- Page 1 VU155 Series Ice and Beverage Dispensers Order parts online Installation, Operation and Service Manual www.follettice.com Service numbers above B50000 Following installation, please forward this manual to the appropriate operations person. 801 Church Lane • PO Box D, Easton, PA 18044, USA Toll free (800) 523-9361 •...
-
Page 2: Table Of Contents
Follett receives the equipment at the factory in Easton, PA within 30 days after issuance of the return authorization number. The equipment must be returned in Follett packaging. If the packaging has been damaged or discarded, Follett will forward, at the customer’s expense, new packaging. -
Page 3: Welcome To Follett Corporation
Before you begin After uncrating and removing all packing material, inspect the equipment for concealed shipping damage. If damage is found, notify the shipper immediately and contact Follett Corporation so that we can help in the filing of a claim, if necessary. -
Page 4: Specifications
Note: Drains should be hard piped and insulated. Maintain at least 1/4" per foot (6mm per 304mm run) slope on drain line run. Water disconnect within 10 feet (3m) of dispenser is suggested for automatic load units. Follett recommends use of a Follett water filter (part# 00130229)on icemakers connected to automatic fill dispensers. Icemaker... - Page 5 Dimensions and clearances Required clearances 51" (1295mm) minimum above counter for installation if dispenser will be dropped into counter 36" (915mm) minimum above counter for all units after installation for auger cleaning and servicing 12" (305mm) minimum on side opposite ice chute for service 12"...
-
Page 6: Installation
Installation Installing dispenser in counter Note: All dispensers must be supported from below with supplied 6" – 9" (153 – 229mm) adjustable leg accessory, or equivalent. Do not hang dispenser on flange. All dispensers must be installed level in both directions to ensure proper operation. 1. -
Page 7: Field Wiring Diagrams
1. Follow detailed cleaning instructions in service manual before operating dispenser. 2. On units with Follett integral ice water bath beverage cooling (“B” models) only, slowly pour water into ice water bath area to fill empty bath and submerge coils. Coils are submerged when water starts to flow out overflow drain. -
Page 8: Connecting Beverage Lines
Ice movement How the dispenser works Follett’s dispensers are available in automatic load configurations, fed from one or two Follett Satellite- fill icemakers or manual load configurations (using ice from another source). In all models, ice is stored below the counter in the dispenser storage area. -
Page 9: Cleaning
Cleaning Using solutions below, clean and sanitize storage area and beverage lines before starting unit and on a routine basis as noted below. Note: Always disconnect power before cleaning dispenser. Do not run plastic parts through a dishwasher. Solution A: Combine 1 oz (250ml) bleach with 2 gal (8L) hot water or use Ecolab Mikro-chlor Cleaner per manufacturers instructions. - Page 10 Recommended daily dispenser cleaning 1. Remove all debris from drain pan. 2. Pour 1 gallon (4L) hot water into drain pan to keep drain lines clear. Recommended weekly dispenser cleaning 1. Remove drain pan and grille and wash with Solution A. Rinse thoroughly. 2.
-
Page 11: Service
Service Fig. 1 RH, 8-valve unit Front View Dispense chute cover removal top cover chute valves 1. Remove top cover. cover 2. Push chute cover up vertically to slip off holding tab. 3. After clearing tab, pull chute cover forward to remove. -
Page 12: Wiring Diagrams
Wiring diagram Right hand unit Left hand unit AUGER MOTOR COUNTERCLOCKWISE ROTATION AUGER MOTOR DISPENSE CLOCKWISE ROTATION PL2-2 PL1-1 PL1-2 PL2-1 PL2-1 PL2-2 BLACK GRAY BLACK BLACK ORANGE PURPLE PURPLE WHITE WHITE POWER REAR TOP LID DRAIN SWITCH SWITCH PL2-3 SWITCH SWITCH PL2-3... -
Page 13: Troubleshooting
(page 16). 4. Check that all drains are clear. Note: For units equipped with Follett compressed nugget icemaker, see Icemaker Operation and Service Manual for service and troubleshooting information. Possible cause... - Page 14 Operational Status The chart below shows the operational status of various parts when certain switches are turned off or accessories are removed. Condition Pump Solenoids Auger Wheel Beverage valves Top lid off Rear lid off Drain pan off On/off switch in off position Beverage switch in OFF...
-
Page 15: Replacement Parts
8 valve unit with right hand (RH) tower 8 valve unit with right hand (RH) tower (push-button dispensing) Reference # Description Part # Lid, 8 valve unit (includes “Follett” label) 502436 Lid, 10 valve unit (includes “Follett” label) 502437 Label, “Follett” 502438... - Page 16 Dispense assembly Dispense assembly (RH unit with bath shown) Side View Top View Reference # Description Part # Gate, dispense 502455 Linkage pin, gate/solenoid 502456 Pin, quick release, 3" (77mm), bath gate and lever 501949 Pin, quick release, 5.53" (141mm), dispense gate 502102 Solenoid (includes linkage pin) 501961...
- Page 17 Water bath Side View Top View Reference # Description Part # Pump, water bath (includes mounting plate and elbow) 00111476 Elbow, overflow drain, 1" (26mm) x 3/4 MPT 502465 Not shown Elbow, clean-out drain, 3/8" (10mm) x 3/8 MPT 502466 Coil, syrup 00125864 Valve, QuickCARB assembly...
- Page 18 Hopper Side View Reference # Description Part # Auger, LH unit (black, stamped with “1”) 502491 Not shown Auger, RH unit (gray, stamped with “2”) 502492 Tube, auger, LH unit with beverage bath 502486 Not shown Tube, auger, RH unit with beverage bath 502485 Not shown Tube, auger, RH unit without beverage bath...
- Page 19 Auger motor Top View Side View Reference # Description Part # Auger motor/drive assembly, vertical (includes all items below) 502493 Motor, vertical auger (includes gearbox and capacitor) 502476 Chain, auger drive #35, 40p 502477 Sprocket #35, 22T 5/8 bore 502478 Sprocket #35, 12T 5/8 bore 502479 Drive shaft...
- Page 20 Electrical components Top View ready (orange) circuit board BEVERAGE BATH CONTROL BOARD DETAIL Side View Front View #1 #2 BEV. BATH INDICATOR WARM COLD Reference # Description Part # Transformer, 24V 502058 Relay, auto fill 501826 Relay, dispense 501826 Timer, auto fill (automatic fill units) 502471 Strips, terminal 502472...
