PARTS LIST

1
4
17
2
ORIGINAL
REF.
PART NO.
1 44388
2 88939
3 89165
4 89163
5 89164
6 89166
89167
7
89169
8 0506B
9 88958
10 0431A
11 89156
12 88954
13 88955
14 0701B
15 84999
16 88959
17 88962
12
7
*PART DESCRIPTION
HANGER BAR (4 required)
OUTLET BOX ASSEMBLY
LOUVER
BLOWER HOUSING
MOTOR MOUNTING PLATE
BLOWER WHEEL
MOTOR – LS80
MOTOR – LS100
MOTOR MOUNTING HARDWARE
GRILLE ASSEMBLY
SPRING SET
DUCT COLLAR
POWER UNIT
POWER UNIT
GRILLE & SPRING ASSEMBLY
LENS
REFLECTOR ASSEMBLY
BALLAST ASSEMBLY
NuTone
Attn: Parts Department
®
4820 Red Bank Rd.
Cincinnati, OH 45227-1599
Phone: (800) 543-8687
Fax: (513) 527-5173
EFFECTIVE
DATE
Rev. MAY
1999
11
14
9
3
6
10
13
5
MODEL NUMBER
LS80LF, LS100LF
15
REPLACEMENT
MODEL USED ON
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF
LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF
LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
LS80LF, LS100LF
NOTE: Always order by
current part number
LS80LF, LS100LF I.I.
PRODUCT
GROUP
FAN
10
16
8
CURRENT
PART NO.
44388-000
88939-000
89165-000
89163-000
89164-000
89166-000
89167-000
89169-000
0506B-000
88958-000
0431A-000
89156-005
88954-000
88955-000
0701B-000
84999-000
88959-000
88962-000
