HD PORTABLE DIGITAL RECORDER
SRW-1
HD VIDEO PROCESSOR
SRPC-1
OPTICAL INTERFACE UNIT
HKSR-101
PICTURE CACHE BOARD
HKSR-102
RGB 60P PROCESSOR BOARD
HKSR-103
OPERATION MANUAL
[English]
1st Edition (Revised 6)

Advertisement

Table of Contents
loading

Related Manuals for Sony SRPC-1

Summary of Contents for Sony SRPC-1

  • Page 1 HD PORTABLE DIGITAL RECORDER SRW-1 HD VIDEO PROCESSOR SRPC-1 OPTICAL INTERFACE UNIT HKSR-101 PICTURE CACHE BOARD HKSR-102 RGB 60P PROCESSOR BOARD HKSR-103 OPERATION MANUAL [English] 1st Edition (Revised 6)
  • Page 2 For the customers in the USA (for SRW-1/SRPC-1/HKSR- WARNING 101) This equipment has been tested and found to comply with the To reduce the risk of fire or electric shock, limits for a Class A digital device, pursuant to Part 15 of the do not expose the apparatus to rain or FCC Rules.
  • Page 3 (environnement EMC contrôlé, ex. studio de télévision). Der Hersteller dieses Produkts ist Sony Corporation, 1-7-1 Konan, Minato-ku, Tokyo, Japan. Le fabricant de ce produit est Sony Corporation, 1-7-1 Konan, Der autorisierte Repräsentant für EMV und Produktsicherheit Minato-ku, Tokyo, Japon. ist Sony Deutschland GmbH, Hedelfinger Strasse 61, 70327 Le représentant autorisé...

  • Page 4: Table Of Contents

    Operations .......... 64 5-2-1 Selecting the Video Input To Record 3-1 Assembly ..........22 (When Optional HKSR-101 Is Installed) 3-1-1 Joining the SRW-1 and SRPC-1 ..22 ............64 3-1-2 Using the Control Panel Extension 5-2-2 Selecting Signals to Output to the HD Cable ..........
  • Page 5 Shooting..........86 6-2 Timer Rec ..........89 6-2-1 Manual Timer Rec......89 6-2-2 Auto Timer Rec......... 90 6-3 Cache Rec ........... 91 Appendixes Maintenance and Inspections ....93 Head Cleaning..........93 Handling the Optical-Fiber Connector (When Optional HKSR-101 Is Installed) ..93 Condensation..........

  • Page 6: Chapter 1 Overview

    HDC1500 multi-format portable camera (not supplied), this mode enables YCbCr 4:2:2 50P/60P recording of This manual explains the SRW-1 and SRPC-1. For details highly detailed video that is rich in depth. In docked on the F23, refer to the Operation Manual supplied with operation with the F23, RGB 4:4:4 1080/60P recording the F23.

  • Page 7: Other Features

    Internal timecode generator and reader Connected to the SRPC-1 The internal timecode generator allows you to record This unit can be combined with the SRPC-1 to meet the timecode (LTC, VITC, and user bit data) along with the diverse I/O interface requirements of production video and audio signals.
  • Page 8 The SRW-1 supports the Tele-File memory label system. 1) Tele-File: A system in which non-contact memory ICs on the spines of cassettes allow you to record and read data about the material on the cassettes. Tele- File is a trademark of Sony Corporation. 1-1 Features...

  • Page 9: System Configuration

    1-2 System Configuration The following figure shows a system configured around the SRW-1 and SRPC-1. HD color video camera BATTERY/ BP-GL95 Microphone DC IN Switching Earphones HD VTR etc. VTR etc. AC-DN10/DN2B Headphones Audio input Analog: 4 channels HD SDI video/...

  • Page 10: Chapter 2 Names And Functions Of Parts

    Names and Functions of Parts Chapter 2-1 SRW-1 2-1-1 Principal Sections (see page 11) Control panel See 3-1-2 “Using the Control Panel Extension Cable” (page 24) for more information about using the control panel apart from the recorder. 8 Top handle (see page 15) 1 Cassette insertion slot Display...

  • Page 11: Control Panel

    POWER (power supply) indicator Use to carry the SRW-1 or joined SRW-1/SRPC-1. If the SRW-1 is docked to the SRPC-1 or the F23, lights in If you need to remove the top handle from the SRW-1 green when both the SRW-1 and the SRPC-1 or F23 are body, use a coin driver, etc.
  • Page 12 TC button: Displays the TC (timecode) Setup menu (see ON: All operation buttons are disabled. page 46). This menu allows you to switch between OFF: During recording, only the STOP button and LTC and VITC, to switch between DF and NDF, and PAUSE button are enabled.
  • Page 13 E-E signals output from the HD SDI OUT A/B connectors or the MONITOR OUT HD SDI/SD SDI connectors of the SRPC-1. While an E-E signal is being monitored, the monitor output format (see page 37) is displayed for a few seconds.
  • Page 14 Name Pressed alone Pressed with FUNC button PAUSE button and Pauses tape transport. (The indicator Cue up a time data position specified with FUNC+REC indicator flashes during pause.) button or SYSTEM >EDIT >IN POINT and stops. The To resume tape transport, press the specified time data (Mark IN data) is displayed in the format button again.

  • Page 15: Display

    2-1-3 Display This manual refers to the screen shown below as the HOME screen. 1 Audio level meters 2 Operation status and warnings When you press the HOME button with the FUNC button held down, the sections 4 to 7 are replaced *SRW-1 OOOO PLAY LOCK...
  • Page 16 current tape position (right side). When no Mark In data Green bar: Recording signal quality is good. has been set, “IN: --:--:--:--” appears. Red bar: Recording signal quality is degraded. If this When one or more of the menu items continues, head cleaning or internal inspection is TC >OTHERS(MAIN) >LTC Delay, needed.

  • Page 17: Connector Panel

    j SR Motion See Chapter 6 “Memory Recording (With HKSR-102 When the SYSTEM >FORMAT >SELECT FPS menu Installed)” (page 73) for more information about the SR item is set to “ON” or “VTR” and the signal format is Motion function. being displayed, pressing both the FUNC and HOME buttons together displays the FPS or FRM on the second line and the memory level on the third line.
  • Page 18 POWER ON/OFF switch When the SRPC-1 power is on, push this switch up to the ON side to power the SRW-1 on. To power the SRW-1 off, push the switch down to the OFF side.

  • Page 19: Srpc-1

    Note Set the input selection switches as follows, depending on Once you have joined the SRW-1 and SRPC-1, do not pull the type and level of the input audio. out the release knob except when you want to detach the...
  • Page 20 LEVEL knob. A warning tone is output to the earphones/headphones Powers the SRPC-1 on when pushed up to the ON side. To when a warning is lit on the control panel display. power the SRPC-1 off, push the switch down to the OFF side.
  • Page 21 POWER (power supply) indicator Lights in green when the SRPC-1 is powered on. Flashes when the SRW-1 is put into power save mode by the setting of SAVE MODE in the SYSTEM Setup menu to “SAVE”.

  • Page 22: Chapter 3 Preparations

    Unit, refer to the HKSR-101 Installation Manual. To mount the SRW-1 on the SRPC-1, proceed as follows. Place the SRPC-1 on a flat, stable surface of a bench, table or the like. Rotate the lock lever counterclockwise (see the figure for step 3) until it is almost horizontal.
  • Page 23 Rotate the assist lever back to its original (lock) position to align the LOCK V mark on the SRW-1 with the v mark on the SRPC-1. (See “To lock” in the previous figure.) When you do this, check to be sure that the release knob (see the following figure) is all the way in.

  • Page 24: Using The Control Panel Extension Cable

    Remove the cable from the control panel and replace it with the extension cable. Connect the extension cable to the CTRL PANEL connector on the SRW-1. Lift the SRW-1 off the SRPC-1. Move the assist lever to the lock position. 3-1-2 Using the Control Panel Extension Cable When they are shipped from the factory, the control panel and SRW-1 are connected by a short cable.
  • Page 25 Groove B Groove A Cable clamp Screws Gently pull the part of the cable closest to the control panel in the direction of the arrow so that there is almost no slack, then fix the cable in groove A and groove B.

  • Page 26: Connections

    To connect the HDW-F900R to record 4:2:2 signals HD SDI OUT HD SDI IN A HDW-F900R HD multi-format camcorder SRW-1 + SRPC-1 To connect the HDC-1500 to record RGB 4:4:4 or 4:2:2 50P/59P signals LINK A/B OUT HD SDI IN A HD SDI IN B...
  • Page 27 CAMERA FC2-PD50/PD250 Optical-Fiber Cable (optional). HDC-F950 multi-format camera system SRW-1 + SRPC-1 + HKSR-101 (optional) Note Set VIDEO I/O >VA INPUT in the VIDEO Setup menu to CAM(Optical). Further, set CAM TYPE to F950 or STD, depending on the type of camera system you are using.

  • Page 28: Connections For Playback

    SDI (D1) HKSR-102 (optional) MONITOR OUT SD SDI + HKSR-103 (optional) SRW-1 + SRPC-1 To connect an HD monitor supporting RGB 4:4:4 or 1080 50P/60P (Dual Link) 3-2-2 Connections for Playback BVM-F24 HD monitor To connect an HD monitor HD monitor...
  • Page 29 To use as player for editing SRW-1 + SRPC-1 HD SDI OUT A HD SDI OUT B HD SDI INPUT B REMOTE SRW-5000/5500 HD SDI INPUT A HD SDI OUTPUT A REMOTE 1-I/O(9P) HD SDI OUTPUT B HD video input...

  • Page 30: About Reference Sync Signals

    3-3 About Reference Sync Signals This section explains how to select reference signals for video output signals. 3-3-1 Reference Signals for Video Output Signals The video signals output from this system are state of the system, SYSTEM Setup menu settings (see synchronized as shown below, depending on the operating page 54), and input signals.

  • Page 31: Connecting Reference Signals (Examples For When External Sync Is Required)

    HDC-F950 camera, with the optional HKSR- signals to this unit 101 installed in the SRPC-1, the first step is to synchronize Set REFERENCE >MODE in the SYSTEM Setup menu by supplying reference signals from this unit to the HDC- to “External”, and set REFERENCE >EXTERNAL to the...
  • Page 32 HD SDI OUT A/B (A only or A/B) REF IN HD In the SYSTEM Setup menu, set REFERENCE >MODE to SRW-1 + SRPC-1 SRW-5000 HD Digital “External,” and set REFERENCE Videocassette Recorder >EXTERNAL to “HD.” Connections to output playback signals from this system (synchronized with both HD23.98PsF and SD59.94i)
  • Page 33 REF IN HD MONITOR OUT HD SDI Recorder REF IN SD MONITOR OUT SD SDI SRW-1 + SRPC-1 (HD 23.98PsF or 59.94i) (according to the setting of PD(MON) in the Video In the SYSTEM Setup menu, set Setup menu) REFERENCE >MODE to “External”, and set REFERENCE...
  • Page 34 (A only, or A/B) SRW-5000 HD Digital Videocassette MONITOR OUT HD SDI Recorder REF IN SD MONITOR OUT SD SDI SRW-1 + SRPC-1 HD monitor In the SYSTEM Setup menu, set REFERENCE >MODE to “External”, and set REFERENCE >EXTERNAL to “SD”. SD monitor...

  • Page 35: Power Supply Preparations

    Align the line on the battery attachment section of the closer to the ground. SRPC-1 with the line on the side of the battery pack. For this reason, you should be careful when moving the system with a battery pack attached as shown in the above figure, to prevent the bottom of the battery pack from striking the ground, which may cause it to come off.

  • Page 36: Powering On And Off

    To power on 12.2V To power the SRW-1 and SRPC-1 on, proceed as follows. If you are using an AC adaptor, turn the AC adaptor Note that this mark does not reflect the actual type of Turn the SRPC-1 POWER ON/OFF switch to ON.

  • Page 37: Display Settings

    MONITOR OUT HD SDI and SD LIGHT switch SDI connectors of the SRPC-1. Use the TC Setup menu to specify whether to superimpose this information, and to select the position and type of the superimposed text.
  • Page 38 b Tape remaining e Timecode reader drop-frame mark (525-line mode The remaining tape capacity is displayed as follows. only) “ . ”: Drop-frame mode “ : ”: Non-drop frame mode Display of remaining tape time when it is 23 minutes or less f Timecode generator drop-frame mark (525-line T C R .

  • Page 39: Handling Cassettes

    Use this unit (SRW-1) or a SRW-5000/5500 unit to rewind tapes. Do not use cassettes which have been rewound by other units or by rewinders. Set the SRW-1 and SRPC-1 POWER ON/OFF switches to ON. Storage of cassettes Store your cassettes at room temperature and normal Press the EJECT button.

  • Page 40: Preventing Accidental Erasure

    SRW-1 powered off, because the battery pack is exhausted or for some other reason. Cassette insertion slot 1 Power off the SRW-1 and SRPC-1. 2 Open the rubber cover by pressing the depression on the left side of the cover with your...

  • Page 41: Memory Stick" Handling

    Precautions • To prevent data loss, make backups of data frequently. In no event will Sony be liable for any loss of data. • Unauthorized recording may be contrary to the provisions of copyright law. When you use a “Memory...

  • Page 42: Inserting And Ejecting "Memory Stick

    • The “Memory Stick” application software of the unit may be modified or changed by Sony without prior notice. • Note that there are certain restrictions on recording stage performances and other entertainment events, even if they are recorded for personal use only.

  • Page 43: Power Saving Mode

    In addition, “xx SAVE” appears on the second line of the 3-9 Power Saving Mode status indication in the display, and the “SRW-1” indication under the audio level meters change as follows. In Power Save Mode1: *SRW-1 In Power Save Mode2: **SRW-1 When the SRW-1 is put into power save mode, it reduces the power consumption during recording and playback, for example, by turning off unnecessary signals.

  • Page 44: Chapter 4 Menu Settings

    4-1-1 Displaying Menus Rotate the SELECT/ENTER dial to move the cursor to the target item. The menu system of the joined SRW-1/SRPC-1 consists of four setup menus. • TC Setup menu (see page 46) T C S e t u p •...
  • Page 45 Submenu window T C S e t u p TCG Setting(Main) TIMER SEL DF/NDF TIMER RESET UBG SRC TIMER PRESET 12H/24H TCR SEL TCG MODE PRST REGEN SRC INT L RUN MODE R RUN TCG SET(MAIN) OTHERS (MAIN) PD TC CHAR(MON) CHAR (SD) S RW- 1...

  • Page 46: Tc Setup Menu

    4-2 TC Setup Menu The TC (timecode) Setup menu allows you to make • Factory default settings are underlined. settings related to timecode. • Square brackets indicate settings as displayed in setting In the Settings column of the following table: windows (see the figure for step 3 on page 61).
  • Page 47 Item Settings TCG SET(MAIN) DF/NDF Selects the frame count mode. Timecode generator (Valid only when the DF [Drop Frm]: Drop-frame mode settings for the main frame frequency of NDF [Non Drop Frm]: Non-drop frame mode timecode this system is 29.97 Note These settings are valid only when the TCG MODE item is set to PRST.
  • Page 48 Item Settings CHAR(MON) ON/OFF Selects whether to output text information. The style of text ON [On]: Output. information OFF [Off]: Do not output. superimposed on the HPOS Sets the horizontal display position of text information. output of the 0 to 15 (8) MONITOR OUT HD SDI connector VPOS...
  • Page 49 Item Settings CHAR(SD) ON/OFF Selects whether to output text information. The style of text ON [On]: Output. information OFF [Off]: Do not output. superimposed on the HPOS Sets the horizontal display position of text information. output of the 0 to 15 (8) MONITOR OUT SD SDI connector VPOS...

  • Page 50: Video Setup Menu

    CAM TYPE Selects the type of connected camera, when CAM is selected under VA INPUT. F950 [F950]: When using the HDC-F950. STD [Standard]: When using a recommended optically-connectable camera. D20 [D-20]: When using the ARRI D-20 camera. Contact a Sony service representative for details about optically-connectable cameras. 4-3 VIDEO Setup Menu...
  • Page 51 Item Settings LUT(MON) LUT MODE Selects whether or not to perform LUT conversion, and selects the bank that contains the LUT file to use when LUT conversion is performed. For details OFF [Off]: Do not perform LUT conversion. about LUT file BANK0 [Bank 0]: Select the LUT file of Bank0.

  • Page 52: Audio Setup Menu

    4-4 AUDIO Setup Menu The AUDIO Setup menu allows you to make settings • Factory default settings are underlined. related to audio signals. • Square brackets indicate settings as displayed in setting In the Settings column of the following table: windows (see the figure for step 3 on page 61).
  • Page 53 Item Settings BEEP(PHONE) ALARM Determines whether to generate alarm tones. Level of beep tones OFF [Off]: Do not generate alarm tones. HIGH [High]: Generate high-level alarm tones. LOW [Low]: Generate low-level alarm tones. WARN Determines whether to generate warning tones. OFF [Off]: Do not generate warning tones.

  • Page 54: System Setup Menu

    4-5 SYSTEM Setup Menu The SYSTEM Setup menu allows you to make system settings. In the Settings column of the following table: • Factory default settings are underlined. • Square brackets indicate settings as displayed in setting windows (see the figure for step 3 on page 61). 4-5 SYSTEM Setup Menu...
  • Page 55 Item Settings FORMAT LINE Sets the number of effective lines and the scanning system. Signal format settings 1080I [1080I] 1080P [1080PsF/P] 720P [720P] FRAME When the SELECT FPS item is set to “OFF”, sets the operation frame frequency. When the SELECT FPS item is set to other than “OFF”, sets the target frame frequency.
  • Page 56 Item Settings REFERENCE MODE Selects the input signals to use as reference signal. Reference signal INP [Input]: Video signals input to the HD SDI IN A/B connectors. selection EXT [External]: Signals selected with the next item EXTERNAL. EXTERNAL When the previous item MODE is set to EXT, selects the signals to use as reference signal.
  • Page 57 Item Settings KEYMAP EJECT DIS [Disable]: Disable the button. Key map settings EJECT button function ENA [Enable]: Enable the button. STOP STOP button function PLAY PLAY button function REC button function REW button function FFWD F FWD button function PAUSE PAUSE button function KEY INHI ALL [ALL]: Lock all buttons.
  • Page 58 Item Settings EDIT IN POINT Set time data to cue up (Mark IN data). (The time data set is displayed in the format “IN: xx:xx:xx:xx” in the time data field of the display.) TIMER REC Sets the Timer Rec operating mode when the HKSR-102 is installed.
  • Page 59 Another 30 seconds later, mode changes to Power Save Mode2 in which all outputs are turned off (the POWER indicator flashes on both the SRW-1 and SRPC-1). When one of the tape transport control buttons is pressed, power save mode is canceled.
  • Page 60 Item Settings BATTERY BATT TYPE Selects the type of battery to attach to the battery attachment Settings relating to section. remaining battery AC [AC Adapter] power display Li-ion [Li-ion Battery] BP-GL [BP-GL Battery]: BP-GL95 OTH1 [Other 1] OTH2 [Other 2] Near END For the battery type selected with the previous item BATT TYPE, (BATT)

  • Page 61: Chapter 5 Recording And Playback

    Recording and Playback Chapter Press the menu selection button “SYSTEM” on the 5-1 Signal Format control panel. The SYSTEM Setup menu appears. Settings Rotate the SELECT/ENTER dial to move the cursor to FORMAT, and then press the dial. 5-1-1 Selecting the System Signal A submenu window appears.
  • Page 62 Select the desired value by rotating and pressing the The format list screen appears. SELECT/ENTER dial. F o r m a t L i s t S E L E C T F P S : O F F This returns you to the submenu window, which is 1080 activated again.

  • Page 63: Telefile Recording

    • OUT (recording end point) Recording/playback HD monitor Output SD • Tape format signal monitor • Duration (time from In point to Out point) Output • File name (automatically assigned file name in the 1080/4:2:2 23.98Ps 1080/ 525/ 23.98PsF format HDCAMSR_00X) 4:2:2 59.94i 59.94i...

  • Page 64: Recording Preparations And Operations

    VIDEO I/O in the Page 64 CAMERA connector. source input to the VIDEO Setup menu SDI Input: Use the input signal from the HD SDI IN SRPC-1 (when the A/B connectors. optional HKSR-101 is installed). Select whether or not PD(MON) in the...

  • Page 65: Making Audio Signal Settings

    ANA1 to ANA4: Analog audio signal input to the AUDIO INPUT CH-1and CH-2 connectors on the Average Average SRW-1 or the AUDIO INPUT CH-3 and CH-4 connectors on the SRPC-1 C A S S O U T 00:00:00: 00 S R W - 1 T CR...

  • Page 66: Setting Recording Audio Levels

    Average: Simple average Press the SELECT/ENTER dial. R e c L e v e l Cursor Recording 5-2-4 Setting Recording Audio levels Levels Channel numbers 4040 4040 4000 To check recording audio levels, use the audio level meters 4040 4040 CH10 4000 Recording...
  • Page 67 To display the TC Setup menu Menu item Timecode Press the menu selection button “TC.” TCG MODE REGENE SOURCE SELECT/ INT L Timecode in synchronization TC button TC Setup menu ENTER dial with the timecode recorded in the longitudinal direction on the tape.
  • Page 68 To synchronize the internal timecode generator • Record the output of the timecode generator synchronized with external timecode or timecode to external timecode recorded in the longitudinal direction on the tape. Use the following method to synchronize the timecode generators of multiple VTRs. To preset an arbitrary initial timecode value Set the TCG MODE menu item to RGN, then use Set the TCG MODE menu item to PRST, then proceed as...

  • Page 69: Recording Operations

    To start sequential recording after pausing 5-2-6 Recording Operations Proceed as follows. When the SRW-1 is docked on the F23, you can record ANLG ANLG from the F23. Refer to the F23 Operation Manual for KEY INHI HOME SELECT/ENTER details about operations. LIGHT BACK SRW-1...

  • Page 70: Playback Preparations And Operations

    The unit cues up the frame where the previous 5-3 Playback recording was stopped, and then enters recording pause mode. Preparations and Press the PAUSE button to start recording. Operations This section describes preparations for playback. About connections for playback, see page 28. 5-3-1 Selecting the Conversion Mode of the Downconverter The following three modes are available for the internal...

  • Page 71: Making Audio Monitor Signal Settings

    To select the conversion mode The TIMER SEL settings window appears. (See “To select the type of time data to display” (page 67).) In the VIDEO Setup menu (see page 50), set DC >TYPE to one of the following. Rotate the SELECT/ENTER dial to select CTL, TC LB: Letterbox mode (timecode), or UBIT (user bits).

  • Page 72: C A Srw Srw O U T

    When the tracking has been automatically optimized, the S Y S T E M S e t u p Servo Config tracking control is not released even if the cassette is FORMAT STBY OFF 30sec ejected or the system is powered off. REFERENCE TRACKING Unity...

  • Page 73: Chapter 6 Memory Recording (With Hksr-102 Installed)

    Memory Recording (With HKSR-102 Installed) Chapter You can use the memory on the optional HKSR-102 Video Capture Board to perform the following kinds of recording while maintaining the high quality of the HDCAM-SR (1920 × 1080) format. • SR Motion: Provides slow and quick motion effects. •...

  • Page 74: Sr Motion

    6-1 SR Motion SR Motion has three functions as shown below. Name Features Supported cameras and required settings Select FPS Provides smooth slow and quick motion effects Cameras compatible with Select FPS function Page 78 without skipped frames. (such as F23). Set the number of frames shot per second (FPS) on the camera and set the system frequency (target frame frequency) for playback and the...
  • Page 75 Target frame 60 FPS 24 FPS frequency 23.98PsF (timecode 24F) System change SELECT FPS = OFF Timecode advances HDC-1500 SRW-1+SRPC-1 (with continuously. HKSR-102 installed) Playback: 1080/23.98PsF SRW-5000 HD DIGITAL VIDEO CASSETTE RECORDER SRW-5000/5500 6-1 SR Motion...
  • Page 76 Interval Frame recording at 4- 24 FPS 24 FPS frame intervals with other frames thinned out (6 FPS recording) Target frame frequency 23.98PsF HDC-1500 SRW-1+SRPC-1 (with HKSR-102 installed) Playback: 1080/23.98PsF SRW-5000 HD DIGITAL VIDEO CASSETTE RECORDER SRW-5000/5500 6-1 SR Motion...
  • Page 77 Relation between the system frequency at Operation of SRW-1 during slow and quick playback (target frame frequency) and the motion shooting number of frames shot During slow and quick motion shooting, input data is stored in the memory of the HKSR-102. Transfer of the To obtain the desired slow and quick motion effects, it is data to tape starts when a specified amount of data has necessary to set the appropriate number of frames...

  • Page 78: Select Fps Function

    6-1-1 Select FPS Function Relation between the number of frames Select FPS is a function for obtaining smooth slow or quick motion effects without skipped frames by adjusting shot and the number of playback frames the number of frames shot per second. This function is (outline of Select FPS) available on cameras such as F23.

  • Page 79: Note

    To set up the Select FPS function Perform the procedure in “Common Settings for SR Motion Shooting” (page 86) to set the target frame frequency and signal format. Rotate the SELECT/ENTER dial to select “SELECT FPS” in the submenu window. A setting window opens.

  • Page 80: Slow Shutter Function

    Store 3 frames (29.97PsF, 10 FPS). Transfer at 30P 1 NV NV 2 NV NV NV 4 NV 10 NV NV 11 NV: Ineffective frame SRW-1+SRPC-1+HKSR-101+HKSR-102 1 2 3 4 5 8 9 10 11 HKSR-102 Store only effective frames in memory.
  • Page 81 To set up the Slow Shutter function Perform the procedure in “Common Settings for SR Motion Shooting” (page 86) to set the target frame frequency and signal format. Rotate the SELECT/ENTER dial to select “SELECT FPS” in the submenu window. A setting window opens.

  • Page 82: Interval Frame Function

    HKSR-102 Selected frames Record only extracted frames onto tape (record with continuous 24F timecode). Converted to 23.98PsF when “SELECT FPS” is set to “OFF” SRW-1+SRPC-1+HKSR-102 Playback: 24P Playback at 24P 1 7 13 19 25 Cassette Quick motion at 6 times normal playback speed...

  • Page 83: S R W

    To set up the Interval Frame function SR Motion Recording Perform the procedure in “Common Settings for SR SYSTEM : 23.98PsF Motion Shooting” (page 86) to set the target frame SEL-FPS : 59.94P MODE : VTR 10.000 frequency and signal format. SIGNAL : 6 FRM MEMORY...
  • Page 84 Select the Ramp function operating mode from the following. End frame frequency Duration Start frame frequency Auto(Linear): Varies the frame frequency (frames) Frames recorded on tape linearly. Operating mode Auto(Inverse): Varies the inverse of the frame frequency (fps) linearly. SR Motion Recording Auto(Even): Varies the frame frequency so that there SYSTEM 23.98PsF...

  • Page 85: Rotate The Select/Enter Dial To Select A Channel

    SR Motion Recording L o a d U s r C u r v e [ *.CSV ] 2.09/3.81 MB Free : 45% used SYSTEM 23.98PsF < MSSONY PRO VTR SRW-1 > SEL-PPS 59.84P MODE 0 . 0 Ramp2.csv SIGNAL O FRM Ramp3.csv MEMORY...

  • Page 86: Common Settings For Sr Motion

    To vary the frame frequency manually Set the target frame frequency (”FRAME”) and signal format (”SIGNAL”) with reference to steps 3 to 5 in Set the frame frequency manually if you want to set upper the procedure of “To set with FORMAT” (page 61) in and lower frame frequency limits.
  • Page 87 Menu Settings State of SRW-1 Format 4 FPS 3 SELECT System 5 Format indication SD monitor FORMAT frame signal output 2 SIGNAL 1 FRAME freq. (Hz) frame (target frame frequency frequency (Hz) (playback timecode), 4:2:2 23.98 23/24 23.98 1080 S23PsF (23PsF) 23.98 525/59.94i 4:2:2...
  • Page 88 Menu Settings State of SRW-1 Format 4 FPS 3 SELECT System 5 Format indication SD monitor FORMAT frame signal output 2 SIGNAL 1 FRAME freq. (Hz) frame (target frame frequency frequency (Hz) (playback timecode), 23.98 23/24 23.98 1080 S23PsF (23PsF) 23.98 525/59 4:4:4 SQ...

  • Page 89: Timer Rec

    is effective for obtaining the maximum slow motion 6-2 Timer Rec effect. However, SD monitor output is disabled. Use HD monitor output. Select [SET] in the submenu window. The Timer Rec function allows you to use the memory of the optional HKSR-102 board to capture and record Note images at specified intervals.

  • Page 90: Auto Timer Rec

    A setting window opens. Rotate the SELECT/ENTER dial to specify the number of frames to record in one take. Put the unit into recording paused mode. SRW-1 KEYINHI RECINHI In Auto Timer Rec mode, “T” appears on the HOME screen before the number of lines of the signal format. IN: --:--:--:-- LOCAL 1080...

  • Page 91: Cache Rec

    When the Cache Rec function is active, “C” appears on 6-3 Cache Rec the HOME screen before the number of lines of the signal format. The Cache Rec function captures about 100 frames of the video and audio that the camera is currently shooting (or about 200 frames in 50P or 59P mode) to the memory of the HKSR-102 option board.
  • Page 92 depending on whether the SR Motion is used for recording. The following table shows how many seconds of data are recorded in advance of the time that the REC button is pressed. (The values shown are approximate and obtained when the frame frequency is 1080/59P.) Status of this unit Recording start timing Standby on mode Standby off mode Not using SR...

  • Page 93: Appendixes

    Refer to the HKSR-101 Installation Manual for the inserted tape with reference to the Maintenance information about cleaning the optical-fiber connector. Manual and check the tape, for example, for moisture and adhesion of sticky substances, or contact a Sony service representative. Maintenance and Inspections...

  • Page 94: Note About The Battery Terminal

    SRPC-1 Approx. 35 W If you notice bending, deformation, or surface corrosion, Operating temperature contact your dealer or a Sony service representative as 0ºC to 40ºC (32ºF to 104ºF) soon as possible to have the battery terminal replaced. Storage temperature Periodic inspections are recommended to keep the unit –20ºC to +60ºC (–4ºF to +140ºF)

  • Page 95: Digital Video System

    TC OUT BNC type (×1) 1.0 Vp-p (75 Ω), 2.2 Vp-p (10 kΩ) Analog output D/A quantization 24 bits/sample SRPC-1 Frequency response HD SDI OUT A, B 20 Hz to 20 kHz +0.5dB/–1.0 dB (at BNC type (×2) reference level)

  • Page 96: Other Connectors

    • Always make a test recording, and verify that it was HKSR-102 Picture Cache Board recorded successfully. RCC-5G 9-pin Remote Control Cable SONY WILL NOT BE LIABLE FOR DAMAGES OF HKSR-103 RGB 60P Processor Board ANY KIND INCLUDING, BUT NOT LIMITED TO, COMPENSATION OR REIMBURSEMENT ON...

  • Page 97: Error Messages And Warning Messages

    When an error message appears Eliminate the cause of the error, and power the system off and on again. If the same error message appears again when the system is powered on, contact a Sony service representative. To close the error message popup window Press the HOME button or the BACK button on the control panel.

  • Page 98: Error Messages

    Error messages Refer to the Maintenance Manual for more detailed information about the content of error messages, and about errors not listed here. Code Message Description SRW-1 error SRPC-1 error 0010 0110 FAN STOP A cooling fan stopped. 0011 0111 0012 —...

  • Page 99: About Warning Messages

    When an SRW-1 error is detected, the error code is displayed following the indication “VTR:”. Example: b) When an SRPC-1 error is detected, the error code is displayed following Popup window displaying warning message the indication “VA:”. “VTR: 0010 TELEFILE FULL”...

  • Page 100: Warning Messages

    DC voltage has fallen below the specified level. 000E 010E TEMPERATURE HIGH The temperature inside the unit has risen. 000F — VA MISSING SRPC-1 is not connected. — 010F VTR MISSING SRW-1 is not connected. 0010 — TELEFILE FULL Telefile memory is almost full. The next recording will erase existing data, beginning with oldest.

  • Page 101: Hksr

    CASSETTE REC INHI The cassette is record-protected. a) When an SRW-1 warning occurs, the warning code is displayed following the indication “VTR:”. b) When an SRPC-1 warning occurs, the warning code is displayed following the indication “VA:”. Error Messages and Warning Messages...

  • Page 102: Warning System

    “Warning (page messages” 100) — Servo lock lost Recording Turn off the power during recording. continues, but the and contact a Sony results may be service invalid. representative. — An error occurred Continues Check the warning (Excepting “0050 operation or stops, message, and NO REC RF”).
  • Page 103 Warning tones Alarm tones Tally indicator Description VTR (SRW-1) Steps to take : 1 beep/ : 1 beep/ behavior : 1 flash/second second second : 4 flashes/ : 4 beeps/ : 4 beeps/ second second second Continuous Continuous tone tone —...

  • Page 104: Attaching The Shoulder Belt

    How to attach Attaching the Shoulder Belt Attach the supplied shoulder belt as shown in the figure below. Clip Note If you fit the shoulder belt incorrectly, the unit may fall down and cause body injury. Follow the procedures described below to fit or remove the shoulder belt. Pull the belt up and secure it firmly.

  • Page 105: Troubleshooting

    The SRW-1 is not powered on. The system does not operate properly when the SRW-1 is not powered on, even if the SRPC-1 is powered on. Check the power switches. Check with the operation panel. Picture color is wrong.
  • Page 106 The SRW-1 software does not Upgrade to a version that supports the Select FPS function. support the Select FPS function. (Contact a Sony service representative.) The Select FPS function is not Enable the Select FPS function on both the camera and the enabled on either the camera or the VTR.
  • Page 107 Audio Problem Cause Steps to take • No sound. The display of the SDI or AES/EBU Set up the input device to output SDI or AES/EBU audio. meter is flashing, and the input is • AUDIO PLL UNLOCK invalid. appears. Mode switching.
  • Page 108 • VTR does not power on. The VTR power switch is not on. Turn the VTR power switch on. • “VTR MISSING”, “VA The SRW-1 and SRPC-1 are not Check the SRW-1 and SRPC-1 assembly. MISSING” appears. completely connected. Low voltage.

  • Page 109: About Recording/Playback Tape Formats

    PB (Slow): Slow motion playback only PB (S/Q): Slow motion or quick motion playback Tape Format No. of Signal Scanning System Recording SRW-1 SRW-5000/5500 Effective System frame Rate +SRPC-1 (440Mbps) Lines frequency (VideoNET) (440/ 880Mbps) HDCAM-SR 1080 4:2:2 Interlaced 440Mbps 29.97 23.98 29.97...

  • Page 110: About Recording/Playback Tape Formats

    Tape Format No. of Signal Scanning System Recording SRW-1 SRW-5000/5500 Effective System frame Rate +SRPC-1 (440Mbps) Lines frequency (VideoNET) (440/ 880Mbps) HDCAM-SR 1080 4:4:4 RGB Interlaced 880Mbps (HQ) 29.97 23.98 29.97 4:2:2 23.98 440Mbps PB (S/Q) with audio 4:4:4RGB(SQ) SELECT FPS: muted 4:2:2×2...

  • Page 111: What Is Dual Link

    Dual Link What Is Dual Link? Dual Link enables input and output of HD SDI signals over two BNC cables. With Dual Link, you can do the following. • Handle different color spaces For HD SDI signal input/output, the SRW-1 supports Dual Dual Link allows you to expand color difference signals Link in addition to the normal Single Link.

  • Page 112: List Of Camera Combinations And Available Functions

    1 to 30 1 to 30 Effects Effects Frame capture (Interval Frame mode) Afterimaging (Select FPS mode/Slow Shutter mode) Smooth motion (Select FPS mode) a) Available by special order. (For details, contact your Sony representative.) b) Discontinued List of Camera Combinations and Available Functions...

  • Page 113: Monitor Lut Function

    “Memory Stick”. The Monitor LUT (Look Up Table) function is available when the SRW-1 is combined with the SRPC-1 and is in Rotate the SELECT/ENTER dial to select a LUT file, separate operation with the F23 camera. If you are using S- and then press the dial.
  • Page 114 that exceed the HD video level range (10-bit signal L U T S t a t u s levels, 4 to 1019 steps). BANK0:709ToCineon.lut BANK1:SlogHG2_Lustre.lut BANK2:DEFAULT BANK3:SlogTo709_Lustre.lut Video converted on the basis of the selected LUT is output. When LUT conversion is performed for monitor output, “(LUT)”...
  • Page 115 Note V i d e o S e t u p LUT(Monitor) This unit supports 10-bit data only. If a LUT file PD(MON) LUT MODE BANK3 LUT STATUS MON SEL(x2) containing 12-bit data is loaded, the most significant 10 LUT LOAD VIDEO I/O LUT SAVE LUT(MON)

  • Page 116: Mpeg-4 Visual Patent Portfolio License

    MPEG-4 VISUAL PATENT PORTFOLIO LICENSE THIS PRODUCT IS LICENSED UNDER THE MPEG-4 VISUAL PATENT PORTFOLIO LICENSE FOR THE PERSONAL AND NON-COMMERCIAL USE OF A CONSUMER FOR (i) ENCODING VIDEO IN COMPLIANCE WITH THE MPEG-4 VISUAL STANDARD (“MPEG-4 VIDEO”) AND/OR (ii) DECODING MPEG-4 VIDEO THAT WAS ENCODED BY A CONSUMER ENGAGED IN A PERSONAL AND NON-COMMERCIAL ACTIVITY AND/OR WAS OBTAINED FROM A VIDEO...

  • Page 117: Index

    20 Connector panel 17 AES/EBU OUTPUT CH1-12 Control panel 11 connector 20 Control panel connection cable 12 Joining the SRW-1 and SRPC-1 22 Assembly 22 Control panel extension cable 24 Assist lever 20 CTRL PANEL connector 17 AUDIO button 12...
  • Page 118 71 position 38 Playback operations 71 System configuration 9 POWER ON/OFF switch SYSTEM Setup menu 54 on SRPC-1 20 on SRW-1 18 Power saving mode 43 Power supply 35 Tally indicator 11 Power, checking 36 Tape protection mode 97...
  • Page 119 The material contained in this manual consists of information that is the property of Sony Corporation and is intended solely for use by the purchasers of the equipment described in this manual. Sony Corporation expressly prohibits the duplication of any...
  • Page 120 Sony Corporation SRW-1 Printed in Japan SRPC-1 http://www.sony.net/ 2008.07.13 (SY) © 2004 Printed on recycled paper. 3-854-913-07 (1)

This manual is also suitable for:

Srw-1Hksr-101Hksr-102Hksr-103

Table of Contents
