Summary of Contents for Dishlex DSF6105W
- Page 1 User Manual Dishwasher DSF6105W DSF6105X...
-
Page 2: Table Of Contents
Contents Safety information Hints and tips Safety instructions Care and cleaning Control panel Troubleshooting Programs Technical information Before first use Warranty Daily use Subject to change without notice. Safety information Before the installation and use of the appliance, carefully read the supplied instructions. -
Page 3: Safety Instructions
If the supply cord is damaged, it must be replaced by the manufacturer, its • Authorised Service Centre or a similarly qualified persons in order to avoid a hazard. Put knives and cutlery with sharp points in the cutlery basket with the •... -
Page 4: Control Panel
• Do not drink and play with the water in the • When you contact the Authorised Service Centre, appliance. ensure that you have the following information that • Do not remove the dishes from the appliance until is available on the rating plate. the programme is completed. -
Page 5: Programs
Indicator Description Rinse aid indicator. It is always off while the program operates. Half Load indicator. Programs Program Degree of soil Program phases Consumption values Type of load Duration Energy Water (min) (kWh) • Prewash Normal soil 0.75 11.7 • Wash 50 °C Crockery and •... -
Page 6: Before First Use
Before first use 1. Fill the rinse aid dispenser. 2. Open the water tap. 3. Start a program to remove any processing residuals that can still be inside the appliance. Do not use detergent and do not load the baskets. Adding rinse aid The rinse aid helps to dry the dishes without streaks and stains. - Page 7 Adding multi-tablets • Set the rinse aid dispenser to the lowest position. Program selection mode The appliance must be in Program selection mode to start a program. If the control panel does not show this condition, use the Reset function. Reset With Reset you can cancel the running program .
- Page 8 Open the water tap, close the door, select a program, press Option Half load 1. Set the program. 2. Press the related indicator comes on. 3. Press to start the program. This option is available with With this option you can wash a small load of tableware and cookware. The option decreases the program duration and the consumption of water and energy.
-
Page 9: Hints And Tips
At the end of the program 5 min The indicator comes on. If you do not deactivate the appliance within 5 minutes all indicators goes off. This helps to decrease energy consumption. Turn the knob to . Close the tap. Hints and tips General Using rinse aid and detergent... -
Page 10: Care And Cleaning
Loading the baskets • The filters are clean and correctly installed. • The spray arms are not clogged. • Only use the appliance to wash items that are • There is dishwasher rinse aid (unless you use multi- dishwasher-safe. tablets). •... -
Page 11: Troubleshooting
• Put back the filter (A) in the flat filter (C). Turn it clockwise until it locks. An incorrect position of the filters can cause bad washing results and damage to the appliance Cleaning the spray arms Internal cleaning Do not remove the spray arms. If the holes in the spray •... -
Page 12: Technical Information
The washing and drying results are not satisfactory Problem Possible solution • The release quantity of rinse aid is too much. Adjust the rinse aid selec- There are whitish streaks or bluish lay- tor to a lower position. ers on glasses and dishes. •... - Page 13 APPLIANCE: DISHWASHER accessible for service, without special equipment and subject to these terms and conditions, repair or This document sets out the terms and conditions of replace any parts which it considers to be the product warranties for Electrolux Appliances. It defective.
-
Page 14: Environment Concerns
purposes the Consumer Guarantee Act does not replacement or refund will apply if an Appliance has apply. a valid warranty claim applicable to it. 9. To the extent permitted by law, Electrolux excludes 12. For Appliances and services provided by Electrolux all warranties and liabilities (other than as in New Zealand, the Appliances come with a contained in this document) including liability for... - Page 16 156978590-A-282014...
