750
Weight Indicating Instrument
With Body Mass Index Features
Owner's Manual
CARDINAL SCALE MFG. CO.
8555-M260-O1 Rev F
PO Box 151 Webb City, MO 64870
09/07
Printed in USA
Ph: 417-673-4631 Fax: 417-673-5001
www.detectoscale.com
Technical Support: Ph: 866-254-8261 techsupport@cardet.com

Advertisement

Table of Contents
loading

Related Manuals for Detecto 750

Summary of Contents for Detecto 750

  • Page 1 Weight Indicating Instrument With Body Mass Index Features Owner’s Manual CARDINAL SCALE MFG. CO. 8555-M260-O1 Rev F PO Box 151 Webb City, MO 64870 09/07 Printed in USA Ph: 417-673-4631 Fax: 417-673-5001 www.detectoscale.com Technical Support: Ph: 866-254-8261 techsupport@cardet.com...

  • Page 3: Table Of Contents

    750 INDICATOR TABLE OF CONTENTS Thank you for purchasing our Detecto Model Specifications ..... . 1 750 Weight Indicating Instrument. It has Proper Disposal .
  • Page 4 Page 2 8555-M260-O1 750 Indicator...

  • Page 5: Specifications

    Please do your part by making certain that this device is properly disposed of. The symbol shown below indicates that this device must not be disposed of in unsorted municipal waste programs. Page 1 8555-M260-O1 750 Indicator...

  • Page 6: European Declaration Of Conformity

    Telephone No. 417 673 4631 Fax No. 417 673 5001 Product: Non-automatic Weight Indicating Instrument Model Number 750 Serial Number EXXXYY-ZZZ where XXX = day of year YY = last two digits of year ZZZ = sequential number The undersigned hereby declares, on behalf of Cardinal Scale Manufacturing Company of...

  • Page 7: Installation

    Pull down to secure the indicator. The spring plunger will lock the indicator to the bracket. See Figures No. 1, 2 and 3. Spring Plunger Load Cell Cable Power Figure No. 1 Figure No. 2 Supply Spring Plunger Release Figure No. 3 Page 3 8555-M260-O1 750 Indicator...

  • Page 8: Power Connections

    Alkaline batteries. Battery Operation The 750 indicator will operate for up to 250 hours on new Alkaline batteries or for up to 100 hours on fully charged Ni-Cad or NiMH batteries depending on the condition of the batteries (from new to about 500 recharges).

  • Page 9: Battery Installation/Replacement

    9. If display turns on, batteries have been installed correctly. If not, remove panel and check for one or more improperly positioned batteries. 10. Return the indicator to the scale. 11. The scale is now ready for operation. Figure No. 5 Page 5 8555-M260-O1 750 Indicator...

  • Page 10: Keypad Functions

    Damage to keypad resulting from this practice is NOT covered under warranty. With the indicator off, pressing this key will apply power to the indicator and turn on the display. If the indicator is on, pressing this key will display 7 and turn the indicator off. Page 6 8555-M260-O1 750 Indicator...
  • Page 11 The ZERO key can be used to clear the recorded values. Use the a or b keys to scroll through the 10 records. Press any other key to return the indicator to normal operation. NOTE! While reviewing the recorded weights, the display will alternate between the transaction number and the weight. Page 7 8555-M260-O1 750 Indicator...

  • Page 12: Annunciators

    This annunciator is turned on to indicate that the displayed weight is in pounds. This annunciator is turned on when the displayed height measurement is in centimeters. FEET INCHES These annunciators are turned on when the displayed height measurement is in feet and inches. Page 8 8555-M260-O1 750 Indicator...

  • Page 13: Operation

    NOTE! The BMI / ENTER key can be used to toggle between the calculated BMI value and the weight until the scale goes below 10% of capacity (40 lbs). At that point, a new height input is required. Page 9 8555-M260-O1 750 Indicator...

  • Page 14: Setup And Calibration

    SETUP AND CALIBRATION Your Model 750 indicator has been thoroughly tested and calibrated before being shipped to you. If you received the indicator with a scale, calibration is not necessary. If the indicator is being connected to a scale for the first time or recalibration is necessary for other reasons, proceed as indicated.
  • Page 15 BMI / ENTER key to save it and proceed to the next prompt. Allowable values are: 0 = Minimal Filter 1 = Moderate Filter 2 = Heavy Filter 3 = Custom Filter NOTE! If 3 = Custom Filter is selected, two additional prompts will be displayed. Page 11 8555-M260-O1 750 Indicator...
  • Page 16 6. Starting at the left and preceding right, a series of dashes will appear on the display. The dashes will stay on the display momentarily, then disappear, after which the display will proceed to the next prompt. Page 12 8555-M260-O1 750 Indicator...
  • Page 17 Consult the factory Tech Support for the Acceleration of Gravity value for your location. NOTE! Once the Gravity Constant has been set, both "? and 7%? must be set to the same value to disable it. Page 13 8555-M260-O1 750 Indicator...
  • Page 18 BMI / ENTER key to save it and proceed to the next prompt. Allowable values are: 0 or 1. PUO = 1 (YES) PUO = 0 (NO) Weight display will be reset to weight display will not be reset to zero zero automatically on power up Page 14 8555-M260-O1 750 Indicator...
  • Page 19 Allowable values are 0 through 9 with 0 disabling Automatic Shutoff. Setup and Calibration Is Completed The setup and calibration process has been completed. The indicator will reset and then turn off. Remove power from the indicator and re-assemble for use. Page 15 8555-M260-O1 750 Indicator...

  • Page 20: Setup Review

    SETUP REVIEW The 750 indicator allows several operational parameters to be reviewed and changed as necessary without having to enter the setup mode. To Enter Setup Review: 1. If indicator is on, press ON / OFF key. 2. Display will show 7 and indicator will turn off.

  • Page 21: Before You Call Service

    6. DO remove power before cleaning with a damp cloth. 7. DO provide clean AC power and adequate protection against lightning damage. 8. DO keep the surroundings clear to provide clean and adequate air circulation. Page 17 8555-M260-O1 750 Indicator...

  • Page 22: Event Counter

    EVENT COUNTER The 750 weight indicating instrument has been designed with an Event Counter type of security seal. When selected, the 750 will display two 3-digit numbers representing the Calibration and Configuration counters. Calibration Counter The calibration counter is incremented when a value in the calibration part of setup is changed ((+, .1<, (1.<, <:, (1+, 4%%, %, "<, , 3:, +:, ", +5<, ",...

  • Page 23: Parts Identification

    SCREW, #6X.375 TH SHEET METAL (BLACK) 6021-2069 SCREW, #6X.50 TH SHEET METAL (WHITE) 6021-0687 SCREW, #6-32X.312 THMS W/THD-LOCK PATCH 593GR986 SERIAL TAG 6680-0052 WASHER, #4 LOCK HELICAL ½ PART OF ITEM 2, PC BOARD, 8555-D251-0A Page 19 8555-M260-O1 750 Indicator...
  • Page 24 PARTS IDENTIFICATION, Cont. Page 20 8555-M260-O1 750 Indicator...
  • Page 25 PARTS IDENTIFICATION, Cont. Page 21 8555-M260-O1 750 Indicator...

  • Page 26: Statement Of Limited Warranty

    (1) year from date of shipment. Detecto shall be the sole judge of what constitutes a defect.
  • Page 27 This warranty sets forth the extent of our liability for breach of any warranty or deficiency in connection with the sale or use of the product. Detecto will not be liable for consequential damages of any nature, including but not limited to, loss of profit, delays or expenses, whether based on tort or contract.
  • Page 28 Page 24 8555-M260-O1 750 Indicator...
