Technical Data - Whirlpool ADP 941/1 WH Service Manual

21.07 .2004 / Page 2
Doc. No: 4812 718 12405

Technical data

Dimension
Height
Width
Depth
Weight
Decor plate
Thicknes max.
Width
Height
Weight max.
Specification (normal program)
Capacity
Water consumption
Energy consumption
Program time
Noise level
Detergent consumption
Salt consumption
by 21˚ dh
Hot water connect. up to 60
Alarms
Refill rinse aid
Refill salt
Water leakage
Program information
Start indicator
Net indicator
Volume (normal)
Water
Regeneration
Back rinse 3x
Prewash
Main wash
Intermediate rinse 1
Intermediate rinse 2
Clear rinse
Safety / overflow
Measuring the level
Remove the coarse sieve, put in a measuring
meter into the sump, measure the hight of the
water level.
ADP 941/1 WH
8542 941 10110
82,0-87 ,0 cm
59,5 cm
57 ,0 cm
~ 55 kg
4 mm
584 mm
595 mm
1,8 kg
12 standard
setting pl.
22 l
1,5 kWh
~ 82 min
52 db (A)
25 ml
<20 g
˚C
Volume Level
0,3 l 15 mm
1,0 l 68 mm
5,0 l 125 mm
6,0 l 129 mm
5,0 l 125 mm
5,0 l 125 mm
5,0 l 125 mm
8,5 l 141 mm
Whirlpool Europe
Customer Service
Detergent max.
Pre-wash
Main-wash
Rinse aid
6 Dosage steps
Water softener
Saltcontainer
Resin container
Regeneration dosage
Water pressure
Inlet pressure
Spray pump pressure
Rotations
Spray pump motor
Drain pump motor
Spray arm lower
Spray arm upper
Ceiling rotor
Flow rates / Inlet volume
Flow meter (at 0,3 bar
= quantity 1,1 l/min)
Spray pump
Drain pump
Pump height max.
Inlet valve
Valve for sieve
Spray arm lower
Sprayarm upper
Ceiling rotor / shower
Water distribution
Fine sieve
Self cleaning
micro filter
Electrical data
Base data
Voltage
Frequency
Total power
Fuse
S E R V I C E
3
10 cm
3
45 cm
3
125 cm
3
1 - 6 cm
2 kg
3
900 cm
3
300 cm
0,3-10 bar
0,4 bar
2800 RPM
2800 RPM
~ 30 RPM
~ 35 RPM
~ 60 RPM
208 lmp/l
~ 70 l/min
16 l/min
1,3 m
4,5 l/min
8 l/min
33 l/min
30 l/min
8 l/min
100 %
~ 32 %
230 V
50 Hz
2,0-2,2 kW
10 A
