  • Page 1 User Guide Le Guide de l’Utilisateur Bedienungsanleitung Manuale d’uso Guia del Usuario Guida dell’Utente Gebruikershandleiding Pengguna Panduan © 2013 Shure Incorporated *27A20681* Printed in China N108 27A20681 (Rev. 2)

  • Page 3: General Description

    General Description The Shure VP83F is a professional-quality condenser microphone designed for use with DSLR and video cameras. The VP83F features built-in flash recording and captures crystal-clear, high definition audio, completely independent from other hardware. The intuitive menu makes configuration fast and simple for use in almost any sonic environment.

  • Page 4: Mounting The Microphone

    Installing the Memory Card and Batteries functionality. card installed. memory card and battery compartment. To Install: Insert the card into the slot located above the battery door, To Remove: Press the card to unlock it, then pull it from the device. Note: Format the memory card in the device prior to first use.

  • Page 5: Audio Connections

    Use the 3.5 mm coiled cable to Important: Never use the microphone gain to connect the VP83F camera output to the camera's audio input. in poor signal quality or distortion. Control Panel Menu Navigation Displays menu information and settings.

  • Page 6: Audio Path

    Audio Path Headphone and Camera Output Volume The following diagram shows how audio flows through the device: Headphone Volume: HEADPHONE, or in the playback, recording, and home screens by Recording to Memory Card Camera Output Volume: Camera Output UTILITIES > CAMERA OUT LOW, MEDIUM, or HIGH) to accommodate different camera preamp sensitivities.
  • Page 7 Tip: For best performance, format the memory card in the device every time after Return to home screen Press record button SD CARD CAMERA OUT VP83F HOME Remaining recording time is displayed and the following settings can be accessed: sent to the camera. FILE LIST FORMAT CARD: Formatting the microSD card will erase HIGH (0 dB): For cameras with a low-gain preamp.

  • Page 8: Accessories And Replacement Parts

    Memory Card Requirements channels. Ring Sleeve cards in the device prior to recording. Shure recommends using name brand memory cards, as lower quality or slower memory cards may have a negative effect on performance. Note: FAT32 file system, Ring Sleeve DEFAULT.

  • Page 9: Camera Output

    Cartridge Type Polar Pattern Recording Format Frequency Response Sensitivity open circuit voltage, @ 1 kHz, typical 0 dB Gain +30 dB Gain 0 dB Gain Setting, 1 kHz at 1% THD 2,500 Hz 250 Hz Signal-to-Noise Ratio 6,300 Hz 500 Hz +30 dB Gain Setting 10,000 Hz 1,000 Hz...
  • Page 10 • Note: Testing is based on the use of supplied and recommended cable types. The This product meets the Essential Requirements of all relevant European Incorporated or any of its European representatives. For contact information please visit www.shure.com...
  • Page 11 Europe, Middle East, Africa: Shure Europe GmbH Jakob-Dieffenbacher-Str. 12, 75031 Eppingen, Germany Phone: 49-7262-92490 Fax: 49-7262-9249114 Email: info@shure.de PT. GOSHEN SWARA INDONESIA Kompleks Harco Mangga Dua Blok L No. 35 Jakarta Pusat I.16.GSI31.00501.0211...
