GENERAL
Power requirement
Power consumption
Temperature
Operating position
Dimensions (W
Maximum recording time
VIDEO/AUDIO (VHS deck)
Signal system
Recording system
Signal-to-noise ratio
Horizontal resolution
Frequency range
VIDEO/AUDIO (DVD deck)
Signal system
Applicable disc
Audio characteristics
Frequency response
Wow and flutter
Dynamic range
Output
Component-Y
Component- PB /PR
Digital Audio
TUNER/TIMER(VHS deck)
TV channel storage capacity
Tuning system
Channel coverage
Aerial output
Program capacity
Memory backup time
ACCESSORIES
Provided accessories
Specifications shown are for SP mode unless otherwise specified.
E.& O.E. Design and specifications subject to change without notice.
Manufactured under license from Dolby Laboratories. "Dolby" and the double-D symbol are trademarks of Dolby Laboratories.
"DTS" and "DTS2.0+ Digital Out" are trademarks of Digital Theater Systems, Inc.
G-CODE is a trademark of Gemstar Development Corporation and is registered in the following countries: Australia, China, Hong
Kong, Japan, South Korea, New ealand, and Taiwan. SHOWVIEW is a trademark of Gemstar Development Corporation and is reg-
istered in the following countries:Austria, Belgium, Czech Republic, Denmark, Finland, France, Germany, Hungary, Iceland, Italy,
Luxembourg, Netherlands, Norway, Poland, Portugal, Russia, Slovakia, South Africa, Spain, Sweden and Switzerland. The G-
CODE/SHOWVIEW system is manufactured under license from Gemstar Development Corporation.
G-CODE and SHOWVIEW are different trademarks used to represent the same easy recording feature. However, for simplicity,
only the term G-CODE will be used in the instructions. If you use SHOWVIEW system, follow the same steps listed for the G-CODE
system.
1-2 (No.YD055)
SPECIFICATION
Power on
Power off
Operating
Storage
×
H × D)
Weight
Format
(SP)
(LP)
(EP)
PAL-type colour signal and CCIR monochrome signal, 625 lines/50 fields
70 Hz to 10,000 Hz (Normal audio) 20 Hz to 20,000 Hz (Hi-Fi audio)
Input/Output
S/N Ratio
Audio
AC 110 V - 240 V, 50 Hz/60 Hz
23 W
4.5 W
5°C to 40°C
-20°C to 60°C
Horizontal only
435 mm × 93 mm × 272 mm
4.2 Kg
VHS PAL/NTSC standard
240 min. with E-240 video cassette(PAL/MESECAM)
160 min. with T-160 video cassette(NTSC)
480 min. with E-240 video cassette(PAL/MESECAM)
480 min. with T-160 video cassette(NTSC)
NTSC colour and EIA monochrome signal, 525 lines/60 fields.
DA4 (Double Azimuth) head helical scan system
45 dB
250 lines (PAL/MESECAM), 220 lines (NTSC)
RCA connectors: IN
NTSC 3.58
DVD (12 cm, 8 cm), CD (12 cm, 8 cm)
DVD:4 Hz - 22 KHz
CD:4 Hz - 20 KHz
90 dB
Below Measurable Level
90 dB
(RCA) 1.0 Vp-p/75 Ω
(RCA) 0.7 Vp-p/75 Ω
(RCA) 2 Vrms, 1 KΩ
-21 dBm to -15 dBm(peak)
99 positions (+AUX position)
Frequency synthesized tuner
VHF(low) : 42 MHz-175 MHz
VHF(high) : 175 MHz-470 MHz
UHF : 470 MHz-870 MHz
UHF channels (Adjustable E28-E60)
1-year programmable timer / 8 programs
Approx. 10 min.
RF cable, Infrared remote control unit, "R6" battery × 2
×
2, OUT × 1
