AMILO Notebook Pi 3660

2
1
18
3
17
16
15
14
13
12
1 = Digital microphone array
2 = Webcam
3 = Loudspeakers
4 = Keyboard with separate number keypad
5 = Status indicators
6 = Touchpad
7 = Touchpad buttons
8 = Multi-format card reader
9 = Line-in port
10 = Microphone jack
11 = Headphones / SPDIF / Line-out port
12 = ExpressCard slot
13 = Combined eSATA/USB port
A26391-K296-Z201-1-7619, edition 1
1
6
8 7
9
10
11
19
20
21
3
22
4
5
24
14 = HDMI port
15 = Network port
16 = VGA monitor port
17 = Ventilation slots
18 = ON/OFF switch
19 = CD/DVD drive (optional: Blu-ray drive)
20 = USB ports
21 = Kensington Lock
22 = DC input connector (DC IN)
23 = Rechargeable battery
24 = Service compartment, memory
and hard disk
Ports and controls
23
