- Page 1 5 series ® loudspeakers Owner’s Manual...
-
Page 2: Included Items
We’re confident that the JBL system you have chosen will provide every note of enjoyment you expect – and that when you think about purchasing additional audio equipment for your home, car or office, you will once again choose JBL products. - Page 3 For the best performance, we recommend that you place the speakers at least 20 inches (51cm) away from the side walls. • Position Studio 530 bookshelf speakers so that the centers of their horns are approximately at ear level. Peel the adhesive rubber feet from the card and apply them to the bottoms of the speakers. Rubber Feet www.jbl.com...
- Page 4 uSiNG tHE SuppLiEd SpikES (Studio 590/Studio 580/Studio 570) Four metal spikes are supplied for use when you place the speaker on a carpeted surface. Using the spikes decouples the speaker from the floor and prevents unwanted acoustic damping. To insert the spikes: 1.
- Page 5 Studio Studio 590/580/ 590/580/ Studio 520C 570/530 570/530 Center Speaker Front Left Front Right Speaker Speaker Studio 530 Studio 530 Surround Right Surround Left Speaker Speaker Surround Left Surround Right Speaker Speaker 3 – 4 ft (0.9m – 1.2m) www.jbl.com...
-
Page 6: Removing The Grilles
Studio 530 – SuRRouNd CHANNELS (7.1-CHANNEL SyStEm) When you use Studio 530 speakers as surround-channel speakers in a 7.1-channel system, place the surround side speakers directly to the sides of the listening position, at least 3 – 4 feet (0.9m – 1.2m) above the floor. Place the surround back speakers on the wall behind the listening position, also at least 3 –... - Page 7 AC outlets) before making any connections. Speakers and amplifiers have corresponding positive and negative (“+” and “–”) connectors. All Studio 5 series speakers have connectors that are marked “+” and “–” on the terminal-cup assembly. Additionally, the “+” connectors have red markings, while the “–”...
- Page 8 The Studio 5 series speakers’ gold-plated speaker connectors can accept a variety of wire connector types: bare wire, pin connectors, spade connectors and banana connectors. uSiNG BARE WiRE oR piN CoNNECtoRS: uSiNG SpAdE CoNNECtoRS: uSiNG BANANA CoNNECtoRS:...
- Page 9 Speaker Connector Panel Receiver or Amplifier Use Either Set (One Channel Shown) of Connectors Do Not Remove + – Jumper Bars www.jbl.com...
-
Page 10: Bi-Wire Connection
Bi-WiRE CoNNECtioN All Studio 5 series speaker connector panels have two sets of input connectors that are joined by metal jumper bars. The upper set of connectors is for the compression-driver/horn assembly, and the lower set of connectors is for the woofer(s). This arrangement allows you to bi-wire the speakers using a single stereo amplifier or using two stereo amplifiers. -
Page 11: Caring For Your Speakers
• Do not wash the grilles in water, as it may fade the color or make it uneven. • If the surfaces of the woofer cones become dusty, you can carefully sweep them clean with a soft, dry calligraphy brush or paint brush. Do not use a damp cloth. www.jbl.com... -
Page 12: Specifications
sPeCiFiCatiOns Studio 590 FLooRStANdiNG SpEAkER Speaker type: 2-1/2-way dual-woofer, floorstanding Two 8" (200mm) PolyPlas™ cones with Symmetrical Field Geometry™ Low-frequency transducer: magnet structures, cast frames and rubber surrounds, magnetically shielded 1" (25mm) compression driver with neodymium magnet and one-piece High-frequency transducer: Teonex diaphragm on a glass-filled ABS Bi-Radial horn, magnetically... - Page 13 Crossover frequencies: 1.5kHz Enclosure type: Ported Connector type: Dual gold-plated binding posts (bi-wire capable) Available finishes: Black or cherry 18-3/8" x 8-7/16" x 8-3/4" Dimensions (H x W x D): (467mm x 214mm x 222mm) Weight: 17 lb (7.7kg) www.jbl.com...
- Page 14 Studio 520C CENtER-CHANNEL SpEAkER Speaker type: 2-way dual-woofer, center-channel Two 4" (100mm) PolyPlas cones with Symmetrical Field Geometry™ Low-frequency transducer: magnet structures, cast frames and rubber surrounds, magnetically shielded 1" (25mm) compression driver with neodymium magnet and one- High-frequency transducer: piece Teonex diaphragm on a glass-filled ABS Bi-Radial horn,...
- Page 15 © 2011 HARMAN International Industries, Incorporated. All rights reserved. JBL and Bi-Radial are trademarks of HARMAN International Industries, Incorporated, registered in the United States and/or other countries. PolyPlas and Symmetrical Field Geometry are trademarks of HARMAN International Industries, Incorporated.
