Summary of Contents for Baby Lock Destiny BLDY

  • Page 3: Introduction

    Never operate this machine if it has a damaged cord or plug, if it is not working properly, if it has been dropped or damaged, or water is spilled on the unit. Return the machine to the nearest authorized Baby Lock retailer for examination, repair, electrical or mechanical adjustment.
  • Page 4 For repair or adjustment: • If the light unit is damaged, it must be replaced by an authorized Baby Lock retailer. • In the event a malfunction occurs or adjustment is required, first follow the troubleshooting table in the back of the Instruction and Reference Guide to inspect and adjust the machine yourself.
  • Page 5 IMPORTANT SAFETY INSTRUCTIONS Use this machine only for its intended use as described in the manual. Use accessories recommended by the manufacturer as contained in this manual. Use only the interface cable (USB cable) included with this machine. Use only the mouse designed specifically for this machine. Use only the sensor pen included with this machine.

  • Page 6: Trademarks

    IMPORTANT SAFETY INSTRUCTIONS Trademarks IMPORTANT: READ BEFORE DOWNLOADING, COPYING, INSTALLING OR USING. By downloading, copying, installing or using the software you agree to this license. If you do not agree to this license, do not download, install, copy or use the software. Intel License Agreement For Open Source Computer Vision Library Copyright ©...

  • Page 7: Declaration Of Conformity

    1760 Gilsinn Lane, Fenton, Missouri 63026 USA declares that the product Product Name: Baby Lock Sewing Machine Model Number: BLDY This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept any interference received, including interference that may cause undesired operation.
  • Page 8 IMPORTANT SAFETY INSTRUCTIONS Laser Notices Laser Safety This sewing machine is certified as a Class 1 laser product under the U.S. Department of Health and Human Services (DHHS) Radiation Performance Standard according to the Radiation Control for Health and Safety Act of 1968. This means that the sewing machine does not produce hazardous laser radiation.
  • Page 9 IMPORTANT SAFETY INSTRUCTIONS...

  • Page 10: Outstanding Features

    OUTSTANDING FEATURES IQ Designer Spool Stand LED Lighting Draw your own shape or lines to design original Now, your sewing machine shows you the thread embroidery patterns. You can specify colors, line color you are going to embroider next. type and fill stitch type. Try the stipple-like embroidery pattern.
  • Page 11 Improved Camera Function Can you imagine a sewing machine with a built-in camera? Not only viewing the close up view of the needle position, but also you can align the embroidery position, connect the embroidery patterns and place the pattern position while checking the fabric image.

  • Page 12: What You Can Do With This Machine

    WHAT YOU CAN DO WITH THIS MACHINE Getting Ready Sewing Basics To learn the operation of the principal parts and the To learn how to prepare for sewing and basic sewing screens operations Chapter Chapter Page 27 Page 79 Utility Stitches Character/Decorative Stitches Pre-programmed with more than 100 frequently used...

  • Page 13: How To Use This Manual

    HOW TO USE THIS MANUAL Chapter 1 and Chapter 2 explain your sewing machine’s basic operation procedures for someone who is using the sewing machine for the first time. If you want to sew utility stitches or character/ decorative stitches, read Chapter 1 and Chapter 2, then go on to Chapter 3 (Utility Stitches) or Chapter 4 (Character/ Decorative Stitches).

  • Page 14: Table Of Contents

    CONTENTS CONTENTS INTRODUCTION ..........1 Chapter 2 Sewing Basics IMPORTANT SAFETY INSTRUCTIONS ....1 SEWING............. 80 Trademarks ................4 Sewing a Stitch ..............80 OUTSTANDING FEATURES ......... 8 Specifying the Multi-Function Foot Controller WHAT YOU CAN DO WITH THIS MACHINE ... 10 (Only for supplied models) ..........
  • Page 15 CONTENTS Multi-directional Sewing (Straight Stitch and Zigzag Stitch)..156 Choosing a Color from the Custom Thread Table ....226 Zipper Insertion ..............157 Find New Color Schemes Edge Sewing ..............160 With the Color Visualizer Function ........227 Designing Repeated Patterns ..........229 Chapter 4 Character/Decorative Stitches Embroidering the Pattern Repeatedly ........
  • Page 16 CONTENTS Using a Frame Pattern to Make an Appliqué (2)....304 Fabric is Caught in the Machine and Cannot be Removed..385 Sewing Split Embroidery Patterns ........305 List of Symptoms..............388 USING THE CAMERA TO CONNECT PATTERNS ..307 ERROR MESSAGES...........

  • Page 17: Names Of Machine Parts And Their Functions

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS NAMES OF MACHINE PARTS AND THEIR FUNCTIONS The names of the various parts of the sewing machine and their functions are described below. Before using the sewing machine, carefully read these descriptions to learn the names of the machine parts. Machine ■...

  • Page 18: Needle And Presser Foot Section

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Needle and Presser Foot Section Measurements on the needle plate, bobbin cover (with mark) and needle plate cover The measurements on the bobbin cover are references for patterns with a middle (center) needle position. The measurements on the needle plate and the needle plate cover are references for stitches with a left needle position.

  • Page 19: Embroidery Unit

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Embroidery Unit Operation Buttons a “Start/Stop” button Press this button and the machine will sew a few stitches at a slow speed and then begin sewing at the speed set by the sewing speed controller. Press the button again to stop the machine.

  • Page 20: Using The Flat Bed Attachment

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS ■ Closing the Accessory Case Using the Flat Bed Attachment Fully slide the bar on each side of the accessory case lid to the unlocked position. Pull the top of the flat bed attachment to open the accessory compartment.
  • Page 21 NAMES OF MACHINE PARTS AND THEIR FUNCTIONS ■ Using the Accessory Trays Two presser foot storage trays are stored in the included accessory case. One is for presser feet for utility sewing, and the other is for presser feet for embroidery and machine quilting.

  • Page 22: Included Accessories

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Included Accessories 75/11 2 needles 2.0/11 needle 75/11 90/14 2 needles 2 needles 90/14 2 needles: Ball point needle (gold colored)
  • Page 23 NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Part Name Part Code Part Name Part Code 36 Spool stand BLMA-STS 1 Zigzag foot “J” (on machine) XC3022-001 See page 24 2 Monogramming foot “N” X53840-351 37 Spool felt (on machine) X57045-051 3 Overcasting foot “G”...

  • Page 24: Options

    Baby Lock retailer (Part code XA4813-051). Options The following are available as optional accessories to be purchased separately from your authorized Baby Lock retailer. Part Name Part Code Foot Controller XC8816-051 2 Embroidery frame set (small) EF73: Frame H 2 cm ×...

  • Page 25: Using The Multi-Purpose Screwdriver

    • All specifications are correct at the time of printing. Please be aware that some specifications may change without notice. Note • Visit your nearest authorized Baby Lock You can install/remove the needle plate. retailer for a complete listing of optional accessories for your machine.

  • Page 26: Using The Spool Stand

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS ■ Position “3” CAUTION • Do not lift the handle of the machine while the spool stand is installed. • Do not push or pull the telescopic thread guide or spool pins with extreme force, otherwise damage may result.
  • Page 27 NAMES OF MACHINE PARTS AND THEIR FUNCTIONS ■ How to remove Note • Make sure that the stoppers on the Pull the spool stand up to remove it from telescopic thread guide shaft are firmly in the machine. place and that the thread guide openings are directly above the two holes for spool pins in the spool support.

  • Page 28: Using The Multi-Function Foot Controller (Only For Supplied Models)

    NAMES OF MACHINE PARTS AND THEIR FUNCTIONS Insert the plug for the main foot controller Using the Multi-function Foot into the foot controller jack on the right side of the machine. Controller (Only for supplied models) Refer to see “Specifying the Multi-Function Foot Controller (Only for supplied models)”...

  • Page 29: Chapter 1 Getting Ready

    Chapter Getting Ready ■ Attaching/Detaching toe............71 TURNING THE MACHINE ON/OFF ....... 28 ■ Using the Dual Feed Position Lever ..........72 ■ Adjusting the Amount of Fabric Feeding of the Dual Feed Foot ..72 Setting Your Machine for the First Time........29 CHANGING THE NEEDLE ........73 LCD SCREEN ............

  • Page 30: Turning The Machine On/Off

    If the cord or plug is damaged, take the machine to your authorized Baby Lock retailer for repairs before continuing use. • Unplug the power cord if the machine is not to be used for a long period of time. Otherwise, a fire may result.

  • Page 31: Setting Your Machine For The First Time

    TURNING THE MACHINE ON/OFF Insert the power supply cord into the power Press cord receptacle, then insert the plug into a wall outlet. The message screen, confirming if you want to set time/date, appears. To set the time/ date, press ;...

  • Page 32: Lcd Screen

    LCD SCREEN LCD SCREEN When the machine is turned on, the opening No. Display Key Name Explanation Page movie is played. Touch anywhere on the screen Sewing Press this key to see for the home page screen to be displayed. Touch machine explanations on how to help key...

  • Page 33: Using The Machine Setting Mode Key

    LCD SCREEN Using the Machine Setting Mode Key Press to change the default machine settings (needle stop position, embroidery speed, opening display, etc.). To display the different settings screens, press for “Sewing settings”, “General settings” or for “Embroidery settings”. Memo •...
  • Page 34 The “No.” is the internal machine number for the embroidery and sewing machine. r Display the program version. Memo • The latest version of software is installed in your machine. Check with your local authorized Baby Lock retailer or at “ www.babylock.com ” for available updates (see page 401).
  • Page 35 LCD SCREEN Embroidery settings a Select from among 23 embroidery frame displays (see page 292). b Change the thread color display on the “Embroidery” screen; thread number, color name (see page 291). c When the thread number “#123” is selected, select from six thread brands (see page 291). d Adjust the maximum embroidery speed setting (see page 291).

  • Page 36: Saving A Settings Screen Image To Usb Media

    LCD SCREEN ■ Saving a Settings Screen Image to ■ Selecting the “Eco Mode” or USB Media “Shutoff Support Mode” An image of the settings screen can be saved as a You can save the machine power by setting the eco BMP file.

  • Page 37: Changing The Pointer Shape When A Usb Mouse Is Used

    LCD SCREEN ■ Changing the Screen Saver Image Note Instead of the default image, you can select your • If you turn off the machine while the own personal images for the screen saver of your machine is in the “Eco Mode” or the machine.

  • Page 38: Selecting The Initial Screen Display

    LCD SCREEN Connect the USB media or the computer Press a file name to select image and then (using a USB cable) that contains your press personal image to the USB port of the machine. See page 46 about USB connectivity. Press to select the first image.

  • Page 39: Choosing The Display Language

    LCD SCREEN ■ Changing the Background Colors of Opening Screen: When the machine is turned on, the home page screen appears after the opening the Embroidery Patterns movie screen is touched. Home Page: When the machine is turned on, the In the settings screen, the background colors can be home page screen appears.

  • Page 40: Specifying The Size Of Pattern Thumbnails

    LCD SCREEN ■ Specifying the Size of Pattern Select the background color from the 66 color thumbnails shown. Thumbnails The thumbnails for selecting an embroidery pattern can be set to be displayed at the normal size or a larger size. The larger size is 1.5 times the normal size.
  • Page 41 LCD SCREEN Press to select the desired thumbnail size. Note • When thumbnail size setting has been changed the pattern selection screen will not immediately reflect the chosen size. To view the patterns with the new thumbnail size, return to the category selection screen, and then select the pattern category again.

  • Page 42: Using The Sewing Machine Help Key

    LCD SCREEN Using the Sewing Machine Help Key Press to open the sewing machine help screen. Four functions are available from the screen shown below. a Press this key to see explanation for upper threading, winding the bobbin, changing the presser foot, preparing to embroider a pattern, and how to use the machine (see page 45).

  • Page 43: Using The Operation Guide Function

    LCD SCREEN Using the Operation Guide Function Press to open the screen shown below. Six categories are displayed at the top of the screen. Press a key to see more information about that category. displays information about displays information about displays information about the main parts of the machine and their the operation buttons.

  • Page 44: Using The Sewing Guide Function

    LCD SCREEN Example: Displaying information about Using the Sewing Guide Function upper threading Press The sewing guide function can be used to select patterns from the Utility Stitch screen. Use this function when you are not sure which Press stitch to use for your application, or to get advice about sewing particular stitches.

  • Page 45: Playing A Tutorial Video

    LCD SCREEN Play the tutorial video. Playing a Tutorial Video Memo • When you find this icon on the title in this manual, you can find the tutorial video of the procedure in your machine. This machine provides tutorial videos on how to use the machine.

  • Page 46: Playing Mpeg-4 (Mp4) Videos

    LCD SCREEN Select the video that you want to play. Playing MPEG-4 (MP4) Videos Your MP4 videos can be played from USB media. In addition, the MP4 video can be saved to the machine so that a tutorial video on creating a project, for example, can be viewed at any time.

  • Page 47: Using The Pattern Explanation Function

    LCD SCREEN Press Using the Pattern Explanation Function If you want to know more about the uses of a stitch pattern, select the pattern and press and then to see an explanation of the stitch selection. Note • With the pattern explanation function, descriptions can be displayed for the patterns available on the Utility Stitch and Character/Decorative Stitch screens.

  • Page 48: Connecting The Accessory To The Machine

    CONNECTING THE ACCESSORY TO THE MACHINE CONNECTING THE ACCESSORY TO THE MACHINE Refer to “Connecting Your Machine to the PC” on Using USB Media page 187 for the available computer operating systems. When sending or reading patterns using the USB media, connect the device to the USB port.

  • Page 49: Using A Usb Mouse (Sold Separately)

    CONNECTING THE ACCESSORY TO THE MACHINE ■ Clicking a Key Using a USB Mouse (Sold When the mouse is connected, the pointer appears Separately) on the screen. Move the mouse to position the pointer over the desired key, and then click the left mouse button.

  • Page 50: Using The Sensor Pen

    USING THE SENSOR PEN USING THE SENSOR PEN Convenient Sewing Features by Using the Sensor Pen By using the sensor pen, you have the option of four separate functions • Setting the guideline as a reference for your sewing position. •...

  • Page 51: Using The Sensor Pen Holder

    USING THE SENSOR PEN Set the sensor pen in the sensor pen holder Using the Sensor Pen Holder with the pen tip pointing downward, and then connect the sensor pen to the When connecting the sensor pen to the machine, machine.

  • Page 52: Important Information About Sensor Pen

    USING THE SENSOR PEN Calibrating the Sensor Pen Memo • The sensor pen can be used to touch on the screen as a touch pen. Before using the sensor pen for the first time, be sure to personalize it using “Sensor Function Calibration”...
  • Page 53 USING THE SENSOR PEN Touch the first point of green dot marking using the sensor pen. Touch on the needle plate cover. a Flat bed attachment b Embroidery unit Press to finish the calibration. To repeat the calibration touch the first point again using the sensor pen, and continue a Needle plate cover with step...

  • Page 54: Lower Threading

    LOWER THREADING LOWER THREADING Turn the main power to ON and open the Winding the Bobbin top cover. Align the groove in the bobbin with the spring on the bobbin winder shaft, and set CAUTION the bobbin on the shaft. •...
  • Page 55 LOWER THREADING With your right hand, hold the thread near the thread spool. With your left hand, hold CAUTION the end of the thread, and use both hands to pass the thread through the thread guide. • If the thread spool and/or spool cap are set incorrectly, the thread may tangle on the spool pin and cause the needle to break.
  • Page 56 LOWER THREADING Pass the end of the thread through the guide slit in the bobbin winder seat, and pull the Note thread to the right to cut the thread with • changes to while the bobbin the cutter. is winding. •...

  • Page 57: Using The Spool Pin

    LOWER THREADING Align the groove in the bobbin with the Memo spring on the bobbin winder shaft, and set • When removing the bobbin, do not pull on the bobbin on the shaft. the bobbin winder seat. Doing so could loosen or remove the bobbin winder seat, and could result in damage to the machine.

  • Page 58: Using The Spool Stand

    LOWER THREADING Pass the thread through the thread guide. Memo • See page 24 to assemble the spool stand. • See page 65 to thread the machine using the spool stand. CAUTION • When winding thread on the bobbin, do not cross the bobbin winding thread with the a Thread guide upper thread in the thread guides.

  • Page 59: Setting The Bobbin

    LOWER THREADING Cut the thread with scissors near the pre- Setting the Bobbin tension disk. CAUTION • Use a bobbin thread that has been correctly wound. Otherwise, the needle may break or the thread tension will be incorrect. a Pre-tension disk Push the bobbin winder switch to the right, and then raise the bobbin at least 100 mm (4 inches) from the shaft.
  • Page 60 LOWER THREADING Remove the bobbin cover. Note • If the thread is not correctly inserted through the tension spring of the bobbin Hold the bobbin with your right hand and case, it may cause incorrect thread tension. hold the end of the thread with your left (see page 90) hand.

  • Page 61: Pulling Up The Bobbin Thread

    LOWER THREADING Gently pull the upper thread. A loop of the Pulling Up the Bobbin Thread bobbin thread will come out of the hole in the needle plate. There may be some sewing applications where you want to pull up the bobbin thread; for example, when making gathers, darts, or doing free motion quilting or embroidery.

  • Page 62: Upper Threading

    UPPER THREADING UPPER THREADING → The upper thread shutter opens so the machine can Upper Threading be threaded. CAUTION • Be sure to thread the machine properly. Improper threading can cause the thread to tangle and break the needle, leading to injury. •...
  • Page 63 UPPER THREADING Push the spool cap onto the spool pin as far While holding the thread with both hands, as possible, then return the spool pin to its pull the thread up from under the thread original position. guide plate. CAUTION •...
  • Page 64 UPPER THREADING Pass the thread through the needle bar thread guide (marked “6”) by holding the Note • When using thread that quickly winds off thread with both hands and guiding it as the spool, such as metallic thread, it may be shown in the illustration.

  • Page 65: Using The Twin Needle Mode

    CAUTION • Twin needle (part code XE4963-001) is recommended for this machine. Contact your authorized Baby Lock retailer for replacement needles (size 2.0/11 is recommended). a About 100-150 mm (approx. 4-6 inches) • Be sure to set the twin needle mode when using the twin needle.
  • Page 66 UPPER THREADING Thread the machine for the first needle Place the additional spool of thread on the according to the procedure for threading a supplemental spool pin, so that the thread single needle (“Upper Threading” on unwinds from the front. Push the spool cap page 60).

  • Page 67: Using The Spool Stand

    UPPER THREADING Continue threading however do not pass Start sewing. the thread in the needle bar thread guide Sample of Twin Needle Sewing “6” on the needle bar. Thread the needle on the right side. a Needle bar thread guide Memo •...
  • Page 68 UPPER THREADING • When using thread on a thin spool, place the Attach the spool stand to the machine. (see included spool felt on the spool pin, place the page 24.) thread spool on the spool pin so that the center of the spool is aligned with the hole at the center of the spool felt, and then insert the spool cap onto the spool pin.

  • Page 69: Using Threads That Unwind Quickly

    UPPER THREADING Pull the thread off the spool. Pass the thread Using Threads that Unwind from the back to the front through the thread guides at the top. Quickly When using thread that quickly feeds off the spool, such as metallic thread, use the enclosed ring to prevent the thread from becoming entangled.

  • Page 70: Changing The Presser Foot

    CHANGING THE PRESSER FOOT CHANGING THE PRESSER FOOT CAUTION • Always press on the screen to lock all keys and buttons before changing the presser foot. If not pressed and the “Start/Stop” button or another button is pressed, the machine will start and may cause injury.

  • Page 71: Attaching The Presser Foot With The Included Adapter

    CHANGING THE PRESSER FOOT Loosen the screw of the presser foot holder Attaching the Presser Foot with to remove the presser foot holder. the Included Adapter You can attach the presser feet using the included adapter and small screw. For example, the walking foot, the free motion echo quilting foot “E”, the free motion quilting foot “C”...

  • Page 72: Using The Dual Feed Foot

    CHANGING THE PRESSER FOOT Set the operation lever of the walking foot Using the Dual Feed Foot so that the needle clamp screw is set in the fork. Position the shank of the walking foot on the presser foot bar. Dual feed foot enables you to have best fabric control when sewing difficult fabrics that slip easily, such as quilted fabrics or fabrics that tend...

  • Page 73: Attaching/Detaching Toe

    CHANGING THE PRESSER FOOT ■ Attaching/Detaching toe Hold the dual feed foot in place with your right hand, then using the included Attach the toe by aligning the pins with the notches screwdriver securely tighten the large and snap it into place. screw.

  • Page 74: Using The Dual Feed Position Lever

    CHANGING THE PRESSER FOOT ■ Using the Dual Feed Position Lever to increase or decrease the When the feed position lever is up, the black roller feeding of the top fabric. belt on the dual feed is not engaged. Select “00” for sewing in most cases. If the feed amount for the top fabric is too little, causing the fabric to be longer than the bottom fabric, press...

  • Page 75: Changing The Needle

    CHANGING THE NEEDLE CHANGING THE NEEDLE CAUTION • Always press on the screen to lock all keys and buttons before changing the needle. If is not pressed and the “Start/Stop” button or another operation button is pressed accidentally, the machine will start and injury may result.
  • Page 76 CHANGING THE NEEDLE With the flat side of the needle facing the back, insert the new needle all the way to the top of the needle stopper (viewing window) in the needle clamp. Use a screwdriver to securely tighten the needle clamp screw.

  • Page 77: About The Needle

    CHANGING THE NEEDLE About the Needle The sewing machine needle is probably the most important part of the sewing machine. Choosing the proper needle for your sewing project will result in a beautiful finish and fewer problems. Below are some things to keep in mind about needles.

  • Page 78: Needle Calibration Using The Built In Camera

    NEEDLE CALIBRATION USING THE BUILT IN CAMERA NEEDLE CALIBRATION USING THE BUILT IN CAMERA Setting the camera needle position is essential Press the “Automatic Threading” button. when you use camera function. It is not necessary to perform this operation each time, but we recommend performing it when the needle is changed.
  • Page 79 3 and 4 of step . If multiple attempts to set the position are not successful, contact your nearest Baby Lock retailer. a White sticker Note • Use a new sticker. The camera needle position cannot be set correctly if there is a hole in sticker or if it is dirty.
  • Page 80 NEEDLE CALIBRATION USING THE BUILT IN CAMERA...

  • Page 81: Chapter 2 Sewing Basics

    Chapter Sewing Basics SEWING ..............80 Sewing a Stitch................80 ■ Using the Multi-Function Foot Controller ........ 81 Specifying the Multi-Function Foot Controller (Only for supplied models) ............82 ■ Functions That Can Be Specified ..........82 ■ Specifying the Functions............82 Sewing Reinforcement Stitches ..........83 Automatic Reinforcement Stitching ..........83 Sewing Curves................85...

  • Page 82: Sewing

    SEWING SEWING CAUTION • To avoid injury, pay special attention to the needle while the machine is in operation. Keep your hands away from moving parts while the machine is in operation. • Do not stretch or pull the fabric during sewing. Doing so may lead to injury. •...

  • Page 83: Using The Multi-Function Foot Controller

    SEWING Press the “Start/Stop” button to start sewing. Note • When cutting thread thicker than #30, nylon Guide the fabric lightly by hand. monofilament thread, or other decorative threads, use the thread cutter on the side of the machine. When the needle has stopped moving, raise Memo the presser foot and remove the fabric.

  • Page 84: Specifying The Multi-Function Foot Controller (Only For Supplied Models)

    SEWING ■ Functions That Can Be Specified Insert the multi-function foot controller plug into its jack on the machine. Before connecting the multi-function foot controller, be sure to assemble the controller. Refer to “Assembling the Controller” on page 26. Controller Functions that can be specified a Main foot controller Start/Stop...

  • Page 85: Sewing Reinforcement Stitches

    SEWING Press the end of sewing (Refer to the next procedure “Automatic Reinforcement Stitching”.). Display page 2 of the Sewing Settings screen. Select the functions to be performed by the multi-function foot controller. a Reverse stitch b Reinforcement stitch The operation performed when the button is pressed differs depending on the selected pattern.
  • Page 86 SEWING Memo “Reverse Stitch” “Reinforcement • Some stitches, such as buttonholes and bar button Stitch” button tacks, require reinforcement stitches at the beginning of sewing. If you select one of Machine starts Machine starts these stitches, the machine will sewing the stitches sewing the stitches automatically turn on this function (the key and only sews...

  • Page 87: Sewing Curves

    SEWING ■ Sewing a Seam Allowance of 0.5 cm Sewing Curves or Less Baste the corner before sewing, and then, after Sew slowly while keeping the seam parallel with changing the sewing direction at the corner, pull the the fabric edge as you guide the fabric around the basting thread toward the back while sewing.

  • Page 88: Sewing Hook-And-Loop Fastener Tape

    SEWING ■ If the Fabric does not Fit under the Release the black button. Presser Foot If the presser foot is in the up position, and you are sewing heavyweight or multiple layers of fabric which do not fit easily under the presser foot, use the presser foot lever to raise the presser foot to its highest position.

  • Page 89: Sewing Lightweight Fabrics

    SEWING Make sure that the needle passes through the Sewing Stretch Fabrics hook-and-loop fastener tape by rotating the handwheel and lower the needle into the hook- and-loop fastener tape before sewing. Sew the First, baste together the pieces of fabric, and then edge of the hook-and-loop fastener tape at a slow sew without stretching the fabric.

  • Page 90: Stitch Settings

    STITCH SETTINGS STITCH SETTINGS When you select a stitch, your machine automatically selects the appropriate stitch width, stitch length, and upper thread tension. However, if needed, you can change any of the individual settings. Note • Settings for some stitches cannot be changed (refer to the “STITCH SETTING CHART” at the end of this manual).

  • Page 91: Setting The Stitch Length

    STITCH SETTINGS Setting the Stitch Length Setting the “L/R Shift” Follow the steps below when you want to change Follow the steps below when you want to change the stitch pattern length. the placement of the zigzag stitch pattern by moving it left and right.

  • Page 92: Setting The Thread Tension

    STITCH SETTINGS Setting the Thread Tension Memo • When you finish sewing, remove the bobbin cover and then make sure that the thread is You may need to change the thread tension, shown as below. If the thread is not shown depending on the fabric and thread being used.

  • Page 93: Useful Functions

    USEFUL FUNCTIONS USEFUL FUNCTIONS Set the fabric in the start position and start Automatic Thread Cutting sewing. After selecting a stitch pattern, turn on the automatic thread cutting function before sewing, and the machine will automatically sew reinforcement stitches (or reverse stitches, depending on the stitch pattern) at the beginning and end of sewing, and trim the threads at the end of sewing.

  • Page 94: Adjusting The Needle Drop Position With The Guideline Marker

    USEFUL FUNCTIONS ■ Adjusting the Guideline Marker Adjusting the Needle Drop Position Position with the Guideline If the guideline marker indicates the position Marker incorrectly in the center needle position, adjust the initial position in the settings screen. The red guideline marker indicates the sewing Press to display “Guideline Marker position on the fabric.

  • Page 95: Pivoting

    USEFUL FUNCTIONS ■ Adjusting the Brightness of the Memo Guideline Marker • When the pivot setting is selected, the height of the presser foot when sewing is Follow steps from to display the stopped can be changed according to the “Guideline Marker Adjustment”...

  • Page 96: Using The Knee Lifter

    USEFUL FUNCTIONS Press to select the pivot setting. Rotate the fabric, and then press the “Start/ Stop” button. → The presser foot is automatically lowered, and sewing continues. Using the Knee Lifter Using the knee lifter, you can raise and lower the presser foot with your knee, leaving both hands →...

  • Page 97: Automatic Fabric Sensor System (Automatic Presser Foot Pressure)

    USEFUL FUNCTIONS Align the tabs on the knee lifter with the Automatic Fabric Sensor System notches in the knee lifter slot on the front of the machine. Insert the knee lifter bar as far (Automatic Presser Foot as possible. Pressure) The thickness of the fabric is automatically detected and the presser foot pressure is automatically adjusted with an internal sensor...

  • Page 98: Needle Position - Stitch Placement

    USEFUL FUNCTIONS Needle Position - Stitch Checking the Needle Location in Placement the Screen When the “Needle Position - Stitch Placement” is You can check the stitch image with actual fabric “ON”, the needle will be partially lowered for image on the screen. precise stitch placement and then press the Select a stitch.

  • Page 99: Using The Camera View Window

    USEFUL FUNCTIONS ■ Using the Camera View Window NEEDLE DROP POSITION Press to show the needle drop position in the screen as “ ”. Lower the presser foot before pressing Once the needle drop position appears on the screen, you can raise the presser foot and change the needle drop position by moving the fabric.

  • Page 100: Using Sensor Functions With Sewing Stitch

    USING SENSOR FUNCTIONS WITH SEWING STITCH USING SENSOR FUNCTIONS WITH SEWING STITCH Before using the sensor functions, carefully read “Utility Stitches” chapter to familiarize yourself with the machine operations. The sensor functions are performed using the sensor pen. Sensor Function Area Memo •...
  • Page 101 USING SENSOR FUNCTIONS WITH SEWING STITCH Press Memo • The position can be precisely adjusted by touching the adjustment areas with the sensor pen. • When using the sensor pen to specify the guideline marker position, it may not be possible to exactly specify the desired location.

  • Page 102: Specifying The Needle Drop Position With The Sensor Pen

    USING SENSOR FUNCTIONS WITH SEWING STITCH With the sensor pen, touch the location to Specifying the Needle Drop be specified as the needle drop position. Position With the Sensor Pen → The guideline marker moves to the touched position and flashes. →...

  • Page 103: Using The Sensor Pen To Specify The Stitching Width And Stitch Position

    USING SENSOR FUNCTIONS WITH SEWING STITCH Press to apply the reference position Press setting. The setting can also be applied by extended touch in the adjustment area with the sensor pen. → The needle moves to the specified position to start sewing.
  • Page 104 USING SENSOR FUNCTIONS WITH SEWING STITCH Press to apply the second point of the Note stitching width. • The following error message appears if the area outside of the sensor pen touch range The setting can also be applied by long touching an adjustment area with the sensor pen.

  • Page 105: Using The Sensor Pen To Specify The Sewing End Point

    USING SENSOR FUNCTIONS WITH SEWING STITCH Press Using the Sensor Pen to Specify the Sewing End Point Note • In order to specify the end point of a longer piece of fabric more accurately, use the sensor pen to touch the end point twice. Be sure to touch the same point.
  • Page 106 USING SENSOR FUNCTIONS WITH SEWING STITCH With the sensor pen, touch the location to Note be specified as the sewing end point. • The displayed distance is not the length of a → The distance from the current needle position to the straight line connecting the current needle position and the location touched with the touched location appears.
  • Page 107 USING SENSOR FUNCTIONS WITH SEWING STITCH With the sensor pen, touch again the Note location to be specified as the sewing end • The stitch end mode key is not available point. with the following situations. → The distance from the current needle position to the - When only is shown.

  • Page 108: Reusing The Previous Setting

    USING SENSOR FUNCTIONS WITH SEWING STITCH ■ Reusing the Previous Setting Note When using the same fabric and pattern to sew the • This resume function will only repeat the same length, the previous setting can be used again, sewing distance that has been assigned instead of using the sensor pen to specify the sewing within the 200 mm (approx.

  • Page 109: Chapter 3 Utility Stitches

    Chapter Utility Stitches ■ Hemstitching (1) (Daisy Stitch) ..........144 SELECTING UTILITY STITCHES......108 ■ Hemstitching (2) (Drawn Work (1))........144 ■ Utility Stitch LCD Screen ............108 ■ Hemstitching (3) (Drawn Work (2))........145 ■ Key Functions ................. 109 Decorative Couching.............. 145 ■...

  • Page 110: Selecting Utility Stitches

    SELECTING UTILITY STITCHES SELECTING UTILITY STITCHES ■ Utility Stitch LCD Screen Press a key with your finger to select the stitch pattern, to select a machine function, or to select an operation indicated on the key. Display Key Name Explanation Page Needle position Shows single or twin needle mode setting, and the needle stop position.

  • Page 111: Key Functions

    SELECTING UTILITY STITCHES ■ Key Functions Display Key Name Explanation Page Utility stitch key Press this key to select a straight stitch, zigzag stitch, buttonhole, blind hem stitch, or other stitches commonly used in garment construction. Character/Decorative Press this key to select character or decorative stitch patterns. stitch key Image key Press this key to display an enlarged image of the selected stitch pattern.

  • Page 112: Stitch Selection Screens

    SELECTING UTILITY STITCHES Display Key Name Explanation Page Stitch width and Shows the zigzag width and stitch length settings of the currently selected stitch length key stitch pattern. You can use the plus and minus keys to adjust the zigzag width and stitch length settings.

  • Page 113: Selecting A Stitch

    SELECTING UTILITY STITCHES ■ Using the Mirror Image Key Selecting a Stitch Depending on the type of utility stitch you select, you may be able to sew a horizontal mirror image of the stitch. Turn the main power to ON and press is lit when you select a stitch, it will be to display the utility stitches.

  • Page 114: Returning To The Beginning Of The Stitch

    SELECTING UTILITY STITCHES ■ Returning to the Beginning of the ■ Using the Image Key Stitch You can display an image of the selected stitch. You can check and change the colors of the image of the Even if you stopped stitching while sewing, you can screen.

  • Page 115: Saving Your Stitch Settings

    SELECTING UTILITY STITCHES Saving Your Stitch Settings Memo • If you try to save settings when there are already 5 sets of settings saved for a stitch, The settings for the zigzag stitch width, stitch the message “The pockets are full. Delete a length, thread tension, automatic thread cutting, pattern”...

  • Page 116: Sewing The Stitches

    SEWING THE STITCHES SEWING THE STITCHES Straight Stitches Stitch Stitch name Presser foot Straight stitch (Left) Straight stitch (Left) a Reverse stitch Straight stitch (Middle) b Reinforcement stitch Memo Straight stitch (Middle) • If the selected stitch has a double mark “ ” at the top of the key display, you can sew reverse stitches holding the “Reverse Triple stretch stitch...
  • Page 117 SEWING THE STITCHES Hold the thread tail and fabric with your When sewing is completed, hold the left hand, and rotate the handwheel with “Reverse Stitch” button or the your right hand to insert the needle into the “Reinforcement Stitch” button to sew 3-4 fabric.

  • Page 118: Changing The Needle Position (Left Or Middle Needle Position Stitches Only)

    SEWING THE STITCHES ■ Changing the Needle Position (Left ■ Aligning the Fabric with a Mark on or Middle Needle Position Stitches the Needle Plate or Bobbin Cover Only) (with Mark) When you select left or middle needle position While sewing, align the edge of the fabric with the 16 mm (approx.

  • Page 119: Aligning The Fabric With The Vertical Stitch Alignment "V" Foot

    SEWING THE STITCHES ■ Aligning the Fabric with the Vertical Remove the flat bed attachment or the embroidery unit if either are attached. Stitch Alignment “V” Foot Grasp both sides of the needle plate cover, Sew while keeping the right edge of the fabric aligned with a desired position of markings on the and then slide it toward you.

  • Page 120: Basting

    SEWING THE STITCHES Press to unlock all keys and buttons, Note and then start sewing. • Align the two screw holes on the needle After sewing, make sure to remove the straight stitch plate with the two holes on the machine. needle plate and the straight stitch foot, and reinstall Use the multi-purpose screw driver the regular needle plate, the needle plate cover and...

  • Page 121: Dart Seam

    SEWING THE STITCHES Dart Seam Gathering Use on waists of skirts, sleeves of shirts, etc. Select and attach presser foot “J”. Select a straight stitch and attach presser foot “J”. Sew a reverse stitch at the beginning of the dart and then sew from the wide end to the other end without stretching the fabric.

  • Page 122: Flat Fell Seam

    SEWING THE STITCHES Sew two rows of straight stitches parallel to the seam line, then trim excess thread leaving 50 mm (approx. 1-15/16 inches). a About 12 mm (approx. 1/2 inch) b Wrong side a Seam line b 10 to 15 mm (approx. 3/8 inch to 9/16 inch) Spread the fabric out along the finish line.

  • Page 123: Pintuck

    SEWING THE STITCHES Finished flat fell seam Sew a straight stitch along the fold. When the automatic thread cutting and automatic reinforcement stitching are preset, reverse stitches will be sewn automatically at the beginning of sewing. Press the “Reinforcement Stitch” button to sew a reinforcement stitch and trim the thread automatically at the end of sewing.

  • Page 124: Zigzag Stitches

    SEWING THE STITCHES ■ Appliqué (Using a Zigzag Stitch) Zigzag Stitches Attach the appliqué material using a temporary spray adhesive or basting, and then sew it. Zigzag stitches are useful for overcasting, Sew a zigzag stitch while positioning the right-hand appliqué, patchwork, and many other side needle drop point just outside the edge of the applications.

  • Page 125: Elastic Zigzag Stitches

    SEWING THE STITCHES ■ Cord Guide Bobbin Cover (Using a Lower the presser foot and start sewing to make a decorative finish. Zigzag Stitch) Remove the bobbin cover from the machine (see page 57). Thread the gimp thread through the hole in the cord guide bobbin cover from top to bottom.

  • Page 126: Overcasting

    SEWING THE STITCHES ■ Overcasting Sew along the presser foot guide. Use this stitch to sew overcasting on the edge of stretch fabrics. Sew the overcasting along the edge of the fabric while positioning the right-hand side needle drop point just outside the edge of the fabric. a Guide CAUTION •...

  • Page 127: Overcasting Using Presser Foot "J

    SEWING THE STITCHES ■ Overcasting Using Presser Foot “J” ■ Overcasting Using the Side Cutter (Sold Separately) Stitch Stitch name Presser foot By using the side cutter, you can do overcasting Overcasting stitch while cutting the fabric. CAUTION Overcasting stitch •...
  • Page 128 SEWING THE STITCHES Position the fork on the side cutter’s Make a cut of approximately 20 mm operating lever onto the needle clamp (approx. 3/4 inch) in the fabric. screw. a 20 mm (approx. 3/4 inch) a Needle clamp screw b Operating lever Position the fabric so that the right side of the cut is on top of the guide plate and the...

  • Page 129: Quilting

    SEWING THE STITCHES • When using the side cutter, sew Memo between low and mid-speed and do • The fabric will not be cut if the whole fabric is simply spread out underneath the presser not touch the knives or operation foot guide plate.
  • Page 130 SEWING THE STITCHES Presser foot Presser foot Stitch Stitch name Stitch Stitch name Stem stitch Decorative stitch Quilting appliqué zigzag stitch Decorative stitch Zigzag stitch (Right) Hemstitching Zigzag stitch (Left) Hemstitching 2 steps elastic zigzag Single diamond overcast 3 steps elastic zigzag Overcasting stitch Quilting appliqué...

  • Page 131: Piecing

    SEWING THE STITCHES ■ Piecing ■ Quilting Sewing two pieces of fabric together is called Sewing the quilt top, batting, and backing together is piecing. When cutting pieces for quilt blocks, make called quilting. You can sew the quilt with the dual sure the seam allowance is 6.5 mm (approx.

  • Page 132: Appliqué

    SEWING THE STITCHES ■ Appliqué Use the quilting appliqué stitch to attach the appliqué. Sew around the edge while dropping the needle as close to the edge as Trace the pattern onto the appliqué fabric possible. and then cut around it, leaving a 3 to 5 mm (approx.

  • Page 133: Quilting With Satin Stitches

    SEWING THE STITCHES ■ Quilting with Satin Stitches Memo For better fabric control, use the foot controller to • You can use the speed control slide to sew with satin stitches. Set the speed control slide to adjust the stitch width. Use the foot control the stitch width to make subtle changes in controller to adjust the sewing speed.
  • Page 134 SEWING THE STITCHES Using Free motion Quilting Foot “C” Attach the straight stitch needle plate (see page 117). Use the free motion quilting foot “C” with straight stitch needle plate for free motion sewing. Free motion quilting foot “C” a Round hole Memo CAUTION •...
  • Page 135 SEWING THE STITCHES CAUTION • Be sure to securely tighten the screws with the included multi-purpose screwdriver. Otherwise, the needle may touch the quilting foot, causing it to bend or break. Use both hands to stretch the fabric taut, and then move the fabric at a consistent pace in order to sew uniform stitches roughly 2.0-2.5 mm (approx.
  • Page 136 SEWING THE STITCHES Using free motion Open Toe Quilting Foot “O” Attach free motion open toe quilting foot “O” by positioning the pin of the quilting The free motion open toe quilting foot “O” is used foot above the needle clamp screw and for free motion quilting with zigzag or decorative aligning the lower-left of the quilting foot stitches or for free motion quilting of straight lines on...

  • Page 137: Echo Quilting Using The Free Motion Echo Quilting Foot "E

    SEWING THE STITCHES Press to cancel the free motion sewing Memo mode. • When starting to sew, the internal sensor → Rotate the handwheel toward you detects the thickness of the fabric, and the (counterclockwise) to raise the feed dogs. quilting foot is raised to the height specified in the machine settings screen.

  • Page 138: Blind Hem Stitches

    SEWING THE STITCHES Tighten the screw with the included multi- Finished project purpose screwdriver. Use the multi-purpose screw driver setting the position to “1”. (see page 23) Press to cancel the free motion sewing mode. → Rotate the handwheel toward you (counterclockwise) to raise the feed dogs.
  • Page 139 SEWING THE STITCHES Fold the fabric along the desired edge of the Unfold the edge of fabric, and position the hem, and press. fabric with the wrong side facing up. a Wrong side of fabric a Wrong side of fabric b Right side of Fabric b Right side of fabric c Edge of fabric...

  • Page 140: If The Needle Catches Too Much Of The Hem Fold

    SEWING THE STITCHES <Normal fabric> Adjust the stitch width until the needle slightly catches the fold of the hem. a Wrong side of fabric b Right side of fabric a Needle drop point When you change the needle drop point, raise the ■...

  • Page 141: Appliqué

    SEWING THE STITCHES ■ Appliqué Sharp Curves Appliqué Stop the machine with the needle in the fabric outside the appliqué. Raise the presser foot and turn the fabric a little bit at a time while sewing for an Use a temporary spray adhesive, fabric glue attractive finish to the seam.

  • Page 142: Shelltuck Stitches

    SEWING THE STITCHES Shelltuck Stitches Shelltuck stitches give an attractive appearance of shells along the curve of a collar. This stitch pattern can be used for edging the neckline or sleeves of dresses and blouses. Select a Needle drop position Memo •...

  • Page 143: Crazy Quilting

    SEWING THE STITCHES Attach presser foot “N”. Sew scallop Select a stitch for top stitching. stitches along the edge of the fabric. Do not sew directly on the edge of the fabric. Place the fabric right side up in the machine, and center the presser foot over the seam when sewing.

  • Page 144: Fagoting

    SEWING THE STITCHES Pull the bobbin threads to obtain the Fagoting desired amount of gather, and then smooth the gathers by ironing them. When there is a space between two fabrics with thread sewn over the space to join the fabrics together, it is called fagoting.

  • Page 145: Tape Or Elastic Attaching

    SEWING THE STITCHES Tape or Elastic Attaching Select Select a straight stitch and attach presser Memo foot “J”. • For details on each stitch, refer to the “STITCH SETTING CHART” at the end of this manual. Set the stitch length to 4.0 mm (approx. 3/16 inch), and loosen the upper thread Sew over the tape (or elastic).

  • Page 146: Heirloom

    SEWING THE STITCHES ■ Hemstitching (2) (Drawn Work (1)) Heirloom Pull out several threads from one area on a piece of fabric to open the area. ■ Hemstitching (1) (Daisy Stitch) Pull out 5 or 6 threads to leave a 3 mm (approx.

  • Page 147: Decorative Couching

    SEWING THE STITCHES Match beginning needle drop points on the opposite edge of the open area to keep the Memo • A wing needle can be used for Hemstitching stitching symmetrical. (3). Decorative Couching You can easily sew decorative stitching using yarn, etc.

  • Page 148: Sewing Decorative Couching

    SEWING THE STITCHES Insert the top left yarn guide into the slot on Attach the toe of the couching dual feed the top left of the machine. foot shown below to the dual feed foot. a Slot Pull out the yarn for about 100 mm Press to lock all keys and buttons.

  • Page 149: One-Step Buttonholes

    SEWING THE STITCHES Rotate the handwheel to set the needle in One-step Buttonholes the sewing start position. Start sewing on the right side of the yarn. With one-step buttonholes, you can make Make sure that the yarn, etc. passes straight buttonholes appropriate to the size of your button.
  • Page 150 SEWING THE STITCHES One-step buttonholes are sewn from the front of Pull out the button holder plate on the the presser foot to the back, as shown below. presser foot, and insert the button that will be put through the buttonhole. Then tighten the button holder plate around the button.
  • Page 151 SEWING THE STITCHES Lower the buttonhole lever so that it is Insert a pin along the inside of one of the positioned behind the metal bracket on the bar tacks, and then insert the seam ripper buttonhole foot. into the center of the buttonhole and cut towards the pin.

  • Page 152: Sewing Stretch Fabrics

    SEWING THE STITCHES ■ Sewing Stretch Fabrics ■ Odd Shaped Buttons/Buttons that do Not Fit into the Button Holder Plate When sewing on stretch fabric with , sew Use the markings on the presser foot scale to set the the buttonhole stitches over a gimp thread. size of the buttonhole.

  • Page 153: Four-Step Buttonholes

    SEWING THE STITCHES Attach monogramming foot “N”, and select Four-step Buttonholes stitch to sew the left side of the You can sew 4-step buttonholes using the buttonhole. following 4 stitches together. You can sew any desired length for the buttonhole when using 4- Press the “Start/Stop”...

  • Page 154: Darning

    SEWING THE STITCHES ■ Darning Check that the needle drops at the desired position and lower the presser foot, making Use darning stitches for mending and other sure the upper thread passes underneath applications. the buttonhole foot. Stitch Stitch name Presser foot Darning Darning...

  • Page 155: Bar Tacks

    SEWING THE STITCHES Gently hold the end of the upper thread, and then press the “Start/Stop” button to Memo • Bar tacks can be between 5 mm (approx. start the machine. 3/16 inch) and 28 mm (approx. 1-1/16 inches). Bar tacks are usually between 5 mm (approx.

  • Page 156: Button Sewing

    SEWING THE STITCHES Lower the buttonhole lever so that it is positioned behind the metal bracket on the Memo • If automatic thread cutting is turned on buttonhole foot. before you start sewing, both threads are automatically cut after the reinforcement stitches are sewn.

  • Page 157: Eyelet

    SEWING THE STITCHES ■ Attaching a Shank to the Button Gently hold the end of the upper thread and start sewing. Pull the shank lever toward you before → The machine stops automatically when sewing is sewing. finished. CAUTION • Make sure the needle does not strike the button during sewing.

  • Page 158: Multi-Directional Sewing (Straight Stitch And Zigzag Stitch)

    SEWING THE STITCHES Select Use the eyelet punch to make a hole in the center of the stitching. in either the stitch width display or the stitch length display to choose the size of the eyelet. Multi-directional Sewing (Straight Stitch and Zigzag Stitch) Actual size a Large 7 mm (approx.

  • Page 159: Zipper Insertion

    SEWING THE STITCHES Set the needle in the fabric at the sewing Zipper Insertion start point, and sew seam “1” as shown. ■ Centered Zipper Use for bags and other such applications. Select Memo • For details on each stitch, refer to the a Start Point “STITCH SETTING CHART”...

  • Page 160: Inserting A Side Zipper

    SEWING THE STITCHES ■ Inserting a Side Zipper Remove presser foot “J”. Align the right side of the pin in zipper foot “I” with the Use for side zippers in skirts or dresses. presser foot holder, and attach the zipper foot.
  • Page 161 SEWING THE STITCHES Align the right side of the pin in zipper foot Close the zipper, turn the fabric over, and “I” with the presser foot holder, and attach sew a basting stitch. the presser foot. a Front of the skirt (wrong side of fabric) b Basting stitches c Front of the skirt (right side of fabric) a Right...

  • Page 162: Edge Sewing

    SEWING THE STITCHES Open the zipper and sew the rest of the seam. Note • Clean stitching cannot be sewn if this function is used when the edge of the fabric has corners as shown below. a Basting stitches b 7 to 10 mm (approx. 1/4 inch to 3/8 inch) •...
  • Page 163 SEWING THE STITCHES Attach the vertical stitch alignment foot “V”. CAUTION a Edge sewing sheet • When edge sewing with the built-in camera, b Feed dogs be sure to use the vertical stitch alignment foot c Between the feed dogs and the edge sewing sheet “V”.
  • Page 164 SEWING THE STITCHES → Depending on the stitch, the straight stitch with the Move the fabric to the desired position for middle (center) needle position is selected, edge sewing. Position the fabric so that its regardless of the preset stitch width. edge is as straight as possible.
  • Page 165 SEWING THE STITCHES (with a blue starting point), blue (with a black When the Fabric Edge Indicator Line Is Not starting point) or black (with a red starting point). Aligned With the Edge of the Fabric The fabric edge indicator line that appears is not aligned with the edge of the fabric.
  • Page 166 SEWING THE STITCHES While checking the screen for the distance from the fabric edge to the edge sewing Note • Distances between 1.5 mm (about 1/16 position, move the fabric to the desired inch) and 38.5 mm (about 1-1/2 inches) can position.
  • Page 167 SEWING THE STITCHES Press the “Start/Stop” button to start edge When sewing is between 10 and 20 mm sewing. (about 3/8 and 3/4 inch) from the edge of → Sewing starts with the set distance to the edge of the the fabric, sewing stops automatically and fabric maintained.
  • Page 168 SEWING THE STITCHES...

  • Page 169: Chapter 4 Character/Decorative Stitches

    Chapter Character/Decorative Stitches SELECTING STITCH PATTERNS ......168 ■ Stitch Selection Screens ............169 Selecting Decorative Stitch Patterns/7mm Decorative Stitch Patterns/Satin Stitch Patterns/7mm Satin Stitch Patterns/ Cross Stitch/Utility Decorative Stitch Patterns .......170 Alphabet Characters/Japanese characters.......170 ■ Deleting Characters..............171 ■ Adjusting the Character Spacing ..........171 SEWING STITCH PATTERNS.........

  • Page 170: Selecting Stitch Patterns

    SELECTING STITCH PATTERNS SELECTING STITCH PATTERNS Press , then to display the screen below. a Decorative stitch patterns b 7mm decorative stitch patterns. You can set stitch length and width. c Satin stitch patterns d 7mm satin stitch patterns. You can set stitch length and width. e Cross stitch f Utility decorative stitch patterns g Alphabet characters (gothic font)

  • Page 171: Stitch Selection Screens

    SELECTING STITCH PATTERNS ■ Stitch Selection Screens There are 11 categories of Character/Decorative stitch patterns. If appears, there is more than one stitch selection screen for that category. Decorative Stitch Patterns 7mm Decorative Stitch Satin Stitch Patterns 7mm Satin Stitch Patterns Patterns Cross Stitch Utility Decorative Stitch...

  • Page 172: Selecting Decorative Stitch Patterns/7Mm Decorative Stitch

    SELECTING STITCH PATTERNS Selecting Decorative Stitch Alphabet Characters/Japanese Patterns/7mm Decorative Stitch characters Patterns/Satin Stitch Patterns/ Entering characters from the groups shown below, 7mm Satin Stitch Patterns/ for example “Blue Sky”. Cross Stitch/Utility Decorative Press Stitch Patterns select a font. Select the category of the pattern you want to sew.

  • Page 173: Deleting Characters

    SELECTING STITCH PATTERNS ■ Deleting Characters Press to enter a space. Press to delete the last character. Press again and enter “S”. Memo • Characters are deleted individually starting with the last character entered. Press and then enter “ky”. Select the correct character. ■...
  • Page 174 SELECTING STITCH PATTERNS Press to adjust character spacing. Press to increase the character spacing and press to decrease the character spacing. Example: Each setting equals a specific distance between characters. Value: 0 Value 0.18 0.36 0.54 Value: 10 0.72 1.08 1.26 1.44 1.62...

  • Page 175: Sewing Stitch Patterns

    SEWING STITCH PATTERNS SEWING STITCH PATTERNS Sewing Attractive Finishes To achieve attractive results when sewing character/decorative stitches, check the table below for the proper fabric/needle/thread combinations. Note • Other factors, such as fabric thickness, stabilizer material, etc., also have an effect on the stitch, so you should always sew a few trial stitches before beginning your project.

  • Page 176: Making Adjustments

    SEWING STITCH PATTERNS Memo Note • If the fabric is pulled or pushed during • When sewing some patterns, the needle will sewing, the pattern may not turn out temporarily pause in the raised position correctly. Also, depending on the pattern, while the fabric is fed due to the operation there may be movement to the left and right of the needle bar separation mechanism...
  • Page 177 SEWING STITCH PATTERNS → The displayed value decreases each time the button Compare the finished pattern to the is pressed and the pattern will slide to the left. illustration of the correct pattern below. Sew the stitch pattern again. Press , and then adjust the pattern with If the stitch pattern still comes out poorly, make adjustments again.

  • Page 178: Editing Stitch Patterns

    EDITING STITCH PATTERNS EDITING STITCH PATTERNS ■ Key Functions You can create just the finish you want using the editing functions. Make patterns larger or smaller, make mirror images, etc. Note • Some editing functions cannot be used with certain stitch patterns. Only the functions for the displayed keys are available when a pattern is selected.
  • Page 179 EDITING STITCH PATTERNS Display Key Name Explanation Page Pattern display size Show the approximate size of the pattern selected. : Nearly the same size as the sewn pattern : 1/2 the size of the sewn pattern : 1/4 the size of the sewn pattern The actual size of the sewn pattern may differ depending on the type of fabric and thread that is used.

  • Page 180: Changing The Size

    EDITING STITCH PATTERNS Changing the Size Creating a Vertical Mirror Image To create a vertical mirror image, select a stitch Select a stitch pattern, then press to change pattern then press the size of the stitch pattern. The stitch pattern will be sewn in the size highlighted on the key.

  • Page 181: Changing Thread Density (For Satin Stitch Patterns Only)

    EDITING STITCH PATTERNS Changing Thread Density Returning to the Beginning of the (for Satin Stitch Patterns Only) Pattern When sewing character/decorative stitches, you After selecting a satin stitch pattern, press can return to the beginning of the pattern after trial select your preferred thread density.

  • Page 182: Checking The Image

    EDITING STITCH PATTERNS Press to return to the original screen. Checking the Image You can display an approximate size image of the selected stitch pattern. You can also check and Memo change the colors of the image on the screen. •...

  • Page 183: Combining Stitch Patterns

    COMBINING STITCH PATTERNS COMBINING STITCH PATTERNS You can combine many varieties of stitch patterns, such as character stitches, cross stitches or satin stitches. You can also combine stitch patterns of different sizes, mirror image stitch patterns, and others. Before Combining Single stitch sewing is automatically selected for sewing combined patterns.

  • Page 184: Combining Large And Small Stitch Patterns

    COMBINING STITCH PATTERNS Press Combining Large and Small Stitch Patterns Example: Select Press → The large size stitch will be selected. Press again, then press to select the small size. Press to sew the pattern continuously. Memo • Patterns are deleted individually starting with the last pattern entered by pressing →...

  • Page 185: Combining Horizontal Mirror Image Stitch Patterns

    COMBINING STITCH PATTERNS Press to sew continuously. Press again, then press → The entered pattern is repeated. → The pattern is flipped along a vertical axis. Combining Horizontal Mirror Press Image Stitch Patterns Example: → The entered pattern is repeated. Press...

  • Page 186: Combining Stitch Patterns Of Different Length

    COMBINING STITCH PATTERNS Press Combining Stitch Patterns of Different Length Example: → The entered pattern is repeated. Making Step Stitch Patterns (for 7mm Satin Stitch Patterns Only) Press , then press once. You can use the keys with 7mm satin stitch patterns to create a step effect, also called step stitch patterns.

  • Page 187: More Examples

    COMBINING STITCH PATTERNS Press Press Press → The next stitch pattern will move to the right. → The entered pattern is repeated. Press again. ■ More Examples → → → → Press Press → → → → → Press → →...
  • Page 188 COMBINING STITCH PATTERNS → → → Press → → → → → → Press → →...

  • Page 189: Using The Memory Function

    USING THE MEMORY FUNCTION USING THE MEMORY FUNCTION Stitch Data Precautions Observe the following precautions when using stitch data other than that created and saved in this machine. ■ Types of Stitch Data that can be Used • In the Character/Decorative Stitch memory, “.pmv”, “.pmx” and “.pmu” stitch data files can be used with this machine.

  • Page 190: Saving Stitch Patterns In The Machine's Memory

    USING THE MEMORY FUNCTION ■ If the Memory is Full Saving Stitch Patterns in the If the following screen appears while you are trying Machine’s Memory to save a pattern on the machine’s memory, the memory is too full to hold the currently selected stitch pattern.

  • Page 191: Saving Stitch Patterns In The Computer

    USING THE MEMORY FUNCTION Insert the USB media into either of the USB Plug the USB cable connector into the ports on the machine. corresponding USB ports for the computer and for the machine. Turn on your computer and select “Computer (My Computer)”.

  • Page 192: Retrieving Stitch Patterns From The Machine's Memory

    USING THE MEMORY FUNCTION Press Retrieving Stitch Patterns from the Machine’s Memory Press Press → The pocket selection screen appears. Press to return to the original screen without Choose a stitch pattern to retrieve. saving. If the entire saved stitch pattern is not displayed, press the thumbnail.

  • Page 193: Recalling From Usb Media

    USING THE MEMORY FUNCTION Press Press Press to delete the stitch pattern. Press when connecting the USB media to the USB port for mouse. → The selected stitch pattern is retrieved and the sewing screen will be displayed. → Stitch patterns and a folder in a top folder are displayed.

  • Page 194: Recalling From The Computer

    USING THE MEMORY FUNCTION Press when there is a subfolder to sort Press two or more stitch patterns to USB media, Press to delete the stitch pattern. The pattern the stitch pattern in the subfolder is will be deleted from the USB media. displayed.

  • Page 195: Using The Memory Function

    USING THE MEMORY FUNCTION Move/copy the pattern data to “Removable Press Disk”. Press to delete the stitch pattern. The pattern will be deleted from the “Removable Disk” folder in your computer. → Stitch pattern data in “Removable Disk” is written to the machine.
  • Page 196 USING THE MEMORY FUNCTION...

Table of Contents
