Summary of Contents for Graco RentalPro 360G 255667
Page 1
Important Safety Instructions Read all warnings and instructions in this manual. Save these instructions. ti10809a Related Manuals 312521 311861 310894 309640 Graco Inc. P.O. Box 1441 Minneapolis, MN 55440-1441 Copyright 2005, Graco Inc. is registered to I.S. EN ISO 9001...
Warning Warning The following are general warnings related to the setup, use, maintenance and repair of this equipment. Additional, more specific, warnings may be found throughout the text of this manual, where applicable. WARNING FIRE AND EXPLOSION HAZARD Flammable fumes, such as solvent and paint fumes, in work area can ignite or explode. To help prevent fire and explosion: •...
Page 4
Do not install a shut-off device between filter outlet and gun. • Use equipment only for its intended purpose. Call your Graco distributor for information. • Route hoses and cables away from traffic areas, sharp edges, moving parts, and hot surfaces.
Maintenance Maintenance Pressure Relief Procedure Maintenance Chart Interval What to do WARNING Daily Check engine oil level and fill as necessary. Check hose for wear and damage. Read Injection Hazard, page 3; Burn Hazard, page 4 Check that all hose fittings are secure. Lock gun trigger safety.
Keep sprayer upright to avoid oil seepage False tripping of WatchDog sys- Operating conditions out of Watch- Turn pressure down. Contact Graco Techni- tem. Pump does not run. Dog parameters cal Assistance to adjust WatchDog parame- Pump output is low, page 7.
Page 7
Troubleshooting Problem Cause Solution Pump output is low Strainer (82) is clogged Clean strainer. Piston ball is not seating Service piston ball. Manual 310894. Piston packings are worn or damaged Replace packings. Manual 310894. O-ring in pump is worn or damaged Replace o-ring.
Bearing Housing and Connecting Rod Bearing Housing and Connecting Rod Removal CAUTION DO NOT use bearing housing screws (41) to align or WARNING seat bearing housing with drive housing. Align these parts with locating pins, to avoid premature bearing wear. Read Injection Hazard, page 3;...
Drive Housing Drive Housing Removal CAUTION DO NOT use drive housing screws (38) to align or seat WARNING drive housing with pinion housing. Align these parts with locating pins, to avoid premature bearing wear. Install screws (38) in drive housing. Torque evenly to note Read Injection Hazard, page 3;...
Pinion Assembly/Clutch Armature/Clamp Installation Clutch Armature Install armature (25) on engine drive shaft. Install four screws (23) and lock washers (24) with torque . 8. Lay two stacks of two dimes on smooth bench of 125 in-lb. surface. Pinion Assembly Lay armature (25) on two stacks of dimes.
Clutch Housing Clutch Housing Removal . 11. Remove four screws (20) and lock washers (21) which hold clutch housing (19) to engine. Remove screw (35) from under mounting plate (D). Pull off clutch housing (19). Installation . 11. Push on clutch housing (19). Install four capscrews (20) and lock washers (21) and secure clutch housing (19) to engine.
Pressure Control Pressure Control Pump ON/OFF Switch Removal Installation Install new pump ON/OFF switch (130f) so tabs of switch snap into place on inside of cover. WARNING Connect pump ON/OFF switch connector to control board. Swing up cover (130a) and secure with two screws (71). Read Injection Hazard, page 3;...
Pressure Control Control Board Removal • Display connector (130m) • Engine, ground and clutch wires Remove four screws (130c) and control board (130b). WARNING Installation . 14. Install control board (130b) with four screws (130c). Connect engine wires to control board (130b). Connect at control board (130b): Read Injection Hazard, page 3;...
Displacement Pump Displacement Pump Removal Raise latch lock. Push latch open. Flush pump. Stop pump with piston rod in its lowest position. WARNING Read Injection Hazard, page 3; Burn Hazard, page 4 Do Pressure Relief, page 5. Separate drain hose from sprayer .
Page 16
Displacement Pump Twist latch u-bolt back from pump door outer edge 10. F . 23. Pull out pump pin and place in pin holder Place u-bolt on pump door protrusion . 20 Ratchet pump door forward. . 23 Installation . 24. Adjust piston rod with pin holder to pull out piston rod.
Page 17
. 28. Attach drain hose to sprayer. Do not tighten latch. . 28 . 29. Fill pump with Graco TSL until fluid flows onto top . 26. Rotate pump to align with paint hose. Connect of seal. paint hose and hand tighten to 70 in-lb .
Pressure Control and Filter Parts List Pressure Control and Filter Parts List PART DESCRIPTION PART DESCRIPTION 150g 116424 NUT, cap, hex, hd †◆ 287510 Filter Replacement Kit 248314 PLUG, (Standard) includes 152 ★ † 15C765 CAP, filter 15D541 O-RING, Standard) ★†...
Technical Data Technical Data Honda GX120 Engine ANSI Power Rating @ 3600 rpm 4.0 Horsepower (3.0 kW) Maximum working pressure 3300 psi (228 bar, 22.8 MPa) Noise Level Sound power 105 dBa per ISO 3744 Sound pressure 96 dBa measured at 3.1 feet (1 m) Maximum delivery rating 1.25 gpm (4.73 liter/min) Maximum tip size...
With the exception of any special, extended, or limited warranty published by Graco, Graco will, for a period of twelve months from the date of sale, repair or replace any part of the equipment determined by Graco to be defective.
