- Page 1 User manual LED Pad Bar Compact 4x144 RGB 10mm...
-
Page 2: Table Of Contents
Table of contents Safety instructions ..........................3 1.1. FOR SAFE AND EFFICIENT OPERATION ................3 Technical Information ........................4 Menu structure ..........................5 DMX Table ............................6 4.1. DMX Mode 14 (14 Channel) ....................6 4.2. DMX Mode 5 (5Channel) ......................7 Building instructions ......................... -
Page 3: Safety Instructions
1. Safety instructions This device is suitable for indoor use only. All modifications to the device will void the warranty. Repairs are to carry out by skilled personnel only. Use only fuses of the same type and original parts as spare parts. Protect the unit from rain and humidity to avoid fire and electric shocks. -
Page 4: Technical Information
Important: Damages caused by the disregard of this user manual are not subject to warranty. The dealer will not accept liability for any resulting defects or problems. Make sure the electrical connection is carried out by qualified personnel. All electrical and mechanical connections have to be carried out according to the European safety standards. -
Page 5: Menu Structure
3. Menu structure Addr Adjusts the DMX address 1...512 Auto SP 1…SP 9 Aut 1 2 different programs, speed control 1-9 Aut 2 SoUd SoU1 Sound to Light, Flash white, control of sound sensitivity 1-9 SP 1…SP 9 SoU 2 Sound to Light, color change flash, control of sound sensitivity CoLO... -
Page 6: Dmx Table
4. DMX Table 4.1. DMX Mode 14 (14 Channel) Value Function Channel 0-255 Dimmer 1 red LEDs 0-255 Dimmer 1 green LEDs 0-255 Dimmer 1 blue LEDs 0-255 Dimmer 2 red LEDs 0-255 Dimmer 2 green LEDs 0-255 Dimmer 2 blue LEDs 0-255 Dimmer 3 red LEDs 0-255... -
Page 7: Dmx Mode 5 (5Channel)
4.2. DMX Mode 5 (5Channel) Value Function Channel 0-255 Dimmer red LEDs 0-255 Dimmer green LEDs 0-255 Dimmer blue LEDs 0-255 Shutter, speed slow-fast Special functions 0-11 No function 12-23 Chase 1 24-35 Chase 2 36-47 Chase 3 48-59 Chase 4 60-71 Chase 5 72-83... -
Page 8: Building Instructions
5. Building instructions 8 / 10... -
Page 9: Foot Controller (Optional Fixtures)
6. Foot controller (optional fixtures) For the LED Pad bar you can additional purchase a foot controller with this you can also control the LED Pad Bar. Pedal Function Auto Activates Auto mode Sound Activates Sound to Light Color Activates color mode Blackout Activates Blackout 7. - Page 10 Importer: B & K Braun GmbH Industriestraße 2 D-76307 Karlsbad www.bkbraun.com info@bkbraun.com 10 / 10...
