How to replace or upgrade memory in Dell Latitude D830
notebook
In this post I explain how to replace or upgrade memory (aka RAM) in a Dell Latitude D830 notebook. Also, these instructions should work
for a Dell Latitude D820 notebooks and maybe some other models. Please mention you notebook model in the comments if this guide
works for you.
You can check the amount of installed memory in the BIOS setup menu. As you see, in my laptop I have 1024MB (or 1GB) memory
installed.
Dell Latitude D830 notebook requires DDR2 memory modules. You should use
can use same memory type for a Latitude D820 notebook too.
Dell Latitude D820/D830 can take up to 4GB memory total. You can install up to 2GB memory in each slot (there are two slots available).
http://www.insidemylaptop.com/replace-upgrade-memory-ram-in-dell-latitude-d830-notebook/
Ads by Google
PC2-5300 SODIMM memory
Page 1 of 15
which runs at 667MHz.You
4/6/2011
Advertisement
Related Manuals for Dell Latitude D830
Summary of Contents for Dell Latitude D830
- Page 1 In this post I explain how to replace or upgrade memory (aka RAM) in a Dell Latitude D830 notebook. Also, these instructions should work for a Dell Latitude D820 notebooks and maybe some other models. Please mention you notebook model in the comments if this guide works for you.
- Page 2 How to replace or upgrade memory in Dell Latitude D830 notebook >> Inside my laptop Page 2 of 15 Crucial Memory Upgrades www.Crucial.com Find The Right RAM Memory Using Our Advisor Tool. Order Today Free S&H! 4gb pc5300 ddr2 sodimm …...
- Page 3 How to replace or upgrade memory in Dell Latitude D830 notebook >> Inside my laptop Page 3 of 15 Before you start, please turn off the laptop, unplug the AC power adapter and remove the battery. STEP 1. Lift up one side of the keyboard cover with a small flat head screwdriver.
- Page 4 How to replace or upgrade memory in Dell Latitude D830 notebook >> Inside my laptop Page 4 of 15 STEP 4. Lift up the keyboard and placed it on the display panel or palm rest, so you can access the memory slot A. Be careful, the keyboard is attached to the motherboard via a flat ribbon cable.
- Page 5 How to replace or upgrade memory in Dell Latitude D830 notebook >> Inside my laptop Page 5 of 15 The memory module will pop up at a 30 degree angle. Pull the memory module from the slot A by the edges.
- Page 6 How to replace or upgrade memory in Dell Latitude D830 notebook >> Inside my laptop Page 6 of 15 The slot DIMM A is empty and you can install a new RAM module in there. In this notebook memory can run in dual-channel mode which doubles the amount of available memory bandwidth and improves the notebook performance.
- Page 7 March 11th, 2011 at 8:22 am oocand, Buenos días, tengo una Latitude D830 y no prende la fuente esta buena, estoy sospechando que es el teclado, quisiera saber si hay alguna manera de prender en computador sin el teclado usando un puente o jumper? There is no jumper.
- Page 8 December 8th, 2010 at 12:26 pm Hi, i have dell lat 820 with 1 gb ram, now i just wanna upgrade to 2 gb. Tell me should i install another 1 gb ram in slot b or should i remove 1 gb and install a 2 gb ram in one slot, which way is better as far as performance and speed?
- Page 9 I used to upgrade my wife’s RAM and install a Dell bluetooth chip. BUT my wife’s Dell Latitude D830 is overheating like crazy and it’s probably dust. QUESTION – how do I open the laptop enough to get to the dust? Is there a picture guide for opening ALL THE WAY??? Please also see http://en.community.dell.com/support-forums/laptop/f/3518/p/19310897/19761306.aspx#19761306...
- Page 10 Dell latitude since a year , weeks ago half screen looks dark er than the other half which is much bright, this is if you were near the screen, but if you were far a little, you can see the screen half black and half bright, verticaly ,...
- Page 11 I have Dell precision M65 workstation mobile. I installed 2×2gb ddr2 PC2-6400 (800), but only I can see 3.25GB to 667, but DELL have 800Mhz RAM for M65. Why this problem whit the memory speed?? According to the specifications, your Dell Precision M65 laptop has 667MHz front side bus. Even if you install faster memory modules (800MHz in your case), they will run at 667MHz.
- Page 12 I have 2 gig (667MHZ) in my machine now. I opened up the back and discovered that the DIMM B slot is empty which would mean that I have one 2 gig DIMM in the DIMM A slot… when I ordered new memory from DELL they sent me two 2 gig (800MHz) DIMMs and it appears that the 667MHz DIMMs are not longer available.
- Page 13 December 25th, 2009 at 11:41 am Memory upgrade for my D830. Presently has matching 512gb chips. Want to increase performance and baught single Dell 2GB stick 9PC2-5300 SODIMM). If I remove one of the 512 sticks (slot B) and replace with the 2GB stick you indicate it will not run as dual- channel.
-
