Class H Fitness Product
Model No. WETL11140
Serial No.
Serial Number Decal
QUESTIONS?
As a manufacturer, we are com-
mitted to providing complete
customer satisfaction. If you
have questions, or if there are
missing or damaged parts,
please call:
08457 089 009
Or write:
ICON Health & Fitness, Ltd.
Unit 4
Revie Road Industrial Estate
Revie Road, Beeston
Leeds, LS11 8JG
UK
csuk@iconeurope.com
CAUTION
Read all precautions and instruc-
tions in this manual before using
this equipment. Save this manual
for future reference.
USER'S MANUAL
Visit our website at
www.iconeurope.com
Advertisement
Table of Contents
Related Manuals for Weslo WETL11140
Summary of Contents for Weslo WETL11140
- Page 1 Class H Fitness Product Model No. WETL11140 USER’S MANUAL Serial No. Serial Number Decal QUESTIONS? As a manufacturer, we are com- mitted to providing complete customer satisfaction. If you have questions, or if there are missing or damaged parts, please call:...
-
Page 2: Table Of Contents
ORDERING REPLACEMENT PARTS ..........Back Cover WESLO is a registered trademark of ICON IP, Inc. -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of burns, fire, electric shock, or injury to persons, read the following important precautions and information before operating the treadmill. 1. It is the responsibility of the owner to ensure 11. If an extension cord is needed, use only a 3- that all users of this treadmill are adequately conductor, 1mm (14-gauge) cord that is no... - Page 4 DANGER: other than the procedures in this manual Always unplug the power should be performed by an authorised service cord immediately after use, before cleaning representative only. the treadmill, and before performing the main- tenance and adjustment procedures de- 23. This treadmill is intended for in-home use scribed in this manual.
-
Page 5: Before You Begin
The model number of the treadmill the convenience and privacy of your home. And when is WETL11140. The serial number can be found on a you’re not exercising, the unique CADENCE 55 tread- decal attached to the treadmill (see the front cover of mill can be folded up, requiring less than half the floor this manual for the location of the decal). -
Page 6: Assembly
2 3/4” Bolt (47 )–4 ASSEMBLY Assembly requires two persons. Place a mat under the treadmill to protect the floor during assembly. Set the treadmill in a cleared area and remove all packing materials. Do not dispose of the packing materials until as- sembly is completed. - Page 7 2. Identify the Right Upright (37), which has a large round hole near the lower end, and the Left Upright (32). Hole See drawing 2a. Make sure that there are two U-nuts 32, 37 (93) in the lower end of each Upright (32, 37). See drawing 2b.
- Page 8 5. See the inset drawings and identify the two Crossbar Small Bracket Screws (86); be careful not to confuse the Crossbar Screws with the 3/4” Screws (77). The Crossbar Screws are slightly larger than the 3/4” Screws. Hold the Crossbar (65) on the small brackets on the Handrails (4, 5).
- Page 9 8. Hold the Console (2) near the Console Base (45). Touch the Right Handrail (5) to discharge any static. Find the connector on the end of the Wire Harness (53). Ties Insert the connector into the red socket beneath the Console.
- Page 10 11. Attach the Latch Housing (25) and the Latch Spacer (99) to the Left Upright (32) with two 3/4” Screws (77). Next, remove the latch knob from the latch pin. Make sure that Knob the collar and the spring are on the pin, and insert the pin into the Latch Housing.
-
Page 11: Operation And Adjustment
OPERATION AND ADJUSTMENT THE PERFORMANT LUBE WALKING BELT , a high-performance lubricant. IMPOR- Your treadmill features a walking belt coated with PERFORMANT LUBE TANT: Never apply silicone spray or other substances to the walking belt or the walking platform. Such substances will deteriorate the walking belt and cause excessive wear. - Page 12 CONSOLE DIAGRAM Displays Note: If there is a thin sheet of plastic on the console, remove it. Clip slide the clip onto the waistband of your clothes. CAUTION: Before operating the Insert the key fully into the console. After a moment, console, read the following precautions.
- Page 13 To stop the walking belt, press the Stop button. When you are finished exercising, remove the The elapsed time will begin to flash in the Time key. display. Step onto the foot rails, press the Stop button, and Note: During the first few minutes that the tread- remove the key from the console.
-
Page 14: How To Fold And Move The Treadmill
HOW TO FOLD AND MOVE THE TREADMILL HOW TO FOLD THE TREADMILL FOR STORAGE Unplug the power cord. CAUTION: You must be able to safely lift 20 kg (45 lbs.) to raise, lower, or move the treadmill. 1. Hold the treadmill with your hands in the locations shown at the right. - Page 15 HOW TO LOWER THE TREADMILL FOR USE 1. Hold the upper end of the treadmill with your right hand as shown. Using your left hand, pull the latch knob to the left and hold it. Pivot the treadmill down until the frame is past the latch pin.
-
Page 16: Maintenance And Troubleshooting
MAINTENANCE AND TROUBLESHOOTING Most treadmill problems can be solved by following the steps below. Find the symptom that applies, and follow the steps listed. If further assistance is needed, please call our Customer Service Department. PROBLEM: The power does not turn on SOLUTION: a. - Page 17 PROBLEM: The walking belt slows when walked on SOLUTION: a. If an extension cord is needed, use only a 3-conductor, 1mm (14-gauge) cord that is no longer than 1.5 m (5 ft.). b. If the walking belt is overtightened, treadmill perfor- mance may decrease and the walking belt may be- 5–7 cm come damaged.
-
Page 18: Conditioning Guidelines
CONDITIONING GUIDELINES is activity that requires large amounts of oxygen for prolonged periods of time. This increases the demand WARNING: Before beginning on the heart to pump blood to the muscles, and on the this or any exercise program, consult your lungs to oxygenate the blood. - Page 19 EXERCISE FREQUENCY tween workouts. After a few months, you may com- plete up to five workouts each week if desired. The key To maintain or improve your condition, complete three to success is to make exercise a regular and enjoyable workouts each week, with at least one day of rest be- part of your everyday life.
- Page 20 NOTES...
-
Page 21: Part List
PART LIST—Model No. WETL11140 R0105A Hood Motor Tension Washer Console Left Foot Rail Motor Belt Wheel Nut/Motor Nut Left Handrail Belt Guide Right Handrail Wire Clip Grounding Nut Right Foot Rail Motor Crossbar Reed Switch Latch Catch Electronics Screw Incline Leg Endcap Reed Switch Clip 5/16”... -
Page 22: Exploded Drawing
EXPLODED DRAWING—Model No. WETL11140 R0105A... - Page 23 EXPLODED DRAWING—Model No. WETL11140 R0105A...
-
Page 24: Ordering Replacement Parts
When ordering parts, please be prepared to give the following information: • the MODEL NUMBER of the product (WETL11140) • the NAME of the product (WESLO CADENCE 55 treadmill) • the SERIAL NUMBER of the product (see the front cover of this manual) •...
