fuel pump shut-off switch in the Roadside emergencies chapter.
Page 7 Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 8 Do not use this vehicle for snowplowing. Using your vehicle as an ambulance Do not use this vehicle as an ambulance. Your vehicle is not equipped with the Ford Ambulance Preparation Package. Notice to owners of pickup trucks and utility type vehicles Utility vehicles have a significantly higher rollover rate than other types of vehicles.
Page 9: Symbol Glossary
Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Tether Warning Anchorage Brake System Anti-Lock Brake System Brake Fluid - Traction Control...
Page 10 Introduction Vehicle Symbol Glossary Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid Power Steering Fluid Level Emission System...
Page 11: Instrument Cluster
Instrument cluster WARNING LIGHTS AND CHIMES DOOR THEFT AJAR RPMX1000 RANGE FUEL SELECT/RESET SERVICE km/h SUSP ENGINE SOON P RN BRAKE CRUISE FUEL DOOR Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions.
Page 12 Instrument cluster If the light remains on, have your vehicle serviced at the first available opportunity. Light is blinking: Engine misfire is occurring which could damage your catalytic converter. You should drive in a moderate fashion (avoid heavy acceleration and deceleration) and have your vehicle serviced at the first available opportunity.
Page 13 Instrument cluster Air bag readiness Illuminates to confirm that the air bags (front or side) are operational. If the light fails to illuminate, continues to flash or remains on, have the system serviced immediately. Charging system Illuminates when the battery is not charging properly.
Page 14 Instrument cluster Oil pressure/Engine coolant Illuminates when the engine coolant temperature is above the normal range or the engine oil pressure is below normal range. Check the engine oil and coolant level refer to Adding engine oil and Adding coolant in the Maintenance and specifications chapter.
Page 15: Gauges
Instrument cluster Four wheel drive low (if equipped) Illuminates when four-wheel drive low is is engaged. If the light RANGE continues to flash have the system serviced. Four wheel drive indicator (if equipped) Illuminates when the four-wheel drive is engaged. If the light continues to flash have the system serviced.
Page 16 Instrument cluster Engine coolant temperature gauge Indicates the temperature of the engine coolant. At normal operating temperature, the needle remains within the normal area (the area between the “H” and “C”). If it enters the red section, the engine is overheating.
Page 17 Instrument cluster Battery voltage gauge Indicates battery voltage. If the pointer moves and stays outside the normal operating range (as indicated by the arrows), have the vehicle’s electrical system checked as soon as possible. Fuel gauge Displays approximately how much fuel is in the fuel tank.
Page 18 Instrument cluster Odometer Registers the total kilometers (miles) of the vehicle. Trip odometer Registers the kilometers (miles) of individual journeys. Press and release the reset button until a “T” P RN appears in the display (this represents the trip mode). Press and hold the button for three seconds to reset.
Page 19: Entertainment Systems
Entertainment systems PREMIUM AM/FM STEREO/CASSETTE (CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE SEEK TUNE SCAN AUTO MUTE SIDE 1 . 2 COMP SHUFF AUDIOPHILE AM/FM STEREO/CASSETTE (CD CHANGER COMPATIBLE) BASS TREB FADE PUSH ON TAPE TUNE SEEK SCAN AUTO MUTE SIDE 1 .
Page 20 Entertainment systems Your audio system is equipped with selective lighting, a unique lighting strategy. This lighting feature is operable when the headlamps are illuminated. During the operation of any selected mode, lighting for the individual function controls will either illuminate or turn off. Those controls which have a function for the specific mode of operation selected will be lit, while the controls which have no function for that mode will be turned off.
Page 21 Entertainment systems • to increase volume compensation • to decrease or shut off the volume compensation Bass adjust The bass adjust control allows you to increase or decrease the audio BASS system’s bass output. Press the BASS control. Use the TREB SEL control to increase or decrease the amount of bass.
Page 22 Entertainment systems Speaker fade adjust Speaker sound can be adjusted between the front and rear speakers. Press the FADE control. Use the FADE SEL control to adjust the sound between the front and rear speakers. Seek function The seek function control works in radio, tape or CD mode (if equipped).
Page 23 Entertainment systems Scan function The scan function works in radio, tape or CD mode (if equipped). SCAN Scan function in radio mode Press the SCAN control to activate scan mode and to hear a brief sampling of all listenable stations on the frequency band. Press the SCAN control again to disengage scan mode.
Page 24 Entertainment systems AM/FM select in CD mode Press this control to stop CD play and begin radio play. Radio station memory preset The radio is equipped with six station memory preset controls. These controls can be used to select up to six preset AM stations and twelve FM stations (six in FM1 and six in FM2).
Page 25 Entertainment systems Setting the clock with radio data system (RDS) feature Press the RDS control until SELECT HOUR or SELECT MINS is displayed. Use the SEL control to manually set the time. • Press to increase hours/minutes. • Press to decrease hours/minutes.
Page 26 Entertainment systems Tape/CD select • To begin tape play (with a tape TAPE loaded into the audio system) while in the radio or CD mode, press the TAPE control. Press the button during rewind or fast forward to stop the rewind or fast forward function.
Page 27 Entertainment systems Tape direction select Press SIDE 1–2 to play the alternate SIDE 1-2 side of a tape. Eject function Press the control to stop and eject a tape. Dolby noise reduction Dolby noise reduction operates only in tape mode. Dolby noise reduction reduces the amount of hiss and static during tape playback.
Page 28 Entertainment systems Shuffle feature The shuffle feature operates in CD SHUFF mode and plays all tracks on the current disc in random order. If equipped with the CD changer, the shuffle feature continues to the next disc after all tracks are played. Press the SHUFFLE control to start this feature.
Page 29 Entertainment systems • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data). Traffic information is not available in most U.S. markets. Program type •...
Page 30 Entertainment systems • Use the SEL control to select TYPE (the display shows the program type), NAME (the display shows the call letters of the station) or NONE. Digital signal processing (if equipped) The digital signal processing (DSP) feature allows you to change the signal mode to suit your listening tastes.
Page 31: Am/Fm Stereo With Cd
Entertainment systems Use the SELECT control to change the equalization to the desired mode. PREMIUM AM/FM STEREO/SINGLE CD RADIO BASS TREB FADE PUSH ON TUNE AUTO SEEK SCAN MUTE COMP SHUFF Your audio system is equipped with selective lighting, a unique lighting strategy.
Page 32 Entertainment systems Volume/power control Press the control to turn the audio system on or off. Turn the control to raise or lower volume. PUSH ON If the volume is set above a certain level and the ignition is turned off, the volume will come back on at a “nominal”...
Page 33 Entertainment systems • to increase volume compensation • to decrease or shut off the volume compensation Bass adjust The bass adjust control allows you to increase or decrease the audio BASS system’s bass output. TREB Treble adjust The treble adjust control allows you to increase or decrease the audio BASS system’s treble output.
Page 34 Entertainment systems Seek function The seek function control works in radio, CD and CD changer mode (if equipped). Seek function in radio mode • Press to find the next SEEK listenable station down the frequency band. • Press to find the next listenable station up the frequency band. Seek function for CD or CD changer (if equipped) •...
Page 35 Entertainment systems AM/FM select The AM/FM select control works in radio, tape and CD changer modes (if equipped). AM/FM select in radio mode This control allows you to select AM or FM frequency bands. Press the control to switch between AM, FM1 or FM2 memory preset stations. AM/FM select in CD or CD changer mode (if equipped) Press this control to stop CD play and begin radio play.
Page 36 Entertainment systems Starting autoset memory preset 1. Select a frequency using the AM/FM select controls. 2. Press the AUTO control. AUTO 3. When the first six strong stations are filled, the station stored in memory preset control 1 will start playing.
Page 37 Entertainment systems Tune adjust for CD changer • Press to select the previous TUNE disc in the CD changer. (Play will begin on the first track of the disc unless the CD changer is in shuffle mode.) Refer to Shuffle feature for more information.
Page 38 Entertainment systems Compression feature (if equipped) Compression adjust brings soft and COMP loud CD passages together for a more consistent listening level. Press the COMP control to activate and deactivate compression adjust. Shuffle feature (if equipped) The shuffle feature operates in CD SHUFF changer mode and plays all tracks on the current disc in random order.
Page 39 Entertainment systems Traffic • Press the RDS control until TRAFFIC is displayed. • Use the SEL control to select ON or OFF. With the feature on, use the SEEK or SCAN control to find a radio station broadcasting a traffic report (if it is broadcasting RDS data).
Page 40: Rear Seat Controls
Entertainment systems Show • With RDS activated, press the RDS control until SHOW is displayed. • Use the SEL control to select TYPE, NAME or NONE. REAR SEAT CONTROLS (IF EQUIPPED) The Personal Audio System, allows - VOLUME + front and middle seat passengers to MODE listen to different media sources (radio, cassette or CD)
Page 41 Entertainment systems To activate the Personal Audio - VOLUME + System, press the MODE speaker/headphone control. Press the MODE control to change audio sources (for headphone mode only). SEEK MEMORY Use the SEEK, VOLUME and MEMORY controls to make adjustments to the playing media. ADJUSTING THE VOLUME Press the + control to increase - VOLUME +...
Page 42 Entertainment systems USING HEADPHONES/PERSONAL AUDIO SYSTEM Plug a 3.5 mm headphone (not included) into the jack. Press the speaker on/off control to operate the headphones. DUAL PLAY illuminates in the radio display and the fade control is disabled. The rear speakers will cut out once the speaker on/off control is pressed. The front speaker will remain playing for the front passengers.
Page 43: Cd Changer
Entertainment systems SEEK FUNCTION • In radio mode, press to find - VOLUME + the next listenable station down MODE the frequency band. • In radio mode, press to find SEEK MEMORY the next listenable station up the frequency band. •...
Page 44 Entertainment systems 1. Pull the lever to remove a CD tray from the magazine. 2. Insert one disc into each CD tray of the magazine (up to 6 discs). Ensure that the label side is facing If you pull too hard on the disc holder, the disc holder may come completely out of the magazine.
Page 45 Entertainment systems 5. Slide the door to the left to close. Use only compact discs containing this mark. The magazine does not need to be full for the changer to operate. Radio power must be turned on to play the CDs in the changer. The magazine may be stored in the glove compartment when not being used.
Page 46 Entertainment systems CLEANING COMPACT DISCS Inspect all discs for contamination before playing. If necessary, clean discs only with an approved CD cleaner and wipe from the center out to the edge. Do not use circular motion. CD AND CD CHANGER CARE •...
Page 47 Entertainment systems RADIO FREQUENCY INFORMATION The Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission(CRTC) establish the frequencies AM and FM stations may use for their broadcasts. Allowable frequencies are: AM 530, 540–1600, 1610 kHz FM 87.7, 87.9–107.7, 107.9 MHz Not all frequencies are used in a given area.
Page 48: Climate Controls
Climate controls MANUAL HEATING AND AIR CONDITIONING SYSTEM (IF EQUIPPED) PANEL COOL WARM Fan speed control Controls the volume of air circulated in the vehicle. Temperature control knob Controls the temperature of the airflow inside the vehicle. COOL WARM Mode Selector Control Controls the direction of the airflow PANEL to the inside of the vehicle.
Page 49 Climate controls • A/C – Uses outside air to cool the vehicle. It is quieter than MAX A/C but not as economical. Airflow will be from the instrument panel registers. • PANEL – Distributes outside air through the instrument panel registers.
Page 50 Climate controls • To reduce humidity buildup inside the vehicle in cold weather conditions, don’t drive with the climate control system in the OFF or MAX A/C position. • To reduce humidity buildup inside the vehicle in warm weather conditions, don’t drive with the climate control system in the OFF position.
Page 51: Electronic Automatic Temperature Control
Climate controls Do not place objects on top of the instrument panel as these objects may become projectiles in a collision or sudden stop. ELECTRONIC AUTOMATIC TEMPERATURE CONTROL (EATC) SYSTEM (IF EQUIPPED) The EATC system will maintain a selected temperature and AUTO automatically control airflow.
Page 52 Climate controls When in AUTOMATIC and weather conditions require heat, air will be sent to the floor. However, if the engine is not warm enough to provide heat, the fan will be at a low speed and the air will be directed to the windshield.
Page 53 Climate controls Temperature conversion Press MAX A/C and DEF the same time (for one second) to AUTO switch between Fahrenheit and OUTSIDE TEMP AUTOMATIC Celsius. MAX A/C VENT PNL • FLR FLOOR FLR • DEF The English/Metric (E/M) control on the trip computer and message center (if equipped) will not change temperature display.
Page 54 Climate controls • MAX A/C-Uses recirculated air to cool the vehicle. The temperature will display 16°C (60°F). To exit, press AUTOMATIC or any other override controls. MAX A/C is louder than normal A/C but more economical and will cool the inside of the vehicle faster. Airflow is from the instrument panel registers.
Page 55 Climate controls Displaying outside temperature Press OUTSIDE TEMP to display the outside air temperature. It will be displayed until OUTSIDE TEMP is pressed again. OUTSIDE TEMP MAX A/C VENT PNL • FLR If the selected temperature is changed while the outside temperature is displayed, the new temperature will be displayed for four seconds after it is changed, then the outside temperature will return to the window.
Page 56 Climate controls • Under snowy or dirty weather conditions, your vehicle’s climate control system should be left in the OFF position when the vehicle is parked. This allows the climate control system to be free from contamination of outside pollutants. •...
Page 57 Climate controls temperature in the rear of the vehicle through a second control panel above the second row, or in the floor console. If your vehicle is equipped with auxiliary A/C controls, they may be located in the floor console, or located in the overhead console.
Page 58 Climate controls In order for the auxiliary A/C-heater controls (if equipped) to function, REAR the driver’s auxiliary A/C-heater control must be set to REAR, unless COOL WARM PANEL FLOOR your vehicle is equipped with a moonroof and a navigation system. In which case, the rear auxiliary A/C-heater control console serves as the main control for the auxiliary climate control system.
Page 59 Climate controls REAR WINDOW DEFROSTER The rear defroster control is located on the instrument panel. Press the rear defroster control to clear the rear window of thin ice and fog. • A small LED will illuminate when the rear defroster is activated. The ignition must be in the ON position to operate the rear window defroster.
Page 60: Lights
Lights HEADLAMP CONTROL Rotate the headlamp control to the first position to turn on the parking lamps. Rotate to the second position to also turn on the headlamps. Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on only when the headlamp control is in the position and...
Page 61 Lights Daytime running lamps (DRL) (if equipped) Turns the headlamps on with a reduced output. To activate: • the ignition must be in the ON position and • the headlamp control is in the OFF or Parking lamps position. Always remember to turn on your headlamps at dusk or during inclement weather.
Page 62 Lights AIMING THE HEADLAMPS The headlamps on your vehicle are properly aimed at the assembly plant. If your vehicle has been in an accident the alignment of your headlamps should be checked by a qualified service technician. TURN SIGNAL CONTROL •...
Page 63: Headlamps
Lights Without trip computer AUTO ROOF To turn on the map lamps, press the control next to each lamp. Rear dome lamp The dome lamp lights when: • any door is opened. • the instrument panel dimmer switch is held up until the courtesy lamps come on.
Page 64 Lights • License plate lamp • Tail lamps • Back-up lamps Do not remove lamp bulbs unless they can be replaced immediately with new ones. If a bulb is removed for an extended period of time, contaminants may enter the lamp housings and affect lamp performance. Using the right bulbs Replacement bulbs are specified in the chart below.
Page 65 Lights Replacing the interior bulbs Check the operation of the following interior bulbs frequently: • interior overhead lamp • map lamp For bulb replacement, see a dealer or qualified technician. Map lamps To change the map lamp bulbs: 1. Use a small screwdriver to remove the map lamp lens.
Page 66 Lights 5. Disconnect the electrical connector from the bulb by pulling rearward. 6. Remove bulb retainer ring by turning it counterclockwise, then slide the ring off the plastic base. 7. Without turning, carefully pull bulb assembly out of headlamp assembly. Handle a halogen headlamp bulb carefully and keep out of children’s reach.
Page 67 Lights Replacing front parking lamp/turn signal bulbs 1. Make sure that the headlamp control is in the OFF position. 2. Open the hood. 3. Remove the screw and lamp assembly from the vehicle. 4. Rotate the bulb socket counterclockwise and remove from the lamp assembly.
Page 68 Lights Replacing foglamp bulbs 1. Remove the bulb socket from the foglamp by turning counterclockwise. 2. Disconnect the electrical connector from the foglamp bulb. 3. Connect the new foglamp bulb to the electrical connector. 4. Install the bulb socket in the foglamp turning clockwise. Replacing running board lamp bulbs For bulb replacement, see a dealer or qualified technician.
Page 69 Lights Replacing license plate lamp bulbs The license plate bulbs are located behind the rear bumper. To change the license plate lamp bulbs: 1. Reach behind the rear bumper to locate the bulb. 2. Twist the bulb socket counterclockwise and carefully pull to remove it from the lamp assembly.
Page 70: Driver Controls
Driver controls WINDSHIELD WIPER/WASHER CONTROLS Rotate the windshield wiper control to the desired interval, low or high speed position. The bars of varying length are for intermittent wipers. When in this position rotate the control upward for fast intervals and downward for slow intervals.
Page 71 Driver controls Windshield wiper blades Check the wiper blades at least twice a year or when they seem less effective. Substances such as tree sap and some hot wax treatments used by commercial car washes reduce the effectiveness of wiper blades. Checking the wiper blades If the wiper blades do not wipe properly, clean both the windshield and wiper blades using undiluted windshield wiper solution or a mild...
Page 72: Steering Wheel Adjustment
Driver controls TILT STEERING Pull the tilt steering control toward you to move the steering wheel up or down. Hold the control while adjusting the wheel to the desired position, then release the control. Never adjust the steering wheel when the vehicle is moving. ILLUMINATED VISOR MIRROR (IF EQUIPPED) To turn on the visor mirror lamps, lift the mirror cover open.
Page 73 Driver controls Forward storage bin (if equipped) Press the release control to open the storage compartment. The door will open slightly and can be moved to full open. The storage compartment may be used to secure sunglasses or a similar object. Installing a garage door opener (if equipped) The storage compartment can be converted to accommodate a variety of aftermarket garage door openers:...
Page 74 Driver controls One-touch moon roof (if equipped) With trip computer ROOF VENT VENT Without trip computer AUTO ROOF • Press and release the rear portion of the moon roof control to open. • Press and hold (as desired) the front portion of the moon roof control to close.
Page 75 Driver controls Trip computer For information on the trip computer, refer to Trip computer this chapter. Electronic compass (if equipped) The compass reading may be affected when you drive near large buildings, bridges, power lines and powerful broadcast antennas. Magnetic or metallic objects placed in, on or near the vehicle may also affect compass accuracy.
Page 76 Driver controls Compass zone adjustment 1. Determine which magnetic zone you are in for your geographic location by referring to the zone map. With trip computer 2. Locate the compass module mounted on the center rear view mirror post. 3. Turn ignition to the ON position. 4.
Page 77 Driver controls Without trip computer 1. Press and hold the SELECT control until VAR appears in the display, then release. The display should show the current zone AUTO number. ROOF 2. Press the SELECT control until the desired zone number appears. The display will flash and then return to normal operation.
Page 78 Driver controls Without trip computer 1. Press and hold the SELECT control until CAL appears in the display (approximately eight seconds) and release. AUTO ROOF 2. Drive the vehicle slowly (less than 5 km/h [3 mph]) in circles until CAL indicator turns off in about 2–3 complete circles.
Page 79 Driver controls Press the portion of the VENT control to open the power rear quarter windows. Press the portion of the VENT control to close the power rear quarter windows. AUXILIARY POWER POINT Power outlets are designed for accessory plugs only. Do not hang any type of accessory or accessory bracket from the plug.
Page 80: Power Windows
Driver controls POWER WINDOWS Press and hold the rocker switches to open and close windows. • Press the top portion of the rocker switch to close. AUTO • Press the bottom portion of the rocker switch to open. AUTO One touch down •...
Page 81: Mirrors
Driver controls Window lock The window lock feature allows only the driver to operate the power windows. To lock out all the window controls WINDOW LOCK except for the driver’s press the left side of the control. Press the right side to restore the window controls. Accessory delay With accessory delay, the window switches may be used for up to ten minutes after the ignition switch is turned to the OFF position or until...
Page 82 Driver controls 1. Select L to adjust the left mirror or R to adjust the right mirror. MIRRORS 2. Move the control in the direction you wish to tilt the mirror. MIRRORS 3. Return to the center position to lock mirrors in place. 4.
Page 83 Driver controls Signal mirrors (if equipped) When the turn signal is activated, the outer portion of the appropriate mirror housing will blink red. This provides an additional warning to other drivers that your vehicle is about to turn. Fold-away mirrors Pull the side mirrors in carefully when driving through a narrow space, like an automatic car wash.
Page 84 Driver controls SPEED CONTROL To turn speed control on • Press ON. Vehicle speed cannot be controlled until the vehicle is traveling at or above 48 km/h (30 mph). Do not shift the gearshift lever into N (Neutral) with the speed control on.
Page 85 Driver controls If you drive up or down a steep hill, your vehicle speed may vary momentarily slower or faster than the set speed. This is normal. Speed control cannot reduce the vehicle speed if it increases above the set speed on a downhill. If your vehicle speed is faster than the set speed while driving on a downhill, you may want to shift to the next lower gear or apply the brakes to reduce your vehicle speed.
Page 86 Driver controls To set a lower set speed • Press and hold COAST. Release the control when the desired speed is reached or • Press and release COAST to operate the Tap-Down function. Each press will decrease the set speed by 1.6 km/h (1 mph) or •...
Page 87 Driver controls Pressing OFF will erase the previously programmed set speed. To return to a previously set speed • Press RES. For RES to operate, the vehicle speed must be faster than 48 km/h (30 mph). Indicator light This light comes on when either the SET ACCEL or RES controls are pressed.
Page 88 Driver controls When programming your HomeLink Universal Transceiver, to a garage door or gate be sure that people and objects are out of the way to prevent potential harm or damage. Do not use the HomeLink Universal Transceiver with any garage door opener that lacks safety stop and reverse features as required by U.S.
Page 89 Driver controls If you do not successfully program the HomeLink Universal Transceiver after repeated attempts, refer to Rolling code programing which follows, or call toll-free customer assistance: 1–800–355–3515 or on the Internet at HomeLink.jci.com. Canadian Programming During programming, your hand-held transmitter may automatically stop transmitting after two seconds which may not be long enough to program the HomeLink Universal Transceiver.
Page 90 Driver controls After completing the “Programming” functions, follow these steps to train a garage door opener with the rolling code feature: 1. Locate the training button on the garage door motor head unit. Refer to the garage door opener manual or call 1–800–355–3515 or on the Internet at HomeLink.jci.com.
Page 91 Driver controls 2. When the indicator light begins to flash slowly (after 20 seconds), position the hand-held transmitter 5–14 cm (2 to 5 inches) away from the HomeLink surface. 3. Press and hold the hand-held transmitter button. 4. The HomeLink indicator light will flash, first slowly and then rapidly. When the indicator light begins to flash rapidly, release both buttons.
Page 92 Driver controls Mode control Each press of the MODE control will display a different feature as follows: Fuel range. This displays the approximate number of kilometers (miles) left to drive before the fuel tank is empty. The indicated distance to empty may be inaccurate: •...
Page 93 Driver controls OVERDRIVE CONTROL Activating overdrive (Overdrive) is the normal drive position for the best fuel economy. The overdrive function allows automatic upshifts and downshifts through all available gears. Deactivating overdrive Press the Transmission Control Switch (TCS) located on the end of OVERDRIVE the gearshift lever.
Page 94 Driver controls Use only soft cups in the cupholder. Hard objects can injure you in a collision. Rear center console features (if equipped) The rear center console incorporates the following features: • utility compartment • cupholders POSITIVE RETENTION FLOOR MAT (IF EQUIPPED) Position the floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to...
Page 95 Driver controls Make sure that the liftgate door and/or window are closed to prevent exhaust fumes from being drawn into the vehicle. This will also prevent passengers and cargo from falling out. If you must drive with the liftgate door or window open, keep the vents open so outside air comes into the vehicle.
Page 96: Locks And Security
Locks and security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency. Refer to SecuriLock Passive Anti-Theft System for more...
Page 97: Anti-Theft System
Locks and security REMOTE ENTRY SYSTEM This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 98 Locks and security Locking the doors Press this control to lock all doors. The doors will lock and the lamps will flash. To confirm doors are closed and locked, press this control a second time within three seconds. The door(s) will lock again, the horn will chirp once and the lamps will flash.
Page 99 Locks and security Sounding a panic alarm Press this control to activate the alarm. To deactivate the alarm, press the control again or turn the ignition to ACC or ON. Panic alarm will only operate with the ignition in the OFF position. Replacing the battery The remote transmitter is powered by one coin type three-volt lithium battery CR2032 or equivalent.
Page 100 Locks and security Replacing lost transmitters If a remote transmitter has been lost and you would like to remove it from the vehicle’s memory, or you would like to purchase additional remote transmitters and have them programmed to your vehicle: •...
Page 101 Locks and security Illuminated entry The illuminated entry system will turn on the interior lights when the remote transmitter unlock control is pressed. The illuminated entry system will turn off the interior lights if the ignition switch is turned to the ON position, or if the remote transmitter lock control is pressed, or after 25 seconds of illumination.
Page 102 Locks and security 1. Turn the ignition key to ON. 2. Press the power door unlock control three times. 3. Turn the ignition key from ON to OFF. 4. Press the power door unlock control three times. 5. Turn the ignition back to ON. The horn will chirp. 6.
Page 103 Locks and security 6. Press the unlock control, then press the lock control. The horn will chirp once if autolock was deactivated or twice (one short and one long chirp) if autolock was activated. 7. Turn the ignition to OFF. The horn will chirp once to confirm the procedure is complete.
Page 104 Locks and security If you wish to erase your personal code, use the following instructions: 1. Enter factory set code. 2. Press 1/2 control within five seconds of step one. 7 8 9 0 3. Press 7/8 control and 9/0 control at the same time within five seconds of step 2.
Page 105 The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Automatic arming...
Page 106 Locks and security Automatic disarming Switching the ignition to the 4 (ON) position with a coded key disarms the vehicle. The light will illuminate for three seconds and then THEFT go out. If the light stays on for an extended period of time or THEFT flashes rapidly, have the system serviced by your dealership or a qualified technician.
Page 107 Locks and security If your keys are lost or stolen you will need to do the following: • Use your spare key to start the vehicle, or • Have your vehicle towed to a dealership or locksmith. The key codes will need to be erased from your vehicle and new key codes will need to be re-coded.
Page 108 Locks and security 1. Insert the first previously programmed coded key into the ignition and turn the ignition from 3 (OFF) to 4 (ON) (maintain ignition in 4 (ON) for at least one second). 2. Turn ignition to 3 (OFF) then 2 (LOCK) and remove the first coded key from the ignition.
Page 109: Seating And Safety Restraints
Seating and safety restraints SEATING Adjustable head restraints (if equipped) Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 110 Seating and safety restraints Lift handle to move seat forward or backward. Pull lever up to adjust seatback. 60/40 split bench seat (if equipped) • Lift the release bar to move the seat forward or backward. Ensure the seat is relatched into place. •...
Page 111 Seating and safety restraints Using the armrest (if equipped) Push the release control to move the armrest up or down. Using the manual lumbar support Turn the lumbar support control toward the front of vehicle to move the lumbar support forward for more direct support.
Page 112 Seating and safety restraints Reclining the seatback can reduce the effectiveness of the seat’s safety belt in the event of a collision. The control is located on the outboard side of the seat cushion. Press to raise or lower the front portion of the seat cushion.
Page 113 Seating and safety restraints Memory seats/rearview mirrors/adjustable pedals (if equipped) This system allows automatic positioning of the driver seat, outside rearview mirrors, and adjustable pedals to three programmable positions. The memory seat control is located on the driver door. • To program position one, move the driver seat to the desired position using the seat controls.
Page 114 Seating and safety restraints REAR SEATS Adjustable head restraints Your vehicle’s seats may be equipped with head restraints which are vertically adjustable. The purpose of these head restraints is to help limit head motion in the event of a rear collision. To properly adjust your head restraints, lift the head restraint so that it is located directly behind your head or as close to that position as possible.
Page 115 Seating and safety restraints 3. Press the green control on the seatback to release the closeout panel. Rotate the panel to closeout the space in the floor. 4. Once the second row seats are in the down position, the front seats may be readjusted.
Page 116 Seating and safety restraints Reclining the seatback Locate the lever at the bottom of the seatback that reads “FOLD FLAT OR RECLINE”. Pull the lever upwards to recline the seatback. Third row seat The third row seat is equipped with combination lap and shoulder belts in the outboard seating positions and a manual adjust tongue lap belt in the center seating position.
Page 117 Seating and safety restraints To minimize the risk of personal injury, the third row seat should not be left in the forward, stowed position while the vehicle is in motion. Please ensure that the seat is in the upright, fully latched position before putting the vehicle in motion.
Page 118 Seating and safety restraints 2. Before removing the seat, be sure that the detachable anchor tongue is stowed flat into the vehicle floor. 3. Use the black plastic clip (located just above the detachable anchor) to stow the loose seat belt. •...
Page 119 Seating and safety restraints Installing the third row seat Always latch the vehicle seat to the floor, whether the seat is occupied or empty. If not latched, the seat may cause injury during a sudden stop. When reinstalling a rear seat in your vehicle it must be placed in its original position.
Page 120 Seating and safety restraints 3rd row tip/stow feature The 3rd row seat has a tip/stow feature to increase cargo space without removing the seat from the vehicle. To put seat in tip/stow position: 1. Pull the seat release lever located on the lower right side of the seatback while pushing the seatback down into the seat cushion.
Page 121: Safety Restraints
Seating and safety restraints 6. Pull down support bar and push into floor latch. To return seat to seating position: 1. Hold seat and pull support bar from floor latch. 2. Rotate support bar up under seat. 3. Rotate floor latch down into floor tub. 4.
Page 122 Seating and safety restraints It is extremely dangerous to ride in a cargo area, inside or outside of a vehicle. In a collision, people riding in these areas are more likely to be seriously injured or killed. Do not allow people to ride in any area of your vehicle that is not equipped with seats and safety belts.
Page 123 Seating and safety restraints • Rear seats (if equipped) 2. To unfasten, push the release button and remove the tongue from the buckle. • Front seats • Rear seats (if equipped) The front and rear outboard safety restraints in the vehicle are combination lap and shoulder belts.
Page 124 Seating and safety restraints response to vehicle movement. For example, if the driver brakes suddenly or turns a corner sharply, or the vehicle receives an impact of approximately 8 km/h (5 mph) or more, the combination safety belts will lock to help reduce forward movement of the driver and passengers. The safety belt system can also be made to lock manually by quickly pulling on the shoulder belt.
Page 125 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision. Safety belt assemblies not in use during a collision should also be inspected and replaced if either damage or improper operation is noted.
Page 126 Seating and safety restraints Disconnect the combination lap/shoulder belt and allow it to retract completely to disengage the automatic locking mode and activate the vehicle sensitive (emergency) locking mode. After any vehicle collision, the front passenger outboard seat belt system must be checked by a qualified technician to verify that the “automatic locking retractor”...
Page 127 Seating and safety restraints Front and second row safety belt height adjustment Your vehicle has safety belt height adjustments for the driver, front passenger and second row outboard passengers. Adjust the height of the shoulder belt so the belt rests across the middle of your shoulder.
Page 128 Seating and safety restraints • 1st row and 3rd row (if equipped) center seating positions The lap belt does not adjust automatically. Insert the tongue into the correct buckle (the buckle closest to the direction the tongue is coming from). To lengthen the belt, turn the tongue at a right angle to the belt and pull across your lap until it reaches the buckle.
Page 129 Seating and safety restraints Conditions of operation If... Then... The driver’s safety belt is not The safety belt warning light buckled before the ignition switch illuminates 1-2 minutes and the is turned to the ON position... warning chime sounds 4-8 seconds.
Page 130 Seating and safety restraints The following are reasons most often given for not wearing safety belts: (All statistics based on U.S. data) Reasons given... Consider... “Crashes are rare 36 700 crashes occur every day. The more we events” drive, the more we are exposed to “rare” events, even for good drivers.
Page 131 Seating and safety restraints One time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, BeltMinder will be disabled for that ignition cycle only. Deactivating/activating the BeltMinder feature Read steps 1 - 9 thoroughly before proceeding with the deactivation/activation programming procedure.
Page 132 (if equipped), LATCH child seat tether anchors and lower anchors (if equipped), and attaching hardware, should be inspected after a collision. Ford Motor Company recommends that all safety belt assemblies used in vehicles involved in a collision be replaced.
Page 133: Air Bags
This information will assist Ford Motor Company in the servicing vehicle and helping to better understand real world collisions...
Page 134 Seating and safety restraints Important supplemental restraint system (SRS) precautions The supplemental restraint system is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly or gently and the risk of injury from a deploying air bag is greatest close to the trim covering the air bag...
Page 135 Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. The front passenger air bag is not designed to offer protection to occupants in the center front seating position.
Page 136 Seating and safety restraints Children and air bags For additional important safety information, read all information on safety restraints in this guide. Children must always be properly restrained. Accident statistics suggest that children are safer when properly restrained in the rear seating positions than in the front seating position.
Page 137 Seating and safety restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 138 Seating and safety restraints The RCM (restraints control module) monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors, the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors). Determining if the system is operational The SRS uses a readiness light in the instrument cluster or a tone to indicate the condition of the system.
Page 139 Do not attempt to service, repair, or modify the air bag supplemental restraint system, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle including the driver should always wear their safety belts even when an air bag SRS is provided.
Page 140 Seating and safety restraints The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side air bags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near- frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 141: Child Restraints
Seating and safety restraints Disposal of air bags and air bag equipped vehicles (including pretensioners) For disposal of air bags or air bag equipped vehicles, see your local dealership or qualified technician. Air bags MUST BE disposed of by qualified personnel. SAFETY RESTRAINTS FOR CHILDREN See the following sections for directions on how to properly use safety restraints for children.
Page 142 To improve the fit of lap and shoulder belts on children who have outgrown child safety seats, Ford recommends use of a belt-positioning booster seat that is labelled as conforming to all applicable Federal motor vehicle safety standards. Belt-positioning booster seats raise the child and provide a shorter, firmer seating cushion that encourages safer seating posture and better fit of lap and shoulder belts on the child.
Page 143 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position which is capable of providing a tether anchorage.
Page 144 Seating and safety restraints Installing child safety seats in combination lap and shoulder belt seating positions Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 145 Seating and safety restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 146 Seating and safety restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 147 Seating and safety restraints 5. If you have not pulled out enough webbing to reach, allow the webbing to fully retract before attempting to pull it out again and repeat steps 2 through 4. 6. Pull the webbing through the child seat toward the buckle while pushing down with your knee on the child seat.
Page 148 The anchor bracket must be installed using the instructions provided with the kit. Tether anchorage hardware kits (part number 613D74) including instructions, may be obtained at no charge from any Ford or Lincoln/Mercury dealer. Tighten the anchor according to specifications. Otherwise, the safety seat may not be properly secured and the child may be injured in a sudden stop or collision.
Page 149 Seating and safety restraints The tether strap anchors in your vehicle are in the following positions (shown from top view): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 150 Seating and safety restraints • You may need to pull the seatback forward to access the tether anchors. Make sure the seat is locked in the upright position before installing the child seat. Refer to the Folding Down The Rear Seats section in this chapter for information on how to operate the rear seats.
Page 151: Driving
Driving STARTING Positions of the ignition 1. ACCESSORY, allows the electrical accessories such as the radio to operate while the engine is not running. 2. LOCK, locks the steering wheel, automatic transmission gearshift lever and allows key removal. 3. OFF, shuts off the engine and all accessories without locking the steering wheel.
Page 152 Driving Do not start your vehicle in a closed garage or in other enclosed areas. Exhaust fumes can be toxic. Always open the garage door before you start the engine. See Guarding against exhaust fumes in this chapter for more instructions. If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately.
Page 153 Driving 4. Make sure the parking brake is set. 5. Turn the key to 4 (ON) without turning the key to 5 (START). If there is difficulty in turning the key, firmly rotate the steering wheel left and right until the key turns freely.
Page 154 Driving Starting the engine Note: Whenever you start your vehicle, release the key as soon as the engine starts. Excessive cranking could damage the starter. 1. Turn the key to 5 (START) without pressing the accelerator pedal and release as soon as the engine starts.
Page 155: Brakes
Driving Guarding against exhaust fumes Although odorless and colorless, carbon monoxide is present in exhaust fumes. Take precautions to avoid its dangerous effects. If you ever smell exhaust fumes of any kind inside your vehicle, have your dealer inspect and fix your vehicle immediately. Do not drive if you smell exhaust fumes.
Page 156 Driving environmental conditions such as cold, heat, moisture, road dust, salt or mud. If a “metal-to-metal,” “continuous grinding” or “continuous squeal” sound is present while braking, the brake linings may be worn-out and should be inspected by a qualified service technician. Anti-lock brake system (ABS) On vehicles equipped with an anti-lock braking system (ABS), a noise from the hydraulic pump motor and pulsation in the pedal may be...
Page 157 Driving ABS warning lamp warning lamp in the instrument cluster momentarily illuminates when the ignition is turned to the ON position. If the light does not illuminate momentarily at start up, remains on or continues to flash, the ABS needs to be serviced. With the ABS light on, the anti-lock BRAKE brake system is disabled and normal...
Page 158 Driving The parking brake is not recommended to stop a moving vehicle. However, if the normal brakes fail, the parking brake can be used to stop your vehicle in an emergency. Since the parking brake applies only the rear brakes, the vehicle’s stopping distance will increase greatly and the handling of your vehicle will be adversely affected.
Page 159 Driving Speed sensitive steering The steering in your vehicle is speed sensitive. At high speeds, steering assist will decrease to improve steering feel. If the amount of effort required to steer your vehicle changes while driving at a constant vehicle speed, have the power steering system checked by your dealer or a qualified service technician.
Page 160 Driving The air suspension shut-off switch is located behind an access panel underneath the passenger side instrument panel. On vehicles equipped with Air Suspension, turn OFF the Air Suspension switch prior to jacking, hoisting or towing your vehicle. Normal vehicle operation does not require any action by the driver.
Page 161 Driving To avoid injury, never run the engine with one wheel off the ground, such as when changing a tire. PREPARING TO DRIVE YOUR VEHICLE Utility vehicles have a significantly higher rollover rate than other types of vehicles. In a rollover crash, an unbelted person is significantly more likely to die than a person wearing a seat belt.
Page 162: Transmission Operation
Driving AUTOMATIC TRANSMISSION OPERATION Brake-shift interlock This vehicle is equipped with a brake-shift interlock feature that prevents the gearshift lever from being moved from P (Park) when the ignition is in the ON position unless brake pedal is depressed. If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1.
Page 163 Driving Driving with a 4–speed automatic transmission Your vehicle’s automatic transmission is equipped with a special shift strategy that insures maximum heater performance during cold weather operation. When ambient temperature is –5° C (23° F) or below and the engine coolant temperature is below 38°...
Page 164 Driving R (Reverse) With the gearshift lever in R (Reverse), the vehicle will move backward. Always come to a complete stop before shifting into and out of R (Reverse). N (Neutral) With the gearshift lever in N (Neutral), the vehicle can be started and is free to roll.
Page 165 Driving Each time the vehicle is started, the transmission will automatically return to normal overdrive mode. Every time the vehicle is shut off and restarted, you must press the transmission control switch to cancel overdrive operation if driving in overdrive is not desired. 2 (Second) Use 2 (Second) to start-up on slippery roads or to provide...
Page 166 Driving REVERSE SENSING SYSTEM (IF EQUIPPED) The reverse sensing system (RSS) sounds a tone to warn the driver of obstacles near the rear bumper when the reverse gear is selected. To help avoid personal injury, please read and understand the limitations on the reverse sensing system described below.
Page 167 Driving The reverse sensing system detects obstacles within approximately 1.8 meters (5.9 ft.) of the rear bumper with a decreased coverage area at the outer corners of the bumper, (refer to the figures for approximate zone coverage areas). As you move closer to the obstacle, the rate of the tone increases.
Page 168 Driving FOUR-WHEEL DRIVE (4WD) OPERATION (IF EQUIPPED) For important information regarding safe operation of this type of vehicle, see Preparing to drive your vehicle in this chapter. When Four–wheel drive (4WD) is engaged, power is supplied to all four wheels through a transfer case. 4WD power can be selected when additional driving power is desired.
Page 169 Driving Utility and four-wheel drive vehicles are not designed for cornering at speeds as high as passenger cars any more than low-slung sports cars are designed to perform satisfactorily under off-road conditions. Avoid sharp turns or abrupt maneuvers in these vehicles.
Page 170 Driving Shifting to A4WD Move the 4WD control back to A4WD at a stop or at speeds up to A4WD 88 km/h (55 mph). Driving off-road with truck and utility vehicles 4WD vehicles are specially equipped for driving on sand, snow, mud and rough terrain and have operating characteristics that are somewhat different from conventional vehicles, both on and off the road.
Page 171 Driving • Drive slower in strong crosswinds which can affect the normal steering characteristics of your vehicle. • Be extremely careful when driving on pavement made slippery by loose sand, water, gravel, snow or ice. If your vehicle goes off the edge of the pavement •...
Page 172 Driving • In the event of an emergency stop, avoid skidding the tires and do not attempt any sharp steering wheel movements. • If the vehicle goes from one type of surface to another (i.e., from concrete to gravel) there will be a change in the way the vehicle responds to a maneuver (steering, acceleration or barking).
Page 173 Driving Sand When driving over sand, try to keep all four wheels on the most solid area of the trail. Avoid reducing the tire pressures but shift to a lower gear and drive steadily through the terrain. Apply the accelerator slowly and avoid spinning the wheels.
Page 174 Ford joins the U.S. Forest Service and the Bureau of Land Management in encouraging you to help preserve our national forest and other public and private lands by “treading lightly.”...
Page 175 Driving Descend a hill in the same gear you would use to climb up the hill to avoid excessive brake application and brake overheating. Do not descend in neutral, disengage overdrive or manually shift to a lower gear. When descending a steep hill, avoid sudden hard braking as you could lose control.
Page 176 Failure to follow tire pressure recommendations can adversely affect the way your vehicle handles. Do not exceed the Ford recommended pressure even if it is less than the maximum pressure allowed for the tire.
Page 177 Ford recommends that caution be used with any vehicle equipped with a high load or device (such as ladder racks or pickup box cover).
Page 178: Vehicle Loading
Driving system gets wet, your engine may stall. Water may also enter your engine’s air intake and severely damage your engine. If driving through deep or standing water is unavoidable, proceed very slowly. Never drive through water that is higher than the bottom of the hubs (for trucks) or the bottom of the wheel rims (for cars).
Page 179 Driving determined by subtracting the vehicle curb weight for each engine/transmission combination, any required option weight for trailer towing and the weight of the driver from the GCWR for the towing vehicle. • Maximum Trailer Weight: Maximum weight of a trailer the loaded vehicle (including occupants and cargo) is permitted to tow.
Page 180 Driving Special loading instructions for owners of pickup trucks and utility-type vehicles For important information regarding safe operation of this type of vehicle, see the Preparing to drive your vehicle section in this chapter. Loaded vehicles, with a higher center of gravity, may handle differently than unloaded vehicles.
Page 181: Trailer Towing
Driving TRAILER TOWING Trailer towing with your vehicle may require the use of a trailer tow option package. Trailer towing puts additional loads on your vehicle’s engine, transmission, axle, brakes, tires, and suspension. For your safety and to maximize vehicle performance, be sure to use the proper equipment while towing.
Page 182 Driving Trailer weight Rear Maximum Tire size - range (0 - Engine axle GCWR - kg cm (inches) maximum) kg ratio (lbs.) (lbs.) 4.6L 3.31 40.6 (16) 4 990 (11 000) 0-2 676 (0-5 900) 4.6L 3.31 40.6 (17) 4 990 (11 000) 0-2 676 (0-5 900) 5.4L 3.31...
Page 183 Driving If your vehicle is not equipped with the factory heavy duty trailer tow option, auxiliary coolers are recommended for the automatic transmission system if you are planning on: • traveling farther than 80 km (50 miles) • towing in hilly terrain •...
Page 184 Driving Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications. The trailer brakes must meet local and Federal regulations. Do not connect a trailer’s hydraulic brake system directly to your vehicle’s brake system.
Page 185 Driving Servicing after towing If you tow a trailer for long distances, your vehicle will require more frequent service intervals. Refer to your scheduled maintenance guide for more information. Trailer towing tips • Practice turning, stopping and backing up before starting on a trip to get the feel of the vehicle trailer combination.
Page 186: Recreational Towing
If a distance of 80 km (50 miles) or a speed of 56 km (35 mph) must be exceeded, the drive shaft will have to be removed before the vehicle is towed. Ford recommends the driveshaft be removed/installed only by a qualified technician. See your local dealer for driveshaft removal/installation. Improper removal/installation of the driveshaft can cause transmission fluid loss, damage to the driveshaft and internal transmission components.
Page 187: Roadside Emergencies
Roadside emergencies GETTING ROADSIDE ASSISTANCE To fully assist if you should have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: • 24–hours, seven days a week •...
Page 188: Hazard Flasher Switch
ROADSIDE COVERAGE BEYOND BASIC WARRANTY In the United States, you may purchase additional roadside assistance coverage beyond this period through the Ford Auto Club by contacting your Ford or Lincoln Mercury dealer. Similarly in Canada, for uninterrupted Roadside Assistance coverage, you may purchase extended coverage prior to your Basic Warranty’s Roadside...
Page 189 Roadside emergencies The fuel pump shut-off switch is located in the passenger’s foot well, by the kick panel. Use the following procedure to reset the fuel pump shut-off switch. 1. Turn the ignition to the OFF position. 2. Check the fuel system for leaks. 3.
Page 190: Fuses And Relays
Roadside emergencies FUSES AND RELAYS Fuses If electrical components in the vehicle are not working, a fuse may have blown. Blown fuses are identified by a broken wire within the fuse. Check the appropriate fuses before replacing any electrical components. Note: Always replace a fuse with one that has the specified amperage rating.
Page 191 Roadside emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 192 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Location Rating Fuse Panel Description Speed Control Module, Reverse Lamp, EVO Module, Climate Mode Switch (Front Blower Relay), Daytime Running Lamp Relay, Reverse Sensing System, Autolock, E/C Mirror Cluster, Overhead Trip Computer, Compass, Brake Shift Interlock Solenoid, Air Suspension Module, GEM Module, EVO Steering Sensor, Heated Mirror, Rear...
Page 193 Roadside emergencies Fuse/Relay Fuse Amp Passenger Compartment Location Rating Fuse Panel Description Audio, Air Suspension Module, GEM Module, Memory Module Starter Relay, Fuse 20, Transmission Range Switch Air Bag Module, Intelligent Passenger Airbag Deactivation Module Aux A/C, Heated Seats, Trailer Tow Battery Charge, Turn/Hazard Flasher, 4x4 Clutch Relay, Overhead Console, E/C Mirror, 4 Wheel Anti-Lock Brake System (4WABS)
Page 194 Roadside emergencies Power distribution box The power distribution box is located in the engine compartment. The power distribution box contains high-current fuses that protect your vehicle’s main electrical systems from overloads. Always disconnect the battery before servicing high current fuses. To reduce risk of electrical shock, always replace the cover to the Power Distribution Box before reconnecting the battery or refilling fluid reservoirs.
Page 195 Roadside emergencies The high-current fuses are coded as follows. Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 20A * Power Point 30A* Powertrain Control Module 30A* Headlamps/Autolamps 20A* Console Powerpoint 20A* Trailer Tow Backup/Park Lamps 15A* Parklamps/Autolamps, Feeds Passenger Compartment Fuse 18 20A* Horn...
Page 196 Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating 30A** 4x4 Shift Motor & Clutch 40A** Climate Control Front Blower — Not Used — Not Used 30A** Trailer Tow Electric Brake 50A** Air Suspension Compressor 30A** Heated Seats 40A** Ignition Switch Battery Feed (Run/Start Circuit)
Page 197: Changing Tires
Roadside emergencies Fuse/Relay Fuse Amp Power Distribution Box Description Location Rating — Not Used — Powertrain Control Module Diode — A/C Clutch Diode — Not Used Delayed Accessory (Power Windows, Flip Windows, Moonroof) — Not Used *Mini fuses **Maxi fuses Relays Relays are located in the power distribution box and should be replaced by qualified technicians.
Page 198 Roadside emergencies Removing the jack handle 1. Open the hood. 2. Unsnap the end of the handle that is retained by the clip on the top of the windshield washer bottle. 3. Unsnap the shaft of the handle from the two retaining clips attached to the top of the radiator shroud.
Page 199 Roadside emergencies Stowing the spare tire 1. Lay the tire on the ground with the outboard side facing up. 2. Install the retainer through the wheel center and slide the wheel under the vehicle. 3. Turn the spare handle clockwise until the tire is raised to its original position underneath the vehicle.
Page 200 Roadside emergencies 1. Park on a level surface, activate hazard flashers and set the parking brake. 2. Place gearshift lever in P (Park) and turn engine OFF. 3. Block the diagonally opposite wheel. 4. Obtain the spare tire and jack from their storage locations.
Page 201 Roadside emergencies 7. Turn OFF the air suspension switch (if equipped). 8. Position the jack according to the following guides and turn the jack handle clockwise until the wheel is completely off the ground. When one of the rear wheels is off the ground, the transmission alone will not prevent the vehicle from moving or slipping off the jack, even if the...
Page 202 Roadside emergencies • Front (4x4) • Rear To lessen the risk of personal injury, do not put any part of your body under the vehicle while changing a tire. Do not start the engine when your vehicle is on the jack. The jack is only meant for changing the tire.
Page 203: Jump Starting
Roadside emergencies 12. Remove the jack and fully tighten the lug nuts in the order shown. 13. Put flat tire, jack and lug wrench away. Make sure the jack is fastened so it does not rattle when you drive. 14. Unblock the wheels. 15.
Page 204 Roadside emergencies 4. Check all battery terminals and remove any excessive corrosion before you attach the battery cables. Ensure that vent caps are tight and level. 5. Turn the heater fan on in both vehicles to protect any electrical surges. Turn all other accessories off. Connecting the jumper cables 1.
Page 205 Roadside emergencies 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery. 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system.
Page 206 Roadside emergencies 3. Once the disabled vehicle has been started, run both engines for an additional three minutes before disconnecting the jumper cables. Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery.
Page 207 Roadside emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 208: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure.
Page 209: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 210 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business).
Page 211 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Please contact your dealer for further information. Since this information is subject to...
Page 212: The Dispute Settlement Board
THE DISPUTE SETTLEMENT BOARD (U.S. ONLY) The Dispute Settlement Board is: • an independent, third-party arbitration program for warranty disputes • available free to owners and lessees of qualifying Ford Motor Company vehicles The Dispute Settlement Board may not be available in all states. Ford...
Page 213 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 214 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 215: Utilizing The Mediation/Arbitration
UTILIZING THE MEDIATION/ARBITRATION PROGRAM (CANADA ONLY) In those cases where you continue to feel that the efforts by Ford and the dealer to resolve a factory-related vehicle service concern have been unsatisfactory, Ford of Canada participates in an impartial third party mediation/arbitration program administered by the Canadian Motor Vehicle Arbitration Plan (CAMVAP).
Page 216: Ordering Additional Owner's Literature
U.S.A. Telephone: (313) 594-4857 FAX: (313) 390-0804 If you are in another foreign country, contact the nearest Ford dealership. If the dealership employees cannot help you, they can direct you to the nearest Ford affiliate office. If you buy your vehicle in North America and then relocate outside of the U.S.
Page 217 Customer assistance payable by the consumer (less a reasonable allowance for consumer use). The consumer has the right to choose whether to receive a refund or replacement vehicle. California Civil Code Section 1793.22(b) presumes that the manufacturer has had a reasonable number of attempts to conform the vehicle to its applicable express warranties if, within the first 18 months of ownership of a new vehicle or the first 29 000 km (18 000 miles), whichever occurs first:...
Page 218: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (202–366–0123 in the Washington D.C.
Page 219: Cleaning
Ph shampoo, such as Detail Wash (ZC-3–A), which is available from your authorized Ford, Lincoln or Mercury dealer. Always use a clean sponge or carwash mitt with plenty of water for best results. Dry the vehicle with a chamois or soft terry cloth towel in order to eliminate water spotting.
Page 220 Minor scratches or paint damage from road debris may be repaired using the Ultra Touch Prep and Finishing Kit (F7AZ-19K507–BA), which is available at your authorized Ford, Lincoln or Mercury dealer. This kit contains: • Lacquer Touch-Up Paint (ALBZ-19500–XXXXA) •...
Page 221 Use Detail Wash (ZC-3–A) for routine cleaning. If tar or grease spots are present, clean with Extra Strength Tar and Road Oil Removal (B7A-19520–AA). Use only approved products to clean plastic parts. These products are available from your authorized Ford, Lincoln or Mercury dealer.
Page 222 Clean the outside of the windshield or rear window with a non-abrasive cleaner such as Ultra Clear Spray Glass Cleaner (E4AZ-19C507–AA), available from your authorized Ford, Lincoln or Mercury dealer. If after cleaning the glass surface, the water sheets from the glass (e.g., does not bead), then the window is clean.
Page 223 Extra Strength Upholstery Cleaner (E8AZ-19523–AA). CLEANING LEATHER SEATS (IF EQUIPPED) All Ford, Lincoln and Mercury vehicles with leather seating surfaces have a clear, protective coating over the leather. To clean the leather seats, simply use a soft cloth with Deluxe Leather...
Page 224: Underbody Preservation
Cleaning It is recommended that you use the Deluxe Leather Care Kit (F8AZ-19G253–AA), available from your authorized Ford, Lincoln or Mercury dealer. The mild cleaner and special pad available in the kit cleans the leather and maintains its natural beauty. For best results, follow the instructions printed on the cleaner label.
Page 225 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 226: Maintenance And Specifications
Maintenance and specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 227 Maintenance and specifications Working with the engine off 1. Set the parking brake and ensure the gearshift is securely latched in P (Park). 2. Turn off the engine and remove the key. 3. Block the wheels to prevent the vehicle from moving unexpectedly. Working with the engine on 1.
Page 228: Engine Compartment
Maintenance and specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 4.6L V8 and 5.4L V8 engines 1. Battery 2. Automatic transmission fluid dipstick 3. Engine oil filler cap 4. Engine oil dipstick 5. Power steering fluid reservoir 6. Brake fluid reservoir 7.
Page 229: Engine Oil
In very cold weather, do not fill the reservoir all the way. Only use a washer fluid that meets Ford specification ESR-M17P5–A. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 230 Maintenance and specifications 4. Open the hood. Protect yourself from engine heat. 5. Locate and carefully remove the engine oil level indicator (dipstick). 6. Wipe the indicator clean. Insert the indicator fully, then remove it again. • If the oil level is between the MIN and MAX marks, the oil level is acceptable.
Page 231 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used...
Page 232: Battery
Maintenance and specifications that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced. It is recommended you use the appropriate Motorcraft oil filter (or another brand meeting Ford specifications) for your engine application.
Page 233 Maintenance and specifications Batteries normally produce explosive gases which can cause personal injury. Therefore, do not allow flames, sparks or lighted substances to come near the battery. When working near the battery, always shield your face and protect your eyes. Always provide proper ventilation.
Page 234 Maintenance and specifications Because your vehicle’s engine is also electronically controlled by a computer, some control conditions are maintained by power from the battery. When the battery is disconnected or a new battery is installed, the engine must relearn its idle and fuel trim strategy for optimum driveability and performance.
Page 235 Maintenance and specifications ENGINE COOLANT Checking engine coolant The concentration and level of engine coolant should be checked at the mileage intervals listed in the scheduled maintenance guide. The coolant concentration should be maintained at 50/50 coolant and water, which equates to a freeze point of -36°...
Page 236 The cooling system in your vehicle is filled with either green-colored Motorcraft Premium Engine Coolant meeting Ford specification ESE-M97B44–A or yellow-colored Motorcraft Premium Gold Engine Coolant meeting Ford Specification WSS-M97B51–A1. To determine your vehicle’s coolant type (color), check your coolant reservoir. • Add Motorcraft Premium Engine Coolant (green-colored), VC-4–A (U.S.) or CXC-10 (Canada) or Motorcraft Premium...
Page 237 • Do not mix with recycled coolant unless from a Ford-approved recycling process (see Use of Recycled Engine Coolant section). For vehicles with overflow coolant systems with a non-pressurized cap on the coolant recovery system, add coolant to the coolant recovery reservoir when the engine is cool.
Page 238 Operating an engine with a low level of coolant can result in engine overheating and possible engine damage. Recycled engine coolant Ford Motor Company recommends the use of a recycled engine coolant produced by Ford-approved processes in vehicles originally equipped with Motorcraft Premium Engine Coolant (green-colored). However, not all coolant recycling processes produce coolant that meets Ford specification ESE-M97B44–A.
Page 239 Maintenance and specifications Fill your engine coolant reservoir as outlined in Adding engine coolant in this chapter. Severe climates If you drive in extremely cold climates (less than –36° C [–34° F]): • It may be necessary to increase the coolant concentration above 50%.
Page 240 Maintenance and specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The and the symbol will illuminate. • The Service Engine Soon indicator light will illuminate. If the engine reaches a preset over-temperature condition, the engine will automatically switch to alternating cylinder operation.
Page 241: Fuel Information
Maintenance and specifications 5. Restart the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank.
Page 242 Maintenance and specifications Observe the following guidelines when handling automotive fuel: • Extinguish all smoking materials and any open flames before fueling your vehicle. • Always turn off the vehicle before fueling. • Automotive fuels can be harmful or fatal if swallowed. Fuel such as gasoline is highly toxic and if swallowed can cause death or permanent injury.
Page 243 If you must replace the fuel filler cap, replace it with a fuel filler cap that is designed for your vehicle. The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used.
Page 244 Maintenance and specifications The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap. Otherwise, fuel may spray out and injure you or others. If you do not use the proper fuel filler cap, excessive pressure or vacuum in the fuel tank may damage the fuel system or cause the fuel cap to disengage in a collision, which may result in possible...
Page 245 Auto Makers’ Choice logo. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality. Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components.
Page 246 Maintenance and specifications Replace the fuel filter with an authorized Motorcraft part. The customer warranty may be void for any damage to the fuel system if an authorized Motorcraft fuel filter is not used. ESSENTIALS OF GOOD FUEL ECONOMY Measuring techniques Your best source of information about actual fuel economy is you, the driver.
Page 247 Maintenance and specifications • Use the same side of the same pump and have the vehicle facing the same direction each time you fill up. • Have the vehicle loading and distribution the same every time. Your results will be most accurate if your filling method is consistent. Calculating fuel economy 1.
Page 248 Maintenance and specifications • Sudden or hard accelerations may reduce fuel economy. • Slow down gradually. • Driving at reasonable speeds (traveling at 88 km/h [55 mph] uses 15% less fuel than traveling at 105 km/h [65 mph]). • Revving the engine before turning it off may reduce fuel economy. •...
Page 249 The scheduled maintenance items listed in the scheduled maintenance guide are essential to the life and performance of your vehicle and to its emissions system. If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting...
Page 250 Maintenance and specifications emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability. Do not park, idle, or drive your vehicle in dry grass or other dry ground cover. The emission system heats up the engine compartment and exhaust system, which can start a fire.
Page 251 Check the power steering fluid. Refer to the scheduled maintenance guide for the service interval schedules. If adding fluid is necessary, use only Ford Premium Power Steering Fluid. 1. Start the engine and let it run until it reaches normal operating...
Page 252 MAX. Do not fill above this line. 4. Use only a DOT 3 brake fluid certified to meet Ford specification ESA-M6C25–A. Refer to Lubricant specifications in this chapter. Brake fluid is toxic. If brake fluid contacts the eyes, flush eyes with running water for 15 minutes.
Page 253 Maintenance and specifications TRANSMISSION FLUID Checking automatic transmission fluid Refer to your scheduled maintenance guide for scheduled intervals for fluid checks and changes. Your transmission does not consume fluid. However, the fluid level should be checked if the transmission is not working properly, i.e., if the transmission slips or shifts slowly or if you notice some sign of fluid leakage.
Page 254 Maintenance and specifications operating temperature can be reached after approximately 30 km (20 miles) of driving. You can check the fluid without driving if the ambient temperature is above 10°C (50°F). However, if fluid is added at this time, an overfill condition could result when the vehicle reaches normal operating temperature.
Page 255: Air Filter(S)
Maintenance and specifications DRIVELINE UNIVERSAL JOINT AND SLIP YOKE Your vehicle may be equipped with universal joints that require lubrication. Refer to the scheduled maintenance guide for maintenance intervals. If the original universal joints are replaced with universal joints equipped with grease fittings, lubrication will also be necessary. AIR FILTER MAINTENANCE Refer to the scheduled maintenance guide for the appropriate intervals for changing the air filter element.
Page 256 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it.
Page 257 Maintenance and specifications Treadwear The treadwear grade is a comparative rating based on the wear rate of the tire when tested under controlled conditions on a specified government test course. For example, a tire graded 150 would wear one and one-half (1 1/2) times as well on the government course as a tire graded 100.
Page 258 Maintenance and specifications SERVICING YOUR TIRES Checking the tire pressure • Use an accurate tire pressure gauge. • Check the tire pressure when tires are cold, after the vehicle has been parked for at least one hour or has been driven less than 5 km (3 miles).
Page 259 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, etc.), as originally offered by Ford. Do not replace your tires with “high performance” tires or larger size tires.
Page 260: Part Numbers
Follow these guidelines when using snow tires and chains: • Use only cable type chains offered by Ford as an accessory or equivalent. SAE class “S” or other conventional link type chains may contact and cause damage to the vehicle’s wheel house and/or body.
Page 261: Refill Capacities
Maintenance and specifications REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid High Fill to line on Performance reservoir DOT 3 Motor Vehicle Brake Fluid Engine oil Motorcraft SAE 5.7L (includes filter 5W-20 Super (6.0 quarts) change) Premium Motor...
Page 262 Maintenance and specifications Fluid Ford Part Application Capacity Name Engine coolant Motorcraft 4.6L V8 engine 20.5 L Premium Engine with 1 row (21.7 quarts) Coolant radiator (green-colored) 4.6L V8 engine 21.8L or Motorcraft with 2 row (23.0 quarts) Premium Gold...
Page 263 The axle lubricant should be changed any time the axle has been submerged in water. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118–A for complete refill of Traction-Lok axles.
Page 264: Lubricant Specifications
Maintenance and specifications LUBRICANT SPECIFICATIONS Ford part Ford part Ford Item name number specification Hinges, latches, Multi-Purpose DOAZ-19584-AA ESB-M1C93-B or striker plates Grease ESR-M1C159-A and rotors, seat F5AZ-19G209-AA tracks, fuel filler door hinge and spring Lock cylinders, Penetrating and Motorcaft XL-1...
Page 265 Maintenance and specifications Ford part Ford part Ford Item name number specification 4x4 front wheel High E8TZ-19590-A ESA-M1C198-A bearings, 4x4 Temperature spindle needle 4x4 Front Axle bearings, spindle & Wheel Bearing thrust bearings Grease & front drive axle u-joint/slip spline...
Page 266: Engine Data
Use of any fluid other than the recommended fluid may cause transmission damage. Add 118 ml (4 oz.) of Additive Friction Modifier C8AZ-19B546-A or equivalent meeting Ford specification EST-M2C118-A for complete refill of Ford Traction-Lok rear axles. ENGINE DATA Engine 4.6L V8 engine...
Page 267: Vehicle Dimensions
Maintenance and specifications VEHICLE DIMENSIONS Vehicle dimensions 4x2 mm (in) 4x4 mm (in) (1) Overall length 5 196.0 5 196.0 (204.6) (204.6) (2) Vehicle width 2 000.0 2 000.0 (78.7) (78.7) *width including 2 293 2 293 mirrors (90.3) (90.3) *with optional 2 071 2 071...
Page 268 Maintenance and specifications...
Page 269 Maintenance and specifications IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 270: Accessories
Accessories FORD ACCESSORIES FOR YOUR VEHICLE A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 271 Accessories Travel equipment Auto headlamps with DRL Bike rack Bumper mount bike carrier Canoe carrier Cell phone holder Daytime running lights (DRL) Factory luggage rack adaptors Fog lights Framed luggage covers Heavy-duty battery Kayak carrier Luggage/cargo basket Removable luggage rack (Track rider bars) Removable luggage rack adapters Running boards (Molded and tubular) Seatback organizer...
Page 272 Accessories Flat splash guards Front end covers (full and sport) Hood deflectors Inside mirror with compass display Inside mirror with compass and temperature display Leather steering wheel Locking gas cap Molded splash guards Molded vinyl floor mats Moonroof deflector Outside signal mirror (requires power mirrors) Rear air deflectors Side window air deflectors Spare tire lock...
Page 273 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 274: Index
Index Auxiliary power point ....78 Axle Accessory delay ......80 lubricant specifications ..263, 265 Air bag supplemental refill capacities ......260 restraint system ..132–133, 137 traction lok ......159 and child safety seats ....135 description ......133, 137 disposal ........140 driver air bag ....135, 138 Battery ........231 indicator light ...12, 137, 139 acid, treating emergencies ..231...
Page 275 Index Child safety restraints ....140 Ford accessories child safety belts ....140 for your vehicle ......224 Ford Extended Child safety seats ......141 Service Plan ......210 attaching with Getting assistance outside tether straps ....146–147 the U.S. and Canada ....214 in front seat ......143 Getting roadside assistance ...186...
Page 276 Index description ......167 driving off road .......169 Emergencies, roadside electronic shift ......168 jump-starting ......202 indicator light ......14 preparing to Emission control system ..248 drive your vehicle ....160 Engine ........265–266 Fuel ..........240 check engine/ calculating fuel economy ..245 service engine soon light ..10 cap ...........242 cleaning ........219 capacity ........260...
Page 277 Index odometer ........17 speedometer ......16 tachometer ........17 Ignition .......150, 265–266 trip odometer ......17 Infant seats GAWR (see Safety seats) .....141 (Gross Axle Weight Rating) ..177 Inspection/ calculating .......179 maintenance (I/M) testing ..249 definition .........177 Instrument panel driving with a heavy load ..177 cleaning ........221 location ........177 cluster ........10, 222...
Page 278 Index headlamps, flash to pass ..60 instrument panel, dimming ..60 interior lamps ....61–62, 64 Message center .....74, 90 replacing bulbs ..62, 64, 66–68 english/metric button ....90 menu button ......91 Lane change indicator (see Turn signal) ......61 Mirrors .........71 automatic dimming rearview Liftgate ........93 mirror ........80 Lights, warning and indicator ..10...
Page 279 Index Preparing to drive memory seat ....100, 112 your vehicle .......160 SecuriLock passive anti-theft system ....104–106 Servicing your vehicle ....225 Rear window defroster ....58 Snowplowing .........7 Relays ........189, 196 Spark plugs, specifications .....259, 265–266 Remote entry system ...96, 98 illuminated entry ....100 Special notice locking/unlocking doors ..95–97 ambulance conversions ....7...
Page 280 Index wrecker ........207 Traction-lok rear axle ....159 Warning chimes ......14 Transmission ......161 Warning lights (see Lights) ..10 fluid, checking and adding (automatic) ......252 Washer fluid ......228 fluid, refill capacities ....260 Water, Driving through .....176 lubricant specifications ..263, 265 Windows Trip odometer ......17 power .........79 Turn signal ......13, 61 rear wiper/washer .....69...

Ford 2002 Expedition Owner's Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Accessories

Index

Quick Links

Related Manuals for Ford 2002 Expedition

Summary of Contents for Ford 2002 Expedition

Table of Contents
