Overview
Overview
2
Serial Port
The serial port is a 16550A high speed communications port that
sends/ receives 16 bytes FIFOs. You can attach a serial mouse
or other serial devices directly to the connector.
Power Button
3
Press the power button to turn the system on or off.
Hard Disk Drive LED
4
This indicator shows the activity status of the HDD. It flashes
when the system is accessing data on the HDD and remains off
when no disk activity is detected.
USB Port
5
The USB (Universal Serial Bus) port is for attaching USB devices
such as keyboard, mouse, or other USB-compatible devices.
Power Jack
6
The power adapter converts AC power to DC power for this jack.
Power supplied through this jack supplies power to the system.
To prevent damage to the system, always use the supplied
power adapter.
Security Lock Port
7
This security lock port allows users to secure the system in place
with a key or some mechanical PIN device and attached through
a rubberised metal cable. The end of the cable has a small loop
which allows the whole cable to be looped around a permanent
object, such as a heavy table or other similar equipment, thus
securing the system in place.
1-4
