Stove Company
Vent-Free Zero-Clearance Universal Firebox
Model VFZC36 and Model VFZC42
Certified for use with any Unvented Log Set tested to ANSI Z21.11.2
This Firebox may also be installed in manufactured (mobile) homes,
where not prohibited by state or local codes.
Shown with optional
cabinet mantel, hearth
base, brass trim, louvered
grills, and firebrick panels.
OWNER'S OPERATION AND INSTALLATION MANUAL
FOR USE ONLY
Carefully review the instructions supplied
WITH DECORATIVE TYPE
with the decorative type unvented room heater
UNVENTED ROOM HEATERS
for the minimum fireplace size requirement.
DO NOT BUILD A WOOD FIRE
DO NOT INSTALL THE APPLIANCE IN
THIS FIREBOX, UNLESS THIS FIREBOX
MEETS THE MINIMUM DIMENSIONS REQUIRED
Save this manual for future
FOR THE INSTALLATION.
reference.
WARNING: If the information in this manual is not followed exactly, a fire or
explosion may result causing property damage, personal injury or loss of life.
851298 2/98
