Intended use

Your washing machine
Congratulations You have opted for a modern, high quality J for use in the household only,
domestic appliance manufactured by Balay. The washing machine is
J for the washing of machine washable textiles
distinguished by its economical use of water and energy.
in a detergent solution,
Each appliance which leaves our factory is inspected thoroughly
J to be operated with cold drinking water and
to ensure that it functions properly and is in perfect condition. commercially available detergents and care products
which are suitable for use in washing machines.
For further information and a selection of our products go to our web
site: http://www.balay.es or contact our customer service centres
- Do not leave children unattended near the washing
machine!
Contents
Page - Keep pets away from the washing machine!
J Intended use . . . . . . . . . . . . . . . . . . . . . . . . . . 1
J Programmes . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Set And Adjust Programme . . . . . . . . . . . . . . .
J 3
J

Washing

. . . . . . . . . . . . . . . . . . . . . . . . . . . . 3/4
J After washing . . . . . . . . . . . . . . . . . . . . . . . . . . 4
J

Individual settings

. . . . . . . . . . . . . . . . . . . . . . 5
J Important information . . . . . . . . . . . . . . . . . 6
J Programme Overview . . . . . . . . . . . . . . . . . . . 7
J Safety Instructions . . . . . . . . . . . . . . . . . . . . . . 8
J Consumption Values . . . . . . . . . . . . . . . . . . . . 8
Care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .
J 9
Programmes
J Information about the indicator lights . . . . . . 9
Detailed programme overview > Page 7.
J Maintenance . . . . . . . . . . . . . . . . . . . . . . . . . 10
Spin Speed can be selected individually, irrespective of the
What to do if ... . . . . . . . . . . . . . . . . . . . . . . . 11
J
selected programme and programme progress.
resistentes algod.
(Cottons/Coloureds) Hard wearing textiles
extra (Eco) . . . . . . . . . Hard wearing textiles
Protection of the environment/
sintéticos (Easy Care) easy care textiles
Conservation tips
mix (Mixed Fabrics) . . different types of washing
- Utilise the maximum amount of washing for the particular
programme. delicado
(Delicates/Silk) . . . . . . delicate washable textiles
- Wash normally soiled washing without prewash.
lana/lã u (Wool) . . . . hand /machine washable wool
- Instead of resistentes algod. (Cottons/Coloureds) 90 °C
programme, select extra (Eco) 60 °C and additional function B (Spin) . . . . . . . . . . extra spin with selectable spin speed
intensivo (Intensive Wash). Comparable cleaning result with b (Empty) . . . . . . . . . the rinsing water with D
7
(Rinse stop = without final spin)
significantly lower energy consumption.
- Meter detergent according to the manufacturer's instructions
and water hardness. I rápido 15 min.
- If the washing is then dried in the tumble dryer, select spin speed (Super Quick 15') . . . . short programme
according to the instructions of the dryer manufacturer.
Before washing for the first time,

Preparation

wash once without any washing -> Page 6.
Sorting and inserting the washing
Correct installation according to separate
Installation instructions.
Follow manufacturer's care information!
According to the information on the care labels.
Checking the machine According to type; colour; soiling and temperature.
Do not exceed maximum load -> Page 7.
- Never switch on a damaged machine!
Follow Important instructions -> Page 6!
- Inform your customer service!
Insert large and small items of washing! Close the washing machine
Insert mains plug door. Take care not to trap any items of clothing between the
loading door and rubber seal.
With dry hands only!
Add Detergent And Care Product
Take hold of the plug only!
Turn on the tap
Washing amount, soiling, water hardness (ask your water supply
company) and manufacturer's instructions.
Models without insert for liquid detergent: Pour liquid detergent into
the appropriate dispenser and place in the drum.
During operation: Caution when opening the detergent drawer!
Insert for liquid detergent (depending on model), Page 5.
Dilute viscous fabric softener and fabric conditioner with
Compartment II: Detergent for the main wash, water softener,
water. This prevents blockages.
bleach, stain remover
Compartment 2 : Fabric softener, starch
Compartment I: Detergent for pre wash
Set and adjust programme
For additional functions and spin
speed see individual settings ->
Programme selector Spin Additional Start/
Status
displays speed functions Pause
Select 0 inicio/pausa
(Start/Pause)
Programme selector for switching the All buttons are sensitive
and a gentle tap is
machine on and off and for selecting
the programme. Can be rotated adequate!
in either direction.
Washing
Removing Washing
Open washing machine door and remove washing.
If D (Rinse stop = without final spin) is active:
Select the spin speed or set the programme selector to
b (Empty) or B (Spin).
Select 0 inicio/pausa(Start/Pause).
Detergent drawer with
Remove any foreign objects risk of rusting.
compartments I, II, 2
Turn off tap
Information on Aqua Stop
The washing machine door
-> Installation instructions, Page 7.
Fascia
Switch off
Meter accordingly: Door handle
Set programme selector to stop (Off).
End of programme when ...
... 0 inicio/pausa (Start/Pause) flashes and
(End) is lit on the indicator light.
1
Change programme ...
If you have mistakenly selected a wrong programme:
3
- Reselect programme.
Page 5.
- Select 0 inicio/pausa(Start/Pause).
Cancel Programme ...
- Select 0 inicio/pausa(Start/Pause).
2
- If required, top up the washing (do not leave the door
open for too long as water from the washing could run
out of the open door)
Service flap
- Select 0 inicio/pausa(Start/Pause).
... or terminate
Programmes with high temperature:
Washing
- Cool washing: Select I rápido 15 min.
.
(Super Quick 15')
- Select 0 inicio/pausa(Start/Pause).
Programmes at lower temperature:
- Select B (Spin) or b (Empty).
- Select 0 inicio/pausa(Start/Pause).
Individual settings
F F Spin speed
The spin speed or D (Rinse stop = without final spin) can be set before and while the selected
programme is running. Effects dependent on the programme progress.
The maximum selectable spin speed depends on the model and the set programme.
F F Additional functions see also programme overview
intensivo Extend the washing time for a more intensive washing of heavily
7
soiled items.
(Intensive Wash)
prelava. (Prewash) For heavily soiled washing. Prewash at max. 30 °C.
4
menos (Less Ironing) Special spin sequence with subsequent fluffing. Gentle final
5
spin - residual moisture in the washing increased slightly.
extra (Extra Rinse) Additional rinse cycle, extended washing time. For areas with
6
very soft water or for further improvement of the rinsing result.
F F 0 inicio/pausa (Start/Pause)
For starting or interrupting the programme.
F F Signal
1. Start signal
1000 1000
800 800
mode
600 600
400 400
D D
terminado
Set to f keep +
1 step to right 1 step to right release
selected and
Optional:
Blind mode*
inicio
direct
ON OFF pausa
ON OFF Set to f
* Long signal - function on. Short signal - function off.
Button signals Information signals
2. Set volume 1000 1000
800 800
for ...
600 600
400 400
D D
1 step to right Set volume * 1 step to right Set volume * Set to f
* If required, select repeatedly
F F Insert for liquid detergent
depending on model
Position insert for dispensing liquid detergent:
- Completely remove the detergent drawer > Page 9.
- Push insert forwards.
Do not use insert (push up):
- for gelatinous detergents and washing powders;
- for programmes with prewash.
Important information
Protecting the washing and the machine
- Empty pockets.
- Remove metal parts (paper clips, etc.).
- Wash delicates in the net/bag (tights, curtains, underwired bras).
- Close zips, button up covers.
- Brush sand out of pockets and collars.
- Remove curtain fittings or include in the net/bag.
Before washing for the first time,
Do not put any washing in the washing machine! Turn on the tap, fill the appliance with
approx.1 litre of water and then pour ½ measuring cup of detergent into dispenser II. Set the
sintéticos (Easy Care) 60 °C programme and select 0 inicio/pausa (Start/Pause). At the end
of the programme set the programme selector to stop (Off).
Washing with different degrees of soiling
Wash new items separately.
Light Do not prewash.
If required, pretreat stains. Select intensivo (Intensive Wash)
7
additional function.
heavy Load less washing. Prewash.
If required, pretreat stains. Select intensivo (Intensive Wash)
7
additional function.
Soaking Load washing of the same colour
Pour soaking agent/detergent into dispenser II according to the manufacturer's instructions.
Set resistentes algod. (Cottons/Coloureds) 30 °C programme and select 0 inicio/pausa
(Start/Pause). After approx. 10 minutes select 0 inicio/pausa (Start/Pause). After the required
soaking time reselect 0 inicio/pausa (Start/Pause), if the programme is to be continued or
change the programme.
Starching Laundry must not be treated with fabric softener
Starching is possible in all wash programmes if liquid starch is used. Add starch to the fabric
softener compartment 2 in accordance with the manufacturer's instructions.
Dyeing/Bleaching
Dye in small quantities only. Salt can corrode stainless steel.
Observe the dye manufacturer's specifications.
Do not bleach laundry in the washing machine.
Emergency Release, E.g. In The Event Of A Power Failure
The programme continues to run when the power has been
restored. However, if the laundry has to be removed, the washing
machine door can be opened as follows:
Risk of scalding.
The detergent solution and laundry may be hot.
If possible, leave it to cool down.
Do not reach into the drum if it is still rotating.
Do not open the washing machine door if water can
be seen through the glass.
- Set the programme selector to Stop (Off) and disconnect the
mains plug.
- Drain the detergent solution -> Page 9.
- Pull the emergency release with a tool and release. The washing
machine door can then be opened.
