VTech CS6648-2 Quick Start Manual

Quick start guide

CS6648-2/CS6649/
CS6649-2/CS6649-3
Introduction
This quick start guide provides you with the basic installation
and setup instructions. A limited set of features are described
in abbreviated form.
For complete installation and operation instructions, refer to the
Abridged user's manual provided in the product package, or see
the online Complete user's manual at www.vtechphones.com.
Telephone base and handset charger installation
Install the telephone base and handset charger as shown below.
Telephone
wall jack
Telephone
line cord
Telephone base
A DSL filter
power adapter
(not included)
is required if you
have DSL
high-speed
Internet service.
The DSL
filter must be
plugged into the
telephone wall
jack.
Telephone base
Use only the power adapters and batteries supplied with
this product.
Battery installation and charging
Install the battery as shown below. Once you have installed
the battery, you may be able to make and receive short
calls. For best performance, charge the handset battery
continuously for at least
1. Plug the battery
connector securely into
the socket.
3. Slide the battery
compartment cover
towards the center of
the handset until it clicks
into place.
Electrical outlet
not controlled by a
wall switch
Charger
adapter
Enter the menu
Press MENU.
1.
2. Press or
feature menu.
Press SELECT to enter that menu.
3.
To return to the previous menu, press CANCEL.
•
Handset charger
• To return to idle mode, press and hold CANCEL.
Set date and time
Press MENU.
1.
2. Scroll to Set date/time, then press SELECT.
3. Use the dialing keys (0-9) to enter the month (MM),
date (DD) and year (YY), then press SELECT.
4. Use the dialing keys (0-9) to enter the hour (HH) and
minute (MM). Then press
5. Press SELECT to save.
10 hours.
2. Place the battery with the
label THIS SIDE UP facing
up and the wires inside the
battery compartment.
4. Place the handset in
the handset charger
to charge.
CHARGE light
remains on when
charging.
until the screen displays the desired
or to choose AM or PM.
Set number of rings
You can set the answering system to answer an incoming
call after 2, 3, 4, 5 or 6 rings; or toll saver. If you choose toll
saver, the answering system answers a call after 2 rings when
you have new messages, or after 4 rings when you have no
new messages.
1. Press MENU.
2. Scroll to Answering sys then press SELECT.
3. Scroll to Ans sys setup then press SELECT.
4. Scroll to # of rings then press SELECT.
5. Press or to choose 6, 5, 4, 3, 2 or Toll saver and
then press SELECT.
Record your own announcement
You can use the preset announcement to answer calls,
or replace it with your own recorded announcement. The
announcement can be up to 90 seconds in length.
Press MENU.
1.
2. Scroll to Answering sys then press SELECT twice.
The system announces, "To play, press 2. To record,
3.
press 7." Then press 7 to record.
4. The system announces, "Record after the tone. Press 5
when you are done." After the tone, speak towards the
microphone.
5. Press 5 when done.
IMPORTANT!
Refer to the online Complete user's manual for a full set of
installation and operation instructions. For manual download or
customer service, visit our website at www.vtechphones.com or
call 1 (800) 595-9511. In Canada, go to www.vtechcanada.com
or call 1 (800) 267-7377.
Copyright © 2012 for VTECH TELECOMMUNICATIONS LTD.
All rights reserved. Printed in China.
96-008624-020-100
