- Page 1 BMCI300SS 30 Litre, Combination Built-in Microwave Oven with Convection & Grill...
- Page 2 MODEL: BMCI300SS Microwave Oven Owner's Manual Please read these instructions carefully before installing and operating the oven. Record in the space below the SERIAL NO. found on the nameplate on your oven and retain this information for future reference.
-
Page 3: Table Of Contents
Do not attempt to operate this oven with the door open since open door operation can result in harmful exposure to microwave energy. It is important not to adjust or tamper with the safety interlocks. Do not place any object between the oven front face and the door or allow food or cleaner residue to accumulate on sealing surfaces. -
Page 4: Precautions To Avoid Possible Exposure To Excessive Microwave Energy
When using electrical appliance basic safety precautions should be followed, including the following: WARNING: To reduce the risk of burns, electric shock, fire, injury to persons or exposure to excessive microwave energy: Read all instructions before using the appliance. Use this appliance only for its intended use as described in this manual. Do not use corrosive chemicals or vapours in this appliance. -
Page 5: Specifications
230V-240V~50Hz, 1400W(Microwave) Power Consumption: 1250W(Grill) Power Consumption (Convection) 2200V Microwave Power Output: 900W Operation Frequency: 2450MHz Outside Dimensions: 354mm(H)×539mm(W)×390mm(D) Oven Cavity Dimensions: 240mm(H)×354mm(W)×358mm(D) Oven Capacity: 30Litres Cooking Uniformity: Turntable System Net Weight: Approx. 18.4kg Make sure that all the packing materials are removed from the inside of the door. WARNING: WARNING: Check the oven for any damage, such as misaligned or bent door, damaged door seals and sealing surface, broken or loose door hinges and latches and dents inside the cavity or on the door. -
Page 6: Grounding Instructions
This appliance must be grounded. This oven is equipped with a cord having a grounding wire with a grounding plug. It must be plugged into a wall receptacle that is properly installed and grounded. In the event of an electrical short circuit, grounding reduces risk of electric shock by providing an escape wire for the electric current. -
Page 7: Microwave Cooking Principles
The ideal material for a microwave utensil is transparent to microwave, it allows energy to pass The ideal material for a microwave utensil is transparent to microwave, it allows energy to pass through the container and heat the food. through the container and heat the food. Microwave can not penetrate metal, so metal utensils or dishes with metallic trim should not be Microwave can not penetrate metal, so metal utensils or dishes with metallic trim should not be used. - Page 8 LED DISPLAY SCREEN Cooking time, power, action indicators, and clock time are displayed. POWER Touch this button to set microwave cooking power level. CONVECTION Press to program convection cooking. MICRO+CONVECTION Press to use combination cooking settings. ...
-
Page 9: How To Set The Oven Controls
ETTING DIGITAL CLOCK With the oven is in standby, touch the CLOCK/TIME button once or twice to set the digital clock in 12 or 24 hours cycle. FOR EXAMPLE: Suppose you want to set the oven clock time to 8:30. In standby mode, press and hold down CLOCK /TIME for 3 seconds to select 24-hour clock. -
Page 10: Quick Start
UICK START This feature allows you to start cooking immediately. In standby mode, press the TIME/MENU/WEIGHT dial and the microwave starts working at full power level immediately. Repeatedly press this button to increase the cooking time. The longest cooking time you can set is 10 minutes. -
Page 11: Micro+Convection
ICRO ONVECTION This oven has four pre-programmed settings that make it easy to cook with both convection and microwave heat. MICRO+CONVECTION Press button to program convection temperature: Touch Temperature(℃) COMB1 Once COMB2 Twice COMB3 3 times COMB4 4 times Suppose you want to cook for 24 minutes on COMB3. Open the oven door, place the food inside and close the door. -
Page 12: Jet Defrost
ET DEFROST FOR EXAMPLE: Suppose you want to defrost frozen food for 10 minutes. Place the food inside and close the door. Rotate TIME/MENU/WEIGHT dial to choose Code 09. Press START/QUICK START button. Turn the TIME/MENU/WEIGHT to enter cooking time. Press START/QUICK START button. -
Page 13: Automatic Protection Mechanism
UTOMATIC PROTECTION MECHANISM RROR CODES If the oven senses an error it will stop working and display an error code. If you see one of the below error codes you should stop using your appliance. You can leave the door closed and leave your food inside, and there is no need to unplug your appliance. -
Page 14: Cleaning And Care
Turn off the oven and remove the power plug from the wall socket before cleaning. Keep the inside of the oven clean. When food splatters or spilled liquids adhere to oven walls, wipe with a damp cloth. Mild detergent may be used if the oven gets very dirty. Avoid the use of spray and other harsh cleaners as they may stain, streak or dull the door surface. - Page 15 Built-in installation instructions: Cabinet Frame fastener (x2) Heat channel Microwave oven Frame kit Screw 4x10 (x4) Screw 4x8 (x4) Screw 4x16 (x4)
- Page 16 Make a cut out in the cabinet as per the below dimensions: Turn the oven over and place on a cushioned surface. Then attach the feet...
- Page 17 Fasten the heat channel to the top of the microwave using the 4 screws (4x8). Fasten the frame kit to the front of the microwave using the screws provided (4x10):...
- Page 18 Attach the 2 frame fasteners to the cabinet using the screws provided (4 x 4x16) Install the microwave into the aperture, ensuring the clips on the frame kit secure to the frame fasteners. You can adjust the feet to aid in alignment.
- Page 19 Ensure that the oven is central Installation complete.
- Page 20 IMPORTANT: If your appliance appears not to be operating correctly, then you should disconnect it from your mains supply and then contact the Customer Care Department. DO NOT ATTEMPT TO REPAIR THE APPLIANCE YOURSELF. Please note that if an engineer is asked to attend whilst the product is under guarantee and finds that the problem is not the result of an appliance fault, then you may be liable for the cost of the call out charge.
- Page 23 United Kingdom Czech Republic Baumatic Ltd., Baumatic CR spol s.r.o. Baumatic Buildings, Lípovà 665 6 Bennet Road, 460 01 Liberec 4 Reading, Berkshire Czech Republic RG2 0QX United Kingdom +420 483 577 200 www.baumatic.cz Sales Telephone (0118) 933 6900 Slovakia Sales Fax Baumatic Slovakia, s.r.o.
