  • Page 1 For Help Call 1.800.241.6264 Datalogic QuickScan Mobile Quick Start More information available at POSMicro.com QUESTIONS? BULk DISCOUNTS SE HaBLa Ask the experts at POSMicro.com. ESpañOL FREE SHIPPING* 1.800.241.6264 Live Chat Now support@POSMicro.com Monday - Friday 6 AM to 5 PM Pacific Time...
  • Page 2 QuickScan Mobile Quick Reference Guide...
  • Page 3 Datalogic Scanning, Inc. or its sub- sidiaries or affiliates ("Datalogic" or “Datalogic Scanning”). Owners of Datalogic products are hereby granted a non-exclusive, revocable license to reproduce and transmit this documentation for the purchaser's own internal business purposes.

  • Page 4: Table Of Contents

    Updates and Language Availability ..............iv Using Quickscan Mobile Reader and Cradle ............. 1 System Connections ..................5 QuickScan Mobile Cradle Configuration ............. 8 QuickScan Mobile Reader Configuration ............8 Interface Selection .................... 9 USB Interface Configuration ................10 USB Interface Selection .................. 11 RS-232 Interface Selection ................

  • Page 5: Updates And Language Availability

    UK/US The latest drivers and documentation updates for this product are available on Internet. Log on to: www.scanning.datalogic.com Su Internet sono disponibili le versioni aggiornate di driver e documentazione di questo prodotto. Questo manuale è disponibile anche nella versione italiana.

  • Page 6: Using Quickscan Tm Mobile Reader And Cradle

    MOBILE READER CRADLE The QuickScan Mobile reader and cradle build a Cordless Reading System for the collection, decoding and transmission of barcoded data. Standard models can be connected to a Host PC through a USB, RS-232, Wedge or Pen emulation cable. All models are suited for single-cradle layouts.
  • Page 7 Successful reading is obtained by an audible tone. Good read LED Not Advised HANDS-FREE USE When using the QuickScan Mobile on the cradle, remember to lock the reader by pushing up the locking system as indicated in the following figure.
  • Page 8 Connect a QuickScan Mobile cradle to the Host. For installation and connection information see page 5. Insert the QuickScan Mobile reader into the cradle to start the battery charging. A full charge of the Lithium battery takes 3.5 – 6 hours.
  • Page 9 DATALOGIC Insert the cover in the handle and screw it back into place. Figure 4 Do not incinerate, disassemble, short terminals or expose to high temperature. Risk of fire, explosion. Use specified charger only. Risk of explosion if the battery is replaced by an incorrect type.

  • Page 10: System Connections

    Host connector on the base of the cradle. Host Interface Cable QuickScan Mobile Cradle - Bottom View To disconnect the cable, insert a paper clip or other similar object into the hole corresponding to the connector on the base of the cradle. Push down on the clip while unplugging the cable.
  • Page 11 DATALOGIC IBM USB POS CAB-413 WEDGE (ONLY FOR QUICKSCAN M2 TYPE:130) CAB-391 or CAB-321 + CAB-431 WEDGE (ONLY FOR QUICKSCAN M2 TYPE:130) CAB-431 POWER SUPPLY ADAPTER CAB-431 POWER SUPPLY ADAPTER...
  • Page 12 QUICKSCAN MOBILE IBM PORT9B / IBM PORT 5B (ONLY FOR QUICKSCAN M2 TYPE:110) CAB-445 CAB-446...

  • Page 13: Quickscan Mobile Cradle Configuration

    USB-COM interface or by reading configuration barcodes with the reader. Serial/USB-COM Configuration By connecting the QuickScan Mobile cradle to a PC through an RS-232 or USB cable (only USB-COM interface) it is possible to send configuration strings from the PC to the reader. Using this method you can also send new configuration strings from the PC to the reader or upgrade application software onto the reader.

  • Page 14: Interface Selection

    Bind Ì$+RN0$-IÎ The green LED on the QuickScan Mobile reader will blink: the reader is ready to be positioned onto the cradle. Firmly position the reader onto the cradle within 10 seconds, a beep will be emitted, signaling that the QuickScan Mobile cradle has been paired to the QuickScan Mobile reader.

  • Page 15: Usb Interface Configuration

    O.S. and should therefore be selected from the dialog box (the first time only). You can now read codes with the associated QuickScan Mobile reader. At this point you can read the USB interface configuration code according to your application.

  • Page 16: Usb Interface Selection

    USB-IBM-Hand Held Ì$+UA01$-.Î When configuring USB-COM, the relevant files and drivers must be installed from the USB Device Installation software, which can be downloaded from the web site http://www.scanning.datalogic.com. Select one keyboard nationality code from the table at page 16.

  • Page 17: Rs-232 Interface Selection

    DATALOGIC RS-232 INTERFACE SELECTION Read the QuickScan Mobile cradle restore default code, and then read the interface selection code for your application: RESTORE QUICKSCAN MOBILE CRADLE DEFAULT Ì$+RX0$-qÎ RS-232 INTERFACE Standard Ì$+CP0$-$Î POS TERMINALS Nixdorf Mode A Ì$+CM2EC0$->Î Fujitsu Ì$+CM1$-ÈÎ...

  • Page 18: Wedge Interface Selection

    WEDGE INTERFACE SELECTION NOTE: only for Quickscan M2 Type:130 Read the QuickScan Mobile cradle restore default code, then read the interface selection code for your application: RESTORE QUICKSCAN MOBILE CRADLE DEFAULT Ì$+RX0$-qÎ WEDGE INTERFACE IBM AT or PS/2 PCs Ì$+CP500$-aÎ...
  • Page 19 DATALOGIC WEDGE INTERFACE (CONTINUED) IBM Terminals 31xx, 32xx, 34xx, 37xx: To select the interface for these IBM Terminals, read the correct KEY TRANSMISSION code. Select the KEYBOARD TYPE if necessary (default = advanced keyboard). KEY TRANSMISSION MODE make-only keyboard Ì$+CP502$-oÎ...
  • Page 20 QUICKSCAN MOBILE WEDGE INTERFACE (CONTINUED) WYSE TERMINALS ANSI Keyboard Ì$+CP509$-9Î PC Keyboard Ì$+CP510$-gÎ ASCII Keyboard Ì$+CP511$-nÎ VT220 style Keyboard Ì$+CP514$-ÇÎ DIGITAL TERMINALS VT2xx/VT3xx/VT4xx Ì$+CP512$-uÎ APPLE APPLE ADB Bus Ì$+CP513$-|Î...

  • Page 21: Usb / Wedge Keyboard Nationality

    DATALOGIC USB / WEDGE KEYBOARD NATIONALITY USB/Wedge interface users should select one of the following KEYBOARD NATIONALITY codes. Belge Ì$+FJ7$-8Î Deutsch Ì$+FJ3$-$Î English (UK) Ì$+FJ4$-)Î Español Ì$+FJ6$-3Î Français Ì$+FJ2$-ÊÎ Italiano Ì$+FJ1$-ÅÎ Svenskt Ì$+FJ5$-.Î Ì$+FJ0$-|Î The following Keyboard Nationality selection is only valid for IBM AT compatible...

  • Page 22: Ibm46Xx Interface Selection

    IBM46XX INTERFACE SELECTION NOTE: only for Quickscan M2 Type:110 Read the QuickScan Mobile cradle restore default code, then read the interface selection code for your application: RESTORE QUICKSCAN MOBILE CRADLE DEFAULT Ì$+RX0$-qÎ IBM 46XX TERMINALS PORT 9B 4501 Protocol Ì$+CP800$-pÎ...

  • Page 23: Pen Interface Selection

    DATALOGIC PEN INTERFACE SELECTION Read the QuickScan Mobile cradle restore default code, then read the interface selection code for your application: RESTORE QUICKSCAN MOBILE CRADLE DEFAULT Ì$+RX0$-qÎ PEN INTERFACE Ì$+CP6$-BÎ...

  • Page 24: Operating Test

    YOUR SYSTEM IS READY TO READ CODES AND TO SEND THE DATA TO THE HOST. To change the defaults, refer to the "QuickScan Mobile Reference Manual", part number 820001971, or to the Datalogic Aladdin™ Configuration program, both downloadable from the website.

  • Page 25: Reader Default Configuration

    DATALOGIC READER DEFAULT CONFIGURATION DATA FORMAT code identifier disabled (enabled for POS terminals), field adjustment disabled, code length tx not transmitted, character replacement disabled, address stamping disabled; address delimiter disabled POWER SAVE sleep state/USB suspend disabled, enter sleep timeout = 0.6 sec...

  • Page 26: Cradle Default Configuration

    QUICKSCAN MOBILE CRADLE DEFAULT CONFIGURATION USB DEFAULT SETTINGS DATA FORMAT: code identifier disabled, code length not transmitted, character replacement disabled, address stamping disabled, address delimiter disabled. USB KEYBOARD: USA keyboard, FIFO enabled, inter-character and inter-code delays disabled. USB COM: handshaking disabled, delay disabled, rx timeout 5 sec., ack/nack disabled, FIFO enabled, serial trigger lock disabled.

  • Page 27: Technical Features

    CCD solid state (2088 pixels) Illuminator LED array Wavelength 630 ~ 670 nm Max. LED Output Power 0.33 mW LED safety class Class 1 EN 60825-1 Reading field see reading diagram Max. resolution 0.10 mm, 4 mils PCS minimum 20% (Datalogic Test Chart)
  • Page 28 QUICKSCAN MOBILE Environmental Features – READER 0°to + 40 °C (32° to 104 °F) Working Temperature Storage Temperature -20° to 70 °C (-4° to 158 °F) (without battery) Humidity 90% non condensing Drop resistance IEC 68-2-32 Test ED 1.5 m (4 ft 9 in) Protection class IP30 Environmental Features - CRADLE...

  • Page 29: Warranty

    36 months from the date of shipment, provided that the product is operated under normal and proper conditions. Datalogic has the faculty to repair or replace the product; these provisions do not prolong the original warranty term. The warranty does not apply to any product that has been subject to misuse, accidental damage, unauthorized repair or tampering.

  • Page 30: Compliance

    FCC COMPLIANCE Modifications or changes to this equipment without the expressed written approval of Datalogic could void the authority to use the equipment. This device complies with PART 15 of the FCC Rules. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) this device must accept any interference received, including interference which may cause undesired operation.

  • Page 31: Led Class

    DATALOGIC LED CLASS EN60825-1:(2001) QuickScan Mobile Product Label Class 1 LED product. RADIO COMPLIANCE Contact the competent authority responsible for the management of radio frequency devices of your country to verify the eventual necessity of a user license. Refer to the web site http://europa.eu.int/comm/enterprise/rtte/spectr.htm for...

  • Page 32: Weee Compliance

    Waste Electrical and Electronic Equipment (WEEE) Statement English For information about the disposal of Waste Electrical and Electronic Equipment (WEEE), please refer to the website at www.scanning.datalogic.com. Italian Per informazioni sullo smaltimento delle apparecchiature elettriche ed elettroniche consultare il sito Web www.scanning.datalogic.com.

  • Page 33: Reading Diagram

    DATALOGIC READING DIAGRAM Reading diagram at 25 °C and 300 lux ambient lighting (cm) Reading Zones (10° skew angle) CODE39 0.50 mm (20 mils) EAN13 M=1 0.33 mm 0.13 mm (13 mils) (5 mils)

  • Page 34: Numeric Table

    QUICKSCAN MOBILE NUMERIC TABLE Ì01Î Ì12Î Ì23Î Ì34Î Ì45Î Ì56Î Ì67Î Ì78Î Ì89Î Ì9:Î...
