JBL STUDIO 580 Technical Manual

Technical Manual
STUDIO 580
ACOUSTIC & ELECTRICAL SPECIFICATIONS:
• Nominal impedance:
• Recommended amplifier
power*:
• Frequency response:
• Sensitivity (2.83V/m):
• Crossover frequency:

SYSTEM COMPONENTS:

• Cabinet:
• Grille:
• Low-frequency transducer:
DC resistance:
• High-frequency transducer:
DC resistance:
• Crossover network:
PACKAGING
6 ohms
200 watts
40Hz – 40kHz (–6dB)
90dB
1.5kHz
Studio 580 cabinet (not for sale)
244-060-05446-0BAE
Two 6-1/2" (165mm) PolyPlas
™
with Symmetrical Field Geometry
magnet structures, cast frames
and rubber surrounds, magnetically
shielded (565J)
10.0 ohms
1" (25mm) compression driver with
neodymium magnet and one-piece
Teonex ® diaphragm, magnetically
shielded (0500166001Z)
3.8 ohms
013-7600-05937-E
Legend on Page 2
Release Date 2011

AURAL SWEEP TEST SPECIFICATIONS

• System Aural Sweep test:
• LF Aural Sweep test:
• HF Aural Sweep test:

PHYSICAL SPECIFICATIONS:

• Dimensions (W x H x D):
• Weight:
cones
™
WARRANTY:
• Refer to the warranty statement packed with the product.
* The maximum recommended amplifier power rating will
ensure proper system headroom to allow for occasional
peaks. We do not recommend sustained operation at these
maximum power levels.
STUDIO 580 WIRING DIAGRAM
RED
520mm
WHITE
520mm
RED
360mm
BLACK
360mm
Discontinued Date XXXX
:
6.0V input 40Hz to 20kHz
5.0V input 40Hz to 1.5kHz
1.0V input 1.5kHz to 20kHz
42-1/16" x 9-7/8" x 13-3/4"
(1069mm x 250mm x 348mm)
49 lb (22.2kg)
YELLOW 600mm
BLACK 600mm
GREEN 380mm
WHITE 380mm
BLACK 380mm
BLACK 380mm
12/11
