Owner's Manual
Cinema ProPack 600
SUB135S
Amplifier/Subwoofer
SERVICE MANUAL
JBL Consumer Products
250 Crossways Park Dr.
Woodbury, New York 11797
Rev1
04/03
For other Service and User Manuals, go to www.ManualDepot.com
Advertisement
Related Manuals for JBL Cinema ProPack 600
Summary of Contents for JBL Cinema ProPack 600
- Page 1 Cinema ProPack 600 SUB135S Amplifier/Subwoofer SERVICE MANUAL JBL Consumer Products 250 Crossways Park Dr. Woodbury, New York 11797 Rev1 04/03 For other Service and User Manuals, go to www.ManualDepot.com...
-
Page 2: Mechanical Parts List
Note: The SUB135S is part of the SCS135S system, which is part of the JBL Cinema Propack 600 system. Satellite loudspeakers 135SAT are replacement-only; order JBL part# SAT135. - CONTENTS - BASIC SPECIFICATIONS……………….….….….….…………….1 DETAILED SPECIFICATIONS ……..…………….……………..2 OPERATION ………….……………………………..…………….3 EXPLODED VIEW..………………………..………….…….……...4 TEST SET-UP AND PROCEDURE……..…………….………….5... - Page 3 SUB135S Cinema ProPack 600 SUB135S 100W Powered Amplifier LINE VOLTAGE Yes/No Hi/Lo Line Unit Notes Normal Operation US 120vac/60Hz 108-132 Vrms Normal Operation Asia 100vac/50Hz 90-110 Vrms Parameter Specification Unit QA Test Limits Conditions Notes Amp Section Type (Class AB, D, other)
- Page 4 Operating the SUB135S Subwoofer GREEN: ON RED: STAND-BY SUB135S POWER JBL, Incorporated NRTL/C This area is designed to become quite warm CSA 22-2 No.1 UL 1492 during normal operation CAUTION RISK OF ELECTRIC SHOCK DO NOT OPEN FUSE AVIS: RISQUE DE CHOC ELECTRIQUE-NE PAS OUVRIR 2.5A/250V...
- Page 5 SUB135S Cinema ProPack 600 SUB135S EXPLODED VIEW/MECHANICAL LIST DESCRIPTION PART# Cabinet Not For Sale Port Tube wi5215 Main Foot wi5447 Rubber Pad for Foot wi5448 Screw 06-t5345005 8” Woofer 20MF10DAG-DW03 Screw 06-t4205012 Amplifier Assembly Not For Sale...
- Page 6 SUB135S Cinema ProPack 600 SUB135S Test Set Up and Procedure SYSTEM AURAL SWEEP TEST Equipment needed: • Function/signal generator/sweep generator • Integrated Amplifier • Multimeter General Unit Function (UUT = Unit Under Test) 1. From the signal generator (set initially at 0 volts), connect one line level (RCA) cable to the SUB135S LFE jack on the UUT.
- Page 7 SUB135S Cinema ProPack 600...
- Page 10 JBL SUB135S Electrical Parts List Part Number Description Reference Designator Main/Input PCB Semiconductors 192027c1815gr Transistor 2SC1815gr NPN Q102,111,112,113,118,206,207,208 192028A1015gr Transistor 2SA1015GR tap PNP Q114,116 1921672n5551 Transistor 2N5551 tap NPN Q103,109 1921682n5401 Transistor 2N5401 AI-PNP 350V Q104,110 197131n4148 1N4148 26mm Diode...
- Page 11 Part Number Description Reference Designator 11016223j26 Resistor 22K 1/6W R128,129,133,237,238,255,263 11016332j26 Resistor 3.3k 1/6W R106,107,144 11016392j26 Resistor 3.9k 1/6W R105,108 11016393j26 Resistor 39k 1/6W R126 11016470j26 Resistor 47 Ohm 1/6W R112,113,115,116 11016471j26 Resistor 470 Ohm 1/6W R140 11016472j26 Resistor 4.7k 1/6W R110,125,130,258 11016473j26 Resistor 47k 1/6W...
- Page 12 Part Number Description Reference Designator 19016tl074cn I.C. TL074CN ST Dual Op-Amp U301 11016103j26 Resistor 10K 1/6W R301,302,303,304,308,309,314 11016223j26 Resistor 22k 1/6W R310,312 11016333j26 Resistor 33k 1/6W R305 11016474j26 Resistor 470k 1/6W R307 11016751j26 Resistor 750 Ohm R311,313 11016755j26 Resistor 7.5M 1/6W R306 1302f104z503 Capacitor 0.1U 50V...
- Page 13 SUB135S Cinema ProPack 600...
- Page 14 SUB135S Cinema ProPack 600...
- Page 15 SUB135S Cinema ProPack 600...
- Page 16 SUB135S Cinema ProPack 600...
