SERVICE MANUAL

MODEL
COMMANDER
KV-29FX11A
KV-29FX11B
KV-29FX11D
KV-29FX11E
M I C R O F I L M
DEST
CHASSIS NO.
RM-886
Italian
SCC-K05S-A
RM-886
French
SCC-K01U-A
RM-886
AEP
SCC-K07U-A
RM-886
Spanish
SCC-K06U-A
SELF-DIAGNOSTIC FUNCTION
MODEL
COMMANDER
KV-29FX11K
KV-29FX11R
KV-29FX11U
TRINITRON
1
BE-3D
CHASSIS
DEST
CHASSIS NO.
RM-886
OIRT
SCC-K20K-A
RM-886
OIRT
SCC-K20L-A
RM-886
UK
SCC-K04Q-A
/
MENU
PROGR
RM-883
COLOR TV
®
®

Advertisement

Table of Contents
loading

Summary of Contents for Sony Trinitron KV-29FX11A

  • Page 1: Service Manual

    SELF-DIAGNOSTIC FUNCTION SERVICE MANUAL BE-3D CHASSIS MODEL MODEL COMMANDER DEST CHASSIS NO. COMMANDER DEST CHASSIS NO. KV-29FX11A KV-29FX11K RM-886 Italian SCC-K05S-A RM-886 OIRT SCC-K20K-A KV-29FX11B KV-29FX11R RM-886 French SCC-K01U-A RM-886 OIRT SCC-K20L-A KV-29FX11D KV-29FX11U RM-886 SCC-K07U-A RM-886 SCC-K04Q-A KV-29FX11E RM-886...
  • Page 2: Input/Output Terminals

    KV-29FX11 ITEM MODEL Television System Stereo System Channel Coverage Color System ITALIA VHF : A-H2 (C) UHF : 21-69 PAL PAL, SECAM Italian B/G/H GERMAN Stereo B/G/H VHF : E2-E12 UHF : E21-E69 NTSC4.43, NTSC3.58 CABLE TV (1) : S1-S41 (VIDEO IN) CABLE TV (2) : S01-S05, M1-M10, U1-U10 L VHF : F02-F10 UHF : F21-F60...
  • Page 3 KV-29FX11 Model Name KV-29FX11A KV-29FX11B KV-29FX11D KV-29FX11E KV-29FX11K KV-29FX11R KV-29XF11U Item Pal Comb Woofer Box Scart 1 Scart 2 Front in (3) Scart 4 Projector AKB in 16:9 mode Norm B/G/H Norm I Norm D/K Norm AUS Norm L Norm SAT...
  • Page 4 KV-29FX11 Pin No Signal Signal level 21 pin connector ( Audio output B Standard level : 0.5V rms (right) Output impedence : Less than 1kohm* Audio output B Standard level : 0.5V rms (right) Output impedence : More than 10kohm* Audio output A Standard level : 0.5V rms (left)
  • Page 5: Table Of Contents

    EXPLOSÈES ET LES LISTES DE PIECES SONT D’UNE IMPORTANCE CRITIQUE POUR LA SÈCURITÈ DU FONCTIONNEMENT, NE LES REMPLACER QUE PAR DES COMPSANTS SONY DONT LE NUMÈRO DE PIÈCE EST INDIQUÈ DANS LE PRÈSENT MANUEL OU DANS DES SUPPLÈMENTS PUBLIÈS PAR SONY.
  • Page 20 KV-29FX11...
  • Page 21 KV-29FX11...
  • Page 22 KV-29FX11...
  • Page 23 KV-29FX11...
  • Page 24: Set-Up Adjustments

    KV-29FX11 SECTION 3 SET-UP ADJUSTMENTS • When complete readjustment is necessary or a new Carry out the following adjustments in this order : picture tube is installed, carry out the following 3-1. Beam Landing adjustments. 3-2. Convergence • Unless there are specific instructions to the contrary, 3-3.
  • Page 25: Convergence

    KV-29FX1 3-2. CONVERGENCE • Tilt the V.STAT magnet and adjust the static convergence by opening or closing the V.STAT magnet. Preparation: • Before starting this adjustment, adjust the focus, horizontal size and vertical size. • Minimize the Brightness setting. • Input a dot pattern from the pattern generator.
  • Page 26 KV-29FX11 • Operation of the BMC (Hexapole) magnet. V.STAT Purity BMC (Hexapole) • The respective dot position resulting from moving each magnet interact, so be sure to perform adjustment whilst tracking. Use the H.STAT VR to adjust the Red, Green and Blue dots so that they coincide at the centre of the screen (by moving the dots in the horizontal direction).
  • Page 27: White Balance

    KV-29FX1 3-3. WHITE BALANCE Screen corner convergence. • If you are unable to adjust the corner convergence properly, correct them with the use of permalloy assemblies. G2 Setting Switch the TV set into AV mode [apply a cross-hatch signal]. Enter into the ‘Service mode’ and select ‘Picture Control’. Enter ‘Picture Control’...
  • Page 28: Circuit Adjustments

    KV-29FX11 SECTION 4 CIRCUIT ADJUSTMENTS 4-1. ELECTRICAL ADJUSTMENTS PICTURE ADJUSTMENT Service adjustments to this model can be performed using the supplied Remote Commander RM-886. AFC mode REF position HOW TO ENTER INTO SERVICE MODE SCP BGR Turn on the main power switch and enter into the stand-by SCP BGF mode.
  • Page 29 KV-29FX1 SUB BRIGHTNESS ADJUSTMENT Input a Phillips pattern. AGC ON/OFF Set the picture control to minimum. Constant gain CDB Enter into the ‘Picture Adjustment’ service menu. FM prescale FMP Adjust the ‘Sub-Brightness’ data so that there is barely a Zwei mono-st WHI difference between the 0 IRE and 10 IRE signal levels.
  • Page 30 KV-29FX11 DEFLECTION SYSTEM ADJUSTMENT SYSTEM B/G, D/K, I & L I.F ADJUSTMENT Enter into the ‘Geometry Adjustment’ service menu. Input an off air signal of between 60-100dBuV / 75 ohm Select and adjust each item in order to obtain the optimum terminated, via the tuner socket.
  • Page 31: Test Mode 2

    KV-29FX1 4-2. TEST MODE 2: Is available by pressing ‘TEST’ button twice, OSD ‘TT’ appears. The functions described below are available by pressing the two numbers. To release the Test mode 2, press 0 twice, or switch the TV into stand-by mode. Note : ‘TT’...
  • Page 32 KV-29FX11 DSP Bypass D/K Nicam Disable Diagnostics OFF Diagnostics ON No function Lumisponder Curve 1 Lumisponder Curve 2 Jungle Select (CXA2000 or CXA2076) Text H Position adjust Picture reset MSP BG filter enabled (h/w required) Sound reset MSP BG filter disabled (h/w required) Wide set-up (Wide screen models only) No function Velocity mod ON...
  • Page 33: Be-3D Self Diagnostic Software

    KV-29FX1 4-3. BE-3D SELF DIAGNOSTIC SOFTWARE The identification of errors within the BE-3D chassis is triggered in one of two ways :- 1: Busy busy or 2: Device failure to respond to IIC. In the event of one of these situations arising the software will first try to release the bus if busy [Failure to do so will report with continuous flashing LED] and then communicate with each device in turn to establish if a device is faulty.
  • Page 40: D Board

    WAVEFORMS D BOARD 1.2K Vp-p (H) 56.0 Vp-p (V) 13 Vp-p (H) 178 Vp-p (H) 2.6 Vp-p (H) 56 Vp-p (V) 31 Vp-p (V) 140 Vp-p (H) 1.0 Vp-p (H) 3.0 Vp-p (H) 5.5 Vp-p (V) 28 Vp-p (H) WAVEFORMS C BOARD 110 Vp-p (H) 108 Vp-p (H) 90 Vp-p (H)
  • Page 42: Semiconductors

    5-4 SEMICONDUCTORS CXA2040Q-T4 MSP3410D-PS-B4-T STR-S6709 TMS27PC020-15FMBE201 1 32 (TOP VIEW) ( TOP VIEW ) ( TOP VIEW ) L4941BV PST593C-MMP-4P STV9379 BF421L-AMMO TEA7605 JA101TP-Q 2SA733-K 2SA933AS 2SA933S 2SA1091-O 2SC3502-E 2SC3601-E 2SC2808STP-R ( TOP VIEW ) TDA4665T-T SBX1981-51 E C B LM393P M5216P TDA2822M...
  • Page 43 TLP721(D4-) AU-01Z-V1 FML-G12S ERA38-06TP1 MTZJ-39 EG-1Z-V1 GP08D MTZJ-3.6A RD3.9ESB2 EGP20G HSS83TD MTZJ-3.9B RD5.1ESB2 EL1Z RGP02 MTZJ-5.1B RD5.6ESB2 EM1-V1 RGP10GPKG23 MTZJ-5.6B RD6.2ESB2 ERB44-06TP1 RGP15GPKG23 MTZJ-6.2BMTZJ-6.8C RD6.8ESB2 EU-1-V1 RU3YX-V1 MTJ-7.5C RD7.5ESB2 EU2A RU4AM-T3 MTZJ-9.1 RD10ESB2 EU2-V1 RU4DS MTZJ-T-77-9.1A RD39ES-B2 MTZJ-10 1SS133T-77 2SC2785-HFE CATHODE CATHODE ANODE...
  • Page 44: Exploded Views

    1-571-433-21 SWITCH, PUSH (AC POWER) 1-693-340-11 TUNER/VIF (FR) (KV-29FX11B) *4-203-315-41 BRACKET, MAIN 1-693-339-11 TUNER/VIF (UK) (KV-29FX11U) *4-202-531-01 AC CORD LOCK (SC) *A-1632-783-A A BOARD, COMPLETE (KV-29FX11A) £ 1-765-286-11 CORD POWER (KV-29FX11A/29FX11B/29FX11D/ *A-1632-782-A A BOARD, COMPLETE (KV-29FX11B) KV-29FX11E/29FX11K) *A-1632-769-A A BOARD, COMPLETE (KV-29FX11D) £...
  • Page 45: Picture Tube

    DESCRIPTION REMARK X-4200-386-1 BEZNET ASSY 55-59 £ 8-453-011-11 NECK ASSY, NA299-M 4-045-250-01 DAMPER *A-1644-091-A VM BOARD, COMPLETE 4-204-190-11 DOOR (KV-29FX11A/29FX11D/29FX11R) *A-1638-113-A C BOARD, COMPLETE 4-204-190-01 DOOR (KV-29FX11B/29FX11E/29FX11K/29FX11U) 4-200-433-01 SPRING, EXTENSION 4-202-555-01 SHAFT DOOR 4-052-452-01 CUSHION DGC 4-042-192-11 CATCHER, PUSH £...
  • Page 46: Electrical Parts List

    All resistors are in ohms. • F : nonflammable. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK *A-1632-783-A A BOARD, COMPLETE (KV-29FX11A) C103 1-126-965-11 ELECT 22MF ***************** C104 1-163-117-00 CERAMIC CHIP 100PF *A-1632-782-A A BOARD, COMPLETE (KV-29FX11B) C110 1-126-967-11 ELECT 47MF...
  • Page 47 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK C225 1-163-133-00 CERAMIC CHIP 470PF C300 1-163-109-00 CERAMIC CHIP 47PF C226 1-126-967-11 ELECT 47MF C301...
  • Page 48 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK C356 1-164-232-11 CERAMIC CHIP 0.01MF D220 8-719-988-62 DIODE 1SS355 C357 1-163-133-00 CERAMIC CHIP 470PF D221 8-719-988-62 DIODE 1SS355 C358...
  • Page 49 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK Q111 8-729-216-22 TRANSISTOR 2SA1162-G 1-216-025-00 RES,CHIP 1/10W Q112 8-729-620-06 TRANSISTOR 2SC3052-EF 1-216-025-00 RES,CHIP 1/10W Q120...
  • Page 50 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK 1-216-081-00 RES,CHIP 1/10W R151 1-216-025-71 RES,CHIP 1/10W 1-216-025-00 RES,CHIP 1/10W R200 1-216-049-00 RES,CHIP 1/10W 1-216-025-00 RES,CHIP...
  • Page 51 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK R256 1-216-025-00 RES,CHIP 1/10W R331 1-216-059-00 RES,CHIP 2.7K 5% 1/10W R257 1-216-013-00 RES,CHIP 1/10W R332...
  • Page 52 8-729-216-22 TRANSISTOR 2SA1162-G X1001 1-579-965-21 VIBRATOR, CRYSTAL < RESISTOR > ********************************************************************* JR01 1-216-296-91 METAL GLAZE 1/8W JR02 1-216-296-91 METAL GLAZE 1/8W A-1652-037-A IF BOARD, COMPLETE (KV-29FX11A/29FX11D/ JR03 1-216-295-00 METAL GLAZE 1/10W ****************** KV-29FX11E/29FX11K/ JR04 1-216-296-91 METAL GLAZE 1/8W KV-29FX11R) JR05...
  • Page 53 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number IF ( KV-29FX11B specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK A-1652-036-A IF BOARD, COMPLETE (KV-29FX11B) < TRANSISTOR > ****************** 8-729-216-22 TRANSISTOR 2SA1162-G...
  • Page 54 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK *A-1638-113-A C BOARD, COMPLETE < CRT SOCKET > ***************** J701 £ 1-526-990-21 SOCKET, CRT <...
  • Page 55 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK < SPARK GAP > D2805 8-719-970-87 DIODE ERA38-06 D2806 8-719-300-33 DIODE RU-3AM SG701 1-517-712-31 GAP, SPARK D2807...
  • Page 56 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK R2821 1-247-807-31 CARBON 1/4W < CAPACITOR > R2823 1-535-465-11 LEAD, JUMPER (5.0MM) R2824 1-249-425-11 CARBON 4.7K 5%...
  • Page 57 V-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK C630 1-111-097-11 ELECT 0.0022F C904 1-126-933-11 ELECT 100MF C631 1-126-965-11 ELECT 22MF C905 1-126-964-11 ELECT...
  • Page 58 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK D503 8-719-979-85 DIODE EGP20G D902 8-719-923-60 DIODE MTZJ-T-77-9.1 D504 8-719-991-33 DIODE 1SS133T-77 D903 8-719-923-60 DIODE MTZJ-T-77-9.1 D505...
  • Page 59 V-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK L609 1-412-533-21 INDUCTOR 47UH < RESISTOR > L610 1-535-465-11 LEAD, JUMPER (5.0MM) L611 1-412-527-11 INDUCTOR 15UH...
  • Page 60 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK R627 1-216-347-11 METAL OXIDE 0.68 5% R836 1-249-439-11 CARBON 1/4W R628 1-249-415-11 CARBON 1/4W F R838...
  • Page 61 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number D VM specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK < RELAY > C1722 1-126-935-11 ELECT 470MF C1723 1-161-830-00 CERAMIC 0.0047MF 500V RY600 £...
  • Page 62 KV-29FX11 The components identified by shading and marked are critical for safety Replace only with the part number specified. REF. NO. PART.NO DESCRIPTION REMARK REF. NO. PART.NO DESCRIPTION REMARK < RESISTOR > C264 1-136-495-11 FILM 0.068MF C265 1-136-176-00 FILM 0.82MF R1701 1-249-397-11 CARBON 1/4W F...
  • Page 63 £ 1-453-269-11 TRANSFORMER ASSY, FLYBACK (NA-4511/U2B4) 1-505-937-11 SPEAKER (10CM) 1-475-833-11 COMMANDER, STANDARD TYPE (RM-886) 1-505-952-11 SPEAKER *********************************************************************_ £ 1-571-433-21 SWITCH, PUSH (AC POWER) 1-693-338-11 TUNER/VIF (AEP) (KV-29FX11A/29FX11D/ KV-29FX11E/29FX11K/ KV-29FX11R) 1-693-340-11 TUNER/VIF (FR) (KV-29FX11B) 1-693-339-11 TUNER/VIF (UK) (KV-29FX11U) £ 1-765-286-11 CORD, POWER...
  • Page 64 KV-29X5 English Sony Corporation 98BP7173-1 Sony UK Printed in U.K. © 1998.2 Service Promotions Dept. 9-974-967-01...
