Optoma W415-M User Manual

Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
Table of contents .................................................................................... 1
Usage Notice .......................................................................................... 3
Safety Information ............................................................................. 3
Precautions ....................................................................................... 5
Eye Safety Warnings ......................................................................... 7
Introduction............................................................................................. 8
Package Overview ............................................................................ 8
Product Overview .............................................................................. 9
Main Unit ...................................................................................... 9
Connection Ports........................................................................ 10
Remote Control .......................................................................... 11
Installation ............................................................................................ 12
Connecting the Projector ................................................................. 12
Connect to Notebook ................................................................. 12
Connect to Video Sources ......................................................... 13
Powering On/Off the Projector ........................................................ 14
Powering On the Projector ......................................................... 14
Powering Off the Projector ......................................................... 15
Warning Indicator ....................................................................... 15
Adjusting the Projected Image ........................................................ 16
Adjusting the Projector's Height ................................................. 16
Adjusting the vertical image position .......................................... 16
Adjusting Projection Image Size (WXGA) .................................. 17
Adjusting Projection Image Size (1080p) ................................... 18
User Controls ....................................................................................... 19
Remote Control ............................................................................... 19
On-screen Display Menus ............................................................... 22
How to operate ........................................................................... 22
Menu Tree ....................................................................................... 23
Image ......................................................................................... 28
Image | Advanced ...................................................................... 30
Image | Advanced | Color Matching ........................................... 32
Image | Advanced | Signal ......................................................... 33
Display ....................................................................................... 34
Display | 3D ................................................................................ 36
Setup .......................................................................................... 37
Setup | Language ....................................................................... 39
Setup | Security .......................................................................... 40
Setup |Audio Settings ................................................................. 43
Setup | Advanced ....................................................................... 44
Setup | Network .......................................................................... 45
Setup | LAN Settings .................................................................. 46
Setup |Control Settings .............................................................. 47
Options ....................................................................................... 48

Table of contents

1

Advertisement

Table of Contents
loading

Related Manuals for Optoma W415-M

Summary of Contents for Optoma W415-M

  • Page 1: Table Of Contents

    Table of contents Table of contents ..................1 Usage Notice ..................3 Safety Information ................3 Precautions ..................5 Eye Safety Warnings ................. 7 Introduction..................... 8 Package Overview ................8 Product Overview ................9 Main Unit ..................9 Connection Ports................ 10 Remote Control ................
  • Page 2 RS232 Protocol Function List............. 80 Telnet Commands ................98 AMX Device Discovery commands ..........98 PJLink™ supported commands ............99 Trademarks ................... 101 Ceiling Mount Installation .............. 103 Optoma Global Offices ..............104 Regulation & Safety Notices ............106 Ver.: 1...

  • Page 3: Usage Notice

    Usage Notice Usage Notice Safety Information The lightning flash with arrow head within an equilateral triangle is intended to alert the user to the presence of uninsulated “dangerous voltage” within the product’s enclosure that may be of sufficient magnitude to constitute a risk of electric shock to persons.
  • Page 4 Do not attempt to service the unit yourself. Opening or removing covers may expose you to dangerous voltages or other hazards. Please call Optoma before you send the unit for repair. 7. Do not let objects or liquids enter the projector. They may touch dangerous voltage points and short out parts that could result in fire or electric shock.

  • Page 5: Precautions

    Usage Notice Precautions Please follow all warnings, precautions and maintenance as recommended in this user’s guide. ▀■ Warning- Do not look into the projector's lens when the lamp is on. The bright light may hurt your eyes. ▀■ Warning- To reduce the risk of fire or electric shock, do not expose this projector to rain or moisture.
  • Page 6 Usage Notice Turn off and unplug the power plug from the AC outlet ▀■ before cleaning the product. Use a soft dry cloth with mild detergent to clean the ▀■ display housing. Disconnect the power plug from AC outlet if the ▀■...

  • Page 7: Eye Safety Warnings

    Usage Notice Eye Safety Warnings ▀■ Avoid staring/facing directly into the projector beam at all times. Keep your back to the beam as much as possible. ▀■ When projector is used in a classroom, adequately supervise students when they are asked to point out something on the screen.

  • Page 8: Introduction

    Introduction Introduction Package Overview Unpack and inspect the box contents to ensure all parts listed below are in the box. If something is missing, please contact Optoma customer service. Projector with lens Power Cord 1.8m 15 pin D-sub VGA Cable...

  • Page 9: Product Overview

    Introduction Product Overview Main Unit IR Receiver Tilt-Adjustment Feet Lens Cap Function Keys LED Indicators Power Button LENS SHIFT Zoom Focus 10. Lens 11. Connection Ports...

  • Page 10: Connection Ports

    Introduction Connection Ports 15 14 13 12 11 Power Socket VGA2-IN/YPbPr VGA1-IN/YPbPr/ SERVICE VGA-OUT RS-232C DisplayPort HDMI RJ-45 10. Kensington Microsaver Lock Port 11. VIDEO 12. AUDIO2-IN (L and R) 13. S-Video 14. AUDIO1 IN 15. AUDIO OUT 16. 12V OUT...

  • Page 11: Remote Control

    Introduction Remote Control 1. Power On 2. Test Pattern 3. Function 1 (Assignable) 4. Display mode / Mouse Left Key 5. Four Directional Select CAUTION Keys Use of controls, 6. Enter adjustments or performance 7. Information Panel of procedures 8. Source other than those 9.

  • Page 12: Installation

    Installation Installation Connecting the Projector Connect to Notebook VGA, DVI, HDMI Due to the difference in applications for each country, some regions may have different accessories. E62405SP 1..............VGA Input Cable 2......... DVI/HDMI Cable (Optional Accessory) 3........HDMI Cable (Optional Accessory) 4................

  • Page 13: Connect To Video Sources

    Installation Connect to Video Sources DVD player, Set-top Box HDTV receiver DVD player, Set-top Box HDTV receiver Due to the difference in applications for each country, some regions may have different accessories. E62405SP 12V OUT is a programmable trigger. S-Video Output Video Output 1....SCART RGB/S-Video Adapter (Optional Accessory) 2........

  • Page 14: Powering On/Off The Projector

    Installation Powering On/Off the Projector Powering On the Projector 1. Remove the lens cover. 2. Connect the power cord to the projector. 3. Turn On the connected devices. 4. Ensure the Power LED is flashing and then press the Turn on the power button to turn On the projector.

  • Page 15: Powering Off The Projector

    Installation Powering Off the Projector 1. Press the " " button on the remote control or "POWER" button on the panel of the projector to turn off the projector. First push of button will display the following message on the screen.

  • Page 16: Adjusting The Projected Image

    Installation Adjusting the Projected Image Adjusting the Projector’s Height The projector is equipped with tilt-adjuster feet for adjusting the image height. To adjust the angle of the picture, turn the tilt-adjuster right • The projector or left until the desired angle has been achieved. table or stand should be level and...

  • Page 17: Adjusting Projection Image Size (Wxga)

    Installation Adjusting Projection Image Size (WXGA) Keystone Correction Angle Projection Distance Screen Size W X H (16:10) Projection distance (D) Diagonal Offset (A) length (inch) size (feet) (feet) of 16:10 Screen Width Height Width Height wide tele wide tele (feet) 0.65 0.40 2.12...

  • Page 18: Adjusting Projection Image Size (1080P)

    Installation Adjusting Projection Image Size (1080p) Keystone Correction Angle Projection Distance Screen Size W X H (16:9) Projection distance (D) Diagonal Offset (A) length (inch) size (feet) (feet) of 16:9 Screen Width Height Width Height wide tele wide tele (feet) 0.66 0.37 2.18...

  • Page 19: User Controls

    User Controls User Controls Remote Control Using the Remote Control Refer to the “Powering Off the Projector” on page 15. Power On/Off Refer to the “Powering On the Projector” on page 14. Test Pattern Refer to the “Test Pattern” on page 49. When connecting your PC to the projector through USB, press “Mouse Switch”...
  • Page 20 User Controls Using the Remote Control Volume +/- Press “Volume +/-” to adjust volume. V Keystone Adjusts image distortion caused by tilting the projector. (±30 degrees) Format Refer to the “Format” on page 34. Zoom Press “Zoom” to zoom out images. Press until Power LED is flashing then press Remote ID 01~99 to set the particular remote code.
  • Page 21 User Controls The remote control number must match the projector number for accurate control; To set the Remote Control Number: Press‘Remote ID’ until the LED above the Power Off button in the top-right of the remote control starts to flash, then input the desired remote control number (between 01-99) while the light is flashing.

  • Page 22: On-Screen Display Menus

    User Controls On-screen Display Menus The Projector has multilingual On-screen Display menus that allow you to make image adjustments and change a variety of settings. The projector will automatically detect the source. How to operate 1. To open the OSD menu, press “Menu” on the Remote Control or Control Panel.

  • Page 23: Menu Tree

    User Controls Menu Tree Main Advanced Sub menu Settings menu menu Image Display Presentation / Bright / Movie / sRGB / Mode Blackboard / DICOM SIM. / User / 3D Brightness -50~50 Contrast -50~50 Sharpness 1~15 #Color -50~50 #Tint -50~50 Advanced Noise Reduction...
  • Page 24 User Controls Main Advanced Sub menu Settings menu menu Display Format WXGA 4:3, 16:9 or 16:10, Native, Auto 1080P 4:3, 16:9, LBX , Native, Auto Zoom -5~25 Edge Mask 0~10 Image Shift H -100~+100 -100 ~ +100 V Keystone -40 ~ +40 3D Mode DLP-Link / IR 3D→2D...
  • Page 25 Speaker Mute On / Off Volume 0~10 Audio Input Default / Audio1 / Audio2 Exit Advanced Logo Optoma / Neutral / User Logo Capture Closed Off / CC1 / CC2 Captioning Exit Network LAN Settings Network Status DHCP IP Address...
  • Page 26 User Controls Main Advanced Sub menu Settings menu menu Options Input VGA1 / VGA2 / Video / S-Video / HDMI / Source DisplayPort / Exit Source On / Off Lock High On / Off Altitude Information On / Off Hide Keypad On / Off Lock...
  • Page 27 User Controls Main Advanced Sub menu Settings menu menu Advanced Direct Power On / Off Signal Power On / Off Auto Power Off (min.) Sleep Timer (min.) Quick Resume On / Off Power Mode Active / ECO (Standby) OSD Time-Out 5 sec. / 15 sec. / 30 sec. / 60 sec. / Never Exit Lamp...

  • Page 28: Image

    User Controls Image Display Mode There are many factory presets optimized for various types of images. Presentation: Good color and brightness from PC input.  Bright: Maximum brightness from PC input.  Movie: For home theater.  sRGB: Standardised accurate color. ...
  • Page 29 User Controls Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Press ◄ to decrease the contrast.  Press ► to increase the contrast.  Sharpness Adjusts the sharpness of the image. Press ◄...

  • Page 30: Image | Advanced

    User Controls Image | Advanced Noise Reduction The motion Adaptive Noise Reduction reduces the amount of visible noise in interlaced signals. The range is from “0” to “10”. (0=Off) BrilliantColor™ This adjustable item utilizes a new color-processing algorithm and system level enhancements to enable higher brightness while providing true, more vibrant colors in picture.
  • Page 31 User Controls Color Matching Enter the Color Matching menu. See page 32 for more details. Signal Enter the Signal menu. Set projector signal properties. The function is available when input source is support VGA 1/ VGA 2. See page 33 for more information.

  • Page 32: Image | Advanced | Color Matching

    User Controls Image | Advanced | Color Matching Colors (Except White) Press ▲▼ to select a color and press “ENTER” to adjust the hue, saturation, and gain settings. Press ▲▼ to select Hue, Saturation, or Gain and press ◄► to adjust the settings. •...

  • Page 33: Image | Advanced | Signal

    User Controls Image | Advanced | Signal Automatic Set Automatic to On or Off to lock or unlock the Phase and Frequency features. Disable—Off auto lock.  Enable—On auto lock.  Frequency Change the display data frequency to match the frequency of your computer’s graphics card.

  • Page 34: Display

    User Controls Display Format Use this function to choose your desired aspect ratio. 4:3: This format is for 4x3 input sources not enhanced for  Wide screen TV. 16:9/16:10: This format is for 16x9 input sources, like  HDTV and DVD enhanced for Wide screen TV. LBX: This format is for non-16x9, letterbox source and ...
  • Page 35 User Controls Zoom Press ◄ to reduce the size of the image.  Press ► to magnify an image on the projected screen.  Edge Mask Edge Mask function removes the noise in a video image. Edge Mask the image to remove video encoding noise on the edge of video source.

  • Page 36: Display | 3D

    User Controls Display | 3D 3D Mode DLP Link: Select DLP Link to use optimized settings for  DLP Link 3D Glasses. IR: Select IR to use optimized settings for IR-based 3D  images. 3D2D Press ◄ or ► to select projector display 3D content in 2D (Left) or 2D(Right) without using 3D glasses to enjoy 3D content.

  • Page 37: Setup

    User Controls Setup Language Enter the Language menu. Select the multilingual OSD menu. See page 39 for more information. Projection Select projection method: Front Desktop  The factory default setting. Rear Desktop  When you select this function, the projector reverses the image so you can project from behind a translucent screen.
  • Page 38 User Controls Menu Location Choose the menu location on the display screen. Screen Type Press ◄► to set the aspect ratio to 16:9 or 16:10. This function is only available for WXGA. Security Enter the Security menu. Access the projector’s security features.

  • Page 39: Setup | Language

    User Controls Setup | Language Language Choose the multilingual OSD menu. Press “ENTER” into the sub menu and then use the Left (◄) or Right (►) key to select your preferred language.

  • Page 40: Setup | Security

    User Controls Setup | Security Security Setting Enable or disable the security password. On—the current password is required to power on the  projector and access the Security menu. Off—no password is required after system power up.  When security is enabled, the following screen displays at startup and before access to the Security menu is allowed: The default password: 1, 2, 3,...
  • Page 41 User Controls Security Timer Enter the Security Timer sub menu. Enter the Months, Days, and hours that the projector can be used without entering the password. Exiting to the Setup menu activates the Security Timer. Once activated, the projector requires a password on the specified dates and times to allow power on and access to the security menu.
  • Page 42 User Controls Change Password Use this submenu to change the security password for the projector. 1. Select Change Password from the Security submenu. The Confirm Change Password dialog box displays. 2. Select Yes. If the incorrect password is entered three 3.

  • Page 43: Setup |Audio Settings

    User Controls Setup | Audio Settings Internal Speaker Off—turn off the internal speaker.  On–turn on the internal speaker.  Mute Toggle the audio on or off. Off—the speaker volume and audio out are turned on.  On–the speaker volume and audio out are turned off. ...

  • Page 44: Setup | Advanced

    User Controls Setup | Advanced Logo Select the screen to display during startup. Optoma—the supplied default startup screen.  Neutral— is Background Color.  User—customized screen capture using the Logo  Capture function. Logo Capture Capture a displayed screen to use as the startup screen.

  • Page 45: Setup | Network

    User Controls Setup | Network LAN Settings Enter the LAN Settings menu. See page 46 for more information. Control Settings Enter the Control Settings menu. See page 47 for more information.

  • Page 46: Setup | Lan Settings

    User Controls Setup | LAN Settings If the connection is successful, the OSD display will show the following dialogue box. Network State—to display network information.  DHCP:  On: Assign an IP address to the projector from the DHCP server automatically. Off: Assign an IP address manually.

  • Page 47: Setup |Control Settings

    User Controls Setup | Control Settings Crestron Press ◄► to check to enable/disable Crestron. Extron Press ◄► to check to enable/disable Extron. PJ Link Press ◄► to check to enable/disable PJ Link. AMX Device Discovery Press ◄► to check to enable/disable AMX Device Discovery.

  • Page 48: Options

    User Controls Options Input Source Enter the Input Source submenu. Select the sources to scan for at startup. See page 51 for more information. Source Lock Lock the current source as the only available source, even if the cable is unplugged. On—only the current source is recognized as an input ...
  • Page 49 User Controls Keypad Lock Lock the buttons on the projector top panel. On—a warning message displays to confirm keypad lock.  Off—projector keypad functions as normal.  Test Pattern Hold "ENTER" key Display a test pattern. There are Grid, White and None. on keypad for 10 Background Color seconds to unlock...
  • Page 50 User Controls Advanced Enter the Advanced menu. See pages 53-54 for more details. Lamp Setting Enter the Lamp Setting menu. See pages 55-56 for more details. Information Show the projector information. Reset Reset all Options to default factory settings.

  • Page 51: Options |Input Source

    User Controls Options | Input Source Input Source Use this option to enable / disable input sources. Press ▲ or ▼ to select a source, then press ◄ or ► to enable / disable it. Press “ENTER” to finalize the selection. The If all sources are projector will not search inputs that are de-selected.

  • Page 52: Options |Remote Settings

    User Controls Options | Remote Settings Function 1 Set F1 key as a hotkey for Brightness, Contrast, Color Matching, Color Temp. or Gamma function. Function 2 Set F2 key as a hotkey for Source Lock, Projection, Lamp Settings, Mute, Zoom or Volume function. IR Function Enable or Disable projector’s IR function.

  • Page 53: Options | Advanced

    User Controls Options | Advanced Direct Power On Enable or disable Direct Power On. On—the projector powers on automatically when AC  power is supplied. Off— the projector must be powered on as normal.  Signal Power On Enable or disable Signal Power On. On—the projector powers on automatically when an ...
  • Page 54 User Controls Auto Power Off (min) Set the Auto Power Off interval. The projector powers off the lamp after 30 minutes of no signal by default. The following warning is displayed 60 seconds before power off. Sleep Timer (min) Set the Sleep Timer interval. The projector powers off after the specified time period of inactivity (regardless of signal).

  • Page 55: Options |Lamp Setting

    User Controls Options | Lamp Setting Lamp Hour Displays the number of hours the lamp has been active. This item is for display only. Lamp Reminder Enable or disable the lamp life span reminder. On—a warning message displays when remaining lamp ...
  • Page 56 User Controls DynamicBlack Select the DynamicBlack mode. Lamp Reset After replacing the lamp, reset the lamp counter to accurately reflect the new lamp’s life span. 1. Select Lamp Reset. A confirmation screen displays. When DynamicBlack is On, and 2. Select Yes to reset the lamp counter to zero. Brightness Mode is set to Bright, the Dynamic range is...

  • Page 57: Lan_Rj45

    User Controls LAN_RJ45 For simplicity and ease of operation, the Optoma projector provides diverse networking and remote management features. • Projector connects to The LAN/RJ45 function of the projector through a network, LAN, please such as remotely manage: Power On/Off, Brightness and use Ethernet Contrast settings.
  • Page 58 User Controls This projector is compliant to support Extron device(s) for reference. http://www.extron.com/ This projector is supported by AMX ( Device Discovery ). http://www.amx.com/ This projector supports all commands of PJLink Class1 (Version 1.00). http://pjlink.jbmia.or.jp/english/ For more detail of information about the diverse types of external devices which can be connected to the LAN/RJ45 port and remote/control the projector, as well as the related control commands supporting for each external device,...
  • Page 59 User Controls 2. On the PC (Laptop), select Start -> Control Panel-> Network Connections. 3. Right Click on your Local Area Connection, and select Property. 4. In the Properties window, select the General tab, and select Internet Protocol (TCP/IP).
  • Page 60 User Controls 5. Click Properties. 6. Fill in the IP address and Subnet mask, then press OK. 7. Press the Menu button on the projector. 8. Select OSD-> SETUP-> Network Settings-> Lan Settings. 9. After getting into Network Status, input the following: DHCP: Off ...
  • Page 61 User Controls 11. Open a web browser (ex, Microsoft Internet Explorer with Adobe Flash Player 9.0 or higher). For more information, please visit http://www. crestron.com 12. In the Address bar, input the IP address: 10.10.10.10. 13. Press “ENTER” / ►. The projector is setup for remote management.
  • Page 62 User Controls Category Item Input-Length IP Address Crestron Control IP ID Port Projector Name Projector Location Assigned To DHCP (Enabled) (N/A) IP Address Network Configuration Subnet Mask Default Gateway DNS Server Enabled (N/A) User Password New Password Confirm Enabled (N/A) Admin Password New Password Confirm...
  • Page 63 User Controls Preparing Email Alerts 1. Make sure that user can access the homepage of LAN RJ45 function by web browser (for ex-ample, Microsoft Internet Explorer v6.01/v8.0). 2. From the Homepage of LAN/RJ45, click Alert Settings. 3. By default, these input boxes in Alert Settings are blank.
  • Page 64 User Controls 4. For Sending alert mail, input the following: The SMTP field is the mail server for sending out email  (SMTP protocol). This is a required field. The To field is the recipient’s email address (for example,  the projector administrator).
  • Page 65 User Controls Quick Start-Guide for “RS232 by TELNET” Check and get the IP-Address on OSD of the projector. Make sure that laptop/PC can access the web-page of the projector. Make sure that “Windows Firewall” setting to be disabled in case of “TELNET” function filtering out by laptop/PC. 1.
  • Page 66 User Controls How to have TELNET enabled in Windows VISTA / 7 By default installation for Windows VISTA, “TELNET” function is not included. But end-user can have it by way of “Turn Windows features On or Off” to be enabled. 1.
  • Page 67 User Controls 4. Have “Telnet Client” option checked, then press “OK” button. Specsheet for “RS232 by TELNET” : 1. Telnet: TCP. 2. Telnet port: 23 (for more detail, kindly please get contact with the service agent or team). 3. Telnet utility: Windows “TELNET.exe” (console mode). 4.

  • Page 68: Appendices

    Appendices Appendices Troubleshooting If you experience a problem with your projector, please refer to the following information. If a problem persists, please contact your local reseller or service center. Image No image appears on-screen Ensure all the cables and power connections are correctly ...

  • Page 69: Other

    Appendices Image is too small or too large Image is too small or too large Adjust the zoom lever from the lens.  Move the projector closer to or further from the screen.  Press [Menu] on the projector panel, go to “Display-> ...

  • Page 70: Projector Led Status Indicator

    Appendices Projector LED Status Indicator Lamp Power LED Temp LED Message (Red) (Green) (Red) Slow Flashing Standby State (Input 2 sec off power cord) 2 sec on Flashing Power on (Warming) 0.5 sec off 0.5 sec on Steady light => Power on &...

  • Page 71: Remote Control

    Appendices LED states On Screen Messages Fan failed:  The projector will switch off automatically. Over temperature:  The projector will switch off automatically. Replacing the lamp:  Lamp is approaching the end of its rated life. Replacement suggested. Remote Control If the remote control does not work Warning: Check the operating angle of the remote control is within...

  • Page 72: Replacing The Lamp

    Appendices Replacing the Lamp The projector automatically detects the lamp life. When the lamp life is nearing the end of use, you will receive a warning message. When you see this message, please contact your local reseller or service center to change the lamp as soon as possible.
  • Page 73 Appendices...
  • Page 74 Appendices Lamp Replacing Procedure: 1. Switch off the power to the projector by pressing the Power button. 2. Allow the projector to cool down at least 30 minutes. 3. Disconnect the power cord. 4. Remove the single screw on the lamp compartment cover. 5.

  • Page 75: Compatibility Modes

    Appendices Compatibility Modes Video Compatibility NTSC NTSC M/J, 3.58MHz, 4.43MHz PAL B/D/G/H/I/M/N, 4.43MHz SECAM SECAM B/D/G/K/K1/L, 4.25/4.4 MHz SDTV 480i/p, 576i/p HDTV 720p(50/60Hz), 1080i(50/60Hz), 1080P(50/60Hz) Video Timing Detail Describe Refresh Signal Resolution Notes Rate(Hz) TV(NTSC) 720 x 480 For Composite Video /S-video TV(PAL, 720 x 576...

  • Page 76: Computer Compatibility - Vesa Standards

    Appendices Computer Compatibility - VESA standards Computer Signal (Analog RGB Compatible Refresh Signal Resolution Notes Rate(Hz) 640 X 480 60/67/72/85 Mac 60/72/85/ SVGA 800 X 600 56/60 (*2)/72/ Mac 60/72/85 85/120 (*2) 1024 X768 48/50(*4)/ 60 (*2)/70/75/ 60/70/75/85 85/120 (*2) HDTV 1280 x 720 50/60 (*2)/...

  • Page 77: Input Signal For Hdmi/Dvi-D

    Appendices Input Signal for HDMI/DVI-D Refresh Signal Resolution Notes Rate(Hz) 640 x 480 Mac 60/72/85 SVGA 800 x 600 60(*2)/72/ Mac 60/72/85 85/120(*2) 1024 x 768 48/50 60(*2)/70/75/ 60/70/75/85 85/120(*2) SDTV (480i) 720 x 480 SDTV (480p) 720 x 480 SDTV (576i) 720 x 576 SDTV (576p)

  • Page 78: True 3D Video Compatibility Table

    Appendices True 3D Video Compatibility table Input Input timing Resolutions HDMI 1.4a 1280 x 720p @50Hz Top-and–Bottom 3D Input 1280 x 720p @60Hz Top-and–Bottom 1280 x 720p @50Hz Frame packing 1280 x 720p @60Hz Frame packing 1920 x 1080i @50Hz Side-by-Side (Half) 1920 x 1080i @60Hz Side-by-Side (Half)

  • Page 79: Rs232 Commands And Protocol Function List

    Appendices RS232 Commands and Protocol Function List RS232 Pin Assignments (projector side) Name I/O (From Projector Side) RS232 RS232...

  • Page 80: Rs232 Protocol Function List

    Appendices RS232 Protocol Function List SEND to projector 232 ASCII Code HEX Code Function Description ~XX00 1 7E 30 30 30 30 20 31 0D Power ON ~XX00 0 7E 30 30 30 30 20 30 0D Power OFF (0/2 for backward compatible) ~XX00 1 ~nnnnn 7E 30 30 30 30 20 31 20 a 0D Power ON with...
  • Page 81 Appendices 232 ASCII Code HEX Code Function Description ~XX12 1 7E 30 30 31 32 20 31 0D Direct Source HDMI Commands ~XX12 5 7E 30 30 31 32 20 35 0D VGA1 ~XX12 6 7E 30 30 31 32 20 36 0D VGA 2 ~XX12 9 7E 30 30 31 32 20 39 0D...
  • Page 82 Appendices 232 ASCII Code HEX Code Function Description ~XX21 n 7E 30 30 32 31 20 a 0D Brightness n = -50 (a=2D 35 30) ~ 50 (a=35 30) ~XX22 n 7E 30 30 32 32 20 a 0D Contrast n = -50 (a=2D 35 30) ~ 50 (a=35 30) ~XX23 n 7E 30 30 32 33 20 a 0D...
  • Page 83 Appendices 232 ASCII Code HEX Code Function Description ~XX338 n 7E 58 58 33 33 38 20 a 0D Magenta Saturationn n = -50 (a=2D 35 30) ~ 50 (a=35 30) ~XX339 n 7E 58 58 33 33 39 20 a 0D Red Gain n = -50 (a=2D 35 30) ~ 50 (a=35 30) ~XX340 n...
  • Page 84 Appendices 232 ASCII Code HEX Code Function Description ~XX35 4 7E 30 30 33 35 20 34 0D Standard ~XX36 3 7E 30 30 33 36 20 30 0D Color Temp. Warm ~XX36 0 7E 30 30 33 36 20 31 0D Standard ~XX36 1 7E 30 30 33 36 20 32 0D...
  • Page 85 Appendices 232 ASCII Code HEX Code Function Description ~XX76 n 7E 30 30 37 36 20 a 0D V. Position n = -5 (a=2D 35) ~ 5 (a=35) By timing ~XX45 n 7E 30 30 34 34 20 a 0D Color (Saturation) n = -50 (a=2D 35 30) ~ 50 (a=35 30) ~XX44 n 7E 30 30 34 35 20 a 0D...
  • Page 86 Appendices 232 ASCII Code HEX Code Function Description ~XX230 1 7E 30 30 32 33 30 20 31 0D 3D Mode DLP-Link ~XX230 3 7E 30 30 32 33 30 20 31 0D 3D Mode ~XX400 0 7E 30 30 34 30 30 20 30 0D 3D→2D ~XX400 1 7E 30 30 34 30 30 20 31 0D...
  • Page 87 Appendices 232 ASCII Code HEX Code Function Description ~XX70 4 7E 30 30 37 30 20 34 0D Italian ~XX70 5 7E 30 30 37 30 20 35 0D Spanish ~XX70 6 7E 30 30 37 30 20 36 0D Portuguese ~XX70 7 7E 30 30 37 30 20 37 0D...
  • Page 88 Appendices 232 ASCII Code HEX Code Function Description ~XX70 18 7E 30 30 37 30 20 31 38 0D Hungarian ~XX70 19 7E 30 30 37 30 20 31 39 0D Czechoslovak ~XX70 20 7E 30 30 37 30 20 32 30 0D Arabic ~XX70 21 7E 30 30 37 30 20 32 31 0D...
  • Page 89 Appendices 232 ASCII Code HEX Code Function Description ~XX72 2 7E 30 30 37 32 20 32 0D Top Right ~XX72 3 7E 30 30 37 32 20 33 0D Centre ~XX72 4 7E 30 30 37 32 20 34 0D Bottom Left ~XX72 5 7E 30 30 37 32 20 35 0D...
  • Page 90 Appendices 232 ASCII Code HEX Code Function Description ~XX79 n 7E 30 30 37 39 20 a 0D Projector ID n = 00 (a=30 30) ~ 99 (a=39 39) ~XX80 1 7E 30 30 38 30 20 31 0D Mute ~XX80 0 7E 30 30 38 30 20 30 0D Off (0/2 for backward compatible)
  • Page 91 Appendices 232 ASCII Code HEX Code Function Description ~XX88 1 7E 30 30 38 38 20 31 0D ~XX88 2 7E 30 30 38 38 20 32 0D ~XX454 0 7E 30 30 34 35 34 20 30 0D Crestron ~XX454 1 7E 30 30 34 35 34 20 31 0D ~XX455 0...
  • Page 92 Appendices 232 ASCII Code HEX Code Function Description ~XX101 1 7E 30 30 31 30 31 20 31 0D High Altitude ~XX101 0 7E 30 30 31 30 31 20 30 0D Off (0/2 for backward compatible) ~XX102 1 7E 30 30 31 30 32 20 31 0D Information Hide ~XX102 0 7E 30 30 31 30 32 20 30 0D...
  • Page 93 Appendices 232 ASCII Code HEX Code Function Description ~XX104 1 7E 30 30 31 30 34 20 31 0D Background Color Blue ~XX104 2 7E 30 30 31 30 34 20 32 0D Black ~XX104 3 7E 30 30 31 30 34 20 33 0D ~XX104 4 7E 30 30 31 30 34 20 34 0D Green...
  • Page 94 Appendices 232 ASCII Code HEX Code Function Description ~XX114 1 7E 30 30 31 31 34 20 31 0D Power Mode(Standby) Eco.(<=0.5W) ~XX114 0 7E 30 30 31 31 34 20 30 0D Active (0/2 for backward compatible) ~XX109 1 7E 30 30 31 30 39 20 31 0D Lamp Reminder ~XX109 0...
  • Page 95 Appendices SEND to emulate Remote 232 ASCII Code HEX Code Function Description ~XX140 10 7E 30 30 31 34 30 20 31 30 0D ~XX140 11 7E 30 30 31 34 30 20 31 31 0D Left ~XX140 12 7E 30 30 31 34 30 20 31 32 0D Enter (for projection MENU) ~XX140 13 7E 30 30 31 34 30 20 31 33 0D...
  • Page 96 Appendices SEND from projector automatically 232 ASCII Code HEX Code Function Projector Return Description when Standby/ INFOn n : 0/1/2/3/4/6/7/8/ = Warming/Cooling/ Standby/Warming/ Out of Range/Lamp Cooling/Out of Range/ fail/Fan Lock/Over Lamp fail/Fan Lock/Over Temperature/ Lamp Temperature/Lamp Hours Hours Running Out/ Running Out/Cover Open Cover Open READ from projector...
  • Page 97 Appendices 232 ASCII Code HEX Code Function Projector Return Description ~XX128 1 7E 30 30 31 32 38 20 31 0D Color Temperature n :3/0/1/2 = Warm/ Standard/Cool/Cold ~XX129 1 7E 30 30 31 32 39 20 31 0D Projection Mode n : 0/1/2/3 = Front- Desktop/ Rear-esktop/ Front-Ceiling/ Rear-Ceiling...

  • Page 98: Telnet Commands

    Command ID Space Variable Code Return      Defined by code Optoma 2 or 3 Per item Fix code One Digit. See the Digit Definition Digit Digit~ Follow content • For wide screen resolution (WXGA), the compatibility support is dependent on Notebook/PC models.

  • Page 99: Pjlink™ Supported Commands

    Appendices Remark Command Description (Parameter) Config-URL Device’s IP address http://xxx.xxx.xxx. xxx/index.html LAN IP address is shown up if LAN IP address is valid. Wireless LAN IP address is shown up if Wireless LAN IP address is valid. Revision The revision must follow a 1.0.0 major.minor.micro scheme.
  • Page 100 Appendices Command Description Remark (Parameter) INPT INPT Input 11 = VGA1 switching INPT? Inquiry about 12 = VGA2 input switching 13 = Component 14 = BNC 21 = VIDEO 22 = S-VIDEO 31 = HDMI 1 32 = HDMI 2 AVMT Mute control 30 = Video and audio mute...

  • Page 101: Trademarks

    The projector name set on projector name the NETWORK menu or the ProjectorView Setup window is returned INF1? Inquiry about the manufacturer “Optoma” is returned. name INF2? Inquiry about the “EH7700” is returned. model name INF0? Inquiry about No other information is other information available.
  • Page 102 Appendices Crestron RoomView Connected™  The projector is monitored and controlled by the control system and software of Crestron Electronics, Inc. PJLink™  PJLink trademark is a trademark applied for registration or is already registered in Japan, the United States of America and other countries and areas.

  • Page 103: Ceiling Mount Installation

    Appendices Ceiling Mount Installation 1. To prevent damage to your projector, please use the Optoma ceiling mount. 2. If you wish to use a third party ceiling mount kit, please ensure the screws used to attached a mount to the...

  • Page 104: Optoma Global Offices

    Appendices Optoma Global Offices For service or support please contact your local office. 3178 Laurelview Ct., Tel : 888-289-6786 Fremont, CA 94538, USA www.optomausa.com Service : services@optoma.com Canada 2420 Meadowpine Blvd., Suite #105, Tel : 888-289-6786 Mississauga, ON, L5N 6S2, Canada Fax : 510-897-8601 www.optoma.ca...
  • Page 105 Appendices Scandinavia Lerpeveien 25 Tel : +47 32 98 89 90 3040 Drammen FAX : +47 32 98 89 99 Norway Service : info@optoma.no PO.BOX 9515 3038 Drammen Norway Latin America 3178 Laurelview Ct. Tel : 888-289-6786 Fremont, CA 94538, USA Fax: 510-897-8601 www.optoma.com.br...

  • Page 106: Regulation & Safety Notices

    Appendices Regulation & Safety Notices This appendix lists the general notices of your Projector. FCC notice This device has been tested and found to comply with the limits for a Class B digital device pursuant to Part 15 of the FCC rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation.

  • Page 107: Operation Conditions

    Appendices Operation conditions This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: 1. This device may not cause harmful interference and 2. This device must accept any interference received, including interference that may cause undesired operation.
