Page 1 2 0 1 1 O W N E R ’ S M A N U A L I n f o r m a t i o n P r o v i d e d b y :...
Page 2 With respect to any Vehicles Sold in Canada, the name This manual illustrates and describes the operation of Chrysler Group LLC shall be deemed to be deleted and features and equipment that are either standard or op- the name Chrysler Canada Inc. used in substitution tional on this vehicle.
Page 3: Table Of Contents
TABLE OF CONTENTS SECTION PAGE ............3 INTRODUCTION .
Page 4 I n f o r m a t i o n P r o v i d e d b y :...
Page 5 INTRODUCTION CONTENTS Introduction ......4 Vehicle Identification Number ....6 How To Use This Manual .
Page 6: Introduction
4 INTRODUCTION INTRODUCTION When it comes to service, remember that your authorized Congratulations on selecting your new Chrysler Group dealer knows your vehicle best, has factory-trained tech- LLC vehicle. Be assured that it represents precision nicians and genuine MOPAR parts, and cares about workmanship, distinctive styling, and high quality - all your satisfaction.
Page 7 INTRODUCTION 5 I n f o r m a t i o n P r o v i d e d b y :...
Page 8: Vehicle Identification Number
6 INTRODUCTION WARNINGS AND CAUTIONS This Owner’s Manual contains WARNINGS against op- erating procedures that could result in a collision or bodily injury. It also contains CAUTIONS against proce- dures that could result in damage to your vehicle. If you do not read this entire manual, you may miss important information.
Page 9: Vehicle Modifications/Alterations
INTRODUCTION 7 VEHICLE MODIFICATIONS/ALTERATIONS WARNING! Any modifications or alterations to this vehicle could seriously affect its roadworthiness and safety and may lead to a accident resulting in serious injury or death. I n f o r m a t i o n P r o v i d e d b y :...
Page 10 I n f o r m a t i o n P r o v i d e d b y :...
Page 11: Things To Know Before Starting Your Vehicle
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE CONTENTS ▫ Rearming Of The System ....17 A Word About Your Keys ....12 ▫...
Page 12 10 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE ▫ Programming Additional Transmitters ..22 ▫ Wind Buffeting ..... . . 38 ▫...
Page 13 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 11 ▫ Seat Belts And Pregnant Women ..54 Safety Tips ......80 ▫...
Page 14: A Word About Your Keys
12 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE A WORD ABOUT YOUR KEYS The Keyless Ignition Node (KIN) has four operating Your vehicle uses a keyless ignition system. This system positions, three of which are labeled and will illuminate consists of a Key Fob with Remote Keyless Entry (RKE) when in position.
Page 15: Key Fob
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 13 Key Fob The Key Fob also contains the Remote Keyless Entry (RKE) transmitter and an emergency key, which stores in the rear of the Key Fob. The emergency key allows for entry into the vehicle should the battery in the vehicle or the Key Fob go dead.
Page 16: Ignition Or Accessory On Message
14 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To remove the emergency key, slide the mechanical latch Ignition Or Accessory On Message on the back of the Key Fob sideways with your thumb Opening the driver’s door when the ignition is in ACC or and then pull the key out with your other hand.
Page 17: Sentry Key
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 15 SENTRY KEY WARNING! The Sentry Key Immobilizer system prevents unauthor- • Never leave children alone in a vehicle. Leaving ized vehicle operation by disabling the engine. The system does not need to be armed or activated. Operation unattended children in a vehicle is dangerous for a is automatic, regardless of whether the vehicle is locked number of reasons.
Page 18: Replacement Keys
16 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Key Fob to start the engine. Either of these conditions will Replacement Keys result in the engine being shut off after two seconds. NOTE: Only Key Fobs that are programmed to the If the Vehicle Security Light turns on during normal vehicle electronics can be used to start and operate the vehicle operation (vehicle running for longer than 10 sec-...
Page 19: Customer Key Programming
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 17 NOTE: When having the Sentry Key Immobilizer VEHICLE SECURITY ALARM — IF EQUIPPED system serviced, bring all vehicle Key Fobs with you to The Vehicle Security Alarm monitors the vehicle doors an authorized dealer. for unauthorized entry and the Keyless Enter-N-Go Start/Stop button for unauthorized operation.
Page 20: To Arm The System
18 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Arm The System NOTE: • The Vehicle Security Alarm remains armed during Press the Keyless Enter-N-Go Start/Stop button until the Electronic Vehicle Information Center (EVIC) indicates trunk entry. Pressing the RKE transmitter or Passive that the vehicle ignition is OFF (refer to “Starting Entry TRUNK button will not disarm the Vehicle Procedures”...
Page 21: Illuminated Entry - If Equipped
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 19 If the Vehicle Security Alarm is armed and the battery ILLUMINATED ENTRY — IF EQUIPPED becomes disconnected the Vehicle Security Alarm will The courtesy lights will turn on when you use the remain armed when the battery is reconnected.
Page 22: Remote Keyless Entry (Rke)
20 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE REMOTE KEYLESS ENTRY (RKE) The RKE system allows you to lock or unlock the doors, open the trunk, or activate the Panic Alarm from dis- tances up to approximately 66 ft (20 m) using a hand-held Key Fob with RKE transmitter.
Page 23: To Lock The Doors
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 21 If the vehicle is equipped with Passive Entry, refer to Turn Headlights On With Remote Key Unlock “Keyless Enter-N-Go” under “Things To Know Before This feature activates the headlights for up to 90 seconds Starting Your Vehicle”...
Page 24: To Unlatch The Trunk
22 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE turned on or turned off. To change the current setting, The Panic Alarm will stay on for three minutes unless refer to “Uconnect Touch™ Settings” in “Understanding you turn it off by either pressing the PANIC button a Your Instrument Panel”...
Page 25: Transmitter Battery Replacement
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 23 Transmitter Battery Replacement The recommended replacement battery is one CR2032 battery. NOTE: • Perchlorate Material — special handling may apply. See www.dtsc.ca.gov/hazardouswaste/perchlorate • Do not touch the battery terminals that are on the back housing or the printed circuit board.
Page 26: General Information
24 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE battery with your fingers. Skin oils may cause battery If your RKE transmitter fails to operate from a normal deterioration. If you touch a battery, clean it with rubbing distance, check for these two conditions: alcohol.
Page 27: How To Use Remote Start
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 25 • Vehicle theft alarm not active How To Use Remote Start All of the following conditions must be met before the • Ignition in OFF state engine will remote start: • Shift lever in PARK WARNING! •...
Page 28 26 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Remote Start Abort Message On Electronic Vehicle programmed). Then, the engine will start and the vehicle Information Center (EVIC) — If Equipped will remain in the Remote Start mode for a 15-minute The following messages will display in the EVIC if the cycle.
Page 29: Door Locks
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 27 To Exit Remote Start Mode Without Driving The DOOR LOCKS Vehicle Manual Door Locks Press and release the REMOTE START button one time or To lock each door, push the door lock knob on each door allow the engine to run for the entire 15 minute cycle.
Page 30: Power Door Locks
28 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If the door lock knob is down when you shut the door, Power Door Locks the door will lock. Therefore, make sure the key is not A power door lock switch is on each front door trim inside the vehicle before closing the door.
Page 31 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 29 The doors can also be locked and unlocked with the NOTE: Use the Automatic Door Locks feature in accor- Keyless Enter-N-Go (Passive Entry) system. For further dance with local laws. information, refer to “Keyless Enter-N-Go” in “Things To Automatic Unlock Doors On Exit Know Before Starting Your Vehicle”.
Page 32: Child-Protection Door Lock System - Rear Doors
30 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To change the current setting, refer to “Uconnect Touch™ 3. Repeat steps 1 and 2 for the opposite rear door. Settings” in “Understanding Your Instrument Panel” for further information. NOTE: Use the Automatic Unlock Doors On Exit feature in accordance with local laws.
Page 33: Keyless Enter-N-Go
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 31 NOTE: For emergency exit from the rear seats when the Child-Protection Door Lock System is engaged, manually raise the door lock knob to the unlocked position, roll down the window, and open the door using the outside door handle.
Page 34 32 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE time out. Pulling the deactivated front door handle will reactivate the door handle’s passive entry feature. • If wearing gloves on your hands, or if it has been raining on the passive entry door handle, the unlock sensitivity can be affected, resulting in a slower re- sponse time.
Page 35 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 33 To Unlock From The Passenger Side: Preventing Inadvertent Locking Of Passive Entry RKE With a valid Passive Entry RKE transmitter within 5 ft Transmitter In Vehicle (1.5 m) of the passenger door handle, grab the front To minimize the possibility of unintentionally locking a passenger door handle to unlock all four doors automati- Passive Entry RKE transmitter inside your vehicle, the...
Page 36 34 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE To Enter The Trunk NOTE: If you inadvertently leave your vehicle’s Passive With a valid Passive Entry RKE transmitter within 3 ft Entry RKE transmitter in the trunk and try to close the (1.0 m) of the deck lid, press the button on the left side of deck lid, the deck lid will automatically unlatch, unless CHMSL, (Center High Mounted Stop Light) which is...
Page 37 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 35 NOTE: • After pressing the door handle LOCK button, you must wait two seconds before you can lock or unlock the doors, using either passive entry door handle. This is done to allow you to check if the vehicle is locked by pulling the door handle, without the vehicle reacting and unlocking.
Page 38: Windows
36 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE WINDOWS There are single window controls on each passenger door trim panel, which operate the passenger door windows. Power Windows The window controls will operate only when the ignition The window controls on the driver’s door control all the is in the ACC or ON/RUN position.
Page 39 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 37 AUTO-Down Feature To close the window part way, lift the window switch to The driver door power window switch and some model the first detent and release it when you want the window passenger door power window switches have an AUTO- to stop.
Page 40: Wind Buffeting
38 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Reset Auto Up Should the Auto Up feature stop working, the window probably needs to be reset. To reset Auto Up: 1. Pull the window switch up to close the window completely and continue to hold the switch up for an additional two seconds after the window is closed.
Page 41: Trunk Lock And Release
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 39 open or partially open positions. This is a normal occur- The trunk lid can be released from rence and can be minimized. If the buffeting occurs with outside the vehicle by pressing the the rear windows open, then open the front and rear TRUNK button on the Remote windows together to minimize the buffeting.
Page 42: Trunk Safety Warning
40 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Refer to “Keyless Enter-N-Go” in “Things To Know Trunk Emergency Release Before Starting Your Vehicle” for more information on The trunk of your vehicle is equipped with an emergency trunk operation with the Passive Entry feature. release handle.
Page 43: Occupant Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 41 • Front seat belts incorporate pretensioners that may OCCUPANT RESTRAINTS Some of the most important safety features in your enhance occupant protection by managing occupant vehicle are the restraint systems: energy during an impact event •...
Page 44 42 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If a child from 1 to 12 years old (not in a rear facing child WARNING! seat) must ride in the front passenger seat, move the seat as far back as possible and use the proper child restraint. Infants in rear facing child restraints should never (Refer to “Child Restraints”) ride in the front seat of a vehicle with a passenger...
Page 45 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 43 5. If the airbag system in this vehicle needs to be WARNING! (Continued) modified to accommodate a disabled person, contact • Being too close to the steering wheel or instrument the Customer Center. Phone numbers are provided panel during Advanced Front Airbag deployment under If You Need Assistance .
Page 46: Lap/Shoulder Belts
44 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Buckle up even though you are an excellent driver, even normal conditions. However, in an accident, the belt will on short trips. Someone on the road may be a poor driver lock and reduce your risk of striking the inside of the and cause an accident that includes you.
Page 47 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 45 WARNING! (Continued) • Wearing your belt in the wrong place could make your injuries in an accident much worse. You might suffer internal injuries, or you could even slide out of part of the belt. Follow these instruc- tions to wear your seat belt safely and to keep your passengers safe, too.
Page 48 46 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 3. When the belt is long enough to fit, insert the latch WARNING! plate into the buckle until you hear a “click.” • A belt that is buckled into the wrong buckle will not protect you properly.
Page 49 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 47 tight, tilt the latch plate and pull on the lap belt. A snug WARNING! (Continued) belt reduces the risk of sliding under the belt in an • A belt that is worn under your arm is dangerous. accident.
Page 50 48 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 6. To release the belt, push the red button on the buckle. WARNING! The belt will automatically retract to its stowed position. • A lap belt worn too high can increase the risk of If necessary, slide the latch plate down the webbing to allow the belt to retract fully.
Page 51: Lap/Shoulder Belt Untwisting Procedure
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 49 above the webbing to release the anchorage, then move it you will prefer a higher position. When you release the up or down to the position that fits you best. anchorage try to move it up and down to make sure that it is locked in position.
Page 52: Seat Belts In Passenger Seating Positions
50 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 4. Continue to slide the latch plate up until it clears the Only pull the belt webbing out far enough to comfortably folded webbing. wrap around the occupants mid-section so as to not activate the ALR.
Page 53: Energy Management Feature
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 51 How To Engage The Automatic Locking Mode WARNING! 1. Buckle the combination lap and shoulder belt. • The belt and retractor assembly must be replaced 2. Grasp the shoulder portion and pull downward until if the seat belt assembly Automatic Locking Re- the entire belt is extracted.
Page 54: Seat Belt Pretensioner
52 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat Belt Pretensioner Enhanced Seat Belt Use Reminder System The seat belts for both front seating positions are (BeltAlert ) equipped with pretensioning devices that are designed to BeltAlert is a feature intended to remind the driver and remove slack from the seat belt in the event of an front passenger (if equipped with front passenger accident.
Page 55 3. Within 60 seconds of turning the ignition switch to the BeltAlert Programming ON/RUN position, unbuckle and then re-buckle the NOTE: Chrysler Group LLC does not recommend de- driver’s seat belt at least three times within 10 seconds, activating the BeltAlert .
Page 56: Seat Belts And Pregnant Women
54 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE BeltAlert can be reactivated by repeating this procedure. dealer can provide you with a seat belt extender. This extender should be used only if the existing belt is not NOTE: Although BeltAlert has been deactivated, the long enough.
Page 57 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 55 instrument panel, above the glove compartment. The words SRS AIRBAG are embossed on the airbag covers. In addition, the vehicle is equipped with a Supplemental Driver Side Knee Airbag mounted in the instrument panel below the steering column.
Page 58 56 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The Advanced Front Airbags have a multistage inflator This vehicle is equipped with Supplemental Seat- design. This allows the airbag to have different rates of Mounted Side Airbags (SAB) to provide enhanced pro- inflation based on the severity and type of collision.
Page 59 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 57 • Instrument Panel determined by the Occupant Restraint Controller (ORC), which may receive information from the front impact • Supplemental Driver Side Knee Airbag sensors. • Knee Impact Bolster The first stage inflator is triggered immediately during an •...
Page 60 58 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE side impact. The Supplemental Seat-Mounted Side Air- WARNING! (Continued) bag is marked with an airbag label sewn into the out- • Do not put anything on or around the airbag board side of the front seats. covers or attempt to open them manually.
Page 61 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 59 deploys independently, that is a left side impact deploys the left airbag only and a right-side impact deploys only the right airbag. Supplemental Side Airbag Inflatable Curtain (SABIC) SABIC airbags may offer side-impact protection to front and rear seat outboard occupants in addition to that provided by the body structure.
Page 62 60 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE The system includes side impact sensors adjacent to both Supplemental Driver Side Knee Airbag front and rear seat occupants that are calibrated to deploy The Supplemental Driver Side Knee Airbag provides the side airbags during impacts that require airbag enhanced protection and works together with the Driver occupant protection.
Page 63: Airbag Deployment Sensors And Controls
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 61 Airbag Deployment Sensors And Controls The Advanced Front Airbags and Supplemental Driver Side Knee Airbag will not deploy in all frontal collisions, Occupant Restraint Controller (ORC) including some that may produce substantial vehicle The ORC is part of a Federally regulated safety system damage —...
Page 64 62 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Seat belts are necessary for your protection in all acci- turns on the Airbag Warning Light, either momentarily dents, and also are needed to help keep you in position, or continuously. A single chime will sound if the light away from an inflating airbag.
Page 65 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 63 Driver And Passenger Advanced Front Airbag The Advanced Front Airbag gas is vented through the Inflator Units vent holes in the sides of the airbag. In this way, the The Driver and Passenger Advanced Front Airbag Infla- airbags do not interfere with your control of the vehicle.
Page 66 64 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Supplemental Seat-Mounted Side Airbag (SAB) Supplemental Side Airbag Inflatable Curtain Inflator Units (SABIC) Inflator Units The Supplemental Seat-Mounted Side Airbags (SAB) are During collisions where the impact is confined to a designed to activate only in certain side collisions. particular area of the side of the vehicle, the ORC may deploy the SABIC airbags, depending on the severity and The ORC determines if a side collision requires the side...
Page 67 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 65 • Turn on the interior lights, which remain on as long as Because airbag sensors estimate deceleration over time, vehicle speed and damage are not good indicators of the battery has power, until the ignition key is re- whether or not an airbag should have deployed.
Page 68 66 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE you might get sliding along a carpet or gymnasium Do not drive your vehicle after the airbags have de- floor. They are not caused by contact with chemicals. ployed. If you are involved in another collision, the They are not permanent and normally heal quickly.
Page 69 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 67 Maintaining Your Airbag System WARNING! (Continued) • Do not attempt to modify any part of your airbag WARNING! system. The airbag may inflate accidentally or may • Modifications to any part of the airbag system not function properly if modifications are made.
Page 70: Event Data Recorder (Edr)
68 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Airbag Warning Light NOTE: If the speedometer, tachometer, or any engine You will want to have the airbags ready to related gauges are not working, the Occupant Restraint inflate for your protection in a collision. The Controller (ORC) may also be disabled.
Page 71: Child Restraints
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 69 • How various systems in your vehicle were operating; To read data recorded by an EDR, special equipment is required, and access to the vehicle or the EDR is needed. • Whether or not the driver and passenger safety belts In addition to the vehicle manufacturer, other parties were buckled/fastened;...
Page 72 70 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Infants And Child Restraints WARNING! • Safety experts recommend that children ride In a collision, an unrestrained child, even a tiny baby, rearward-facing in the vehicle until they are at least can become a projectile inside the vehicle. The force one year old and weigh at least 20 lbs (9 kg).
Page 73 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 71 The belt-positioning booster seat is for children weighing WARNING! more than 40 lbs (18 kg), but who are still too small to fit the vehicle’s seat belts properly. If the child cannot sit Rearward-facing child seats must never be used in with knees bent over the vehicle’s seat cushion while the the front seat of a vehicle with the front passenger...
Page 74 • Before buying any restraint system, make sure that it has a label certifying that it meets all applicable Safety Standards. Chrysler Group LLC also recommends that I n f o r m a t i o n P r o v i d e d b y :...
Page 75 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 73 you make sure that you can install the child restraint in Lower Anchors and Tether for CHildren (LATCH) the vehicle where you will use it before you buy it. Your vehicle’s rear seat is equipped with the child restraint anchorage system called LATCH.
Page 76 74 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE strap kits or retrofit kits. You are urged to take advantage of all the available attachments provided with your child restraint in any vehicle. All three rear-seating positions have lower anchorages that are capable of accommodating LATCH-compatible child seats.
Page 77 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 75 Again, carefully follow the installation instructions that means of adjusting the tension in the strap. Forward- are provided with the child restraint system. facing toddler restraints and some rear-facing infant restraints will also be equipped with a tether strap, a The rear seat lower anchorages are round bars hook for attachment to the tether strap anchorage and a located at the rear of the seat cushion where it...
Page 78 76 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE For center seating position route the tether strap over the seatback and adjustable headrest then attach the hook to the tether anchor located in the panel between the rear seatback and the rear window. Adjustable Headrest Release Push Button Adjustable Headrest I n f o r m a t i o n P r o v i d e d b y :...
Page 79 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 77 restraint installation, instead of tucking the seat belt WARNING! behind the child restraint, route the seat belt through the child restraint belt path and then buckle it. This An incorrectly anchored tether strap could lead to should stow the seat belt out of the reach of an increased head motion and possible injury to the inquisitive child.
Page 80 78 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Installing Child Restraints Using The Vehicle Seat Driver Center Passenger Belts CRS Lock CRS Lock CRS Lock The seat belts in the passenger seating positions are First Row equipped with an Automatic Locking Retractor (ALR) to Second Row secure a Child Restraint System (CRS).
Page 81 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 79 To attach a child restraint tether strap: 2. Route the tether strap to provide the most direct path for the strap between the anchor and the child seat. 1. Rotate the cover over the anchor directly behind the seat where you are placing the child restraint.
Page 82: Engine Break-In Recommendations
80 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Transporting Pets The engine oil installed in the engine at the factory is a Airbags deploying in the front seat could harm your pet. high-quality energy conserving type lubricant. Oil An unrestrained pet will be thrown about and possibly changes should be consistent with anticipated climate injured, or injure a passenger during panic braking or in conditions under which vehicle operations will occur.
Page 83: Exhaust Gas
THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 81 Exhaust Gas WARNING! • Do not leave children or animals inside parked WARNING! vehicles in hot weather. Interior heat build-up may Exhaust gases can injure or kill. They contain carbon cause serious injury or death. monoxide (CO), which is colorless and odorless.
Page 84: Safety Checks You Should Make Inside The Vehicle
82 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE If you are required to drive with the trunk/liftgate open, Safety Checks You Should Make Inside The make sure that all windows are closed and the climate Vehicle control BLOWER switch is set at high speed. DO NOT Seat Belts use the recirculation mode.
Page 85 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 83 Defroster WARNING! Check operation by selecting the defrost mode and place the blower control on high speed. You should be able to Pedals that cannot move freely can cause loss of feel the air directed against the windshield. See your vehicle control and increase the risk of serious per- authorized dealer for service if your defroster is sonal injury.
Page 86: Periodic Safety Checks You Should Make Outside The Vehicle
84 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE Periodic Safety Checks You Should Make Outside WARNING! (Continued) The Vehicle • Check mounting of mats on a regular basis. Al- Tires ways properly reinstall and secure floor mats that Examine tires for excessive tread wear and uneven wear have been removed for cleaning.
Page 87 THINGS TO KNOW BEFORE STARTING YOUR VEHICLE 85 Fluid Leaks Check area under vehicle after overnight parking for fuel, engine coolant, oil, or other fluid leaks. Also, if gasoline fumes are detected or if fuel, power steering fluid, or brake fluid leaks are suspected, the cause should be located and corrected immediately.
Page 88 I n f o r m a t i o n P r o v i d e d b y :...
Page 89: Understanding The Features Of Your Vehicle
UNDERSTANDING THE FEATURES OF YOUR VEHICLE CONTENTS ▫ Power Mirrors ..... . . 96 Mirrors ......94 ▫...
Page 90 88 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Uconnect™ Phone Features ... . . 117 ▫ Ventilated Seats — If Equipped ..144 ▫...
Page 91 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 89 ▫ Headlights On With Wipers (Available With ▫ Interior Lights ..... . 162 Automatic Headlights Only) .
Page 92 90 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ To Activate ......174 ▫ To Turn Off ......183 ▫...
Page 93 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 91 ▫ Parksense Warning Display ... . 201 Garage Door Opener — If Equipped ..213 ▫ Parksense Display ....202 ▫...
Page 94 92 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ▫ Closing Sunroof — Manual Mode ..221 ▫ Opening Power Shade – Express ..225 ▫ Pinch Protect Feature ....221 ▫...
Page 95 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 93 ▫ Front Seat Cupholders ....231 Cargo Area Features ....238 ▫...
Page 96: Mirrors
94 UNDERSTANDING THE FEATURES OF YOUR VEHICLE MIRRORS CAUTION! Automatic Dimming Mirror To avoid damage to the mirror during cleaning, never This mirror automatically adjusts for headlight glare spray any cleaning solution directly onto the mirror. from vehicles behind you. Apply the solution onto a clean cloth and wipe the mirror clean.
Page 97: Outside Mirrors Folding Feature - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 95 turned on or off by pressing the button at the base of the WARNING! inside mirror. The mirror will automatically adjust for headlight glare when the inside mirror adjusts. Vehicles and other objects seen in the passenger side convex mirror will look smaller and farther away NOTE: This feature is also available on the passenger’s than they really are.
Page 98: Tilt Mirrors In Reverse - If Equipped
96 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the Remote Keyless Entry (RKE) transmitter or open any vehicle is shifted out of the REVERSE position. Each door. This LED shines outward to illuminate the front stored memory setting will have an associated Tilt Mir- and rear door handles.
Page 99: Power Folding Outside Mirrors - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 97 NOTE: A light in the select button will illuminate indicating the mirror is activated and can be adjusted. Power mirror preselected positions can be controlled by the optional Memory Seat Feature. Refer to “Driver Memory Seat”...
Page 100: Heated Mirrors - If Equipped
98 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Mirrors — If Equipped Uconnect Phone supports the following features: These mirrors are heated to melt frost or ice. This Voice Activated Features: feature is activated whenever you turn on the rear •...
Page 101 • Viewing and Calling contacts from Phonebooks dis- For Uconnect™ customer support call: played on the touch screen. • For Chrysler vehicles call 1–800–247–9753 • Setting Favorite Contact Phone numbers so the are • For Dodge vehicles call 1–800–423–6343 easily accessible on the Main Phone screen.
Page 102 100 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Uconnect™ Phone allows you to transfer calls between long as your phone is turned on and has been paired to the system and your mobile phone as you enter or exit the vehicle’s Uconnect™ Phone. The Uconnect™ Phone your vehicle and enables you to mute the system’s allows up to ten mobile phones or audio devices to be microphone for private conversation.
Page 103: Operation
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 101 button is also used to access the Voice 2. Say the individual commands and allow the system to guide you to complete the task. Commands for the Uconnect™ Voice Command features if your vehicle is equipped. Please see the Uconnect™ You will be prompted for a specific command and then Voice Command section for direction on how to use the guided through the available options.
Page 104 102 UNDERSTANDING THE FEATURES OF YOUR VEHICLE example, you can use the combined form voice com- Smith”. For multiple inputs in the same phrase or sen- mand “Search for John Smith”, or you can break the tence, the system identifies the topic or context and combined form command into two voice commands: provides the associated follow-up prompt such as “Who “Search Contact”...
Page 105 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 103 To activate the Uconnect™ Phone from idle, simply press Pair (Link) Uconnect™ Phone To A Mobile Phone button and say a command or say “help”. All To begin using your Uconnect™ Phone, you must pair your compatible Bluetooth enabled mobile phone.
Page 106 104 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. If there is no phone currently connected with the 3. Select Yes to begin the pairing process. Then, search system, a pop up will appear. for available devices on your Bluetooth enabled mobile phone.
Page 107 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 105 Pair Additional Mobile Phones • Touch the More soft-key to begin. • Touch the Settings soft-key. • Next, touch the Phone/Bluetooth soft-key. • Touch the Add Device soft-key. • Search for available devices on your Bluetooth en- abled mobile phone.
Page 108 106 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the pairing process has successfully completed, NOTE: For phones which are not made a favorite, the the system will prompt you to choose whether or not phone priority is determined by the order in which it was this is your favorite phone.
Page 109 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 107 • Search for available devices on your Bluetooth en- • “Show Paired Audio Devices” abled audio device. When prompted on the device, Connecting To A Particular Mobile Phone Or enter the name and PIN shown on the Uconnect™ Device Touch screen.
Page 110 108 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Touch the + Options soft-key, then touch the + next to Making A Phone A Favorite the appropriate device to be disconnected. • Touch the Phone soft-key. • The options pop-up will be displayed. •...
Page 111 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 109 phonebook. Specific Bluetooth Phones with Phone Book downloaded names can be used. Until then, if avail- Access Profile may support this feature. See Uconnect™ able, the previous downloaded phonebook is available website for supported phones. for use.
Page 112 110 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 2. After loading the mobile phonebook, select phone- 3. From the Phone main screen, select phonebook. From book from the Phone main screen, then select the appro- the phonebook screen, select favorites and then select the priate number.
Page 113 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 111 To Remove A Favorite • To remove a Favorite, select phonebook from the Phone main screen. • Next select Favorites on the left side of the screen and then touch the + Options soft-key. •...
Page 114: Phone Call Features
112 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To change the Emergency or Towing number follow these steps. • Touch the phonebook soft-key from the Phone main screen. • Touch the Favorites soft-key. Next scroll to the bottom of the list to locate the Emergency and Towing Favor- ites.
Page 115 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 113 For example, if your mobile service plan provides three- NOTE: All of the above operations except Redial can be way calling, this feature can be accessed through the done with 1 call or less active. Uconnect™...
Page 116 114 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Call Controls Touch-Tone Number Entry The touch-screen allows you to control the following call • Touch the Phone soft-key. features: • Touch the Dial soft-key. • Answer • The Touch-Tone screen will be displayed. •...
Page 117 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 115 Recent Calls These can be accessed by touching the recent calls You may browse up to 34 of the most recent of each of the soft-key on the Phone main screen. following call types: You can also press the button and say “Show my incoming calls”...
Page 118 116 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Answer Or Ignore An Incoming Call — Call in progress. Or you can place a call on hold by touching Currently In Progress the Hold soft-key on the Phone main screen, then dial a If a call is currently in progress and you have another number from the dialpad, recent calls, SMS Inbox or from incoming call, you will hear the same network tones for...
Page 119: Uconnect™ Phone Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 117 • The Uconnect™ Phone will call the last number that Conference Call When two calls are in progress (one active and one on was dialed from your mobile phone. hold), touch the Conference soft-key on the Phone main Call Continuation screen to combine all calls into a Conference Call.
Page 120 118 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Uconnect™ Phone does slightly lower your If the phone is not reachable and the Uconnect™ Phone is operational, you may reach the emergency number as chances of successfully making a phone call as to that follows: for the mobile phone directly.
Page 121 3454 for Mexico City and 1-800-712-3040 for outside When calling a number with your Uconnect™ Phone that Mexico City in Mexico). Please refer to the Chrysler normally requires you to enter in a touch-tone sequence on Group LLC 24-Hour “Towing Assistance” coverage...
Page 122 120 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Some paging and voice mail systems have system time You can also send stored mobile phonebook entries as tones for fast and easy access to voice mail and pager out settings that are too short and may not allow the entries.
Page 123 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 121 Voice Response Length Dialing Using The Mobile Phone Keypad It is possible for you to choose between Brief and You can dial a phone number with your mobile phone Detailed Voice Response Length. keypad and still use the Uconnect™...
Page 124: Advanced Phone Connectivity
122 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Mute/Un-Mute (Mute OFF) Connect Or Disconnect Link Between The When you mute the Uconnect™ Phone, you will still be Uconnect™ Phone And Mobile Phone able to hear the conversation coming from the other If you would like to connect or disconnect the Bluetooth party, but the other party will not be able to hear you.
Page 125 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 123 • Make sure that no one other than you is speaking • Storing names in your favorites phonebook when the during a voice command period. vehicle is not in motion is recommended. • Performance is maximized under: •...
Page 126 124 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • low road noise, Your phone must support SMS over Bluetooth in order to use this feature. If the Uconnect™ Phone determines • smooth road surface, your phone is not compatible with SMS messaging over •...
Page 127 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 125 Read Messages: Once a message is received and viewed or listened to, you will have the following options: If you receive a new text message while your phone is • Send a Reply connected to Uconnect™...
Page 128 126 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Touch one of the 18 preset messages and the person Send Messages Using Voice Commands: you wish to send the message to. • Press the button. • After the “Listening” prompt and the following beep, say “Send message to John Smith mobile”.
Page 129 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 127 6. I’ll call you later. 7. I’m on my way. 8. Thanks. 9. I’ll be late. 10. I will be <number> minutes late. 11. See you in <number> minutes. 12. Stuck in traffic. 13.
Page 130 128 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Bluetooth Communication Link Power-Up Mobile phones have been found to lose connection to the After switching the ignition key from OFF to either the Uconnect™ Phone. When this happens, the connection ON or ACC position, or after a language change, you can generally be reestablished by switching the phone must wait at least 15 seconds prior to using the system.
Page 131 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 129 Voice Tree I n f o r m a t i o n P r o v i d e d b y :...
Page 132 130 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r m a t i o n P r o v i d e d b y :...
Page 133: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 131 General Information NOTE: Take care to speak into the Voice Interface This device complies with Part 15 of the FCC rules and System as calmly and normally as possible. The ability of RSS 210 of Industry Canada. Operation is subject to the the Voice Interface System to recognize user voice com- following conditions: mands may be negatively affected by rapid speaking or a...
Page 134 132 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If no command is spoken or recorded the system with say These commands are universal and can be used from any one of three responses: menu. All other commands can be used depending upon the active application.
Page 135: Uconnect™ Voice Commands
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 133 Natural Speech Uconnect™ Voice Commands Natural speech allows the user to speak commands in The Uconnect™ Voice Command system understands phrases or complete sentences. The system filters out two types of commands. Universal commands are avail- certain non-word utterances and sounds such as “ah”...
Page 136 134 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Starting Voice Recognition (VR) Session in Disc Radio/Player Modes To switch to the disc mode, say “Change source to Disc”. In this mode, you can say the following commands: This command can be given in any mode or screen: •...
Page 137: Voice Tree
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 135 Voice Tree I n f o r m a t i o n P r o v i d e d b y :...
Page 138 136 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r m a t i o n P r o v i d e d b y :...
Page 139 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 137 I n f o r m a t i o n P r o v i d e d b y :...
Page 140 138 UNDERSTANDING THE FEATURES OF YOUR VEHICLE I n f o r m a t i o n P r o v i d e d b y :...
Page 141: Seats
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 139 SEATS Power Seats — If Equipped Seats are a part of the Occupant Restraint System of the On models equipped with power seats, the switch is vehicle. located on the outboard side of the seat near the floor. Use this switch to move the driver’s seat up or down, WARNING! forward or rearward or to recline the seatback.
Page 142 140 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Adjusting The Seat Forward Or Rearward Reclining The Seatback The seat can be adjusted both forward and rearward. The angle of the seatback can be adjusted forward or Push the seat switch forward or rearward, the seat will rearward.
Page 143: Power Lumbar - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 141 increase or decrease the lumbar support. Push the switch WARNING! (Continued) upward or downward to raise or lower the lumbar • Do not ride with the seatback reclined so that the support. shoulder belt is no longer resting against your chest.
Page 144: Heated Seats - If Equipped
142 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Heated Seats — If Equipped WARNING! (Continued) On some models, the front and rear seats may be • Do not place anything on the seat that insulates equipped with heaters in both the seat cushions and against heat, such as a blanket or cushion.
Page 145 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 143 Front Heated Seat Operation — Vehicles Equipped NOTE: Once a heat setting is selected, heat will be felt With Uconnect™ Touch 4.3: within two to five minutes. Press the CLIMATE hard-key to enter the climate control When the HI-level setting is selected, the heater will screen.
Page 146: Ventilated Seats - If Equipped
144 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Rear Heated Seats one, indicating the change. Operation on the LO-level On vehicles equipped with rear heated seats, the seats setting also turns OFF automatically after approximately closest to the doors are heated. The controls for these 30 minutes.
Page 147: Head Restraints
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 145 Front Ventilated Seat Operation — Vehicles NOTE: The engine must be running for the ventilated Equipped With Uconnect™ Touch 4.3: seats to operate. Press the CLIMATE hard-key to enter the climate control Vehicles Equipped With Remote Start screen.
Page 148 146 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The AHRs will automatically return to their normal WARNING! position following a rear impact. If the AHRs do not return to their normal position see your authorized deal The head restraints for all occupants must be prop- immediately.
Page 149 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 147 WARNING! Do not place items over the top of the Active Head Restraint, such as coats, seat covers or portable DVD players. These items may interfere with the operation of the Active Head Restraint in the event of a collision and could result in serious injury or death.
Page 150: Folding Rear Seat
148 UNDERSTANDING THE FEATURES OF YOUR VEHICLE To raise the head restraint, pull upward on the head NOTE: The outboard head restraints are not adjustable. restraint. To lower the head restraint, press the push Refer to “Occupant Restraints” in “Things To Know button, located at the base of the head restraint, and push Before Starting Your Vehicle”...
Page 151 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 149 Rear Seatback Loop Folded Rear Seatback After releasing the seatback, it can be folded forward. When the seatback is folded to the upright position, make sure it is latched by strongly pulling on the top of the seatback above the seat strap.
Page 152: Driver Memory Seat - If Equipped
150 UNDERSTANDING THE FEATURES OF YOUR VEHICLE settings for the driver seat, side mirrors, adjustable WARNING! pedals (if equipped), and power tilt and telescopic steer- • Be certain that the seatback is securely locked into ing column (if equipped) and a set of desired radio station presets.
Page 153: Programming The Memory Feature
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 151 rocker switch allows the driver to recall either of two To create a new memory profile, perform the following: pre-programmed memory profiles by pressing the appro- 1. Place the ignition into the RUN position. priate side of the switch.
Page 154: Linking And Unlinking The Remote Keyless Entry Transmitter To Memory
152 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The Recall Memory with Remote Key Unlock feature release the side of the rocker switch labeled 1 or 2 can be enabled through the Uconnect™ Touch System, accordingly. “Memory Profile Set” (1 or 2) will display in refer to “Uconnect™...
Page 155: Easy Entry/Exit Seat (Available With Memory Seat Only)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 153 • The driver’s seat belt must be unbuckled to recall Easy Entry/Exit Seat (Available With Memory Seat memory positions. Only) This feature provides automatic driver seat positioning to To recall the memory settings for driver one, press enhance driver mobility when entering and exiting the MEMORY button number 1 on the driver’s door or the vehicle.
Page 156: To Open And Close The Hood
154 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When you remove the Key Fob from the ignition (or TO OPEN AND CLOSE THE HOOD change the ignition to OFF, for vehicles equipped with Two latches must be released to open the hood. Keyless Enter-N-Go), the driver seat will move to a 1.
Page 157 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 155 2. Move to the outside of the vehicle and push the safety CAUTION! catch to the left. The safety catch is located under the center front edge of the hood. To prevent possible damage, do not slam the hood to close it.
Page 158: Lights
156 UNDERSTANDING THE FEATURES OF YOUR VEHICLE LIGHTS Headlight Switch The headlight switch is located on the left side of the instrument panel. This switch controls the operation of the headlights, parking lights, instru- ment panel lights, instrument panel light dimming, inte- rior lights and fog lights.
Page 159: Automatic Headlights - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 157 Automatic Headlights — If Equipped addition, the headlights will turn off when the wipers are This system automatically turns the headlights on or off turned off if they were turned on by this feature. according to ambient light levels.
Page 160: Smartbeam™ - If Equipped
158 UNDERSTANDING THE FEATURES OF YOUR VEHICLE If you turn the headlights off before the ignition, they will NOTE: • SmartBeam™ can be turned on or off using the turn off in the normal manner. Uconnect™ Touch System, refer to “Uconnect™ Touch NOTE: Settings”...
Page 161: Lights-On Reminder
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 159 NOTE: The Daytime Running Lights can be turned on and off using the Uconnect™ Touch System, refer to “Uconnect™ Touch Settings” in “Understanding Your Instrument Panel” for further information. Lights-On Reminder If the headlights or parking lights are on after the ignition is placed in the OFF position, a chime will sound to alert the driver when the driver’s door is opened.
Page 162: Multifunction Lever
160 UNDERSTANDING THE FEATURES OF YOUR VEHICLE An indicator light in the instrument cluster illuminates when the fog lights are turned on. NOTE: The fog lights will operate with the low beam headlights or parking lights on. However, selecting the high beam headlights will turn off the fog lights.
Page 163: Turn Signals
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 161 Turn Signals Lane Change Assist Move the multifunction lever up or down and the arrows Tap the lever up or down once, without moving beyond on each side of the instrument cluster flash to show the detent, and the turn signal (right or left) will flash proper operation of the front and rear turn signal lights.
Page 164: Interior Lights
162 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the UNLOCK button on the Remote Keyless Entry (RKE) Interior Lights transmitter is pressed or when the dimmer control is The interior lights come on when a door is opened. turned fully upward, past the second detent. To protect the battery, the interior lights will turn off automatically 10 minutes after the ignition switch is moved to the LOCK position.
Page 165 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 163 Dimmer Controls Rotating the right dimmer control upward will increase the brightness of the door handle lights, map pockets and cupholders — if equipped. Dome Light Position Rotate the dimmer control completely upward to the second detent to turn on the interior lights.
Page 166: Windshield Wipers And Washers
164 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WINDSHIELD WIPERS AND WASHERS Rotate the end of the multifunction lever to the first The multifunction lever operates the windshield wipers detent, past the intermittent settings for low-speed wiper and washer when the ignition is placed in the RUN operation, or to the second detent past the intermittent position.
Page 167: Intermittent Wiper System
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 165 Mist Feature CAUTION! (Continued) Rotate the end of the lever downward to the Mist • Always remove any buildup of snow that prevents position to activate a single wipe cycle to clear off road the windshield wiper blades from returning to the mist or spray from a passing vehicle.
Page 168: Headlights On With Wipers (Available With Automatic Headlights Only)
166 UNDERSTANDING THE FEATURES OF YOUR VEHICLE “Uconnect Touch™ Settings” in “Understanding Your WARNING! Instrument Panel” for further information. Sudden loss of visibility through the windshield Rain Sensing Wipers — If Equipped could lead to a collision. You might not see other This feature senses moisture on the windshield and vehicles or other obstacles.
Page 169 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 167 moisture that is sensed on the windshield. Place the The Rain Sensing system has protective features for the wiper switch in the OFF position when not using the wiper blades and arms. It will not operate under the system.
Page 170: Tilt/Telescoping Steering Column
168 UNDERSTANDING THE FEATURES OF YOUR VEHICLE TILT/TELESCOPING STEERING COLUMN To unlock the steering column, pull the control handle This feature allows you to tilt the steering column outward. To tilt the steering column, move the steering upward or downward. It also allows you to lengthen or wheel upward or downward as desired.
Page 171: Power Tilt/Telescoping Steering Column - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 169 POWER TILT/TELESCOPING STEERING COLUMN — IF EQUIPPED This feature allows you to tilt the steering column upward or downward. It also allows you to lengthen or shorten the steering column. The power tilt/telescoping steering column lever is located below the multifunction lever on the steering column.
Page 172: Heated Steering Wheel - If Equipped
170 UNDERSTANDING THE FEATURES OF YOUR VEHICLE transmitter or the memory switch on the driver’s door wheel has only one temperature setting. Once the heated trim panel to return the tilt/telescopic steering column to steering wheel has been turned on it will operate for pre-programmed positions.
Page 173: Adjustable Pedals - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 171 Vehicles Equipped With Remote Start WARNING! (Continued) On models that are equipped with remote start, the • Do not place anything on the steering wheel that heated steering wheel and seat can be programmed to insulates against heat, such as a blanket or cush- come on during a remote start.
Page 174 172 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The pedals can be adjusted with the ignition OFF. The switch is located on the front side of the driver’s seat cushion side shield. • The pedals can be adjusted while driving. •...
Page 175: Electronic Speed Control - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 173 The Electronic Speed Control buttons are located on the CAUTION! right side of the steering wheel. Do not place any article under the adjustable pedals or impede its ability to move as it may cause damage to the pedal controls.
Page 176: To Activate
174 UNDERSTANDING THE FEATURES OF YOUR VEHICLE the same time. If this occurs, the Electronic Speed Control To Set A Desired Speed System can be reactivated by pushing the Electronic Turn the Electronic Speed Control ON. When the vehicle Speed Control ON/OFF button and resetting the desired has reached the desired speed, press the SET (-) button vehicle set speed.
Page 177: To Resume Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 175 To Resume Speed decrease until the button is released. Release the button To resume a previously set speed, push the RES (+) when the desired speed is reached, and the new set speed button and release.
Page 178: Adaptive Cruise Control (Acc) - If Equipped
176 UNDERSTANDING THE FEATURES OF YOUR VEHICLE On steep hills, a greater speed loss or gain may occur so ADAPTIVE CRUISE CONTROL (ACC) — IF it may be preferable to drive without Electronic Speed EQUIPPED Control. Adaptive Cruise Control (ACC) increases the driving convenience provided by cruise control while traveling WARNING! on highways and major roadways.
Page 179 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 177 WARNING! WARNING! (Continued) − Cannot take street, traffic, and weather conditions • Adaptive Cruise Control (ACC) is a convenience into account, and may be limited upon adverse sight system. It is not a substitute for active driving distance conditions.
Page 180: Adaptive Cruise Control (Acc) Operation
178 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The Cruise Control system has two control modes: WARNING! • Adaptive Cruise Control mode for maintaining an You should switch off the ACC system: appropriate distance between vehicles. • When driving in fog, heavy rain, heavy snow, •...
Page 181: Activating Adaptive Cruise Control (Acc)
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 179 NOTE: Any chassis/suspension modifications to the vehicle will effect the performance of the Adaptive Cruise Control. Activating Adaptive Cruise Control (ACC) You can only activate ACC if the vehicle speed is above 20 mph (32 km/h). When the system is turned on and in the READY state, the Electronic Vehicle Information Center (EVIC) dis- plays “Adaptive Cruise Ready.”...
Page 182: To Activate
180 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • When the automatic transmission is in PARK, RE- VERSE or NEUTRAL. • When pushing the RES + button without a previously set speed in memory. To Activate Push and release the ON/OFF button. The ACC menu in the EVIC displays “Adaptive Cruise Ready.”...
Page 183: To Set A Desired Acc Speed
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 181 WARNING! Leaving the Adaptive Cruise Control (ACC) system on when not in use is dangerous. You could acciden- tally set the system or cause it to go faster than you want. You could lose control and have a collision. Always leave the system off when you are not using To Set A Desired ACC Speed When the vehicle reaches the speed desired, push the...
Page 184: To Cancel
182 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • The system will not be controlling the distance be- To Cancel tween your vehicle and the vehicle ahead. The vehicle The system will disable ACC without erasing the speed will only be determined by the position of the memory if: accelerator pedal.
Page 185: To Turn Off
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 183 To Resume Speed Press the RES + button and release. Then remove your foot from the accelerator pedal. The EVIC will display the last set speed. NOTE: You can resume ACC from a minimum of 20 mph (32 km/h).
Page 186: Setting The Following Distance In Acc
184 UNDERSTANDING THE FEATURES OF YOUR VEHICLE continually pressed, the set speed will continue to in- NOTE: • When you use the SET - button to decelerate, if the crease in 5 mph (8 km/h) increments until the button is released.
Page 187 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 185 vehicle speed, ACC calculates and sets the distance to the If there is no vehicle ahead, the vehicle will maintain the vehicle ahead. This distance setting displays in the EVIC. set speed. If a slower moving vehicle is detected in the same lane, the EVIC displays the “Sensed Vehicle Indi- cator”...
Page 188: Adaptive Cruise Control (Acc) Menu
186 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The maximum braking applied by ACC is limited; how- ever, the driver can always apply the brakes manually, if necessary. NOTE: The brake lights will illuminate whenever the ACC system applies the brakes. A Proximity Warning will alert the driver if ACC predicts that its maximum braking level is not sufficient to maintain the set distance.
Page 189 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 187 Press the MENU button (located on the steer- ACC SET ing wheel) repeatedly until one of the follow- − When ACC is set, the set speed will display. ing displays in the EVIC: The set speed will continue to display in place of the Menu odometer reading when changing the EVIC display...
Page 190: Display Warnings And Maintenance
188 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The ACC screen will display once again if any ACC Display Warnings And Maintenance activity occurs, which may include any of the following: “Clean Radar Sensor In Front Of Vehicle” Warning • Set Speed Change The ACC “Clean Radar Sensor In Front Of Vehicle”...
Page 191 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 189 If weather conditions are not a factor, the driver should examine the sensor. It may require cleaning or removal of an obstruction. The sensor is located in the center of the vehicle behind the lower grille. To keep the ACC System operating properly, it is impor- tant to note the following maintenance items: •...
Page 192 190 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • Do not attach or install any accessories near the sensor, ACC Unavailable Warning including transparent material or aftermarket grilles. If the system turns off, and the EVIC displays “ACC/ Doing so could cause an ACC system failure or FCW Unavailable, Vehicle System Error”, there may be a malfunction.
Page 193: Precautions While Driving With Acc
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 191 Precautions While Driving With ACC In certain driving situations, ACC may have detection issues. In these cases, ACC may brake late or unexpect- edly. The driver needs to stay alert and may need to intervene.
Page 194 192 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Offset Driving Turns And Bends ACC may not detect a vehicle in the same lane that is In turns or bends, ACC may detect a vehicle ahead too offset from your direct line of travel. There will not be late or too early.
Page 195 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 193 ACC may occasionally provide braking and/or a driver alert that you consider unnecessary. This may be the system’s response to signs, guardrails, and other station- ary objects in a curve. This may also occur at the base of steep hills.
Page 196 194 UNDERSTANDING THE FEATURES OF YOUR VEHICLE system to take action. ACC will not detect a vehicle until Narrow Vehicles it is completely in the lane. There will not be sufficient Some narrow vehicles traveling near the outer edges of distance to the lane-changing vehicle.
Page 197: General Information
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 195 Stationary Objects And Vehicles General Information ACC does not react to stationary objects and stationary FCC Requirements For Vehicular Radar Systems vehicles. For example, ACC will not react in situations Classification Specifications: where the vehicle you are following exits your lane and 47 C.F.R.
Page 198 196 UNDERSTANDING THE FEATURES OF YOUR VEHICLE displayed if the system was in the ACC OFF position. To To Set A Desired Speed switch back to Adaptive Cruise Control mode, press the When the vehicle reaches the speed desired, press the MODE button a second time.
Page 199 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 197 To Cancel To Turn Off The system will disable normal Cruise Control without The system will turn off and erase the set speed in erasing the memory if: memory if: • You softly tap or depress the brake pedal. •...
Page 200: Forward Collision Warning - If Equipped
198 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Forward Collision Warning — If Equipped Forward Collision Warning (FCW) warns the driver of a potential collision with the vehicle in front of you and prompts the driver to take action in order to avoid the collision.
Page 201 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 199 Changing the FCW status to the “Near” setting, allows WARNING! the system to warn you of a possible collision with the vehicle in front of you when you are much closer. This Forward Collision Warning (FCW) is not intended to setting provides less reaction time than the “Far”...
Page 202: Parksense Rear Park Assist - If Equipped
200 UNDERSTANDING THE FEATURES OF YOUR VEHICLE • FCW will be disabled like ACC below with the un- available screens. FCW Unavailable Warning If the system turns off, and the EVIC displays “ACC/ FCW Unavailable, Vehicle System Error”, there may be a temporary malfunction that limits FCW functionality.
Page 203: Parksense Sensors
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 201 Usage Precautions” for limitations of this system and (200 cm) from the rear fascia/bumper in the horizontal recommendations. direction, depending on the location, type and orienta- tion of the obstacle. ParkSense will retain the last system state (enabled or disabled) from the last ignition cycle when the ignition is ParkSense Warning Display changed to the ON/RUN position.
Page 204: Parksense Display
202 UNDERSTANDING THE FEATURES OF YOUR VEHICLE ParkSense Display When the vehicle is in REVERSE, the warning display will turn ON indicating the system status. Rear Park Assist OFF Rear Park Assist Display I n f o r m a t i o n P r o v i d e d b y :...
Page 205 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 203 The system will indicate a detected obstacle by showing three solid arcs and will produce a one-half second tone. As the vehicle moves closer to the object, the EVIC display will show fewer arcs and the sound tone will change from slow, to fast, to continuous.
Page 206 204 UNDERSTANDING THE FEATURES OF YOUR VEHICLE The vehicle is close to the obstacle when the warning display shows one flashing arc and sounds a continuous tone. The following chart shows the warning alert opera- tion when the system is detecting an obstacle: Continuous Tone I n f o r m a t i o n P r o v i d e d b y :...
Page 207: Enabling And Disabling Parksense
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 205 WARNING ALERTS Rear Distance Greater than 79-39 in 39-25 in 25-12 in Less than (in/cm) 79 in (200 cm) (200-100 cm) (100-65 cm) (65-30 cm) 12 in (30 cm) Audible Alert None Single 1/2- Slow Fast Continuous...
Page 208: Service The Parksense Rear Park Assist System
206 UNDERSTANDING THE FEATURES OF YOUR VEHICLE (200 cm) away from the rear bumper fascia. ParkSense If “CLEAN PARK ASSIST SENSORS” appears in the provides both visual and audible warnings to indicate EVIC and the rear fascia/bumper is clean and clear of the range of the object.
Page 209 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 207 • Jackhammers, large trucks, and other vibrations could • Objects such as bicycle carriers, trailer hitches, etc., affect the performance of ParkSense . must not be placed within 12 in (30 cm) from the rear fascia/bumper while driving the vehicle.
Page 210 208 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! (Continued) WARNING! • The vehicle must be driven slowly when using • Drivers must be careful when backing up even ParkSense in order to be able to stop in time when using the ParkSense Rear Park Assist sys- when an obstacle is detected.
Page 211: Parkview Rear Back Up Camera - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 209 PARKVIEW REAR BACK UP CAMERA — IF WARNING! (Continued) EQUIPPED • Before using the ParkSense Rear Park Assist Your vehicle may be equipped with the ParkView Rear system, it is strongly recommended that the ball Back Up Camera that allows you to see an on-screen mount and hitch ball assembly is disconnected image of the rear surroundings of your vehicle whenever...
Page 212 210 UNDERSTANDING THE FEATURES OF YOUR VEHICLE When displayed, static grid lines will illustrate the width zones that will help indicate the distance to the rear of the of the vehicle while a dashed center-line will indicate the vehicle. The following table shows the approximate center of the vehicle to assist with parking or aligning to distances for each zone: a hitch/receiver.
Page 213: Turning Parkview On Or Off - With Touch Screen Radio
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 211 WARNING! CAUTION! (Continued) • To avoid vehicle damage, the vehicle must be Drivers must be careful when backing up even when driven slowly when using ParkView to be able to using the ParkView Rear Back Up Camera. Always stop in time when an obstacle is seen.
Page 214: Overhead Console
212 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 4. Press the “Safety & Driving Assistance” soft button. 5. Press the check box soft key next to “Parkview Backup Camera” to enable/disable. OVERHEAD CONSOLE The overhead console contains courtesy/reading lights and storage for sunglasses. Universal Garage Door Opener (HomeLink ) buttons and power sunroof switch may also be included, if equipped.
Page 215: Sunglasses Storage
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 213 To turn on the map lighting, press the button with the systems. The HomeLink unit operates off your vehicle’s light graphic. Press a second time to turn off. battery. The lights also turn on when a front or rear door is The HomeLink buttons are located in the overhead opened, when the UNLOCK button on the Remote...
Page 216: Programming Homelink
214 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: HomeLink is disabled when the Vehicle Secu- a garage door opener without these safety features. Call rity Alarm is active. toll-free 1–800–355–3515 Internet www.HomeLink.com for safety information or assis- WARNING! tance. • Your motorized door or gate will open and close Programming HomeLink while you are training the Universal Transceiver.
Page 217 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 215 Your vehicle should be parked outside of the garage If the EVIC display states “DID NOT TRAIN” repeat while training. Step 3. If the signal is too weak, replace the battery in the handheld transmitter.
Page 218 216 UNDERSTANDING THE FEATURES OF YOUR VEHICLE garage door opener may have rolling code. If so, proceed to the heading “Programming A Rolling Code System.” Programming A Rolling Code System At the garage door opener motor (in the garage), locate the “Learn”...
Page 219: Gate Operator/Canadian Programming
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 217 2. Return to the vehicle and press the programmed Gate Operator/Canadian Programming HomeLink button twice (holding the button for two Canadian radio-frequency laws require transmitter sig- seconds each time). If the device is plugged in and nals to “time-out”...
Page 220: Using Homelink
218 UNDERSTANDING THE FEATURES OF YOUR VEHICLE successfully accepted the frequency signal. The EVIC 1. Place the ignition in the RUN position. display will change from “CHANNEL # TRAINING” to 2. Press and hold the desired HomeLink button for “CHANNEL # TRAINED.” 20 seconds until the EVIC display states “CHANNEL # If you unplugged the device for training, plug it back in TRAINING.”...
Page 221: Troubleshooting Tips
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 219 Troubleshooting Tips General Information If you are having trouble programming HomeLink , here This device complies with FCC rules Part 15 and Industry are some of the most common solutions: Canada RSS-210. Operation is subject to the following two conditions: •...
Page 222: Power Sunroof - If Equipped
220 UNDERSTANDING THE FEATURES OF YOUR VEHICLE POWER SUNROOF — IF EQUIPPED WARNING! The power sunroof switch is located between the sun • Never leave children in a vehicle with the key in visors on the overhead console. the ignition switch. Occupants, particularly unat- tended children, can become entrapped by the power sunroof while operating the power sunroof switch.
Page 223: Opening Sunroof - Express
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 221 Opening Sunroof — Express position. The sunroof will close fully and stop automati- Press the switch forward and release it within one-half cally. This is called “Express Close”. During Express second and the sunroof will close automatically from any Close operation, any movement of the switch will stop position.
Page 224: Pinch Protect Override
222 UNDERSTANDING THE FEATURES OF YOUR VEHICLE NOTE: If three consecutive sunroof close attempts re- Sunshade Operation sult in Pinch Protect reversals, the fourth close attempt The sunshade can be opened manually. However, the will be a Manual Close movement with Pinch Protect sunshade will open automatically as the sunroof opens.
Page 225: Sunroof Maintenance
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 223 Sunroof Maintenance The power shade switch is located to the right between Use only a nonabrasive cleaner and a soft cloth to clean the sun visors on the overhead console. the glass panel. Ignition OFF Operation The power sunroof switches can be programmed to remain active for up to approximately ten minutes after...
Page 226: Opening Sunroof - Express
224 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Opening Sunroof – Express WARNING! Press the sunroof switch rearward for less than one • Never leave children in a vehicle with the key in second and release, and the sunroof glass will automati- cally slide fully open from any position, then stop.
Page 227: Closing Sunroof - Express
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 225 the vent switch is pressed, the shade will automatically position then stop. During Express Shade Open opera- move to the middle position before the sunroof begins tion, any sunroof switch press or shade switch press will Express Vent operation.
Page 228: Sunroof And Power Shade Movement - Manual
226 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Sunroof and Power Shade Movement – Manual Pinch Protect Override If any sunroof or shade switch is pressed and held for Method 1: If a known obstruction (ice, debris, etc) more than one second, the sunroof or shade movement prevents closing of the sunroof or shade, press the will continue only as long as the switch is continuously corresponding switch forward and hold for two seconds...
Page 229: Wind Buffeting
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 227 Wind Buffeting the ignition switch has been turned OFF. Refer to “Elec- Wind buffeting can be described as the perception of tronic Vehicle Information Center (EVIC)/Customer- pressure on the ears or a helicopter-type sound in the Programmable Features (System Setup)”...
Page 230 228 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CAUTION! • Do not exceed the maximum power of 160 Watts (13 Amps) at 12 Volts. If the 160 Watt (13 Amp) power rating is exceeded, the fuse protecting the system will need to be replaced. •...
Page 231 UNDERSTANDING THE FEATURES OF YOUR VEHICLE 229 The center console outlet, located on the back of the center console, is powered directly from the battery (power available at all times). Items plugged into this outlet may discharge the battery and/or prevent the engine from starting.
Page 232 230 UNDERSTANDING THE FEATURES OF YOUR VEHICLE WARNING! CAUTION! • Many accessories that can be plugged in draw To avoid serious injury or death: • Only devices designed for use in this type of power from the vehicle’s battery even when not in use (i.e., cellular phones, etc.).
Page 233: Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 231 CAUTION! (Continued) • Power outlets are designed for accessory plugs only. Do not hang any type of accessory or acces- sory bracket from the plug. Improper use of the power outlet can cause damage. CUPHOLDERS Front Seat Cupholders The cupholders are located in the forward edge of the...
Page 234 232 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Front Cupholders Heated And Cooled Cupholder Switches Heated and Cooled Cupholders — If Equipped Press the “Cold” symbol once to turn on the cupholder; Your vehicle may be equipped with heated and cooled press the symbol a second time to turn the cupholder off.
Page 235: Rear Seat Cupholders
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 233 convenient access to beverage cans or bottles while WARNING! maintaining a resting place for the rear occupant’ s elbows. When using the cupholder in the “Heat” position, avoid contact with the heated portion of the cup- holder in order to reduce the possibility of burns.
Page 236: Storage
234 UNDERSTANDING THE FEATURES OF YOUR VEHICLE STORAGE Glovebox Storage The glovebox storage compartment is located on the passenger side of the instrument panel. Opened Glovebox Storage Compartment Glovebox Storage Compartment I n f o r m a t i o n P r o v i d e d b y :...
Page 237: Console Features
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 235 Console Features The center console contains two shift bezel cubby bins with rubber mats for holding small items. For vehicles not equipped with navigation radio, the console also contains an extra storage bin located below the climate control, which holds up to four CD jewel cases.
Page 238: Door Storage
236 UNDERSTANDING THE FEATURES OF YOUR VEHICLE power cords to pass conveniently out of the bin with the Row Armrest Storage — If Equipped lid closed. This feature is ideal for games, laptops, mobile For rear passengers there is a storage bin located in the phones, or other electrical equipment.
Page 239: Cargo Area - Vehicles Equipped With 60/40
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 237 Cargo Area — Vehicles Equipped with 60/40 WARNING! (Continued) Split-Folding Rear Seat • The cargo area in the rear of the vehicle (with the The 60/40 split-folding rear seat provides cargo-carrying rear seatbacks in the locked-up or folded down versatility.
Page 240: Cargo Area Features
238 UNDERSTANDING THE FEATURES OF YOUR VEHICLE CARGO AREA FEATURES WARNING! Trunk Mat — If Equipped The weight and position of cargo and passengers can A trunk mat covers the bottom of the cargo area. The change the vehicle center of gravity and vehicle trunk mat is used to protect the interior of the trunk from handling.
Page 241: Load Leveling System - If Equipped
UNDERSTANDING THE FEATURES OF YOUR VEHICLE 239 A hydraulic pump contained within the shock absorbers CAUTION! raises the rear of the vehicle to the correct height. It takes approximately 1 mile (1.6 km) of driving for the leveling Failure to follow these cautions can cause damage to to complete depending on road surface conditions.
Page 242 240 UNDERSTANDING THE FEATURES OF YOUR VEHICLE Press the “Controls” soft-key and then press the “Sun- screen” soft-key to raise the power sunscreen. Press the “Sunscreen” soft-key a second time to lower the sun- screen. The power sunscreen can also be operated by passengers in the rears seats.
Page 243 UNDERSTANDING YOUR INSTRUMENT PANEL CONTENTS ▫ Oil Change Required ....263 Instrument Panel Features ....243 ▫...
Page 244 242 UNDERSTANDING YOUR INSTRUMENT PANEL ▫ Turn Menu Off ..... . 268 Steering Wheel Audio Controls ... . 286 ▫...
Page 245: Instrument Panel Features
UNDERSTANDING YOUR INSTRUMENT PANEL 243 INSTRUMENT PANEL FEATURES 1 — Air Outlet 7 — ESC Off Switch 13 — Engine Start/Stop Button 2 — Instrument Cluster 8 — Uconnect Touch™ System Hard Controls 14 — Trunk Release Button 3 — Hazard Switch 9 —...
Page 246: Instrument Cluster
244 UNDERSTANDING YOUR INSTRUMENT PANEL INSTRUMENT CLUSTER I n f o r m a t i o n P r o v i d e d b y :...
Page 247: Instrument Cluster Descriptions
UNDERSTANDING YOUR INSTRUMENT PANEL 245 INSTRUMENT CLUSTER DESCRIPTIONS 5. Turn Signal Indicators The arrow will flash with the exterior turn signal 1. Tachometer when the turn signal lever is operated. The red segments indicate the maximum permissible engine revolutions per minute (RPM x 1000) for each gear If the vehicle electronics sense that the vehicle has range.
Page 248 246 UNDERSTANDING YOUR INSTRUMENT PANEL 7. Odometer Display / Electronic Vehicle Information Electronic Vehicle Information Center (EVIC) Display Center (EVIC) Display The Electronic Vehicle Information Center (EVIC) fea- tures a driver-interactive display that is located in the Odometer Display instrument cluster. For further information refer to “Elec- The odometer display shows the total distance the ve- tronic Vehicle Information Center (EVIC)”.
Page 249 UNDERSTANDING YOUR INSTRUMENT PANEL 247 ignition switch is turned to the ON/RUN position, have Accordingly, when the low tire pressure telltale illumi- the light inspected by an authorized dealer. nates, you should stop and check your tires as soon as possible, and inflate them to the proper pressure.
Page 250 248 UNDERSTANDING YOUR INSTRUMENT PANEL illuminated. This sequence will continue upon subse- CAUTION! quent vehicle start-ups as long as the malfunction exists. When the malfunction indicator is illuminated, the sys- The TPMS has been optimized for the original tem may not be able to detect or signal low tire pressure equipment tires and wheels.
Page 251 UNDERSTANDING YOUR INSTRUMENT PANEL 249 does not come on when turning the key from OFF to WARNING! ON/RUN, have the condition checked promptly. A malfunctioning catalytic converter, as referenced Certain conditions such as a loose or missing gas cap, above, can reach higher temperatures than in normal poor fuel quality, etc., may illuminate the MIL after operating conditions.
Page 252 250 UNDERSTANDING YOUR INSTRUMENT PANEL system. If this light remains on after several ignition 12. Electronic Stability Control (ESC) OFF Indicator cycles, and the vehicle has been driven several miles Light — If Equipped (kilometers) at speeds greater than 30 mph (48 km/h), see This light indicates the Electronic Stability Con- your authorized dealer as soon as possible to have the trol (ESC) is off.
Page 253 UNDERSTANDING YOUR INSTRUMENT PANEL 251 16. Airbag Warning Light Select (ERS) feature is active. Use the +/- selector on This light will turn on for four to eight seconds the shift lever to activate ERS. Refer to “Automatic as a bulb check when the ignition switch is first Transmission”...
Page 254 252 UNDERSTANDING YOUR INSTRUMENT PANEL master cylinder reservoir, it indicates a possible brake NOTE: The light may flash momentarily during sharp hydraulic system malfunction or that a problem with the cornering maneuvers, which change fluid level condi- Brake Booster has been detected by the Anti-Lock Brake tions.
Page 255 UNDERSTANDING YOUR INSTRUMENT PANEL 253 Operation of the Brake Warning Light can be checked by 21. Seat Belt Reminder Light turning the ignition switch from the OFF position to the When the ignition switch is first turned to ON/ ON/RUN position. The light should illuminate for ap- RUN, this light will turn on for four to eight proximately two seconds.
Page 256 254 UNDERSTANDING YOUR INSTRUMENT PANEL CAUTION! WARNING! Driving with a hot engine cooling system could A hot engine cooling system is dangerous. You or damage your vehicle. If temperature gauge reads “H” others could be badly burned by steam or boiling pull over and stop the vehicle.
Page 257: Electronic Vehicle Information Center (Evic)
UNDERSTANDING YOUR INSTRUMENT PANEL 255 ELECTRONIC VEHICLE INFORMATION CENTER This system allows the driver to select a variety of useful (EVIC) information by pressing the switches mounted on the The Electronic Vehicle Information Center (EVIC) fea- steering wheel. The EVIC consists of the following: tures a driver-interactive display that is located in the •...
Page 258 256 UNDERSTANDING YOUR INSTRUMENT PANEL The system allows the driver to select information by UP Button pressing the following buttons mounted on the steering Press and release the UP button to scroll up- wheel. ward through the main menu and Vehicle Info and Trip Info sub menus (Fuel Economy, Ve- hicle Info, Tire PSI, Cruise, Messages) and sub menus.
Page 259: Electronic Vehicle Information Center (Evic) Displays
UNDERSTANDING YOUR INSTRUMENT PANEL 257 BACK Button menu. The main display area also displays pop up Press the BACK button to return to the main messages that consist of approximately 60 possible warn- menu from an info screen or sub menu item. ing or information messages.
Page 260: Evic White Telltales
258 UNDERSTANDING YOUR INSTRUMENT PANEL of this message type are Turn Signal On (if a turn signal EVIC White Telltales is left on) and Lights On (if driver leaves the vehicle). This area will show reconfigurable white caution tell- tales. These telltales include: 3.
Page 261: Evic Amber Telltales
UNDERSTANDING YOUR INSTRUMENT PANEL 259 • Electronic Speed Control SET • Forward Collision Warning (FCW) OFF This telltale will illuminate when the electronic This telltale informs the driver that the For- speed control is SET. For further information, ward Collision Warning feature is Off. The refer to “Electronic Speed Control”...
Page 262: Evic Red Telltales
260 UNDERSTANDING YOUR INSTRUMENT PANEL • Service AWD Telltale — If Equipped and shut off the engine as soon as possible. A chime will This telltale is on when the All Wheel Drive feature sound for four minutes when this light turns on. requires service.
Page 263 UNDERSTANDING YOUR INSTRUMENT PANEL 261 • Electronic Throttle Control (ETC) Telltale • Engine Temperature Warning Telltale This telltale informs you of a problem with the This telltale warns of an overheated engine condi- Electronic Throttle Control (ETC) system. If the tion.
Page 264 262 UNDERSTANDING YOUR INSTRUMENT PANEL • Transmission Temperature Warning Telltale WARNING! This telltale indicates that the transmission fluid temperature is running hot. This may If the Transmission Temperature Warning Telltale is occur with severe usage, such as trailer towing. illuminated and you continue operating the vehicle, If this telltale turns on, safely pull over and in some circumstances you could cause the fluid to stop the vehicle.
Page 265: Oil Change Required
UNDERSTANDING YOUR INSTRUMENT PANEL 263 Oil Change Required 2. Fully depress the accelerator pedal slowly three times Your vehicle is equipped with an engine oil change within 10 seconds. indicator system. The Oil Change Due message will 3. Cycle the ignition OFF. display in the EVIC for five seconds after a single chime has sounded at the start of each ignition that an oil NOTE: If the indicator message illuminates when you...
Page 266 264 UNDERSTANDING YOUR INSTRUMENT PANEL Average Fuel Economy Shows the average fuel economy since the last reset. When Average Fuel Economy is selected, The word RESET> (with right arrow) appears next to it. Pressing the right arrow button will reset Average Fuel Economy which displays 0 immediately after reset.
Page 267: Cruise Control
UNDERSTANDING YOUR INSTRUMENT PANEL 265 Distance To Empty (DTE) Miles Per Gallon (MPG) Shows the estimated distance that can be traveled with The Miles Per Gallon (MPG) feature displays instanta- the fuel remaining in the tank. This estimated distance is neous fuel economy in a bar graph below the DTE, this determined by a weighted average of the instantaneous function cannot be reset.
Page 268: Vehicle Speed
266 UNDERSTANDING YOUR INSTRUMENT PANEL or other feature is in the EVIC main display, the ACC will toggle the unit of measure between mph or km/h. status will be displayed in place of the EVIC odometer Press the BACK button to return to the main menu. line.
Page 269: Tire Psi
UNDERSTANDING YOUR INSTRUMENT PANEL 267 The Trip Functions mode displays the following informa- Tire PSI tion: Press and release the UP or DOWN button until Tire PSI is highlighted in the EVIC. Press and release the SELECT Trip A button and one of the following will be displayed: Shows the total distance traveled for Trip A since the last •...
Page 270: Vehicle Info (Customer Information Features)
268 UNDERSTANDING YOUR INSTRUMENT PANEL • Trans Temperature Vehicle Info (Customer Information Features) Press and release the UP or DOWN button until Vehicle Displays the actual transmission temperature. Info is highlighted in the EVIC. Press and release the • Engine Hours SELECT button and Coolant Temp will be displayed.
Page 271: Uconnect Touch™ Settings
UNDERSTANDING YOUR INSTRUMENT PANEL 269 Uconnect Touch™ Settings Auto-On Comfort & Remote Start, Engine Off Operation, The Uconnect Touch™ system uses a combination of soft Compass Settings, Audio, Phone/Bluetooth and SIRIUS and hard keys located on the center of the instrument Setup.
Page 272 270 UNDERSTANDING YOUR INSTRUMENT PANEL • Display Brightness with Headlights ON release the preferred setting until a check-mark appears next to the setting, showing that setting has been se- When in this display you may select display brightness lected. with the headlights on and the headlights off. Adjust the brightness with the + and –...
Page 273 UNDERSTANDING YOUR INSTRUMENT PANEL 271 • Touchscreen Beep language, showing that setting has been selected. Press the back arrow soft-key to return to the previous menu. When in this display you may turn on or shut off the sound heard when a touch screen button (soft-key) is •...
Page 274 272 UNDERSTANDING YOUR INSTRUMENT PANEL your selection, press the Fuel Saver Display soft-key, hours up or down. Press the back arrow soft-key to until a check-mark appears next to the setting, showing return to the previous menu or press the X soft-key to that setting has been selected.
Page 275 UNDERSTANDING YOUR INSTRUMENT PANEL 273 • Show Time in Status Bar possible collision with the vehicle in front of you when When in this display you may turn on or shut off the you are much closer. This allows for a more dynamic digital clock in the status bar.
Page 276 274 UNDERSTANDING YOUR INSTRUMENT PANEL • Tilt Mirrors In Reverse alert when the turn signal is on. When “Off” is selected When this feature is selected, the outside sideview mir- the Blind Spot Monitor (BSM) system is deactivated. To rors will tilt downward when the ignition is in the RUN change the Blind Spot Alert status press the Off, Lights or position and the transmission shift lever is in the RE- Lights &...
Page 277 UNDERSTANDING YOUR INSTRUMENT PANEL 275 top of the screen. After five seconds this note will and operating information. To make your selection, press disappear. The ParkView camera is located on the rear the Hill Start Assist soft-key, until a check-mark appears of the vehicle above the rear License plate.
Page 278 276 UNDERSTANDING YOUR INSTRUMENT PANEL Illuminated Approach status press the + or - soft-key to setting has been selected. Press the back arrow soft-key to select your desired time interval. Press the back arrow return to the previous menu.. Refer to “Lights/ soft-key to return to the previous menu.
Page 279 UNDERSTANDING YOUR INSTRUMENT PANEL 277 • Headlight Dip (Traffic Changeover) • Auto Unlock on Exit Low beam headlights have more control of upward light When this feature is selected, all doors will unlock when and direct most of their light downward and either to the the vehicle is stopped and the transmission is in the right for right had drive countries or to the left for left PARK or NEUTRAL position and the driver’s door is...
Page 280 278 UNDERSTANDING YOUR INSTRUMENT PANEL • Sound Horn with Lock Press is selected, you must press the RKE transmitter When this feature is selected, the horn will sound when UNLOCK button twice to unlock the passenger’s doors. the remote start is activated. To make your selection, When Unlock All Doors On 1st Press is selected, all of press the Sound Horn with Remote Start soft-key, until a the doors will unlock on the first press of the RKE...
Page 281 UNDERSTANDING YOUR INSTRUMENT PANEL 279 • Passive Entry to ON) when the RKE transmitter is used to unlock the This feature allows you to lock and unlock the vehicle’s door. Refer to “Driver Memory Seat” in “Understanding door(s) without having to press the RKE transmitter lock The Features Of Your Vehicle”...
Page 282 280 UNDERSTANDING YOUR INSTRUMENT PANEL • Engine Off Power Delay temperatures are below 40° F (4.4° C). When tempera- tures are above 80° F (26.7° C) the driver vented seat will When this feature is selected, the power window turn on. To make your selection, press the Auto Heated switches, radio, Uconnect™...
Page 283 UNDERSTANDING YOUR INSTRUMENT PANEL 281 Compass Settings After pressing the Compass Settings soft-key the follow- ing settings will be available. • Variance Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differences the variance should be set for the zone where the vehicle is driven, per the zone map.
Page 284 282 UNDERSTANDING YOUR INSTRUMENT PANEL • Equalizer calibrate the compass by pressing the ON soft-key and completing one or more 360–degree turns (in an area free When in this display you may adjust the Bass, Mid and from large metal or metallic objects) until the CAL Treble settings.
Page 285 UNDERSTANDING YOUR INSTRUMENT PANEL 283 • Paired Devices • Subscription Information This feature shows which phones are paired to the New vehicle purchasers or lessees will receive a free Phone/Bluetooth system. For further information, refer limited time subscription to SIRIUS Satellite Radio with to the Uconnect Touch™...
Page 286: Setting The Analog Clock
284 UNDERSTANDING YOUR INSTRUMENT PANEL SETTING THE ANALOG CLOCK iPod /USB/MP3 CONTROL— IF EQUIPPED To set the analog clock at the top center of the instrument This feature allows an iPod or external USB device to be panel, press and hold the button until the setting is plugged into the USB port.
Page 287: Kicker High Performance Sound System With Driver-Selectable Surround (Dss) - If Equipped
UNDERSTANDING YOUR INSTRUMENT PANEL 285 KICKER HIGH PERFORMANCE SOUND SYSTEM sound from any stereo audio source. A new feature of the WITH DRIVER-SELECTABLE SURROUND (DSS) – KICKER audio system offers the ability to choose sur- IF EQUIPPED round sound for any audio source. “Audio Surround”...
Page 288: Steering Wheel Audio Controls
286 UNDERSTANDING YOUR INSTRUMENT PANEL NOTE: Dependent on the audio source, the output may sound better in stereo or DDS surround mode. When in “Audio Surround” mode, balance is set auto- matically. Fader control is available in surround mode but should be set to the center position for optimal surround performance.
Page 289: Radio Operation
UNDERSTANDING YOUR INSTRUMENT PANEL 287 Pressing the center button will make the radio switch CD Player between the various modes available (AM/FM/TAPE/ Pressing the top of the switch once will go to the next CD, etc.). track on the CD. Pressing the bottom of the switch once will go to the beginning of the current track, or to the The left-hand control is a rocker-type switch with a beginning of the previous track if it is within one second...
Page 290: Cd/Dvd Disc Maintenance
288 UNDERSTANDING YOUR INSTRUMENT PANEL CD/DVD DISC MAINTENANCE NOTE: If you experience difficulty in playing a particu- To keep a CD/DVD in good condition, take the following lar disc, it may be damaged (i.e., scratched, reflective precautions: coating removed, a hair, moisture or dew on the disc) oversized, or have protection encoding.
Page 291: Climate Controls
UNDERSTANDING YOUR INSTRUMENT PANEL 289 CLIMATE CONTROLS General Overview The air conditioning and heating system is designed to Hard-Keys make you comfortable in all types of weather. This The hard-keys are located below the Uconnect Touch™ system can be operated through either the Automatic screen, in the center of the instrument panel.
Page 292 290 UNDERSTANDING YOUR INSTRUMENT PANEL Soft-Keys Button Descriptions (Applies To Both Hard-keys And Soft-keys are accessible on the Uconnect Touch™ system Soft-keys) screen. 1. A/C Button Press and release to change the current Air Conditioning (A/C) setting, the indicator illuminates when A/C is ON. Performing this function will cause the automatic opera- tion to switch into manual mode and the AUTO indicator will turn off.
Page 293 UNDERSTANDING YOUR INSTRUMENT PANEL 291 Hard-key 5. Rear Defrost Button The blower speed increases as you turn the control Press and release this button to turn on the rear window clockwise from the lowest blower setting. The blower defroster and the heated outside mirrors (if equipped). speed decreases as you turn the knob counter-clockwise.
Page 294 292 UNDERSTANDING YOUR INSTRUMENT PANEL 8. Climate Control OFF Button CAUTION! (Continued) Press and release this button to turn the Climate Control • Do not use scrapers, sharp instruments, or abra- ON/OFF. sive window cleaners on the interior surface of the 9.
Page 295 UNDERSTANDING YOUR INSTRUMENT PANEL 293 11. Driver Temperature Control Up Button to side to regulate airflow direction. There is a shut off Provides the driver with independent temperature con- wheel located below the air vanes to shut off or adjust the trol.
Page 296: Climate Control Functions
294 UNDERSTANDING YOUR INSTRUMENT PANEL • Mix Mode enabled. Sync is used to synchronize the passenger Air comes from the floor, defrost and side window temperature setting with the driver temperature setting. demist outlets. This mode works best in cold or Changing the passenger temperature setting while in snowy conditions.
Page 297: Automatic Temperature Control (Atc)
UNDERSTANDING YOUR INSTRUMENT PANEL 295 • If fog or mist appears on the windshield or side glass, NOTE: In cold weather, use of Recirculation mode may select Defrost mode and increase blower speed. lead to excessive window fogging. On systems with Manual Climate Controls, the Recirculation mode is not •...
Page 298 296 UNDERSTANDING YOUR INSTRUMENT PANEL • The temperature can be displayed in U.S. or Metric 2. Next, adjust the temperature you would like the system to maintain by adjusting the driver and passenger units by selecting the US/M customer-programmable temperature hard or soft control buttons (6, 7, 10, 11). feature.
Page 299: Operating Tips
UNDERSTANDING YOUR INSTRUMENT PANEL 297 The operator can also select the direction of the airflow Winter Operation by selecting one of the available mode settings. A/C Use of the air Recirculation mode during Winter months operation and Recirculation control can also be manually is not recommended because it may cause window selected in Manual operation.
Page 300 298 UNDERSTANDING YOUR INSTRUMENT PANEL Window Fogging Outside Air Intake Interior fogging on the windshield can be quickly re- Make sure the air intake, located directly in front of the moved by turning the mode selector to Defrost. The windshield, is free of obstructions such as leaves. Leaves Defrost/Floor mode can be used to maintain a clear collected in the air intake may reduce airflow, and if they windshield and provide sufficient heating.
Page 301 STARTING AND OPERATING CONTENTS Starting Procedures ....304 Automatic Transmission ....309 ▫...
Page 302 300 STARTING AND OPERATING ▫ Traction Control System (TCS) ... 328 Driving On Slippery Surfaces ... . . 318 ▫ Acceleration ......318 ▫...
Page 303 STARTING AND OPERATING 301 ▫ Tire Inflation Pressures ....343 Snow Tires ......353 ▫...
Page 304 302 STARTING AND OPERATING ▫ Materials Added To Fuel ....368 Adding Fuel ......373 ▫...
Page 305 STARTING AND OPERATING 303 ▫ Trailer And Tongue Weight ... . . 383 Recreational Towing (Behind Motorhome, Etc.)....... . 390 ▫...
Page 306: Starting Procedures
304 STARTING AND OPERATING STARTING PROCEDURES CAUTION! Before starting your vehicle, adjust your seat, adjust the inside and outside mirrors, fasten your seat belt, and if Damage to the transmission may occur if the follow- present, instruct all other occupants to buckle their seat ing precautions are not observed: belts.
Page 307: Keyless Enter-N-Go
STARTING AND OPERATING 305 Keyless Enter-N-Go 10 seconds. If you wish to stop the cranking of the engine This feature allows the driver to oper- prior to the engine starting, press the button again. ate the ignition switch with the push To Turn Off the Engine Using ENGINE of a button, as long as the Remote START/STOP Button...
Page 308: Extreme Cold Weather (Below -20°F Or 29°C)
306 STARTING AND OPERATING • Press the ENGINE START/STOP button a second time NOTE: If the ignition switch is left in the ACC or RUN (engine not running) position and the transmission is in to change the ignition switch to the RUN position PARK, the system will automatically time out after (EVIC displays “ON/RUN”), 30 minutes of inactivity and the ignition will switch to the...
Page 309: If Engine Fails To Start
STARTING AND OPERATING 307 If Engine Fails To Start WARNING! (Continued) • Do not attempt to push or tow your vehicle to get WARNING! it started. Vehicles equipped with an automatic • Never pour fuel or other flammable liquids into transmission cannot be started this way.
Page 310: After Starting
308 STARTING AND OPERATING Clearing a Flooded Engine (Using ENGINE ENGINE BLOCK HEATER — IF EQUIPPED START/STOP Button) The engine block heater warms the engine, and permits If the engine fails to start after you have followed the quicker starts in cold weather. Connect the cord to a “Normal Starting”...
Page 311: Automatic Transmission
STARTING AND OPERATING 309 AUTOMATIC TRANSMISSION WARNING! CAUTION! It is dangerous to move the shift lever out of PARK or NEUTRAL if the engine speed is higher than idle Damage to the transmission may occur if the follow- speed. If your foot is not firmly on the brake pedal, ing precautions are not observed: the vehicle could accelerate quickly forward or in •...
Page 312 310 STARTING AND OPERATING • Shift lever position • The electronically-controlled transmission provides a precise shift schedule. The transmission electronics are • Accelerator position self-calibrating. Therefore, the first few shifts on a new • Vehicle speed vehicle may be somewhat abrupt or soft until after the break-in period.
Page 313: Brake/Transmission Shift Interlock System
STARTING AND OPERATING 311 Over-Temperature Mode WARNING! The transmission electronics constantly monitor the transmission oil temperature. If the transmission exceeds Unintended movement of a vehicle could injure normal operating temperature, the transmission will those in and near the vehicle. As with all vehicles, change the way it shifts to help control the condition.
Page 314: Five-Speed Automatic Transmission
312 STARTING AND OPERATING Five-Speed Automatic Transmission Gear Ranges Shifting from DRIVE to PARK or REVERSE should be PARK done only after the accelerator pedal is released and the This range supplements the parking brake by locking the vehicle is stopped. Be sure to keep your foot on the brake transmission.
Page 315 STARTING AND OPERATING 313 WARNING! CAUTION! Never use the PARK position as a substitute for the Damage to the shifter could result if the shift lever is parking brake. Always apply parking brake fully moved out of PARK before the ignition light is when parked to guard against vehicle movement and turned from the OFF to the RUN position.
Page 316 314 STARTING AND OPERATING The transmission automatically upshifts through fifth CAUTION! gear. The DRIVE position provides optimum driving characteristics under all normal operating conditions. Coasting the vehicle or driving for any other reason with shift lever in NEUTRAL can result in transmis- When frequent transmission shifting occurs (such as sion damage.
Page 317: Autostick
STARTING AND OPERATING 315 If vehicle acceleration worsens, or the transmission no 6. Move the shift lever to the desired range. If the longer shifts, the transmission is most likely operating in problem is no longer detected, the transmission will the Limp Home Mode.
Page 318: Operation
316 STARTING AND OPERATING downshifts, and improve overall vehicle performance. Fully pressing the accelerator pedal while in Autostick This system can also provide you with more control mode will downshift the transmission as needed for during passing, city driving, cold slippery conditions, maximum acceleration (3.6L Models Only).
Page 319: All-Wheel Drive (Awd) - If Equipped
STARTING AND OPERATING 317 vehicle automatically shifts into AWD mode. Automatic WARNING! AWD operation could be activated by outside tempera- ture, wheel slip, or other predetermined conditions (there Do not downshift for additional engine braking on a may be a slight delay for AWD engagement after a wheel slippery surface.
Page 320: Driving On Slippery Surfaces
318 STARTING AND OPERATING CAUTION! WARNING! All wheels must have the same size and type tires. Rapid acceleration on slippery surfaces is dangerous. Unequal tire sizes must not be used. Unequal tire Unequal traction can cause sudden pulling of the rear size may cause failure of the front differential and/or wheels.
Page 321: Driving Through Water
STARTING AND OPERATING 319 2. Slow down if the road has standing water or puddles. Flowing/Rising Water 3. Replace tires when tread wear indicators first become WARNING! visible. Do not drive on or across a road or path where water 4.
Page 322 320 STARTING AND OPERATING CAUTION! CAUTION! (Continued) • Driving through standing water may cause dam- • Always check the depth of the standing water age to your vehicle’s drivetrain components. Al- before driving through it. Never drive through ways inspect your vehicle’s fluids (i.e., engine oil, standing water that is deeper than the bottom of transmission, axle, etc.) for signs of contamination the tire rims mounted on the vehicle.
Page 323: Power Steering
STARTING AND OPERATING 321 POWER STEERING WARNING! Your vehicle is equipped with an electro-hydraulic power • Driving through standing water limits your vehi- steering system that will give you good vehicle response and increased ease of maneuverability in tight spaces. cle’s traction capabilities.
Page 324: Multi-Displacement System (Mds) (If Equipped) - 5.7L Engine Only
322 STARTING AND OPERATING If the “SERVICE POWER STEERING SYSTEM” NOTE: • Even if power steering assistance is no longer opera- message and a flashing icon are displayed on the EVIC screen, it indicates that the vehicle tional, it is still possible to steer the vehicle. Under needs to be taken to the dealer for service.
Page 325: Parking Brake
STARTING AND OPERATING 323 PARKING BRAKE Before leaving the vehicle, make sure that the parking brake is fully applied and place the shift lever in the PARK position. The foot operated parking brake is located below the lower left corner of the instrument panel. To apply the park brake, firmly push the park brake pedal fully.
Page 326 324 STARTING AND OPERATING NOTE: WARNING! • When the parking brake is applied and the transmis- • Never use the PARK position as a substitute for sion is placed in gear, the “Brake Warning Light” will flash. If vehicle speed is detected, a chime will sound the parking brake.
Page 327: Anti-Lock Brake System
STARTING AND OPERATING 325 the brakes during severe braking conditions to prevent WARNING! (Continued) wheel lock-up. • Always fully apply the parking brake when leav- The Electronic Brake Force Distribution (EBD) prevents ing your vehicle, or it may roll and cause damage the rear wheels from over-braking and provides greater or injury.
Page 328 326 STARTING AND OPERATING You also may experience the following when the brake WARNING! system goes into Anti-Lock: • The ABS contains sophisticated electronic equip- • The ABS motor running (it may continue to run for a ment that may be susceptible to interference short time after the stop), caused by improperly installed or high output •...
Page 329: Electronic Brake Control System
STARTING AND OPERATING 327 ELECTRONIC BRAKE CONTROL SYSTEM WARNING! (Continued) Your vehicle is equipped with an advanced electronic • The ABS cannot prevent the natural laws of phys- brake control system that include Anti-Lock Brake Sys- ics from acting on the vehicle, nor can it increase tem (ABS), Traction Control System (TCS), Brake Assist braking or steering efficiency beyond that af- System (BAS), and the Electronic Stability Control (ESC).
Page 330: Traction Control System (Tcs)
328 STARTING AND OPERATING Brake Assist System (BAS) WARNING! This system complements the ABS by optimizing the vehicle braking capability during emergency brake ma- The ABS cannot prevent the natural laws of physics neuvers. This system detects an emergency braking situ- from acting on the vehicle, nor can it increase the ation by sensing the rate and amount of brake application traction afforded by prevailing road conditions.
Page 331: Electronic Stability Control (Esc)
STARTING AND OPERATING 329 power may also be reduced to assist in counteracting the WARNING! condition of oversteer or understeer and help the vehicle maintain the desired path. The BAS cannot prevent the natural laws of physics from acting on the vehicle, nor can it increase the The ESC uses sensors in the vehicle to determine the path traction afforded by prevailing road conditions.
Page 332 330 STARTING AND OPERATING ESC Operating Modes The “ESC Off” switch is located on the switch bank in the The ESC system has two available operating modes: center of the instrument panel. To enter the “Partial Off” mode, momentarily press the “ESC Off” switch and the ESC On “ESC Activation/Malfunction Indicator Light”...
Page 333: Esc Activation/Malfunction Indicator Light And Esc Off Indicator Light
STARTING AND OPERATING 331 position. It should go out with the engine running. If the WARNING! “ESC Activation/Malfunction Indicator Light” comes on continuously with the engine running, a malfunction has The Electronic Stability Control (ESC) cannot pre- been detected in the ESC system. If this light remains on vent the natural laws of physics from acting on the after several ignition cycles, and the vehicle has been vehicle, nor can it increase the traction afforded by...
Page 334: Synchronizing Esc
332 STARTING AND OPERATING NOTE: Synchronizing ESC • The “ESC Activation/Malfunction Indicator Light” If the power supply is interrupted (battery and the “ESC OFF Indicator Light” come on momen- disconnected discharged), “ESC tarily each time the ignition switch is turned ON. Activation/Malfunction Indicator Light”...
Page 335: Tire Safety Information
STARTING AND OPERATING 333 TIRE SAFETY INFORMATION NOTE: • P (Passenger) - Metric tire sizing is based on U.S. Tire Markings design standards. P-Metric tires have the letter “P” molded into the sidewall preceding the size designa- tion. Example: P215/65R15 95H. •...
Page 336 334 STARTING AND OPERATING • Temporary spare tires are high-pressure compact • High flotation tire sizing is based on U.S. design spares designed for temporary emergency use only. standards and it begins with the tire diameter molded Tires designed to this standard have the letter “T” into the sidewall.
Page 337 STARTING AND OPERATING 335 EXAMPLE: 15 = Rim diameter in inches (in) Service Description: 95 = Load Index — A numerical code associated with the maximum load a tire can carry H = Speed Symbol — A symbol indicating the range of speeds at which a tire can carry a load corresponding to its load index under certain operating conditions —...
Page 338: Tire Identification Number (Tin)
336 STARTING AND OPERATING Tire Identification Number (TIN) Look for the TIN on the outboard side of black sidewall The TIN may be found on one or both sides of the tire, tires as mounted on the vehicle. If the TIN is not found on however, the date code may only be on one side.
Page 339: Tire Terminology And Definitions
STARTING AND OPERATING 337 Tire Terminology and Definitions Term Definition B-Pillar The vehicle B-Pillar is a structural member of the body located between the front and rear door (of a four-door vehicle) running from the sill to the roof. Cold Tire Pressure Cold tire inflation pressure is defined as the tire pressure after the vehicle has not been driven for at least 3 hours, or driven less than 1 mile (1.6 km) after sitting for a three hour period.
Page 340: Tire Loading And Tire Pressure
338 STARTING AND OPERATING Tire Loading And Tire Pressure Tire and Loading Information Placard Tire Placard Location NOTE: The proper cold tire inflation pressure is listed on the driver’s side B-Pillar. Tire and Loading Information Placard This placard tells you important information about the: 1) number of people that can be carried in the vehicle 2) total weight your vehicle can carry 3) tire size designed for your vehicle...
Page 341 STARTING AND OPERATING 339 Loading The combined weight of occupants, cargo/luggage and The vehicle maximum load on the tire must not exceed trailer tongue weight (if applicable) should never exceed the load carrying capacity of the tire on your vehicle. You the weight referenced here.
Page 342 340 STARTING AND OPERATING available cargo and luggage load capacity is 650 lbs NOTE: • The following table shows examples on how to calcu- (295 kg) (since 5 x 150 = 750, and 1400 – 750 = 650 lbs [295 kg]). late total load, cargo/luggage, and towing capacities of your vehicle with varying seating configurations 5.
Page 343 STARTING AND OPERATING 341 I n f o r m a t i o n P r o v i d e d b y :...
Page 344: Tires - General Information
342 STARTING AND OPERATING Safety WARNING! WARNING! Overloading of your tires is dangerous. Overloading can cause tire failure, affect vehicle handling, and • Improperly inflated tires are dangerous and can increase your stopping distance. Use tires of the cause collisions. recommended load capacity for your vehicle.
Page 345: Tire Inflation Pressures
STARTING AND OPERATING 343 Tire Inflation Pressures WARNING! (Continued) The proper cold tire inflation pressure is listed on the • Unequal tire pressures from one side of the ve- driver’s side “B” Pillar. hicle to the other can cause the vehicle to drift to Some vehicles may have Supplemental Tire Pressure the right or left.
Page 346: Tire Pressures For High Speed Operation
344 STARTING AND OPERATING Tire pressures change by approximately 1 psi (7 kPa) per CAUTION! 12°F (7°C) of air temperature change. Keep this in mind when checking tire pressure inside a garage, especially in After inspecting or adjusting the tire pressure, al- the Winter.
Page 347: Radial Ply Tires
STARTING AND OPERATING 345 loading may be required for high-speed vehicle opera- Radial Ply Tires tion. Refer to original equipment or an authorized tire WARNING! dealer for recommended safe operating speeds, loading and cold tire inflation pressures. Combining radial ply tires with other types of tires on your vehicle will cause your vehicle to handle WARNING! poorly.
Page 348: Compact Spare Tire - If Equipped
346 STARTING AND OPERATING vehicle has an option for a spare tire matching original CAUTION! equipment tire and wheel, refer to the recommended tire rotation pattern in “Tire Rotation Recommendations” in Because of the reduced ground clearance, do not take “Starting and Operating”...
Page 349: Full Size Spare - If Equipped
STARTING AND OPERATING 347 Since this tire has limited tread life the original equip- Full Size Spare – If Equipped ment tire should be repaired (or replaced) and reinstalled The full size spare is for temporary emergency use only. on your vehicle at the first opportunity. This tire may look like the original equipped tire on the front or rear axle of your vehicle, but it is not.
Page 350: Tire Spinning
348 STARTING AND OPERATING your original equipment tire, replace (or repair) the Tire Spinning original equipment tire and reinstall on the vehicle at the When stuck in mud, sand, snow, or ice conditions, do not first opportunity. spin your vehicle’s wheels faster than 30 mph (48 km/h) or for longer than 30 seconds continuously without WARNING! stopping when you are stuck.
Page 351: Tread Wear Indicators
STARTING AND OPERATING 349 Tread Wear Indicators These indicators are molded into the bottom of the tread Tread wear indicators are in the original equipment tires grooves. They will appear as bands when the tread depth to help you in determining when your tires should be becomes 1/16 in (2 mm).
Page 352: Replacement Tires
350 STARTING AND OPERATING Replacement Tires WARNING! The tires on your new vehicle provide a balance of many characteristics. They should be inspected regularly for Tires and the spare tire should be replaced after six wear and correct cold tire inflation pressure. The manu- years, regardless of the remaining tread.
Page 353: Tire Chains
STARTING AND OPERATING 351 WARNING! WARNING! (Continued) • Failure to equip your vehicle with tires having • Do not use a tire, wheel size or rating other than adequate speed capability can result in sudden tire that specified for your vehicle. Some combinations failure and loss of vehicle control.
Page 354 352 STARTING AND OPERATING NOTE: Do not use tire chains on a compact spare tire. CAUTION! (Continued) • Drive cautiously and avoid severe turns and large CAUTION! bumps, especially with a loaded vehicle. To avoid damage to your vehicle or tires, observe the •...
Page 355: Snow Tires
STARTING AND OPERATING 353 Always use the lower suggested operating speed if both original equipment or an authorized tire dealer for the chain manufacturer and vehicle manufacturer sug- recommended safe operating speeds, loading and cold gest a maximum speed. This notice applies to all chain tire inflation pressures.
Page 356 354 STARTING AND OPERATING tires. Rotation will increase tread life, help to maintain mud, snow and wet traction levels, and contribute to a smooth, quiet ride. Refer to the “Maintenance Schedule” for the proper maintenance intervals. The reasons for any rapid or unusual wear should be corrected prior to rotation being performed.
Page 357: Tire Pressure Monitor System (Tpms)
STARTING AND OPERATING 355 TIRE PRESSURE MONITOR SYSTEM (TPMS) The TPMS will warn the driver of a low tire pressure if The Tire Pressure Monitor System (TPMS) will warn the the tire pressure falls below the low-pressure warning driver of a low tire pressure based on the vehicle recom- limit for any reason, including low temperature effects mended cold placard pressure.
Page 358 356 STARTING AND OPERATING For example, your vehicle may have a recommended CAUTION! cold (parked for more than three hours) placard pressure • The TPMS has been optimized for the original of 30 psi (207 kPa). If the ambient temperature is 68°F (20°C) and the measured tire pressure is 27 psi (186 kPa), equipment tires and wheels.
Page 359: Base System
STARTING AND OPERATING 357 • Seasonal temperature changes will affect tire pressure, NOTE: • The TPMS is not intended to replace normal tire care and the TPMS will monitor the actual tire pressure in and maintenance or to provide warning of a tire failure the tire.
Page 360 358 STARTING AND OPERATING The matching full size spare wheel and tire assembly (if message will turn off. The vehicle may need to be driven equipped) has a TPM sensor. The matching full size spare for up to 20 minutes above 15 mph (24 km/h) in order for can be used in place of any of the four road tires.
Page 361 STARTING AND OPERATING 359 3. Accumulation of snow or ice around the wheels or TIRE message as long as no tire pressure is below the wheel housings. low-pressure warning limit in any of the four active road tires. 4. Using tire chains on the vehicle. Vehicles with Compact Spare 5.
Page 362: Premium System - If Equipped
360 STARTING AND OPERATING 4. For each subsequent ignition switch cycle, a chime will NOTE: It is particularly important for you to check the sound and the TPM Telltale Light will flash on and off for tire pressure in all of the tires on your vehicle monthly 75 seconds and then remain on solid.
Page 363 STARTING AND OPERATING 361 Tire Pressure Monitoring Low Pressure Warnings The TPM Telltale Light will illuminate in the instrument cluster and a chime will sound when tire pressure is low in one or more of the four active road tires. In addition, the EVIC will display a LOW TIRE message and a graphic showing the pres- sure values of each tire with the low tire pressure values flashing.
Page 364 362 STARTING AND OPERATING turn off. The vehicle may need to be driven for up to 20 minutes above 15 mph (24 km/h) in order for the TPMS to receive this information. Service TPMS Warning If a system fault is detected, the TPM Telltale Light will flash on and off for 75 seconds and then remain on solid.
Page 365 STARTING AND OPERATING 363 1. Signal interference due to electronic devices or driving position. The system still needs to be serviced as long as next to facilities emitting the same radio frequencies as the SERVICE TPM SYSTEM message is displayed. the TPM sensors.
Page 366 364 STARTING AND OPERATING Vehicles with Compact Spare 4. For each subsequent ignition switch cycle, a chime will sound, the TPM Telltale Light will flash on and off for 1. The compact spare tire does not have a TPM sensor. 75 seconds and then remain on solid, and the EVIC will Therefore, the TPMS will not monitor the pressure in the display a SERVICE TPM SYSTEM message for a mini-...
Page 367: General Information
STARTING AND OPERATING 365 General Information FUEL REQUIREMENTS This device complies with Part 15 of the FCC rules and 3.6L Engine – If Equipped RSS 210 of Industry Canada. Operation is subject to the This engine is designed to meet all emis- following conditions: sions regulations and provide excellent •...
Page 368: Reformulated Gasoline
366 STARTING AND OPERATING optimum performance. The use of premium gasoline is Reformulated Gasoline not recommended, as it will not provide any benefit over Many areas of the country require the use of cleaner regular gasoline in these engines. burning gasoline referred to as “Reformulated Gasoline.” Reformulated gasoline contains oxygenates and are spe- Light spark knock at low engine speeds is not harmful to cifically blended to reduce vehicle emissions and im-...
Page 369: E-85 Usage In Non-Flex Fuel Vehicles
STARTING AND OPERATING 367 If a Non-FFV vehicle is inadvertently fueled with E-85 CAUTION! fuel, the engine will have some or all of these symptoms: DO NOT use gasoline containing Methanol or gaso- • operate in a lean mode line containing more than 10% Ethanol. Use of these •...
Page 370: Mmt In Gasoline
368 STARTING AND OPERATING MMT In Gasoline Materials Added to Fuel MMT is a manganese-containing metallic additive that is All gasoline sold in the United States is required to blended into some gasoline to increase octane. Gasoline contain effective detergent additives. Use of additional blended with MMT provides no performance advantage detergents or other additives is not needed under normal beyond gasoline of the same octane number without...
Page 371: Carbon Monoxide Warnings
STARTING AND OPERATING 369 Carbon Monoxide Warnings CAUTION! (Continued) • An out-of-tune engine or certain fuel or ignition WARNING! malfunctions can cause the catalytic converter to Carbon monoxide (CO) in exhaust gases is deadly. overheat. If you notice a pungent burning odor or Follow the precautions below to prevent carbon some light smoke, your engine may be out of tune monoxide poisoning:...
Page 372: Flexible Fuel (3.6L Engine Only) - If Equipped
370 STARTING AND OPERATING WARNING! (Continued) CAUTION! • Guard against carbon monoxide with proper Only vehicles with the E-85 fuel filler door label can maintenance. Have the exhaust system inspected operate on E-85. every time the vehicle is raised. Have any abnor- mal conditions repaired promptly.
Page 373: Ethanol Fuel (E-85)
STARTING AND OPERATING 371 Ethanol Fuel (E-85) When you do switch fuel types it is recommended that: E-85 is a mixture of approximately 85% fuel ethanol and • you do not add less than 5 gal (19 L) when refueling 15% unleaded gasoline.
Page 374: Selection Of Engine Oil For Flexible Fuel Vehicles (E-85) And Gasoline Vehicles
32°F (0°C). in MOPAR engine oils, and in equivalent oils meeting Cruising Range Chrysler Specification MS-6395. The manufacturer only Because E-85 fuel contains less energy per gallon/liter recommends engine oils that are API Certified and meet than gasoline, you will experience an increase in fuel the requirements of Material Standard MS-6395.
Page 375: Maintenance
STARTING AND OPERATING 373 ADDING FUEL CAUTION! 1. Press the fuel filler door release switch (located in the Replacing fuel system components with non-ethanol driver’s door map pocket). compatible components can damage your vehicle. Maintenance If you operate the vehicle using E-85 fuel, follow the maintenance schedule section of this manual.
Page 376 374 STARTING AND OPERATING 2. Open the fuel filler door. NOTE: Only the correct size nozzle opens the latches allowing the flapper door to open. 5. Fill the vehicle with fuel – when the fuel nozzle “clicks” or shuts off the fuel tank is full. 6.
Page 377: Emergency Fuel Filler Door Release
STARTING AND OPERATING 375 2. Pull the release cable located on the driver’s side. WARNING! VEHICLE LOADING • Never have any smoking materials lit in or near The load carrying capacity of your vehicle is shown on the vehicle when the fuel door is open or the tank the “Vehicle Certification Label.”...
Page 378: Gross Vehicle Weight Rating (Gvwr)
376 STARTING AND OPERATING • Gross Axle Weight Rating (GAWR) front WARNING! • Gross Axle Weight Rating (GAWR) rear Because the front wheels steer the vehicle, it is • Vehicle Identification Number (VIN) important that you do not exceed the maximum front or rear GAWR.
Page 379: Loading
STARTING AND OPERATING 377 Figure out the weight on the front and rear of the vehicle NOTE: • Refer to the “Vehicle Certification Label” affixed to the separately. It is important that you distribute the load evenly over the front and rear axles. rear of the driver’s door for your vehicle’s GVWR and GAWRs.
Page 380: Common Towing Definitions
378 STARTING AND OPERATING Common Towing Definitions Gross Combination Weight Rating (GCWR) The following trailer towing related definitions will assist The GCWR is the total permissible weight of your vehicle you in understanding the following information: and trailer when weighed in combination. Gross Vehicle Weight Rating (GVWR) NOTE: The GCWR rating includes a 150 lbs (68 kg) The GVWR is the total allowable weight of your vehicle.
Page 381 STARTING AND OPERATING 379 Trailer Sway Control WARNING! The trailer sway control is a telescoping link that can be installed between the hitch receiver and the trailer tongue It is important that you do not exceed the maximum that typically provides adjustable friction associated with front or rear GAWR.
Page 382 380 STARTING AND OPERATING Weight-Distributing Hitch WARNING! A weight-distributing system works by applying lever- • An improperly adjusted weight distributing hitch age through spring (load) bars. They are typically used for heavier loads to distribute trailer tongue weight to the system may reduce handling, stability, braking tow vehicle’s front axle and the trailer axle(s).
Page 383: Trailer Hitch Classification
STARTING AND OPERATING 381 Trailer Hitch Classification Trailer Hitch Classification Definitions Your vehicle may be factory equipped for safe towing of Max. Trailer Hitch Class trailers weighing over 2,000 lbs (907 kg) with the optional Industry Standards Trailer Tow Prep Package. See your authorized dealer for Class I - Light Duty 2,000 lbs (907 kg) package content.
Page 384: Trailer Towing Weights (Maximum Trailer Weight Ratings)
382 STARTING AND OPERATING Trailer Towing Weights (Maximum Trailer Weight Ratings) The following chart provides the maximum trailer weight ratings towable for your given drivetrain. Engine/Transmission Frontal Area Max. GTW (Gross Trailer Max. Tongue Wt. (See Wt.) Note) 3.6L Automatic 22 sq ft (2.04 sq m) 1,000 lbs (454 kg) 100 lbs (45 kg)
Page 385: Trailer And Tongue Weight
STARTING AND OPERATING 383 Trailer And Tongue Weight Always load a trailer with 60% to 65% of the weight in the front of the trailer. This places 10% to 15% of the Gross Trailer Weight (GTW) on the tow hitch of your vehicle.
Page 386: Towing Requirements
384 STARTING AND OPERATING NOTE: Remember that everything put into or on the CAUTION! (Continued) trailer adds to the load on your vehicle. Also, additional • Then, during the first 500 miles (805 km) that a factory-installed options or dealer-installed options must trailer is towed, do not drive over 50 mph be considered as part of the total load on your vehicle.
Page 387 STARTING AND OPERATING 385 WARNING! (Continued) WARNING! (Continued) • Make certain that the load is secured in the trailer • Vehicles with trailers should not be parked on a grade. When parking, apply the parking brake on and it will not shift during travel. When trailering the tow vehicle.
Page 388 386 STARTING AND OPERATING Towing Requirements – Tires on replacement tires and for the proper tire replace- ment procedures. Replacing tires with a higher load − Do not attempt to tow a trailer while using a compact carrying capacity will not increase the vehicle’s GVWR spare tire.
Page 389 STARTING AND OPERATING 387 CAUTION! WARNING! (Continued) • Towing any trailer will increase your stopping If the trailer weighs more than 1,000 lbs (454 kg) distance. When towing, you should allow for ad- loaded, it should have its own brakes, and they ditional space between your vehicle and the ve- should be of adequate capacity.
Page 390 388 STARTING AND OPERATING The wiring harness is not installed when leaving the factory; it must be done by the dealer or customer. Refer to the following illustrations. Seven-Pin Connector 1 — Battery 5 — Ground 2 — Backup Lamps 6 —...
Page 391: Towing Tips
STARTING AND OPERATING 389 Towing Tips specified for “police, taxi, fleet, or frequent trailer tow- Before setting out on a trip, practice turning, stopping, ing.” Refer to “Maintenance Schedule” for the proper and backing up the trailer in an area located away from maintenance intervals.
Page 392: Etc.)
390 STARTING AND OPERATING adequate performance. For example, choose “4” if the − Air Conditioning desired speed can be maintained. Choose “3” or “2” if Turn off temporarily. needed to maintain the desired speed. RECREATIONAL TOWING (BEHIND − Extended driving at high RPM should be avoided to MOTORHOME, ETC.) prevent excess heat generation.
Page 393: What To Do In Emergencies
WHAT TO DO IN EMERGENCIES CONTENTS Hazard Warning Flashers ....392 Jump-Starting Procedures ....404 ▫...
Page 394: Hazard Warning Flashers
392 WHAT TO DO IN EMERGENCIES HAZARD WARNING FLASHERS NOTE: With extended use the Hazard Warning flashers The Hazard Warning flasher switch is located in the may wear down your battery. center of the instrument panel between the center air IF YOUR ENGINE OVERHEATS outlets.
Page 395: Jacking And Tire Changing
WHAT TO DO IN EMERGENCIES 393 • You can also turn the temperature control to maximum WARNING! heat, the mode control to floor and the blower control to high. This allows the heater core to act as a You or others can be badly burned by hot engine supplement to the radiator and aids in removing heat coolant (antifreeze) or steam from your radiator.
Page 396: Jack Location/Spare Tire Stowage
394 WHAT TO DO IN EMERGENCIES Jack Location/Spare Tire Stowage WARNING! (Continued) The jack and spare tire are both stowed under an access • Being under a jacked-up vehicle is dangerous. The cover in the trunk. Follow these steps to access the jack vehicle could slip off the jack and fall on you.
Page 397 WHAT TO DO IN EMERGENCIES 395 Opening The Access Panel Spare Tire Fastener 3. Remove the fastener securing the spare tire. 4. Remove the spare tire. I n f o r m a t i o n P r o v i d e d b y :...
Page 398: Preparations For Jacking
396 WHAT TO DO IN EMERGENCIES 5. Remove the fastener securing the jack. WARNING! • A loose tire or jack thrown forward in a collision or hard stop could endanger the occupants of the vehicle. Always stow the jack parts and the spare tire in the places provided.
Page 399: Jacking And Changing A Tire
WHAT TO DO IN EMERGENCIES 397 NOTE: Passengers should not remain in the vehicle WARNING! when the vehicle is being jacked. Do not attempt to change a tire on the side of the Jacking and Changing a Tire vehicle close to moving traffic, pull far enough off the road to avoid being hit when operating the jack WARNING! or changing the wheel.
Page 400 398 WHAT TO DO IN EMERGENCIES WARNING! (Continued) CAUTION! • Never start or run the engine with the vehicle on a Do not attempt to raise the vehicle by jacking on jack. locations other than those indicated in the Jacking •...
Page 401 WHAT TO DO IN EMERGENCIES 399 3. Before raising the vehicle, use the lug wrench to loosen, but not remove, the lug nuts on the wheel with the flat tire. Turn the lug nuts counterclockwise one turn while the wheel is still on the ground. Center Cap Removal WARNING! To avoid possible personal injury, handle the wheel...
Page 402 400 WHAT TO DO IN EMERGENCIES 4. Place the jack underneath the lift area that is closest to the flat tire. Turn the jack screw clockwise to firmly engage the jack saddle with the lift area of the sill flange. Rear Jacking Location 5.
Page 403 WHAT TO DO IN EMERGENCIES 401 avoid the risk of forcing the vehicle off the jack, do not WARNING! tighten the lug nuts fully until the vehicle is lowered to the ground. Raising the vehicle higher than necessary can make the vehicle less stable.
Page 404: Compact Spare Tire
402 WHAT TO DO IN EMERGENCIES • Keep tire inflated to 60 psi (414 KPa) cold inflation 11. Stow the jack, tools and flat tire. Make sure the base of the jack faces the front of the vehicle before tightening pressure.
Page 405: Wheel Cover Or Center Cap Installation - If Equipped
WHAT TO DO IN EMERGENCIES 403 Wheel Cover or Center Cap Installation — If Equipped NOTE: Do not attempt to install a center cap or wheel cover on the compact spare. 1. Mount the road tire on the axle. For vehicles equipped with wheel covers, perform Steps 2 and 3.
Page 406: Jump-Starting Procedures
404 WHAT TO DO IN EMERGENCIES 3. Align the valve notch in the wheel cover with the 7. For vehicles equipped with center caps, install the valve stem on the wheel. Install the cover by hand, center cap by hand. Do not use a hammer or excessive snapping the cover over the two lug nuts.
Page 407: Preparations For Jump-Start
WHAT TO DO IN EMERGENCIES 405 pack. Jump-starting can be dangerous if done improperly Preparations For Jump-Start so please follow the procedures in this section carefully. The battery is stored under an access cover in the trunk. Remote battery posts are located on the right side of the NOTE: When using a portable battery booster pack engine compartment for jump-starting.
Page 408: Jump-Starting Procedure
406 WHAT TO DO IN EMERGENCIES 3. If using another vehicle to jump-start the battery, park WARNING! the vehicle within the jumper cables reach, set the • Take care to avoid the radiator cooling fan when- parking brake and make sure the ignition is OFF. ever the hood is raised.
Page 409 WHAT TO DO IN EMERGENCIES 407 CAUTION! WARNING! Failure to follow these procedures could result in Do not connect the cable to the negative post (-) of the damage to the charging system of the booster vehicle discharged battery. The resulting electrical spark or the discharged vehicle.
Page 410: Freeing A Stuck Vehicle
408 WHAT TO DO IN EMERGENCIES 8. Disconnect the positive (+) jumper cable from the FREEING A STUCK VEHICLE positive (+) post of the booster battery. If your vehicle becomes stuck in mud, sand, or snow, it can often be moved by a rocking motion. Turn your 9.
Page 411: Shift Lever Override
WHAT TO DO IN EMERGENCIES 409 NOTE: Turn off the Electronic Stability Program (ESP) WARNING! — if equipped, or Traction Control System (TCS) — if equipped before rocking the vehicle. Refer to “Electronic Fast spinning tires can be dangerous. Forces gener- Brake Control”...
Page 412 410 WHAT TO DO IN EMERGENCIES 2. Remove the rubber tray from the storage bin located to the right of the shift lever. The override access port is near the bottom of the bin to the right of the shift lever gate. 3.
Page 413: With Keyless Enter-N-Go - If Equipped
WHAT TO DO IN EMERGENCIES 411 With Keyless Enter-N-Go — If Equipped If the engine is running, press the START/STOP button to turn it off. Release the brake pedal and press the START/ STOP button once or twice to go to the ON/RUN position.
Page 414 412 WHAT TO DO IN EMERGENCIES Proper towing or lifting equipment is required to prevent CAUTION! damage to your vehicle. Use only tow bars and other • Do not use sling type equipment when towing. equipment designed for the purpose, following equip- ment manufacturer’s instructions.
Page 415: Without The Ignition Key
WHAT TO DO IN EMERGENCIES 413 The manufacturer does not recommend that you tow this CAUTION! vehicle on a tow dolly. Vehicle damage may occur. Failure to follow these towing methods can cause Flatbed towing is recommended. DO NOT tow an AWD severe transmission damage.
Page 416 I n f o r m a t i o n P r o v i d e d b y :...
Page 417: Maintaining Your Vehicle
MAINTAINING YOUR VEHICLE CONTENTS ▫ Engine Oil Filter ..... 426 Engine Compartment – 3.6L ....417 ▫...
Page 418 416 MAINTAINING YOUR VEHICLE ▫ Cooling System ..... 437 Bulb Replacement ..... 463 ▫...
Page 419: Engine Compartment - 3.6L
MAINTAINING YOUR VEHICLE 417 ENGINE COMPARTMENT – 3.6L 1 — Integrated Power Module (Fuses) 5 — Air Cleaner Filter 2 — Engine Oil Dipstick 6 — Engine Oil Fill 3 — Brake Fluid Reservoir Access Cover 7 — Remote Jump Start (Positive Battery Post) 4 —...
Page 420: Engine Compartment - 5.7L
418 MAINTAINING YOUR VEHICLE ENGINE COMPARTMENT — 5.7L 1 — Integrated Power Module (Fuses) 5 — Engine Oil Fill 2 — Brake Fluid Reservoir 6 — Engine Oil Dipstick 3 — Engine Coolant Reservoir 7 — Remote Jump Start (Positive Battery Post) 4 —...
Page 421: Onboard Diagnostic System - Obd Ii
MAINTAINING YOUR VEHICLE 419 ONBOARD DIAGNOSTIC SYSTEM — OBD II CAUTION! Your vehicle is equipped with a sophisticated onboard • Prolonged driving with the MIL on could cause diagnostic system called OBD II. This system monitors the performance of the emissions, engine, and automatic further damage to the emissions control system.
Page 422 420 MAINTAINING YOUR VEHICLE Indicator Light (MIL)” is functioning and is not on when 3. As soon as you turn the ignition switch to the ON the engine is running, and that the OBD II system is position, you will see the MIL symbol come on as part of ready for testing.
Page 423: Replacement Parts
MAINTAINING YOUR VEHICLE 421 you may need to do nothing more than drive your DEALER SERVICE vehicle as you normally would in order for your OBD II Your authorized dealer has the qualified service person- system to update. A recheck with the above test routine nel, special tools, and equipment to perform all service may then indicate that the system is now ready.
Page 424: Maintenance Procedures
Immediately have potential malfunctions Checking Oil Level – 3.6L Engine examined by an authorized Chrysler Group LLC To assure proper engine lubrication, the engine oil must dealership or qualified repair center. be maintained at the correct level. Check the oil level at...
Page 425 MAINTAINING YOUR VEHICLE 423 regular intervals, such as every fuel stop. The best time to Checking Oil Level – 5.7L Engine check the engine oil level is about five minutes after a To assure proper engine lubrication, the engine oil must fully warmed engine is shut off.
Page 426 API Certified and meet Do not use chemical flushes in your engine oil as the the requirements of Chrysler Material Standard MS-6395. chemicals can damage your engine. Such damage is not covered by the New Vehicle Limited Warranty.
Page 427 MAINTAINING YOUR VEHICLE 425 Engine Oil Viscosity (SAE Grade) – 3.6L Engine engine oil filler cap location, refer to “Engine Compart- SAE 5W-30 engine oil is recommended for all operating ment” in “Maintaining Your Vehicle” for further informa- temperatures. tion. The engine oil filler cap also shows the recommended NOTE: Vehicles equipped with a 5.7L engine must use engine oil viscosity for your engine.
Page 428: Engine Oil Filter
426 MAINTAINING YOUR VEHICLE Materials Added to Engine Oil Engine Oil Filter Do not add any supplemental materials, other than leak The engine oil filter should be replaced with a new filter detection dyes, to the engine oil. Engine oil is an engi- at every engine oil change.
Page 429 MAINTAINING YOUR VEHICLE 427 Engine Air Cleaner Filter Selection WARNING! The quality of replacement engine air cleaner filters varies considerably. Only high quality filters should be The air induction system (air cleaner, hoses, etc.) can used to assure most efficient service. MOPAR engine air provide a measure of protection in the case of engine cleaner filters are a high quality filter and are backfire.
Page 430: Maintenance-Free Battery
428 MAINTAINING YOUR VEHICLE Maintenance-Free Battery Your vehicle is equipped with a maintenance-free battery. You will never have to add water, nor is periodic main- tenance required. NOTE: The battery is stored under an access cover in the trunk. Remote battery terminals are located in the engine compartment for jump starting.
Page 431 MAINTAINING YOUR VEHICLE 429 WARNING! WARNING! (Continued) • The battery in this vehicle has a vent hose that • Battery fluid is a corrosive acid solution and can should not be disconnected and should only be burn or even blind you. Do not allow battery fluid replaced with a battery of the same type (vented).
Page 432: Air Conditioner Maintenance
430 MAINTAINING YOUR VEHICLE Air Conditioner Maintenance WARNING! For best possible performance, your air conditioner • Use only refrigerants and compressor lubricants should be checked and serviced by an authorized dealer at the start of each warm season. This service should approved by the manufacturer for your air condi- include cleaning of the condenser fins and a performance tioning system.
Page 433: A/C Air Filter
MAINTAINING YOUR VEHICLE 431 Refrigerant Recovery and Recycling 1. Remove the access door in the cowl screen by pressing R-134a Air Conditioning Refrigerant is a hydrofluoro- the retaining clips. carbon (HFC) that is endorsed by the Environmental Protection Agency and is an ozone-saving product. How- ever, the manufacturer recommends that air conditioning service be performed by authorized dealers or other service facilities using recovery and recycling equipment.
Page 434 432 MAINTAINING YOUR VEHICLE 2. Slide the lid on the filter adapter forward and down and remove the used filter. A/C Air Filter Refer to the “Maintenance Schedule” for the proper maintenance intervals. 3. Install the new filter with arrows pointing in the direction of airflow, which is toward the rear of the vehicle (text and arrows on the filter will indicate this).
Page 435: Body Lubrication
MAINTAINING YOUR VEHICLE 433 Body Lubrication amount of a high quality lubricant, such as MOPAR Locks and all body pivot points, including such items as Lock Cylinder Lubricant or equivalent directly into the seat tracks, door hinge pivot points and rollers, liftgate, lock cylinder.
Page 436: Adding Washer Fluid
434 MAINTAINING YOUR VEHICLE performance of blades may be present with chattering, exceeds the temperature range of your climate. This marks, water lines or wet spots. If any of these conditions rating information can be found on most washer fluid are present, clean the wiper blades or replace as containers.
Page 437 MAINTAINING YOUR VEHICLE 435 If you notice a change in the sound of the exhaust system; WARNING! or if the exhaust fumes can be detected inside the vehicle; • Exhaust gases can injure or kill. They contain or when the underside or rear of the vehicle is damaged; have an authorized technician inspect the complete ex- carbon monoxide (CO), which is colorless and haust system and adjacent body areas for broken, dam-...
Page 438 436 MAINTAINING YOUR VEHICLE Under normal operating conditions, the catalytic con- CAUTION! verter will not require maintenance. However, it is im- • The catalytic converter requires the use of un- portant to keep the engine properly tuned to assure proper catalyst operation and prevent possible catalyst leaded fuel only.
Page 439: Cooling System
MAINTAINING YOUR VEHICLE 437 To minimize the possibility of catalytic converter dam- Cooling System age: WARNING! • Do not shut off the engine or interrupt the ignition, • When working near the radiator cooling fan, dis- when the transmission is in gear and the vehicle is in motion.
Page 440 438 MAINTAINING YOUR VEHICLE Coolant Checks If the cap is sealing properly, the engine coolant (anti- Check engine coolant (antifreeze) protection every freeze) will begin to drain from the coolant recovery 12 months (before the onset of freezing weather, where bottle.
Page 441 MAINTAINING YOUR VEHICLE 439 CAUTION! CAUTION! (Continued) • This vehicle has not been designed for use with • Mixing of engine coolant (antifreeze) other than propylene glycol-based engine coolant (anti- specified HOAT engine coolant (antifreeze), may freeze). Use of propylene glycol-based engine result in engine damage and may decrease corro- coolant (antifreeze) is not recommended.
Page 442 440 MAINTAINING YOUR VEHICLE Please review these recommendations for using Hybrid Please note that it is the owner’s responsibility to main- Organic Additive Technology (HOAT) engine coolant tain the proper level of protection against freezing ac- (antifreeze). When adding engine coolant (antifreeze): cording to the temperatures occurring in the area where the vehicle is operated.
Page 443 MAINTAINING YOUR VEHICLE 441 rules for your community. To prevent ingestion by ani- WARNING! mals or children, do not store ethylene glycol-based • The warning words “DO NOT OPEN HOT” on engine coolant (antifreeze) in open containers or allow it to remain in puddles on the ground.
Page 444 442 MAINTAINING YOUR VEHICLE When additional engine coolant (antifreeze) is needed to coolant (antifreeze) needs to be added, contents of maintain the proper level, it should be added to the coolant recovery bottle must also be protected against coolant bottle. Do not overfill. freezing.
Page 445: Brake System
MAINTAINING YOUR VEHICLE 443 • Do not change the thermostat for Summer or Winter Master Cylinder – Brake Fluid Level Check operation. If replacement is ever necessary, install Check the fluid level in the master cylinder immediately ONLY the correct type thermostat. Other designs may if the brake system warning light indicates system fail- result in unsatisfactory coolant performance, poor gas ure.
Page 446 444 MAINTAINING YOUR VEHICLE Use only manufacturer’s recommended brake fluid. Re- WARNING! (Continued) fer to “Fluids, Lubricants, and Genuine Parts” in “Main- • To avoid contamination from foreign matter or taining Your Vehicle” for further information. moisture, use only new brake fluid or fluid that has been in a tightly closed container.
Page 447: Automatic Transmission
MAINTAINING YOUR VEHICLE 445 fluid. No chemical flushes should be used in any trans- WARNING! (Continued) mission; only the approved lubricant may be used. • Do not allow petroleum based fluid to contami- Special Additives nate the brake fluid. Brake seal components could Automatic Transmission Fluid (ATF) is an engineered be damaged, causing partial or complete brake product and its performance may be impaired by supple-...
Page 448 446 MAINTAINING YOUR VEHICLE Fluid Level Check CAUTION! (Continued) Regular automatic transmission fluid level checks are not • The fluid level is preset at the factory and it does required. For this reason, the dipstick is omitted. not require adjustment under normal operating If you notice fluid loss or transmission malfunction, have conditions.
Page 449: All Wheel Drive (Awd) - If Equipped
MAINTAINING YOUR VEHICLE 447 All Wheel Drive (AWD) – If Equipped Rear Axle The all wheel drive system consists of a transfer case and For normal service, periodic fluid level checks are not front differential. The exterior surface of these compo- required.
Page 450: Appearance Care And Protection From Corrosion
448 MAINTAINING YOUR VEHICLE Appearance Care and Protection from Corrosion The most common causes are: • Road salt, dirt, and moisture accumulation. Protection of Body and Paint from Corrosion Vehicle body care requirements vary according to geo- • Stone and gravel impact. graphic locations and usage.
Page 451 MAINTAINING YOUR VEHICLE 449 • Use a high quality cleaner wax, such as MOPAR Special Care Cleaner Wax or equivalent to remove road film, stains • If you drive on salted or dusty roads or if you drive and to protect your paint finish. Take care never to near the ocean, hose off the undercarriage at least once scratch the paint.
Page 452 450 MAINTAINING YOUR VEHICLE • If you carry special cargo such as chemicals, fertilizers, Stain Repel Fabric Cleaning Procedure – If de-icer salt, etc., be sure that such materials are well Equipped packaged and sealed. Stain Repel seats may be cleaned in the following man- •...
Page 453 MAINTAINING YOUR VEHICLE 451 Interior Care solvents, detergents, or ammonia-based cleaners to clean Use MOPAR Fabric Cleaner or equivalent to clean fabric your leather upholstery. Application of a leather condi- upholstery and MOPAR Carpet Cleaner or equivalent tioner is not required to maintain the original condition. for carpeting.
Page 454 452 MAINTAINING YOUR VEHICLE Do not use abrasive cleaning components, solvents, steel 1. Clean with a wet soft rag or micro-fiber towel. A mild wool or other aggressive material to clean the lenses. soap solution may be used, but do not use high alcohol content or abrasive cleaners.
Page 455: Fuses
MAINTAINING YOUR VEHICLE 453 Cleaning the Center Console Cupholders Clean with a damp cloth or towel using a mild detergent with the cupholder in the center console. NOTE: The cupholder cannot be removed. FUSES Integrated Power Module The Integrated Power Module is located in the engine compartment.
Page 456 454 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description CAUTION! tridge Fuse • When installing the integrated power module Fuse cover, it is important to ensure the cover is prop- — — Fuse – Spare erly positioned and fully latched. Failure to do so 40 Amp —...
Page 457 MAINTAINING YOUR VEHICLE 455 Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 10 Amp Security 50 Amp — Power Steering #2 — 20 Amp Horns 30 Amp — Wiper Motor Yellow Pink — 10 Amp Air Conditioning Clutch 30 Amp...
Page 458 456 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 25 Amp Engine Module — 10 Amp Power Steering Natural Module/AC Clutch Re- — — Fuse – Spare — 10 Amp AWD Module/Front —...
Page 459: Rear Power Distribution Center
MAINTAINING YOUR VEHICLE 457 Rear Power Distribution Center There is also a power distribution center located in the trunk under the spare tire access panel. This center contains fuses and relays. Rear Power Distribution Center Opening The Access Panel I n f o r m a t i o n P r o v i d e d b y :...
Page 460 458 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description CAUTION! tridge Fuse • When installing the power distribution center Fuse cover, it is important to ensure the cover is prop- 60 Amp — Front PDC Feed #1 erly positioned and fully latched. Failure to do so Yellow may allow water to get into the power distribution —...
Page 461 MAINTAINING YOUR VEHICLE 459 Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse 30 Amp — Driver Door — — Fuse — Spare Pink — 10 Amp Fuel Door/Diagnostic 30 Amp — Passenger Door Port Pink —...
Page 462 460 MAINTAINING YOUR VEHICLE Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 15 Amp Ignition Switch/Wireless — 25 Amp Rear Heated Seats/ Blue Module Natural Steering Wheel — 10 Amp Steering Column — 10 Amp Park Assist/Blind Spot/ Module/Clock...
Page 463 MAINTAINING YOUR VEHICLE 461 Cavity Car- Mini- Description Cavity Car- Mini- Description tridge Fuse tridge Fuse Fuse Fuse — 20 Amp Front Heated Seats — — Fuse — Spare Yellow — — Fuse — Spare — 10 Amp Heated Cupholders/ —...
Page 464: Vehicle Storage
462 MAINTAINING YOUR VEHICLE VEHICLE STORAGE REPLACEMENT BULBS If you are leaving your vehicle dormant for more than 21 days, you may want to take these steps to protect your Interior Bulb Number battery. Rear Courtesy/Reading Lamps ... . . W5W Rear Compartment (Trunk) Lamp .
Page 465: Bulb Replacement
MAINTAINING YOUR VEHICLE 463 Exterior Bulb Number Center High Mount Stop Lamp (CHMSL)..LED (Serviced at Authorized Dealer) Low Beam/High Beam (Bi-Halogen Headlamp) ....HIR2LL License .
Page 466 464 MAINTAINING YOUR VEHICLE Standard Low Beam Headlamp, High Beam WARNING! Headlamp, Park/Turn Lamp, Inner Park Lamp, and Outer Park Lamp A transient high tension occurs at the bulb sockets of HID headlamps when the headlamp switch is turned 1. Open the hood. ON.
Page 467 MAINTAINING YOUR VEHICLE 465 1 — High Beam Headlamp Bulb 3 — Park/Turn Lamp Bulb 2 — Low Beam Headlamp Bulb I n f o r m a t i o n P r o v i d e d b y :...
Page 468 466 MAINTAINING YOUR VEHICLE CAUTION! Do not touch the new bulb with your fingers. Oil contamination will severely shorten bulb life. If the bulb comes in contact with an oily surface, clean the bulb with rubbing alcohol. 4 — Inner Park Lamp Bulb 5 —...
Page 469: Rear Backup Lamp And Turn Signal Lamps
MAINTAINING YOUR VEHICLE 467 Rear Backup Lamp and Turn Signal Lamps 7. Disconnect the electrical connector. 1. Open the trunk. 8. Continue removing lamp from vehicle in order to access the bulb(s). 2. Remove the trunk trim by removing the grocery hook (using a T-20 torque driver or similar tool), remove the 9.
Page 470: License Lamp
468 MAINTAINING YOUR VEHICLE License Lamp 4. Reinstall the bulb and socket assembly. 1. Remove the screws securing the lamp to the rear fascia. 5. Reattach the lamp to the rear fascia, and then install 2. Remove the bulb and socket assembly. the screws.
Page 471: Fluid Capacities
MAINTAINING YOUR VEHICLE 469 FLUID CAPACITIES U.S. Metric Fuel (Approximate) All Engines 19 Gallons 72 Liters Engine Oil with Filter 3.6 Liter Engine (SAE 5W-30, API Certified) 6 Quarts 5.6 Liters 5.7 Liter Engine (SAE 5W-20, API Certified) 7 Quarts 6.6 Liters Cooling System * 3.6 Liter Engine without All Wheel Drive (MOPAR Antifreeze/...
Page 472: Fluids, Lubricants, And Genuine Parts
Organic Additive Technology) or equivalent. Engine Oil – 3.6L Engine Use API Certified SAE 5W-30 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395. Refer to the engine oil fill cap for correct SAE grade. Engine Oil – 5.7L Engine Use API Certified SAE 5W-20 Engine Oil, meeting the requirements of Chrysler Material Standard MS-6395.
Page 473: Chassis
MAINTAINING YOUR VEHICLE 471 Chassis Component Fluid, Lubricant, or Genuine Part Automatic Transmission MOPAR ATF+4 Automatic Transmission Fluid or equivalent licensed ATF+4 product. Brake Master Cylinder MOPAR DOT 3 and SAE J1703 should be used or equivalent. If DOT 3 brake fluid is not available, then DOT 4 is acceptable.
Page 474 I n f o r m a t i o n P r o v i d e d b y :...
Page 475: Maintenance Schedules
MAINTENANCE SCHEDULES CONTENTS ▫ Required Maintenance Intervals ..476 Maintenance Schedule ....474 I n f o r m a t i o n P r o v i d e d b y :...
Page 476 474 MAINTENANCE SCHEDULES MAINTENANCE SCHEDULE Based on engine operation conditions, the oil change The Scheduled Maintenance services listed in this indicator message will illuminate. This means that ser- manual must be done at the times or mileages specified vice is required for your vehicle. Have your vehicle to protect your vehicle warranty and ensure the best serviced as soon as possible, within the next 500 miles vehicle performance and reliability.
Page 477 MAINTENANCE SCHEDULES 475 Your authorized dealer will reset the oil change indicator At Each Stop for Fuel message after completing the scheduled oil change. If a • Check the engine oil level. Refer to “Maintenance scheduled oil change is performed by someone other Procedures/Engine Oil”...
Page 478 476 MAINTENANCE SCHEDULES At Each Oil Change Required Maintenance Intervals Refer to the Maintenance Schedules on the following • Change the engine oil filter. pages for the required maintenance intervals. • Inspect the brake hoses and lines. CAUTION! Failure to perform the required maintenance items may result in damage to the vehicle.
Page 479 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 480: Service Schedule
Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 481 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 482 56,000 miles (91 000 km). Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 483 ❏ Inspect the front suspension, tie rod ends and boot seals for cracks or leaks and all parts for damage, wear, improper looseness or end play; replace if necessary. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 484 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 485 88,000 miles (143 000 km). Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 486 ❏ Inspect the rear axle fluid. Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 487 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 488 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 489 Repair Order # Dealer Code Repair Order # Dealer Code Signature Authorized Chrysler Dealer Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 490 152,000 miles (247 000 km). Odometer Reading Date Repair Order # Dealer Code Signature Authorized Chrysler Dealer I n f o r m a t i o n P r o v i d e d b y :...
Page 491 MAINTENANCE SCHEDULES 489 † This maintenance is recommended by the manufacturer to the owner, but is not required to maintain emissions warranty. WARNING! • You can be badly injured working on or around a motor vehicle. Do only service work for which you have the knowledge and the right equipment.
Page 492 I n f o r m a t i o n P r o v i d e d b y :...
Page 493: If You Need Consumer Assistance
Reporting Safety Defects ....496 ▫ Chrysler Group LLC Customer Center ..494 ▫ In The 50 United States And Washington, D.C.
Page 494 492 IF YOU NEED CONSUMER ASSISTANCE ▫ Traction Grades ..... 499 Department Of Transportation Uniform Tire Quality Grades ......499 ▫...
Page 495: Suggestions For Obtaining Service For Your Vehicle
IF YOU NEED CONSUMER ASSISTANCE 493 SUGGESTIONS FOR OBTAINING SERVICE FOR the service advisor and list the items in order of priority. YOUR VEHICLE At many authorized dealers, you may obtain a rental vehicle at a minimal daily charge. If you need a rental, it Prepare For The Appointment is advisable to make these arrangements when you call If you’re having warranty work done, be sure to have the...
Page 496: Chrysler Group Llc Customer Center
494 IF YOU NEED CONSUMER ASSISTANCE This is why you should always talk to an authorized Chrysler Group LLC Customer Center dealer’s service manager first. Most matters can be re- P.O. Box 21–8004 solved with this process. Auburn Hills, MI 48321–8004 Phone: (800) 247–9753...
Page 497: Customer Assistance For The Hearing Or Speech Impaired (Tdd/Tty)
IF YOU NEED CONSUMER ASSISTANCE 495 Customer Assistance For The Hearing Or Speech the manufacturer’s service contracts. If you purchased a Impaired (TDD/TTY) manufacturer’s service contract, you will receive Plan To assist customers who have hearing difficulties, the Provisions and an Owner Identification Card in the mail manufacturer has installed special TDD (Telecommuni- within three weeks of the vehicle delivery date.
Page 498: Warranty Information
See the Warranty Information Booklet, located on the has also made a major investment in facilities, tools, and DVD, for the terms and provisions of Chrysler Group training to assure that you are absolutely delighted with LLC warranties applicable to this vehicle and market.
Page 499: In Canada
If you believe that your vehicle has a safety defect, you need in diagnosing/troubleshooting, problem solving, should contact the Customer Service Department immedi- maintaining, servicing, and repairing Chrysler Group ately. Canadian customers who wish to report a safety defect LLC vehicles. A complete working knowledge of the...
Page 500 • Diagnostic Procedure Manuals acquaint you with specific Chrysler Group LLC ve- hicles. Included are starting, operating, emergency Diagnostic Procedure Manuals are filled with dia- and maintenance procedures as well as specifications, grams, charts and detailed illustrations.
Page 501 IF YOU NEED CONSUMER ASSISTANCE 499 DEPARTMENT OF TRANSPORTATION UNIFORM significantly from the norm due to variations in driving TIRE QUALITY GRADES habits, service practices, and differences in road charac- The following tire grading categories were established by teristics and climate. the National Highway Traffic Safety Administration.
Page 502 500 IF YOU NEED CONSUMER ASSISTANCE Temperature Grades WARNING! The temperature grades are A (the highest), B, and C, representing the tire’s resistance to the generation of heat The temperature grade for this tire is established for and its ability to dissipate heat, when tested under a tire that is properly inflated and not overloaded.
Page 503 INDEX I n f o r m a t i o n P r o v i d e d b y :...
Page 504 502 INDEX About Your Brakes ..... . . 323 Airbag, Window (Side Curtain) ... 59,61,64 ABS (Anti-Lock Brake System) .
Page 505 INDEX 503 Automatic Headlights ....157 B-Pillar Location ......338 Automatic Oil Change Indicator .
Page 506 504 INDEX Brightness, Interior Lights ....163 Checking Your Vehicle For Safety ... . . 80 Bulb Replacement .
Page 507 INDEX 505 Conserving Fuel ......264 Customer Assistance ..... 493 Console, Floor .
Page 508 506 INDEX Door Locks ......27 Electronic Stability Control (ESC) ... . . 329 Door Locks, Automatic .
Page 509 INDEX 507 Compartment Identification ....417 Engine Oil Viscosity ..... . 425 Coolant (Antifreeze) .
Page 510 508 INDEX Flashers Engine Oil ......422,423 Hazard Warning ..... . . 392 Transfer Case .
Page 511 INDEX 509 Methanol ......366 Tachometer ......245 Octane Rating .
Page 512 510 INDEX Bulb Replacement ..... . 463 Hood Release ......154 Cleaning .
Page 513 INDEX 511 Jack Operation ......397 LATCH (Lower Anchors and Tether for Jacking Instructions ..... . 397 CHildren) .
Page 514 512 INDEX Dimmer Switch, Headlight ... . . 160,161 Malfunction Indicator (Check Engine) ..248 Electronic Stability Program (ESP) Indicator . . . 331 Map Reading .
Page 515 INDEX 513 Tires ....... 338 Manual, Service ......497 Locks .
Page 516 514 INDEX Monitor, Tire Pressure System ....355 Change Interval ....263,424 MOPAR Accessories .
Page 517 INDEX 515 Paint Care ......448 Power Steering Fluid ..... 471 Panic Alarm .
Page 518 516 INDEX Recorder, Event Data ..... . 68 Restraint, Head ......145 Recreational Towing .
Page 519 INDEX 517 Extender ......54 Selection of Coolant (Antifreeze) ..438,470 Front Seat .
Page 520 518 INDEX Slippery Surfaces, Driving On ....318 Starting Procedures ..... . 304 SmartBeams .
Page 521 INDEX 519 Synthetic Engine Oil ..... . 425 Chains ......351 System, Remote Starting .
Page 522 520 INDEX Spare Tire ......394 Trailer and Tongue Weight ....383 Spinning .
Page 523 INDEX 521 Tread Wear Indicators ....349 Vehicle Theft Alarm (Security Alarm) ..17 Trip Odometer .
Page 524 522 INDEX Power ....... 36 Windshield Wipers ..... . . 164 Windshield Defroster .
Page 525 INSTALLATION OF RADIO TRANSMITTING EQUIPMENT Special design considerations are incorporated into this The antenna cable should be as short as practical and vehicle’s electronic system to provide immunity to radio routed away from the vehicle wiring when possible. Use frequency signals. Mobile two-way radios and telephone only fully shielded coaxial cable.
Page 526 Chrysler Group LLC 11C481-126-AA First Edition Printed in U.S.A. I n f o r ma t i o n P r o v i d e d b y :...

Chrysler 300 2011 Owner's Manual

Table of Contents

Things to Know before Starting Your Vehicle

Understanding the Features of Your Vehicle

Understanding Your Instrument Panel

Starting and Operating

Quick Links

Chapters

Related Manuals for Chrysler 300 2011

Summary of Contents for Chrysler 300 2011
