- Page 1 CDX-497/397 COMPACT DISC PLAYER LECTEUR COMPACT DISQUE OWNER’S MANUAL MODE D’EMPLOI BEDIENUNGSANLEITUNG BRUKSANVISNING MANUALE DI ISTRUZIONI MANUAL DE INSTRUCCIONES GEBRUIKSAANWIJZING ИНСТРУКЦИЯ ПО ЭКСПЛУАТАЦИИ...
- Page 2 12 Only voltage specified on this unit must be used. Using this unit with a higher voltage than specified is dangerous and may cause Blue: NEUTRAL fire, damage to this unit, and/or personal injury. YAMAHA will Brown: LIVE not be held responsible for any damage resulting from use of this unit with a voltage other than specified.
-
Page 3: Table Of Contents
CONTENTS FEATURES ............2 RANDOM-SEQUENCE PLAY ...... 12 SUPPORTED DISC TYPES ......2 REPEAT PLAY ..........12 UNPACKING ............ 3 Repeat a selected item ......12 Repeat A-B ..........13 NOTES ABOUT THE REMOTE CONTROL ............3 PROGRAM PLAY ......... 14 CONNECTIONS .......... -
Page 4: Features
Thank you for selecting this YAMAHA compact disc player. FEATURES CD-R,CD-RW Disc Playability Automatic Peak Level Search Function (For details, refer to page 22.) CD Synchronized Recording CD-TEXT Data Display capability Adjustable Display Brightness Program Play Remote Control Capability Random-Sequence Play... -
Page 5: Unpacking
UNPACKING Carefully remove this unit and accessories from the box. You should find the unit itself and the following accessories. Remote control Audio pin cable (CDX-397) (CDX-497) OPEN/CLOSE OPEN/CLOSE INDEX INDEX DIMMER RANDOM DIMMER RANDOM REPEAT A–B PROGRAM CLEAR REPEAT A–B PROGRAM CLEAR... -
Page 6: Connections
CONNECTIONS ● Before making any connection, switch OFF the power to ● If the placement of this unit causes noise to another the unit and the amplifier or other component. equipment, such as a tuner, separate them from each ● Connections should be made to the correct input other. -
Page 7: Identification Of Components
IDENTIFICATION OF COMPONENTS ) indicates the page number on which the controls are best described. Front panel The control functions on the main unit and on the remote control are virtually identical, with the exceptions below. POWER (p. 7) Disc tray (p. 7) (play/pause) (p. -
Page 8: Remote Control
Remote control ) ) ) ) ) OPEN/CLOSE (p. 7) OPEN/CLOSE Numeric buttons (p. 8) INDEX (p. 15) INDEX DIMMER RANDOM RANDOM (p. 12) DIMMER (p. 11) REPEAT A–B PROGRAM CLEAR REPEAT (p. 12) CLEAR (p. 15) A-B (p. 13) PROGRAM (p. -
Page 9: Basic Operation
This manual describes how to operate this unit by using the remote control. To operate this unit from the front panel, use the corresponding buttons on the front panel. BASIC OPERATION 2, 3 OPEN/CLOSE SYNCHRO TAPE SEARCH Press POWER to turn on the power. Press OPEN/CLOSE to close the disc tray. -
Page 10: To Pause Playback
To pause playback To turn off the power Press Press POWER again. * If you turn on the power again with a disc still on the tray, the playback starts automatically from the first track. To play back the desired track To resume the playback, press again (or press Select a desired track by using the numeric buttons. -
Page 11: To Skip To The Beginning Of The Desired Track (Skip Search)
To skip to the beginning of the desired track (Skip search) ● These operations can also be performed when the unit is To play back from the beginning of the next track paused or stopped. ● Pressing and holding ) on the remote control skips tracks continuously toward lower (or higher) numbers. -
Page 12: Changing Display
Changing display ■ When playing back an Audio CD 1 - 4) TIME/INFO You can select the following displays ( by pressing . When you play back a CD-TEXT disc, the disc title, artist name, and track name ( – ) are also displayed. -
Page 13: Changing Brightness Of The Display
Changing brightness of the display You can change brightness of the display Normal illumination in three degrees by pressing DIMMER. DIMMER Slightly dim Automatic spacing If you record a disc onto tape with an insufficient time space between tracks, the tape deck will not be able to perform blank search operations on the tape correctly. -
Page 14: Random-Sequence Play
RANDOM-SEQUENCE PLAY You can play back the tracks on a disc in a random sequence. Note To perform random-sequence play If the power is switched off during random-sequence play, Press RANDOM. pressing POWER again to turn on the unit automatically restores random-sequence play. -
Page 15: Repeat A-B
Repeat A-B You can repeat the specified section of the disc by setting two points (start and end point). To cancel the repeat A-B Press A-B to select the start point of repeat play. ” ” ” ” B” disappears from the Press A-B repeatedly until “A”... -
Page 16: Program Play
PROGRAM PLAY You can enjoy listening to your favorite tracks in any desired order by programming tracks. 40 tracks can be programmed in sequence. SYNCHRO TAPE PEAK SPACE SEARCH INDEX DIMMER RANDOM 2, 4 TIME/INFO REPEAT A–B PROGRAM CLEAR FOLDER Press to stop the playback. -
Page 17: Index Search
To stop program playback To check program data Press . The first programmed track number is displayed. 1. If during program play, press 2. Press PROGRAM. To resume program play, press . The playback starts 3. Each time is pressed, the track numbers and from the first programmed track number. -
Page 18: Track Programming For Recording To Tape
TRACK PROGRAMMING FOR RECORDING TO TAPE The unit can program tracks on a disc for recording onto tape. By considering the total possible recording time of the tape, the unit automatically programs tracks or help you program tracks so they fits onto the tape with the least amount of unrecorded space at each end of the tape. - Page 19 Notes ● In step 4, you can check the program data for side A and side B after pressing REPEAT. Information for each side is displayed for 3 seconds. PROG. Shows the number of programmed tracks. Shows the total time of programmed tracks. Shows the side of the tape.
-
Page 20: Manual Tape-Programming (For Audio Cd)
Manual tape-programming (for Audio CD) This is for recording desired tracks in any order onto a tape. DIMMER RANDOM REPEAT A–B PROGRAM CLEAR 3, 5 SYNCHRO TAPE PEAK SPACE INDEX DIMMER RANDOM SEARCH 7, 8 REPEAT A–B PROGRAM CLEAR SYNCHRO TAPE PEAK SPACE... -
Page 21: Random Sequential Tape-Programming (For Audio Cd)
Random sequential tape-programming (for Audio CD) The unit automatically programs tracks in random sequential order for recording to tape. DIMMER RANDOM REPEAT A–B PROGRAM CLEAR SYNCHRO TAPE PEAK SPACE SEARCH 3, 4 TIME/INFO FOLDER Notes ● Because programmed data changes every time RANDOM is Follow steps 1 –... -
Page 22: Automatic Searching For The Peak Level On A Disc (For Audio Cd)
Automatic searching for the peak level on a disc (for Audio CD) This unit automatically searches for the peak level of the disc, and play back the part repeatedly. When recording to tape, this feature is very helpful for adjusting the recording level on the tape deck. To cancel the peak level search function Press Press... -
Page 23: Cd Synchronized Recording
This unit can automatically synchronize a tape deck recording with CD play. With this function, you can record a CD on tape easily and precisely. This recording method requires a YAMAHA tape deck compatible with this function. (Refer to the tape deck operation manual to find out whether it is compatible or not.) * This unit and the tape deck must be placed close to each other so that both of them can simultaneously receive the signals from the remote control of this unit. -
Page 24: Notes About Discs
NOTES ABOUT DISCS Notes about handling compact discs Discs playable with this unit ● Always handle the disc with care so that This compact disc player is designed only for playing back its surface is not scratched. compact discs bearing the marks shown below. Never attempt to load any other type of disc into the unit. -
Page 25: Troubleshooting
If the unit fails to operate normally, check the following points to determine whether the fault can be corrected by the simple measures suggested. If it cannot be corrected, or if the fault is not listed in the SYMPTOM column, disconnect the power cord and contact your authorized YAMAHA dealer or service center for help. SYMPTOM... -
Page 26: Specifications
SPECIFICATIONS Audio Section General Frequency response ..... 2 Hz – 20 kHz, ± 0.5 dB Power requirements Australia model .......... 240 V, 50 Hz Harmonic distortion + noise (1 kHz) Europe and U.K. models ..... 220-240 V, 50 Hz ..............0.003 % or less General model .... - Page 27 CAUTION VISIBLE AND INVISIBLE LASER RADIATION WHEN OPEN. AVOID EXPOSURE TO BEAM. ADVARSEL SYNLIG OG USYNLIG LASERSTRALING VED ÅBNING. UNDGÅ UDSÆTTELSE FOR STRÅLING. ADVARSEL SYNLIG OG USYNLIG LASERSTRÅLING NÅR DEKSEL ÅPNES. UNNGÅ EKSPONERING FOR STRÅLEN. VARNING SYNLIG OCH OSYNLIG LASERSTRÅLNING NÄR DENNA DEL ÄR ÖPPNAD.
