Web-based Quick Setup Wizard
Choose the WAN Type for Internet access. If ADSL WAN
3
is selected, please continue to read this guide; If Ethernet
WAN is selected, please refer to section 4.4.2 WAN Service
in User Guide.
If you are unwilling to con gure WAN Service now,
you can click the Skip WAN button, and you can
con gure it in the Layer2 Interface referring to
User Guide later.

Troubleshooting

T1. How can I restore my modem router's
con guration to its factory default settings?
Once the modem router is reset, the current settings will be lost and
you will need to reconfigure the modem router. We strongly suggest
you back up the current settings before resetting the modem router.
With the modem router powered on, use a pin to press and hold the
RESET button on the rear panel for 8 to 10 seconds before releasing
it.
T2. What can I do if I forget my password?
1) For default wireless password:
Please refer to the "Wireless Password/PIN" lableled on the
bottom of the modem router.
2) For the web management page password:
Reset the modem router first and then use the default user
name and password: admin/admin.
T3. What can I do if I cannot access 192.168.1.1?
For Mac OS X
Click the Apple icon on the upper left corner of the screen.
Go to "System Preferences -> Network".
Select Airport on the left menu bar, and then click Advanced
for wireless con guration; or select Ethernet for wired
con guration.
In the Con gure IPv4 box under TCP/IP, select Using DHCP.
Click Apply to save the settings.
( For Mac OS/Linux/Windows users who are unable to run the Resource CD )
Choose the WAN Link Type given by your ISP. Here we
4
use PPPoE as an example. Enter the PPP Username
and PPP Password provided by your ISP and then click
Next.
Record this information here:
PPP Username:
PPP Password:
For the advanced con gurations, please log on to www.tp-link.com -> select your region -> search for the product -> User Guide can be found under the "Download" tab on the product page.
For Windows 7
Click "Start -> Control Panel -> Network and Internet -> View network
status -> Change adapter settings".
Right-click Wireless Network Connection (or Local Area Connection),
and then click Properties.
Select Internet Protocol Version 4 (TCP/IPv4), and then click Properties.
Select Obtain an IP address automatically and Obtain DNS server
address automatically. Then click OK.
For Windows XP
Click "Start -> Control Panel -> Network and Internet Connections ->
Network Connections".
Right-click Wireless Network Connection (or Local Area Connection),
and then click Properties.
Select Internet Protocol (TCP/IP), and then click Properties.
Select Obtain an IP address automatically and Obtain DNS server
address automatically. Then click OK.
For Windows 8
Move your mouse to the lower right corner and you will see Search icon
in the Popups.
Go to Apps, type Control Panel in the search box and press Enter.
Go to "Control Panel -> View network status and tasks -> Change
adapter settings".
Right-click Ethernet and then select Properties.
Double-click Internet Protocol Version 4 (TCP/IPv4). Select Obtain an
IP address automatically, choose Obtain DNS server address
automatically and then click OK.
T4. What can I do if I cannot access the Internet?
1) Check your cables and make sure they are all plugged in securely, including
the telephone line, Ethernet cables and power adapter.
You can rename your wireless network and create your
5
own password in this page. The default wireless
network name is TP-LINK_XXXXXX; and the default
wireless password, the same as the PIN code, is printed
on the bottom label. Click Next to continue.
Record your wireless information here:
SSID:
Password:
2) Check to see if you can log on to the web management page of
the modem router. The default IP address of the web management
page is 192.168.1.1.If you can, try the following steps. (If you are
unable to access the web management page , please refer to T3
and then try to access the Internet again after following those
steps.)
3) Consult your ISP and make sure all the VPI/VCI, Connection Type,
account username and password are correct. If they are not, please
repleace them with the correct settings and try again.
4) If you still cannot access the Internet, please restore your modem
router to its factory default settings and reconfigure your modem
router following the instructions in this QIG.
For more details about Troubleshooting and
Technical Support contact information,
please log on to our Technical Support
website: http://www.tp-link.com/en/support
Please con rm all the parameters. Click Back to modify
6
them or click Con rm to make your settings take
e ect.
