INTRODUCTION
Congratulations! By purchasing our Oregon Scientific
whatever daytime or night. We hope it could help you easily acquire activity data and transfer it to your mobile app through Bluetooth Smart (Bluetooth Low Energy). From now
on, you can easily and systematically track your activity volume and sleep quality on a daily basis. Some of its features include:
•
Detachable smart core
•
Anti-dust and adjustable strap
The activity tracker is currently compatible with iPhone 4S and advanced version / iPod touch (5
NOTE
This manual contains important safety and care information, and provides step-by-step instructions for using this product. To get the greatest benefit from your purchase,
read the manual thoroughly, and keep it in a safe place in case you need to later refer to it.
PACkAgE ITEMS
The package should include the following items:
•
x Activity tracker
•
x Charger pod
•
1 x Oregon Scientific
warranty card
TM
•
x Quick start guide
OVERVIEW
4
ChARgINg AND INDICATORS
Before you start using the activity tracker, please charge it for at least 1 hour.
1. Un-route the USB cable from the charger pod.
2. Align the two metal connection points of the charger pod with the pair on the smart core.
3. Make the connection points approach to each other by magnetic until they are completed connected.
4. Plug the big end of the USB cable into USB port of your PC.
PE128_UM_EN_R16.indd 1
24/7 Activity Tracker
Model: PE128
User Manual
Ssmart Dynamo 24/7 Activity Tracker (PE128), you've made the first step toward taking control of your all-day activities,
TM
1
2
3
5
1
th
Gen) / iPad 3 that is with logo
1. LED Indicator
2. Operational button
3. Snap buttonholes
4. Snap buttons
5. Smart core
2
to achieve reliable transmission linkage.
SMART READY
3
2013/8/22 11:26:53 AM
4
Advertisement
Table of Contents
Related Manuals for Oregon Scientific Smart Dynamo PE128
Summary of Contents for Oregon Scientific Smart Dynamo PE128
- Page 1 User Manual INTRODUCTION Congratulations! By purchasing our Oregon Scientific Ssmart Dynamo 24/7 Activity Tracker (PE128), you’ve made the first step toward taking control of your all-day activities, whatever daytime or night. We hope it could help you easily acquire activity data and transfer it to your mobile app through Bluetooth Smart (Bluetooth Low Energy). From now on, you can easily and systematically track your activity volume and sleep quality on a daily basis.
-
Page 2: Get Started
5. Once the smart core is correctly connected with the charger pod, the indicator turns on. Indicators Status Action Red is on Charging To keep the smart core charged, connect it with the charger pod when not in use. Green is on Charging completed Remove the charger pod from the smart core. -
Page 3: User Profile
USER PROfIlE Once your application successfully connects to the smart core through Bluetooth (first time only), you will automatically enter Profile screen. Tap on each arc to complete individual setting, such as gender, height and measure unit (cm or inch), Weight and (kg or lb), Age (birthday), Units preference (ft, in, lbs). The screen automatically enter Activity screen. - Page 4 NOTE If the activity tracker is paired, you can see serial number under Unpair activity tracker button. DAIly ACTIVITy lEVEl TARgET You can set activity level in the application (30/60/90/120 minutes), the application will generate a series target data as a reference, including target steps, calories and distance. Or, in Activity screen, tap Activity level to select the activity time options (30/60/90/120 minutes).
-
Page 5: Sleep Time Setting
Tap Set goal for Calories in (kcal) and manually input the value. You can add up some values anytime. The value of Calories out (kcal) will be automatically calculated and displayed. Animated icon represents the signal reception condition of data transmission. SlEEP TIME SETTINg You can set your sleep monitoring function, including Wake up time range (Weekdays / Weekends or both) and exact time options. -
Page 6: Activity Mode
ACTIVITy MODE Smart core collects your activity volume for analysis and then display the real-time data in the application. The activity tracker uses 3D sensor technology to count your activity volume to achieve 30 minutes a day or 150 minutes per week in total. Different colors of the indicator on the activity tracker represent different activity achievement. - Page 7 To view graphical data: Rotate the screen to be horizontal, and then you can review the data history by selecting the icons, Day, Week, Month and year. Tap to select your desired time range or swipe the screen to left or right. SlEEP MONITORINg MODE You need to set wake-up time range, please see Sleep Time Setting section for details.
- Page 8 To view graphical data: Rotate the screen to be horizontal, and then you can review the data history by selecting the icons, Week, Month and year. Tap to select your desired time range. ShARE yOUR DATA Share your activity status: You can share the activity status both on facebook and twitter.
-
Page 9: Specifications
Stretch the band and remove the smart core from the band by fingers with some pressure. Wipe the activity tracker by a soft, slightly moistened cloth. Do not use chemical detergent to clean it, which may cause damage. Ensure the band is fully dried before return the smart core back to the activity tracker. -
Page 10: About Oregon Scientific
For any enquiry, please contact our Customer Services at info@oregonscientific.com. Oregon Scientific Global Distribution Limited reserves the right to interpret and construe any contents, terms and provisions in this user manual and to amend it, at its sole discretion, at any time without prior notice. To the extent that there is any inconsistency between the English version and any other language versions, the English version shall prevail.
