  • Page 1 Solice Mini Audio Mixer Operation Manual...
  • Page 2: Table Of Contents

    For Mixers with PCB Version 3.0 Copyright 2014 Professional Sound Corporation Valencia ca usa Table of Contents: INTRODUCTION: Panel Views Introduction Safety Warnings Overview Construction INPUT SECTION: Input Panel View Microphone Input (CH 1 & 2) Microphone Power Line Inputs (CH3 through CH8) Pre-Amplifier Gain Setting High Pass Filter...
  • Page 3 REAR PANEL: Rear Panel View Main outputs (Left, Right, Mono) Auxiliary Output External Power Connection Slate Output Link Connection Multi-Pin Connector SPECIFICATIONS CONNECTOR PIN-OUTS 18-19 RoHS CE Mark Warranty...
  • Page 4: Panel Views

    TOP VIEW REAR PANEL VIEW...
  • Page 5 LEFT SIDE PANEL VIEW RIGHT SIDE PANEL VIEW MAIN OUTPUT METERS VIEW...
  • Page 6: Introduction

    Introduction Thank you for purchasing the Professional Sound Corporation Solice Mini Portable Audio Mixer. The Solice Mini is the result of our desire to provide you with a comprehensive, yet simple to use portable mixer. The idea for developing this mixer came from Mr. Pascal Van Strydonck who volunteered many hours of his time outlining the need for a small, compact and flexible mixer.
  • Page 7: Construction

    This powder coating is super tough and should provide years of service in the field. All silk-screen lettering on the Solice Mini is applied to the back side of tough Lexan tm overlays. Printing the lettering and graphics on the back side of a clear overlay provides years of wear free use.
  • Page 8: Input Panel View

    Input Channel Panel View 48 Phantom Mic Power Switch High EQ Limiter LED +10dB LED 0dB LED -20dB LED Hi Pass Filter Pan Switch Gain Control Aux Send Pre-Fader Listen 100mm Fader...
  • Page 9: Microphone Input (Ch 1 & 2)

    -15dB or -10dB and then adjust the gain setting on the Solice Mini’s input channel to match that audio level. We recommend the -10dB or -15dB setting on your wireless to maximize the headroom on the wireless output.
  • Page 10: Gain Setting

    High Pass Filters Each input channel of the Solice Mini mixer is equipped with a 3-way switchable high pass filter (low frequency roll off). The filters are very useful for eliminating wind rumble and air conditioning noise. As a general rule, you should only use as much low frequency roll off as needed to get a good recording.
  • Page 11: Pan Switch

    Comtek transmitter to transmit audio to the director. Direct Line Output: Each input channel on the Solice Mini mixer is equipped with a dedicated direct line output. This output can be used to feed multi-track recorders when recording separate tracks for each actor.
  • Page 12: Pre-Fade Listen Switch

    “0” line. This will leave you with an additional 10dB of signal range if needed for those hard to mix actors. Pre-Fade Listen Switch Each input channel of the Solice Mini mixer is equipped with a Pre-Fader Listen switch. These latching pushbutton switches are located at the bottom of each input channel.
  • Page 13: Output Panel View

    Slate Level Private Line (slate element) Power Switch The main power switch for the Solice Mini mixer is located just to the right of the main output meters. This switch controls an internal relay which powers up the entire mixer.
  • Page 14: Reference Tone Oscillator Switch

    LED output is very bright. Slate Microphone, Internal and External: The Solice Mini mixer is equipped with a built in Slate Microphone used for voice slating of takes, mixer voice notes, etc. This same built in microphone is used for the Private Line function that allows the mixer operator to talk to the boom operator.
  • Page 15: Slate Microphone Gain

    The Mixer’s headphone monitoring section allows the use of tape returns. These “Tape Return Audio Inputs” are contained on the TB3M “Returns” connector on the rear panel of the Solice Mini mixer. There are two tape returns “Left” and “Right”. These tape returns allow the operator to monitor “Tape” confidence (an old, outdated, but still used term for recording verification) to insure that audio is actually being recorded.
  • Page 16: Headphone Selection

    the operator desires to check the tape inputs, he or she simply switches the headphone select rotary switch to “Return” and your headphones are automatically switched to monitor the tape return inputs. If you are not using any form of tape monitoring, you can also use this input to be able to monitor an iPod or other similar audio source for your convenience.
  • Page 17: Peak Reading Meters

    Main Output Level Adjustment The Solice Mini mixer is equipped with a 3-way output level switch and also an output fine trim pot. The output level switch allows the operator to select from three common output levels.
  • Page 18: Main Outputs (Left, Right, Mono)

    Main (Left, Right and Mono) Mini XLR Outputs The Solice Mini mixer is a two buss mixer and thus has two main balanced outputs. The balanced outputs are located on the rear panel of the mixer and utilize “mini” size 3 pin male XLR connectors.
  • Page 19: Link Connection

    The link connector provides audio to and from the summing amplifier. You can use this connection to connect or “Link” two Solice Mini mixers. You can also use it as a summing input to accept audio from another small auxiliary mixer.
  • Page 20: Specifications

    SPECIFICATIONS: Size: 13.125” wide, 10.250” deep, 2.00” high 34cm wide, 26cm deep, 5.1cm high Weight: 4 Lbs, 1.8 Kg Operating Temperature: -20F to +120F, -7C to +49C External Power: 10 to 18Vdc, approx 7 to 10 watts Meters: LED, Peak Reading, Multi-Colored Slate Microphone: Electret Condenser Reference Oscillator:...
  • Page 21: Connector Pin-Outs

    Solice Mixer Connector Pin Outs External Power XLR-4-Male Pin 1 = Ground Pin 2 = N.C. Pin 3 = N.C. Pin 4 = +10 to +18Vdc Channel Inputs: DB-25 Female wiring: INPUT NUMBER COLD GROUND *Note* pin 13 is N.C. Channel Outputs: DB-25 Male wiring: INPUT NUMBER...
  • Page 22 Pin 3 = Audio Low Aux Output TB3M Pin 1 = Ground Pin 2 = Audio High Pin 3 = Audio Low Slate Output TB3M Pin 1 = Ground Pin 2 = Audio High Pin 3 = Audio Low Returns Input TB3M Pin 1 = Ground Pin 2 = Left Input...
  • Page 23: Rohs

    RoHS Certificate of Compliance Professional Sound Corporation certifies that all products designated by Professional Sound Corporation as “PB-Free”, “RoHS Compliant” or “Green” are compliant with the requirements of the European Union’s Restriction on Use of Hazardous Substances (“RoHS”) Directive, 2002/95/EC. Professional Sound Corporation bases its material content knowledge on information provided by third parties, including parts manufacturers, distributors and vendors.
  • Page 24: Ce Mark

    Low Voltage Directive, 73/23/EEC. 93/68/EEC as defined in EN60065, 1993 and/or EN60950/A1/A2/A3: 1995 TRADE NAME: MODEL: Solice Mini Mixer RESPONSIBLE PARTY: Professional Sound Corp. 28085 Smyth Drive Valencia, CA 91355 USA CONTACT PERSON: Ronald Meyer (661) 295-9395...
  • Page 25: Warranty

    PSC Solice Mini Mixer Limited Warranty Professional Sound Corporation warrants the Solice Mini Mixer to be free of defective material and workmanship for a period of one year from the original date of purchase and agrees to repair or replace such defective parts or the whole product at its option, provided that the equipment is returned to Professional Sound Corporation.
