  • Page 1 VOLVO WEB EDITION 2005...

  • Page 2: Table Of Contents

    Audio The specifications, design features and illustrations in this Owner’s Manual are not binding. We reserve the right to make modifications Telephone without prior notice. © Volvo Car Corporation Index...
  • Page 3 Dashboard - left-hand drive Temperature gauge ....30 Tachometer ......30 Speedometer ......30 Automatic gearbox ....30 Odometer ........ 30 Clock ........30 Trip odometer ......30 Outside temperature sensor ..30 Warning symbols ....31 Fuel gauge ......30 Display ........
  • Page 4 Dashboard - right-hand drive Temperature gauge ....30 Automatic gearbox ....30 Speedometer ......30 Clock ........30 Odometer ........ 30 Outside temperature sensor ..30 Tripodometer ......30 Fuel gauge ......30 Warning symbols ....31 Display ........35 Hazard warning Tachometer ......
  • Page 5 Interior - left-hand drive Doors and Locks ..... 74 Alarm ........79 Power windows ...... 46 Power mirror controls ..... 47 Glovebox ....68 Manual gearbox ....87 Automatic gearbox ....88 Geartronic ......89 Handbrake ......45 Switches in centre console ... 36 8502000d Manual adjustment of front seats ....
  • Page 6 Interior - right hand drive Doors and Locks ..... 74 Alarm ........79 Power windows ...... 46 Power mirror controls ..... 47 Glovebox ....68 Manual gearbox ....87 Automatic gearbox ....88 Geartronic ......89 Handbrake ......45 Switches in centre console ... 36 8502062d Tipping backrests forward ..
  • Page 7 Exterior Sunroof ......48 Fuel filler flap ......84 Refuelling ......... 84 Economical driving ....85 Cleaning the car body ....138 Rustproofing ......136 Touching up paintwork .... 137 8000233d Replacing main beam bulb ..130 Tyres ......110 Boot lid ............

  • Page 8: Volvo Cars And The Environment

    - for example in heavy city traffic, tailbacks and tunnels - while the carbon philosophy Your Volvo is designed to be clean inside and filter traps nitrogen oxides, ground-level ozone out, a concept which means that you benefit in and hydrocarbons.
  • Page 9 Regular maintenance carried out by an author- · Drive gently! Avoid accelera- ised Volvo workshop creates the conditions for ting and braking too hard. low fuel consumption and contributes to a · Drive in the highest possible cleaner environment.

  • Page 10: Safety

    Safety Seat belts SRS (airbag) and SIPS bag (side airbag) SIPS airbag IC system (Inflatable Curtain) WHIPS Brake system Stability system Children in the car...

  • Page 11: Seat Belts

    Never modify or repair the belt yourself. The belt is not normally restricted and you Entrust this work to an authorised Volvo can move freely. workshop. The belt is restricted and cannot be pulled out...

  • Page 12: Airbag

    Airbag (SRS) and side airbag (SIPS bag) 8802099m 8802092M 8801919d 8801907e The airbag is housed in the centre of the The side airbag is above the glovebox, The side impact airbags are installed in the steering wheel, which is marked SRS AIRBAG. marked SRS AIRBAG front seat backrest frames Airbag (SRS) and side airbag (SIPS bag)

  • Page 13: Seat Belts And Belt Tensioners

    Airbag (SRS) SRS system SRS system left-hand drive (airbags in the steering wheel and dashboard) The system consists of a gas generator (1) surrounded by the inflatable airbag (2). Upon a sufficiently violent collision, a sensor (3) reacts, activating the gas generator igniter, and the airbag inflates as it heats up. To cushion the impact, the airbag deflates when compressed.
  • Page 14 Side airbag (SIPS bag) SIPS bag system left-hand drive SIPS bag system (side impact airbag) The SIPS airbag system is an electronic system consisting of two main components: the side airbag and the sensors. The side airbags are mounted in the backrest frames of the front seats while the sensors are located inside the centre and rear pillars.
  • Page 15 This decal is located in the rear left door opening The airbag-system is continually monitored by the control module and its The year and month in which you should contact your Volvo workshop for special inspection and possible replacement of the airbags and belt warning lamp is located in the combined instrument panel.
  • Page 16 · Ensure that the passengers keep their Volvo Genuine covers or Volvo feet on the floor (not on the dashboard, approved seat covers for SIPS airbags. on the seat, in the map and newspaper ·...
  • Page 17 Airbag (SRS) 8801909e Airbags (SRS) and child seats are not compatible! Child seat and airbag (SRS) The child could be seriously injured if sitting in a child seat or on a booster cushion that is pla- WARNING! ced in the front seat of a car with an activated* passenger airbag (SRS).
  • Page 18 Check that the switch This is necessary if a child seat is to be placed If the car is equipped with a front passenger is in the required position. Volvo recommends there. airbag (SRS), but does not have PACOS, that that the ignition key is used to change the airbag will always be activated.
  • Page 19 (SRS) is deactivated and the airbag warning symbol is displayed in the combined instru- ment panel. This indicates that there has been a severe malfunction. Contact an authorised Volvo workshop as soon as possible. 8803405m 8803404m Which position should the switch be set to? ON = Airbag (SRS) activated.
  • Page 20 Inflatable Curtain (IC) 8801999d 8801966e Inflatable Curtain (IC system) WARNING! The IC system protects the head from blows against the car interior. The curtain also protects against objects that the car is in collision with. The IC Do not screw or mount anything to the headlining, door pillars system protects both those travelling in the front and outer rear seats.
  • Page 21 Parts of the WHIPS protective capacity may have been lost. Allow an authorised Volvo workshop to check the system even after minor collision from behind. Never modify or repair the seat or the WHIPS system yourself! * For information on activated/deactivated airbag (SRS), see page 17.
  • Page 22 If the airbags have been deployed, we recommend the following: · Have the car towed to an authorised Volvo workshop. Do not drive the car with the airbags deployed even if the car can be driven after an accident.
  • Page 23 Brake system/ABS/EBD If a brake circuit fails particularly hard. Because the speed is often NOTE! You must depress the brake pedal fully low the brakes are not cooled as effectively as to take maximum advantage of the ABS system. If a fault should occur in one of the when driving on flat roads.
  • Page 24 Volvo workshop to have the brake system checked. If the level in the brake fluid reservoir is nor-...

  • Page 25: Stability System

    Stability system When the stability system is in action, it may Traction Control (TC) Active Yaw Control (AYC) seem like the car does not respond normally to The Traction Control function transfers power The Active Yaw Control function automatically acceleration. from the spinning drive wheel to the drive brakes one or more wheels to stabilise the car in This is because the system detects the amount...

  • Page 26: Children In The Car

    Volvo’s own child safety equipment is designed springs, rails or any of the rails and struts for your car. If you select Volvo equipment, you under the seat which may have sharp edges. · Allow the back of the child seat to rest...

  • Page 27: Integrated Booster Cushion For Children

    The regular armrest in the rear seat must not When a child uses the booster cushion, the lap be used as a booster cushion. Only Volvo’s belt must be positioned low across the hips - not integrated booster cushion may over the stomach.
  • Page 28 The car can be equipped with an Isofix bracket necessary. system for child seats in the outer rear seats. Contact your Volvo dealer for further informa- tion on child safety equipment.
  • Page 29 Location of the child in the car Weight / Age Front seat* Outer rear seats Centre rear seat 1. Rear-facing child seat, secured with 1. Rear-facing child seat, secured with 1. Rear-facing child seat, secured with <10 kg seatbelt. seatbelt and support arm. seatbelt, support arm and securing (0-9 months) strap.
  • Page 30 Instruments, switches and controls Combined instrument panel Indicator and warning symbols Messages in the display Switches in the centre console Trip computer Cruise control Headlamps, Fog lamps, Headlamp levelling, Instrument lighting Direction indicators, Follow-me-home, Steering wheel adjustment Windscreen wipers/washer Ignition switch and steering wheel lock Hazard warning flashers, Rear defroster, Heated seats Parking brake, Electrical socket Power windows...

  • Page 31: Temperature Gauge

    Combined instrument panel 3800838m 1. Temperature gauge 5. Cruise control indicator 11. Outside temperature gauge Displays the engine cooling system temperatu- See page 34. Displays the outside temperature. When the re. If the temperature is abnormally high and the temperature lies between +2 °C and -5 °C, a needle enters the red field a message is shown 6.

  • Page 32: Warning Symbols

    Indicator and warning symbols Warning symbol in centre of dashboard This symbol shines as an red or yellow light depending on the severity of the fault discov- ered. See next page for more information! Red symbol Stop the car. Read the message in the display. Symbol and message text are shown until the error is rectified.

  • Page 33: Indicator And Warning Symbols

    · If the reservoir level is below MIN the car heavy braking. should not be driven further. Have it towed to an authorised Volvo workshop to check If BRAKE and ABS warning the brake system. symbols light up at the same...
  • Page 34 If the warning symbol remains lit, drive to an to increase speed. Always follow the usual authorised Volvo workshop to have the system precautions for safe cornering and driving on checked.
  • Page 35 Contact a Volvo workshop. the SRS system. Drive to a Volvo workshop to applied, not how hard. Check by pulling the have it checked. lever! You must always pull it hard enough for the brake to fasten in a “notch”.

  • Page 36: Messages In The Display

    Messages in the display Messages in the display Whenever a warning or indicator symbol lights up, a message is displayed. When you have read and understood, press the READ button (A). Read messages are then erased from the display and are put into the memory. The message remains in the memory until the fault is remedied.

  • Page 37: Switches In The Centre Console

    Switches in the centre console 3603559d NOTE! The order of the buttons may vary. Active chassis, The STC/DSTC Reduce the system if you must use a wheel of a different dimension than the other wheels. system* FOUR-C (option) The STC/DSTC system is reactivated when the Press the button to shift This button is used to reduce or engine is started.

  • Page 38: Parking Assistance

    Switches in the centre console Lowering outer Auxiliary lamps Parking assistance rear seat head (accessory) (option) restraints (option) The system is always Use this button if the auxiliary activated when the car is lamps of the car are to light - Turn the ignition key to started.

  • Page 39: Trip Computer

    Trip computer Speed in miles per hour7 Current speed is displayed in mph. Current fuel consumption Continuous information on current fuel consumption. Fuel consumption is calculated every second. The figure in the display is updated every few seconds. When the car is stationary “----”...

  • Page 40: Cruise Control

    Cruise control (option) Temporary disengagement Press 0 to disengage the cruise control temporarily. CRUISE will be shown on the combined instrument panel. The speed set earlier is stored in the memory. The cruise control is also temporarily disenga- ged when: ·...

  • Page 41: Position/Parking Lamps

    B because headlamp levelling is automatic. Before trips to certain countries, your Volvo NOTE! The light switch must be turned to workshop can help you deactivate the daytime C - Instrument lighting position for the main beam to be turned on.

  • Page 42: Steering Wheel Adjustment

    The steering wheel can be adjusted both time settings for your car can be changed by an main beam flash vertically and front-rear. authorised Volvo workshop. Push down the control on the left-hand side of 1 “Resistance point position” the steering column. Then adjust the steering For turns requiring small steering adjust- wheel to the position that suits you best.

  • Page 43: Windscreen Washer

    Windscreen wipers/washer Rain sensor (option) The rain sensor is automatically deactivated when the key is removed from the ignition The rain sensor automatically increases or switch or five minutes after the ignition is decreases the speed of the windscreen wipers switched off.

  • Page 44: Ignition Switch And Steering Wheel Lock

    Ignition switch and steering wheel lock Ignition and steering Ignition keys and electronic wheel lock immobilizer 0 Locked position The ignition key must not hang with other keys The steering wheel locks when the or metal objects on the same key ring. ignition key is removed.

  • Page 45: Flashers

    The LED in the switch lights. A built-in timer · Press once again: heating switched off country. automatically deactivates the door mirror (no LEDs are lit). defroster after about 4 minutes and the rear window defroster after about 12 minutes. Your Volvo workshop can adjust the temperature.

  • Page 46: Handbrake

    Parking brake, Electrical socket/cigarette lighter 68 72 5500045e 3601943e 3601974d Parking brake lever Electrical socket at the front seat Electrical socket for the rear seat Parking brake (handbrake) Electrical socket/ cigarette lighter The lever is located between the front seats. The parking brake operates on the rear wheels.

  • Page 47: Power Windows

    Power windows Windows can be opened or closed from the front seat two ways. 1. Press the switch gently downwards or pull it gently upwards. The power windows go up or down as long as the switch is affected. 2. Press the switch all the way down, or pull it all the way up, and then release it.

  • Page 48: Door Mirrors

    If the car has door mirrors with memory function, they work together with the memory setting of the seat; see page 66. NOTE! The above only applies if your Volvo is equipped with a driver’s power seat. Memory function in the remote control...

  • Page 49: Sunroof

    Power sunroof (option) Manual control Open: Pull the switch rearwards to the resistance point position (3). The sunroof will move towards maximum opening position as long as the switch is held in this position. Close: Press the switch forwards to the resistance point position (2).

  • Page 50: Sun Screen

    Sun screen, Sun blinds (option) 8301256d Sun screen Sun blinds - rear side Sun blind - rear window windows The sunroof also has an inner manually sliding Pull the sun blind up from the parcel shelf and sun screen. The sun screen slides back hook it into the holes above the rear window, as Lower the window slightly.

  • Page 51: Laminated Side Windows (Option), Water-Repellent Coating (Option)

    Laminated side windows (option), Water-repellent coating (option) Water and dirt-repellent Laminated side windows coating on the front windows (option) and/or door mirrors (option) The laminated windows in the front and rear doors improve sound insulation in the passen- The front windows and/or door mirrors are ger compartment and provide better protection treated with a coating that ensures that visibility against unauthorised entry.

  • Page 52: Climate Control

    Climate control Air distribution Your climate control system - useful hints Electronic Climate Control ECC Electronic Climate Control ECC with Interior Air Quality system Electronic Climate Control ECC - manual settings Manual climate control with air conditioning (AC) Fuel-driven parking heater (option)

  • Page 53: Air Distribution

    Air distribution 8702818d 8702826d 8702835d Air vents in the dashboard Air vents in the door pillars Air vents in the dashboard Air distribution Air vents in the door pillars A Open The incoming air is distributed through 14 A Open B Closed different air vents located in different parts of B Closed...

  • Page 54: Your Climate Control System - Useful Hints

    Fault tracing way of preventing the battery from becoming Actual temperature - ECC Your Volvo workshop has the instruments and discharged when the engine is off. tools required for any fault tracing or repair of The temperature you select corresponds to the your climate control system.

  • Page 55: Electronic Climate Control Ecc

    Electronic Climate Control ECC Recirculation/Interior Air Quality System AUTO Defroster, windscreen and side windows Passenger compartment Recirculation Defroster, rear window temperature sensor and door mirrors Seat heater, right-hand side AC On/Off Seat heater left hand side 8704253d Temperature, Temperature left hand side right-hand side Air distribution...
  • Page 56 See next page. the air intake is closed and the air inside the · Follow the Volvo service programme for compartment is recirculated. The multifilter also the recommended interval for multifilter Press to activate the air quality sensor cleans the air recirculating in the compartment.
  • Page 57 Electronic Climate Control ECC AUTO Defroster - rear window and door mirrors The AUTO function regulates climate control so that the selected temperature is attained. The Use this button to quickly remove ice and misting automatic function controls heating, air condition- from the rear window and door mirrors.

  • Page 58: Electronic Climate Control Ecc - Manual Settings

    Electronic Climate Control ECC - manual settings AC - On/Off Recirculation (see also page 58) When the ON LED lights the air conditioning (A/C) system is controlled automatically by the The best cooling in warm system. In this way incoming air is cooled and climates is achieved by 8702776d moderately dehumidified.

  • Page 59: Left Side

    Manual climate control with air conditioning (AC) Recirculation Recirculation, together with your air conditioning The timer function minimises the risk of ice, misting and bad air. To (A/C) control, helps to cool a warm cabin more activate the function: press for more than 3 seconds.

  • Page 60: Heating The Front Seats

    Manual climate control with air conditioning (AC) Use the air distribution control positions (marked with dots) between the Here is some supplementary different symbols to fine-tune air distribution for maximum comfort. advice and information: · You must turn the fan knob (from the Air distribution Use…...
  • Page 61 At temperatures of -10 °C and below, the parking heater runs a maximum of 60 minutes. If the parking heater does not start despite re- peated attempts, a message is shown on the display. Contact an authorised Volvo work- shop. WARNING! 3602296d •...

  • Page 62: Direct Start Of Heater

    Fuel-driven parking heater (option) Battery and fuel After setting TIMER 1, toggle to TIMER 2. Settings are made the same way as for TIMER 1. If the battery is not sufficiently charged or the Deactivating timer-started heating petrol tank is close to empty, the parking heater Do as follows to manually switch off the heater will be switched off.

  • Page 64: Interior

    Interior Front seats Interior lighting Storage compartments Centre console storage compartments, Load curtain Spare wheel, Warning triangle Coat hanger, Cup holders in armrest Long loads...

  • Page 65: Front Seats

    Front seats The driver’s and passenger seats can be adjusted to the optimum sitting and driving positions. 1. Forward/rearward: Lift the handle to adjust the distance to the steering wheel and pedals. Check that the seat is locked after changing position. 2.

  • Page 66: Glovebox

    Folding the front passenger seat, Rear seat head restraints 8502027e 8501727A Adjust the head restraint vertically Folding the front passenger seat Rear seat head restraints The front passenger seat backrest can be folded to a horizontal position The centre seating position head restraint is to make room for a long load.

  • Page 67: Emergency Stop

    Front seats Power seat (option) Preparations The seat is usually adjusted with the ignition key is in position I or II. It can also be adjusted within 4.5 minutes of unlocking the door with the key or remote control. If the door is closed 8505020m but the ignition key has not yet been inserted in the ignition switch or is in position 0 in the...

  • Page 68: Interior Lighting

    · When one of the doors is open. automatic function reconnects. The pre-programmed times of 30 seconds and * The function is light-dependent and is only 10 minutes can be changed. Contact an activated when it is dark. authorised Volvo workshop.

  • Page 69: Storage Compartments

    Storage compartments WARNING! 8504930d Make sure that no hard, sharp or heavy objects lie on or in (or protrude from) the parcel shelf, map pocket or other storage compartments where they might cause injury during heavy braking. Always fasten large heavy objects with one of the seat belts.

  • Page 70: Cup Holder

    Centre console storage compartments, Load curtain 8501983E Cup holder Retaining strap in cargo (option) compartment (option) The retaining strap can be used to secure lighter Some models are objects, such as grocery bags or hand luggage. 8502003d equipped with cup Pull it out.

  • Page 71: Spare Wheel, Warning Triangle

    Spare wheel, Warning triangle Warning triangle Floor support Jack Tool kit with towing eye Jack Mounting Spare wheel Floor support 7700231d 8901312d Spare wheel, tools, jack Warning triangle (certain countries) The spare wheel with the jack and tool kit can be found under the floor Follow the regulations concerning warning triangles of the country you are of the cargo compartment.

  • Page 72: Coat Hanger, Cup Holders In Armrest

    Coat hanger, Cup holders in armrest 8503126m 8504929m Coat hanger Cup holders in the rear seat armrest The coat hanger is only intended for light garments.

  • Page 73: Long Loads

    When raising the backrests, ensure that they accidentally knock the gear lever or gear are properly secured and locked. NOTE! If your Volvo is equipped with an selector with the load and cause a gear to integrated booster cushion, you must fold this engage and the car to move off.

  • Page 74: Locks, Alarm

    Locks and Alarm Immobilizer, remote control Locking and unlocking Replacing the battery When it is dark, deadlocks Child safety lock, Service locking Alarm...

  • Page 75: Doors And Locks

    Store the label in a safe place. This key operates all locks 1. Unlock 2. Open boot lid Take the label to your Volvo dealer if you wish 3. Alarm function 4. Approach lighting to order new keys. A maximum of six remote 5.

  • Page 76: Locking And Unlocking

    These lights will remain lit for 30, 60 or 90 seconds. An appropriate time setting for 8301290d your car can be performed at an authorised 8302186m Volvo workshop. In order to switch off Approach lighting: press the yellow button again. Locking and unlocking the Locking and unlocking the...

  • Page 77: Automatic Relocking

    Twist the key upwards or If all doors are locked when you close the boot · Turn the old battery in to your Volvo downwards and remove the plug. Then unlock lid, it locks automatically.
  • Page 78 When it is dark, deadlocks When it is dark Deadlocks* Approach lighting Your car has a special deadlock position which Carry out the following when you approach means that the doors cannot be opened from the the car: inside if they are locked. Deadlocks can only be ·...
  • Page 79 Child safety lock, Service locking 8301235d 8301289d Service locking*, boot lid Control for child safety lock - left rear door Control for child safety lock - right rear door This function is beneficial if the car is left for Mechanical child safety lock - WARNING! service, with a hotel parking valet or the like.

  • Page 80: Alarm

    Alarm The alarm system (option) Deactivating a triggered alarm When the alarm is connected, it continually monitors all alarm points. The Press the UNLOCK button on the remote control if the alarm sounds and alarm is triggered if: you wish to deactivate it. Two short flashes of the direction indicators are ·...
  • Page 81 Alarm Status indicator lamp on the dashboard An indicator lamp (LED) at the top of the dashboard gives a description of the alarm system status: · Lamp not lit: Alarm is deactivated. · Lamp flashes once every 2 seconds: alarm is armed. 3602415d ·...
  • Page 82 5. Deactivate the alarm by unlocking with the remote control. 5. Repeat the test for the other door. 6. Deactivate the alarm by unlocking with the remote control. If the alarm system does not work correctly, have the car examined by an authorised Volvo workshop.
  • Page 84 Starting and driving Starting the engine Economical driving Manual gearbox Automatic gearbox All-Wheel Drive (AWD) Active chassis FOUR-C Parking assistance Towing Jumpstarting Driving with trailer Detachable towbar Adjusting headlamp pattern BLIS (Blind Spot Information System)

  • Page 85: Fuel Filler Flap

    - the ring signal can cause The reason for this is Volvo's ambition to Opening fuel tank sparks which may ignite petrol fumes and minimise exhaust emissions by bringing up the lead to fires or personal injury.

  • Page 86: Economical Driving

    Economical driving Your new car - slippery road Do not overload the battery Drive with anticipation surfaces Economical driving results from driving gently The electrical functions in the car load the with anticipation and adapting your driving battery to varying degrees. Driving on a slipper road surface may feel Avoid having the ignition key in position II style and speed to the situation.

  • Page 87: Safety Systems

    Economical driving Do not allow the engine and Cold start Lock-up function The gears have a lock-up function (locked cooling system to overheat When starting in cold temperatures, gear shifts gears), which gives better engine braking and may feel harder. Under certain conditions, e.g.

  • Page 88: Manual Gearbox

    Manual gearbox M 56 M 56 4302395n 4301589e Gear positions, 5-speed Reverse gear inhibitor Depress the clutch pedal fully with each gear Only engage reverse gear when the car is change. Remove your foot from the clutch stationary. pedal between gear changes! Follow the To put the car in reverse, the gear lever must appropriate shifting pattern.

  • Page 89: Automatic Gearbox

    Automatic gearbox W – Winter parking brake when the car is stationary with the gear lever in N. The W button by the gear D – Driving position selector engages and disengages the winter D is the normal driving position. The car programme W.

  • Page 90: Geartronic

    Automatic gearbox 4302476e 4302106d 4301647d Gear selector, automatic gearbox Geartronic Gear selector, Geartronic While driving Mechanical gear selector Manual positions, Geartronic inhibitor Move the gear selector to the right to shift from The manual gearshift mode can be selected at automatic driving position D to manual mode.

  • Page 91: All Wheel Drive

    All Wheel Drive All-Wheel Drive (AWD) (option) Speed-dependent power steering (option) All-wheel drive is always engaged. All-wheel drive means that the vehicle is driven If the car is equipped with speed-dependent by all four wheels at the same time. power steering it is more easily steered at low The power is distributed automatically between speeds to facilitate parking or the like.

  • Page 92: Active Chassis Four-C

    Active chassis FOUR-C Active chassis FOUR-C* (option) The car is equipped with an extremely advanced active chassis system - Continuously Control- led Chassis Concept - that is regulated electro- nically. The FOUR-C control unit analyses data from 3603554m the sensors and performs the necessary shock absorber setting adjustments up to 500 times per second.
  • Page 93 Rear parking assistance is deactivated automati- audio system is high, this is automatically The signal comes from the front speakers. cally when towing a trailer if a Volvo genuine lowered. trailer cable is used. The system is always activated when the car is started.
  • Page 94 Parking assistance Rear parking assistance Rear parking assistance is activated when reverse gear is engaged. The signal comes from the rear speakers. Fault indicator The information symbol shines with a steady glow PARK ASSIST SERVICE 3603503m REQUIRED is shown in the Parking assistance sensors information display in the centre of the combined...

  • Page 95: Towing Eye

    Towing Bump starting (tow starting) the engine If you bump start (tow start) a car with manual gearbox, the catalytic converter may be damaged. Cars with automatic gearbox cannot be bump started (tow started). Use a booster battery if the battery is flat. Towing eye The towing eye is located in the tool kit in the cargo compartment.
  • Page 96 Jumpstarting WARNING! Remember that batteries, especially the booster battery, contain oxyhydrogen which is highly explosive. A spark, which can be caused if you incorrectly install the jump leads, is enough to cause the battery to explode and both damage the car and injure you. The battery also contains sulphuric acid, which can cause serious corrosive damage.

  • Page 97: Driving With Trailer

    You should therefore check with and let the engine idle a few minutes. your closest Volvo dealer about just your car if a towbar has been fitted at · If the car overheats, the air conditioning system can be temporarily a later date.
  • Page 98 Driving with trailer NOTE! The maximum permitted trailer weights stated are the ones that the Volvo Car Corporation allows. Remember that national vehicle regulations may further limit the trailer weight and speed. The towbars can be certified for higher towing weights than what the car may tow.

  • Page 99: Towing Bracket

    Ensure that the cable does not drag on the ground. 3701780d WARNING! If your car is fitted with Volvo's detachable towbar: Make sure that the towbar is locked before you drive off. · The red signal pin (see the arrow in the illustration to the left) should not be visible! ·...
  • Page 100 Towing bracket 8902082d 8902083d Distance B above: Distance A above: Fixed: 65 mm Fixed: 1152 mm Detachable: 65 mm Detachable: 1152 mm Max. ball pressure: 75 kg...
  • Page 101 Detachable towbar - mounting the ball section OPEN OPEN 8902079M 8902078M 8902074M Hold the towball and turn the lever clockwise Remove the connector pin cover. Insert the key and turn it clockwise to the to the locked position. Release the lever. unlocked position.
  • Page 102 Detachable towbar - removing the ball section OPEN OPEN 8902078M 8902074M 8902081M Insert the key into the detachable part and turn Turn the lever clockwise to the locked position Grasp the towbar. Pull the towball section from it clockwise to the unlocked position. and grip the towball.

  • Page 103: Floor Mats

    2. Fit the guide pins into the guide holes (1). that Volvo has specially designed for your car. · Check periodically that the load carriers 3. Carefully lower the bracket on the other side to the roof.

  • Page 104: Adjusting Headlamp Pattern

    Adjusting headlamp pattern 3501842m 3501716j A. Headlamp pattern for left-hand traffic B. Right-hand traffic Correct light pattern for left or right-hand traffic 3501841m So as not to dazzle oncoming drivers, the Fitting the mask to the headlamps. The upper illustration is for halogen headlamps and the lower headlamp beam pattern can be altered by illustration is for Bi-Xenon headlamps.
  • Page 105 Adjusting headlamp pattern Masking templates for halogen headlamps The templates are for LHD variants, and are reversed for RHD variants. Template 1 is fitted to the left-hand headlamp for LHD variants and on the right-hand headlamp for RHD variants. Template 2 is fitted to the right-hand headlamp for LHD variants and on the left-hand headlamp for RHD variants.
  • Page 106 Adjusting headlamp pattern Masking templates for Bi-Xenon headlamps The templates are for LHD variants, and are reversed for RHD variants. Template 3 is fitted to the left-hand headlamp for LHD variants and on the right-hand headlamp for RHD variants. 3501844m Template 4 is fitted to the right-hand headlamp for LHD variants and on the left-hand headlamp for RHD variants.
  • Page 107 BLIS - Blind Spot Information System WARNING! - BLIS is an information system, NOT a warning or safety system. - The system is a complement to, and not a replacement for, the existing rearview mirrors. It can never replace the awareness and responsibility of the driver.
  • Page 108 BLIS - Blind Spot Information System WARNING! - The BLIS system does not work in sharp bends. - The system does not work if the camera lenses are covered. In this case the BLIS indicator lamps flash and a text message is shown in the display (see table on page 108).
  • Page 109 BLIS - Blind Spot Information System System status Text in the display BLIS system not functioning BLIND-SPOT SYST SERVICE REQUIRED Right-hand camera blocked BLIND-SPOT SYST R CAMERA BLOCKED Left-hand camera blocked BLIND-SPOT SYST L CAMERA BLOCKED Both cameras blocked BLIND-SPOT SYST CAMERAS BLOCKED BLIS system off BLIND-SPOT INFO SYSTEM OFF BLIS system on...

  • Page 110: Wheels And Tyres

    Wheels and tyres General about wheels and tyres Tyre pressures Wear, Changing the tyres, Spare wheel Changing wheels Temporary puncture repair and tools...

  • Page 111: New Tyres

    General New tyres General wheels and tyres Bear in mind that tyres are perishable goods - after a All tyres have a dimension designation, such as 215/55R16 93W. few years they begin to harden while their friction These tyre size designations, which are used by all tyre manufacturers, properties deteriorate little by little.

  • Page 112: Winter Tyres

    Always use winter tyres on all four wheels! valve. Otherwise the wheel cover cannot be fitted on the rim. NOTE: Always consult your Volvo dealer as to which wheel and tyre type is appropriate for your car. Studded winter tyres Studded winter tyres should be run in for 500-1000 kilometres (300-600 miles), softly and gently so that the studs sit in the tyre correctly.

  • Page 113: Tyre Pressures

    However, you should increase pressure if it is too low. Remember that tyre pressure can vary depending on exterior temperature. Therefore check the tyres outdoors when the tyres are cold. WARNING! The only Volvo approved “special wheel rims” are those tested by Volvo and are Volvo Genuine parts .
  • Page 114 Tyres with the greatest tread depth should always - irrespective of rear or front wheel drive - be fitted at the rear. Contact your closest Volvo dealer to check if you are unsure. Storage Wheels should be stored horizontally or suspended, not vertically.

  • Page 115: Changing Wheels

    Changing wheels 7700 7700 7700401r Remove wheel studs · Cars with aluminum rims with a cover: remove the cover using the The spare wheel is stored under the carpet in the cargo compartment. socket wrench. Remember to set out the warning triangle. ·...
  • Page 116 Changing wheels WARNING! · Never crawl under the car when it is raised on a jack! · The car and the jack should be on a solid horizontal surface. · The car original jack should be used for wheel changing. All other work on the car should be carried out using workshop jacks and axle stands under the part of the car which is raised.
  • Page 117 Temporary puncture repair and tools General NOTE! The emergency puncture repair kit is Taking out the emergency puncture only intended for the sealing of tyres with a repair kit Cars which do not have a spare tyres are instead puncture in the tread. The emergency puncture 1.

  • Page 118: Inflating Tyres

    Temporary puncture repair and tools Inflating tyres WARNING! Set up the warning triangle if a tyre must be inflated in an area where there is other traffic. Inhaling car exhaust fumes can result in · Ensure that the orange-coloured switch (2) danger to life.
  • Page 119 Temporary puncture repair and tools WARNING! Never stand next to the tyre when the compressor is running. Be particularly observant of the tyre walls. If cracks, irregularities or other damage appears, turn off the compressor immediately. Under these circumstances do not continue your journey. Contact an authorised tyre centre.
  • Page 120 Temporary puncture repair and tools · Check the tyre pressure again: NOTE! Do not open the orange-coloured part (7) when only the compressor will be used for inflating. 1) Connect the air hose (4) to the air valve on the tyre. 2) Connect the cable (5) to the 12 V socket.
  • Page 121 Replacement can be carried out by an authori- canister (6) and holder (9) clockwise. · Pull out the air hose (10). sed Volvo workshop or according to the is not damaged. Screw the canister into · Wipe off remaining sealant with a rag or instruction.
  • Page 122 Temporary puncture repair and tools · Check that the seal (7) on the new canister is not damaged. Screw the holder (9) onto the canister (6) and turn it anticlockwise until there is an audible click. · Refit the casing (3). Check that the casing is correctly mounted, screw it on with the ·...

  • Page 124: Fuses, Bulb Replacement

    Fuses, bulb replacement Fuses Relay/fuse box in the engine compartment Fuses in the passenger compartment at dashboard end on driver’s side Fuses in the passenger compartment within the sound barrier on the driver’s side Fuses in the cargo compartment Bulb replacement...
  • Page 125 3. Fuse box in the passenger compartment at the fuses. dashboard end on driver’s side. 4. Fuse box in the cargo compartment. If the same fuse burns out repeatedly, there is a fault in the component, and you should visit your Volvo workshop to have it checked.
  • Page 126 Fuses in the engine compartment Fuses in the engine compartment Fuse pliers This fuse box contains 24 fuse positions. Be sure to replace a blown fuse with a new fuse of the same colour and amperage. There are also a number of spare fuses.
  • Page 127 Fuses in the passenger compartment at dashboard end on driver’s side This fuse box contains 38 fuse positions. Fuses are located inside the access panel on the end face of the dashboard. There are also a number of spare fuses. 3701482D Ampere rating 1.

  • Page 128: Seat Heating

    Fuses in the passenger compartment within the sound barrier on the driver’s side This fuse box contains 36 fuse positions. The fuses are located within the sound barrier on the left-hand side. Be sure to replace a blown fuse with a new fuse of the same colour and amperage.
  • Page 129 Fuses in the cargo compartment The fuses are located behind the upholstery on the left-hand side. Be sure to replace a blown fuse with a new fuse of the same colour and amperage. Ampere rating 19. Foldable head restraint ......15 1.

  • Page 130: Replacing Bulbs

    Grease and oils from your fingers are work on the lights should be carried out by vaporised by the heat, coating and damaging an authorised Volvo workshop. the reflector. Bi-Xenon headlamps must be handled with extreme care due to the high-voltage...

  • Page 131: Dipped And Main Beam

    Replacing bulbs 3500903d 3500535d 3500536d Dipped and main beam · Press the clamp spring upwards and a little Front position/parking lamp* to the left so that it secures in its catch (2). · Switch off all lights and turn ignition key to Replace headlamp bulbs from the engine ·...
  • Page 132 Press the locking pins towards one another · Switch on the ignition and check that the Volvo workshop needs to be consulted in order to remove the lamp holder from the new bulb lights.
  • Page 133 Replacing bulbs 3500894d 3500903d 3500889d Replacing front fog lamp bulb Replacing side Replacing position/ direction indicator bulb parking lamp bulb NOTE! Never touch the bulb glass with your fingers. · Open the front door halfway. · Switch off all lights and turn ignition key ·...

  • Page 134: Replacing Number Plate Lighting

    Replacing bulbs 3500871d 3500888D 3500916d Replacing courtesy lighting Replacing courtesy lighting Replacing numberplate lighting bulb bulb - front door bulb - rear door The courtesy lighting is under the dashboard · Switch off the lights and turn the ignition · Insert a screwdriver and twist lightly so that on the driver’s and passenger sides.
  • Page 135 Replacing bulbs 3500891d 3501378m 3500918d Insert screwdriver and turn carefully Replacing cargo Replacing side marker bulb Replacing the make up-mirror bulb compartment bulb · Press the entire lamp insert backwards and remove. · The lighting is to the left and right of the boot Insert a screwdriver and gently turn so that ·...

  • Page 136: Car Care And Service

    Car care and Service Rustproofing Checking and repairing paintwork damage Washing Volvo Service Bonnet, Engine Compartment Diesel Engine oil Coolant Brake fluid, Power steering, Windscreen washer fluid Battery care Replacing wiper blades...

  • Page 137: Rustproofing

    Rustproofing - check and repair Improving Your Volvo received a very thorough and complete rustproofing at the If you want to repair the rustproofing yourself, make sure the area is clean factory. Areas that are extremely vulnerable, such as the underbody, and dry.

  • Page 138: Colour Code

    (illustration 2). Mask if necessary · When the primer is dry, apply the surface MADE IN VOLVO CAR CORP. SWEDEN coat with a brush. · Ensure that the paint is well stirred and apply several thin coats allowing it to dry 0300048A between coats.
  • Page 139 Sunlight and heat can cause permanent damage. Consult your Volvo workshop. · Dry the car with a clean, soft chamois. · Clean the wiper blades with a lukewarm soap solution.

  • Page 140: Cleaning The Upholstery

    A special cleaning agent available at your Volvo dealer is recommended when cleaning leather upholstery. Polishing and waxing Use the Volvo leather care kit once or twice a year to preserve suppleness and comfort. Polish and wax the car when you feel the paintwork is matte and when you wish to give the paintwork extra protection, such as before winter.
  • Page 141 There is natural wear of the water-repellent coating. NOTE! Treatment with a special finishing agent available from Volvo dealers is recommended in order to maintain the water-repellent proper- ties. This should be used first after three years and then each year.

  • Page 142: Volvo Service

    In order for you to keep your Volvo at the highest level of traffic safety, Such data can contain information including, but not limited to, vehicle...

  • Page 143: Lifting The Car

    The battery contains acid that is both corrosive and poisonous. See the illustration. It is important that the battery is handled in an environmentally friendly way. Let your Volvo dealer assist you.
  • Page 144 Bonnet, Engine compartment - left-hand drive Pull the handle.. 8200092d 2000305d ...press up and open Opening the bonnet Engine compartment WARNING! Pull the handle on the far left under the Expansion tank, cooling system dashboard. You hear when the lock releases. Engine oil filler pipe Electric engine cooling fan: Insert the hand in the centre of the front edge...
  • Page 145 Bonnet, Engine compartment - right-hand drive Pull the handle... 8200095d 2000306d ..press up and open Opening the bonnet Engine compartment WARNING! Pull the handle on the far right under the Expansion tank, cooling system Electric engine cooling fan: dashboard. You hear when the lock releases. Engine oil filler pipe Cooling fan may continue running Insert the hand in the centre of the front edge of...

  • Page 146: Fuel System

    Diesel fuels not to be used: special additives, Marine Diesel Fuel, fuel oil, RME (Rape Methyl Ester), vegetable oil. These fuels do not fulfil the requirements of Volvo’s recommendation and generate increased wear and engine damage that is not covered by the Volvo warranty.

  • Page 147: Engine Oil

    Check the oil level using the dipstick. The oil level must be between the MIN and WARNING! Volvo recommends checking the oil level every MAX marks. 2500 km.The most accurate measurements are Do not spill oil onto the hot exhaust manifold •...
  • Page 148 See capacities and recommended grade for fluids and oils on page 158. Important! Always use coolant with anti-corrosion agent as recommended by Volvo. New cars are filled with coolant that can withstand temperatures down to approximately -35 °C. Check the coolant regularly The level should lie between the MIN and MAX marks on the expansion tank.

  • Page 149: Power Steering Fluid Reservoir

    Brake fluid, Power steering, Windscreen washer fluid Clutch and brake fluid reservoir WARNING! If the level of brake fluid in the reser- voir is below the MIN mark, the car FULL should not be driven until the brake flu- id has been topped up. The reason for the loss of brake fluid must be investi- gated.

  • Page 150: Battery Care

    Battery care Symbols: · Check all battery cells. Use a screwdriver to remove the caps. Each cell has its own max- imum level mark. · If necessary, top up with distilled water to the battery’s maximum mark. · Never fill above the maximum mark (A). Use protective goggles.
  • Page 151 Battery care Replacing the battery WARNING! Removing the battery: · Switch off the ignition and remove the key. Batteries can generate oxyhydrogen gas, · Wait at least 5 minutes before touching any which is very dangerous. One spark, electrical terminals. This allows time for the which can be generated if you connect information in the car’s electrical system to the jump leads incorrectly, is sufficient to...

  • Page 152: Replacing Wiper Blades

    Replacing wiper blades 3603056d Replacing windscreen wiper blades • Fold out the wiper arm and hold the wiper blade. • Push in the ribbed locking springs on the wiper blade while lifting it from the arm ex- tension. • Install the new blade following the instruc- tions in reverse order and check that the blade is properly secured.

  • Page 154: Specifications

    Specifications Type designation Dimensions and weights Engine specifications Capacities Fuel Catalytic converter and suspension Electrical system...

  • Page 155: Type Designation

    Specifications Type designation When contacting your Volvo dealer about your car and when ordering spare parts and accesso- B5254S ries, it makes things easier if you know your 1234567 car’s type designation, vehicle identification number and engine number. 1 Type, model year designation and vehicle...

  • Page 156: Dimensions And Weights

    Rear track ............156 cm weight. For the location of the decal, see page 154. 1. Max. total weight MADE IN VOLVO CAR CORP. SWEDEN 2. Max. train weight (car+trailer) 3. Max. front axle load 4. Max rear axle load Max load...

  • Page 157: Engine Specifications

    Engine specifications 2.0T BIFUEL BIFUEL 2.5T 2.4T Engine variant B5204T5 B5244SG B5244SG2 B5244S B5244S2 B5254T2 B5244T4 Output* (kW/rps) 132/92 103/97 103/85 125/98 103/75 154/83 162/83 (hp/rpm) 180/5500 140/5800 140/5100 170/6000 140/4500 210/5000 220/5000 Torque* (Nm/rps) 240/30-83 192/75 214/75 225/75 220/55 320/25-75 285/33-83 (kpm/rpm) 24.5/1850-5000 19.6/4500...
  • Page 158 Engine specifications 2.4D Engine variant B6294T B6294S2 D5244T D5244T2 Output* (kW/rps) 200/87 144/87 120/67 96/67 (hp/rpm) 272/5200 196/5200 163/4000 130/4000 Torque (Nm/rps) 380/30-83 280/65 340/29-50 280/29-50 (kpm/rpm) 38.8/1800-5000 28.6/3900 34.7/1750-3000 28.6/1750-3000 No. of cylinders Bore (mm) Stroke (mm) 93.2 93.2 Cylinder displacement (dm (l)) 2.92 2.92...
  • Page 159 The recommended transmission fluid must be used to prevent damage to the gearbox. Do not mix with any other transmission fluid. If the transmission is topped up with a different fluid, contact an authorised Volvo workshop for servicing. Weights can vary depending on the engine variant. Contact an authorised Volvo workshop for the exact information.
  • Page 160 Never use oil additives. These can damage the engine. Engine decal If the system is topped up with a different oil, contact the nearest Volvo workshop for The engine decal specifies: servicing. oil grade Using oil of a different grade than recom-...
  • Page 161 There may be abnormally high oil temperatures or oil consumption. Petrol engines: Under extreme operating conditions, choose a fully synthetic engine oil that provides extra protection for the engine. Volvo recommends Castrol® oil products.
  • Page 162 10.6 4-speed (GM4T65) 2.4T B5244T4 Automatic gearbox (AW55-51) - Emission values are affected by fuel quality and may therefore differ from those specified if fuel of a different standard than that recommended by Volvo is used. Certain countries. Fuel tank.
  • Page 163 · 91 RON must not be used in 4-cylinder of 91 RON. Volvo warranty. engines and, in general, should only be used as an exception. However, the engine will not be damaged by this fuel grade.

  • Page 164: Catalytic Converter

    Catalytic converter and suspension Wheel suspension, springing Lambda-sond Heated oxygen sensor The lambda sensor is part of a management Front end system intended to reduce emissions and McPherson type spring strut. Unitary construc- improve fuel economy. An oxygen sensor tion of shock absorbers and spring. Rack and monitors the oxygen content of the exhaust gases leaving the engine.

  • Page 165: Electrical System

    Electrical system General 12-volt system with voltage regulated alterna- ting current generator. Single pole system in which the chassis and engine block are used as conductors.The negative pole is connected to the chassis. The car is equipped with an extra ground lead to reduce the magnetic fields.

  • Page 166: Audio

    Audio Overview, Stereo HU-450 Overview, Stereo HU-650 Overview, Stereo HU-850 Audio functions Radio functions Cassette player CD player Dolby Surround Pro Logic II Technical data - Audio...
  • Page 167 Stereo HU-450 HU-450 3905005d 1. POWER (Off/On) - Press Volume - 7. Navigation buttons - 15. Cassette opening Turn CD/radio - seek/change station or 16. Cassette opening 2. PRESET/ CD PUSH MENU - track Cassette - Fast forward/rewind, Stored radio stations select next/previous track CD changer (option) 8.
  • Page 168 Stereo HU-650 COMPACT DIGITALAUDIO HU-650 3905004d CD eject POWER (Off/On) - PressVolume - Turn CD slot PRESET/ CD PUSH MENU - 10. CD random Stored radio stations 11. FM - Shortcut CD changer (option) 12. AM - Shortcut SOURCE PUSH MENU - Open the 13.
  • Page 169 Stereo HU-850 COMPACT DIGITALAUDIO HU-850 3905006d SOURCE PUSH MENU - CD eject POWER (Off/On) - Press Open the main menu - Press Dolby Pro Logic II VOLUME - Turn Turn to select: 2-channel stereo BASS - Press out and turn Radio - FM, AM 3-channel stereo TREBLE - Press out, pull and turn...

  • Page 170: Volume Control

    Audio functions HU-450/650/850 3901856d 3902418d On/Off switch Volume control - TP/PTY/ Bass NEWS Set the bass by pressing out the button and Press button to switch the radio on or off. turning to right or left. In the centre position the If a cassette or a CD is playing when the radio Volume control volume is “normalised”.
  • Page 171 Audio functions HU-450/650/850 3901858d 3905008m 3905009m 3905063m Fader – Balance front/rear Selection of sound source Balance – Balance right/left Set a suitable balance between the front and rear There are two ways to select sound source: Set the balance by pressing, pulling out the loudspeakers by pressing out the button and button and turning to right or left.

  • Page 172: Station Search

    Radio functions HU-450/650/850 3905010m 3901873d Scanning Station search Steering wheel keypad If you have a keypad in the steering wheel, Press the SCAN button to start the search. Press to seek lower or higher When the radio finds a station, it stops scanning frequencies.
  • Page 173 Radio functions HU-450/650/850 3905007d 3905009m 3901873d Programming stations Autostoring stations 4. Briefly press the AUTO button or one of the arrows of the steering wheel keypad to 1. Set the desired frequency. This function automatically seeks and stores up scroll to another of the automatically preset to 10 strong AM or FM stations in a separate stations.
  • Page 174 Radio functions HU-450/650/850 Traffic information - TP Radio Data System - RDS Station Activate traffic information from a special RDS is a system that links specific network channel: transmitters. It is used, for example, to tune the Traffic information from RDS stations correct frequency of a station irrespective of the 1.
  • Page 175 Radio functions HU-450/650/850 TP search Activating News: This function allows you to listen to traffic Setting the current station as news source: 1. Select radio mode using the FM button and information when travelling between different press SOURCE. areas and countries without selecting a station. 1.
  • Page 176 Radio functions HU-450/650/850 PTY standby Programme type - PTY Programme types Displayed PTY mode is then in standby until the selected Use the PTY function to select between the PTY OFF programme type is broadcast. When this various programme types New features New features happens, the radio automatically switches to the...
  • Page 177 Radio functions HU-450/650/850 Automatic frequency Regional radio programmes EON - Local/Distant updating (Enhanced Other Networks) The regional function is normally deactivated. When the function is activated you can continue The AF function is normally activate and When EON is activated, the radio programme is listening to a regional broadcast even if the ensures that the radio tunes to the strongest interrupted for traffic bulletins, news broadcasts...

  • Page 178: Resetting Rds Functions

    Radio functions HU-450/650/850 Resetting RDS functions Radio text Resets all radio settings to the original factory Some RDS stations broadcast information, settings. such as about programme content and artists. 1. Select radio mode using the FM button and Hold the FM button depressed a few seconds press SOURCE.
  • Page 179 Cassette player HU-450/650 DOLBYBNR 3905010m 3901857d 3901876d 3901873d Cassette opening Fast forward/rewind Cassette eject Slide cassette into the cassette opening with the The tape is fast forwarded by pressing and If you press the button, the tape stops and the tape to the right.

  • Page 180: Cd Player Hu

    CD player HU- 650 3901862d 3905010m 3901873d Fast forward/rewind CD player Random Insert a CD. If there is already a CD in the Press and hold to search within a Press RND to connect the random function. track or the entire disc. The search continues as player, activate it by turning the SOURCE knob The unit plays tracks from the disc in random long as the button is depressed.

  • Page 181: Cd Changer

    External CD changer 3905010m 3901873d 3903125m CD changer Fast forward Random The external CD changer (option) is mounted Press and hold to search within a track Press RND (for HU-650 and 850) to activate behind the panel on the rear left side of the or the entire disc.

  • Page 182: Internal Cd Changer Hu

    Internal CD changer HU-850 3905010m 3901862d 3901873d Internal CD changer Random Selecting disc number HU-850 contains an internal 6-disc CD Press RND to connect the random function. Turn the PRESET/CD knob. The disc and track changer. A randomly selected track is chosen from a numbers are shown on the display.

  • Page 183: Dolby Surround Pro Logic Ii Hu

    Dolby Surround Pro Logic II HU-850 3901877d 3905088d Dolby Surround Pro Logic II 3-channel stereo Dolby Surround Pro Logic II Mode Dolby Surround Pro Logic II is a further refi- To select 3-channel stereo press “3-CH”. nement of the previous system and provides a “3-CH”...
  • Page 184 Dolby Surround Pro Logic II HU-850 3902419d 3902419d Centre loudspeaker volume Rear loudspeaker output level (surround sound) Set the centre loudspeaker volume by pressing out the button and turning it left or right. In Set the power output of the rear channels by the centre position the volume is “normalised”...
  • Page 185 Technical data - Audio HU-450 Alarm Output: 4 x 25 W “Alarm!” is shown in the radio display when an alarm message is Impedance: 4 Ohm transmitted. The function is used to warn the driver of serious Voltage required: 12 V, negative ground accidents or catastrophes, such as collapsed bridges, earthquakes or nuclear accidents.

  • Page 186: Telephone

    Telephone (option) Telephone system Operating Call options Memory functions Menu functions Miscellaneous information...

  • Page 187: Emergency Calls

    Telephone Telephone system 1. Keypad in centre console General rules 5. SIM card · Put traffic safety first! If you as the All telephones system functions can be All telephone functions can be controlled via controlled from the keypad in the centre driver must use the privacy handset the keypad in the centre console.
  • Page 188 Telephone 3903012m...

  • Page 189: Active Mode

    Telephone Operating 3903019m 3902219d 3903022m SIM card Switching the telephone on and off Active mode To switch the telephone on: turn the ignition key The telephone can only be used in conjunction The telephone must be in active mode to use its to position I.

  • Page 190: Call Options

    Telephone Call options 3902219d 3902220d 3800670d Display Making and receiving calls Ending a call The display shows the current function, such as To place a call: enter the number and press To conclude a call, press on the steering menu alternative, message, telephone number, on the steering wheel or centre console keypad wheel or centre console keypad or put the or setting.
  • Page 191 Telephone Call options (cont.) Speed dial Storing speed dial numbers A number stored in the telephone book can be linked to a speed dial button (0-9) as follows: 1. Go into active mode. Scroll with Edit memory (Menu 3) and press 2.

  • Page 192: Call Waiting

    Telephone The following functions are available during Functions during a call three-way calling (scroll with arrows): The following functions are available during a call (scroll with arrows): Secret mode/ Secret mode Secret mode off Secret mode/ Secret mode Handset/ Secret mode off Handsfree Use the handset or Hold/No hold...

  • Page 193: Memory Functions

    Telephone Memory functions Enter a name (or message) Telephone numbers and names can be stored Press the button with the desired character: in either the telephone memory or the SIM card once for the first character, twice for the memory. second, etc.

  • Page 194: Menu Functions

    Telephone Menu functions Traffic safety For reasons of safety, the menu system cannot The menu function is used to check and alter settings and programme new functions in your be accessed at speeds in excess of 8 km/h system. The different menus are shown in the (5 mph).
  • Page 195 Telephone Main menus/submenus 1. Call register 3. Edit memory 5. Settings Missed calls Enter item Factory settings Received calls Search Network selection Dialled calls 3.2.1 Edit Language Erase list 3.2.2 Erase 5.3.1 English UK 1.4.1 All 3.2.3 Copy 5.3.2 English US 1.4.2 Missed 3.2.4 Move 5.3.3 Svenska...
  • Page 196 Telephone Menu 1. Call register Menu 2. Messages Menu 3. Edit memory 1.1 Missed calls: A list of missed calls is 2.1 Read: Here you can read received text 3.1 Enter item: You can store names and shown here. You can choose to call, erase or messages.
  • Page 197 Telephone 5.5 Change codes: Change the PIN code or Menu 4. Call options Menu 5. Settings telephone code. 5.1 Factory settings: Function to return to 4.1 Transmit number: Choose whether or not 5.5.1 PIN code to display your number to the person you call. the system’s factory settings.

  • Page 198: Miscellaneous Information

    Telephone Miscellaneous information Specifications Output SIM card small Memory positions 255* SMS (Short Message Service) Computer/Fax Dual band (900/1800) * 255 memory positions in the telephone memory. The number of memory positions on the SIM card varies depending on your subscription.

  • Page 200: Index

    Index AW5 (automatic gearbox) ..... 88 Cigarette lighter socket ......45 Alphabetical index Average fuel consumption ....38 Cleaning the seat belts .......139 Axle load ..........155 Cleaning the upholstery .....139 Climate control with air conditioning (AC) ......58 Battery (jump start) ....... 95 Coat hanger ...........
  • Page 201 Index Fuel gauge ..........30 Instrument lighting ....... 40 Driving with trailer ....... 96 DSTC ............. 33 Function selector ........59 Interior - LHD .......... 4 Interior - RHD .......... 5 Interior lighting ........67 ECC ............54 Gearbox type designation ....154 Isofix mounting system for Electric cooling fan ....
  • Page 202 Index Master key ..........74 Power steering ........148 Seat setting ..........64 SEE MANUAL ........35 Minor stone chips and scratches ..137 Power sunroof ........48 Mirrors ........... 47 Power windows ........46 Service key ..........74 Misting on window interiors ....53 Puncture, temporary repair ....116 SERVICE REQUIRED ......
  • Page 203 Towbar ........... 98 Ventilation ..........51 Towbar - detachable (mounting) ..100 VIN ............154 Towbar - detachable (removal) ...101 Volvo integrated booster cushion ..26 Towing equipment ......98, 99 Volvo Service Programme ....141 Towing eye ..........94 Towing ........... 94 Warning - fault in ABS system .....
  • Page 204 Index...
  • Page 206 TP 7528 (English). AT 0446. Printed in Sweden, Elanders Infologistics Väst AB, Mölnlycke 2004...

Table of Contents
