- Page 1 Quick Start Guide 3200 Linear Imager...
- Page 2 The information in this publication does not represent a commitment on the part of Hand Held Products. Hand Held Products shall not be liable for technical or editorial errors or omissions contained herein; nor for incidental or consequential damages resulting from the furnishing, performance, or use of this material.
- Page 3 Nijverheidsweg 9-13 5627 BT Eindhoven The Netherlands Hand Held Products, Inc. shall not be liable for use of our product with equipment (i.e., power supplies, personal computers, etc.) that is not CE marked and does not comply with the Low Voltage Directive.
- Page 4 You are cautioned that changes or modifications not expressly approved by Hand Held Products could void your authority to operate the equipment. This device complies with part 15 of the FCC Rules. Operation is subject to the following two conditions: (1)
- Page 5 This device has been tested in accordance with IEC60825-1 LED safety, and has been certified to be within the limits of a Class 1 LED device. Solids and Water Protection The 3200 has a rating of IP41, immunity of foreign particles and dripping water according to IEC60529.
-
Page 7: Usb Connection
Note: Refer to your user’s guide for information about cleaning your device. For localized language versions of this document, go to www.handheld.com. Getting Started Turn off computer’s power before connecting the scanner, then power up the computer once the scanner is fully connected. USB Connection... - Page 8 Keyboard Wedge Connection Reading Techniques The view finder projects a red aiming beam that should be centered over the bar code. Hold the scanner over the bar code, pull the trigger, and center the aiming beam on the bar code.
- Page 9 The aiming beam is smaller when the scanner is closer to the code and larger when it is farther from the code. Hold the scanner close to smaller bar codes, and farther away from large bar codes to get a proper read. If the bar code is highly reflective (e.g., laminated), you may need to tilt the scanner at an angle so the bar code can be scanned.
- Page 10 Interface Scan the bar code that describes the PC or interface you are using. USB Keyboard (PC) (Default) Japan DOS/V AT/PS2 Keyboard Wedge Emulate External Keyboard...
-
Page 11: Keyboard Country
Keyboard Country Scan the Program Keyboard Country bar code below, then scan the numeric bar code(s) from page 10, then the Save bar code to program the keyboard for your country. As a general rule, the following characters are not supported by the scanner for countries other than the United States: @ | $ # { } [ ] = / ‘... -
Page 12: Reread Delay
Trigger The following bar codes will allow you to use the reader in Manual Trigger mode (need to press the trigger to read) or Automatic Trigger mode (the beam is always on). Manual Trigger (Default) Automatic Trigger Reread Delay This sets the time period before the scanner can read the same bar code a second time. - Page 13 Suffix If you want a carriage return after the bar code, scan the Add CR Suffix bar code. To add a tab after the bar code, scan the Add Tab Suffix bar code. Otherwise, scan the Remove Suffix bar code to remove the suffixes. Add CR Suffix Add Tab Suffix Remove Suffix...
- Page 14 Scan the following bar code to clear a Code ID Prefix. Clear All Prefixes Note: For a complete list of Code IDs, see the User’s Guide for your product at our website, www.handheld.com. Data Format Editor Instructions The following are abbreviated instructions for entering a data format.
- Page 15 Enter Data Format Clear All Data Formats Save...
- Page 16 Programming Chart...
- Page 17 Save...
-
Page 18: Technical Assistance
Technical Assistance If you need assistance installing or troubleshooting your imager, please call your Distributor or the nearest Hand Held Products technical support office: Latin America Telephone: (803) 835-8000 Telephone: (800) 782-4263 E-mail: latechsupport@handheld.com Brazil Telephone: +55 (21) 3535-9100 Fax: +55 (21) 3535-9105 E-mail: brsuporte@handheld.com... -
Page 19: For Further Information
To download the full User’s Guide for these products, visit our website at www.handheld.com Product Service and Repair Hand Held Products provides service for all its products through service centers throughout the world. To obtain warranty or non-warranty service, return the unit to Hand Held Products (postage paid) with a copy of the dated purchase record attached. - Page 20 Mexico Telephone: +52 (55) 5203-2100 Fax: +52 (55) 5531-3672 E-mail: mxservice@handheld.com Europe, Middle East, and Africa Telephone: +31 (0) 40 2901 633 Fax: +31 (0) 40 2901 631 E-mail: euservice@handheld.com Asia Pacific Telephone: +852-2511-3050 Fax: +852-2511-3557 E-mail: apservice@handheld.com Japan Telephone: +813-5770-6312 Fax: +813-5770-6313 E-mail: apservice@handheld.com Online Product Service and Repair...
-
Page 21: Limited Warranty
Hand Held Products, Inc. ("Hand Held Products") warrants its products to be free from defects in materials and workmanship and to conform to Hand Held Products published specifications applicable to the products purchased at the time of shipment. This warranty does not cover any Hand Held Products product which is (i) improperly installed or used;... - Page 22 PURCHASER’S EXCLUSIVE REMEDY UNDER THIS WARRANTY IS LIMITED TO THE REPAIR OR REPLACEMENT OF THE DEFECTIVE PRODUCT. IN NO EVENT SHALL HAND HELD PRODUCTS BE LIABLE FOR INDIRECT, INCIDENTAL, OR CONSEQUENTIAL DAMAGES, AND, IN NO EVENT, SHALL ANY LIABILITY OF HAND HELD PRODUCTS ARISING IN...
- Page 23 Hand Held Products, Inc. extends these warranties only to the first end-users of the products. These warranties are nontransferable. The limited duration of the warranty for the 3200 is for two (2) years.
- Page 24 Hand Held Products 700 Visions Drive P.O. Box 208 Skaneateles Falls, NY 13153-0208 3200-QS Rev A 1/08...
