Page 1 2 0 0 5 VOLVO This manual deals with the operation and care of your Volvo. Welcome to the world-wide family of Volvo owners. We trust that you will enjoy many years of safe file:///K|/ownersdocs/2005/2005_S80/05s80_00.htm (1 of 6)12/30/2006 4:38:12 PM...
Page 2 2005 Volvo S80 driving in your Volvo, an automobile designed with your safety and comfort in mind. To help ensure your satisfaction with this vehicle, we encourage you to familiarize yourself with the equipment descriptions, operating instructions and maintenance requirements/recommendations in this manual. We also urge you and your passengers to wear seat belts at all times in this (or any other) automobile.
Page 3 Chapter 10 - Audio systems HomeLink® Universal Transceiver (option) Index Back Cover © 2004 Volvo Cars of North America LLC. General information Shiftlock When your car is parked, the gear selector is locked in the (P)ark position. To release the selector from this position, turn the ignition key to position II (or start the engine), depress the brake pedal, press the button on the front side of the gear selector and move the selector from (P)ark.
Page 4 Volvo and the environment Volvo is committed to the well being of its customers. As a natural part of this commitment, we care about the environment in which we all live. Caring for the environment means an everyday involvement in reducing our environmental impact.
Page 5 In addition to continuous environmental refinement of conventional gasoline-powered internal combustion engines, Volvo is actively looking at advanced technology alternative-fuel vehicles. When you drive a Volvo, you become our partner in the work to lessen the car's impact on the environment.
Page 6 2005 Volvo S80 PremAir® On the surface of the radiator in the engine compartment, there is a special coating called PremAir®. PremAir® works as a catalytic converter, converting most of the ozone passing through the radiator into oxygen, thereby reducing harmful ground-level ozone.
Page 7 1 Safety Not wearing a seat belt is like believing "It'll never happen to me!" Volvo, the inventor of the three-point seat belt, urges you and all adult occupants of your car to wear seat belts and ensure that children are properly restrained, using an infant, car or booster seat determined by age, weight and height.
Page 8 2005 Volvo S80 Stability Traction Control (STC) 20 Dynamic Stability and Traction Control (DSTC) pg. 2 Seat belts Seat belts Always fasten the seat belts before you drive or ride. A chime will sound several times if the driver has not fastened his seat belt.
Page 9 2005 Volvo S80 Lap portion of the belt should sit low Child seats: Please refer to page 16 for information on securing child seats with the seat belts. During pregnancy Pregnant women should always wear seat belts. Remember that the belt should always be positioned in such a way as to avoid any possible pressure on the abdomen.
Page 10 Never repair the belt on your own; have this work done by an authorized Volvo retailer only. Any device used to induce slack into the shoulder belt portion of the three-point belt system will have a detrimental effect on the amount of protection available to you in the event of a collision.
Page 11 As an enhancement to the three-point seat belt system, your Volvo is equipped with a Supplemental Restraint System (SRS). The Volvo SRS consists of an airbag (2) on both the driver's and passenger's sides and seat belt tensioners in both front door pillars (4). The system is designed to supplement the protection provided by the three-point seat belt system.
Page 12 When installing any optional equipment, make sure that the SRS system is not damaged. Do not attempt to service any component of the SRS yourself. Attempting to do so may result in serious personal injury. If a problem arises, take your car to the nearest authorized Volvo retailer for inspection as soon as possible.
Page 13 If the SRS warning light stays on after the engine has started or if it comes on while you are driving, drive the car to the nearest authorized Volvo retailer for inspection as soon as possible. There is no maintenance to perform on the SRS yourself. The month and year shown on the decal on the door pillar indicate when you should contact your Volvo retailer for specific servicing or replacement of airbags and seatbelt tensioners.
Page 14 2005 Volvo S80 800-458-1552 1-800-663-8255 pg. 6 Front airbags - SRS file:///K|/ownersdocs/2005/2005_S80/05s80_01a.htm (8 of 14)12/30/2006 4:38:14 PM...
Page 15 Collisions can occur where only one of the airbags deploys. NOTE: Volvo's dual-stage airbags: If the impact is less severe, but severe enough to present a clear injury risk, the dual-stage airbags are triggered at just 70% of its total capacity. If the impact is more severe, the dual-stage airbags are triggered with full capacity.
Page 16 Seat belts - the heart of the Volvo safety system The heart of the Volvo safety system is the three-point seat belt (a Volvo invention)! In order for the SRS system to provide the protection intended, seat belts must be worn at all times by everyone in the car.
Page 17 (see below). This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
Page 18: Airbag (Sips)
Never try to open or repair any components of the SIPS airbag system. This should only be done by an authorized Volvo service technician. In order for the SIPS airbag to provide its best protection, both front seat occupants should sit in an upright position with the seat belt properly fastened.
Page 19 This may cause airbag deployment which could result in personal injury. Have the car towed to an authorized Volvo retailer for repairs.
Page 20 2005 Volvo S80 If the inflatable curtain deploys, it remains inflated for approximately 3 seconds. WARNING! The IC system is a supplement to the Side Impact Protection System. It is not designed to deploy during collisions from the front or rear of the car or in rollover situations.
Page 21 2005 Volvo S80 pg. 12 Whiplash Protection System (WHIPS) Whiplash Protection System (WHIPS) - front seats only The WHIPS system consists of specially designed hinges and brackets on the front seat backrests and head restraints designed to help absorb some of the energy generated in a collision from the rear ("rear- ended").
Page 22 Check seat belt mechanism function as follows: Attach the seat belt and pull rapidly on the strap. Volvo Concern for Safety Safety is the Volvo cornerstone. Our concern dates back to 1927 when the first Volvo rolled off the production line. three-point seat belts (a Volvo invention), safety cages, and energy-absorbing impact zones were designed into Volvo cars long before it was fashionable or required by government regulation.
Page 23 However, NHTSA cannot become involved in individual problems between you, your retailer, or Volvo Cars of North America. To contact NHTSA, you may either call the Auto Safety Hotline toll free at 1-800-424-9393 (or 202-366-0123 in Washington, D.C.
Page 24 2005 Volvo S80 pg. 14 Child safety Child Restraint Anchorages Volvo cars are fitted with child restraint top tether anchorages in the rear seat. Refer to the child seat manufacturer's instruction for information on securing the child seat. WARNING! Child Restraint Anchorages are designed to withstand only those loads imposed by correctly fitted Child Restraints.
Page 25 2005 Volvo S80 ISOFIX/LATCH anchors Lower anchors for ISOFIX-equipped child seats are located in the rear, outboard seats, hidden below the backrest cushions. Symbols on the seat back upholstery mark the anchor positions as shown. To access the anchors, kneel on the seat cushion and locate the anchors by feel.
Page 26 The booster cushion should also be replaced if it is badly worn or damaged in any way. This work should be performed by an authorized Volvo retailer only. - The booster cushion should be cleaned while in place in the vehicle if possible. If not, please consult your Volvo retailer.
Page 27 2005 Volvo S80 Storing the booster cushion Fold the seat up - it will lock automatically to the backrest. NOTE: Canada only: This cushion may be referred to as a built-in booster cushion. pg. 16 Child safety Keeping child seats in place (ALR/ELR*) To make child seat installation easier, each seat belt (except for the driver's belt) is equipped with a locking mechanism to help keep the seat belt taut.
Page 28: Airbag (Srs)
Because of the size of the airbag and its speed of inflation, a child should never be placed in the front seat, even if he or she is properly belted or strapped into a child safety seat. Volvo has been an innovator in safety for over fifty years, and we'll continue to do our part.
Page 29 A specially designed and tested booster cushion (not available in Canada) can be obtained from your Volvo retailer for children weighing 33 - 80 lb (15 - 36 kg) and 38 - 54 inches (97 - 137 cm) in height.
Page 30 NOTE: Press the brake pedal hard and maintain pressure on the pedal - do not pump the brakes. WARNING! If the fluid level is below the MIN mark in the reservoir: DO NOT DRIVE. Tow the car to a Volvo retailer and have the brake system inspected.
Page 31 If the warning lamp lights up there is a malfunction of the ABS system (the standard braking system will however function) and the vehicle should be driven cautiously to a Volvo retailer for inspection. The Anti-lock Braking System (ABS) helps to improve vehicle control (stopping and steering) during severe braking conditions by limiting brake lockup.
Page 32 If the fluid level is below the MIN mark in the reservoir, DO NOT DRIVE. Have the car towed to an authorized Volvo retailer and have the brake system inspected. If the brake fluid level is above the MIN mark, drive carefully to an authorized Volvo retailer and have the brake system inspected.
Page 33 2005 Volvo S80 wheel spin. This is quite normal. This is one of the STC/DSTC's permanent functions and is not affected when the button on the center control panel is pressed. 2. Spin control (SC) The spin control function is designed to help prevent the drive wheels from spinning while the car is accelerating.
Page 34 That the system has been automatically disengaged due to a fault. "ANTI SKID SERVICE REQUIRED" be displayed in the text window. An authorized Volvo retailer should check the system. The system has been temporarily switched off due to high brake temperature. "TRACTION CONTROL TEMPORARILY OFF"...
Page 35 2005 Volvo S80 pg. 22 Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_01b.htm (15 of 15)12/30/2006 4:38:15 PM...
Page 36 2005 Volvo S80 2 0 0 5 VOLVO Chapter 2 - Instruments, switches and controls pg. 23 Instruments, switches and controls Interior 24 Exterior 25 Instruments 26 Instrument panel 27 Indicator and warning lights 28 Text information window 30 Switches in center console 31...
Page 37: Alarm
2005 Volvo S80 Electrically operated windows 41 Rearview/sideview, vanity mirrors 42 Power moonroof 43 Sun visor, sun blinds 44 pg. 24 Interior Locking and unlocking the 63/65 Alarm Electrically operated windows Sideview mirror controls Glove compartment Automatic transmission file:///K|/ownersdocs/2005/2005_S80/05s80_02a.htm (2 of 11)12/30/2006 4:38:16 PM...
Page 38 2005 Volvo S80 Geartronic Parking brake Center console switches Power seat adjustment Heated seats (option) Cleaning upholstery Folding rear seat Panel for long loads Folding down head restraint Adjusting center head restraint Child safety locks Integrated booster cushion pg. 25 Exterior...
Page 39 2005 Volvo S80 Economical driving Replacing a back-up light Replacing a brake light Replacing a tail light Replacing a turn signal Replacing a rear fog light Replacing license plate lights Tires Wheels Brake system Spare tire Changing wheels Replacing a high beam...
Page 40 2005 Volvo S80 Temperature gauge Speedometer Odometer Trip odometer Warning lights Text window Tachometer Clock Ambient temperature sensor Fuel gauge Hazard warning flashers Audio system Electronic climate control Heated seats (option) Heated rear window/rearview mirrors file:///K|/ownersdocs/2005/2005_S80/05s80_02a.htm (5 of 11)12/30/2006 4:38:16 PM...
Page 41 2005 Volvo S80 Steering wheel adjustment Airbag Cruise control Windshield wipers/washer Turn signal lever Trip computer Audio system controls High/low beam headlights Parking lights Fog lights Instrument panel lighting Button to unlock fuel filler door pg. 27 Instrument panel 1 Turn signals...
Page 42 The fuel tank holds approximately 21.1 US gal. (80 liters) on T6 models, or 18 US gal. (68 liters) on the S80 All Wheel Drive and the S80 2.5T Front Wheel Drive. A warning light in the gauge comes on there are approximately 1.8 US gal. (8 liters) of fuel remaining in the tank.
Page 43 If the light comes on (or stays on after the vehicle has started), the SRS diagnostic system has detected a fault. Drive to an authorized Volvo retailer for an inspection of the system. See the SRS section for more information.
Page 44 137. If the light stays on after restart, have the car towed to the nearest authorized Volvo retailer. After hard driving, the light may come on occasionally when the engine is idling. This is normal, provided it goes off when the engine speed is increased.
Page 45 Anti-lock Brake System ABS If the warning light comes on, there is a malfunction of the ABS system (the standard braking system pwill however function). The vehicle should be driven to a Volvo retailer for inspection. See page 19 additional information.
Page 46 2005 Volvo S80 Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_02a.htm (11 of 11)12/30/2006 4:38:16 PM...
Page 47 STOP SAFELY: Stop and switch off the engine - to help prevent serious risk of damage. STOP ENGINE: Stop and switch off the engine - to help prevent serious risk of damage. SERVICE URGENT: Take your car to an authorized Volvo retailer for inspection as soon as possible. file:///K|/ownersdocs/2005/2005_S80/05s80_02b.htm (1 of 15)12/30/2006 4:38:18 PM...
Page 48 2005 Volvo S80 SEE MANUAL: Refer to your owner's manual. For additional information, please contact your Volvo retailer. SERVICE REQUIRED: Take your car to an authorized Volvo retailer for inspection at your convenience (but preferably before the next scheduled maintenance service).
Page 49 2005 Volvo S80 Four-C active chassis system (option) page 82 for information on this function. Stability Traction Control (STC)/Dynamic Stability Traction Control (DSTC) - option Press this switch for at least half a second to turn the Spin Control (SC) function of the STC/DSTC system on or off.
Page 50 2005 Volvo S80 WARNING! For safety reasons, no one should be allowed to sit in the outboard rear seat positions if the head restraints are folded down. If these positions are occupied, the head restraints should be in the upright (fixed) position.
Page 51 2005 Volvo S80 NOTE: The auxiliary sockets can also be used for cigarette lighters, which are available at your Volvo retailer. pg. 32 Trip computer Trip computer The trip computer stores information gathered from several systems in your car and has five menus that can be displayed in the text window.
Page 52 2005 Volvo S80 Driving distance on current fuel reserve This function shows the approximate distance that can be driven on the fuel remaining in the tank. This calculation is based on average fuel consumption during the last 12 miles (20 km) of driving and the amount of fuel remaining in the tank when the reading was taken.
Page 53 2005 Volvo S80 The cruise control panel is located on the left side of the steering wheel hub. Engaging cruise control Press the CRUISE button. CRUISE will be displayed in the information window in the instrument panel. NOTE: This does not set the vehicle's speed.
Page 54 II. Front and rear parking lights and license plate lights will also be on. Volvo recommends the use of daytime running lights. If, however, you would prefer to have these lights turned off (USA only), please consult your Volvo retailer. Please note that the use of daytime running lights is mandatory in Canada.
Page 55 2005 Volvo S80 NOTE: Bi-Xenon headlights (option): Turn the headlight switch to position 0 to activate a daylight sensor, which automatically switches the low beams on or off, depending on ambient light conditions. When driving in daylight, the headlights will switch off and the daytime running lights will come on. In darkness, the daytime running lights will switch off and the Bi-Xenon headlights will switch on.
Page 56 2005 Volvo S80 NOTE : If the fuel filler door does not unlock after the button has been pressed, please see page 35 information on manually unlocking this door. D - Front fog lights (option) The front fog lights will only function in combination with the low beam headlights.
Page 57 2005 Volvo S80 2. Fold down the cover panel to access the electric motor (C). 3. Press the catch (D) rearward to unlock the fuel filler door, or forward to lock the door. pg. 36 Turn signals Turn signals 1 Lane change position. In maneuvers such as lane changing, the driver can flash the turn signals by moving the turn signal lever to the first stop and holding it there.
Page 58 2005 Volvo S80 Windshield wipers/washers 0 Windshield wipers off "Single sweep" position: Move the lever slightly upward from the 0 position for one sweep of the wipers. The lever returns automatically to 0 when released. Intermittent wiper function. With the lever in this position, you can set the wiper interval by twisting ring 1 upward to increase wiper speed or downward to decrease the speed.
Page 59 2005 Volvo S80 · Move the windshield wiper lever down to another position. Moving the lever up will not deactivate the rain sensor. Doing so will cause the wipers to sweep the windshield until the lever is released, at which time the wipers return to rain sensor mode.
Page 60 2005 Volvo S80 Steering wheel adjustment Both the height and the reach of the steering wheel can be adjusted to a comfortable position for the driver. Pull down the lever on the left of the steering column. Adjust the steering wheel to a suitable position and press the lever back into place to lock the steering wheel in the new position.
Page 61 2005 Volvo S80 opened. * The gear selector must be in the (P)ark position. ** Please be aware that leaving the key in this position will increase battery drain. Steering wheel lock The steering wheel lock might be under tension when the car is parked.
Page 62 2005 Volvo S80 pg. 39 Warning flashers, Heated mirrors/rear window, Heated front seats Hazard warning flashers The four-way flasher should be used to indicate that the vehicle has become a traffic hazard. To activate the flashers, press the triangular button in the center dash. Press the button again to turn off the flashers.
Page 63 2005 Volvo S80 Heated front seats (option) The front seat heating can be switched on and off as required. Press the switch once for maximum seat heating. Both LEDs in the switch will be lit. Press the switch a second time for comfort heating. One LED in the switch will be lit.
Page 64 NOTE: The cover should be kept on when the auxiliary sockets are not in use. Ashtrays Volvo cars in North America do not have an ashtray in the front seat as standard equipment. If you want to have an ashtray in the front seat, please contact your Volvo retailer.
Page 65 2005 Volvo S80 Electrically operated windows The electrically operated windows are controlled by buttons in the arm rests. The ignition switch must be ON * (ignition key in position I or II or the engine running) for the electrically operated windows to function.
Page 66 2005 Volvo S80 Cutout switch for rear windows The electrically operated rear door windows can be disabled by a switch located on the driver's door (see illustration). If the LED in the switch is OFF: The rear door windows can be raised or lowered with the buttons on the rear door armrests or with the buttons on the driver's door armrest.
Page 67 2005 Volvo S80 Rearview mirror A Normal position B Night position, reduces glare from following headlights Autodim function (option) The autodim function reacts to headlights from following traffic and automatically reduces glare. NOTE: This function is automatically switched off when the gear selector is placed in the Reverse position.
Page 68 2005 Volvo S80 Sideview mirror controls Remote control (central locking system) If you lock the car and later unlock it with the same remote control and open the driver's door, the sideview mirrors will automatically move to the position they were in when you left the car. This feature will work in the same way with all of the remote control transmitters (up to 3) that you use with your car.
Page 69 2005 Volvo S80 Power moonroof To operate the moonroof, turn the ignition key to position I or II, or start the engine. The moonroof can be operated in two ways: A. Tilt position B. Sliding moonroof A. Tilt position Open: With the moonroof closed, push up the rear edge of the switch (position 5 in the illustration below).
Page 70 2005 Volvo S80 Manual close: Push the switch to position 2 and hold it until the moonroof has closed completely or to the position of your choice. Auto close: Push the switch forward as far as possible (position 1) and release it to automatically close the moonroof .
Page 71 2005 Volvo S80 moonroof is opened. The visor must be closed manually. Sun blind - rear window Pull up the blind from the rear parcel shelf and attach the two hooks in the fasteners in the roof liner above the rear window, as shown in the illustration above.
Page 72 2005 Volvo S80 2 0 0 5 VOLVO Chapter 3 - Climate control system pg. 45 Climate control system Ventilation 46 Electronic Climate Control (ECC) 47 Climate control system - general information 50 Interior Air Quality system (option) 51 pg. 46 Ventilation...
Page 73 2005 Volvo S80 B Closed C Horizontal air flow D Vertical air flow Direct the outer air vents toward the side windows to demist. In cold weather, close the air vents in the center of the dash to direct as much air as possible toward the windows.
Page 74 2005 Volvo S80 Direct the air vents toward the rear side windows to demist. Direct the air vents toward the rear seat for the best heating/cooling effect. pg. 47 Electronic Climate Control (ECC) pg. 48 Electronic Climate Control (ECC) AUTO This function automatically regulates the Electronic Climate Control system so that the selected temperatures are maintained.
Page 75 2005 Volvo S80 Temperature These controls are used to individually set the temperature for both sides of the passenger compartment. Please note that the compartment will not be heated or cooled faster by setting the temperature higher or lower than necessary.
Page 76 2005 Volvo S80 Press this switch to engage the recirculation function (air in the passenger compartment recirculates - no fresh air enters the compartment). The LED in the switch will light up to indicate that the function is engaged. Use this function if the outside air is contaminated with exhaust gases, smoke, etc or to heat/cool the car quickly.
Page 77 Replace the cabin air filter with a new one at the recommended intervals. Please refer to your Warranty and Service Records Information booklet, or consult your Volvo retailer for these intervals. The filter should be replaced more often when driving under dirty and dusty conditions. The filter cannot be cleaned and therefore should always be replaced with a new one.
Page 78 Acceleration The air conditioning is momentarily disengaged during full-throttle acceleration. ECC maintenance All maintenance on the climate control systems should be carried out by an authorized Volvo service technician only. Refrigerant Volvo cares about the environment. The air conditioning system in your car contains a CFC-free refrigerant - R134a (HFC134a).
Page 79 2005 Volvo S80 Operation: Press to activate the Air quality sensor (normal setting). Or select one of three functions by pressing 1. Press the LED AUT comes on. The Air quality sensor is now activated. 2. Press no LED is lighted.
Page 80 2005 Volvo S80 2 0 0 5 VOLVO Chapter 4 - Interior pg. 53 Interior Front seats 54 Coat hanger 55 Interior lighting 56 Storage compartments 57 Storage compartments in center console, Long loads 58 Spare tire, Cargo net in trunk 59 Folding rear seat backrests 60 pg.
Page 81 2005 Volvo S80 1. Power seat control panel, 2. Lumbar support: turn for softer or firmer support Electrically operated seats Operation Driver's seat: The seat can be adjusted if the ignition key is in position I, II or if the engine is running.
Page 82 2005 Volvo S80 WARNING! Because the driver's seat can be adjusted with the ignition off, children should never be left unattended in the car. Movement of the seat can be STOPPED at any time by pressing any button on the power seat control panel.
Page 83 2005 Volvo S80 Remote keyless entry system and the driver's seat The remote control transmitter also controls the position of the electrically operated driver's seat in the following way: 1. Adjust the seat to your preferences. 2. When you leave your vehicle, lock it using the remote control.
Page 84 2005 Volvo S80 down the backrest: Move the seat as far rearward as possible Adjust the backrest tilt to the most upright position Lift the catches on the lower rear side of the backrest Without releasing the catches, push the backrest forward Move the seat as far forward as possible so that the head restraint slides under the glove compartment.
Page 85 When switched on with the engine running, the light will stay on indefinitely. The light may be switched off at any time by pressing the center button a second time. The courtesy light timer periods can be changed. Consult your Volvo retailer. Overriding the Interior and Trunk Courtesy Lights Normally if a car door is left open with the engine turned off, the interior courtesy light will stay on for 10 minutes.
Page 86 2005 Volvo S80 To switch off the interior and trunk courtesy lights indefinitely, press and hold the center button in the panel above the rearview mirror for 3 seconds.The courtesy lights will go off and remain off until the center button is pressed again.
Page 87 2005 Volvo S80 WARNING! Packages on the rear window shelf can obscure vision and may become dangerous projectiles in the event of a sudden stop or an accident. Anchor any heavy objects to help prevent them from moving during sudden stops.
Page 88 2005 Volvo S80 Storage compartment in center console/cup holders Press button A to pop open the cup holder. Press button B to open the storage space in the center console for cassettes, accessory coin holder, etc. Secure long loads with the seat belt...
Page 89 2005 Volvo S80 Release the flap by pushing the catch (located on the rear side of the backrest) upward and pulling the flap forward. Return the backrest to the upright position. * If your car is equipped with the optional integrated child booster cushion, this cushion must be folded...
Page 90 2005 Volvo S80 Cargo net in the trunk The cargo net in the trunk can be used to secure light objects. Pull the net out and slide the runner in the handle down into one of the two slots provided at the rear edge of the trunk. Use the release tab to release tension on the net while it is being placed around an object.
Page 91 Fold the backrest down. WARNING! All S80 cars feature 60/40 split fold-down rear seats. This function is performed by handles inside the trunk, and also provides a means for children and adults to enter the passenger compartment in the event they become locked inside the trunk.
Page 92 2005 Volvo S80 WARNING! Keep vehicle doors and the luggage compartment locked and keep keys out of a child's reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles.
Page 93 2005 Volvo S80 2 0 0 5 VOLVO Chapter 5 - Keys, Locks, Alarm pg. 61 Keys, Locks, Alarm Keys, Exterior courtesy lights, Locking and unlocking the car 62 Remote keyless entry system 63 Locking and unlocking the car 65...
Page 94 The car will start only with a properly coded key. If you misplace a key, take the other keys to an authorized Volvo retailer for reprogramming as an antitheft measure.
Page 95 They will also activate or deactivate the vehicle's alarm system(s). The car can also be locked/unlocked with the key. If one of the transmitters is misplaced, contact your nearest authorized Volvo retailer for replacement. file:///K|/ownersdocs/2005/2005_S80/05s80_05.htm (3 of 13)12/30/2006 4:38:23 PM...
Page 96 2005 Volvo S80 1 - Fold key in/out, 2 - Lock, 3 - Approach lighting, 4 - "Panic" function, 5 - Open trunk, 6- Unlock Using the remote control Button 1: Press to extend the key. This button must also be pressed when the key is folded back into the slot in the side of the remote control unit.
Page 97 2005 Volvo S80 Canadian 2306104388 Model 504 2927 by Donnelly Operation is subject to the following conditions: (1) this device may not cause interference, and (2) this device must accept any interference, including interference that may cause undesired operation of the device.
Page 98 Press the cover back into place. Ensure that the rubber seal seats correctly to help prevent moisture from entering the unit. NOTE: The old battery should be disposed of properly at a recycling center or at your Volvo retailer. pg. 65 Locking and unlocking the car Unlocking the trunk with the master key file:///K|/ownersdocs/2005/2005_S80/05s80_05.htm (6 of 13)12/30/2006 4:38:23 PM...
Page 99 Opening the trunk from the inside - (U.S. models only) The S80 is equipped with a florescent handle on the inside of the trunk lid, which can be used in an emergency situation to open the trunk from the inside.
Page 100 2005 Volvo S80 WARNING! Keep vehicle doors and trunk locked and keep keys out of a child's reach. Unsupervised children could lock themselves in an open trunk and risk injury. Children should be taught not to play in vehicles. On hot days, the temperature in the trunk or vehicle interior can rise very quickly. Exposure of people to these high temperatures for even a short period of time can cause heat-related injury or death.
Page 101 2005 Volvo S80 Trunk lock button* Valet security locking The security locking feature of your car allow you to prevent unwanted access to your trunk and glove compartment, while still allowing a parking attendant to unlock, start, and relock the rest of your car. To prevent unwanted access to the trunk and glove compartment do the following: Give your service key to the parking attendant.
Page 102 2005 Volvo S80 The hood is forced opened. The trunk is forced opened. A door is forced opened. The ignition switch is tampered with. If there is movement in the passenger compartment (if the car is equipped with the optional movement sensor).
Page 103 2005 Volvo S80 The position of this button may vary, depending on the specifications of your car. Temporarily turning off the inclination and movement alarm sensor(s) - accessory This button will only be found in cars equipped with the accessory inclination and/or movement sensors.
Page 104 LED flashes rapidly before the ignition is switched on - the alarm has been triggered Fault in the alarm system: If a fault has been detected in the alarm system, a message will be displayed in the text window. Contact a Volvo retailer. Automatic re-lock/re-arm function If the car is unlocked with the remote, the car will re-lock and the alarm will re-arm after 2 minutes unless a door or the trunk has been opened.
Page 105 2005 Volvo S80 WARNING! Remember, in the event of an accident, the rear seat passengers cannot open the doors from the inside with the buttons in position A. pg. 70 This page intentionally left blank. Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_05.htm (13 of 13)12/30/2006 4:38:23 PM...
Page 106 2005 Volvo S80 2 0 0 5 VOLVO Chapter 6 - Starting and driving pg. 71 Starting and driving Fuel requirements 72 Refueling 74 Starting the engine 75 Automatic transmission 76 Four-C active chassis system 82 Front/rear park assist 83...
Page 107: Fuel Requirements
(MMT). If such fuels are used, your Emission Control System performance may be affected, and the Check Engine light (malfunction indicator lamp) located on your instrument panel may light. If this occurs, please return your vehicle to an authorized Volvo retailer for service.
Page 108 To meet seasonal air quality standards, some areas require the use of "oxygenated" fuel. Volvo allows the use of the following "oxygenated" fuels; however, the octane ratings listed on this page must still be met.
Page 109 The fuel tank holds approximately 21.1 US gal. (80 liters) on T6 models, or 18 US gal. (68 liters) on the S80 All Wheel Drive and the S80 2.5T Front Wheel Drive with sufficient volume left over to accommodate possible expansion of the fuel in hot weather. Be aware that the "usable" tank capacity will be somewhat less than the specified maximum.
Page 110 * If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine Light (malfunction indicator lamp) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps.
Page 111 2005 Volvo S80 NOTE: On certain models, when the car is started, idle speed may be noticeably higher than normal for a short period, depending on the temperature of the engine. This has been done to help bring components in the emission control system to their normal operating temperature as quickly as possible, which enables them to function normally.
Page 112 2005 Volvo S80 pg. 85 Points to remember Speed-sensitive power steering With this feature, the steering is most responsive at lower speeds to make parking, driving in city traffic, etc., easier. The effect of the power steering diminishes as you accelerate for greater stability at highway speeds.
Page 113 2005 Volvo S80 may be used at one time. Electrical system When replacing the battery or when carrying out work involving the electrical system, the following should be observed: A battery connection to the wrong terminal will damage the electrical system. Be sure to connect the positive battery cable to the positive battery terminal and the negative battery cable to the negative battery terminal.
Page 114 Volvo-approved removable roof racks are designed to carry the maximum allowable roof load for this vehicle: 220 lbs (100 kg). For Non-Volvo roof racks, check the manufacturer's weight limits for the rack. Never exceed the rack manufacturer's weigh limits and never exceed the maximum rated roof load of 220 lbs (100 kg).
Page 115 2005 Volvo S80 Front towing eyelet Emergency towing The towing eyelet is located in the tool bag, under the floor of the trunk, with the spare tire. This eyelet must be screwed into the positions provided on the right sides of either the front or rear bumper (see illustration).
Page 116 88 Vehicle towing information Towing cars with front wheel drive Volvo recommends the use of flat bed equipment. If wheel lift equipment must be used, please use extreme caution to help avoid damage to the car. In this case, the car should be towed with the rear wheels on the ground if at all possible.
Page 117 89 Towing a trailer When preparing for trailer towing, observe the following: Volvo recommends the use of Volvo trailer hitches which are specially designed for the car. Maximum trailer weight recommended by Volvo is: Trailers without brakes: 1650 lbs (750 kg) Trailers with brakes: 2"...
Page 118 Do not connect the trailer's brake system directly to the vehicle's brake system. More frequent vehicle maintenance is required. Remove the ball and drawbar assembly when the hitch is not being used. Volvo recommends the use of synthetic engine oil when towing a trailer over long distances or in mountainous areas. WARNING! Bumper-attached trailer hitches must not be used on Volvos, nor should safety chains be attached to the bumper.
Page 119 2005 Volvo S80 pg. 91 Detachable trailer hitch - removing file:///K|/ownersdocs/2005/2005_S80/05s80_06b.htm (8 of 14)12/30/2006 4:38:26 PM...
Page 120 2005 Volvo S80 pg. 92 Jump starting Jump starting Follow these instructions to jump start your car's dead battery or to jump start another car's dead battery using your car. Although your car's battery is located under the floor of the cargo area, jumper cables should be connected in the engine compartment , to the points shown in the illustrations.
Page 121 Make sure that the engine coolant contains 50 percent antifreeze. Any other mixture will reduce freeze protection. This gives protection against freezing down to -31°F (-35°C). See section "Coolant". The use of "recycled" antifreeze is not approved by Volvo. Different types of antifreeze may not be mixed.
Page 122 It is therefore advisable to check the state of charge more frequently and spray an anti-rust oil on the battery posts. Volvo recommends the use of snow tires on all four wheels for winter driving - see section "Wheels and tires".
Page 123 Check all lights, including high beams. Reflective warning triangles are legal requirement in some countries. Have a word with your Volvo retailer if you intend to drive in countries where it may be difficult to obtain the correct fuel. Consider your destination. If you will be driving through an area where snow or ice are likely to occur, consider snow tires.
Page 124: All Wheel Drive (Awd) General Information
96 All Wheel Drive (AWD) - option All Wheel Drive (AWD) - general information Your Volvo can be equipped with permanent All Wheel Drive, which means that power is distributed automatically between the front and rear wheels. Under normal driving conditions, most of the engine's power is directed to the front wheels.
Page 125 2005 Volvo S80 Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_06b.htm (14 of 14)12/30/2006 4:38:26 PM...
Page 126 2005 Volvo S80 2 0 0 5 VOLVO Chapter 7 - Wheels and tires pg. 97 Wheels and tires General information 98 Tire inflation 99 Tire inflation pressure tables 101 Tire Pressure Monitoring System (TPMS) 102 Self supporting run flat tires 103...
Page 127 2005 Volvo S80 (the structural member at the side of the vehicle, at the rear of the driver's door opening), or on the inside of the fuel filler door on Canadian models. The tires have good road holding characteristics and offer good handling on dry and wet surfaces. It should be noted however that the tires have been developed to give these features on snow/ice-free surfaces.
Page 128 2005 Volvo S80 characteristics of the vehicle. New tires Remember that tires are perishable goods. As of 2000, the manufacturing week and year will be indicated with 4 digits (e.g. 1502 means that the tire illustrated was manufactured during week 15 of 2002).
Page 129 2005 Volvo S80 Tire inflation Check tire inflation pressure regularly. A table listing the recommended inflation pressure for your vehicle can be found on page 101. Tire inflation pressure placards are also located on the driver's side B-pillar (the structural member at the side of the vehicle, at the rear of the driver's door opening), or on the inside of the fuel filler door on Canadian models.
Page 130 2005 Volvo S80 • Use a tire gauge to check the tire inflation pressure, including the spare, at least once a month and before long trips. You are strongly urged to buy a reliable tire pressure gauge, as automatic service station gauges may be inaccurate.
Page 131 101 Wheels and tires Tire inflation pressure tables Tire pressures recommended by Volvo for your vehicle. Refer to the tire inflation placard for information specific to the tires installed on your vehicle at the factory. Cold tire pressure for vehicle loads up to 890 lbs (400 kg)
Page 132 2005 Volvo S80 225/50R17 39 (270) 39 (270) 39 (270) 39 (270) 235/45R17 SSRFT 235/40R18 39 (270) 39 (270) Temporary spare tire 61 (420) 61 (420) T125/80R17 These weights include the weight of all occupants of the car plus cargo.
Page 133 NOTE: TPMS indicates low tire pressure but does not replace normal tire maintenance. For information on correct tire pressure, please refer to the table on page 101, or consult your Volvo retailer. Erasing warning messages When a low tire pressure warning message has been displayed, and the tire pressure warning light has come on: 1.
Page 134 This message will remain on until wheels with TPMS sensors are mounted on the vehicle and it has been driven for at least one minute at a speed of 20 mph (30 km/h) or faster. TPMS valves can be fitted on winter wheels or full-size spare wheels/tires. Consult your Volvo retailer. CAUTION! When inflating tires with TPMS valves, press the pump's mouthpiece straight onto the valve to help avoid bending or otherwise damaging the valve.
Page 135 2005 Volvo S80 WARNING! • Only specially trained persons should mount self supporting run flat tires. • If self supporting run flat tires are mounted, the vehicle must be equipped with a Tire Pressure Monitoring System. • After a low pressure warning has been displayed, do not exceed 50 mph (80 km/h).
Page 136 2005 Volvo S80 3. R: Radial tire. 4. 15: The diameter of the wheel rim (in inches). 5. 95: The tire's load index. In this example, a load index of 95 equals a maximum load of 1521 lbs (690 kg).
Page 137 2005 Volvo S80 tubeless, etc. Glossary of tire terminology • Tire information placard: A placard showing the OE (Original Equipment) tire sizes, recommended inflation pressure, and the maximum weight the vehicle can carry. • Tire Identification Number (TIN): A number on the sidewall of each tire providing information about the tire brand and manufacturing plant, tire size and date of manufacturer.
Page 138 2005 Volvo S80 • Recommended tire inflation pressure: inflation pressure, established by Volvo, which is based on the type of tires that are mounted on a vehicle at the factory. This inflation pressure is affected by the number of occupants in the car, the amount of cargo, and the speed at which the vehicle will be driven for a prolonged period.
Page 139 2005 Volvo S80 The vehicle's curb weight + cargo + passengers. NOTE: • The location of the various labels in your vehicle can be found on page 144. • A table listing important weight limits for your vehicle can be found on page 145.
Page 140 2005 Volvo S80 pg. 107 Wheels and tires Uniform tire quality grading ALL PASSENGER VEHICLE TIRES MUST CONFORM TO FEDERAL SAFETY REQUIREMENTS IN ADDITION TO THESE GRADES Quality grades can be found, where applicable, on the tire sidewall between the tread should and maximum section width.
Page 141 Snow chains can be used on your Volvo with the following restrictions: • Snow chains should be installed on front wheels only. Use only Volvo approved snow chains. • If accessory, aftermarket or "custom" tires and wheels are installed and are of a size different than the original tires and wheels, chains in some cases CANNOT be used.
Page 142 Recommended tire pressure (see the placard on the B-pillar or on the fuel filler door) should be maintained irrespective of which position on the car the temporary spare tire is used on. In the event of damage to this tire, a new one can be purchased from your Volvo retailer. file:///K|/ownersdocs/2005/2005_S80/05s80_07.htm (17 of 21)12/30/2006 4:38:28 PM...
Page 143 2005 Volvo S80 WARNING! Current legislation prohibits the use of the "Temporary Spare" tire other than as a temporary replacement for a punctured tire. It must be replaced as soon as possible by a standard tire. Road holding and handling may be affected with the "Temporary Spare" in use. Do not exceed 50 mph (80 km/h).
Page 144 2005 Volvo S80 Remove the wheel cap (where applicable) using the lug wrench in the tool bag. With the car still on the ground, use the lug wrench to loosen the wheel bolts 1/2 -1 turn by exerting downward pressure. Turn the bolts counterclockwise to loosen.
Page 145 2005 Volvo S80 changing over to winter tires/wheels). pg. 111 Changing wheels Correct tightening order for wheel bolts Installing the wheel Clean the contact surfaces on the wheel and hub. Lift the wheel and place it on the hub. Install the wheel bolts and tighten hand-tight. Using the lug wrench, tighten crosswise (see illustration above) until all bolts are snug.
Page 146 2005 Volvo S80 WARNING! · The jack must correctly engage the bar in the jack attachment (A). The car's weight must not rest on the jack attachment (B). See illustration on page 110. · Be sure the jack is on a firm, level, non-slippery surface.
Page 147 2005 Volvo S80 2 0 0 5 VOLVO Chapter 8 - Maintenance/Servicing pg. 113 Maintenance/Servicing Fuses 114 Replacing bulbs 119 Paint touch up 126 Washing the car 127 Cleaning the upholstery 129 Maintenance service, Warranty 130 Fuel/emissions systems 131 Drive belt, Coolant 132...
Page 148 If so, put in a new fuse of the same color and amperage (written on the fuse). Spare fuses are stored in the fuse box in the passenger compartment. If fuses burn out repeatedly, have the electrical system inspected by an authorized Volvo retailer. WARNING! Never use fuses with higher amperage than those stated on the following pages.
Page 149 2005 Volvo S80 pg. 115 Fuses in the engine compartment Relays/fuses in the engine compartment When replacing fuses, be sure to replace a blown fuse with a new one of the same color and amperage (written on the fuse). Fuses in positions marked X are replacement fuses.
Page 150 2005 Volvo S80 Windshield wipers Driver's side low beam Front parking lights Passenger's side low beam Fuel pump Starter motor Engine control module, engine relay pg. 116 Fuses in the passenger compartment Fuse box on the edge of the dashboard Fuses are located inside the access panel on the edge of the dashboard.
Page 151 2005 Volvo S80 Power driver's seat (option) Power passenger's seat (option) Climate system blower Control module - front passenger's door Control module - driver's door Ceiling lighting, upper electrical control module Moon roof (option) Ignition switch, SRS system, engine control module, 7.5A...
Page 152 2005 Volvo S80 pg. 117 Fuses in the passenger compartment Fuse box in the passenger compartment, behind the plastic cover This fuse box is located behind the plastic cover below the steering wheel. When replacing a blown fuse, be sure to replace it with a new one of the same color and amperage (written on the fuse).
Page 153 2005 Volvo S80 ABS, STC/DSTC Power steering, Bi-Xenon headlights (option) Driver's side front foglight (option) 7.5A Passenger's side front foglight (option) 7.5A Transmission control module, reverse gear block (M66 gearbox) Driver's side high beam Passenger's side high beam Power passenger's seat (option), audio system...
Page 154 2005 Volvo S80 Fuses in the trunk The fuses in the trunk are located behind the panel on the driver's side. When replacing a blown fuse, be sure to replace it with a new one of the same color and amperage (written on the fuse).
Page 155 2005 Volvo S80 Accessory audio Folding head restraints (option) Trailer wiring (15-feed) All Wheel Drive (option) 7.5A Four-C chassis system (option) Park assist (option) Main fuse: trailer wiring, Four-C, park assist, All Wheel Drive Central locking system Driver's side trailer lighting: parking lights, turn signal...
Page 156 2005 Volvo S80 Replacing high/low beam headlight bulbs The headlight bulbs must be replaced from the engine compartment. CAUTION: Do not touch the glass on halogen bulbs with your fingers. Grease, oil or any other impurities can be carbonized onto the bulb and cause damage to the reflector.
Page 157 Reinstall the plastic cover and turn it clockwise until it is correctly in place (4). "TOP" must be upward. NOTE: If the vertical aim of your headlights needs to be adjusted for any reason (e.g., towing a trailer for extended periods), this should be done by an authorized Volvo retailer. pg. 120 Replacing bulbs Front parking light...
Page 158 2005 Volvo S80 Front parking lights Switch off the ignition. Remove the plastic cover over the high beam bulb by turning it counterclockwise. Pull out the bulb and its socket. Replace the bulb. Press the bulb and its socket back into place.
Page 159 2005 Volvo S80 Press the connector onto the bulb holder. Switch on the ignition to test the bulb. Press the lamp housing back into place on the fender. Be sure it seats properly. pg. 121 Replacing bulbs Tail lights 1. Tail light 2.
Page 160 2005 Volvo S80 · Press the bulb holder back into place. · Reconnect the wiring. · Fold up and close the covering panel. To replace bulb 5: · Pull the bulb holder straight out of its retainer. · Pull the bulb out of the holder.
Page 161 2005 Volvo S80 Vanity mirror lights Carefully insert a screwdriver and pry out the lens. Pry out the defective bulb and replace it. Carefully press the lower edge of lens onto the four tabs and press the upper edge of the lens into place.
Page 162 2005 Volvo S80 Door step courtesy lights The door step courtesy lights are located under the dash on the driver's and passenger's sides. To replace a bulb: Carefully insert a screwdriver and pry out the lens. Replace the defective bulb.
Page 163 2005 Volvo S80 pg. 124 Replacing bulbs Side turn signal Open the front door halfway. From the inside of the fender, push the lamp housing out. Turn the bulb holder 1/4 turn counterclockwise and pull it out from the lens.
Page 164 Press the lamp unit back into place. pg. 125 Replacing bulbs Front courtesy lights These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. file:///K|/ownersdocs/2005/2005_S80/05s80_08b.htm (2 of 12)12/30/2006 4:38:32 PM...
Page 165 These bulbs may be difficult for you to replace yourself. We recommend that you let an authorized Volvo retailer replace these bulbs if necessary. NOTE: Other bulbs may be difficult for you to replace yourself. Let an authorized Volvo retailer replace these bulbs if necessary.
Page 166 2005 Volvo S80 Paint - touch-up bottle Brush Masking tape NOTE: When touching up the car, it should be clean and dry. The surface temperature should be above 60° F (15° C). Minor scratches on the surface If the stone chip has not penetrated down to the metal and an undamaged layer of paint remains, the touchup paint can be applied as soon as the spot has been cleaned.
Page 167 2005 Volvo S80 Bird droppings: Remove from paintwork as soon as possible. Otherwise the finish may be permanently damaged. A detergent can be used to facilitate the softening of dirt and oil. A water-soluble grease solvent may be used in cases of sticky dirt. However, use a wash place equipped with a drainage separator.
Page 168 2005 Volvo S80 WARNING! When the car is driven immediately after being washed, apply the brakes several times in order to remove any moisture from the brake linings. Engine cleaning agents should not be used when the engine is warm. This constitutes a fire risk.
Page 169 2005 Volvo S80 CAUTION: Volvo does not recommend the use of long-life or durable paint protection coatings, some of which may claim to prevent pitting, fading, oxidation, etc. These coatings have not been tested by Volvo for compatibility with your vehicle's clear coat. Some of them may cause the clear coat to soften, crack, or cloud.
Page 170 Volvo also offers a special leather softener that should be applied after the cleaner and protectant. It leaves leather soft and smooth, and reduces friction between leather and other finishes in the vehicle.
Page 171 The maintenance services contain several checks which require special instruments and tools and therefore must be performed by a qualified technician. To keep your Volvo in top condition, specify time-tested and proven Genuine Volvo Parts and Accessories.
Page 172 2005 Volvo S80 may be read and used by: · Volvo Car Corporation · service and repair facilities · law enforcement or government agencies · others who may assert a legal right to know, or who obtain your consent to know such information.
Page 173 Changing coolant Normally, the coolant does not need to be changed. If the system must be drained, consult your Volvo retailer. NOTE: Do not top up with water only. This reduces the rust-protective and antifreeze qualities of the...
Page 174 2005 Volvo S80 coolant and has a lower boiling point. It can also cause damage to the cooling system if it should freeze. Top up with Volvo Genuine Coolant/Antifreeze only. CAUTION: The cooling system must always be kept filled to the correct level. If it is not kept filled, there can be high local temperatures in the engine which could result in damage.
Page 175 NOTE: If the fuel filler cap is not closed tightly or if the engine is running when the car is refueled, the Check Engine light (Malfunction Indicator) may indicate a fault. However, your vehicle's performance will not be affected. Use only Volvo original or approved fuel filler caps. Timing belt For proper functioning of the engine and emission control systems, the timing belt and belt tensioner must be replaced every 105,000 miles (168,000 km) or at 120,000 miles (193,000 km) for the 2.5T...
Page 176: Antifreeze
2005 Volvo S80 Spark plugs The spark plugs should be replaced every 60,000 miles (96,000 km) under normal driving conditions. City driving or fast highway driving may necessitate replacement sooner. Under normal driving conditions, spark plugs require no maintenance between replacement intervals.
Page 177 2005 Volvo S80 Hoisting the car If a garage jack is used to lift the car, the two jack attachments points should be used. They are specially reinforced to bear the weight of the car. A garage jack can also be placed under the front of the engine support frame.
Page 178 2005 Volvo S80 Press up the release control located under the front edge of the hood (at the center) and lift. WARNING! Check that the hood locks properly when closed. Engine compartment 1 Expansion tank - coolant 2 Oil filler cap - engine...
Page 179 Engine oil must meet the minimum ILSAC specification GF-2, including ACEA A1, API SJ, SJ/CF and SJ/Energy Conserving. Your Volvo has been certified to standards using ILSAC oil specification GF-2 5W-30. Volvo recommends use of oil with a quality rating equal to or higher than ILSAC GF-2. Equivalent and better oils include ACEA A1, API SJ, SJ/CF, and SJ/Energy conserving.
Page 180 144 Label information 1 Vehicle Emission Control Information Your Volvo is designed to meet all applicable emission standards, as evidenced by the certification label on the underside of the hood. For further information regarding these regulations, please consult your Volvo retailer.
Page 181 6 Federal Motor Vehicle Safety Standards (FMVSS) specifications (USA) and Ministry of Transport (CMVSS) standards (Canada) Your Volvo is designed to meet all applicable safety standards, as evidenced by the certification label on the facing side of the driver's door. For further information regarding these regulations, please consult your Volvo retailer.
Page 182 2005 Volvo S80 pg. 145 Dimensions and weights Dimensions Length 190.9 in. (485 cm) Width 72.1 in. (183 cm) Height 57.2 in. (145 cm) Wheelbase 109.9 in. (279 cm) Track, front 62.3 in. (158 cm) Track, rear 61.4 in. (156 cm) Turning circle (between 35.8 - 39 ft.
Page 183 *** See also section "Trailer towing" All specifications are subject to change without prior notice. pg. 146 Engine specifications Engine specifications Designation: Volvo B 6294 T Output 268 hp at 5200 rpm (200 KW/87 rps) Max torque 280 ft. lbs. at 1800-5000 rpm (380 Nm at 35-83 rps)
Page 184 The charge air cooler (which resembles a radiator) is located between the turbo-compressor and inlet manifold. Designation: Volvo B 5254 T2 Output 208 hp at 5000 rpm (154 kW/83 rps) Max.
Page 185 Fuel Minimum octane requirement - AKI 87 (RON 91) Volume (fuel tank): 21.1 US gals (80 liters) on T6 models, or 18 US gal. (68 liters) on the S80 All Wheel Drive and the S80 2.5T Front Wheel Drive. Washer fluid reservoir Volume: 6 cyl: 4.7 US qts.
Page 186 Individual rear wheel suspension with longitudinal support arms, double link arms and track rods. Vehicle loading The tires on your Volvo should perform to specifications at all normal loads when inflated as recommended on the tire information label. The label is located on the inside of the fuel filler door and lists vehicle design limits.
Page 187 SV8.5 11. Vanity mirror 1.2W SV5.5 WARNING! Bi-Xenon headlights (option) - due to the high voltage used by these headlights, these bulbs should only be replaced by an authorized Volvo service technician. Electrical system file:///K|/ownersdocs/2005/2005_S80/05s80_09.htm (8 of 10)12/30/2006 4:38:34 PM...
Page 188 150 On Call Roadside Assistance Volvo On Call Roadside Assistance Your new Volvo comes with a four-year On Call Roadside Assistance program. Additional information, features, and benefits are described in a separate information package in your glove compartment. If you have misplaced your package, dial: In the U.S.A.
Page 189 Besides passing exams, each technician must also have worked in the field for two or more years before a certificate is issued. These professional technicians are best able to analyze vehicle problems and perform the necessary service procedures to keep your Volvo at peak operating condition. Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_09.htm (10 of 10)12/30/2006 4:38:34 PM...
Page 190 2005 Volvo S80 2 0 0 5 VOLVO Chapter 10 - Audio systems pg. 151 Audio systems Introduction 152 HU-650 overview 153 HU-850 overview 154 Audio functions HU-650/HU-850 155 Radio functions HU-650/HU-850 157 CD player HU-650 162 Internal CD changer - HU-850 163...
Page 191 · Do not put tape or labels on the disc itself. · Volvo does not recommend the use of plastic outer rings on the disc. · Condensation may occur on discs/optical components of the changer in cold winter weather. The disc can be dried with a clean, lint-free cloth.
Page 192 · Take up slack using a pen or a pencil before inserting a cassette in the cassette slot. Cassette cleaning We recommend the use of the Volvo Cleaning Cassette available as a genuine Volvo accessory. Regular use improves sound quality, cleans vital parts and prevents tape tangle.
Page 193 2005 Volvo S80 6. Scan function (automatically search for radio stations) 7. Navigations buttons (seek/change radio station or CD track) 8. CD eject 9. CD slot 10. CD random play 11. FM 12. AM 13. CD player 14. Automatically search for radio stations 15.
Page 194 2005 Volvo S80 6. Source/Menu Press to open main menu Turn to select FM, AM, CD, CD changer (option), selecting a disc 7. Exit (exit the menu) 8. Scan function (automatically search for radio stations) 9. Navigations buttons (seek/change radio station or CD track) 10.
Page 195 2005 Volvo S80 After the bulletin has been completed, the audio system reverts to the originally selected sound source (radio or CD), which is played at the volume that was selected for that source. If the bulletin volume is adjusted while the bulletin is being broadcast, this new volume is saved and used for subsequent bulletins.
Page 196 2005 Volvo S80 Fader - Balance front/rear Adjust front/rear speaker balance by pressing the button to extend the control and turning it to the left (more sound from the rear speakers) or to the right (more sound from the front speakers). A "detent"...
Page 197 2005 Volvo S80 Scan Press the SCAN button to start the station scan function. When a station is found, scanning stops for approximately 10 seconds, after which scanning will continue. Press the SCAN or EXIT button when a station has been found if you would like to listen to that station and to discontinue the scan function.
Page 198 2005 Volvo S80 pg. 158 Radio functions HU-650/HU-850 Storing stations 1. Tune to the desired station. 2. Press the knob. Choose a number by turning the knob. Press again to store the station. Preset To choose a preset station, turn button to the stored number. The currently selected station is displayed.
Page 199 The RBDS or Radio Broadcast Data System operates in the FM band only, and the information transmitted is supplied exclusively by participating broadcasters. Volvo has no control over the accuracy of the data or information.
Page 200 2005 Volvo S80 Press FM briefly. Station information will be shown twice in the display. Alarm Alarms bulletins are transmitted automatically by certain RBDS stations. The function cannot be deactivated. "Alarm!" is shown in the radio display when an alarm message is sent. The function is used to warn motorists of serious accidents, etc.
Page 201 2005 Volvo S80 The PTY symbol in the display turns off and the radio returns to normal. Program type Display text PTY OFF News NEWS Current affairs AFFAIRS Information INFO Sports SPORT Education EDUCATION Drama DRAMA Art and culture CULTURE...
Page 202 2005 Volvo S80 Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_10a.htm (13 of 13)12/30/2006 4:38:36 PM...
Page 203 2005 Volvo S80 pg. 161 Radio functions HU-650/HU-850 Automatic Frequency update (AF) The AF function tunes to the strongest transmitter for the current station, if that station supports alternative frequencies. AF is OFF by default. To activate/deactivate AF: 1. Select radio mode using the FM button, or by turning the SOURCE knob.
Page 204: Cd Player
2005 Volvo S80 pg. 162 CD player HU-650 Starting the CD player Please refer to the illustration on page 153 for the location of the buttons referred to on this page. 1. Insert a disc into the player. 2. Press the CD button or turn the SOURCE knob to CD.
Page 205 2005 Volvo S80 Starting the CD changer The HU-850 is equipped with an internal, 6-disc CD changer. Please refer to the illustration on page 154 for the location of the buttons referred to on this page. To load discs into the changer: 1.
Page 206 2005 Volvo S80 NOTE: · The EJECT ALL function can only be used while the vehicle is at a standstill and will be cancelled if the vehicle begins to move. · For reasons of traffic safety, you have 12 seconds in which to remove the ejected disc. After that, the disc automatically reinserts into the player, and the CD player will resume playing the most recently selected track.
Page 207 2005 Volvo S80 Changing tracks Briefly press the keys (or the corresponding keys on the optional steering wheel keypad) to skip to the previous or next track. The track number is shown in the display. Fast forward/back Press and hold down the keys (or the corresponding keys on the optional steering wheel keypad) to search within a track or the entire disc.
Page 208 2005 Volvo S80 Tape eject button Tape eject If you press this button the tape stops and the cassette is ejected. To select a new mode (radio, CD) turn the "SOURCE" button. A cassette can be ejected even if the ignition is switched off.
Page 209 2005 Volvo S80 same way. page 152 for information on caring for cassettes. pg. 166 Dolby Surround Pro Logic II - HU-850 only Dolby Surround Pro Logic II Dolby Surround Pro Logic II is a further development of the previous version of the system and provides enhanced sound quality.
Page 210 2005 Volvo S80 3 Channel stereo To select 3 channel stereo mode press "3-CH". "3 ch" is displayed. Press "OFF" to return to 2 channel stereo. pg. 167 Dolby Surround Pro Logic II - HU-850 Center level This function is used to set the level of the center speaker in the dashboard. To set the level: 1.
Page 211 The optional supplementary amplifier (HU-850) may be mounted under the front passenger's seat. If the floor of the car has become soaked for any reason, do not turn on the radio. This would cause damage to the amplifier. Contact a Volvo retailer. Low battery voltage If the level of battery voltage is low, a message will be displayed.
Page 212 2005 Volvo S80 Contents Top of Page file:///K|/ownersdocs/2005/2005_S80/05s80_10b.htm (10 of 10)12/30/2006 4:38:37 PM...
Page 213 2005 Volvo S80 2 0 0 5 VOLVO HomeLink® Universal Transceiver (option) pg. 169 HomeLink® Universal Transceiver (option) HomeLink® Universal Transceiver HomeLink® is an advanced system that can be programmed to learn the codes of three different remote controlled-devices (e.g., garage door openers, remote lighting, entry door lock). HomeLink®'s sun visor- mounted transceiver, powered by your car's electrical system, may then be used in place of your hand- held remote controls.
Page 214 2005 Volvo S80 indicator light begins to flash. Then release the buttons. 3. Hold your hand-held transmitter (garage door opener, for example) 2 to 5 in. (5 to 12 cm) away from the HomeLink® surface, keeping the indicator light in view. For placement questions, contact HomeLink®...
Page 215 2005 Volvo S80 manufactured after 1996: Refer to the garage door opener owner's manual for verification. If your hand-held transmitter appears to program the HomeLink® Universal Transceiver but the programmed button does not activate the garage door, your garage door opener may have a rolling code.
Page 216 2005 Volvo S80 pg. 171 HomeLink® Universal Transceiver (option) Erasing programmed buttons Individual buttons cannot be erased. To erase all three programmed buttons: 1. Turn the ignition key to the "accessory" position (II). 2. Hold down the two outside buttons on the HomeLink® Universal Transceiver for about 20 seconds, until HomeLink®'s indicator light begins to flash.
Page 217: Table Of Contents
2005 Volvo S80 2 0 0 5 VOLVO Index pg. 173 Index ABS..19 ABS - warning light..29 Active chassis system (Four-C)..82 Adjusting the steering wheel..38 Air conditioning..47- 49, 51 Air filter - engine..133 Air vents..46 Airbag (SIPS)..10 Airbag (SRS)..4 Alarm..67, 68 Alarm - "panic"...
Page 218 2005 Volvo S80 HU-650 - overview..153 HU-850 - overview..154 specifications..168 Automatic car washing..128 Automatic Locking Retractor (ALR)..16 Automatic transmission five speed..78 four speed..76 Geartronic..80 Auxiliary socket..40 Backrests, rear seat - folding..60 Battery..93, maintenance..140 replacing..139 ventilation hose..139 Blinds - rear/side rear windows..44 Booster cushion - integrated..15...
Page 219 2005 Volvo S80 Chassis setting ..82 Child booster cushion ..15 Child restraint anchorages ..14 Child safety..14 -17 Child safety locks - rear doors..69 Child seat anchors ISOFIX ..14 Climate controls..47 - 49, 51 Climate system - general information..50 Clock..27...
Page 220 2005 Volvo S80 Electrical system - general information..85 Electrically operated front seats..54 Electrically operated moonroof..43 Electrically operated sideview mirrors..42 Electrically operated windows..41 Electronic Brake Force Distribution..19 Electronic Climate Control(ECC)..47 - 49, 51 Emergency Locking Retractor (ELR)..16 Emergency towing..87, 88 Emergency warning flashers..39 Emissions systems..131...
Page 221 2005 Volvo S80 Front suspension..148 Fuel..72, Fuel filler cap..74 Fuel filler door..74 Fuel filler door - unlocking manually..35 Fuel filter ..133 Fuel gauge..27 Fuel requirements..72 Fuel system..131, 133, Fuel/emissions systems..131 Fuses..114 - 118 Gas cap..74 Gasoline..72 Gear indicator..27 Geartronic ..80 Generator..149...
Page 222 2005 Volvo S80 Home Safe System..62 HomeLink® ..169, 170, 171 Hood - opening..135 Ignition switch..38 Immobilizer (start inhibitor)..65,75 Indicator lights..28, 29 Inflatable curtain (IC)..11 Inflation pressure tables..101 Instrument illumination..34 Instrument panel..27 Instruments..26 Integrated booster cushion ..15 Interior Air Quality system ..51 Interior features - overview..24...
Page 223 2005 Volvo S80 Lifting the car..134 Load carriers..86 Locking and unlocking the car..62 Locking steering wheel..38 Long distance trip..94 Long loads..55 Maintenance service..130 Malfunction indicator lamp..29 Manually unlocking the fuel filler door..35 Mirrors..42 Mirrors, sideview - memory function..42 Moonroof..43 Occupant safety..13 Octane rating..72...
Page 224 2005 Volvo S80 Power moonroof..43 Power seats..54 Power steering - speed-sensitive..85 Power steering fluid ..138, Power windows..41 Radio..153, 154 Radio Broadcast Data System - RBDS..159 Rain sensor - windshield wipers..37 Reading lights - front/rear ..56 Rear door step lights - replacing..123 Rear fog light..29,...
Page 225 2005 Volvo S80 Run flat tires..103 Safety defects - reporting..13 Safety locks - child..69 Seat belt maintenance..13 Seat belts..2, Seat belts - cleaning..129 Seats - front..54 Self supporting run flat tires..103 Servicing..133, 134 Shiftlock..75, 76, 78, 80 Side impact airbag system (SIPS)..10 Side marker lights - replacing..124...
Page 226 2005 Volvo S80 Suspension..148 Switches in center console ..31 Tachometer..27 Tail light bulbs - replacing ..121 Temperature gauge..27 Text window..30 Three-way catalytic converters..95, 96 Timing belt..133 Tire inflation..99 Tire inflation pressures tables..101 Tire Pressure Monitoring System (TPMS)..102 Tires..85, 98 - 109 Tires - changing..110, 111...
Page 227 2005 Volvo S80 Vanity mirror lights - replacing..122 Vehicle Identification Number (VIN)..144 Vehicle loading..148 Ventilation..46 Ventilation hose, battery ..139 Volumes (oils and fluids) ..147 Volvo On Call..150 Warning lights..28, 29 Warranty..130 Washer fluid reservoir..134 Washer fluid solvent..93 Washing the car..127 - 129 Water repellent glass..128...
Page 228 Additionally, your authorized Volvo retailer knows where accessories may and may not be safely installed in your Volvo. In all cases, please consult your authorized Volvo retailer before installing any accessory in or on your car.
Page 229 2005 Volvo S80 driving safely. Distraction can lead to a serious accident. In addition to this general warning, we offer the following guidance regarding specific newer features that may be found in your vehicles: Never use a hand-held cellular telephone while driving. Some jurisdictions prohibit cellular telephone use by a driver while the vehicle is moving.
Page 230 2005 Volvo S80 4 Engine oil level should be between the dipstick marks. The distance between the marks represents approx. 1.6 US qts (1.5 liters). See page 136. 5 Brake fluid - check, without removing the cap, that the level is above the MIN mark. Use brake fluid DOT 4+.

This manual is also suitable for:

2005 s80

Volvo S80 Operation Manual

Quick Links

Related Manuals for Volvo S80

Summary of Contents for Volvo S80

This manual is also suitable for:
