- Page 1 A 218 LA active subwoofer user manual...
- Page 2 Musikhaus Thomann e.K. Treppendorf 30 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 13.11.2013...
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 7 Features............................... 11 Installation..............................12 Connections and operating elements................... 14 Starting up ..............................19 Networking and remote control ..................... 23 Technical specifications........................27 Plug and connection assignment....................29 Protecting the environment......................31 A 218 LA... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device to other users, be sure that they also receive this manual. - Page 5 General notes Symbols and signal words This section provides an overview of the symbols and signal words used in this user manual. Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided.
- Page 6 General notes Warning signs Type of danger Warning – danger zone. active subwoofer...
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is intended to be used in a sound reinforcement system. Use the device only as described in this user manual. Any other use or use under other operating conditions is consid‐ ered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present. Never remove any covers. There are no user-serviceable parts inside. DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord). Do not modify the mains cable.
- Page 9 Safety instructions CAUTION! Possible hearing damage The device can produce volume levels that may cause temporary or permanent hearing impairment. Over an extended period of time, even levels that seem to be uncritical can cause hearing damage. Decrease the volume level immediately if you experience ringing in your ears or hearing impairment.
- Page 10 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. NOTICE! Power supply Before connecting the device, ensure that the input voltage (AC outlet) matches the voltage rating of the device and that the AC outlet is protected by a residual current circuit breaker.
-
Page 11: Features
Network port for connecting a notebook/PC using exclusively the CanBus converters (item no.: 326058 the box pro USB2CAN CanBus Converter) and the Pronet software (free down‐ load from www.thomann.de). Ten carrying handles Birch plywood housing with waterproof paint... -
Page 12: Installation
Installation Installation Unpack and carefully check that there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the device against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 13 Installation NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field. A 218 LA...
-
Page 14: Connections And Operating Elements
Connections and operating elements Connections and operating elements active subwoofer... - Page 15 Connections and operating elements 1 INPUT Audio signal input with lockable XLR chassis socket. The socket is electronically perfectly symmetrical wired to ach‐ ieve an optimal signal-to-noise ratio and a sufficient power reserve, including A / D conversion. 2 [GND LIFT] pushbutton If hum is caused by a ground loop, you can use this switch to disconnect the connection between the earth pin of the device and the signal ground of the device.
- Page 16 Connections and operating elements 6, 7 NETWORK IN/OUT RJ45 CAT5 connectors for establishing a network connection to the CanBus Converter (item number 326058), to the Pronet software and to the line array elements. active subwoofer...
- Page 17 Connections and operating elements 8 Preset button This button has two functions: If it's kept pressed while turning the device on, the ID assignment is made. The internal digital signal processor (DSP) assigns a new ID to the device for the remote control within the Pronet network. Each element must have a unique ID so that it can be represented in the Pronet network.
- Page 18 Connections and operating elements This LED lights up when the user setting is loaded. This setting corresponds to the user preset no. 1 of the DSP. In delivered condition, the user setting is identical to the setting STANDARD. If you want to change it, you must connect the element to a PC, edit the parameters using the Pronet software, and save the setting to user memory preset no.
-
Page 19: Starting Up
Starting up Starting up Switching on After you have made all the required connections, turn on the audio system. It is recommended to provide one switch for turning on the entire audio system and to always leave the powerCon plugs connected to the sockets of the individual elements. With this simple trick you can extend the life of the powerCON connectors. - Page 20 Starting up Application example for stacked The units can be combined vertically or horizontally to subwoofer stacks. Of each three subwoofers devices, the middle one should aim to the stage working with the DSP preset CARDIOID . The other two devices point toward the audience and work with the DSP preset STANDARD. By this configuration, the bass level for the artists on stage is reduced, but maximized for the audience.
- Page 21 Starting up A 218 LA...
- Page 22 Starting up 1 Stage. 2 Wall or huge obstacle. 3 Auditorium. 4 Doubled bass. 5 Reduced bass. Subwoofer stacks must be placed at a distance of 80 cm from walls and fixed obstacles, so that the sound is not affected by reflections. active subwoofer...
-
Page 23: Networking And Remote Control
The communication protocol used in the Pronet network is CanBus. USB2CAN All you need to build such a network is the free Thomann Pronet software offered in the Tho‐ mann Cyberstore for download, the CanBus Converter (item number 326058) available from Thomann and a notebook or PC. - Page 24 Networking and remote control 1 Network ports on the rear panel of the first unit. 2 [TERMINATE] pushbutton must not be pressed. The LED above it is off. active subwoofer...
- Page 25 Networking and remote control 3 Network ports on the rear panel of the last unit. 4 [TERMINATE] pushbutton must be pressed. The LED above it is on. Network setup and termination The individual units must be linearly linked by RJ45 CAT5 cable. Beginning and end of the net‐ work bus must be terminated.
- Page 26 Networking and remote control Press the [TERMINATE] button on the rear panel of the last unit. Turn on the first device while keeping its [PRESET] button pressed on the rear panel. Leave the first device turned on and repeat step 4 for all other devices until the last device is turned on.
-
Page 27: Technical Specifications
Technical specifications Technical specifications Speakers 2 × 18" woofers (4" voice coil) Input XLR chassis socket (balanced) Input impedance 20 kΩ Input sensitivity +4 dBu / 1.25 V Output XLR chassis plug Frequency response 36 Hz … 100 Hz (–3 dB) Output power 2 ×... - Page 28 Technical specifications Dimensions (W × H × D, without casters) 1215 mm × 590 mm × 950 mm Weight 101.7 kg active subwoofer...
-
Page 29: Plug And Connection Assignment
Plug and connection assignment Plug and connection assignment Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 30 Plug and connection assignment Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) active subwoofer...
-
Page 31: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 32 Notes active subwoofer...
- Page 33 Notes A 218 LA...
- Page 34 Notes active subwoofer...
- Page 36 Musikhaus Thomann e.K. · Treppendorf 30 · 96138 Burgebrach · Germany · www.thomann.de...
