Control 47C/T:
Frequency Range (-10 dB)
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Nominal Coverage Angle
Directivity Factor (Q)
Directivity Index (DI)
Rated Maximum SPL: 110 dB @ 1 m (3.3 ft) average, 116 dB peak
Rated Impedance: 8 Ω (in bypass mode)
Transformer Taps: 60W 30W, 15W, (& 7.5W @ 70V)
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency:
Dimensions: Ø 305 mm (12.0 in) diameter x 359 mm (10.2 in) mounting depth
Cutout Size: 282 mm (11.1 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Net Weight: 5 kg (11 lbs)
Included Accessories: Press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
Control 47LP:
Frequency Range (-10 dB)
Frequency Response (± 3 dB)
Power Capacity
Nominal Sensitivity (2.83V/1m)
Nominal Coverage Angle
Directivity Factor (Q)
Directivity Index (DI)
Rated Maximum SPL: 110 dB @ 1 m (3.3 ft) average, 116 dB peak
Rated Impedance: 8 Ω (in bypass mode)
Transformer Taps: 60W 30W,
Input Connectors: Two removeable locking 2-pin connectors with screw-down terminals.
Knockouts: Two (top and side)
Safety Agency: Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
Dimensions: Ø 305 mm (12.0 in)
Cutout Size: 282 mm (11.1 in)
Ceiling Thickness Range: Accommodates tiles / drywall up
Net Weight: 4.3 kg (9.5 lbs)
Included Accessories:

8 JBL Professional Control Contractor 40 Series

SPECIFICATIONS

1
: 55 Hz - 20 kHz
1
: 75 Hz - 17 kHz
2
: 150 Watts Continuous Program Power
75 Watts Continuous Pink Noise
1
: 91 dB
3
: 120° conical coverage
3
: 6.5
3
: 7.9dB
LF Driver: 165mm (6.5 in) with polypropylene cone, butyl rubber surround,
copper-clad coil, vented aluminum former.
HF Driver: 25mm (1 in) soft dome w/ dampening, ferrofluid-cooled.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
Suitable for use in air handling spaces per UL1480, UL2043, CUL, NFPA90, NFPA70A, and in
accordance with the requirements of IEC60849/EN60849
cutout template, paint shield
1
: 68 Hz - 20 kHz
1
: 100 Hz - 17 kHz
2
: 150 Watts Continuous Program Power
75 Watts Continuous Pink Noise
1
: 91 dB
3
: 120° conical coverage
3
: 6.7
3
: 7.9dB
15W, (& 7.5W @ 70V)
LF Driver: 165mm (6.5 in) with polypropylene cone, butyl rubber surround,
copper-clad coil, vented aluminum former.
HF Driver: 25mm (1 in) soft dome w/ dampening, ferrofluid-cooled.
Max wire 12 AWG (2.5 mm). Key: 1) + in, 2) - in, A) + loop thru, B) - loop thru
accordance with the requirements of IEC60849/EN60849
diameter
Press-in grille, C-ring support backing plate, 2 tile support rails, knockout strain relief,
cutout template, paint shield
to 70 mm (2.75 inches) thick
x 142 mm (5.6 in) mounting depth
to 70 mm (2.75 inches) thick
