Page 1 Model No. Please read these instructions carefully before using this product, and save this manual for future use. Message Display P331 Troubleshooting P344 Finding the information you need Contents Menu list P335 Register online at www.panasonic.com/register SQW0047 (U.S. customers only) F0914CT0...
Page 2: Finding The Information You Need
Finding the information you need In this “Owner’s Manual for advanced features”, you can find the information you need from the following pages.  By clicking a page number, you can jump to the linked page and quickly find the information.
Page 3: How To Use This Manual
How to use this manual About the indication of the applicable mode Applicable modes: The icons indicate the modes available for a function. • Black icons: Applicable modes • Gray icons: Unavailable modes will differ depending on the Recording Modes registered under custom settings. •...
Page 4: Quick Start Guide
Quick Start Guide If you want to start taking pictures now, refer to the steps for using the Intelligent Auto Mode as a guide. In Intelligent Auto Mode, you can leave the settings to the camera and take pictures easily. ...
Page 5 [When the interchangeable lens (H-FS12032/ H-FS35100) is used] Extend the lens barrel. (P39) Format the card (initialization). (P29) Set the mode dial to [¦]. (P42) • The settings of the main functions are adjusted automatically. Press the shutter button halfway to focus. A Focus indication •...
Page 6: Table Of Contents
Contents Finding the information you need................2 How to use this manual.....................3 Quick Start Guide ......................4 1. Before Use Care of the camera ....................12 Standard Accessories .....................13 Names and Functions of Components..............14 About the Lens......................17 Cards Compatible with this unit................19 2. Getting Started/Basic Operations Attaching the Shoulder Strap ..................20 Charging the Battery ....................21 •...
Page 7 3. Recording Modes Taking Pictures using the Automatic Function (Intelligent Auto Mode) ....75 • Recording night scenes ([iHandheld Night Shot]) ..........79 • Combining pictures into a single picture with rich gradation ([iHDR]).....80 • Taking a picture with a blurred background (Defocus Control).......81 •...
Page 8 • Selecting the Auto Focus Mode ..............141 • Setting up position of the AF area/changing size of the AF area ....145 • Setting the AF area position with the Touch Pad..........148 • Optimizing the focus and brightness for a touched position ......149 •...
Page 9 9. Recording Motion Pictures Recording Motion Picture..................214 • Setting the format, size and recording frame rate ........217 • How to set focus when recording a motion picture ([Continuous AF]) ..219 Recording still pictures while recording motion pictures ........220 Recording Snap Movies ..................221 Using the [Motion Picture] Menu ................224 •...
Page 10 • [Print Set]......................252 • [Protect] ......................254 • [Face Rec Edit] .....................255 • [Picture Sort]....................255 • [Delete Confirmation]..................256 11. Using the Wi-Fi function Wi-Fi function ......................257 What you can do with the Wi-Fi function...............260 Controlling with a Smartphone/Tablet ..............261 • Installing the smartphone/tablet app “Image App” ........261 •...
Page 11 Printing the Pictures ....................318 13. Others Optional accessories.....................324 Monitor Display/Viewfinder Display...............326 Message Display....................331 Menu list........................335 • [Rec] ......................335 • [Motion Picture] ....................338 • [Custom] .......................339 • [Setup] ......................341 • [Playback] .....................343 Troubleshooting ....................344 Cautions for Use ....................358...
Page 12: Before Use
Before Use Care of the camera Do not subject to strong vibration, shock, or pressure. • The lens, monitor, or external case may be damaged if used in the following conditions. It may also malfunction or image may not be recorded if you: –...
Page 13: Standard Accessories
1. Before Use Standard Accessories Check that all the accessories are supplied before using the camera. • The accessories and their shape will differ depending on the country or area where the camera was purchased. For details on the accessories, refer to “Basic Owner’s Manual”. •...
Page 14: Names And Functions Of Components
1. Before Use Names and Functions of Components Camera body ∫ 14 15 16 17 Status indicator (P36)/ Mode dial (P42) ® Wi-Fi connection lamp (P258) • Shutter button (P40) The lamp lights green when the camera is turned on, and lights blue when it is Camera ON/OFF switch (P36) connected to Wi-Fi.
Page 15 (P325) Rear dial (P43) • When using an AC adaptor, ensure that the Motion picture button (P214) Panasonic DC coupler (optional) and AC adaptor (optional) are used. [HDMI] socket (P308) Release lever (P27) [AV OUT/DIGITAL] socket (P309, 315, 317, 318)
Page 16 1. Before Use Lens ∫ H-FS12032 Lens surface Tele Zoom ring (P197) Wide Contact point Lens fitting mark (P33) Focus ring (P153) Decoration ring • Remove this cover when using the lens hood. Aperture ring H-FS35100 • Rotate this to adjust the aperture value. •...
Page 17: About The Lens
(P202) For details on the lens used, refer to the website. Refer to catalogs/Web pages for most current information regarding compatible lenses. http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.) • The available flash range etc. differs depending on the aperture value of the lens you are using.
Page 18 • To view the latest information on the firmware or to download the firmware, visit the support site below: http://panasonic.jp/support/global/cs/dsc/ (This Site is English only.) • To check the firmware version of the interchangeable lens, attach it to the camera body and...
Page 19: Cards Compatible With This Unit
(8 MB to 2 GB) • Check that the PC and other equipment are compatible when using the SDXC Memory Cards. SDHC Memory Card http://panasonic.net/avc/sdcard/information/SDXC.html (4 GB to 32 GB) • This unit is compatible with UHS-I standard SDHC/SDXC memory cards.
Page 20: Getting Started/Basic Operations
Getting Started/Basic Operations Attaching the Shoulder Strap • We recommend attaching the shoulder strap when using the camera to prevent it from dropping. Pass the shoulder strap through the shoulder strap eyelet on the camera body. A: Shoulder strap eyelet Pass the end of the shoulder strap through the ring in the direction of the arrow and then pass it through the stopper.
Page 21: Charging The Battery
To ensure that safe products are used, we recommend that a genuine Panasonic battery pack is used. • Use the dedicated charger and battery.
Page 22 2. Getting Started/Basic Operations About the [CHARGE] indicator ∫ Charging. Off: Charging has completed. (Disconnect the charger from the electrical socket and detach the battery after charging is completed.) • When the [CHARGE] indicator flashes – The battery temperature is too high or too low. It is recommended to charge the battery again in an ambient temperature of between 10 oC and 30 oC (50 oF and 86 oF).
Page 23: Approximate Operating Time And Number Of Recordable Pictures
2. Getting Started/Basic Operations Approximate operating time and number of recordable pictures By CIPA standard in Program AE Mode The values in “( )” indicate the values when the flash is fired in full brightness for one in every two pictures you take. [When the flash (supplied) is used] Recording still pictures (when using the Monitor) ∫...
Page 24 CIPA is an abbreviation of [Camera & Imaging Products Association]. • Temperature: 23 oC (73.4 oF)/Humidity: 50%RH when monitor/viewfinder is on. • When using a Panasonic SDHC Memory Card. • Using the supplied battery. • Starting recording 30 seconds after the camera is turned on.
Page 25 2. Getting Started/Basic Operations Recording motion pictures (when using the monitor) ∫ [AVCHD] (Recording with picture quality set to [FHD/17M/60i]) When the interchangeable lens (H-FS12032) is used Recordable time Approx. 80 min Actual recordable time Approx. 40 min When the interchangeable lens (H-FS35100) is used Recordable time Approx.
Page 26 2. Getting Started/Basic Operations Playback (when using the monitor) ∫ When the interchangeable lens (H-FS12032) is used Playback time Approx. 160 min When the interchangeable lens (H-FS35100) is used Playback time Approx. 160 min When the interchangeable lens (H-X015) is used Playback time Approx.
Page 27: Inserting And Removing The Card (Optional)/The Battery
Inserting and Removing the Card (optional)/ the Battery • Check that this unit is turned off. • We recommend using a Panasonic card. 1: Slide the release lever in the direction of the arrow. 2: Open the card/battery door. •...
Page 28 2. Getting Started/Basic Operations 1: Close the card/battery door. 2: Slide the release lever in the direction of the arrow. • Remove the battery after use. (The battery will be exhausted if left for a long period of time after being charged.) •...
Page 29: About The Card
Do not turn the camera off during formatting. • If the card has been formatted on a PC or other equipment, format it on the camera again. • If the card cannot be formatted, please try another card before contacting Panasonic.
Page 30: Approximate Number Of Recordable Pictures And Available Recording Time
2. Getting Started/Basic Operations Approximate number of recordable pictures and available recording time Number of recordable pictures ∫ • Aspect ratio [4:3], Quality [A] [Picture Size] 8 GB 16 GB 32 GB 64 GB L (16M) 1810 3640 7260 M (8M) 1650 3340 6690...
Page 31 2. Getting Started/Basic Operations • When a high ambient temperature, continuous recording or other conditions cause the camera to overheat, the following restrictions will occur to protect the camera. Wait until the camera cools down. – Continuous recording, motion picture recording, and the Wi-Fi connection will be temporarily disabled.
Page 32: Changing The Lens
2. Getting Started/Basic Operations Changing the Lens By changing the lens, you will increase your picture taking-options and further your enjoyment of the camera. Change the lens using the following procedure. • Check that the camera is turned off. • When attaching or detaching the interchangeable lens (H-FS12032/H-FS35100), retract the lens barrel.
Page 33 2. Getting Started/Basic Operations Attaching the lens • Remove the lens rear cap from the lens. • If the body cap is fitted to the camera, remove it. Align the lens fitting marks A and then rotate the lens in the direction of the arrow until it clicks.
Page 34 2. Getting Started/Basic Operations Attaching the Lens Hood When recording into strong backlight, irregular reflection may occur within the lens. The lens hood reduces the inclusion of unwanted light in the recorded images and lowers the drop in contrast. The lens hood cuts off excess lighting and improves the picture quality. •...
Page 35 2. Getting Started/Basic Operations Interchangeable Lens (H-X015) ∫ • Before attaching the lens hood, make sure to remove the lens cap. The lens hood cannot be attached unless you remove the lens cap. Rotate the decoration ring in the direction of the arrow to remove it.
Page 36: Setting Date/Time (Clock Set)
2. Getting Started/Basic Operations Setting Date/Time (Clock Set) • The clock is not set when the camera is shipped. Turn the camera on. • When the camera is turned on, the status indicator 1 lights up green. • If the language select screen is not displayed, proceed to step Press [MENU/SET].
Page 37: Changing The Clock Setting
2. Getting Started/Basic Operations Changing the Clock Setting Select [Clock Set] in the [Setup] menu. (P57) • The clock can be reset as shown in steps on P36. • The clock setting is maintained for 3 months using the built-in clock battery even without the battery.
Page 38: Basic Operations
2. Getting Started/Basic Operations Basic Operations Tips for taking good pictures Hold the camera gently with both hands, keep your arms still at your side and stand with your feet slightly apart. • Do not cover the AF assist lamp A, microphone B or the speaker C with your fingers or other objects.
Page 39: Extending/Retracting The Lens [When The Interchangeable Lens (H-Fs12032/H-Fs35100) Is Attached]
2. Getting Started/Basic Operations Extending/retracting the lens [when the interchangeable lens (H-FS12032/H-FS35100) is attached] How to Extend the Lens Example: H-FS12032 ∫ Rotate the zoom ring in the direction of arrow 1 from position  A (the lens is retracted) to position B [12 mm to 32 mm (H-FS12032), 35 mm to 100 mm (H-FS35100)] to extend the lens.
Page 40: Shutter Button (Taking Pictures)
2. Getting Started/Basic Operations Shutter button (Taking pictures) The shutter button works in two steps. To take a picture, press it. Press the shutter button halfway to focus. A Aperture value B Shutter speed C Focus indication • Aperture value and shutter speed are displayed. (It will flash in red if the correct exposure is not achieved, except when set to flash.) •...
Page 41: Motion Picture Button (Recording Motion Pictures)
2. Getting Started/Basic Operations Displaying a picture right after it is taken > [Custom] > [Auto Review] MENU Set the length of time that the picture is displayed after taking the still picture. [HOLD]: [Duration Time] The pictures are displayed until shutter button is pressed halfway. [5SEC]/[4SEC]/[3SEC]/[2SEC]/[1SEC]/[OFF] [ON] Switching the display of the playback screen, deleting...
Page 42: Mode Dial (Selecting A Recording Mode)
2. Getting Started/Basic Operations Mode dial (Selecting a Recording Mode) Select the mode by rotating the mode dial. • Rotate the mode dial slowly to select the desired mode. Intelligent Auto Mode (P75) The subjects are recorded using settings automatically selected by the camera.
Page 43: Rear Dial
2. Getting Started/Basic Operations Rear Dial There are 2 ways to operate the rear dial, rotating left or right, and deciding by pressing. Rotating: Selection of items or setting of values is performed during the various settings. Pressing: Operations that are the same as [MENU/SET] button, such as determine settings, etc., are performed during the various settings.
Page 44: Cursor Buttons/[Menu/Set] Button
2. Getting Started/Basic Operations Cursor buttons/[MENU/SET] button Pressing the cursor button: Selection of items or setting of values etc., is performed. Pressing [MENU/SET]: Confirmation of setting contents, etc., is performed. • This owner's manual expresses the up, down, left, and right of the cursor button as 3/4/2/1.
Page 45: [Disp.] Button (Switching The Displayed Information)
2. Getting Started/Basic Operations [DISP.] button (Switching the displayed information) Press [DISP.] to switch the information displayed on the screen. In Recording Mode • You can select between [ ] (monitor style) and [ ] (viewfinder style) for each of the monitor and the viewfinder display screen using [Monitor Disp.
Page 46 2. Getting Started/Basic Operations ] viewfinder style) • Screen will switch as follows: (Example of display on viewfinder) With information With information With information (detailed (detailed With information (tilt sensor information tilt information) ¢ display) sensor display) ¢ 60 i 60 i ¢...
Page 47 2. Getting Started/Basic Operations Displaying/not displaying the histogram > [Custom] > [Histogram] > [ON]/[OFF] MENU You can set the position by pressing 3/4/2/1. • Direct touch operation is also possible from the recording screen. • A histogram is a graph that displays brightness along the horizontal axis (black to white) and the number of pixels at each brightness level on the vertical axis.
Page 48 2. Getting Started/Basic Operations About the tilt sensor display ∫ With the tilt sensor displayed, it is easy to correct the tilt of the camera etc. Press [DISP.] to display the tilt sensor. Check the tilt of the camera.  ...
Page 49 2. Getting Started/Basic Operations In Playback Mode • Screen will switch as follows: Without Detailed With Histogram information information information ¢1 display ¢2 (Highlight display ¢2 display) ¢1, 2, 3, 4 F3.5 1/98 1/98 1/98 1/98 F3.5 STD. STD. STD. 10:00 DEC.
Page 50 2. Getting Started/Basic Operations Displaying/not displaying white saturated areas > [Custom] > [Highlight] > [ON]/[OFF] MENU When the Auto Review function is activated or when playing back, white saturated areas appear blinking in black and white. This does not affect the recorded image. [ON] [OFF] •...
Page 51: [Lvf] Button (Switching The Monitor/Viewfinder)
2. Getting Started/Basic Operations [LVF] button (Switching the Monitor/Viewfinder) Press [LVF] to switch between the Monitor and Viewfinder. A [LVF] button B Eye sensor [LVF]/[Fn2] button can be used in two ways, as [LVF] or as [Fn2] (function 2). The button can be used as the [LVF] button at the time of purchase.
Page 52 2. Getting Started/Basic Operations Setting the eye sensor sensitivity and the automatic switching of the display between the Monitor and Viewfinder > [Custom] > [Eye Sensor] MENU This will set the sensitivity of the eye sensor. [Sensitivity] [HIGH]/[LOW] This will set the method for switching between the monitor and viewfinder. [LVF/MON AUTO] (automatic switching between the monitor and [LVF/Monitor viewfinder)/...
Page 53: Touch Screen (Touch Operations)
2. Getting Started/Basic Operations Touch screen (Touch operations) Touch screen of this unit is capacitive. Touch the panel directly with your bare finger. Touch ∫ To touch and release the touch screen. • When selecting features using the touch screen, be sure to touch the center of the desired icon.
Page 54 2. Getting Started/Basic Operations Enabling/disabling the touch operation > [Custom] > [Touch Settings] MENU • When set to [OFF], no corresponding touch tab or touch icon is displayed on the screen. [ON] All touch operations. Sets a part of the touch screen to a non-touch-sensitive area. Touch operations in the area will be disabled.
Page 55: Taking Pictures Using The Touch Function
2. Getting Started/Basic Operations Taking Pictures Using the Touch Function Taking pictures using the Touch Shutter function Applicable modes: Just by touching the subject you want as your point of focus, the camera will focus on the subject and take the picture automatically. Touch [ ].
Page 56 2. Getting Started/Basic Operations Easily Optimizing the Brightness for a Specified Area (Touch AE) Applicable modes: You can easily optimize the brightness for a touched position. When the face of the subject appears dark, you can brighten the screen according to the brightness of the face. Touch [ ].
Page 57: Setting Menu Items
2. Getting Started/Basic Operations Setting menu items You can set the menus using two types of operation—touch operations in which you touch the screen, and button operations in which you press the cursor button and rotate the rear dials. In this owner's manual, steps for setting a menu item are described as follows. Example: In the [Rec] menu, change [Quality] from [ ] to [ ›...
Page 58 2. Getting Started/Basic Operations Switching to other menus ∫ e.g.: Switching to the [Setup] menu from [Rec] menu. Press 2. Press 3/4 to select a menu selector icon, such as • You can also select a menu selector icon by rotating the rear dial.
Page 59 2. Getting Started/Basic Operations Close the menu ∫ Press [ ] or press the shutter button halfway. (In touch operation) Touch [ • When [Menu Information] (P71) in the [Setup] menu is set to [ON], explanations of the menu items and settings are displayed on the menu screen. •...
Page 60: Calling Frequently-Used Menus Instantly (Quick Menu)
2. Getting Started/Basic Operations Calling frequently-used menus instantly (Quick Menu) By using the Quick Menu, some of the menu settings can be easily found. • The features that can be adjusted using Quick Menu are determined by the mode or a display style the camera is in.
Page 61 2. Getting Started/Basic Operations Switching the method for setting Quick Menu items > [Custom] > [Q.MENU] MENU [PRESET]: The default items can be set. [CUSTOM]: The Quick Menu will consist of desired items. (P62)
Page 62: Change The Quick Menu To Your Preferred Item
2. Getting Started/Basic Operations Change the Quick Menu to your preferred item When [Q.MENU] (P61) in the [Custom] menu is set to [CUSTOM], the Quick Menu can be changed as desired. Up to 15 items can be set to the Quick Menu. Press 4 to select [ ] and then press [MENU/ SET].
Page 63 2. Getting Started/Basic Operations [Motion Picture] menu – – [Snap Movie] (P221) [Picture Mode] (P220) – [Motion Pic. Set] ([Rec Format] (P217)/[Rec Quality] (P217)) [Custom] menu – – [Silent Mode] (P186) [Monochrome Live View] (P194) – – [Peaking] (P158) [Rec Area] (P215) –...
Page 64: Assigning Frequently Used Functions To The Buttons (Function Buttons)
2. Getting Started/Basic Operations Assigning frequently used functions to the buttons (function buttons) You can assign recording functions, etc. to specific buttons and icons. Select the menu. > [Custom] > [Fn Button Set] MENU Press 3/4 to select the function button you want to assign a function to and then press [MENU/ SET].
Page 65 2. Getting Started/Basic Operations [Custom] menu – – [Silent Mode] (P186) [Monochrome Live View] (P194) – – [Peaking] (P158) [Rec Area] (P215) – – ¢ [Histogram] (P47): [Fn5] [Step Zoom] (P201) – – [Guide Line] (P47) [Zoom Speed] (P201) – –...
Page 66: Configuring Basic Settings Of This Unit (Setup Menu)
2. Getting Started/Basic Operations Configuring basic settings of this unit (Setup Menu) For details on how to select the [Setup] menu settings, refer to P57. [Clock Set] and [Economy] are important items. Check their settings before using them. — [Clock Set] •...
Page 67 2. Getting Started/Basic Operations Departure date and return date of the trip as well as the name of the travel destination can be set. You can display the number of days that have passed when playing back the pictures and stamp it on the recorded pictures with [Text Stamp] (P242).
Page 68 2. Getting Started/Basic Operations This allows you to set the volume for electronic sound and the electronic shutter sound. [Beep Volume]: [Shutter Vol.]: [u] (High) ] (High) [Beep] [t] (Low) ] (Low) [s] (OFF) ] (OFF) [Shutter Tone]: • When [Silent Mode] is set to [ON], [Beep Volume] and [Shutter Vol.] is set to [OFF]. Set the frame rate of the recording screen (Live View screen).
Page 69 2. Getting Started/Basic Operations Sets the monitor brightness according to the ambient light level. „ [AUTO]: The brightness is adjusted automatically depending on how bright it is around the camera. … [MODE1]: [Monitor Luminance] Make the monitor brighter. … [MODE2]: Set the monitor to the standard brightness.
Page 70 2. Getting Started/Basic Operations Select the USB communication system when connecting the camera to your PC or your printer with the USB connection cable (supplied). y [Select on connection]: Select either [PC] or [PictBridge(PTP)] if you connected the [USB Mode] camera to a PC or a printer supporting PictBridge.
Page 71 2. Getting Started/Basic Operations [3D Playback]: Set the output method for 3D pictures. Set when connecting to a 3D compatible television. Set when connecting to a television not compatible with Set this when you would like to view pictures in 2D (conventional image) on a 3D compatible television.
Page 72 2. Getting Started/Basic Operations Set the language displayed on the screen. [Language] • If you set a different language by mistake, select [~] from the menu icons to set the desired language. — [Version Disp.] • This enables the firmware versions of the camera and lens to be checked. •...
Page 73 2. Getting Started/Basic Operations Reset all settings in the [Wi-Fi] menu to factory default settings. [Reset Wi-Fi Settings] (Excluding [LUMIX CLUB] (P293)) • Always reset the camera when disposing or selling it to prevent personal information saved within the camera from being misused. •...
Page 74: Entering Text
2. Getting Started/Basic Operations Entering Text It is possible to enter babies’ and pets’ names and the locations when recording. When a screen that looks like the one on the right is displayed, you can enter characters. (Only alphabetical characters and symbols can be entered.) •...
Page 75: Recording Modes
Recording Modes Taking Pictures using the Automatic Function (Intelligent Auto Mode) Recording Mode: In this mode, the camera makes the optimal settings for the subject and scene, so we recommend it when you wish to leave the settings to the camera and record without thinking about them.
Page 76 3. Recording Modes Set the mode dial to [¦]. • The camera will switch to either the most recently used of Intelligent Auto Mode or Intelligent Auto Plus Mode. At the time of purchase, the mode is set to Intelligent Auto Plus Mode.
Page 77 3. Recording Modes Functions that work automatically ∫ • The following functions are performed automatically to allow the camera to make the optimal settings. – Scene Detection – Backlight Compensation – [Face/Eye Detection] – Auto White Balance – Intelligent ISO sensitivity control –...
Page 78: Scene Detection
3. Recording Modes Scene Detection ∫ • If a tripod is used, for instance, and the camera has judged that camera shake is minimal when the scene detection has been identified as [ ], the shutter speed will be slower than normal. Take care not to move the camera while taking pictures.
Page 79: Recording Night Scenes ([Ihandheld Night Shot])
3. Recording Modes Recording night scenes ([iHandheld Night Shot]) Recording Mode: When [iHandheld Night Shot] is set to [ON] and [ ] is detected while taking handheld night shots, pictures of the night scenery will be taken at a high burst speed and composed into a single picture.
Page 80: Combining Pictures Into A Single Picture With Rich Gradation ([Ihdr])
3. Recording Modes Combining pictures into a single picture with rich gradation ([iHDR]) Recording Mode: When [iHDR] is set to [ON] and there is, for example, strong contrast between the background and the subject, multiple still pictures are recorded with differing exposures and combined to create a single still picture rich in gradation.
Page 81: Taking A Picture With A Blurred Background (Defocus Control)
3. Recording Modes Taking a picture with a blurred background (Defocus Control) Recording Mode: You can easily set the blurriness of the background while checking the screen. Press the rear dial to display the setting screen. • Each time the rear dial is pressed in Intelligent Auto Plus Mode, the camera switches between brightness setting operation (P82), Defocus Control operation, and normal operation.
Page 82: Recording Images By Changing The Brightness Or Color Tone
3. Recording Modes Recording images by changing the brightness or color tone Recording Mode: This mode enables you to change the brightness and color tone to your preferred settings from the ones set by the camera. Setting brightness Press the rear dial to display the setting screen. •...
Page 83: About Intelligent Auto Plus Mode And Intelligent Auto Mode
3. Recording Modes About Intelligent Auto Plus Mode and Intelligent Auto Mode Switching between Intelligent Auto Plus Mode and Intelligent Auto Mode ∫ Press [MENU/SET]. Press 2. Press 3/4 to select the [ ] or [ ] tab. Press 2/1 to select [ ] or [ ] and then press [MENU/SET].
Page 84 3. Recording Modes Menus that can be set ∫ Only the following menus can be set. Intelligent Auto Plus Mode Menu Item [Photo Style]/[Aspect Ratio]/[Picture Size]/[Quality]/[AFS/AFF]/[Burst Rate]/ [Auto Bracket]/[Self Timer]/[iHandheld Night Shot]/[iHDR]/[Time Lapse Shot]/ [Rec] [Stop Motion Animation]/[Shutter Type]/[Ex. Tele Conv.]/[Color Space]/ [Stabilizer]/[Face Recog.]/[Profile Setup] [Motion [Photo Style]/[Snap Movie]/[Rec Format]/[Rec Quality]/[AFS/AFF]/[Continuous...
Page 85: Taking Pictures With Your Favorite Settings (Program Ae Mode)
3. Recording Modes Taking Pictures with Your Favorite Settings (Program AE Mode) Recording Mode: The camera automatically sets the shutter speed and the aperture value according to the brightness of the subject. You can take pictures with greater freedom by changing various settings in the [Rec] menu.
Page 86 3. Recording Modes Program Shift In Program AE Mode, you can change the preset aperture value and shutter speed without changing the exposure. This is called Program Shift. You can make the background more blurred by decreasing the aperture value or record a moving subject more dynamically by slowing the shutter speed when taking a picture in Program AE Mode.
Page 87 3. Recording Modes Example of Program Shift [When the interchangeable lens (H-FS12032) is used] 9 10 11 12 13 14 15 16 1 / 2 1 / 4 1 / 8 1 / 15 1 / 30 1 / 60 1 / 125 1 / 250 1 / 500 1 / 1000 1 / 2000 1 / 4000 1 / 8000 1 / 16000 (A): Aperture value (B): Shutter speed 1 Program Shift line chart...
Page 88: Taking Pictures By Specifying The Aperture/Shutter Speed
3. Recording Modes Taking Pictures by Specifying the Aperture/ Shutter Speed Recording Mode: • The effects of the set aperture value and shutter speed will not be visible on the recording screen. To check on the recording screen, please use [Preview]. (P93) •...
Page 89: Shutter-Priority Ae Mode
3. Recording Modes Shutter-Priority AE Mode When you set the shutter speed, the camera automatically optimizes the aperture value for the brightness of the subject. When you want to take a sharp picture of a fast moving subject, set with a faster shutter speed.
Page 90: Manual Exposure Mode
3. Recording Modes Manual Exposure Mode Determine the exposure by manually setting the aperture value and the shutter speed. The Manual Exposure Assistance appears on the lower portion of the screen to indicate the exposure. Set the mode dial to [ Rotate the rear dial to set the aperture value and shutter speed.
Page 91 3. Recording Modes Optimizing the ISO sensitivity for the shutter speed and aperture value When the ISO sensitivity is set to [AUTO], the camera sets the ISO sensitivity automatically so that the exposure will be appropriate for the shutter speed and aperture value.
Page 92 3. Recording Modes Checking/not checking the effects of aperture and shutter speed on the recording screen > [Custom] > [Constant Preview] > [ON]/[OFF] MENU • This function does not work when using the flash. • It can only be used with Manual Exposure Mode. •...
Page 93: Confirm The Effects Of Aperture And Shutter Speed (Preview Mode)
3. Recording Modes Confirm the Effects of Aperture and Shutter Speed (Preview Mode) Applicable modes: The effects of aperture and shutter speed can be checked by using the Preview Mode. • Confirm the effects of aperture: You can check the depth of field (effective focus range) before taking a picture by closing the leaf shutter to the aperture value you set.
Page 94: Easily Set Aperture/Shutter Speed For Suitable Exposure (One Push Ae)
3. Recording Modes Easily set aperture/shutter speed for suitable exposure (One Push AE) Applicable modes: When the exposure setting is too bright or too dark, you can use one push AE to achieve a suitable exposure setting. How to tell if the exposure is not adequate •...
Page 95: Taking Panorama Pictures (Panorama Shot Mode)
3. Recording Modes Taking panorama pictures (Panorama Shot Mode) Recording Mode: Consecutive photos taken while the camera is moved are combined to form a panorama. Set the mode dial to [ • After the screen that asks you to check the recording direction is displayed, the horizontal/vertical guidelines will be displayed.
Page 96 3. Recording Modes Press the shutter button once again to end the picture recording. • Recording can also be ended by keeping the camera still while recording. • Recording can also be ended by moving the camera to the end of the guide. Technique for Panorama Shot Mode ∫...
Page 97 3. Recording Modes About playback ∫ Pressing 3 will start scrolling playback automatically in the same direction as the recording. 1/98 1/98 1/98 1/98 • The following operations can be performed during scrolling playback. Start panorama playback/Pause ¢ Stop ¢ When the playback is paused, you can scroll forwards and backwards by dragging the screen.
Page 98: Taking Pictures That Match The Scene Being Recorded (Scene Guide Mode)
3. Recording Modes Taking Pictures that match the Scene being recorded (Scene Guide Mode) Recording Mode: If you select a scene to suit the subject and recording conditions with reference to the example images, the camera will set optimal exposure, color, and focus, allowing you to record in a manner appropriate to the scene.
Page 99 3. Recording Modes Switching the scene selection screen display ∫ Press [DISP.] to switch the monitor screen. • When it is set to the guide display, tips for creating picture effects suitable for each scene, etc. is displayed. Normal display Guide display List display Displaying/not displaying the selection screen when the mode dial is...
Page 100: Backlit Softness
3. Recording Modes For details on “Scene Guide Mode” settings, refer to P98. [Clear Portrait] The brightness of the face is adjusted and the background is defocused to create a clear portrait. Tips • If you are using a lens with the zoom function, you can enhance the effect by zooming in as much as possible and closing the distance between the camera and the subject.
Page 101: Distinct Scenery
3. Recording Modes [Relaxing Tone] The warm color tone creates an image with a relaxing mood. [Sweet Child's Face] Moderate background defocusing and skin tone highlighted draws attention to the child’s face. Touch the face. • A still picture is recorded with the focus and exposure set for the touched location.
Page 102 3. Recording Modes [Romantic Sunset Glow] The enhanced purple tone creates a romantic image of the sky just after sunset. [Vivid Sunset Glow] Red is enhanced to create a vivid image of the sunset. [Glistening Water] The glisten of the water is enhanced to look brighter and slightly bluish.
Page 103: Cool Night Sky
3. Recording Modes [Cool Night Sky] Blue tones are enhanced to create a cool and sophisticated image of the night sky after sunset. Tips • We recommend using a tripod and the self-timer. • The shutter may remain closed after taking the picture. This is due to signal processing and is not a malfunction.
Page 104: Glittering Illuminations
3. Recording Modes [Glittering Illuminations] The star filter enhances pinpoints of light. Tips • We recommend using a tripod and the self-timer. • Display of the recording screen will be delayed more than usual and the screen will look as if frames are dropping. •...
Page 105: Appetizing Food
3. Recording Modes [Soft Image of a Flower] The soft focus creates a diffused image. Tips • We recommend using a tripod and the self-timer. • We recommend that you avoid using the flash when taking close-up pictures. • Display of the recording screen will be delayed more than usual and the screen will look as if frames are dropping.
Page 106 3. Recording Modes [Cute Dessert] The overall screen brightness is set higher to enhance the cuteness of the dessert. Tips • If you are using a lens with the zoom function, you can enhance the effect by zooming in as much as possible and closing the distance between the camera and the subject.
Page 107: Taking Pictures With Different Image Effects (Creative Control Mode)
3. Recording Modes Taking Pictures with different image effects (Creative Control Mode) Recording Mode: This mode records with additional image effects. You can set the effects to add by selecting example images and checking them on the screen. Set the mode dial to [ Press 3/4 to select the image effects (filters).
Page 108 3. Recording Modes Switching the image effect (filter) selection screen display ∫ Press [DISP.] to switch the monitor screen. • When the image effect selection screen display is set to the guide display, description of the selected image effect is displayed. Normal display Guide display List display...
Page 109: Setting Brightness
3. Recording Modes Taking a picture with a blurred background (Defocus Control) You can easily set the blurriness of the background while checking the screen. Press the rear dial to display the setting screen. • Each press of the rear dial switches among brightness setting, Defocus Control and end operation.
Page 110 3. Recording Modes For details on “Creative Control Mode” settings, refer to P107. [Expressive] This effect emphasizes the color to make a pop art picture. Items that can be set Freshness Understated colors Pop colors [Retro] This effect gives a faded image. Items that can be set Color Yellow emphasized...
Page 111 3. Recording Modes [Low Key] This effect adds a dark and relaxing feel to the overall image and enhances bright parts. Items that can be set Color Red emphasized Blue emphasized [Sepia] This effect creates a sepia image. Items that can be set Contrast Low contrast High contrast...
Page 112: Impressive Art
3. Recording Modes [Rough Monochrome] This effect creates a black and white picture with granular noise. Items that can be set Grittiness Less gritty Grittier • Display of the recording screen will be delayed more than usual and the screen will look as if frames are dropping. [Silky Monochrome] This effect blurs the overall image to add a soft feel to a black and white picture.
Page 113 3. Recording Modes [Cross Process] This effect gives your photo a dramatic color look. Items that can be set Color Green tone/Blue tone/Yellow tone/Red tone • Select the desired color tone by rotating the rear dial, and then press [MENU/SET]. [Toy Effect] This effect reduces peripheral brightness to give the impression of a toy camera.
Page 114 3. Recording Modes [Miniature Effect] This effect blurs peripheral areas to give the impression of a diorama. Items that can be set Freshness Understated colors Pop colors Setting the type of defocus ∫ With [Miniature Effect] you can make the subject stand out by intentionally creating defocused and in-focus portions.
Page 115 3. Recording Modes [Soft Focus] This effect blurs the overall image to produce a soft feel. Items that can be set Extent of defocus Weak defocus Strong defocus • Display of the recording screen will be delayed more than usual and the screen will look as if frames are dropping.
Page 116 3. Recording Modes [One Point Color] This effect leaves one selected color to emphasize impressiveness. Items that can be set Small amount of Large amount of Amount of color left color color Set the color to leave in ∫ Set the color to leave in by selecting a location on the screen. Press [Fn1] to display the setting screen.
Page 117 3. Recording Modes [Sunshine] This effect adds a cast of light to the scene. Items that can be set Color Yellow tone/Red tone/Blue tone/White tone • Select the color tone by rotating the rear dial, and then press [MENU/ SET]. Setting the light source ∫...
Page 118: Recording Motion Pictures With Manually Set Aperture Value/Shutter Speed (Creative Video Mode)
3. Recording Modes Recording motion pictures with manually set aperture value/shutter speed (Creative Video Mode) Recording Mode: It is possible to manually change the aperture and shutter speed and record motion pictures. Set the mode dial to [ Select the menu. (P57) >...
Page 119: Minimizing Operational Sounds During Motion Picture Recording
3. Recording Modes Minimizing operational sounds during motion picture recording The operational sound of the zoom or button operation may be recorded when it is operated during the recording of a motion picture. Using touch icons allows silent operation while recording motion pictures. Select the menu.
Page 120: Registering Your Preferred Settings (Custom Mode)
3. Recording Modes Registering your preferred settings (Custom Mode) Recording Mode: You can register the current camera settings as custom settings. If you then record in Custom Mode, you can use the registered settings. • Initial setting of the Program AE Mode is registered as the custom settings initially. Registering Personal Menu Settings (Registering custom settings) To allow recording using the same settings, up to 3 sets of current camera settings can be registered using [Cust.Set Mem.].
Page 121: Recording Using Registered Custom Set
3. Recording Modes Recording using registered custom set You can easily call up the settings you have registered using [Cust.Set Mem.]. Set the mode dial to [ ] • The custom set you used last time ([ ], [ ], or [ ]) will be called up.
Page 122: Picture Quality And Color Tone Settings
Picture Quality and Color Tone Settings Adjusting the Picture Quality by Adding an Effect ([Photo Style]) Applicable modes: You can select effects to match the type of image you wish to record. It is possible to adjust the items such as color or picture quality of the effect to your desire. >...
Page 123 4. Picture Quality and Color Tone Settings Adjusting the picture quality ∫ • Picture quality cannot be adjusted in the Intelligent Auto Plus Mode. Press 2/1 to select the type of Photo Style. Press 3/4 to select the items, and then press 2/ 1 to adjust.
Page 124: Recording Images With Image Effects ([Filter Settings])
4. Picture Quality and Color Tone Settings Recording Images with Image Effects ([Filter Settings]) Applicable modes: You can apply image effects (filters) that are available for Creative Control Mode to images in other modes, such as Aperture-Priority AE Mode or Panorama Shot Mode. >...
Page 125 4. Picture Quality and Color Tone Settings • [Rough Monochrome]/[Silky Monochrome]/[Soft Focus]/[Star Filter]/[Sunshine] are not available in Creative Video Mode. • [Toy Effect]/[Toy Pop]/[Miniature Effect]/[Sunshine] are not available in Panorama Shot Mode. • The image effects of [Rough Monochrome]/[Silky Monochrome]/[Soft Focus]/[Star Filter] are not visible on the screen when taking panorama pictures.
Page 126: Adjusting Bright/Dark Portions ([Highlight Shadow])
4. Picture Quality and Color Tone Settings Adjusting Bright/Dark Portions ([Highlight Shadow]) Applicable modes: You can adjust the brightness of bright and dark portions on an image while checking the brightness on the screen. Select the menu. (P57) > [Rec] > [Highlight Shadow] MENU Press 2/1 to select the item.
Page 127: Adjusting The White Balance
4. Picture Quality and Color Tone Settings Adjusting the White Balance Applicable modes: In sunlight, under incandescent lights or in other such conditions where the color of white takes on a reddish or bluish tinge, this item adjusts to the color of white which is closest to what is seen by the eye in accordance with the light source.
Page 128 4. Picture Quality and Color Tone Settings You can set the color temperature manually for taking natural pictures in different lighting 6500K conditions. The color of light is measured as a number in degrees Kelvin. As the color temperature increases, the picture becomes more bluish. As the color temperature decreases, the picture becomes more reddish.
Page 129 4. Picture Quality and Color Tone Settings Auto White Balance ∫ Depending on the conditions prevailing when pictures are taken, the pictures may take on a reddish or bluish tinge. Furthermore, when a multiple number of light sources are being used or there is nothing with a color close to white, Auto White Balance may not function properly.
Page 130 4. Picture Quality and Color Tone Settings White Balance Bracket Bracket setting is performed based on the adjustment values for the White Balance fine adjustment, and 3 pictures with different colors are automatically recorded when the shutter button is pressed once. Fine-adjust the White Balance in step of “Finely G G G G G G...
Page 131: Setting The Picture Quality And Size
4. Picture Quality and Color Tone Settings Setting the Picture Quality and Size Setting the aspect ratio of pictures Applicable modes: This allows you to select the aspect ratio of the pictures to suit printing or the playback method. > [Rec] >...
Page 132: Setting The Compression Rate Of Pictures ([Quality])
4. Picture Quality and Color Tone Settings Setting the compression rate of pictures ([Quality]) Applicable modes: Set the compression rate at which the pictures are to be stored. > [Rec] > [Quality] MENU Settings File format Description of settings A JPEG image in which image quality was given priority. A standard image quality JPEG image.
Page 133: Using Image Correction Functions
4. Picture Quality and Color Tone Settings Using Image Correction Functions Compensating the contrast and exposure ([i.Dynamic]) Applicable modes: Contrast and exposure are compensated when the brightness difference between the background and subject is great, etc. > [Rec] > [i.Dynamic] MENU Settings: [AUTO]/[HIGH]/[STANDARD]/[LOW]/[OFF] •...
Page 134: Combining Pictures With Different Exposures ([Hdr])
4. Picture Quality and Color Tone Settings Combining pictures with different exposures ([HDR]) Applicable modes: You can combine 3 pictures with different levels of exposure into a single picture with rich gradation. You can minimize the loss of gradations in bright areas and dark areas when, for example, the contrast between the background and the subject is large.
Page 135: Reducing The Long Shutter Noise ([Long Shtr Nr])
4. Picture Quality and Color Tone Settings Reducing the long shutter noise ([Long Shtr NR]) Applicable modes: The camera automatically removes noise that appears when the shutter speed becomes slower to take pictures of night scenery etc. so you can take beautiful pictures. >...
Page 136: Setting The Color Space ([Color Space])
4. Picture Quality and Color Tone Settings Setting the color space ([Color Space]) Applicable modes: Set this when you want to correct the color reproduction of the recorded pictures on a PC, printer etc. > [Rec] > [Color Space] MENU Color space is set to sRGB color space.
Page 137: Focus And Brightness (Exposure) Settings
Focus and Brightness (Exposure) Settings Taking Pictures with Auto Focus By setting the optimum Focus Mode or Auto Focus Mode for the subject or recording condition, you can let the camera automatically adjust focus in various scenes. Set the focus mode dial to [AFS] or [AFC]. •...
Page 138 5. Focus and Brightness (Exposure) Settings • If you zoom in/out after focusing on a subject, the focus may lose its accuracy. In that case, re-adjust the focus. • When the Focus Mode is set to [AFF] or [AFC]. – A beep will be emitted when focus is first achieved during the pressing halfway.
Page 139: Selecting The Focus Mode (Afs/Aff/Afc)
5. Focus and Brightness (Exposure) Settings Selecting the Focus Mode (AFS/AFF/AFC) Applicable modes: The method for achieving focus when the shutter button is pressed halfway is set. Set the focus mode dial to [AFS] or [AFC]. The movement of the Item subject and the scene Description of settings...
Page 140 5. Focus and Brightness (Exposure) Settings About [AFS] of the focus mode dial ∫ In [AFS/AFF] in the [Rec] menu or the [Motion Picture] menu, you can assign [AFS] or [AFF] to [AFS] of the focus mode dial. When recording using [AFF], [AFC] •...
Page 141: Selecting The Auto Focus Mode
5. Focus and Brightness (Exposure) Settings Selecting the Auto Focus Mode Applicable modes: This allows the focusing method that suits the positions and number of the subjects to be selected. Press 2 ( Press 2/1 to select AF Mode and then press [MENU/SET].
Page 142 5. Focus and Brightness (Exposure) Settings The camera focuses on the subject in the AF area on the center of the screen. • Position and size of the AF area can be changed. ([1-Area]) (P146) You can achieve a more precise focus on a point that is smaller than [Ø].
Page 143 5. Focus and Brightness (Exposure) Settings ([Tracking]) • ] cannot be used with [Time Lapse Shot]. • In the following cases, [ ] operates as [Ø]. – [Glistening Water]/[Glittering Illuminations]/[Soft Image of a Flower]/[Monochrome] (Scene Guide Mode) – [Sepia]/[Monochrome]/[Dynamic Monochrome]/[Rough Monochrome]/[Silky Monochrome]/ [Soft Focus]/[Star Filter]/[Sunshine] (Creative Control Mode) –...
Page 144 5. Focus and Brightness (Exposure) Settings Locking the subject to be tracked ( [Tracking]) Button operation Aim the AF tracking frame over the subject, and press the shutter button halfway. A AF tracking frame • AF area will turn green when the camera detects the subject. •...
Page 145: Setting Up Position Of The Af Area/Changing Size Of The Af Area
5. Focus and Brightness (Exposure) Settings Setting up position of the AF area/changing size of the AF area Applicable modes: When [š], [ ], [Ø], or [ ] in Auto Focus Mode is selected, you can change the position and size of the AF area. •...
Page 146 5. Focus and Brightness (Exposure) Settings When selecting [š], [Ø] Position and size of the AF area can be changed. Press 2 ( Select [š] or [Ø] and press 4. • AF area setting screen is displayed. • You can also display the AF area setting screen by touching the screen.
Page 147 5. Focus and Brightness (Exposure) Settings When selecting [ You can set the focus position precisely by enlarging the screen. • The focus position cannot be set at the edge of the screen. Press 2 ( Select [ ] and press 4. Press 3/4/2/1 to set the focus position and then press [MENU/SET].
Page 148: Setting The Af Area Position With The Touch Pad
5. Focus and Brightness (Exposure) Settings Setting the AF area position with the Touch Pad Applicable modes: By setting [Touch Pad AF] in [Touch Settings] (P54) in the [Custom] menu, you can move the AF area displayed on the viewfinder by touching the monitor. >...
Page 149: Optimizing The Focus And Brightness For A Touched Position
5. Focus and Brightness (Exposure) Settings Optimizing the focus and brightness for a touched position Applicable modes: By setting [Touch AF] (P54) in [Touch Settings] of the [Custom] menu to [AF+AE], you can optimize the focus and brightness for the position you have touched. Select the menu.
Page 150: Setting The Desired Focus Method
5. Focus and Brightness (Exposure) Settings • When recording with the Touch Shutter, the focus and brightness are optimized for the touched position before recording takes place. • At the edge of the screen, the metering may be affected by the brightness around the touched location.
Page 151 5. Focus and Brightness (Exposure) Settings Turning on/not turning on the AF Assist Lamp > [Custom] > [AF Assist Lamp] > [ON]/[OFF] MENU AF assist lamp will illuminate the subject when the shutter button is pressed halfway, making it easier for the camera to focus when recording in low light conditions. (Larger AF area is displayed depending on the recording conditions.) •...
Page 152 5. Focus and Brightness (Exposure) Settings Recording/not recording even when focus is not achieved > [Custom] > [Focus/Release Priority] MENU [FOCUS]: You cannot take a picture until the subject is brought into focus. [RELEASE]: This gives priority to the best time to take a picture so you can take a picture when the shutter button is pressed fully.
Page 153: Taking Pictures With Manual Focus
5. Focus and Brightness (Exposure) Settings Taking Pictures with Manual Focus Applicable modes: Use this function when you want to fix the focus or when the distance between the lens and the subject is determined and you do not want to activate Auto Focus. The operations used to focus manually differ depending on the lens.
Page 154 5. Focus and Brightness (Exposure) Settings • You can also enlarge the area by rotating the focus ring, moving the focus lever, or pinching out (P53) the screen or touching the screen twice. • You can also determine the area to be enlarged by dragging (P53) the screen.
Page 155 5. Focus and Brightness (Exposure) Settings Press the shutter button halfway. • The assist screen will close. The recording screen will be displayed. • You can also close the assist screen by pressing [MENU/SET]. • If you have enlarged the picture by rotating the focus ring or moving the focus lever, the assist screen will close approximately 10 seconds after the operation.
Page 156 5. Focus and Brightness (Exposure) Settings About the focus distance reference mark ∫ The focus distance reference mark is a mark used to measure the focus distance. Use this when taking pictures with Manual Focus or taking close-up pictures. Focus range A Focus distance reference mark B Focus distance reference line C 0.2 m (0.66 feet) (focal length 12 mm to 20 mm)
Page 157 5. Focus and Brightness (Exposure) Settings Setting the display method of the MF Assist (enlarged screen) > [Custom] > [MF Assist] MENU • Available settings vary depending on the lens used. When an interchangeable lens with no focus ring (H-FS12032) is used Focus can be adjusted when you press 2( ) and the screen that lets you set the [ON]...
Page 158 5. Focus and Brightness (Exposure) Settings Highlighting/not highlighting in-focus portions > [Custom]>[Peaking] MENU In-focus portions are highlighted with color. [ON] In-focus portions are not highlighted. [OFF] The detection level for in-focus portions is set. When [HIGH] is set, portions to be highlighted are [Detect Level] reduced, allowing you to achieve a more precise focus.
Page 159: Fixing The Focus And The Exposure (Af/Ae Lock)
5. Focus and Brightness (Exposure) Settings Fixing the Focus and the Exposure (AF/AE Lock) Applicable modes: This is useful when you want to take a picture of a subject outside the AF area or the contrast is too strong and you cannot achieve appropriate exposure. Set a function button to [AF/AE LOCK].
Page 160 5. Focus and Brightness (Exposure) Settings • AF Lock only is effective when taking pictures in Manual Exposure Mode. • AE Lock only is effective when taking pictures with Manual Focus. • Only the AF lock is active during motion picture recording. Once you cancel the AF lock during the recording, the AF lock cannot be reactivated.
Page 161: Compensating The Exposure
5. Focus and Brightness (Exposure) Settings Compensating the Exposure Applicable modes: Use this function when you cannot achieve appropriate exposure due to the difference in brightness between the subject and the background. Press the rear dial to switch to Exposure Compensation operation.
Page 162: Setting The Light Sensitivity
5. Focus and Brightness (Exposure) Settings Setting the Light Sensitivity Applicable modes: This allows the sensitivity to light (ISO sensitivity) to be set. Setting to a higher figure enables pictures to be taken even in dark places without the resulting pictures coming out dark. Press 3 ( Select the ISO sensitivity by rotating the rear dial.
Page 163: Setting The Upper Limit On Iso Sensitivity
5. Focus and Brightness (Exposure) Settings Characteristics of the ISO sensitivity 25600 Recording location When it is light (outdoors) When it is dark (recommended) Shutter speed Slow Fast Noise Less Increased Jitter of the subject Increased Less • For the focus range of flash when [AUTO] is set, refer to P205. •...
Page 164: Setting The Step Increment Of Iso Sensitivity
5. Focus and Brightness (Exposure) Settings Setting the step increment of ISO sensitivity Applicable modes: You can adjust the ISO sensitivity settings for every 1/3 EV. > [Rec] > [ISO Increments] MENU ¢ ¢ ¢ [L.100] /[L.125] /[L.160] /[200]/[250]/[320]/[400]/[500]/[640]/[800]/[1000]/[1250]/ [1/3 EV] [1600]/[2000]/[2500]/[3200]/[4000]/[5000]/[6400]/[8000]/[10000]/[12800]/[16000]/ [20000]/[25600] ¢...
Page 165: Selecting The Method For Measuring Brightness ([Metering Mode])
5. Focus and Brightness (Exposure) Settings Selecting the Method for Measuring Brightness ([Metering Mode]) Applicable modes: Type of optical measurement to measure brightness can be changed. > [Rec] > [Metering Mode] MENU This is the method in which the camera measures the most suitable exposure by judging the allocation of brightness on the whole screen (Multiple) automatically.
Page 166: Shutter And Drive Settings
Shutter and Drive Settings Setting the Shutter Type Applicable modes: You can take pictures using either of the two shutter methods: the Electronic Front Curtain method or the electronic shutter method. Electronic Front Curtain Electronic Shutter The camera starts an exposure The camera starts and ends an Description electronically, and ends it with the...
Page 167 6. Shutter and Drive Settings • When [ ] is displayed on the screen, pictures will be taken with the electronic shutter. • When [Burst Rate] is set to [SH], pictures will be taken with the electronic shutter. • When [Silent Mode] is set to [ON], pictures will be taken with the electronic shutter. •...
Page 168: Select A Drive Mode
6. Shutter and Drive Settings Select a Drive Mode Applicable modes: You can change what the camera will do when you press the shutter button. Press 4 ( 1 2 3 4 Press 2/1 to select the drive mode, and 31/3 then press [MENU/SET].
Page 169: Taking Pictures Using Burst Mode
6. Shutter and Drive Settings Taking Pictures using Burst Mode Applicable modes: Pictures are taken continuously while the shutter button is pressed. • Pictures taken with a burst speed of [SH] will be recorded as a single burst group (P231). Press 4 ( Press 2/1 to select the burst icon ([ 31/3...
Page 170 6. Shutter and Drive Settings • The burst speed may become slower depending on the following settings. – [Picture Size] (P131)/[Quality] (P132)/[Sensitivity] (P162)/Focus Mode (P139)/[Focus/ Release Priority] (P152) • Burst speed can also be set with [Burst Rate] in the [Rec] menu. •...
Page 171 6. Shutter and Drive Settings • When a high ambient temperature, continuous recording or other conditions cause the camera to overheat, the following restrictions will occur to protect the camera. Wait until the camera cools down. – Continuous recording, motion picture recording, and the Wi-Fi connection will be temporarily disabled.
Page 172: Taking Pictures Using Auto Bracket
6. Shutter and Drive Settings Taking Pictures using Auto Bracket Applicable modes: Maximum of 7 pictures will be recorded with different exposure settings following the Exposure Compensation range every time the shutter button is pressed. With Auto Bracket [Step]: [3•1/3], [Sequence]: [0/s/r] 1st picture 2nd picture 3rd picture...
Page 173 6. Shutter and Drive Settings Canceling the Auto Bracket ∫ Select [ ] ([Single]) or [ ] from among the drive modes. (P168) Changing the settings for [Single/Burst Settings], [Step] and [Sequence] in Auto ∫ Bracket Select the menu. (P57) >...
Page 174 6. Shutter and Drive Settings • When taking pictures using Auto Bracket after setting the Exposure Compensation value, the pictures taken are based on the selected Exposure Compensation value. Not available in these cases: • Auto Bracket is disabled in the following cases. –...
Page 175: Taking Pictures With The Self-Timer
6. Shutter and Drive Settings Taking Pictures with the Self-timer Applicable modes: Press 4 ( Press 2/1 to select the self-timer icon 31/3 ], etc.), and then press 3. Press 2/1 to select the time setting for the self-timer, and then press [MENU/SET]. Picture is taken 10 seconds after shutter is pressed.
Page 176 6. Shutter and Drive Settings Press the shutter button halfway to focus and then press it fully to take the picture. • Focus and exposure will be set when the shutter button is pressed halfway. • After the self-timer indicator flashes, recording starts. Canceling the self-timer ∫...
Page 177: Functions Customized For Various Subjects And Purposes
Functions Customized for Various Subjects and Purposes Taking Pictures Automatically at Set Intervals ([Time Lapse Shot]) Applicable modes: If you set the start time of recording, the recording interval and the number of pictures, the camera can automatically take pictures of subjects such as animals or plants as time elapses and create a motion picture.
Page 178 7. Functions Customized for Various Subjects and Purposes • Set the recording interval D so that it will be longer than the exposure time (shutter speed) E. (The figure below) Recording may be skipped when the recording interval D is shorter than the exposure time (shutter speed) E, for example during night-time recording.
Page 179 7. Functions Customized for Various Subjects and Purposes • This function is not for use in a security camera. • If you leave the unit somewhere to perform [Time Lapse Shot], please be careful of theft. • Recording for long periods in cold places such as ski resorts or places at high altitude, or in warm, wet environments may cause a malfunction, so please be careful.
Page 180: Creating Stop Motion Pictures ([Stop Motion Animation])
7. Functions Customized for Various Subjects and Purposes Creating Stop Motion Pictures ([Stop Motion Animation]) Applicable modes: A stop motion picture is created by splicing pictures together. • Set the date and time settings in advance. (P36) • Pictures taken with [Stop Motion Animation] are displayed as a set of group pictures. (P231) Before creating a motion picture with [Stop Motion Animation] With [Stop Motion Animation], you can make a motion picture in which objects appear to...
Page 181 7. Functions Customized for Various Subjects and Purposes Press 3/4 to select the recording method, and then press [MENU/SET]. [ON] Takes pictures automatically at a set recording interval. [Auto When the shutter button is pressed fully, recording starts. Shooting] [OFF] This is for taking pictures manually, frame by frame.
Page 182 7. Functions Customized for Various Subjects and Purposes Select the methods for creating a motion picture. • The recording format is set to [MP4]. Sets the quality of a motion picture. [Rec Quality] [FHD/60p]/[FHD/30p]/[HD/30p]/[VGA/30p] Sets the number of frames per second. The larger the number is, the smoother the motion picture will be.
Page 183 7. Functions Customized for Various Subjects and Purposes • Automatic recording may not take place at set intervals because recording takes time under certain recording conditions, such as when the flash is used for recording. • When a picture quality different from the aspect ratio of the original pictures is selected, black strips will be displayed on the top and bottom or the left and right of the motion picture.
Page 184: Making Multiple Exposures On One Picture ([Multi Exp.])
7. Functions Customized for Various Subjects and Purposes Making Multiple Exposures on One Picture ([Multi Exp.]) Applicable modes: Gives an effect like multi exposure. (up to 4 times equivalent per a single image) Select the menu. (P57) > [Rec] > [Multi Exp.] MENU Press 3/4 to select [Start] and then press [MENU/ SET].
Page 185 7. Functions Customized for Various Subjects and Purposes About Automatic Gain Control setting ∫ Select [Auto Gain] on the screen shown in step and set it. • [ON]: The brightness level is adjusted according to the number of pictures taken and the pictures are superimposed over each other.
Page 186: Disabling Operational Sounds And The Output Of Light At Once ([Silent Mode])
7. Functions Customized for Various Subjects and Purposes Disabling Operational Sounds and the Output of Light at once ([Silent Mode]) Applicable modes: This function is useful for recording images in a quiet environment, public facility, etc. or recording images of subjects such as babies or animals. Select the menu.
Page 187: Taking Clear Pictures By Registering Faces ([Face Recog.])
7. Functions Customized for Various Subjects and Purposes Taking Clear Pictures by Registering Faces ([Face Recog.]) Applicable modes: Face Recognition is a function which finds a face resembling a registered face and prioritizes focus and exposure automatically. Even if the person is located towards the back or on the end of a line in a group photo, the camera can still take a clear picture.
Page 188 7. Functions Customized for Various Subjects and Purposes • [Face Recog.] only works when the AF Mode is set to [š]. • During the Burst Mode, [Face Recog.] picture information can be attached to only the first picture. • When group pictures are played back, the name of the first picture of the set is displayed. •...
Page 189 7. Functions Customized for Various Subjects and Purposes Face Settings You can register information such as names and birthdays for face images of up to 6 people. Point of recording when registering the face images ∫ (Good example for registering) •...
Page 190 7. Functions Customized for Various Subjects and Purposes Set the item. • You can register up to 3 face images. It is possible to register names. 1 Press 4 to select [SET] and then press [MENU/SET]. [Name] 2 Enter the name. •...
Page 191 7. Functions Customized for Various Subjects and Purposes Change or delete the information for a registered person You can modify the pictures or information of an already registered person. You can also delete the information of the registered person. Press 4 to select [MEMORY] and press [MENU/SET]. Press 3/4/2/1 to select the face image to edit or delete and then press [MENU/SET].
Page 192: Recording Profiles Of Babies And Pets On Images
7. Functions Customized for Various Subjects and Purposes Recording Profiles of Babies and Pets on Images Applicable modes: If you set the name and birthday of your baby or pet in advance, you can record their name and age in months and years in the images. You can display these at playback or stamp the recorded images using [Text Stamp] (P242).
Page 193: Using Screens And Displays Suitable For Recording
7. Functions Customized for Various Subjects and Purposes Using screens and displays suitable for recording Checking areas that may be white saturated ([Zebra Pattern]) Applicable modes: You can check areas that may be white saturated by displaying areas above a certain luminance level in a zebra pattern.
Page 194 7. Functions Customized for Various Subjects and Purposes Displaying the recording screen in black and white ([Monochrome Live View]) Applicable modes: You can display the recording screen in black and white. This function is convenient when a black and white screen will make it easier to set focus with Manual Focus. >...
Page 195: Stabilizer, Zoom And Flash
Stabilizer, Zoom and Flash Optical Image Stabilizer Applicable modes: The camera detects jitter during recording and automatically corrects it, so you can record images with reduced jitter. A lens which supports the stabilizer function is required. • The interchangeable lens (H-FS12032/H-FS35100) supports the Optical Image Stabilizer function.
Page 196 8. Stabilizer, Zoom and Flash Preventing jitter (camera shake) When the jitter alert [ ] appears, use [Stabilizer], a tripod or the self-timer (P175). • Shutter speed will be slower particularly in the following cases. Keep the camera still from the moment the shutter button is pressed until the picture appears on the screen.
Page 197: Taking Pictures With The Zoom
8. Stabilizer, Zoom and Flash Taking Pictures with the Zoom Optical zoom Applicable modes: You can zoom-in to make people and objects appear closer or zoom-out to record landscapes, etc. T side: Enlarges distant subject W side: Widens angle of view Rotate the zoom ring.
Page 198: Raising The Telescopic Effect
8. Stabilizer, Zoom and Flash Raising the telescopic effect [Ex. Tele Conv.] Applicable modes: The Extended Tele Conversion enables you to take pictures that are further enlarged without deteriorating the picture quality. 1.2k: [ M] ([16:9]) [Ex. Tele Conv.] When taking pictures 1.4k: [ M] ([4:3]/[3:2]/[1:1]) ([Rec])
Page 199 8. Stabilizer, Zoom and Flash Increasing the zoom magnification in steps ∫ • This can be used only when recording pictures. Select the menu. (P57) > [Rec] > [Ex. Tele Conv.] > [ZOOM] MENU Set a function button to [Zoom Control]. (P64) •...
Page 200 8. Stabilizer, Zoom and Flash • When the Extended Tele Conversion is used, angle of view for still pictures will be different from the angle of view for motion pictures because the zoom factor is different between them. Angle of view for recording can be checked beforehand by matching the [Rec Area] (P215) setting to the mode you wish to record in.
Page 201 8. Stabilizer, Zoom and Flash Changing the settings for a power zoom lens Applicable modes: Sets the screen display and lens operations when using an interchangeable lens that is compatible with power zoom (electrically operated zoom). This may only be selected when using a lens that is compatible with power zoom (electrically operated zoom).
Page 202: Zooming Using Touch Operations
8. Stabilizer, Zoom and Flash Zooming using touch operations You can perform zoom operations by touching. (Touch zoom) (Optical Zoom and Extended Tele Conversion for still picture recording are operable) • If you are using an interchangeable lens not supporting power zoom (H-FS12032/H-FS35100/ H-X015), you can only operate the Extended Tele Conversion for pictures by setting [Ex.
Page 203: Taking Pictures With The Flash (Supplied)
8. Stabilizer, Zoom and Flash Taking Pictures with the Flash (Supplied) Applicable modes: To take pictures with the camera using a flash, attach an external flash. Please note that this section provides instructions based on the flash (supplied). • For information on other external flashes, refer to P324. Removing the Hot Shoe Cover ∫...
Page 204 8. Stabilizer, Zoom and Flash Forcing the flash off ([Œ]) In situations where pictures cannot be taken with the flash, such as when the flash (supplied) is turned off or when you are recording a motion picture, [ Œ ] (forced flash off) is displayed on the recording screen and the flash does not fire.
Page 205 8. Stabilizer, Zoom and Flash The available flash range (approximation) ∫ When you use certain lenses, light from the flash may be blocked or fail to cover the lens field of view, causing dark areas to appear in the resulting pictures. The distance at which light from the flash is blocked by lens, and the distance to which light from the flash is delivered vary depending on the lens used.
Page 206: Setting The Flash Functions
8. Stabilizer, Zoom and Flash Setting the Flash Functions • [Flash] in the [Rec] menu is available only when an external flash is attached. Changing the firing mode Applicable modes: Select whether to set the flash output automatically or manually. Select the menu.
Page 207: Changing Flash Mode
8. Stabilizer, Zoom and Flash Changing Flash Mode Applicable modes: Set the flash to match the recording. Select the menu. (P57) > [Rec] > [Flash] > [Flash Mode] MENU Press 3/4 to select the item and then press [MENU/SET]. The flash is activated every time regardless of the recording conditions.
Page 208 8. Stabilizer, Zoom and Flash Available flash settings by Recording Mode [When the flash (supplied) is attached] ∫ The available flash settings depend on the Recording Mode. (±: Available, —: Not available, ¥: Initial setting of Scene Guide Mode) Recording Mode ‰...
Page 209: Setting To The 2Nd Curtain Synchro
8. Stabilizer, Zoom and Flash Shutter speed for each flash setting ∫ Flash setting Shutter speed (Sec.) Flash setting Shutter speed (Sec.) ‰ 1/50th ¢1 1 to 1/16000th ¢2 to 1/16000th Œ ¢1 In Shutter Priority AE Mode, the shutter speed can be set to a value between 60 seconds and 1/50th of a second;...
Page 210: Adjust The Flash Output
8. Stabilizer, Zoom and Flash Adjust the flash output Applicable modes: Adjust the flash brightness when pictures taken with the flash are over or underexposed. Select the menu. (P57) > [Rec] > [Flash] > [Flash Adjust.] MENU Press 2/1 to set the flash output and then press [MENU/SET]. •...
Page 211: Taking Pictures With Wireless Flashes
8. Stabilizer, Zoom and Flash Taking Pictures with Wireless Flashes Applicable modes: By using flashes that support wireless recording (DMW-FL360L/DMW-FL580L: optional), you can separately control the firing of three flash groups and the flash attached to the hot shoe of the camera. •...
Page 212 8. Stabilizer, Zoom and Flash Preparations: Attach the flash (supplied) or a flash (DMW-FL360L/DMW-FL580L: optional) to the camera. Set the wireless flashes to RC Mode and then place them. • Set a channel and groups for the wireless flash. Select the menu. (P57) >...
Page 213 8. Stabilizer, Zoom and Flash [Firing Mode] [TTL]: The camera automatically sets the output. [AUTO]: ¢ Flash output is set by the external flash. [MANUAL]: Set the luminosity ratio of the external flash manually. [OFF]: The flash on the camera side emits only communication light. [External [Flash Adjust.] Flash]...
Page 214: Recording Motion Pictures
Recording Motion Pictures Recording Motion Picture Applicable modes: This camera can record full high definition motion pictures compatible with the AVCHD format or motion pictures recorded in MP4. Audio will be recorded in stereo. The functions available when recording motion pictures differ according to the lens you are using, and the operational sound of the lens may be recorded.
Page 215 9. Recording Motion Pictures Enabling/disabling the motion picture button > [Custom] > [Video Button] > [ON]/[OFF] MENU • This function is for preventing accidental operation of the button. Switching between the angle of view for taking pictures and the one for recording motion pictures >...
Page 216 9. Recording Motion Pictures • When a high ambient temperature, continuous recording or other conditions cause the camera to overheat, the following restrictions will occur to protect the camera. Wait until the camera cools down. – Continuous recording, motion picture recording, and the Wi-Fi connection will be temporarily disabled.
Page 217: Setting The Format, Size And Recording Frame Rate
9. Recording Motion Pictures Setting the format, size and recording frame rate Applicable modes: Select the menu. (P57) > [Motion Picture] > [Rec Format] MENU Press 3/4 to select the item and then press [MENU/SET]. This data format is suitable for when playing back on a high-definition [AVCHD] TV, etc.
Page 218 9. Recording Motion Pictures When [MP4] is selected Recording frame Item Size Sensor output Bit rate rate 1920k1080 28 Mbps [FHD/28M/60p] 60 frames/second 1920k1080 20 Mbps [FHD/20M/30p] 30 frames/second 1280k720 10 Mbps [HD/10M/30p] 640k480 4 Mbps [VGA/4M/30p] • What is bit rate This is the volume of data for a definite period of time, and the quality becomes higher when the number gets bigger.
Page 219: How To Set Focus When Recording A Motion Picture ([Continuous Af])
9. Recording Motion Pictures How to set focus when recording a motion picture ([Continuous AF]) Applicable modes: Focusing changes depending on the Focus Mode setting (P139) and the [Continuous AF] setting in the [Motion Picture] menu. [Continuous Focus mode Description of settings The camera automatically keeps focusing on subjects [ON] during recording.
Page 220: Recording Still Pictures While Recording Motion Pictures
9. Recording Motion Pictures Recording still pictures while recording motion pictures Applicable modes: Still pictures can be recorded even while recording a motion picture. (Simultaneous recording) During motion picture recording, press the shutter button fully to record a still picture. •...
Page 221: Recording Snap Movies
Motion pictures will be recorded with [FHD/20M/30p] in [MP4]. • Using the smartphone/tablet app “Panasonic Image App”, you can combine motion pictures recorded with the camera. Music can be added and various editing operations can be performed when you combine them. In addition, you can send the combined motion picture to a web service.
Page 222 9. Recording Motion Pictures Start recording by pressing the motion SNAP picture button. 4SEC A Elapsed recording time B Set recording time • Release the motion picture button right after you press it. • You cannot stop motion picture recording in the middle.The recording will stop automatically when the set recording time has elapsed.
Page 223 9. Recording Motion Pictures Setting up [Pull Focus] Set the frames that determine a focus start (first) position and focus end (second) position. The camera then measures its distance to the subjects and sets focus. When you start motion picture recording, focus shifts from the first frame to the second frame.
Page 224: Using The [Motion Picture] Menu
9. Recording Motion Pictures Using the [Motion Picture] Menu For details on [Motion Picture] menu settings, refer to P57. • [Photo Style], [Filter Settings], [AFS/AFF], [Metering Mode], [Highlight Shadow], [i.Dynamic], [i.Resolution] and [Digital Zoom] are common to both the [Rec] menu and [Motion Picture] menu.
Page 225: [Silent Operation]
9. Recording Motion Pictures [Silent Operation] • Refer to P119 for details. [Mic Level Disp.] Applicable modes: Set whether or not the mic levels are displayed on the screen. Settings: [ON]/[OFF] Not available in these cases: • This function is not available in the following case: –...
Page 226: Playing Back And Editing Images
Playing Back and Editing Images Playing Back Pictures Press [(]. Press 2/1. 1/98 1/98 1/98 1/98 2: Play back the previous picture 1: Play back the next picture • If you press and hold 2/1, you can play back the pictures in succession.
Page 227: Playing Back Motion Pictures
10. Playing Back and Editing Images Playing Back Motion Pictures This unit was designed to play motion pictures using the AVCHD, MP4 and QuickTime Motion JPEG formats. • Motion pictures are displayed with the motion picture icon Press 3 to play back. A Motion picture recording time •...
Page 228: Creating Still Pictures From A Motion Picture
10. Playing Back and Editing Images Operations during automatic Snap Movie playback ∫ Playback from the beginning Back to previous picture Ahead to next picture • If you touch the screen, automatic playback will stop. • To play back the motion pictures recorded by this unit on a PC, use the “PHOTOfunSTUDIO” software on the DVD (supplied).
Page 229: Switching The Playback Method
10. Playing Back and Editing Images Switching the Playback Method Using the Playback Zoom Rotate the rear dial right. 2.0X 2.0X 2.0X 2.0X • If the rear dial is rotated to the left after the image is enlarged, the magnification will be reduced. •...
Page 230: Displaying Multiple Screens (Multi Playback)
10. Playing Back and Editing Images Displaying multiple screens (Multi Playback) Rotate the rear dial left. 1/98 1 screen 12 screens 30 screens Calendar screen display • If the rear dial is rotated to the right, the previous playback screen will be displayed. •...
Page 231: Playing Back Group Pictures
10. Playing Back and Editing Images Playing Back Group Pictures A picture group consists of multiple pictures. You can play back pictures in a group either continuously or one by one. • You can edit or delete all pictures in a group at once. (For example, if you delete a picture group, all pictures in the group are deleted.) A picture group consisting of pictures taken in the Burst 1/98...
Page 232 10. Playing Back and Editing Images Playing back each Group Pictures Press 4. • The same operation can be performed by touching 1/98 1/98 1/98 1/98 MENU Press 3/4 to select [Display In Group], and then press [MENU/SET]. MENU Press 2/1 to flip through images. •...
Page 233: Deleting Pictures
10. Playing Back and Editing Images Deleting Pictures Once deleted, pictures cannot be recovered. • Pictures that are not in the DCF standard or those that are protected cannot be deleted. To delete a single picture In Playback Mode, select the picture to delete and then press [ ].
Page 234 10. Playing Back and Editing Images To delete multiple pictures (up to 100 ¢ ) or all the pictures ¢ Picture groups are treated as a single picture. (All the pictures in the selected picture group will be deleted.) In Playback Mode, press [ ]. Press 3/4 to select [Delete Multi] or [Delete All] and then press [MENU/SET].
Page 235: Using The [Playback] Menu
10. Playing Back and Editing Images Using the [Playback] Menu With this menu, you can use various playback functions such as cropping and other editing of recorded images, protect settings, etc. • With [Clear Retouch], [Text Stamp], [Time Lapse Video], [Stop Motion Video], [Resize] or [Cropping], a new edited picture is created.
Page 236 10. Playing Back and Editing Images Operations during a slideshow ∫ Button Touch Description of Button Touch Description of operation operation operation operation operation operation Play/Pause Exit slide show Back to previous Ahead to next picture picture Increase volume Reduce volume level level •...
Page 237: [Playback Mode]
10. Playing Back and Editing Images [Playback Mode] Playback in [Normal Play], [Picture Only], [Video Only], [3D Play], [Category Play] or [Favorite Play] can be selected. Select the menu. (P57) > [Playback] > [Playback Mode] MENU Select the group to play back by pressing 3/4, and then press [MENU/SET]. •...
Page 238: [Location Logging]
• You can send location information and write it on images using a smartphone. (P268) • You need to install “Panasonic Image App” on your smartphone. (P261) • Read the [Help] in the “Image App” menu for further details on how to operate.
Page 239: [Clear Retouch]
10. Playing Back and Editing Images [Clear Retouch] You can erase unnecessary parts recorded on the pictures taken. • The erasure operation can only be performed by touching. [Clear Retouch] automatically enables the touch operation. Select the menu. (P57) > [Playback] >...
Page 240 10. Playing Back and Editing Images • Pictures may appear unnatural because the background of deleted parts is artificially created. • For group pictures, perform [Clear Retouch] on each picture. (They cannot be edited at once.) • When [Clear Retouch] is performed on group pictures, they are saved as new pictures separate from the original ones.
Page 241: [Title Edit]
10. Playing Back and Editing Images [Title Edit] You can add text (comments) to pictures. After text has been registered, it can be stamped in prints using [Text Stamp] (P242). Select the menu. (P57) > [Playback] > [Title Edit] > [Single]/[Multi] MENU Select the picture.
Page 242: [Text Stamp]
10. Playing Back and Editing Images [Text Stamp] You can stamp the recording date/time, name, location, travel date or title onto the recorded pictures. LISA LISA LISA Select the menu. (P57) > [Playback] > [Text Stamp] > [Single]/[Multi] MENU Select the picture. •...
Page 243 10. Playing Back and Editing Images Press 3/4 to select text stamp items, and then press [MENU/SET]. Press 3/4 to select the settings, and then press [MENU/SET]. [W/O TIME]: Stamp the year, month and date. [Shooting Date] [WITH TIME]: Stamp the year, month, day, hour and minutes. [OFF] ([Face Recognition]):...
Page 244 10. Playing Back and Editing Images • When you print pictures stamped with text, the date will be printed over the stamped text if you specify printing of the date at the photo shop or on the printer. • You can set up to 100 pictures at one time in [Multi]. •...
Page 245: [Video Divide]
10. Playing Back and Editing Images [Video Divide] Recorded motion picture can be divided in two. It is recommended for when you want to divide a part you need with a part you do not need. Dividing a motion picture is permanent. Decide before you divide! Select the menu.
Page 246: [Time Lapse Video]
10. Playing Back and Editing Images [Time Lapse Video] This function allows you to create a motion picture from a picture group recorded with [Time Lapse Shot]. The created motion picture is saved in MP4 recording format. Select the menu. (P57) >...
Page 247: [Resize]
10. Playing Back and Editing Images [Resize] To allow easy posting to web pages, attachment to e-mail etc., picture size (number of pixels) is reduced. Select the menu. (P57) > [Playback] > [Resize] > [Single]/[Multi] MENU Select the picture and size. [Single] setting 1 Press 2/1 to select the picture, and then press [MENU/SET].
Page 248 10. Playing Back and Editing Images • You can set up to 100 pictures at one time in [Multi]. • The picture quality of the resized picture will deteriorate. Not available in these cases: • This function is not available in the following cases: –...
Page 249: [Cropping]
10. Playing Back and Editing Images [Cropping] You can enlarge and then clip the important part of the recorded picture. Select the menu. (P57) > [Playback] > [Cropping] MENU Press 2/1 to select the picture, and then press [MENU/SET]. Use the rear dial and press 3/4/2/1 to select the parts to be cropped. Rear dial (right): Enlargement Rear dial (left): Reduction 3/4/2/1: Move...
Page 250: [Rotate]/[Rotate Disp.]
10. Playing Back and Editing Images [Rotate]/[Rotate Disp.] This mode allows you to automatically display pictures vertically if they were recorded holding the camera vertically or rotate pictures manually in 90o steps. [Rotate] (The picture is rotated manually) • The [Rotate] function is disabled when [Rotate Disp.] is set to [OFF]. Select the menu.
Page 251: [Favorite]
10. Playing Back and Editing Images [Favorite] You can do the following if a mark has been added to pictures and they have been set as favorites. • Play back the pictures set as favorites only as a slide show. •...
Page 252: [Print Set]
For details, ask at your photo printing store. When you set [Print Set] for a group pictures, the print setting for the number of prints will be applied to every picture in the group. For more information visit: http://panasonic.jp/dc/dpof_110/white_e.htm Select the menu. (P57) >...
Page 253 10. Playing Back and Editing Images Canceling all the [Print Set] settings ∫ Select the menu. (P57) > [Playback] > [Print Set] > [Cancel] MENU • Confirmation screen is displayed. It is executed when [Yes] is selected. Exit the menu after it is executed. To print the date ∫...
Page 254: [Protect]
10. Playing Back and Editing Images [Protect] You can set protection for pictures you do not want to delete by mistake. Select the menu. (P57) > [Playback] > [Protect] > [Single]/[Multi] MENU Select the picture. [Single] setting Press 2/1 to select the picture, and then press [MENU/SET].
Page 255: [Face Rec Edit]
10. Playing Back and Editing Images [Face Rec Edit] You can clear and replace all information relating to face recognition in selected images. Select the menu. (P57) > [Playback] > [Face Rec Edit] > [REPLACE]/[DELETE] MENU Press 2/1 to select the picture and then press [MENU/SET]. Press 2/1 to select the person and then press [MENU/SET].
Page 256: [Delete Confirmation]
10. Playing Back and Editing Images [Delete Confirmation] This sets which option, [Yes] or [No], will be highlighted first when the confirmation screen for deleting a picture is displayed. Select the menu. (P57) > [Playback] > [Delete Confirmation] MENU Press 3/4 to select an item and then press [MENU/SET]. [“Yes”...
Page 257: Using The Wi-Fi Function
There is the risk that the camera violates the radiowave regulations if used in countries other than those where this camera is sold, and Panasonic takes no responsibility for any violations. There is the risk that data sent and received via radio waves may be intercepted ∫...
Page 258 11. Using the Wi-Fi function About the Wi-Fi connection lamp ∫ Lit blue: The Wi-Fi connection is on standby Blinking blue: Sending/receiving data through the Wi-Fi connection About the [Wi-Fi] button ∫ [Wi-Fi]/[Fn1] button can be used in two ways, as [Wi-Fi] or as [Fn1] (function 1).
Page 259 11. Using the Wi-Fi function Describing method ∫ When “select [Select a destination from History]”, etc. is described in a step, perform any of the following operations. Button operation: Select [Select a destination from History] with the cursor button, and then press [MENU/SET].
Page 260: What You Can Do With The Wi-Fi Function
11. Using the Wi-Fi function What you can do with the Wi-Fi function Controlling with a Smartphone/Tablet (P261) Recording with a smartphone (P266) Playing back pictures in the camera (P267) Saving images stored in the camera (P267) Sending images to an SNS (P268) Writing location information on images stored in the camera (P268) Combining motion pictures recorded with Snap Movie according to your preference on a smartphone/tablet (P270)
Page 261: Controlling With A Smartphone/Tablet
Connect the smartphone to a network. (Android) Select “Google Play Store”. (iOS) Select “App Store ”. Enter “Panasonic Image App” or “LUMIX” into the search box. Select “Panasonic Image App” and install it. • Use the latest version. • Supported OSs are current as of September 2014 and are subject to change.
Page 262: Connecting To A Smartphone/Tablet
11. Using the Wi-Fi function Connecting to a smartphone/tablet By pressing and holding [Wi-Fi], you can easily establish a connection. Preparations • Install the “Image App” in advance. (P261) Press and hold [Wi-Fi] on the camera. • The information required for connecting the smartphone to this unit (QR code, SSID and password) is displayed.
Page 263 If the smartphone is locked with a passcode, enter the IMAGE APP passcode to unlock the smartphone. Panasonic Corporation 5 Press the home button to close the browser. 6 Turn on the Wi-Fi function in the setting menu of the smartphone.
Page 264 11. Using the Wi-Fi function When using an SSID and password to set up a connection 1 Turn on the Wi-Fi function in the setting menu of the smartphone. 2 Select the SSID displayed on the screen of the camera. Wi-Fi 0123456789ABC 3 Enter the password displayed on the screen of the...
Page 265 11. Using the Wi-Fi function Changing the connection method ∫ To change the connection method, press [DISP.], and then select the connection method. When connecting with [Via Network]: On the camera Select [Via Network]. • Follow the connection procedure described on P295 to connect the camera to a wireless access point.
Page 266: Taking Images Via A Smartphone/Tablet (Remote Recording)
11. Using the Wi-Fi function Taking images via a smartphone/tablet (remote recording) Connect to a smartphone. (P262) Operate the smartphone. 1 Select [ 2 Record an image. • The recorded images are saved in the camera. • Some settings are not available. •...
Page 267: Playing Back Images In The Camera
11. Using the Wi-Fi function Playing back images in the camera Connect to a smartphone. (P262)  Operate the smartphone. 1 Select [ • You can switch the images to be displayed by selecting the icon (A) on the top left of the screen. To ...
Page 268: Sending Images In The Camera To An Sns
11. Using the Wi-Fi function Sending images in the camera to an SNS Connect to a smartphone. (P262)  Operate the smartphone. 1 Select [ • You can switch the images to be  displayed by selecting the icon ( A ) on the top left of the screen.
Page 269 11. Using the Wi-Fi function Operate the smartphone ∫ Select [ Select [Geotagging]. Select an icon. Start recording location information. Finish recording the location information. Sending and writing location information. • Follow the on-screen messages to operate the smartphone. • Location information is not written onto the images recorded when [Rec Format] is set to [AVCHD].
Page 270: Combining Motion Pictures Recorded With Snap Movie According To Your Preference On A Smartphone/Tablet
11. Using the Wi-Fi function Combining motion pictures recorded with Snap Movie according to your preference on a smartphone/tablet Using a smartphone, you can combine motion pictures recorded with the camera’s [Snap Movie] function (P221). Music can be added to motion pictures to be combined. In addition, you can save combined motion picture or upload it on a web service.
Page 271: Sending Images To A Smartphone/Tablet By Controlling The Camera
11. Using the Wi-Fi function Sending images to a smartphone/tablet by controlling the camera Methods for sending and images that can be sent ∫ JPEG AVCHD Sending an image each time a recording is made ± — — — — ([Send Images While Recording]) Select and send the images —...
Page 272 11. Using the Wi-Fi function Sending an image each time a recording is made ([Send Images While Recording]) Select the menu. > [New Connection] > [Send Images While Recording] > Wi-Fi [Smartphone] Select [Via Network] or [Direct], and connect. (P294) On your smartphone When connecting with [Via Network]: 1 Turn on the Wi-Fi function.
Page 273 11. Using the Wi-Fi function Select and send the images ([Send Images Stored in the Camera]) Select the menu. > [New Connection] > [Send Images Stored in the Camera] > Wi-Fi [Smartphone] Select [Via Network] or [Direct], and connect. (P294) On your smartphone When connecting with [Via Network]: 1 Turn on the Wi-Fi function.
Page 274: Displaying Pictures On A Tv
11. Using the Wi-Fi function Displaying pictures on a TV You can display pictures on a TV that supports the Digital Media Renderer (DMR) function of the DLNA standard. Preparations Set the TV to DLNA waiting mode. • Read the operating instructions for your TV. Select the menu.
Page 275: Printing Wirelessly
11. Using the Wi-Fi function Printing Wirelessly You can send images to a compatible printer, and print them wirelessly. Methods for sending and images that can be sent ∫ JPEG AVCHD Select and send the images — — — — ±...
Page 276: When Sending Images To Av Device
11. Using the Wi-Fi function When sending images to AV device You can send pictures and motion pictures to AV devices in your house (home AV devices). A Wireless access point B Home AV device Methods for sending and images that can be sent ∫...
Page 277 11. Using the Wi-Fi function Sending an image each time a recording is made ([Send Images While Recording]) Select the menu. > [New Connection] > [Send Images While Recording] > [AV device] Wi-Fi Select [Via Network] or [Direct], and connect. (P294) Select a device you want to connect.
Page 278: When Sending Images To Pc
11. Using the Wi-Fi function When sending images to PC You can send pictures and motion pictures recorded with this unit to a PC. Methods for sending and images that can be sent ∫ ¢ JPEG AVCHD Sending an image each time a recording is made —...
Page 279 11. Using the Wi-Fi function To create a folder that receives images • Create a PC user account [account name (up to 254 characters) and password (up to 32 characters)] consisting of alphanumeric characters. An attempt to create a receive folder may fail if the account includes non-alphanumeric characters.
Page 280 11. Using the Wi-Fi function Sending an image each time a recording is made ([Send Images While Recording]) Select the menu. > [New Connection] > [Send Images While Recording] > [PC] Wi-Fi Select [Via Network] or [Direct], and connect. (P294) Select the PC you want to connect to.
Page 281 11. Using the Wi-Fi function Select and send the images ([Send Images Stored in the Camera]) Select the menu. > [New Connection] > [Send Images Stored in the Camera] > [PC] Wi-Fi Select [Via Network] or [Direct], and connect. (P294) Select the PC you want to connect to.
Page 282: Using Web Services
11. Using the Wi-Fi function Using Web services You can send pictures and motion pictures to an SNS, etc. via “LUMIX CLUB”. By setting up automatic transfers of pictures and motion pictures to the Cloud Sync Service, you can receive the transferred pictures or motion pictures on a PC or smartphone.
Page 283: When Sending Images To Web Service
Check this information before uploading images to web services. • Panasonic assumes no responsibility for the damages resulting from the leakage, loss, etc. of images uploaded on web services. •...
Page 284 “LUMIX CLUB”. (P289) • Check the “FAQ/Contact us” on the following site for compatible web services. http://lumixclub.panasonic.net/eng/c/lumix_faqs/ Preparation: Make sure that you have created an account on the web service you want to use, and have the login information available.
Page 285 11. Using the Wi-Fi function Select and send the images ([Send Images Stored in the Camera]) Select the menu. > [New Connection] > [Send Images Stored in the Camera] > [Web Wi-Fi service] Select [Via Network], and connect. (P295) Select a web service. Check the send settings, and select [Set].
Page 286 11. Using the Wi-Fi function Sending images in the camera to a web service with simple operations ∫ Once you send an image, you can send other images to a web service with simple, smartphone-like operations in an environment where a wireless access point connection is available.
Page 287: When Sending Images To [Cloud Sync. Service]
11. Using the Wi-Fi function When sending images to [Cloud Sync. Service] Using [Cloud Sync. Service] (As of September 2014) ∫ Preparations You need to register to “LUMIX CLUB” (P289) and configure the Cloud Sync. setting to send a picture to a Cloud Folder. For a PC, use “PHOTOfunSTUDIO”...
Page 288 11. Using the Wi-Fi function Sending an image each time a recording is made ([Send Images While Recording]) Select the menu. > [New Connection] > [Send Images While Recording] > [Cloud Wi-Fi Sync. Service] Select [Via Network], and connect. (P295) Check the send settings, and select [Set].
Page 289: Registering To The "Lumix Club
You can set the same “LUMIX CLUB” login ID for this unit and a smartphone. (P292) Refer to the “LUMIX CLUB” site for details. http://lumixclub.panasonic.net/eng/c/ Please note: • The service may be suspended due to regular maintenance or unexpected troubles, and the service contents may be changed or added, without prior notice to the users.
Page 290 11. Using the Wi-Fi function Read through the “LUMIX CLUB” terms of use and select [Agree]. • You can switch pages by 3/4. • You can enlarge (2k) the display by rotating the rear dial to the right. • You can reset the enlarged display to its original size (1k) by rotating the rear dial to the left.
Page 291 11. Using the Wi-Fi function Using the acquired login ID/Checking or changing the login ID or password ([Set Login ID]) Preparation: When using the acquired login ID, check the ID and password. To change the “LUMIX CLUB” password on the camera, access the “LUMIX CLUB” website from your smartphone or PC and change the “LUMIX CLUB”...
Page 292 11. Using the Wi-Fi function To set the same login ID for the camera and the smartphone/tablet • Setting the same login ID on this unit and your smartphone is convenient for sending images on this unit to other devices or web services. When either this unit or the smartphone/tablet has acquired the login ID: Connect this unit to the smartphone.
Page 293 11. Using the Wi-Fi function Delete your login ID and account from the “LUMIX CLUB” Delete the login ID from the camera when transferring it to another party or disposing of it. You can also delete your “LUMIX CLUB” account. Select the menu.
Page 294: About Connections
11. Using the Wi-Fi function About Connections You can select a connection method after selecting a Wi-Fi function and a destination. Performing a direct connection is convenient for when you are in a place away from home where wireless access points are not available or for when connecting temporarily to a device you do not usually use.
Page 295: Connecting From Your House (Via The Network)
11. Using the Wi-Fi function Connecting from your house (via the network) You can select the method for connecting to a wireless access point. ¢ WPS refers to a function that allows you to easily configure the settings related to the connection and security of wireless LAN devices.
Page 296 11. Using the Wi-Fi function If you are not sure about the WPS compatibility (connecting by [From List]) Search for available wireless access points. • Confirm encryption key of the selected wireless access point if the network authentication is encrypted. •...
Page 297: Connecting From A Location Away From Your House (Direct Connection)
11. Using the Wi-Fi function • Check the wireless access points instruction manual and settings when saving a wireless access point. • If no connection can be established, the wireless access point’s radio waves may be too weak. “ ” “...
Page 298: Connecting Quickly With The Same Settings As The Previous Ones ([Select A Destination From History]/[Select A Destination From Favorite])
11. Using the Wi-Fi function Connecting quickly with the same settings as the previous ones ([Select a destination from History]/[Select a destination from Favorite]) When the Wi-Fi function is used, a record is saved in the history. You can register records as favorites.
Page 299 11. Using the Wi-Fi function Editing the items registered to favorites Press [Wi-Fi]. Select [Select a destination from Favorite]. Select the favorite item you want to edit, and then press 1. Select the item. [Remove from Favorite] — [Change the Order in Select the destination.
Page 300: About Settings For Sending Images
11. Using the Wi-Fi function About settings for sending images When sending images, select the method for sending them after selecting [New Connection]. After the connection has been completed, settings for sending, such as the image size for sending, can also be changed. Images that can be sent ∫...
Page 301 11. Using the Wi-Fi function Send Images While Recording A picture can be automatically sent to a specified device every time you take it. • Since the camera gives priority to recording, sending may take longer during the recording. • When connected with [Send Images While Recording], [ is displayed on the recording screen, and [ ] is displayed...
Page 302 11. Using the Wi-Fi function Changing the settings for sending images Pressing [DISP.] after completing a connection allows you to change the settings for sending such as the image size for sending. Resize the image to send. [Original]/[Auto] ¢1 /[Change] •...
Page 303: [Wi-Fi Setup] Menu
11. Using the Wi-Fi function [Wi-Fi Setup] Menu Configure the settings required for the Wi-Fi function. The settings cannot be changed when connected to Wi-Fi. Select the menu. (P57) > [Setup] > [Wi-Fi] > [Wi-Fi Setup] > Desired item to be set MENU [LUMIX CLUB] Acquires or changes the “LUMIX CLUB”...
Page 304 11. Using the Wi-Fi function To prevent incorrect operation or use of the Wi-Fi function by a third party and to protect saved personal information, it is recommended that you protect the Wi-Fi function with a password. Setting a password will automatically display the password input [Wi-Fi Password] screen when the Wi-Fi function is used.
Page 305: Connecting To Other Equipment
Connecting to other equipment Enjoying 3D pictures Taking 3D pictures Attaching the 3D interchangeable lens (H-FT012: optional) to the camera allows you to take 3D pictures for extra impact. To view 3D pictures, a television that supports 3D is required. Attach the 3D interchangeable lens to the camera.
Page 306 If your television does not switch to a 3D picture, make the necessary settings on the TV. (For details, refer to the operating instructions of the TV.) • 3D pictures can be saved to your computer or Panasonic devices. (P312, 317)
Page 307: Recording Functions
12. Connecting to other equipment Functions that cannot be used on 3D pictures Functions that cannot be used during 3D recording ∫ When recording with the 3D interchangeable lens (H-FT012: optional), the following feature will be disabled: (Recording functions) • •...
Page 308: Playing Back Pictures On A Tv Screen
12. Connecting to other equipment Playing Back Pictures on a TV Screen Pictures recorded with this unit can be played back on a TV screen. Preparations: Turn this unit and the TV off. • Confirm the terminals on your TV and HDMI Video use a cable compatible with the...
Page 309 12. Connecting to other equipment To connect with an AV cable (optional) • Always use a genuine Panasonic AV cable (DMW-AVC1: optional). • Check the [TV Aspect]. (P70) • Audio will be played back in monaural. • The viewfinder cannot be displayed when connected with a AV cable.
Page 310: Using Viera Link (Hdmi)
What is the VIERA Link (HDMI) (HDAVI Control™)? • This function allows you to use your remote control for the Panasonic TV for easy operations when this unit has been connected to a VIERA Link compatible device using a HDMI micro cable for automatic linked operations.
Page 311: Automatic Input Switching
Available linked operations between this unit and a Panasonic TV are different depending on the types of Panasonic TVs even if they are compatible with VIERA Link. Refer to the operating instructions of the TV for the operations are supported on the TV.
Page 312: Saving Still Pictures And Motion Pictures On Your Pc
(Doing so will cause recorded images to be erased so do not choose to format.) If the card is not recognized, please refer to the below support site. http://panasonic.net/avc/sdcard/information/SDXC.html PC that can be used ∫...
Page 313: About The Supplied Software
12. Connecting to other equipment About the supplied software The supplied DVD includes the following software. Install the software on to your computer before use. • PHOTOfunSTUDIO 9.6 PE (Windows Vista/Windows 7/Windows 8/Windows 8.1) This software allows you to manage images. For example, you can send pictures and motion pictures to a PC and sort them by recording date or model name.
Page 314 12. Connecting to other equipment Installing supplied software ∫ • Before inserting the DVD, close all running applications. Check the environment of your PC. • Operating environment of “PHOTOfunSTUDIO” – Windows Vista (32bit) SP2, Windows 7 (32bit/64bit) or SP1, Windows 8 (32bit/64bit), Windows 8.1 (32bit/64bit)
Page 315 Do not connect devices to incorrect terminals. Doing so may cause malfunction. • Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB connection cable (DMW-USBC1: optional). A USB connection cable (supplied) B Align the marks, and insert.
Page 316 12. Connecting to other equipment Copying to a PC without using “PHOTOfunSTUDIO ” ∫ If you are not able to install “PHOTOfunSTUDIO”, you can copy files and folders to your PC by dragging and dropping files from this unit. • The content (folder structure) on the card of this unit is as follows.
Page 317: Saving Still Pictures And Motion Pictures On A Recorder
Saving still pictures and motion pictures on a Recorder If you insert card holding content recorded with this unit into a Panasonic recorder, you can dub the content to a Blu-ray Disc or DVD etc. Methods to export still pictures and motion pictures to other devices will vary depending on the file format.
Page 318: Printing The Pictures
Do not connect devices to incorrect terminals. Doing so may cause malfunction. • Do not use any other USB connection cables except the supplied one or a genuine Panasonic USB connection cable (DMW-USBC1: optional). A USB connection cable (supplied) B Align the marks, and insert.
Page 319 12. Connecting to other equipment • Use a battery with sufficient battery power or the AC adaptor (optional). If the remaining battery power becomes low while the camera and the printer are connected, the status indicator blinks and the alarm beeps. If this happens during printing, stop printing at once. If not printing, disconnect the USB connection cable.
Page 320 12. Connecting to other equipment Selecting a single picture and printing it Press 2/1 to select the picture and then press [MENU/SET]. Pi PictBridge PictBridge ctBridge Press 3 to select [Print start] and then press [MENU/SET]. • Refer to P321 for the items that can be set before starting to print the pictures.
Page 321 12. Connecting to other equipment Print Settings Select and set the items both on the screen in step of the “Selecting a single picture and printing it” and in step of the “Selecting multiple pictures and printing them” procedures. • When you want to print pictures on a paper size or a layout which is not supported by the camera, set [Paper Size] or [Page Layout] to [{] and then set the paper size or the layout on the printer.
Page 322 12. Connecting to other equipment [Paper Size] ∫ Settings on the printer are prioritized. [L/3.5qk5q] 89 mmk127 mm [2L/5qk7q] 127 mmk178 mm [POSTCARD] 100 mmk148 mm [16:9] 101.6 mmk180.6 mm [A4] 210 mmk297 mm [A3] 297 mmk420 mm [10k15cm] 100 mmk150 mm [4qk6q] 101.6 mmk152.4 mm [8qk10q]...
Page 323 12. Connecting to other equipment Layout printing ∫ When printing a picture several times on 1 sheet of paper. For example, if you want to print the same picture 4 times on 1 sheet of paper, set [Page Layout] to [ä] and then set [Num.of prints] to 4 for the picture that you want to print. When printing different pictures on 1 sheet of paper.
Page 324: Others
Others Optional accessories • Some optional accessories may not be available in some countries. External Flash (optional) Optional flashes (DMW-FL360L/DMW-FL580L: optional) provide a wider flash recording range than the flash (supplied) does. When attaching a flash, remove the hot shoe cover attached to the camera. (P203) •...
Page 325 PC or printer and use without worrying about the capacity of the battery. To use the AC adaptor, a DC coupler (optional) is required. • Always use a genuine Panasonic AC adaptor (optional). • When using an AC adaptor, use the AC cable supplied with the AC adaptor. •...
Page 326: Monitor Display/Viewfinder Display
13. Others Monitor Display/Viewfinder Display • The following images are examples of when the display screen is set to [ ] (monitor style) in the monitor. In recording    MINI MINI MINI MINI   SNAP SNAP SNAP ...
Page 327 13. Others Color (P82) Number of recordable pictures ¢6 Name ¢ (P192) (P30) Number of days that have passed since the ¢1, 6 Available recording time ¢ departure date (P67) 8m30s (P30) ¢ (P192) Location ¢ (P67) Current date and time/Travel destination setting ¢4 Touch tab (P54)
Page 328 13. Others In recording On-monitor recording information 3.5 1/60  Single (P168)  Burst (P169) AUTO  Auto Bracket (P172) Wi-Fi  Self-timer (P175) AFS AFF AFC MF Focus Mode (P139, 153) š Ø AF Mode (P141) Recording Mode (P42) Quality (P132) ›...
Page 329 13. Others In playback Connected to Wi-Fi Number of group pictures   1/98 1/98 1/98 1/98 Motion picture recording time ¢1 8m30s (P227)    Clear Retouch completed icon F3.5 F3.5 F3.5 60 60 60 (P239) Currently retrieving information icon (P333) Playback Mode (P237)
Page 330: Histogram Display
13. Others In playback Detailed information display F3.5  STD. STD. STD.   100-0001 Recorded date and time/World Time (P66) Recording information Intelligent Dynamic Range Control ¢3 (P133) Picture size/Aspect Ratio (P131) ¢4 (P134)/iHDR ¢4 (P80) Quality (P132) A › Intelligent Resolution (P133) Color space...
Page 331: Message Display
[Lens not detected. Please turn camera on again.] • This is displayed when the lens has stopped operating normally due to being pressed on by a hand etc. Turn the camera off and on. If the message persists, contact the dealer or Panasonic.
Page 332 13. Others [Memory Card Error]/[This memory card cannot be used] • Use a card compatible with this unit. (P29) [Insert SD card again]/[Try another card] • An error has occurred accessing the card. Insert the card again. • Insert a different card. [Read Error/Write Error Please check the card] •...
Page 333 When you switch on again, the information retrieval will restart from the same point. [This battery cannot be used] • Use a genuine Panasonic battery. If this message is displayed even when a genuine Panasonic battery is used, contact the dealer or Panasonic. •...
Page 334 13. Others [Upload to the Cloud Folder is available after Cloud Sync settings have been set up on downloadable devices such as PCs or smartphones.] • Devices that download images from a cloud folder are not registered. • Perform Cloud Sync setting. Configure the settings on a PC with “PHOTOfunSTUDIO” or on a smartphone with “Image App”.
Page 335: Menu List
13. Others Menu list [Rec] P335 [Motion Picture] P338 [Custom] P339 [Setup] P341 [Playback] P343 • [Photo Style], [Filter Settings], [AFS/AFF], [Metering Mode], [Highlight Shadow], [i.Dynamic], [i.Resolution] and [Digital Zoom] are common to both the [Rec] menu and [Motion Picture] menu.
Page 336 13. Others There is, for example, strong contrast between the background and the subject, multiple still pictures are [iHDR] recorded with differing exposures and combined to create a single still picture rich in gradation. You can combine 3 pictures with different levels of [HDR] P134 exposure into a single picture with rich gradation.
Page 337 13. Others Increases the Tele effect. [Digital Zoom] The higher the level of magnification, the greater the P200 degradation in image quality. Set this when you want to correct the color reproduction of [Color Space] P136 the recorded pictures on a PC, printer etc. When camera shake is sensed during recording, the [Stabilizer] P195...
Page 338: [Motion Picture]
13. Others [Motion Picture] You can select effects to match the type of image you wish [Photo Style] to record. P122 You can adjust the color and image quality of the effects. [Filter Settings] Changes the settings related to image effects (filters). P124 Lets you specify the recording time in advance and records [Snap Movie]...
Page 339: [Custom]
13. Others [Custom] [Cust.Set Mem.] Registers the current camera settings as custom set. P120 [Silent Mode] Disables operational sounds and output of light at once. P186 Sets the fixed content for focusing and exposure when the [AF/AE Lock] P159 AF/AE lock is on. The shutter will immediately fire when the shutter button is [Half Press Release] P150...
Page 340 13. Others When the Auto Review function is activated or when [Highlight] playing back, white saturated areas appear blinking in black and white. Indicates parts that may be whited out through [Zebra Pattern] P193 overexposure in a zebra pattern. [Monochrome Live View] You can display the recording screen in black and white. P194 You can check the effects of the chosen aperture and [Constant Preview]...
Page 341: [Setup]
13. Others [Setup] [Clock Set] Setting Date/Time. Sets the times for the region where you live and your [World Time] holiday destination. Departure date and return date of the trip as well as the [Travel Date] name of the travel destination can be set. [Wi-Fi] Configure the each setting for Wi-Fi functions.
Page 342 13. Others Sets whether or not to cancel the self-timer when this unit [Self Timer Auto Off] is turned off. [No.Reset] Returns the image file number to 0001. The recording or setup/custom settings are reset to the [Reset] default. Reset all settings in the [Wi-Fi] menu to factory default [Reset Wi-Fi Settings] settings.
Page 343: [Playback]
13. Others [Playback] [2D/3D Settings] Switches the playback method for 3D images. P235 [Slide Show] Selects the type etc. of the images and plays back in order. P235 Selects the type etc. of the images and plays back only [Playback Mode] P237 particular images.
Page 344: Troubleshooting
13. Others Troubleshooting First, try out the following procedures (P344 to P357). If the problem is not resolved, it may be improved by selecting [Reset] (P72) on the [Setup] menu. Battery and power source The camera cannot be operated even when it is turned on. The camera turns off immediately after it is turned on.
Page 345 13. Others Taking pictures is not possible. The shutter will not operate immediately when the shutter button is pressed. • Is the subject focused? > Is [Focus/Release Priority] in the [Custom] menu set to [FOCUS]? (P152) You cannot take a picture until the subject is brought into focus. The recorded picture is whitish.
Page 346 13. Others The recorded picture looks rough. Noise appears on the picture. • Try the following: > Take pictures in bright places. > Decrease the ISO sensitivity. (P162) > Increase the setting for [Noise Reduction] in [Photo Style] or lower the setting for each of the items other than [Noise Reduction].
Page 347: Motion Pictures
13. Others Operation sound is small. • Is your finger covering up the speaker? (P14) Recording by Panorama Shot Mode is ended before finishing. • If the camera is moved too slowly, the camera has assumed that camera motion was stopped and will end the still picture recording.
Page 348 • The Optical Image Stabilizer function of the interchangeable lens (H-FS12032/H-FS35100) only works correctly with supported cameras. > When older Panasonic digital cameras (DMC-GF1/DMC-GH1/DMC-G1) are used, [Stabilizer] in the [Rec] menu (P195) cannot be set to [OFF].
Page 349 13. Others Flash The flash is not activated. • Is the flash (supplied) turned off? > Turn on the flash. (P203) • When the electronic shutter is used, the flash is not activated. (P166) > Set [Shutter Type] to [AUTO] or [EFC]. •...
Page 350 13. Others Black, white, red, blue and green dots appear on the Monitor/Viewfinder. • This is not a malfunction. These pixels do not affect the recorded pictures. Noise appears on the monitor. • In dark places, noise may appear to maintain the brightness of the monitor. The monitor displays distorted images.
Page 351 13. Others The folder number and the file number are displayed as [—] and the screen turns black. • Is this a non-standard picture, a picture which has been edited using a PC or a picture which was taken by another make of digital camera? •...
Page 352 13. Others Wi-Fi function A Wi-Fi connection cannot be established. Radio waves get disconnected. Wireless access point is not displayed. General tips for using a Wi-Fi connection ∫ • Use within the communication range of the device to be connected. •...
Page 353 I have forgotten the login ID or password for the “LUMIX CLUB”. • Check the information in the login screen of “LUMIX CLUB”. http://lumixclub.panasonic.net/eng/c/ I do not have a wireless access point at my home, but I would like to perform service user registration of the “LUMIX CLUB”.
Page 354 13. Others Images cannot be transmitted to the web service. • Confirm that the login information (login ID/user name/email address/password) is correct. • Web service server or the network may be busy. > Try again after a while. > Check the site of the web service you are sending the image to. It takes time to transmit an image to the web service.
Page 355 13. Others I have forgotten the password for the Wi-Fi. • Execute the [Reset Wi-Fi Settings] in the [Setup] menu. (P73) However, all the information you have set on the [Wi-Fi Setup] menu will be reset. (excluding [LUMIX CLUB]) TV, PC and printer The picture does not appear on the television.
Page 356 The card is not recognized by the PC. (SDXC memory card is used.) • Check if your PC is compatible with SDXC memory cards. http://panasonic.net/avc/sdcard/information/SDXC.html • A message prompting to format the card may be displayed when connecting, but do not format. •...
Page 357 13. Others The camera makes a noise when this unit is turned on. • This is the noise of the Dust Reduction Function working (P359); it is not a malfunction. There is a sound from lens unit. • It is a sound of lens movement or aperture operation when this unit is turned on or off, and it is not a malfunction.
Page 358: Cautions For Use
13. Others Cautions for Use Optimal use of the camera Keep this unit as far away as possible from electromagnetic equipment (such as microwave ovens, TVs, video games etc.). • If you use this unit on top of or near a TV, the pictures and/or sound on this unit may be disrupted by electromagnetic wave radiation.
Page 359 As the eye cup cannot be removed, blow away the dust on the viewfinder surface with a blower (commercially available), gently wipe it with a dry and soft cloth, and be careful not to remove it. • If you wipe the eye cup too hard and it is removed, consult the dealer or Panasonic.
Page 360 13. Others About the Monitor/Viewfinder • Do not press the monitor with excessive force. Uneven colors may appear on the monitor and it may malfunction. • If the camera is cold when you turn it on, the picture on the Monitor/Viewfinder will be slightly darker than usual at first.
Page 361 13. Others Battery The battery is a rechargeable lithium ion battery. Its ability to generate power comes from the chemical reaction that takes place inside it. This reaction is susceptible to the surrounding temperature and humidity. If the temperature is too high or too low, the operating time of the battery will become shorter.
Page 362 13. Others About 3D About 3D recording ∫ With the 3D interchangeable lens attached, do not record a subject at less than the minimum focus distance. • The 3D effects may be more pronounced, and therefore cause tiredness or discomfort. •...
Page 363 Information including personal information may be altered or vanish due to erroneous operation, effect of static electricity, accident, malfunction, repair, or other handlings. Please note in advance that Panasonic is not liable in any way for any direct or indirect damage from the alteration or vanishing of information or personal information.
Page 364 Settings may return to factory default when camera is repaired. • Please contact the dealer where you purchased the camera or Panasonic if above operations are not possible due to malfunction. When transferring to another party, or disposing of the memory card, please refer to “Notice for when transferring to another party, or disposing of the memory card”.
Page 365 About the picture data • Recorded data may be damaged or lost if the camera breaks down due to inappropriate handling. Panasonic will not be liable for any damage caused due to loss of recorded data. About tripods or unipods •...
Page 366 • SDXC Logo is a trademark of SD-3C, LLC. • “AVCHD”, “AVCHD Progressive” and the “AVCHD Progressive” logo are trademarks of Panasonic Corporation and Sony Corporation. • Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories.
Page 367 • QuickTime and the QuickTime logo are trademarks or registered trademarks of Apple Inc., used under license therefrom. • Android and Google Play are trademarks or registered trademarks of Google Inc. • The Wi-Fi CERTIFIED™ Logo is a certification mark of Wi-Fi Alliance •...

Panasonic Lumix DMC-GM5 Owner's Manual For Advanced Features

1 Before Use

2 Getting Started/Basic Operations

3 Recording Modes

4 Picture Quality and Color Tone Settings

5 Focus and Brightness (Exposure) Settings

6 Shutter and Drive Settings

7 Functions Customized for Various Subjects and Purposes

8 Stabilizer, Zoom and Flash

9 Recording Motion Pictures

10 Playing Back and Editing Images

11 Using the Wi-Fi Function

12 Connecting to Other Equipment

13 Others

Quick Links

Related Manuals for Panasonic Lumix DMC-GM5

Summary of Contents for Panasonic Lumix DMC-GM5
