- Page 1 0802_GB_42 Instructions for installation, use e maintenance GAS KITCHENS ADN 644 ADN 645 · ADN 600 ADN 601 · ADN 602 ADN 603 · 04/2008...
- Page 2 CHARACTERISTICS Supplied by: Date: Customer Service: e-mail 0802_GB_42 - GAS KITCHENS 04/2008 2 · 16...
-
Page 3: Table Of Contents
INDEX Diagram 6 Instructions for use 6.1 Safety, cleaning and repair rules Characteristics of the appliances 6.2 Start-up 6.2.1 Lighting and disconnecting flame burner without pilot Technical data 6.3 Lighting and shutdown of electric oven GN 1/1 6.4 Turning the appliance off in case of breakdown 4 Installation instructions 6.4.1 What to do in case of failure 4.1 Safety rules... - Page 4 1 - DIAGRAM ADN 645 ADN 644 Gas 1/2" Gas 1/2" Data plate Gas 1/2" Gas 1/2" Data plate Data plate ADN 601 ADN 600 1000 Gas 1/2" Data plate Gas 1/2" Gas 1/2" Data plate Data plate 1000 0802_GB_42 - GAS KITCHENS 04/2008 4 ·...
- Page 5 1 - DIAGRAM ADN 603 ADN 602 1000 Electric Electric power power Gas 1/2" Gas 1/2" Data plate Gas 1/2" Gas 1/2" Electric power Electric power Data plate Data plate 1000 0802_GB_42 - GAS KITCHENS 04/2008 5 · 16...
-
Page 6: Characteristics Of The Appliances
THE APPLIANCE MUST BE INSTALLED BY QUALIFIED PERSONNEL. 20 mbar 3 - TECHNICAL DATA Model Description Dimensions in mm. (LxDxH) ADN 644 Gas range 2 burners 400 x 600 x 270 51BS3545 ADN 645 Gas range 4 burners 600 x 600 x 270... - Page 7 Air necessary for combustion Nominal thermal power Minimum thermal power 0.85 Overall thermal power (gas) Hour consumption G30/G31 kg/h ADN 644 0,78 0,58 ADN 645 • ADN 600 • ADN 602 14.8 1,57 1,16 ADN 601 • ADN 603 22.2...
-
Page 8: Installation Instructions
4 - INSTALLATION INSTRUCTIONS 4.1 Safety rules Electric version GN 1/1 ventilated The heating element is place in the rear around the fan and is pro- • Only a local gas utility technician is authorized to carry out gas tected by a bulkhead. Temperature adjustment between 50°C and installations and connections. -
Page 9: Preparation And Start-Up
4 - INSTALLATION INSTRUCTIONS • The power cord is suitable to the electrical input of the appli- ance (see table 1 pag. 7) and approved. The cord must be at least type H07 RN-F. The ground wire must be long enough to prevent tug after the cable lead wires in case of raceway breakage. -
Page 10: Operation Control
5 - SET-UP FOR OPERATION Fig. 1 5.1.6 Operation control which is provided with the appliance. If injectors are not available please contact the factory with model and serial number written on • Start the appliance in accordance with the instructions. technical data sticker. -
Page 11: Replacing Parts
5 - SET-UP FOR OPERATION 5.2 Maintenance 5.3.3 Open flame thermocouple Attention! Before doing any repair or maintenance Unfix the graft (pos. 8 fig. 1) fixing the thermocouple on the cock, work, unplug the appliance. unscrew the screws (pos. 12 fig. 1) fixing the injector-holder cup (pos. -
Page 12: Instructions For Use
6 - INSTRUCTIONS FOR USE 6.1 Safety, cleaning and repair rules 6.3 Lighting and shutdown of electric oven GN 1/1 • This appliance is used for the preparation of meals at industri- al level. Usage and cleaning can be carried only by expert per- With knob (pos. - Page 13 6 - INSTRUCTIONS FOR USE 6.6 Recommendations for the treatment of formed rust spots can be removed with slightly abrasive liquid soaps or fine-grained sand paper. Larger rust spots can be stainless “steel industrial” kitchens removed with 2-3% of hot oxalic acid solution. If these cleaning products do not do the job, a nitric acid (10%) treatment is 6.6.1 Useful information on “stainless steel”...
- Page 14 6 - INSTRUCTIONS FOR USE 6.6.3 The 2002/96/EC (WEEE) Directive: information to users This informational note is meant only Fig. A for owners of equipment marked with the symbol shown in fig. A on the adhe- sive label featuring the technical specifi- cations applied on the actual product (the label also giving the serial number).
- Page 15 7 - APPENDIX: ELECTRICAL DIAGRAMS ADN 602 • ADN 603 N L1 PE Terminal board Commutator Heating element 2500 W Thermostat Green indicator light Yellow indicator light Motorized fan Total power: 2.5 kW 0802_GB_42 - GAS KITCHENS 04/2008 15 · 16...
- Page 16 THE MANUFACTURER RESERVES THE RIGHT TO MAKE ANY CHANGES DEEMED NECESSARY. THE MANUFACTURER CANNOT BE HELD RESPONSIBLE IF THE INSTRUCTIONS CONTAINED IN THIS MANUAL ARE NOT OBSERVED. WHIRLPOOL EUROPE srl V.le Guido Borghi, 27 I – 21025 Comerio – VA...
