- Page 1 Instruction Manual STVG529BK/W Please read before using this unit. The Singing Machine® is a registered trademark or The Singing Machine Co., Inc.
-
Page 2: Important Safety Information
Warnings WARNING: TO PREVENT FIRE OR SHOCK HAZARD, DO NOT EXPOSE CAUTION THIS UNIT TO RAIN OR MOISTURE. RISK OF ELECTRIC SHOCK FCC WARNING: This equipment may generate or use radio frequency DO NOT OPEN energy. Changes or modifications to this equipment may cause harmful interference unless the modifications are expressly approved in the CAUTION: TO REDUCE THE RISK OF ELECTRIC SHOCK, DO NOT instruction manual. -
Page 3: Front View
CONTROL LOCATIONS FRONT VIEW CD Door Monitor REPEAT Button PLAY/PAUSE Button PROGRAM Button STOP Button SKIP Button SKIP Button ON/OFF Button ECHO Control BALANCE Control Monitor ON/OFF Button MIC Holder MIC holder MIC Volume Control MASTER Volume Control ON/OFF LED MIC 2 Jack ON/OFF Button AUX IN Jack... -
Page 4: Connecting The Power
DISPLAY TRK 01/18 PROG 00:16:04 P P L L A A Y Y I I N N G G T T I I M M E E R R E E P P E E A A T T M M O O D D E E - - R R E E P P E E A A T T O O N N E E - - R R E E P P E E A A T T A A L L L L - - N N O O R R E E P P E E A A T T F F U U N N C C T T I I O O N N... -
Page 5: Connecting To Your Tv
2. Connect the RCA video cable (Yellow) to the VIDEO OUT jack and the audio cables (White and Red) to the AUDIO OUT jacks located on the back of the Singing Machine. 3. Connect the opposite end of the RCA video cable (Yellow) to the VIDEO IN jack and the audio cables (White and Red) to the AUDIO IN on your TV. -
Page 6: Turning On/Off
OPERATION This unit is designed to play CDs and CD+Gs bearing the identification logo respectively. If the disc does not conform to the standard, it may not play properly. TURNING ON/OFF To turn on the unit, press the ON/OFF button, the ON/OFF LED indicator will light To turn it off, press the ON/OFF button again, the ON/OFF LED indicator will turn off. -
Page 7: Karaoke Functions
OPERATION (continued) REPEAT To repeat the track currently playing, press the REPEAT button once. The REPEAT ONE ( ) indicator will light up. To repeat all tracks, press the REPEAT button twice. The REPEAT ALL ( ) indicator will light up. To clear the REPEAT function, press the REPEAT button again. -
Page 8: Care And Maintenance
Care and Maintenance Care for Compact Discs Treat the compact disc carefully. Handle the compact disc only by its edges. Never allow your fingers to come in contact with the shiny, unprinted side of the compact disc. Do not attach adhesive tape, stickers, etc. to the compact disc label. -
Page 9: Troubleshooting Guide
CD compartment. Moisture has formed inside the Wait about 20 to 30 minutes to let it CD deck. dry out. The Singing Machine needs to be Power the system OFF and disconnect the machine from electrical outlet for reset. 30 seconds. - Page 10 TROUBLESHOOTING GUIDE (continued) PROBLEM POSSIBLE CAUSE SOLUTION Lyrics do not appear on Video cable is not connected Follow direction in the “ the TV screen properly to the TV. CONNECTIONS” section. TV does not have video line input. Connect from AV OUT of Singing Machine to the VIDEO IN on your TV.
-
Page 11: Audio Section
