SURROUND
S –1000
PREAMP/PROCESSOR
Owner's Reference
INSTRUCTIONS FOR USE

Advertisement

Table of Contents
loading

Related Manuals for Krell Industries S-1000

Summary of Contents for Krell Industries S-1000

  • Page 1 SURROUND S –1000 PREAMP/PROCESSOR Owner’s Reference INSTRUCTIONS FOR USE...

  • Page 2: Important Safety Instructions

    This product is manufactured in the United States of America. Krell Industries, Inc., its subsidiaries, and authorized agents. Krell Smart System Setup™ is a trademark of Krell Industries, Inc. “DTS”, “DTS Digital Surround”, “DTS ES Extended Surround”, and “Neo:6” are registered trademarks of Digital Theater Systems, Inc. TosLink is a trademark of Toshiba Corporation.

  • Page 3: Table Of Contents

    Contents Krell S–1000 INTRODUCTION DEFINITION OF TERMS UNPACKING PLACEMENT AC Power Guidelines GETTING STARTED FRONT PANEL DESCRIPTION REMOTE CONTROL DESCRIPTION Battery Installation and Removal BACK PANEL DESCRIPTION CONNECTING THE S–1000 TO YOUR SYSTEM First: Connect Analog and Digital Sources Next: Connect Video Sources Last: Connect Amplifiers and Sources OVERVIEW: SYSTEM CONFIGURATION AND NAVIGATION Configuration Steps...
  • Page 4 Tables Illustrations TABLE 1 S–1000 Connections and Corresponding Factory Default Decoding Modes, by Device TABLE 2 Krell Music Surround Modes for the S–1000 FIGURE 1 The S–1000 Front Panel FIGURE 2 The S–1000 Remote Control FIGURE 5 The S –1000 Back Panel Page Page Krell S–1000...

  • Page 5: Introduction

    Introduction Krell S–1000 Thank you for your purchase of the Krell S–1000 Surround Preamp/ Processor. The S–1000 serves as the centerpiece in a Krell HEAT™—High End Audio Theater—system, which applies the fundamental principles of Krell engineering to the creation of a fully integrated high-perfor- mance multi-channel sound system.

  • Page 6: Definition Of Terms

    Definition of Terms INPUT AND OUTPUT CONNECTIONS OPERATION Following are the definitions of key terms used in your owner’s refer- ence manual: Balanced A symmetrical input or output circuit that has equal impedance from both input terminals to a common ground reference point. The industry standard for professional and sound recording installations, balanced connections have 6 dB more gain than single-ended con- nections and allow the use of long interconnect cables.
  • Page 7 Definition of Terms, continued TECHNOLOGY VIDEO Krell S–1000 Krell HEAT The Krell term HEAT, or High End Audio Theater, is a design applica- tion incorporated into Krell components to enhance multi-channel home entertainment systems. A Krell HEAT system is an integrated home theater system consisting of a state-of-the-art Krell preamp/ processor and matching amplifiers that reproduce two channel and multi-channel sources with audiophile sound quality, placing the...

  • Page 8: Unpacking

    Unpacking Note Open the box and remove the top layer of foam. You see these items: 1 S–1000 Surround Preamp/processor 1 IEC connector (AC power) cord 1 S–1000 handheld remote control 1 CR2025 lithium battery 1 12 VDC output (12 V trigger) cable 1 packet containing the S–1000 Quick Setup Guide and the warranty registration card.

  • Page 9: Placement

    Placement AC POWER GUIDELINES Krell S–1000 Before you install the S–1000 Surround Preamp/processor into your system, review the following guidelines to choose the location for the component. This will facilitate a clean, trouble-free installation. The S–1000 does not require any type of special rack or cabinet for installation.

  • Page 10: Getting Started

    Getting Started IMPORTANT: ACCESSING THE ON-SCREEN DISPLAY The S–1000 Surround Preamp/processor provides a variety of con- nection and operation options for outstanding music and cinema soundtrack reproduction, and offers a high degree of flexibility via an on-screen menu system. To setup the S–1000 quickly: 1.

  • Page 11: Figure 1 The S–1000 Front Panel

    Figure 1 The S –1000 Front Panel TUNER GAME TAPE/VCR2 RECALL POWER SAVE 25 14 FRONT PANEL BASIC OPERATION AND REMOTE 1 Power Button/Pre Key 2 Power/Stand-by LED FUNCTIONS 3 Infrared Sensor 4 Infrared Emitter INPUT DEVICE SELECTION 5 DVD Button/Key 6 Cable Button/LD Key 7 SAT Button/Key 8 VCR Button/Key...

  • Page 12: Front Panel Description

    Front Panel and Remote Control Description See Figures 1 and 2 on page 7 FUNCTIONS Button = on front panel Key = on remote control Blue LED illuminated = function active, except for power/stand-by LED which illuminates red when in stand-by mode. Basic Functions Input Device Selection The S–1000 Surround Preamp/processor front panel and remote...
  • Page 13 Front Panel Description, continued Input Device Selection Buttons and LEDs, continued Decoding Modes Krell S –1000 TV Button/Key Press this button or key to select the television device. 10 CD Button/Key Press this button or key to select the compact disc device. 11 Tuner Button/Key Press this button or key to select the AM/FM tuner device.
  • Page 14 Front Panel Description, continued Decoding Modes, continued Note Note Display Window Individualized Channel Trim 18 Pro Logic II Button/LED/PL Key Press this button or key to select the Dolby Pro Logic II modes for Dolby Surround encoded material, including laser discs, videotapes, television broadcasts, and compact discs.
  • Page 15 Front Panel Description, continued Individual Channel Trim, continued Processor Functions Krell S–1000 22 Surr/Back Button/LED/Rear Key Press the surr/back button or key, then use the direction or level buttons (28) to adjust the volume of the surround loudspeakers. The phrase SURROUND TRIM adjust the back loudspeakers, press the surr/back button again.

  • Page 16: Battery Installation And Removal

    Remote Control Only Description See Figure 2 on page 7 BATTERY INSTALLATION AND REMOVAL Notes REMOTE ONLY FUNCTIONS Notes The S–1000 remote control uses one CR2025 lithium battery, which is included with the shipment. To open the battery compartment on the back of the remote control: 1.

  • Page 17: Remote Control Description

    Front Panel Description, continued REMOTE ONLY FUNCTIONS, continued Krell S–1000 30 Prev Key Use this key to return to the previously displayed setup menu screen. 31 Mute Key Use this key to mute the S–1000 output. When this function is active, appears in the front panel display.

  • Page 18: Back Panel

    Figure 3 The S–1000 Back Panel COMPONENT VIDEO MULTI-CHANNEL INPUTS ANALOG AUDIO INPUTS NO USER SERVICEABLE PARTS INSIDE 42 36 BACK PANEL ANALOG AUDIO INPUTS AND OUTPUTS FUNCTIONS 34 Balanced Analog Audio Outputs 35 Single-ended Analog Audio Outputs 36 Balanced Analog Audio Inputs 37 Tape In Left and Right 38 Tape Out Left and Right...
  • Page 19 TABLE 1 S–1000 Connections and Corresponding Factory Default Decoding Modes, by Device Connect the S–1000 to the rest of the components in your system, using this table as a guide. DEVICE S–1000 CONNECTIONS Digital Video Audio Component 1 COAX 1 CABLE HDMI COAX 3...

  • Page 20: Back Panel Description

    Back Panel Description See Figure 3 on page 14 FUNCTIONS Analog Audio Outputs and Inputs Digital Audio Inputs and Outputs The back panel of the S–1000 Surround Preamp/processor provides all audio and video input and output connections, remote control inputs and outputs, power on and off, and power connection. The back panel functions are described below.
  • Page 21 Back Panel Description, continued Digital Audio Inputs and Outputs, continued Video Inputs and Outputs Note Krell S–1000 44 Coaxial Digital Audio Inputs The S–1000 is equipped with four coaxial digital audio inputs with RCA connectors. 45 Digital Audio Outputs The S–1000 is equipped with one digital audio outputs: coaxial with an RCA connector.
  • Page 22 Back Panel Description, continued Note Back Panel Remote Control Connections Note Power Connections 53 HDMI™ Inputs The S–1000 is equipped with four HDMI™ video inputs. The S–1000 switches HDMI™ video only. Audio signal is not available via the HDMI™ inputs. On screen display (OSD) is not available from the HDMI™...

  • Page 23: Connecting The S-1000 To Your System

    Connecting the S–1000 to Your System FOLLOW THESE CONNECTION STEPS First: Connect Analog and Digital Sources Krell S–1000 This section provides information about connecting the S–1000 Sur- round Preamp/processor to analog and digital sources, video sources, and amplifiers. The S–1000 is equipped with balanced and single- ended inputs.

  • Page 24: Next: Connect Video Sources

    Connecting the S–1000 to Your System, Next: Connect Video Sources Note IMPORTANT: ACCESSING THE ON-SCREEN DISPLAY continued 4. Connect the video source outputs to the appropriate video inputs on the S–1000. Component video inputs. Use the component connection when the source device (DVD) and output device (TV) both feature component connections.

  • Page 25: Last: Connect Amplifiers And Sources

    Connecting the S–1000 to Your System, Last: Connect Amplifiers and Sources IMPORTANT Krell S–1000 continued The S–1000 has balanced outputs with XLR connectors and single- ended outputs with RCA connectors. Both outputs are active at all times, allowing simultaneous connection to separate amplifiers. Connect only one of these output formats to a single amplifier.

  • Page 26: Overview: System Configuration And Navigation

    Overview: System Configuration and Navigation CONFIGURATION STEPS IMPORTANT: FOR BEST RESULTS FOLLOW THESE STEPS This section briefly outlines S–1000 Surround Preamp/processor configuration menus and introduces menu navigation features. The easy-to-follow, step-by-step configuration menus let you set up your S–1000 for optimum performance. Detailed instructions begin on page 24.

  • Page 27: Navigation Conventions

    Overview: System Configuration and Navigation, NAVIGATION CONVENTIONS To Select and Enter Menu Options Krell S–1000 continued The remote control is the main input device for configuring the S–1000. For all menu mode options, use the following keys to navi- gate through the configuration menu screens: 29 Menu Key Press this key once to enter the configuration menu.

  • Page 28: System Configuration

    System Configuration ACCESSING Menu THE MAIN MENU Main Menu Screen HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.

  • Page 29: Step 1: Configure Loudspeakers

    System Configuration, continued Step 1, Listening Room Setup STEP 1 LISTENING ROOM SETUP Speaker Main Menu Screen Configure Speakers Speaker Setup Screen Krell S–1000 The first option on the main menu screen, you define the number and type of loudspeakers in your system and select the bass range for each loudspeaker.
  • Page 30 System Configuration, continued Step 1, Listening Room Setup Configure Speakers, continued Note FRONT CENTER SURROUND BACK 5.1 SURR CRSOVR Prev If you have a 5.1 system, select a 6.1 system, select . If you have a 7.1 system, select 1 BACK 2 BACK When is selected, the signal is present at the left back output.
  • Page 31 System Configuration, continued Step 1, Listening Room Setup Speaker Distance Room Setup Screen Prev Note HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.

  • Page 32: Calibrate Volume

    System Configuration, continued Step 1, Listening Room Setup Calibrate Volume Note Calibrate Room Setup Screen Auto Noise Sequence Auto Calibration Screen HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode.
  • Page 33 System Configuration, continued Step 1, Listening Room Setup AUTO NOISE SEQUENCE continued Note Manual Noise Sequence Prev Prev Note Program Material Option Krell S–1000 Set the SPL meter to C weighting and slow response. After initializ- ing, the channel dB setting on the screen blinks, and you hear LEFT band limited white noise through the left loudspeaker.

  • Page 34: Step 2: Configure Devices

    System Configuration, continued Step 2, Configure Devices IMPORTANT: PLEASE READ BEFORE STARTING STEP 2, CONFIGURE DEVICES IMPORTANT HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 35 System Configuration, continued Step 2, Configure Devices STEP 2 CONFIGURE DEVICES Configure Devices Screen Assign Video Input Assign Video Input Screen assigned input=input on back panel Krell S –1000 The second option on the main menu screen, allows you to assign video and audio inputs to source devices and configure triggers for devices in the system.
  • Page 36 System Configuration, continued Step 2, Configure Devices Assign Video Inputs, continued Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 37 System Configuration, continued Step 2, Configure Devices Assign Analog Audio Inputs Assign Audio Inputs Screen Assign Analog Audio Input Screen Krell S–1000 Select from the CONFIGURE AUDIO screen appears: AUDIO INPUTS Select ANALOG. ASSIGN ANALOG AUDIO INPUT Use the direction and enter keys to scroll through and select the device you want to configure, select the choose the analog mode, if mode options are available.
  • Page 38 System Configuration, continued Step 2, Configure Devices Assign Analog Audio Inputs, continued Assign Digital Audio Inputs Assign Digital Audio Input Screen Notes Prev allows the S–1000 to switch to the analog input AUTO-MIGRATION ON automatically, if no digital input is present. This function is particular- ly useful for SACD players.
  • Page 39 System Configuration, continued Step 2, Configure Devices Assign Lip Synch Delay Assign Lip Synch Delay Screen Prev Krell S–1000 The lip synchronization screen allows you to add an adjustable amount of delay, from 0 to 200 ms, to the digital audio signal decod- ing process.
  • Page 40 System Configuration, continued Step 2, Configure Devices Assign EQ Memory Assign EQ Memory Screen Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 41 System Configuration, continued Step 2, Configure Devices Configure Trigger Configure Trigger Screen Prev Krell S–1000 The final option on the CONFIGURE DEVICES This option allows you to customize the operation of the four remote output 12 VDC (12 Volt trigger) connectors (54) on the back panel. Select from the CONFIGURE TRIGGER...
  • Page 42 System Configuration, continued Step 2, Configure Devices Configuring Additional Inputs HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.

  • Page 43: Step 3: Configure Level Adjustment

    System Configuration, continued Step 3, Configure Level Adjustment STEP 3 CONFIGURE LEVEL ADJUSTMENT Note Configure Levels Screen Krell S–1000 Use the third option on the main menu, set trims, adjust modes, and set the main volume limit. Trims add a fixed positive or negative volume offset that allows you to compensate for devices with different volume levels.
  • Page 44 System Configuration, continued Step 3, Configure Level Adjustment Device Trim Device Trim Screen Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 45 System Configuration, continued Step 3, Configure Level Adjustment IMPORTANT: PLEASE READ BEFORE CONFIGURING ANALOG INPUT TRIM Krell S–1000 An analog device must be selected in order for the analog input trim option to function. The following screen appears if an analog device is not selected: To select an analog device, first exit the menu program by pressing the menu key (29).
  • Page 46 System Configuration, continued Step 3, Configure Level Adjustment Analog Input Trim Analog Input Trim Screen ANTI-CLIP INPUT GAIN Prev Use the menu to adjust the level of an analog input ANALOG INPUT TRIM source to the S–1000. Select from the ANALOG INPUT TRIM screen appears: INPUT TRIM...
  • Page 47 System Configuration, continued Step 3, Configure Level Adjustment Music Mode Sub Trim Music Mode Sub Trim Screen Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode.
  • Page 48 System Configuration, continued Step 3, Configure Level Adjustment DTS Control DTS Control Screen Prev Note HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 49 System Configuration, continued Step 3, Configure Level Adjustment PLII Control PLII Control Screen Prev Krell S–1000 Use the menu to adjust the signal for Dolby Pro Logic II PLII CONTROL music mode, which derives a 5.0 signal from two-channel material. DIMENSION You can adjust the sound field toward the front or rear loudspeakers, to achieve a more suitable balance from all loudspeakers with cer-...
  • Page 50 System Configuration, continued Step 3, Configure Level Adjustment Maximum Volume Limit Maximum Volume Limit Screen Prev Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.

  • Page 51: Step 4 Operation

    System Configuration, continued Step 4, Operation STEP 4 OPERATION Operation Screen OSD Operation OSD Operation Screen Krell S–1000 The final option on the main menu screen, position and display time for on-screen display (OSD), set audio operation, program a learning remote control, adjust lip synchroniza- tion, and adjust frequency response using the Krell Digital Room Equalizer.
  • Page 52 System Configuration, continued Step 4, Operation OSD Operation, continued Prev Audio Operation Audio Operation Screen HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 53 System Configuration, continued Step 4, Operation Audio Operation, continued Prev Krell S–1000 DOLBY MODE HOLD Dolby mode hold sets the time your S–1000 remains in Dolby Digital mode when the incoming bitstream is interrupted. Bitstreams are interrupted in some devices when you press and release fast forward, track back/forward, or change channels for a compact disc, video disc, or satellite receiver.
  • Page 54 System Configuration, continued Step 4, Operation 7.1 Input Setup 7.1 Input Setup Screen Prev HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 55 System Configuration, continued Step 4, Operation Program Remote Note Program Remote Screen A Program Remote Screen B Krell S–1000 menu allows you to program a learning remote PROGRAM REMOTE control to operate the S–1000. The infrared sensor on the front panel is inactive until programming is com- plete.
  • Page 56 System Configuration, continued Step 4, Operation Program Remote, continued Prev System Information System Information Screen Prev 1. Rotate the knob (26) on the front panel to select a command. The command appears on the front panel display window (20). 2. Place the programmable remote in program mode (see the learn- ing remote user manual).
  • Page 57 System Configuration, continued Step 4, Operation IMPORTANT: PLEASE READ BEFORE CONFIGURING ROOM EQ SETUP ADJUSTABLE PARAMETERS HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.
  • Page 58 System Configuration, continued Step 4, Operation CHANNEL SELECTION IMPORTANT APPLYING YOUR CONFIGURATIONS SAVING ROOM EQ SETUP MEMORY USING ROOM EQ SETUP IN THE OPERATIONAL MODE HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode.
  • Page 59 System Configuration, continued Step 4, Operation Room EQ Setup Room EQ Setup Screen IMPORTANT Krell S–1000 The final item on the OPERATION adjust your loudspeaker to your listening area using the Krell Digital Room Equalizer. Select ROOM EQ SETUP screen appears, with the cursor blinking at ROOM EQ SETUP Use the direction and enter keys on the S–1000 remote control to scroll through and select the following step-by-step options for...
  • Page 60 System Configuration, continued Step 4, Operation Room EQ Setup continued Note Prev Prev Menu HOW TO NAVIGATE IN THE MENU MODE 1 Press the menu key (29) to enter and exit the menu mode from the operational mode. 2 Press the direction keys (33) to scroll from line to line, and to scroll through options within a line.

  • Page 61: Saving And Recalling Customized Settings And Restoring The Factory Default System Settings

    RESTORING THE FACTORY DEFAULT SYSTEM SETTINGS Note Krell S-1000 To save the customized settings that you have entered, press and hold the save button (25) for approximately four seconds. The front panel displays while the settings are being stored in the SAVING SETUP nonvolatile memory of the S–1000 Surround Preamp/processor.

  • Page 62: Operating The S-1000

    2. Use the tape input to compare the output signal of a three-head analog tape recorder to the output signal of an audio source. Press the tape button or key (14) to switch between the tape recorder output (LED illuminated) and the input source (LED not illuminated). Krell S-1000...

  • Page 63: Simulcast

    Operating the S–1000, continued Tape Input and Output, continued Notes SIMULCAST Krell S–1000 3. Use the tape output to create a processor loop, when the S–1000 is connected to a graphic equalizer or other ancillary equipment. Connect the equipment to the S–1000 tape outputs (34) as described in the equipment manufacturer’s manual.

  • Page 64: Appendix: Operating Modes For The S-1000

    Appendix: Decoding Modes for the S–1000 AUTOMATICALLY DETECTED MODES Note The S–1000 Surround Preamp/processor automatically engages the appropriate decoding mode for the following signals: DOLBY DIGITAL 2.0 OR DOLBY DIGITAL 2.0 + DOLBY PRO LOGIC Select a Dolby Digital 2.0 or Dolby Digital 2.0 + Dolby Pro Logic default mode using the configuration menu.

  • Page 65: User Selectable Modes

    Appendix: Additional Decoding Modes for the S–1000, continued USER SELECTABLE MODES Dolby Pro Logic II Modes DTS Neo:6 Modes Krell S–1000 User selectable modes available on the S–1000 are listed below: Dolby Pro Logic II is the next generation in Dolby Surround decod- ing.
  • Page 66 Appendix: Additional Decoding Modes for the S–1000, continued Krell Music Surround Modes TABLE 6 Krell Music Surround Modes for the S–1000 Krell Music Surround Modes simulate different soundfield experiences when listening to music. The table below lists the modes and the loudspeakers that operate within each mode: OPERATING MODES GENERAL ADMISSION...

  • Page 67: Warranty

    Warranty To register your product for warranty benefits, please complete and return the Warranty Registration Card enclosed in the shipping box within 15 days of purchase. Thank you. Krell S–1000 Krell products have a limited warranty. Amplifiers, preamplifiers, pre- amp/ processors, and receivers carry a limited warranty of five years for parts and labor on circuitry.
  • Page 68 Warranty, continued Freight to the factory is your responsibility. Return freight within the United States (U.S.A.) is included in the warranty. If you have pur- chased your Krell product outside the U.S.A. and wish to have it ser- viced at the factory, all freight and associated charges to the factory are your responsibility.

  • Page 69: Return Authorization Procedure

    Return Authorization Procedure HOW TO EXPEDITE SERVICE ACCESSING THE SERVICE REQUEST FORM TO CONTACT THE KRELL SERVICE DEPARTMENT HOW TO RETURN A PRODUCT IMPORTANT HOW TO PURCHASE ADDITIONAL PACKING SERIAL NUMBER Krell S–1000 If you believe there is a problem with your component, please con- tact your dealer, distributor, or the Krell factory to discuss the prob- lem before you return the component for repair.

  • Page 70: Specifications

    Specifications SIGNAL-TO-NOISE RATIO TOTAL HARMONIC DISTORTION (THD) INPUTS OUTPUTS REMOTE DECODING MODES "A" WEIGHTED UNWEIGHTED ANALOG AUDIO DIGITAL AUDIO VIDEO ANALOG TAPE HDMI ANALOG CHANNEL (one per channel) ANALOG TAPE DIGITAL VIDEO HDMI REMOTE CONTROL REMOTE CONNECTORS 94 dB 20 Hz-20 kHz, -88 dB 1 pair balanced via XLR connectors 7 pairs single-ended via RCA connectors 8 7.1 via RCA connectors...

  • Page 71: Specifications

    Specifications, continued SURROUND ENHANCEMENT MODES POWER CONSUMPTION DIMENSIONS WEIGHT Krell S–1000 KRELL MUSIC SURROUND INCHES CENTIMETERS SHIPPING UNIT ONLY All operational features, functions, specifications, and policies are subject to change without notification. General Admission Front Row On Stage Enhanced Stereo Orchestra Mezzanine Full Range + Sub...
  • Page 72 Krell Industries, Inc. 45 Connair Road Orange, CT 06477-3650 USA TEL 203-298-4000 FAX 203-891-2028 E-MAIL krell@krellonline.com WEBSITE http://www.krellonline.com SURROUND S–1000 PREAMP/PROCESSOR v 07.0...
