Aiwa HV-GX950 K Service Manual

Video cassette recorder
Hide thumbs Also See for HV-GX950 K:
Table of Contents

Advertisement

Quick Links

SERVICE MANUAL
VIDEO CASSETTE RECORDER
POWER REQUIREMENTS .................
POWER CONSUMPTION ...................
WEIGHT ..............................................
DIMENSIONS ......................................
OPERATING TEMPERATURE ...........
VIDEO RECORDING SYSTEM ..........
VIDEO SIGNAL SYSTEM ...................
VIDEO HEAD ......................................
USABLE CASSETTES ........................
CHANNEL COVERAGE ......................
RF OUTPUT ........................................
HORIZONTAL RESOLUTION ............
TIMER BACKUP .................................
TUNER SYSTEM ................................
TV SYSTEM ........................................
HV-GX950
HV-GX900
BASIC TAPE MECHANISM : OVD-6
SPECIFICATIONS
230 V AC, 50 Hz
14W
3.5 kg (7.7 lbs.)
380 mm (W) x 267 mm (D) x
95 mm (H)
(15 x 10 5/8 x 3 3/4 in.)
5°C to 40°C
Rotary 2 head helical scanning
system
PAL colour system, 625 lines,
50 fields
Azimuth 2 heads
VHS video cassette
UHF: 21 to 69
UHF channels between 23 and
69, 73 dBµ
240 lines
30 minutes
Frequency synthesized tuner
I
S/M Code No. 09-975-331-5N1
TAPE SPEED ...................................
RECORDING/PLAYBACK TIME .....
VIDEO INPUT ...................................
VIDEO OUTPUT ..............................
VIDEO S/N .......................................
AUDIO INPUT ..................................
AUDIO OUTPUT ..............................
AUDIO TRACK .................................
FAST-FORWARD TIME ...................
REWIND TIME .................................
•
Design and specifications are subject to change without
notice.
K
K
PAL
SP: 23.39 mm/sec
LP: 11.69 mm/sec
NTSC (playback only)
SP: 33.35 mm/sec
PAL
SP: 5 hours with E-300 tape
LP: 10 hours with E-300 tape
NTSC (playback only)
SP: 3 hours 30 minutes with
T-210 tape
1.0 Vp-p, 75 ohm, unbalanced
1.0 Vp-p, 75 ohm, unbalanced
53 dB (nominal)
–3.8dBs, 50K ohm
–3.8dBs, less than 1 Kohm
1 track (Mono)
135 seconds with E-180 tape
108 seconds with E-180 tape

Advertisement

Table of Contents
loading

Related Manuals for Aiwa HV-GX950 K

Summary of Contents for Aiwa HV-GX950 K

  • Page 1 HV-GX950 HV-GX900 SERVICE MANUAL VIDEO CASSETTE RECORDER BASIC TAPE MECHANISM : OVD-6 SPECIFICATIONS POWER REQUIREMENTS ....230 V AC, 50 Hz TAPE SPEED ........SP: 23.39 mm/sec POWER CONSUMPTION ....LP: 11.69 mm/sec 3.5 kg (7.7 lbs.) NTSC (playback only) WEIGHT ..........

  • Page 2: Table Of Contents

    TABLE OF CONTENTS SPECIFICATIONS ................................COVER TABLE OF CONTENTS ............................... SERVICING NOTICES ON CHECKING ..........................IMPORTANT NOTICE ................................DISASSEMBLY INSTRUCTIONS REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS .................... B1-1 REMOVAL OF DECK PARTS ............................B2-1~B2-5 KEY TO ABBREVIATIONS ..............................C1-1, C1-2 SERVICE MODE LIST .................................

  • Page 3: Servicing Notices On Checking

    SERVICING NOTICES ON CHECKING 1. KEEP THE NOTICES 3. PUT PARTS AND WIRES IN THE ORIGINAL POSITION AFTER ASSEMBLING OR WIRING As for the places which need special attentions, they are indicated with the labels or seals on the cabinet, chassis There are parts which use the insulation material such and parts.

  • Page 4: Disassembly Instructions

    DISASSEMBLY INSTRUCTIONS 1. REMOVAL OF MECHANICAL PARTS AND P.C. BOARDS 1-1: TOP CABINET, FRONT CABINET AND OPERATION 1, 2 PCB (Refer to Fig. 1-1) Deck Chassis Remove the 4 screws 1. Remove the Top Cabinet in the direction of arrow (A). Disconnect the following connectors: (CP651 and CP652).

  • Page 5: Removal Of Deck Parts

    DISASSEMBLY INSTRUCTIONS NOTE 2. REMOVAL OF DECK PARTS When you install the Tape Guide L, install as shown in the 2-1: TOP BRACKET (Refer to Fig. 2-1) circle of Fig. 2-3-B. (Refer to Fig. 2-3-B) Remove the 2 screws 1. Slide the 2 supports 2 and remove the Top Bracket.
  • Page 6 DISASSEMBLY INSTRUCTIONS 2-6: LINK ASS'Y (Refer to Fig. 2-6) 2-9: TENSION ASS'Y (Refer to Fig. 2-9-A) Set the Link Ass'y to the Eject position. Move the Inclined S Ass'y to the back side. Unlock the support 1 and remove the S Reel Stopper. Remove the (A) side of the Link Ass'y first, then remove the (B) side.
  • Page 7 DISASSEMBLY INSTRUCTIONS 2-11: S REEL/T REEL ASS'Y (Refer to Fig. 2-11) NOTE Remove the Idler Ass'y. Do not touch the Pinch Roller Ass'y. (Use gloves.) Remove the S Reel and T Reel Ass'y. When you install the Pinch Roller Ass'y, install as Remove the 2 Polyslider Washers 1.
  • Page 8 DISASSEMBLY INSTRUCTIONS 2-15: AHC ASS'Y/CYLINDER UNIT ASS'Y (Refer to Fig. 2-15) Middle Gear Unlock the support 1 and remove the AHC Ass'y. E-Ring Remove the 3 screws 2. Remove the Cylinder Unit Ass'y. Main Cam NOTE Pinch Roller Cam When you install the Cylinder Unit Ass'y, tighten the screws from (1) to (3) in order while pulling the Ass'y Joint Gear Link Lever Spacer...
  • Page 9 DISASSEMBLY INSTRUCTIONS 2-19: LOADING GEAR S/T ASS'Y (Refer to Fig. 2-19-A) 2-20: INCLINED S/T ASS'Y (Refer to Fig. 2-20) Remove the E-Ring 1 and remove the Main Loading Unlock the support 1 and remove the P4 Cover. Gear. Remove the S-S Brake Spring. Unlock the support 2 and remove the Loading Gear Remove the Capstan Brake Spring.

  • Page 10: Key To Abbreviations

    KEY TO ABBREVIATIONS Audio/Control H.SW Head Switch Automatic Color Control Hertz Audio Erase Integrated Circuit Automatic Frequency Control Intermediate Frequency Automatic Fine Tuning Indicator AFT DET Automatic Fine Tuning Detect Inverter Automatic Gain Control Killer Amplifier Left Antenna Light Emitting Diode A.PB Audio Playback LIMIT AMP...
  • Page 11 KEY TO ABBREVIATIONS SYNC Synchronization SYNC SEP Sync Separator, Separation Transistor TRAC Tracking TRICK PB Trick Playback Test Point UNREG Unregulated Volt Voltage Controlled Oscillator Video Intermediate Frequency Vertical Pulse, Voltage Display V.PB Video Playback Variable Resistor V.REC Video Recording Visual Search Fast Forward Visual Search Rewind Voltage Super Source...

  • Page 12: Service Mode List

    SERVICE MODE LIST This unit provided with the following SERVICE MODES so you can repair, examine and adjust easily. Method Operations Press both PLAY button and Initialization of the factory. CH UP button on the set for NOTE: Do not use this for the normal servicing. more than 2 seconds.

  • Page 13: Preventive Checks And Service Intervals

    PREVENTIVE CHECKS AND SERVICE INTERVALS The following standard table depends on environmental conditions and usage. Unless maintenance is properly carried out, the following service intervals may be quite shortened as harmful effects may be had on other parts. Also, long term storage or misuse may cause transformation and aging of rubber parts. Time 1,000 1,500...
  • Page 14 PREVENTIVE CHECKS AND SERVICE INTERVALS CLEANING NOTE 2. TAPE RUNNING SYSTEM After cleaning the heads with isopropyl alcohol, do not When cleaning the tape transport system, use the run a tape until the heads dry completely. If the heads gauze moistened with isopropyl alcohol. are not completely dry and alcohol gets on the tape, 3.

  • Page 15: Note For The Replacing Of Memory Ic

    NOTE FOR THE REPLACING OF MEMORY IC If a service repair is undertaken where it has been required to change the MEMORY IC, the following steps should be taken to ensure correct data settings while making reference to TABLE 1. Turn on the POWER and press both FF key and CH UP key on the set for more than 2 seconds.

  • Page 16: Servicing Fixtures And Tools

    SERVICING FIXTURES AND TOOLS (For 1 speed model) (For 2 speed model) JG002B Adapter JG005 Post Adjustment VHS Alignment Tape VHS Alignment Tape JG002E Dial Torque Gauge Screwdriver JG001E (TTV-P2) JG001C (TTV-P2) (10~90gf•cm) Part No. SV-TG0-030-000 JG001F (TTV-P1L) JG001D (TTV-P1L) JG002F (60~600gf•cm) (small)

  • Page 17: Vcr Test Tape Interchangeability Table

    VCR TEST TAPE INTERCHANGEABILITY TABLE There are two types of the new alignment tape CH-1B (for NTSC) and CH-2 (for PAL). On each tape four signals (1) - (4) are recorded for the times and in the order shown below. (1) : 8min.

  • Page 18: Mechanical Adjustments

    MECHANICAL ADJUSTMENTS 1-2: CONFIRMATION AND ADJUSTMENT OF TENSION 1. CONFIRMATION AND ADJUSTMENT POST POSITION Read the following NOTES before starting work. Set to the PLAY mode. • Place an object which weighs between 450g~500g on Adjust the Tension Adjust until the length from the edge the Cassette Tape to keep it steady when you want to of the Tension Arm to the standard line of the Main make the tape run without the Cassette Holder.

  • Page 19: Confirmation And Adjustment Of Tape Running Mechanism

    MECHANICAL ADJUSTMENTS 1-4: CONFIRMATION OF VSR TORQUE 2. CONFIRMATION AND ADJUSTMENT OF TAPE RUNNING MECHANISM Operate within 4~5 seconds after the reel disk begins to turn. Tape Running Mechanism is adjusted precisely at the Install the Torque Gauge (JG002F) and Adapter (JG002B) factory.
  • Page 20 MECHANICAL ADJUSTMENTS 2-2: CONFIRMATION AND ADJUSTMENT OF AUDIO/ 2-3: TAPE RUNNING ADJUSTMENT CONTROL HEAD (X VALUE ADJUSTMENT) When the Tape Running Mechanism does not work well, Confirm and adjust the height of the Reel Disk. adjust the following items. (Refer to item 1-1) Confirm and adjust the position of the Tension Post.

  • Page 21: Mechanism Adjustment Parts Location Guide

    MECHANICAL ADJUSTMENTS 3. MECHANISM ADJUSTMENT PARTS LOCATION GUIDE 1. Tension Adjust P4 Post 2. Tension Arm T Brake Spring 3. Guide Roller T Reel Ass'y 4. P1 Post Idler Ass'y 5. Audio/Control Head S-S Brake Spring 6. X value adjustment driver hole S Reel D1-4...

  • Page 22: Electrical Adjustments

    ELECTRICAL ADJUSTMENTS Read and perform this adjustment when repairing the circuits or replacing electrical parts or PCB assemblies. 1. BASIC ADJUSTMENT CAUTION When replacing IC's or transistors, use only specified silicon grease (YG6260M). (To prevent the damage to IC's and transistors.) 1-1: PG SHIFTER CONDITIONS MODE-PLAYBACK...

  • Page 23: Electrical Adjustment Parts Location Guide

    ELECTRICAL ADJUSTMENTS 2. ELECTRICAL ADJUSTMENT PARTS LOCATION GUIDE T501 TP1002 TP1001 TU6001 TP4001 TP4002 J4501 SYSCON PCB D2-2...
  • Page 24 TROUBLESHOOTING GUIDE TROUBLESHOOTING GUIDE POWER DOES NOT TURN ON Replace F501. Does DISPLAY light ? Is F501 broken ? Check the peripheral circuit to Is the voltage at emitter of Q507 6V ? pin 14 of T501. Is the voltage at collector Replace Q507.

  • Page 25: Troubleshooting Guide

    TROUBLESHOOTING GUIDE POWER SHUTS OFF Insert a cassette and press PLAY button. Check TAPE LOADING, LOADING BELT, DD Does it Power off in about 3 seconds ? MOTOR and CYLINDER MOTOR. Does it Power off in about Check REEL SENSOR and 6 seconds ? REEL BELT.
  • Page 26 TROUBLESHOOTING GUIDE CYLINDER NOT ROTATING DURING PLAYBACK AND RECORDING Check AT 12.6V line of Is the voltage at pin 2 of POWER BLOCK. CP1002 about DC12.6V ? In playback, is the voltage at pin 5 of CP1002 about Check IC1002. DC1.5V ? Replace CYLINDER MOTOR.
  • Page 27 TROUBLESHOOTING GUIDE AUDIO SHAKES Replace AUDIO HEAD. Is AUDIO HEAD scratched ? Is input level at pin 85 of Replace CAPSTAN DD UNIT. IC1002 about 1.7Vp-p ? In playback, is the voltage Check IC1002. at pin 4 of CP1003 2.5V ? Check AUDIO BLOCK.
  • Page 28 TROUBLESHOOTING GUIDE CASSETTE TAPE IS NOT ACCEPTED Does WORM GEAR on Check FRONT LOADING CASSETTE LOADING GEARS and LOCKER. BLOCK activate ? When a cassette is inserted, Check LED and PHOTO is the voltage at pin 4 of SENSOR on SYSCON PCB. IC1002 0V ? When a cassette is inserted, Replace LOADING MOTOR.
  • Page 29 TROUBLESHOOTING GUIDE WHEN INSERTING CASSETTE, IT EJECTS IMMEDIATELY Does another cassette Defective CASSETTE or go down ? CASSETTE LOADING BLOCK. When cassette is inserted, is the voltage at pins 3 and Check FRONT LOADING GEARS. 4 of IC1002 0V ? Check IC1002.
  • Page 30 TROUBLESHOOTING GUIDE FF/REW DO NOT WORK Is the voltage changing at Check pins 9 and 10 of IC1002 pin 11 of IC1002 when lines. you press FF/REW ? Check DECK MECHANISM.
  • Page 31 TROUBLESHOOTING GUIDE TAPE LOADING IS OK, BUT UNLOADS IMMEDIATELY Does CYLINDER Is the voltage at pin 2 Check Power circuit. rotate ? of CP1002 AT 12.6V ? In playback, is the voltage at pin 5 of CP1002 1.5V ? Replace CYLINDER UNIT. Does TP4001 feed Does PG PULSE signal HEAD SWITCHING...
  • Page 32 TROUBLESHOOTING GUIDE PLAYBACK PICTURE JITTERS HORIZONTALLY Is FG output level at pin 3 Replace CYLINDER MOTOR. of CP1002 about 4.0Vp-p ? Is the voltage at pin 5 Replace IC1002. of CP1002 1.5V ? Replace CYLINDER MOTOR. PLAYBACK PICTURE SHAKES Is FG output level at Replace CYLINDER MOTOR.
  • Page 33 TROUBLESHOOTING GUIDE AUTO TRACKING DOES NOT OPERATE By manual tracking, does the DC level at pin 84 Check CYLINDER UNIT. of IC4001 change ? Does the CTL PULSE (about In auto tracking, is the 4.6Vp-p) appear at pin 97 of Check CONTROL HEAD.
  • Page 34 TROUBLESHOOTING GUIDE WHEN IN PLAYBACK, FAST FORWARD OR REWIND MODE IS ACTIVATED, UNIT STOPS IMMEDIATELY Does CAPSTAN DD Refer to section "CAPSTAN MOTOR rotate ? DD MOTOR NOT ROTATING". Does the REEL SENSOR PULSE signal appear Check Q1001 and Q1002. at pins 79 and 80 IC1002 ? Replace IC1002.
  • Page 35 TROUBLESHOOTING GUIDE PLAYBACK PICTURE JITTERS VERTICALLY Does tracking noise appear in the picture ? By adjusting the manual tracking UP/DOWN Check P/B ENVELOPE. buttons, will the noise disappear in the picture ? Are GUIDE POSTS Adjust GUIDE POST height. the right height ? Is PG SHIFTER Adjust PG SHIFTER.
  • Page 36 TROUBLESHOOTING GUIDE NO PLAYBACK PICTURE Is the voltage at pins 12, Is E-E appearing on 36 61, 90 and 96 of Check Power circuit. the Monitor TV ? IC4001 5V ? Check VIDEO OUT LINE and IC4001. Is there FM signal at pins Check connection of the 78 and 79 of IC4001 ? CYLINDER.
  • Page 37 TROUBLESHOOTING GUIDE NO COLOR DURING PLAYBACK Does COMPOSITE Replace IC4001. signal appear at pin 2 of IC4001? Check Q4802 circuit. E-14...
  • Page 38 TROUBLESHOOTING GUIDE PLAYBACK PICTURE IS NOISY (EVEN AFTER CLEANING HEADS) Is FM signal at pin 79 Check CYLINDER UNIT. of IC4001 250mVp-p ? Perform the interchangeable Is FM signal at pin 6 of adjustment of DECK. IC1002 more than 1V ? Is VIDEO output at the emitter of Q4802 2Vp-p, Check IC4001 and Q4802.
  • Page 39 TROUBLESHOOTING GUIDE NO COLOR DURING SELF RECORDING AND PLAYBACK Does VIDEO signal appear Replace J4501. at pin 31 of IC4001 ? Check VIDEO input circuit. Does color signal at Check IC4001. pin 52 of IC4001 ? Check Q4802 emitter. E-16...
  • Page 40 TROUBLESHOOTING GUIDE NO NORMAL AUDIO ON PLAYBACK Does audio appear Refer to section "NO E-E" on E-E ? Does AUDIO signal appear at Check C4039 and peripheral pin 2 of IC4001 6mVp-p ? circuit. Does AUDIO signal appear at Replace IC4001. pin 11 of IC4001 800mVp-p ? Check AUDIO HEAD for debris or stains.
  • Page 41 TROUBLESHOOTING GUIDE CAPSTAN DD MOTOR NOT ROTATING In playback is the Check POWER circuit. voltage at pin 5 of CP1003 12.6V ? Is the voltage at pin 8 of CP1003 5V ? In playback, check the voltage at pin 3 of Replace IC1002.
  • Page 42 TROUBLESHOOTING GUIDE AUDIO CAN NOT BE RECORDED Is BIAS level O.K Is the voltage at pin 2 Check POWER circuit. at L4005 ? of L4005 5.5V ? Is the voltage at base Check pin 29 of IC1002. of Q4005 about 5V ? L4005 is broken or shorted.
  • Page 43 TROUBLESHOOTING GUIDE CASSETTE IN AND DOWN, UNIT HAS NO FUNCTIONS Does mode indicator Check LOADING MOTOR, appear in Display? and the peripheral parts. Does VCR operate with Check IC1002. the remote control? Check Operation PCB. E-20...
  • Page 44 TROUBLESHOOTING GUIDE RECORDING MECHANISM WORKS, BUT NO VIDEO RECORDED FROM INPUT JACK OR TUNER Check the circuit from VIDEO Does VIDEO signal input jack to IC4001, from Tuner appear at pin 31 of Pack to IC4001. IC4001? Check CYLINDER UNIT . E-21...
  • Page 45 TROUBLESHOOTING GUIDE NO E-E(VIDEO AND AUDIO FROM TUNER) Are the plugs connected Disconnect the plugs from the to the VIDEO/AUDIO VIDEO/AUDIO input jacks. input jacks ? Do the voltages appear at each terminal B+(5V), Check Power Block. PB(5V), and TU(32V) of TU6001 ? CHECK AUDIO CHECK VIDEO...
  • Page 46 TROUBLESHOOTING GUIDE NO E-E AUDIO (MONO) Does AUDIO signal Check J4501 and peripheral appear at pin 9 of circuit. IC4001 ? Is the voltage at pins Check POWER BLOCK. 12, 36, 61, 90 and 96 of IC4001 5V ? Is the voltage at pin Check pin 57 of IC1002 and 99 of IC4001 0V ? peripheral circuit.

  • Page 47: Ic Descriptions

    IC DESCRIPTIONS OEC7035A Pin No. Pin Name Description AFT-SC AFT S Curve input for tuner. AGC-DET Input of CASS DOWN, TAB switch and setting of service mode. Tape end sensor input signal. Tape start sensor input signal. RF SW/A-ENV Ground. V-ENV Input terminal of video RF envelope.
  • Page 48 IC DESCRIPTIONS OEC7035A Pin No. Pin Name Description POWER ON L O For control the user power switch ON/OFF. O Not used. ONE TOUCH PB O Control the LED for the ONE TOUCH PLAYBACK. PELI CTL Control the 21 pin IC output. O Not used.

  • Page 49: Servo Timing Chart

    SERVO TIMING CHART IC1001 (OEC7035A) DPG * 6 PIN DFG *7 PIN H. SW. P CH 1 CH 2 ! 8 PIN V-SYNC (E-E) * 4 PIN REC CTL (REC) ( 7 PIN V-SYNC (TRICK PB) ! 3 PIN • WAVEFORM CHANGES DEPENDED ON THE TAPE SPEED...

  • Page 50: System Switch Mode

    SYSTEM SWITCH MODE : CAPSTAN FWD ROTATING SLOW : SETTING SPEED TO SERVO LOADING DIRECTION DIRECTION : MECHANICAL MOVEMENT AND CAPSTAN ROTATING (FWD) : CAPSTAN RVS ROTATING : MECHANICAL MOVEMENT (NO CAPSTAN ROTATING) DIRECTION EJECTION UNLOADING STP3 F. SLOW PB/STP STP2 FF/REW LIGHT...

  • Page 51: Y/C/Audio/Head Amp (Hv-Gx900K

    Y/C/AUDIO/HEAD AMP BLOCK DIAGRAM (MODEL:HV-GX900K) X4001 4.433619MHz CP4001 SP-CH2(L) 2MLPF CTL TRAP SP-COM 6db AMP fh HPF 6db AMP SP-CH1(R) CLPF C SQUELCH DELAY CLPF CLEAR TRAP MAIN MAIN SYNC CONV2 CONV1 SQUELCH IIC_CLK IIC_DATA SYSCON/ MUTE SERVO/ V.H_SW VIDEO ALC TIMER ENV.DET LEVELADJ...

  • Page 52: System Control/Servo/Timer (Hv-Gx900K

    SYSTEM CONTROL/SERVO/TIMER BLOCK DIAGRAM (MODEL:HV-GX900K) LOADING MOTOR DRIVER IC1001 BA6955AN SYSCON/SERVO/TIMER IC1002 OEC7035A CP1004 HETER_SW HEATER SW POWER_FAIL P.FAIL LDM FWD LDM - DECK POWER POWER ON-H A POWER_ON-H LDM RVS LDM + CAP HI-H CAP_HI-H REMOCON REMOCON IC1004 SYSTEM RESET RE5VS31A RESET...
  • Page 53 TUNER/HIFI/21PIN/OSD/VPS BLOCK DIAGRAM (MODEL:HV-GX900K) J4501 NORMAL_A_IN NORMAL_A_OUT Y/C/AUDIO/ TU_A_OUT HEAD AMP SWD VIDEO IN TU_V_OUT EE/VV_V_OUT 2FSC Q4802 BUFFER Q6003 BUFFER Q4801 TU6001 DC CLAMP IC4801 OEC3031A CG_DATA SYSCON/ CG_CLK SERVO/ CG_CS TIMER IIC_CLK IIC_DATA RECORD LUMINANCE SIGNAL PLAYBACK LUMINANCE SIGNAL RECORD COLOR SIGNAL PLAYBACK COLOR SIGNAL TUNER VIDEO SIGNAL...

  • Page 54: Power Block Diagram

    OPERATION BLOCK DIAGRAM (MODEL:HV-GX900K/HV-GX950K) V651 SVV-07SS22 26 25 HEATER_DC + POWER HEATER_DC - CH.UP CH.UP_SW Q601 POWER IC651 FIP DRIVER OTPB SW STILL/PAUSE BU2979K SYSCON/ OTPB SERVO/TIMER OS651 CH.DOWN REMOCON STOP/EJECT KEY-A REC/OTR FF/CUE PLAY REW/REV POWER BLOCK DIAGRAM (MODEL:HV-GX900K/HV-GX950K) IC502 NJM431L D525 VOLTAGE CTL.
  • Page 55 Y/C/AUDIO/HEAD AMP BLOCK DIAGRAM (MODEL:HV-GX950K) X4001 4.433619MHz CP4001 SP-CH2(L) 2MLPF CTL TRAP SP COM 6db AMP fh HPF 6db AMP SP-CH1(R) CLPF C SQUELCH CLPF DELAY CLEAR TRAP MAIN MAIN SYNC CONV2 CONV1 SQUELCH IIC_CLK SYSCON/ IIC_DATA SERVO/ MUTE V.H_SW VIDEO ALC TIMER ENV.DET...
  • Page 56 SYSTEM CONTROL/SERVO/TIMER BLOCK DIAGRAM (MODEL:HV-GX950K) LOADING MOTOR DRIVER IC1001 BA6955AN SYSCON/SERVO/TIMER IC1002 OEC7035A CP1004 HEATER_SW HEATER SW P.FAIL POWER_FAIL POWER LDM FWD LDM - DECK POWER_ON-H POWER ON-H A LDM RVS LDM + CAP_HI-H CAP_HI-H REMOCON REMOCON IC1004 SYSTEM RESET RE5VS31A RESET KEY-A...
  • Page 57 TUNER/HIFI/21PIN/OSD/VPS BLOCK DIAGRAM (MODEL:HV-GX950K) J4501 A/V SW IC IC4501 BUFFER BUFFER BUFFER BUFFER BUFFER BUFFER LA7158M 6MB AMP 6MB AMP 6MB AMP CLAMP CLAMP CLAMP CLAMP NORMAL_A_IN NORMAL_A _OUT Y/C/AUDIO/ SWD_VIDEO_IN HEAD AMP Q4802 EE/VV_V_OUT BUFFER 2FSC Q4801 Q6003 P.CON+5V DC CLAMP BUFFER Q4501...
  • Page 58 PRINTED CIRCUIT BOARDS (MODEL:HV-GX900K/HV-GX950K) DECK OPERATION 1 OPERATION 2 CP101 CP102 CD601 SW602 CD602 Q601 SW607 SW608 Q101 Q102 D601 SW609 SW610...

  • Page 59: Operation Schematic Diagram

    OPERATION SCHEMATIC DIAGRAM (MODEL:HV-GX900K/HV-GX950K) (OPERATION 2 PCB) (OPERATION 1 PCB) OTPB SW Q601 DTA143ES TO DISPLAY FROM/TO DISPLAY CD601(CP651) R601 R602 R603 R604 R605 KEY A CD602(CP652) 3.3K 2.7K 3.9K 6.8K CH.UP_SW CH25082A OTPB CH23042A CH.UP_SW C601 AT+5V 470P B R606 KEY-A 1.5K...

  • Page 60: Deck Schematic Diagram

    DECK SCHEMATIC DIAGRAM (MODEL:HV-GX900K/HV-GX950K) LOADING MOTOR M101 (DECK PCB) S105 BOT SENSOR S106 Q101 RPT-38PB113 S101 S102 S103 S104 FROM/TO SYSCON/SERVO/TIMER CP101(CP1004) 52044-0445 LDM+ LDM- FROM/TO SYSCON/SERVO/TIMER CP102(CP1001) 173979-2 EOT SENSOR Q102 RPT-38PB113 PCB550 VE8851 NOTE: NOTE: THIS SCHEMATIC DIAGRAM IS THE LATEST AT THE TIME THE DC VOLTAGE AT EACH PART WAS CAUTION: SINCE THESE PARTS MARKED BY...
  • Page 61 PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX900K) R4038 Q4005 R1014 Q1009 R4005 C4518 R4529 R4004 C6010 R4018 C4098 R4022 R4011 R4029 C4034 R4010 C4050 C4104 C4027 C4072 C4064 R4525 C4011 Q4008 C4063 C4076 Q4011 C4065 R6009 C4100 C4058 Q6003 C4080 C4082 C4047 R1036 R4040 C4086...

  • Page 62: Printed Circuit Boards (Syscon) (Hv-Gx900K

    PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX900K)
  • Page 63 PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX900K) R4038 Q4005 R1014 Q1009 R4005 C4518 R4529 R4004 C6010 R4018 C4098 R4022 R4011 R4029 C4034 R4010 C4050 C4104 C4027 C4072 C4064 R4525 C4011 Q4008 C4063 C4076 Q4011 C4065 R6009 C4100 C4058 Q6003 C4080 C4082 C4047 R1036 R4040 C4086...

  • Page 64: Y/C/Audio/Head Amp Schematic Diagram (Hv-Gx900K

    Y/C/AUDIO/HEAD AMP SCHEMATIC DIAGRAM (MODEL:HV-GX900K) (SYSCON PCB) FROM/TO SYSCON/SERVO/TIMER VV-H V.H_SW PICTURE_CTL NA_REC-H DUMMY_V.SYNC SYNC A_MUTE/TRICK-H IIC_DATA IIC_CLK ENV.DET CTL+ H.SW V.ENV R4033 CTL- TP4001 TP4002 HIFI_H.SW/VV-H Y/C/AUDIO/CCD/H.AMP C4011 IC4001 FROM/TO 21PIN/OSD/VPS HA118217F 0.001 B 2FSC R4045 C GND CVCC V.H_SW NTSC/PAL SYNC...

  • Page 65: System Control/Servo/Timer Schematic Diagram (Hv-Gx900K

    SYSTEM CONTROL/SERVO/TIMER SCHEMATIC DIAGRAM FROM/TO POWER (MODEL:HV-GX900K) HEATER_SW HEATER_SW (SYSCON PCB) CAP_HI-H (AC) POWER_FAIL POWER_FAIL CAP_VCO AT+5V-A D1007 D1006 1N4005E AT+5.8V 1SS133 POWER_ON-H AT+12.6V P.CON+5V (S/S) (CYL) (CAP) (LDM) IC1001 BA6955AN LOADING MOTOR DRIVER FROM/TO Y/C/A/H.AMP D1010 CONTROL LOGIC 1SS133 VV-H V.H_SW NC NC...

  • Page 66: 21Pin/Osd/Vps Schematic Diagram (Hv-Gx900K

    21PIN/OSD/VPS SCHEMATIC DIAGRAM (MODEL:HV-GX900K) (SYSCON PCB) AT+12V VCR 10V Q4502 W828 2SA933S VCR SW Q4503 DTC124EKA I/O_S.DATA/VCR-H R4529 TV-L/VCR-[10V] R4819 RF_CONV.V DC CLAMP Q4801 2SC2412K W847 OSD_VIDEO_OUT C4804 EE/VV_V_OUT BUFFER 6.3V Q4802 KANP 2SA1037AK L4801 P.CON+5V 100uH W886 L4802 C4820 100uH 6.3V R4513...

  • Page 67: Tuner/Hifi Schematic Diagram (Hv-Gx900K

    TUNER/HIFI SCHEMATIC DIAGRAM (MODEL:HV-GX900K) (SYSCON PCB) R6017 NORMAL_A_OUT TU6001 L6001_1 MRF11-UB51 100uH W885 AT+5V R6005 RF_CONV.A_OUT A.IN IIC_DATA L6002 P.CON+5V 100uH IIC_CLK W826 SWD_A_IN-L C6012 RF_CONV.V V.IN W827 6.3V AUDIO_OUT-L +32V TU(MD) NORMAL_A_OUT NORMAL_A_IN L6004 P.CON+5V 100uH ELC0607 R6009 BUFFER Q6003 2SC2412K TU_V_OUT...

  • Page 68: Power Schematic Diagram (Hv-Gx900K

    POWER SCHEMATIC DIAGRAM (MODEL:HV-GX900K) (SYSCON PCB) D512 11DF2N TO TUNER/HIFI R517 D513 +32V D504 1N4005E 390 1/4W 1N4005E P.CON+5V CD501 D502 06635817 CP506 (AUDIO) AC230V_50Hz 1-1123724-2 1N4005E (TUNER) FH501 FH502 BLUE BLUE (HIFI) D503 EYF-52BC EYF-52BC BROWN BROWN 1N4005E L502_1 F501 D505 22uH ELC0607...

  • Page 69: Display Schematic Diagram

    DISPLAY SCHEMATIC DIAGRAM (MODEL:HV-GX900K/HV-GX950K) (SYSCON PCB) V651 SVV-07SS22 V651 (SVV-07SS22) ANODE CONNECTION col2 col1 SLPM col2 col1 OS651 PNA4612M00YB Vout C651 6.3V -23.3 -14.9 -18.9 -14.6 -14.6 -15.0 -19.5 -19.3 -21.3 -11.3 SEG10 -17.5 FL_CS 33 SEG9 SEG11 -21.3 FL_S_CLK SEG12/GRID11 FIP DRIVER -26.2...

  • Page 70: Interconnection Diagram (Hv-Gx900K

    INTERCONNECTION DIAGRAM (MODEL:HV-GX900K) DECK MECHA ASS’Y F/E HEAD H5002 HALL MAIN ROTOR SENSOR COIL MAGNET FG SENSOR HALL HALL SWITCH LOGIC CD501 AC230V50Hz CP506 CP1003 BLUE MOTOR GND I LIMIT BROWN VCO(12V) J4501 PERITEL CAP.M F/R CAPSTAN DD UNIT VCC(5V) A.OUT(R) M2001 A.IN(R)

  • Page 71: Printed Circuit Boards (Syscon) (Hv-Gx950K

    PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX950K) R4038 Q4005 R1014 Q1009 R4005 C4518 R4529 R4004 C4533 R4524 C6010 Q4505 R4018 Q4506 R4504 C4524 C4532 R4502 R4011 R4029 C4034 R4010 C4050 C4104 C4543 C4027 C4072 C4523 IC4501 C4064 C4011 Q4008 C4063 C4076 Q4011 C4065 R6009 C4100...
  • Page 72 PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX950K) I-15...
  • Page 73 PRINTED CIRCUIT BOARDS SYSCON (MODEL:HV-GX950K) R4038 Q4005 R1014 Q1009 R4005 C4518 R4529 R4004 C4533 R4524 C6010 Q4505 R4018 Q4506 R4504 C4524 C4532 R4502 R4011 R4029 C4034 R4010 C4050 C4104 C4543 C4027 C4072 C4523 IC4501 C4064 C4011 Q4008 C4063 C4076 Q4011 C4065 R6009 C4100...

  • Page 74: Y/C/Audio/Head Amp Schematic Diagram (Hv-Gx950K

    Y/C/AUDIO/HEAD AMP SCHEMATIC DIAGRAM (MODEL:HV-GX950K) (SYSCON PCB) FROM/TO SYSCON/SERVO/TIMER VV-H V.H_SW PICTURE_CTL NA_REC-H DUMMY_V.SYNC SYNC A_MUTE/TRICK-H IIC_DATA IIC_CLK ENV.DET CTL+ H.SW V.ENV R4033 CTL- TP4001 TP4002 HIFI_H.SW/VV-H Y/C/AUDIO/CCD/H.AMP C4011 IC4001 FROM/TO 21PIN/OSD/VPS HA118217F 0.001 B 2FSC R4045 C GND CVCC V.H_SW NTSC/PAL SYNC...

  • Page 75: System Control/Servo/Timer Schematic Diagram (Hv-Gx950K

    SYSTEM CONTROL/SERVO/TIMER SCHEMATIC DIAGRAM FROM/TO POWER HEATER_SW HEATER_SW (MODEL:HV-GX950K) CAP_HI-H (AC) (SYSCON PCB) POWER_FAIL POWER_FAIL CAP_VCO AT+5V-A D1007 D1006 1N4005E AT+5.8V 1SS133 POWER_ON-H AT+12.6V P.CON+5V (S/S) (CYL) (CAP) (LDM) IC1001 BA6955AN LOADING MOTOR DRIVER D1010 FROM/TO Y/C/A/H.AMP CONTROL LOGIC 1SS133 VV-H V.H_SW POWER...

  • Page 76: 21Pin/Osd/Vps Schematic Diagram (Hv-Gx950K

    21PIN/OSD/VPS SCHEMATIC DIAGRAM (MODEL:HV-GX950K) (SYSCON PCB) AT+5V DEC_V_IN DEC_V_OUT PERI_CTL-L SCRANBLE R4524 L4506 R4512 Q4501 DEC_A_IN-L DTC114EKA 22uH R4502 L4501 R4504 DEC_A_OUT-L 22uH CLAMP REGULATOR MUTE GAIN CTL SERIAL CONTROL SW1-L R4511 SW2-L SW3-L CLAMP CLAMP CLAMP EXT COTROL2 EXT CONTROL1 R4529 TV-L/VCR-[10V] R4526...

  • Page 77: Tuner/Hifi Schematic Diagram (Hv-Gx950K

    TUNER/HIFI SCHEMATIC DIAGRAM (MODEL:HV-GX950K) (SYSCON PCB) R6017 NORMAL_A_OUT TU6001 MRF11-UB51 L6001 W885 AT+5V 100uH ELC0607 R6005 RF_CONV.A_OUT A.IN IIC_DATA L6002 P.CON+5V 100uH IIC_CLK W826 SWD_A_IN-L C6012 RF_CONV.V V.IN W827 6.3V AUDIO_OUT-L +32V R6011 TU(MD) AGC_DET R6016 R6006 Q6001 NORMAL_A_OUT 2SC2412K 100K C6021 NORMAL_A_IN...

  • Page 78: Power Schematic Diagram (Hv-Gx950K

    POWER SCHEMATIC DIAGRAM (MODEL:HV-GX950K) (SYSCON PCB) D512 11DF2N TO TUNER/HIFI R517 D513 +32V D504 1N4005E 390 1/4W 1N4005E P.CON+5V CD501 D502 06635817 CP506 (AUDIO) AC230V_50Hz 1-1123724-2 1N4005E (TUNER) BLUE BLUE FH501 FH502 (HIFI) D503 EYF-52BC EYF-52BC BROWN BROWN 1N4005E L502_1 F501 D505 22uH ELC0607...

  • Page 79: Interconnection Diagram (Hv-Gx950K

    INTERCONNECTION DIAGRAM DECK MECHA ASS’Y F/E HEAD (MODEL:HV-GX950K) HALL MAIN ROTOR H5002 SENSOR COIL MAGNET FG SENSOR HALL HALL SWITCH LOGIC CD501 CP506 AC230V50Hz CP1003 BLUE MOTOR GND I LIMIT BROWN VCO(12V) J4501 DECORDER/PERITEL CAP.M F/R CAPSTAN DD UNIT VCC(5V) A.OUT(R) DEC.A.OUT(R) M2001...

  • Page 80: Semiconductor Base Connections

    SEMICONDUCTOR BASE CONNECTIONS (MODEL:HV-GX900K) (MODEL:HV-GX950K) DIODE DIODE CATHODE CATHODE CATHODE CATHODE ANODE ANODE ANODE ANODE 11DF2N-TA2B2 11ES1N-TA1B2 1SS244T-77 SID1050CM SLZ-345B-02-T1 11DF2N-TA2B2 11ES1N-TA1B2 RGP15D-G23 1SS244T-77 SID1050CM SLZ-345B-02-T1 1SS133T-77 1N4005E-G23 1SS133T-77 1N4005E-G23 GMA-02-BT RD12FB-T7 GMA-02-BT RD12FB-T7 MTZJ12B T-77 RU30Z LF014-102 MTZJ12B T-77 SB340L-6737 MTZJ27B T-77 SB340L-6737...

  • Page 81: Waveforms

    WAVEFORMS Y/C/AUDIO/HEAD AMP REC, PB 17 REC, PB 0.5V 10U/div 10V 5U/div 0.5V 0.5V/div 1V 0.5s/div REC, PB REC, PB 2 PB 18 REC, PB 200mV 0.5V/div 1V 5U/div 200mV 10U/div 1V 0.5s/div SYSCON/SERVO/TIMER POWER ON REC, PB REC, PB 100mV 50T/div 1V 5V/div 1V 5U/div...

  • Page 82: Mechanical Exploded View

    MECHANICAL EXPLODED VIEW (HV-GX950K) TU6001 PCB010 (SYSCON PCB ASS'Y) PCB280 (OPERATION 2 PCB ASS'Y) PCB270 (OPERATION 1 PCB ASS'Y) L1-1...

  • Page 83: Mechanical Replacement Parts List

    MECHANICAL REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY S4-D10-5B7-200 CAB,FRONT ASS'Y(HV-GX900K) S4-D10-6B7-200 CAB,FRONT ASS'Y(HV-GX950K) S0-1WP-A03-480 HOLDER,DECK(A) S0-4WP-A00-070 HOLDER,DECK(R) S2-344-900-130 BADGE,BRAND S3-5WP-D06-050 BUTTON,FF S3-5WP-D06-060 BUTTON,REW ----- SHIELD,CASE HEAD AMP ----- SHIELD,COVER HEAD AMP ----- SPR,EARTH HEAD AMP ----- SPR,EARTH HEAD AMP S3-5WP-D06-070 BUTTON,BASE S5-5WP-A00-090...

  • Page 84: Chassis Exploded View (Top View)

    CHASSIS EXPLODED VIEW (TOP VIEW) M2003 UN4001 H5001 H5002 M101 PCB550 (DECK PCB ASS'Y) NOTE: Applying positions AA, AB, AC and BA for the CLASS PART NO. MARK grease or oil are displayed for this section. GREASE G-555G Check if the correct grease or oil is applied for each position.

  • Page 85: Chassis Exploded View (Bottom View)

    CHASSIS EXPLODED VIEW (BOTTOM VIEW) M2001 NOTE: Applying positions AA, AB, AC and BA for the CLASS PART NO. MARK grease or oil are displayed for this section. GREASE G-555G Check if the correct grease or oil is applied for each position.

  • Page 86: Chassis Replacement Parts List

    CHASSIS REPLACEMENT PARTS LIST REF. NO. PART NO. DESCRIPTION Q'TY REF. NO. PART NO. DESCRIPTION Q'TY S5-OA5-000-220 AHC ASS'Y S5-OP9-006-860 TAPE GUIDE R S5-OP2-002-700 BELT,CAPSTAN S5-OP9-006-870 COVER,SENSOR L S5-OP9-006-890 LEVER,REC S5-OP9-006-880 LEVER,FLAP S5-OP5-000-830 BASE,AC HEAD S5-OP9-006-900 CASS HOLDER S5-OP8-003-240 SPR,AC HEAD S5-OP9-006-910 LOCKER,L S5-OA0-002-970 MAIN CHASSIS ASS'Y S5-OP9-006-920 LOCKER,R...

  • Page 87: Electrical Replacement Parts List

    ELECTRICAL REPLACEMENT PARTS LIST REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION SYSCON PCB ASS'Y *** CAPACITORS *** *** RESISTORS *** C4075 87-015-075-040 CAP,E 10-16V C4077 87-010-403-080 CAP,E 3.3-50V ! R502 S3-118-A01-0J0 RES,M 1-2W C4079 87-015-075-040 CAP,E 10-16V ! R516 87-029-174-090 RES,FUSE 1-1/4W C4081...
  • Page 88 ELECTRICAL REPLACEMENT PARTS LIST REF.NO. PART NO. DESCRIPTION REF.NO. PART NO. DESCRIPTION *** ICS *** *** COILS *** ! IC501 87-A21-186-010 IC,STR-F6552 L4012 87-003-154-080 COIL,220UH ! IC502 S0-Q90-431-L00 IC,NJM431L L4013 87-003-152-010 COIL,100UH IC651 S0-7F5-297-900 IC,BU2979K L4015 87-003-152-010 COIL,100UH ! IC1001 S0-7SQ-955-AN0 IC,BA6955AN L4501 87-005-688-080...
  • Page 89 ELECTRICAL REPLACEMENT PARTS LIST REF.NO. PART NO. DESCRIPTION OPERATION 1 PCB ASS'Y *** SWITCHES *** SW601 S5-042-01T-320 SW,TACT SW602 S5-042-01T-320 SW,TACT SW603 S5-042-01T-320 SW,TACT SW604 S5-042-01T-320 SW,TACT SW605 S5-042-01T-320 SW,TACT SW606 S5-042-01T-320 SW,TACT OPERATION 2 PCB ASS'Y *** DIODE *** D601 S0-213-5Q1-600 LED,SLZ-345B-02...
  • Page 90 2–11, IKENOHATA 1–CHOME, TAITO-KU, TOKYO 110-8710, JAPAN TEL:03 (3827) 3111 Printed in Singapore 920074...
