Page 1 2003 Focus Table of Contents Table of Contents Introduction Instrument Cluster Warning and control lights Gauges Entertainment Systems AM/FM stereo cassette AM/FM stereo with CD Climate Controls Heater only Manual heating and air conditioning Lights Headlamps Turn signal control Driver Controls...
Page 2: Table Of Contents
Table of Contents Seating and Safety Restraints Seating Safety restraints Air bags Child restraints Driving Starting Brakes Traction control Transmission operation Trailer towing Roadside Emergencies Getting roadside assistance Hazard flasher switch Fuel pump shut-off switch Fuses and relays Changing tires Jump starting Wrecker towing Customer Assistance...
Page 4 State of California to cause cancer and birth defects or other reproductive harm. CONGRATULATIONS Congratulations on acquiring your new Ford. Please take the time to get well acquainted with your vehicle by reading this handbook. The more you know and understand about your vehicle the greater the safety and pleasure you will derive from driving it.
Page 5 Introduction SAFETY AND ENVIRONMENT PROTECTION Warning symbols in this guide How can you reduce the risk of personal injury and prevent possible damage to others, your vehicle and its equipment? In this guide, answers to such questions are contained in comments highlighted by the warning triangle symbol.
Page 6 Introduction SPECIAL NOTICES Emission warranty The New Vehicle Limited Warranty includes Bumper-to-Bumper Coverage, Safety Restraint Coverage, Corrosion Coverage, and 7.3L Power Stroke Diesel Engine Coverage. In addition, your vehicle is eligible for Emissions Defect and Emissions Performance Warranties. For a detailed description of what is covered and what is not covered, refer to the Warranty Guide that is provided to you along with your Owner’s Guide.
Page 7 This information may be stored during regular operation or in a crash or near crash event. This stored information may be read out and used by: • Ford Motor Company. • service and repair facilities. • law enforcement or government agencies.
Page 8 Introduction These are some of the symbols you may see on your vehicle. Vehicle Symbol Glossary Safety Alert See Owner’s Guide Fasten Safety Belt Air Bag-Front Air Bag-Side Child Seat Child Seat Installation Child Seat Lower Warning Anchor Child Seat Tether Brake System Anchor Brake Fluid -...
Page 9 Introduction Vehicle Symbol Glossary Power Windows Power Window Lockout Front/Rear Interior Luggage Child Safety Door Compartment Release Lock/Unlock Symbol Panic Alarm Engine Oil Engine Coolant Engine Coolant Temperature Do Not Open When Hot Battery Avoid Smoking, Flames, Battery Acid or Sparks Explosive Gas Fan Warning Maintain Correct Fluid...
Page 10: Instrument Cluster
Instrument Cluster Instrument Cluster WARNING LIGHTS AND CHIMES Standard instrument cluster Optional instrument cluster 2.3L 14 PZEV instrument cluster...
Page 11 Instrument Cluster Warning lights and gauges can alert you to a vehicle condition that may become serious enough to cause expensive repairs. A warning light may illuminate when a problem exists with one of your vehicle’s functions. Many lights will illuminate when you start your vehicle to make sure the bulb works.
Page 12 Instrument Cluster Driving a vehicle with the brake system warning light on is dangerous. A significant decrease in braking performance may occur. It will take you longer to stop the vehicle. Have the vehicle checked by your dealer immediately. Anti-lock brake system: If the ABS light stays illuminated or continues to flash, a malfunction has been detected, have the system...
Page 13 Instrument Cluster Overdrive off (if equipped): Illuminates when the overdrive function of the transaxle has been turned off, refer to the Driving chapter. If the light flashes steadily, have the system serviced immediately. Upshift (if equipped): To maximize fuel economy, this light illuminates when the manual transmission should be shifted to the next highest gear.
Page 14: Gauges
Instrument Cluster Door ajar: Illuminates when the ignition is in the ON position and any door is open. Turn signal: Illuminates when the left or right turn signal or the hazard lights are turned on. If the indicators stay on or flash faster, check for a burned out bulb. High beams: Illuminates when the high beam headlamps are turned on.
Page 15 Instrument Cluster Speedometer: Indicates the current vehicle speed. Engine coolant temperature gauge: Indicates engine coolant temperature. At normal operating temperature, the needle will be in the normal range (between “H” and “C”). If it enters the red section, the engine is overheating. Stop the vehicle as soon as safely possible, switch off the engine and let the engine cool.
Page 16 Instrument Cluster Trip odometer: Registers the kilometers (miles) of individual journeys. To reset, depress the reset control. Tachometer (if equipped): Indicates the engine speed in revolutions per minute. Driving with your tachometer pointer continuously at the top of the scale may damage the engine.
Page 17: Entertainment Systems
Entertainment Systems Entertainment Systems AM/FM STEREO WITH CASSETTE 1. Cassette door: Insert the cassette with the opening to the right. 2. Rewind/fast forward: Press to reverse/advance to the previous/next cassette selection. If the end of the tape is reached, playback begins on the other side. Partially press both to change tape sides.
Page 18 AM/FM to activate. AST will flash in the display. When the six strongest stations are filled, the sound will be restored. 8. Anti-theft protection panel: To deter would-be thieves, Ford audio units have a removable front panel without which the unit will not work.
Page 19 Replacement panels: Your Ford Dealer will require the following if you need to order a replacement panel: • Your name and address.
Page 20: Am/Fm Stereo With Cd
Entertainment Systems AM/FM STEREO WITH CD PLAYER 1. CD door: Insert the CD label side up. 2. CD: Press to engage CD mode. CDs and tracks are selected and played chronologically. Press the AM/FM control to restore radio reception without ejecting the disc. 3.
Page 21 AM/FM to activate. AST will flash in the display. When the six strongest stations are filled, the sound will be restored. 7. Anti-theft protection panel: To deter would-be thieves, Ford audio units have a removable front panel without which the unit will not work.
Page 22 Entertainment Systems Replacement panels: Your Ford Dealer will require the following if you need to order a replacement panel: • Your name and address. • The vehicle identification number (visible in the corner of the windscreen). • The audio unit type.
Page 23 Entertainment Systems 6006 AM/FM SOUND SYSTEM WITH 6–DISC IN DASH CHANGER 6 DISC CD PLAYER LOAD 6006 CD TUNER VOL ON/OFF BASS FADE MENU SCAN SEEK SEEK AM/FM TREB 9006 AM/FM SOUND SYSTEM WITH 6–DISC IN DASH CHANGER...
Page 24 Entertainment Systems 1. CD Door: Insert the disc with the playing side down and printed side up. 2. Load: Press to load a CD. WAIT LOAD will appear in the display then change to INSERT. Insert the CD. LOAD and a disc icon will flash in the display. Repeat this step to load up to 6 CDs.
Page 25 Entertainment Systems 6. Memory presets: To set a station: Select frequency band AM/FM; tune to a station, press and hold a preset button until sound returns. With a CD, press the preset control that corresponds to the desired disc. CD 1–01. CD 3–01, NO DISC or NO DISCS will be displayed depending on what preset button was selected.
Page 26 Replacement panels: Your Ford Dealer will require the following if you need to order a replacement panel: • Your name and address.
Page 27 Entertainment Systems 11. Scan: Press SCAN to move up SCAN the radio frequency band. SCAN automatically finds a station, plays it for five seconds, then moves to the next station. Press again to stop. CD: Press SCAN to sample CD selections for eight seconds. Press again to stop.
Page 28 Entertainment Systems IN-DASH CD/MP3 SOUND SYSTEM 1. CD door: Insert a CD or MP3 label side up. 2. Soft keys: Press to make various selections in the audio menus. 3. Mute: Press to mute the playing MUTE media. Press again to return. 4.
Page 29 Entertainment Systems Press again for a brief sampling of all MP3 directories on the disc. SCAN ALL appears at the bottom of the display. 6. Shuffle: CD/CD changer: Press SHUF to play the songs on the current CD in random order. SHUF ALB appears in the display.
Page 30 Entertainment Systems Display/brightness: Adjusts the brightness level of the display. Press ENTER and select DISPLAY. Press ENTER again to confirm. You may adjust the setting to: DAY/NIGHT, DIM DAY, DIM NIGHT or ANGLE. Press ENTER again to confirm. Automatic volume control (AVC): Radio volume changes automatically with vehicle speed to compensate for road and wind noise.
Page 31 Entertainment Systems 11. CDC: Press to access the CD changer. Press the desired soft key to select from the CDs in the CD changer. During playback, press to repeat the current track. 12. CD/MP3: Press to play a CD/MP3 CD/MP3 that is already loaded in the system.
Page 32 Entertainment Systems 17. Balance: Press BAL then turn the volume control to adjust the audio between the left and right speakers. The selected level will appear in the display. 18. Bass: Press to adjust the bass levels. Turn the volume control to increase/decrease levels.
Page 33 Entertainment Systems • CD-R media is supported, but CD-RW is not. • If more than one session is written to the CD, only the first session will be detected. RADIO FREQUENCIES AM and FM frequencies are established by the Federal Communications Commission (FCC) and the Canadian Radio and Telecommunications Commission (CRTC).
Page 34 Due to technical incompatibility, certain recordable and re-recordable compact discs may not function correctly when used in Ford CD players. Irregular shaped CDs, CDs with a scratch protection film attached, and CDs with homemade paper (adhesive) labels should not be inserted into the CD player.
Page 35: Climate Controls
Climate Controls Climate Controls HEATER ONLY SYSTEM 1. Air flow selections: Controls the direction of the airflow in the vehicle. See the following for a brief description on each control. : Distributes outside air through the instrument panel vents. : Distributes outside air through the instrument panel vents and the floor vents.
Page 36: Manual Heating And Air Conditioning
Climate Controls To aid in side window defogging/demisting in cold weather: 1. Select 2. Set the temperature control to full heat 3. Set the fan speed to HI 4. Direct the outer instrument panel vents towards the side windows To increase airflow to the outer instrument panel vents, close the vents located in the middle of the instrument panel.
Page 37 Climate Controls Operating tips • To reduce fog build up on the windshield during humid weather, place the air flow selector in the position. • To reduce humidity build up inside the vehicle: do not drive with the air flow selector in the OFF or MAX A/C position. •...
Page 38: Lights
Lights Lights HEADLAMP CONTROL Turns the lamps off. Turns on the parking lamps, instrument panel lamps, license plate lamps and tail lamps. Turns the headlamps on. Foglamp control (if equipped) The headlamp control also operates the foglamps. The foglamps can be turned on when the headlamp control is in the position and the high...
Page 39 Lights High beams Push the lever toward the instrument panel to activate. Pull the lever towards you to deactivate. Flash to pass Pull toward you slightly to activate and release to deactivate. PANEL DIMMER CONTROL Use to adjust the brightness of the instrument panel during headlight and parklamp operation.
Page 40 Lights 1. Park the vehicle on a level surface approximately 7.6 meters (25 feet) from the vertical wall or the screen directly in front of it. 2. Measure the height of the headlamp bulb center from the ground and mark a 2.5 meters (8 foot) horizontal reference line on the vertical wall or screen at this height.
Page 41: Turn Signal Control
Lights 3. Open the hood. 4. Remove the battery cover. 5. Remove the headlamp bulb cover by releasing the four snap hooks (two top and two bottom). Note: On the left headlamp, pull the bulb cover approximately 1 inch rearward and then slide it out until the vertical aiming adjuster is accessible.
Page 42 Lights INTERIOR LAMPS Dome lamps The dome lamp is equipped with a control switch that will illuminate when: • the doors are closed and the switch is in the on position. • the switch is in the door activated position and any door is open. When the dome lamp switch is in the off position, it will not illuminate when you open the doors.
Page 43 Lights Using the right bulbs Replacement bulbs are specified in the chart below. Headlamp bulbs must be marked with an authorized “D.O.T.” for North America to assure lamp performance, light brightness and pattern and safe visibility. The correct bulbs will not damage the lamp assembly or void the lamp assembly warranty and will provide quality bulb burn time.
Page 44 Lights Replacing headlamp bulbs Make sure the headlamp switch is in the OFF position. To remove the high or low beam headlamp bulb: 1. Lift the hood and remove the bulb cover. 2. Swivel the wire clip to the side and pull out the lamp.
Page 45 2. Open the hood and remove the bulb socket from the headlamp unit by turning it counterclockwise. 3. Pull the bulb straight out of the bulb socket. Note: On vehicles fitted with VOL (HID) headlamps, have your Ford dealer change the park lamp bulbs.
Page 46 Lights Replacing tail/brake/backup lights and turn signal bulbs (coupe) 1. Make sure the headlamp control is in the OFF position and then open the hatchback. 2. From inside the luggage compartment remove the wing nut of the rear light assembly cover. 3.
Page 47 Lights Replacing tail/brake/backup lights and turn signal bulbs (wagon) 1. Make sure the headlamp control is in the OFF position and then open the hatchback. 2. Using a screw driver remove the fixings and trim from the body. 3. Remove the socket from the lamp assembly 4.
Page 48 Lights Replacing high-mount brake lamp bulbs Sedan 1. Make sure the headlamp control is in the OFF position and open the luggage compartment. 2. Using a screw driver remove the trim from the tailgate. 3. Pull the bulb holder from the lamp assembly.
Page 49 Lights Replacing the luggage compartment lamp 1. Make sure the headlamp control is in the OFF position. 2. Carefully pry out the light assembly from the holder with a flathead screwdriver. 3. Pull the bulb straight out. Install in reverse order. Replacing interior lamps 1.
Page 50: Driver Controls
Driver Controls Driver Controls MULTI-FUNCTION LEVER Windshield wiper: Move the lever down for a single wipe. For intermittent operation, move control up one position and adjust the rotary control to the desired speed. For normal operation, move control up two positions. For high speed operation, move control up three positions.
Page 51 Driver Controls Changing the wiper blades 1. Pull the wiper arm away from the vehicle. Turn the blade at an angle from the wiper arm. Push the lock pin manually to release the blade and pull the wiper blade down toward the windshield to remove it from the arm.
Page 52: Power Windows
Driver Controls HORN Press the steering wheel pad. The horn can be operated when the ignition is off. POWER WINDOWS (IF EQUIPPED) When closing the power windows, you should verify they are free of obstructions and ensure that children and/or pets are not in the proximity of the window openings.
Page 53: Mirrors
Driver Controls MIRRORS Power side view mirrors The ignition must be in the ACC or ON position to adjust the power side view mirrors. To adjust your mirrors: 1. Rotate the control clockwise to adjust the right mirror and rotate the control counterclockwise to adjust the left mirror.
Page 54 Driver Controls Setting speed control The controls for using your speed control are located on the steering wheel for your convenience. 1. Press the ON control and release 2. Accelerate to the desired speed. 3. Press the SET ACCEL control and release it.
Page 55 Driver Controls Resuming a set speed Press the RES (resume) control and release it. This will automatically return the vehicle to the previously set speed. The RES control will not work if the vehicle speed is not faster than 48 km/h (30 mph). Increasing speed while using speed control There are two ways to set a higher speed:...
Page 56 Driver Controls • Depress the brake pedal until the desired vehicle speed is reached, press the SET ACCEL control. Turning off speed control Press the speed control OFF control. Note: When you turn off the speed control or the ignition, your speed control set speed memory is erased.
Page 57 The moon roof will move about 0.5 seconds at a time and then stop again. Press the switch again and again until the moon roof is closed. Have the system checked by your Ford Dealer immediately. REMOTE LUGGAGE COMPARTMENT RELEASE (IF EQUIPPED) To open the luggage compartment, press the control.
Page 58 Note: If the storage area is felt lined, it’s a storage bin only, do not use as an ashtray. (Smokers package kit is available through Ford Accessories.) CELL PHONE USE The use of Mobile Communications Equipment has become increasingly important in the conduct of business and personal affairs.
Page 59 Driver Controls POSITIVE RETENTION FLOOR MAT Position the driver floor mat so that the eyelet is over the pointed end of the retention post and rotate forward to lock in. Make sure that the mat does not interfere with the operation of the accelerator or the brake pedal.
Page 60 Driver Controls LUGGAGE COVER Coupe Detach the lifting straps on the liftgate. Release the cover at the sides and pull it out horizontally without tilting it. Install in reverse order. Make sure the cover is properly aligned when inserting it. Wagon Pull out the roller cover and secure the retaining points.
Page 61 Driver Controls LUGGAGE RACK (IF EQUIPPED) The maximum recommended load is 100 kg (220 lbs) on the luggage rack structure. The load must be placed directly on the luggage rack. The vehicle’s roof panel is not designed to carry a load. When loading the luggage rack, it is recommended to evenly distribute the load, as well as maintain a low center of gravity.
Page 62: Locks And Security
Locks and Security Locks and Security KEYS The key operates all locks on your vehicle. In case of loss, replacement keys are available from your dealer. You should always carry a second key with you in a safe place in case you require it in an emergency.
Page 63 Locks and Security Childproof door locks • When these locks are set, the rear doors cannot be opened from the inside. • The rear doors can be opened from the outside when the doors are unlocked. The childproof locks are located on rear edge of each rear door and must be set separately for each door.
Page 64 Locks and Security To open the luggage compartment door (lid) from within the luggage compartment, pull the illuminated “T” shaped handle and push up on the trunk lid. The handle is composed of a material that will glow for hours in darkness following brief exposure to ambient light.
Page 65: Anti-Theft System
Locks and Security REMOTE ENTRY SYSTEM (IF EQUIPPED) This device complies with part 15 of the FCC rules and with RS-210 of Industry Canada. Operation is subject to the following two conditions: (1) This device may not cause harmful interference, and (2) This device must accept any interference received, including interference that may cause undesired operation.
Page 66 Locks and Security Locking the doors • Press and release to lock all the doors. Note: the parking lamps will flash once. If any of the doors are not properly closed the horn will make two quick chirps. This process will also activate the vehicle’s anti-theft system (if equipped).
Page 67 Locks and Security To replace the battery: 1. Twist a thin coin between the two halves of the remote entry transmitter near the key ring. DO NOT TAKE THE FRONT PART OF THE REMOTE ENTRY TRANSMITTER APART. 2. Remove the old battery. 3.
Page 68 Note: The SecuriLock passive anti-theft system is not compatible with non-Ford aftermarket remote start systems. Use of these systems may result in vehicle starting problems and a loss of security protection. Note: Large metallic objects, electronic devices that are used to purchase gasoline or similar items, or a second coded key on the same key chain may cause vehicle starting issues.
Page 69 Locks and Security • When the ignition is in the ON position, the indicator will glow for 3 seconds, then turn off, to indicate normal system functionality. If a problem occurs with the SecuriLock system, the indicator will flash rapidly or glow steadily when the ignition is in the ON position. If this occurs, the vehicle should be taken to an authorized dealer for service.
Page 70 Locks and Security 2. Turn the ignition from the 1 (OFF) position to the 3 (ON) position. Keep the ignition in the 3 (ON) position for at least one second, but no more than 10 seconds. 3. Turn the ignition to the 1 (OFF) position. 4.
Page 71 Locks and Security PERIMETER ALARM SYSTEM (IF EQUIPPED) The perimeter anti-theft system will help prevent your vehicle from unauthorized entry. If there is any potential perimeter anti-theft problem with your vehicle, ensure ALL remote entry transmitters are taken to the dealership to aid in troubleshooting.
Page 72: Seating And Safety Restraints
Seating and Safety Restraints Seating and Safety Restraints SEATING Notes: Reclining the seatback can cause an occupant to slide under the seat’s safety belt, resulting in severe personal injuries in the event of a collision. Do not pile cargo higher than the seatbacks to reduce the risk of injury in a collision or sudden stop.
Page 73 Seating and Safety Restraints Adjusting the front manual seat Pull the lever located under the front edge of the seat to move the seat forward or backward. Turn the control to adjust the lumbar support. Turn the handle to adjust the height of the seat.
Page 74 Seating and Safety Restraints • Push control to activate. • Push again to deactivate. The maximum temperature is reached after five or six minutes. The indicator light on the switch is illuminated when activated. The heating will operate when the ignition switch is in position 2. Heating with the engine off will drain the battery.
Page 75 Seating and Safety Restraints REAR SEATS Folding rear seat cushion forward Lift the seat cushion and pull it forward. When returning the seats back to their original positions, make sure they are fully locked and that the safety restraints are positioned in front of the seatback.
Page 76: Safety Restraints
Seating and Safety Restraints Returning the seatback to the upright position Fold back the seatback until it locks with a distinct “click.” Do not place any objects behind the seat which could prevent the seat from locking. When returning the seats back to their original positions, make sure they are fully locked and that the safety restraints are positioned in front of the seatback.
Page 77 Seating and Safety Restraints • Front safety belts with pretensioners, energy management retractors, and safety belt usage sensors. • Driver’s seat position sensor. • Front crash severity sensor. • Restraints Control Module (RCM) with impact and safing sensors. • Restraint system warning light and back-up tone. •...
Page 78 Seating and Safety Restraints Driver’s seat position sensor The driver’s seat position sensor allows your Personal Safety System to tailor the deployment level of the driver dual-stage air bag based on seat position. The system is designed to help protect smaller drivers sitting close to the driver air bag by providing a lower air bag output level.
Page 79 Seating and Safety Restraints • A series of five beeps will be heard. The tone pattern will repeat periodically until the problem and warning light are repaired. If any of these things happen, even intermittently, have the Personal Safety System serviced at your dealership or by a qualified technician immediately.
Page 80 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always properly use appropriate child restraints. Combination lap and shoulder belts 1. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) until you hear a snap and feel it latch.
Page 81 Seating and Safety Restraints BELT AND RETRACTOR ASSEMBLY MUST BE REPLACED if the seat belt assembly “automatic locking retractor” feature or any other seat belt function is not operating properly when checked according to the procedures in Workshop Manual. Failure to replace the belt and retractor assembly could increase the risk of injury in collisions.
Page 82 This indicates the safety belt is now in the automatic locking mode. How to disengage the automatic locking mode Ford Motor Company recommends that all passenger safety belt assemblies and attaching hardware should be inspected by a qualified technician after any collision to verify that the automatic locking retractor feature for child seats is still working properly.
Page 83 Seating and Safety Restraints Safety belt pretensioner Your vehicle is equipped with safety belt pretensioners at the driver and front passenger seating positions. The safety belt pretensioner is a device which removes excess webbing from the safety belt system. The safety belt pretensioner uses the same crash sensor system as the front air bag supplemental restraint system (SRS).
Page 84 Seating and Safety Restraints Position the safety belt height adjusters so that the belt rests across the middle of your shoulder. Failure to adjust the safety belt properly could reduce the effectiveness of the seat belt and increase the risk of injury in a collision. Safety belt warning light and indicator chime The safety belt warning light illuminates in the instrument cluster and a chime sounds to remind the occupants to fasten their safety belts.
Page 85 Seating and Safety Restraints If... Then... The driver’s safety belt is not The BeltMinder feature is activated - buckled approximately 5 the safety belt warning light seconds after the safety belt illuminates and the warning chime warning light has turned off... sounds for 6 seconds every 30 seconds, repeating for approximately 5 minutes or until safety belt is...
Page 86 Seating and Safety Restraints Reasons given... Consider... “I was in a hurry” Prime time for an accident. BeltMinder reminds us to take a few seconds to buckle up. “Safety belts don’t work” Safety belts, when used properly, reduce risk of death to front seat occupants by 45% in cars, and by 60% in light trucks.
Page 87 Seating and Safety Restraints One time disable Any time the safety belt is buckled and then unbuckled during an ignition ON cycle, the BeltMinder will be disabled for that ignition cycle only. Deactivating/activating the BeltMinder feature Read steps 1 - 9 thoroughly before proceeding with the deactivation/activation programming procedure.
Page 88 (slide bar-if equipped), shoulder belt height adjusters (if equipped), shoulder belt guide on seatback (if equipped), child safety seat LATCH and tether anchors, and attaching hardware, should be inspected after a collision. Ford Motor Company...
Page 89: Air Bags
Seating and Safety Restraints recommends that all safety belt assemblies used in vehicles involved in a collision be replaced. However, if the collision was minor and a qualified technician finds that the belts do not show damage and continue to operate properly, they do not need to be replaced.
Page 90: Child Restraints
Seating and Safety Restraints Important SRS precautions The SRS is designed to work with the safety belt to help protect the driver and right front passenger from certain upper body injuries. Air bags DO NOT inflate slowly; there is a risk of injury from a deploying air bag.
Page 91 Seating and Safety Restraints Do not attempt to service, repair, or modify the air bag supplemental restraint systems or its fuses. See your Ford or Lincoln Mercury dealer. Children and air bags Children must always be properly restrained. Accident statistics...
Page 92 Seating and Safety Restraints The air bags inflate and deflate rapidly upon activation. After air bag deployment, it is normal to notice a smoke-like, powdery residue or smell the burnt propellant. This may consist of cornstarch, talcum powder (to lubricate the bag) or sodium compounds (e.g., baking soda) that result from the combustion process that inflates the...
Page 93 Seating and Safety Restraints • diagnostic module. • and the electrical wiring which connects the components. The diagnostic module monitors its own internal circuits and the supplemental air bag electrical system warning (including the impact sensors), the system wiring, the air bag system readiness light, the air bag back up power and the air bag ignitors.
Page 94 Do not attempt to service, repair, or modify the air bag SRS, its fuses or the seat cover on a seat containing an air bag. See your Ford or Lincoln Mercury dealer. All occupants of the vehicle should always wear their safety belts even when an air bag SRS is provided.
Page 95 Seating and Safety Restraints The fact that the air bags did not inflate in a collision does not mean that something is wrong with the system. Rather, it means the forces were not of the type sufficient to cause activation. Side air bags are designed to inflate in side-impact collisions, not roll-over, rear-impact, frontal or near-frontal collisions, unless the collision causes sufficient lateral deceleration.
Page 96 Seating and Safety Restraints Always transport children 12 years old and under in the back seat and always use appropriate child restraints. Accident statistics indicate that children are safer when properly restrained in the rear seats. Do not leave children, unreliable adults, or pets unattended in your vehicle.
Page 97 To improve the fit of both the lap and shoulder belt on children who have outgrown child safety seats, Ford Motor Company recommends use of a belt-positioning booster. Booster seats position a child so that safety belts fit better. They lift the child up so that the lap belt rests low across the hips and the knees bend comfortably.
Page 98 Seating and Safety Restraints Types of booster seats There are two types of belt-positioning booster seats: • Those that are backless. If your backless booster seat has a removable shield, remove the shield and use the lap/shoulder belt. If a seating position has a low seat back and no head restraint, a backless booster seat may place your child’s head (top...
Page 99 Seating and Safety Restraints The importance of shoulder belts Using a booster without a shoulder belt increases the risk of a child’s head hitting a hard surface in a collision. For this reason, you should never use a booster seat with a lap belt only. It is best to use a booster seat with lap/shoulder belts in the back seat- the safest place for children to ride.
Page 100 (passenger side front and outboard rear seating positions) (if equipped) section in this chapter. Ford recommends the use of a child safety seat having a top tether strap. Install the child safety seat in a seating position with a tether anchor.
Page 101 Seating and Safety Restraints Installing child safety seats with combination lap and shoulder belts Air bags can kill or injure a child in a child seat. NEVER place a rear-facing child seat in front of an active air bag. If you must use a forward-facing child seat in the front seat, move the seat all the way back.
Page 102 Seating and Safety Restraints 3. While holding the shoulder and lap belt portions together, route the tongue through the child seat according to the child seat manufacturer’s instructions. Be sure the belt webbing is not twisted. 4. Insert the belt tongue into the proper buckle (the buckle closest to the direction the tongue is coming from) for that seating position until...
Page 103 Seating and Safety Restraints 7. Pull the lap belt portion across the child seat toward the buckle and pull up on the shoulder belt while pushing down with your knee on the child seat. 8. Allow the safety belt to retract to remove any slack in the belt.
Page 104 Seating and Safety Restraints The tether strap anchors in your vehicle are in the following positions (shown from top view, left is front of the vehicle): Attach the tether strap only to the appropriate tether anchor as shown. The tether strap may not work properly if attached somewhere other than the correct tether anchor.
Page 105 Seating and Safety Restraints 5. Clip the tether strap to the anchor as shown. If the tether strap is clipped incorrectly, the child safety seat may not be retained properly in the event of a collision. 6. Refer to the Installing child safety seats in combination lap and shoulder belt seating positions section of this chapter for further instructions to secure the child safety seat.
Page 106 Seating and Safety Restraints LATCH attachments on belt webbing can be used at the center rear seat unless a child seat at an outboard rear seat is attached to one of these lower anchors. Install a child seat onto the lower anchors at the center rear seat ONLY IF the child restraint manufacturer recommends that the child seat can be installed to anchors that are spaced up to 450 mm apart.
Page 107: Driving
Driving Driving STARTING Positions of the ignition 1. LOCK, locks the steering wheel, automatic transaxle gearshift lever and allows key removal. 2. OFF, shuts the engine and all electrical accessories off without locking the steering wheel. The audio system will still function. 3.
Page 108 Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. •...
Page 109 Driving If starting a vehicle with a manual transaxle: 1. Make sure the parking brake is set. 2. Push the clutch pedal to the floor. • Turn the key to 3 (ON) without turning the key to 4 (START).
Page 110 Driving Make sure the corresponding lights illuminate or illuminate briefly. If a light fails to illuminate, have the vehicle serviced. • If the driver’s safety belt is fastened, the light may not illuminate. Starting the engine 1. Turn the key to 3 (ON/RUN) without turning the key to 4 (START).
Page 111: Brakes
Driving If you smell exhaust fumes inside your vehicle, have your dealer inspect your vehicle immediately. Do not drive if you smell exhaust fumes. Important ventilating information If the engine is idling while the vehicle is stopped for a long period of time, open the windows at least 2.5 cm (one inch) or adjust the heating or air conditioning to bring in fresh air.
Page 112: Traction Control
Driving Even when the ABS is disabled, normal braking is still effective. (If your BRAKE warning lamp illuminates with the parking brake released, have your brake system serviced immediately.) Parking brake To set the parking brake (1), pull the parking brake handle up as far as possible.
Page 113 Driving The Traction Control switch is located on the center console, by the gearshift lever. The Traction Control system will automatically turn on every time the ignition is turned off and on. If you should become stuck in snow or ice or on a very slippery road surface, try switching the Traction Control system off.
Page 114 Driving • Hitting a patch of ice • Changing lanes on a snow-rutted road • Entering a snow-free road from a snow-covered side street, or vice versa • Entering a paved road from a gravel road, or vice versa • Hitting a curb while turning •...
Page 115: Transmission Operation
Driving All these conditions are normal during AdvanceTrac operation. Do not alter or modify your vehicle’s suspension or steering; the resulting changes to the vehicle’s handling can adversely affect the AdvanceTrac system. Also, do not install a stereo loudspeaker near the front center console or under either front seat.
Page 116 Driving If you cannot move the gearshift lever out of P (Park) with ignition in the ON position and the brake pedal depressed: 1. Apply the parking brake, turn ignition key to LOCK, then remove the key. When the key is in the ignition OFF position, the automatic transmission shift lever can be moved from the P (Park) position without the brake pedal depressed.
Page 117 Driving Understanding the gearshift positions of the 4–speed automatic transaxle P (Park) This position locks the transaxle and prevents the rear wheels from turning. To put your vehicle in gear: • Start the engine • Depress the brake pedal • Move the gearshift lever into the desired gear To put your vehicle in P (Park): •...
Page 118 Driving D (Overdrive) The normal driving position for the best fuel economy. transaxle operates in gears one through four. D (Overdrive) can be deactivated by pressing the transaxle control switch on the end of the gearshift lever. This will illuminate the O/D OFF lamp and activate Drive. Drive (not shown) Drive is activated when the transaxle control switch is pressed.
Page 119 Driving If necessary, try turning the Traction Control or AdvanceTrac system off. This will allow the wheels to spin, which may help to free your stuck vehicle. For more information, refer to Traction Control (if equipped) or AdvanceTrac stability enhancement system (if equipped) in this chapter.
Page 120 Driving • If your vehicle is equipped with the Zetec engine or 2.3L engine, you must lift the locking ring (1), then move the gearshift lever fully to the right, then back into R (Reverse) (2). Parking your vehicle 1. Apply the brake and shift into the neutral position. 2.
Page 121 Driving • Base Curb Weight: Weight of the vehicle including any standard equipment, fluids, lubricants, etc. It does not include occupants or aftermarket equipment. • Payload: Combined maximum allowable weight of cargo, occupants and optional equipment. The payload equals the gross vehicle weight rating minus base curb weight.
Page 122: Trailer Towing
Driving Note: Do not exceed the GVWR or the GAWR specified on the certification label. Exceeding any vehicle weight rating limitation could result in serious damage to the vehicle, loss of vehicle control, vehicle rollover, and/or personal injury. Do not use replacement tires with lower load carrying capacities than the originals because they may lower the vehicle’s GVWR and GAWR limitations.
Page 123 Driving If you use a rental trailer, follow the instructions that the rental agency gives to you. Do not attach safety chains to the bumper. Trailer brakes Electric brakes and manual, automatic or surge-type trailer brakes are safe if installed properly and adjusted to the manufacturer’s specifications.
Page 124 Driving • Allow more distance for stopping with a trailer attached. • If you are driving down a long or steep hill, shift to a lower gear. Do not apply the brakes continuously, as they may overheat and become less effective. •...
Page 125: Roadside Emergencies
Roadside Emergencies GETTING ROADSIDE ASSISTANCE Roadside Emergencies To fully assist you should you have a vehicle concern, Ford Motor Company offers a complimentary roadside assistance program. This program is separate from the New Vehicle Limited Warranty. The service is available: •...
Page 126: Fuel Pump Shut-Off Switch
1–800–241–3673; Lincoln vehicle customers call 1–800–521–4140. Canadian customers who require roadside assistance, call 1–800–665–2006. If you need to arrange roadside assistance for yourself, Ford Motor Company will reimburse a reasonable amount. To obtain reimbursement information, U.S. Ford or Mercury vehicles customers call 1-800-241-3673;...
Page 127: Fuses And Relays
Roadside Emergencies This switch is located in the front passenger’s footwell, by the kick panel access cover. To reset the switch: 1. Turn the ignition OFF. 2. Check the fuel system for leaks. 3. If no leaks are apparent, reset the switch by pushing in on the reset button.
Page 128 Roadside Emergencies Standard fuse amperage rating and color COLOR Cartridge Fuse Mini Standard Maxi Fuse link maxi rating fuses fuses fuses cartridge fuses Grey Grey — — — Violet Violet — — — Pink Pink — — — — — —...
Page 129 Roadside Emergencies Passenger compartment fuse panel The fuse panel is located below and to the left of the steering wheel by the brake pedal. Remove the panel cover to access the fuses. To remove a fuse use the fuse puller tool provided on the fuse panel cover.
Page 130 Roadside Emergencies The fuses are coded as follows. Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description — Starter relay – Rear intermittent relay — Front wiper intermittent relay — Not used — Not used — Not used — Horn relay —...
Page 131 Roadside Emergencies Fuse/Relay Fuse Amp Passenger Compartment Fuse Location Rating Panel Description Data link connector Rear defroster 7.5A Heated mirror, Heated backlite indicator — Not used Heated seats Backup lamps (manual transaxle) Rear power windows Front power windows Front wipers 7.5A Position and side lights (right) 7.5A...
Page 132 Roadside Emergencies To remove a fuse, use the fuse puller tool provided on the power distribution box cover. The high-current fuses are coded as follows: Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description Main power supply to electrical system Engine cooling fan (A/C) 2nd fuse Cooling fan (2.0L engine only) Air pump motor...
Page 133 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description 10A (2.0L engine Battery voltage sensor only) 1A (2.3L engine only) Anti-lock Brake System (ABS) Fuel pump — Not used — Not used A/C clutch solenoid Low beam (left side - conventional headlamps) Low beam (left side - HID headlamps)
Page 134 Roadside Emergencies Fuse/Relay Fuse Amp Power Distribution Box Location Rating Description Heater blower motor — Ignition relay — Air pump motor relay — Cooling fan (Run-on fan) relay (2.3L engine only) — Not used — High beams relay — Low beams relay —...
Page 135 Roadside Emergencies The use of tire sealants is not recommended and may compromise the integrity of your tires. Temporary spare tire information The temporary spare tire for your vehicle is labeled as such. It is smaller than a regular tire and is designed for emergency use only. Replace the temporary spare tire with a full-size tire as soon as possible.
Page 136 Roadside Emergencies Tire change procedure 1. Park on a level surface, activate hazard flashers and set the parking brake. When one of the front wheels is off the ground, the transaxle alone will not prevent the vehicle from moving or slipping off the jack, even if the vehicle is in P (Park) (automatic transaxle) or R (Reverse) (manual transaxle).
Page 137 Roadside Emergencies 4. On coupe models, unsnap and remove the access door (if equipped) on the lower rocker molding to access the proper jacking points. 5. Loosen each wheel lug nut one-half turn counterclockwise but do not remove them until the wheel is raised off the ground.
Page 138: Jump Starting
Roadside Emergencies 6. The vehicle jacking points are depicted on the yellow warning label on the jack shown here. Depending on which tire is to be changed, locate the jack at the half-moon cutout located approximately 15 cm (6 inches) from the front wheel opening (1) or approximately 38 cm (15 inches) from the rear wheel opening (2).
Page 139 Roadside Emergencies Do not attempt to push-start your vehicle. Automatic transmissions do not have push-start capability; also, the catalytic converter may become damaged. Preparing your vehicle When the battery is disconnected or a new battery is installed, the transmission must relearn its shift strategy. As a result, the transmission may have firm and/or soft shifts.
Page 140 Roadside Emergencies 2. Connect the other end of the positive (+) cable to the positive (+) terminal of the assisting battery. 3. Connect the negative (-) cable to the negative (-) terminal of the assisting battery.
Page 141 Roadside Emergencies 4. Make the final connection of the negative (-) cable to an exposed metal part of the stalled vehicle’s engine, away from the battery and the carburetor/fuel injection system. Do not use fuel lines, engine rocker covers or the intake manifold as grounding points. Do not connect the end of the second cable to the negative (-) terminal of the battery to be jumped.
Page 142 Roadside Emergencies Removing the jumper cables Remove the jumper cables in the reverse order that they were connected. 1. Remove the jumper cable from the ground metal surface. Note: In the illustrations, lightning bolts are used to designate the assisting (boosting) battery. 2.
Page 143 Roadside Emergencies 3. Remove the jumper cable from the positive (+) terminal of the booster vehicle’s battery. 4. Remove the jumper cable from the positive (+) terminal of the disabled vehicle’s battery. After the disabled vehicle has been started and the jumper cables removed, allow it to idle for several minutes so the engine computer can relearn its idle conditions.
Page 144: Wrecker Towing
It is recommended that your vehicle be towed with a wheel lift or flatbed equipment. Do not tow with a slingbelt. Ford Motor Company has not approved a slingbelt towing procedure. If your vehicle is to be towed from the rear using wheel lift equipment, the front wheels (drive wheels) must be placed on a dolly to prevent damage to the transmission.
Page 145: Customer Assistance
Ford Customer Relationship Center. Away from home If you own a Ford or Mercury vehicle and are away from home when your vehicle needs service, or if you need more help than the dealership could provide, after following the steps described above, contact the Ford Customer Relationship Center to find an authorized dealership to help you.
Page 146 P.O. Box 2000 Oakville, Ontario L6J 5E4 1-800-565-3673 (FORD) www.ford.ca In order to help you service your Ford or Lincoln Mercury vehicle, please have the following information available when contacting a Customer Relationship Center: • Your telephone number (home and business) •...
Page 147 5,000 participating Ford or Lincoln Mercury and Ford of Canada dealers. If you did not take advantage of the Ford Extended Service Plan at the time of purchasing your vehicle, you may still be eligible. Since this information is subject to change, please ask your dealer for complete details about Ford Extended Service Plan coverage options, or visit the Ford ESP website at www.ford-esp.com.
Page 148 Customer Assistance The Dispute Settlement Board may not be available in all states. Ford Motor Company reserves the right to change eligibility limitations, modify procedures and/or to discontinue this service without notice and without incurring obligations per applicable state law.
Page 149 • The name of the dealer(s) who sold or serviced the vehicle. • A brief description of your unresolved concern. • A brief summary of the action taken by the dealer(s) and Ford Motor Company. • The names (if known) of all the people you contacted at the dealership(s).
Page 150 After a case is reviewed, the Board mails you a decision letter and a form on which to accept or reject the Board’s decision. The decisions of the Board are binding on Ford (and, in some cases, on the dealer) but not on consumers who are free to pursue other remedies available to them under state or federal law.
Page 151 If your vehicle must be serviced while you are traveling or living in Central or South America, the Caribbean, or the Middle East, contact the nearest Ford dealership. If the dealership cannot help you, write or call: FORD MOTOR COMPANY...
Page 152 Obtaining a French owner’s guide French Owner’s Guides can be obtained from your dealer or by writing to Ford Motor Company of Canada, Limited, Service Publications, P.O. Box 1580, Station B, Mississauga, Ontario L4Y 4G3. IN CALIFORNIA (U.S. ONLY) California Civil Code Section 1793.2(d) requires that, if a manufacturer...
Page 153: Reporting Safety Defects (U.s. Only)
However, NHTSA cannot become involved in individual problems between you, your dealer, or Ford Motor Company. To contact NHTSA, you may either call the Auto Safety Hotline toll-free at 1–800–424–9393 (or 366–0123 in the Washington D.C.
Page 154: Cleaning
Cleaning Cleaning WASHING THE EXTERIOR Wash your vehicle regularly with cool or lukewarm water and a neutral Ph shampoo, such as Motorcraft Detail Wash (ZC-3–A), which is available from your dealer. • Never use strong household detergents or soap, such as dish washing or laundry liquid.
Page 155 • Do not use hydrofluoric acid-based or high caustic-based wheel cleaners, steel wool, fuels or strong household detergent. • To remove tar and grease, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA), available from your dealer. ENGINE Engines are more efficient when they are clean because grease and dirt buildup keep the engine warmer than normal.
Page 156 Cleaning When washing: • Take care when using a power washer to clean the engine. The high-pressure fluid could penetrate the sealed parts and cause damage. • Do not spray a hot engine with cold water to avoid cracking the engine block or other engine components.
Page 157 Cleaning • 2.0L Zetec-E engine • 2.3L engine...
Page 158 Use only approved products to clean plastic parts. These products are available from your dealer. • For routine cleaning, use Motorcraft Detail Wash (ZC-3–A). • If tar or grease spots are present, use Ford Extra Strength Tar and Road Oil Removal (B7A-19520–AA). WINDOWS AND WIPER BLADES The windshield, rear window and wiper blades should be cleaned regularly.
Page 159 For fabric, carpets, cloth seats, safety belts and seats equipped with side air bags: • Remove dust and loose dirt with a vacuum cleaner. • Remove light stains and soil with Ford Extra Strength Upholstery Cleaner (E8AZ-19523–AA). • If grease or tar is present on the material, spot-clean the area first with Motorcraft Spot and Stain Remover (ZC-14).
Page 160 Cleaning FORD, LINCOLN AND MERCURY CAR CARE PRODUCTS Your Ford, Lincoln or Mercury dealer has many quality products available to clean your vehicle and protect its finishes. These quality products have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and appearance of your vehicle.
Page 161: Maintenance And Specifications
Maintenance and Specifications Maintenance and Specifications SERVICE RECOMMENDATIONS To help you service your vehicle: • We highlight do-it-yourself items in the engine compartment for easy location. • We provide a scheduled maintenance guide which makes tracking routine service easy. If your vehicle requires professional service, your dealership can provide the necessary parts and service.
Page 162 Maintenance and Specifications Working with the engine on • Automatic transmission: 1. Set the parking brake and shift to P (Park). 2. Block the wheels. • Manual transmission: 1. Set the parking brake, depress the clutch and place the gearshift in N (Neutral).
Page 163: Engine Compartment
Maintenance and Specifications IDENTIFYING COMPONENTS IN THE ENGINE COMPARTMENT 2.0L I4 SPI 1. Power steering fluid reservoir 2. Engine oil dipstick 3. Engine oil filler cap 4. Brake/Clutch fluid reservoir 5. Power distribution box 6. Air filter assembly 7. Windshield washer fluid reservoir 8.
Page 164 Maintenance and Specifications 2.0L Zetec-E Engine 1. Power steering fluid reservoir 2. Engine oil filler cap 3. Brake/Clutch fluid reservoir 4. Power distribution box 5. Air filter assembly 6. Windshield washer fluid reservoir 7. Battery 8. Automatic transaxle fluid dipstick (if equipped) 9.
Page 165 Maintenance and Specifications 2.3L I4 PZEV Engine 1. Power steering fluid reservoir 2. Engine oil filler cap 3. Brake/Clutch fluid reservoir 4. Power distribution box 5. Battery 6. Windshield washer fluid reservoir 7. Air filter service minder 8. Automatic transaxle fluid dipstick (if equipped) 9.
Page 166: Engine Oil
In very cold weather, do not fill the reservoir completely. Only use a washer fluid that meets Ford specification WSB-M8B16–A2. Refer to Lubricant specifications in this chapter. State or local regulations on volatile organic compounds may restrict the use of methanol, a common windshield washer antifreeze additive.
Page 167 Maintenance and Specifications 2. Turn the engine off and wait a few minutes for the oil to drain into the oil pan. 3. Set the parking brake and ensure the gearshift is securely latched in P (automatic transaxle) or 1st (manual transaxle). 4.
Page 168 Maintenance and Specifications • 2.0L Zetec • 2.3L I4 • If the oil level is below the MIN/ADD mark, add enough oil to raise the level within the MIN-MAX/ADD-FULL range. • Oil levels above the MAX/FULL mark may cause engine damage. Some oil must be removed from the engine by a service technician.
Page 169 Change your engine oil and filter according to the appropriate schedule listed in the scheduled maintenance guide. Ford production and aftermarket (Motorcraft) oil filters are designed for added engine protection and long life. If a replacement oil filter is used that does not meet Ford material and design specifications, start-up engine noises or knock may be experienced.
Page 170: Battery
Maintenance and Specifications BATTERY Your vehicle is equipped with a Motorcraft maintenance-free battery which normally does not require additional water during its life of service. However, for severe usage or in high temperature climates, check the battery electrolyte level. Refer to the scheduled maintenance guide for the service interval schedules.
Page 171 Maintenance and Specifications When lifting a plastic-cased battery, excessive pressure on the end walls could cause acid to flow through the vent caps, resulting in personal injury and/or damage to the vehicle or battery. Lift the battery with a battery carrier or with your hands on opposite corners.
Page 172 Maintenance and Specifications If the battery has been disconnected or a new battery has been installed, the clock and the preset radio stations must be reset once the battery is reconnected. • Always dispose of automotive batteries in a responsible manner. Follow your local authorized standards for disposal.
Page 173 Do not put engine coolant in the windshield washer fluid container. If sprayed on the windshield, engine coolant could make it difficult to see through the windshield. • Add Motorcraft Premium Gold Engine Coolant (yellow-colored), VC-7–A (VC-7–B in Oregon), meeting Ford Specification WSS-M97B51–A1.
Page 174 • Do not add/mix an orange-colored, extended life coolant such as Motorcraft Speciality Orange Engine Coolant, VC-2 (US) or CXC-209 (Canada), meeting Ford specification WSS-M97B44–D with the factory-filled coolant. Mixing Motorcraft Speciality Orange Engine Coolant or any orange-colored extended life product with your factory filled coolant can result in degraded corrosion protection.
Page 175 Recycled engine coolant Ford Motor Company does NOT recommend the use of recycled engine coolant in vehicles originally equipped with Motorcraft Premium Gold Engine Coolant since a Ford-approved recycling process is not yet available.
Page 176 Maintenance and Specifications Severe climates If you drive in extremely cold climates (less than –36° C [–34° F]): • It may be necessary to increase the coolant concentration above 50%. • NEVER increase the coolant concentration above 60%. • Increased engine coolant concentrations above 60% will decrease the overheat protection characteristics of the engine coolant and may cause engine damage.
Page 177 Maintenance and Specifications How fail-safe cooling works If the engine begins to overheat: • The engine coolant temperature gauge will move to the red (hot) area. • The “Multi-function warning light: automatic transaxle/cooling system” will illuminate (2.0L Zetec engine only). •...
Page 178 Maintenance and Specifications 5. Restart the engine and take your vehicle to a service facility. Driving the vehicle without repairing the engine problem increases the chance of engine damage. Take your vehicle to a service facility as soon as possible. WHAT YOU SHOULD KNOW ABOUT AUTOMOTIVE FUELS Important safety precautions Do not overfill the fuel tank.
Page 179 Maintenance and Specifications • Avoid inhaling fuel vapors. Inhaling too much fuel vapor of any kind can lead to eye and respiratory tract irritation. In severe cases, excessive or prolonged breathing of fuel vapor can cause serious illness and permanent injury. •...
Page 180 The customer warranty may be void for any damage to the fuel tank or fuel system if the correct genuine Ford or Motorcraft fuel filler cap is not used. The fuel system may be under pressure. If the fuel filler cap is venting vapor or if you hear a hissing sound, wait until it stops before completely removing the fuel filler cap.
Page 181 Fuel Charter should be used when available. Ask your fuel supplier about gasolines that meet the World-wide Fuel Charter. In Canada, look for fuels that display the Auto Makers’ Choice logo. Cleaner air Ford endorses the use of reformulated “cleaner-burning” gasolines to improve air quality.
Page 182 Maintenance and Specifications Running out of fuel Avoid running out of fuel because this situation may have an adverse affect on powertrain components. If you have run out of fuel: • You may need to cycle the ignition from OFF to ON several times after refueling, to allow the fuel system to pump the fuel from the tank to the engine.
Page 183 Maintenance and Specifications vehicle after the fuel gauge indicates empty, you might not be able to refuel the full amount of the advertised capacity of the fuel tank due to the empty reserve still present in the tank. For consistent results when filling the fuel tank: •...
Page 184 Maintenance and Specifications Habits • Smooth, moderate operation can yield up to 10% savings in fuel. • Steady speeds without stopping will usually give the best fuel economy. • Idling for long periods of time (greater than one minute) may waste fuel.
Page 185 Maintenance and Specifications • Adding certain accessories to your vehicle (for example bug deflectors, rollbars/light bars, running boards, ski/luggage racks) may reduce fuel economy. • Using fuel blended with alcohol may lower fuel economy. • Fuel economy may decrease with lower temperatures during the first 12–16 km (8–10 miles) of driving.
Page 186 Maintenance and Specifications If other than Ford, Motorcraft or Ford-authorized parts are used for maintenance replacements or for service of components affecting emission control, such non-Ford parts should be equivalent to genuine Ford Motor Company parts in performance and durability.
Page 187 Maintenance and Specifications 3. The fuel cap may not have been securely tightened. These temporary malfunctions can be corrected by filling the fuel tank with good quality fuel and/or properly tightening the fuel cap. After three driving cycles without these or any other temporary malfunctions present, the Check Engine/Service Engine Soon light should turn off.
Page 188 Maintenance and Specifications CHECKING AND ADDING POWER STEERING FLUID Check the fluid. Refer to the Scheduled Maintenance Guide for service maintenance schedules. 1. Start the engine and let it run until it reaches normal operating schedules. 2. Turn the steering wheel left and right several times.
Page 189 Maintenance and Specifications CLUTCH FLUID (IF EQUIPPED) The clutch master cylinder and brake master cylinder are part of the same system; both are refillable through the brake master cylinder with brake fluid. For more information on brake fluid maintenance, refer to Brake fluid in this chapter.
Page 190 Maintenance and Specifications 5. Remove the dipstick, wiping it clean with a clean, dry lint free rag. If necessary, refer to Identifying components in the engine compartment in this chapter for the location of the dipstick. 6. Install the dipstick making sure it is fully seated in the filler tube. 7.
Page 191 4. Add enough fluid through the filler opening so that the fluid level is at the bottom of the opening. 5. Install and tighten the fill plug securely. Use only fluid that meets Ford specifications. Refer to Lubricant Specifications in this chapter.
Page 192 10 to 12 inches or limited production tires as defined in Title 49 Code of Federal Regulations Part 575.104(c)(2). U.S. Department of Transportation-Tire quality grades: The U.S. Department of Transportation requires Ford to give you the following information about tire grades exactly as the government has written it. Treadwear...
Page 193 Maintenance and Specifications The traction grade assigned to this tire is based on straight-ahead braking traction tests, and does not include acceleration, cornering, hydroplaning or peak traction characteristics. Temperature A B C The temperature grades are A (the highest), B and C, representing the tire’s resistance to the generation of heat and its ability to dissipate heat when tested under controlled conditions on a specified indoor laboratory test wheel.
Page 194 Make sure that all replacement tires are of the same size, type, load-carrying capacity and tread design (e.g., “All Terrain”, “Touring”, etc.), as originally offered by Ford. Failure to follow these precautions may adversely affect the handling of the vehicle, and increase the risk of loss of vehicle control, vehicle rollover and/or personal injury.
Page 195 Maintenance and Specifications SNOW TIRES AND CHAINS Snow tires must be the same size and grade as the tires you currently have on your vehicle. The tires on your vehicle have all weather treads to provide traction in rain and snow. However, in some climates, you may need to use snow tires and chains.
Page 196: Part Numbers
If a spark plug is removed for inspection and replaced, it must be reinstalled in the same cylinder. If a spark plug needs to be replaced, use only spark plugs with the service number suffix letter as shown above. REFILL CAPACITIES Fluid Ford Part Application Capacity Name Brake fluid...
Page 197 Maintenance and Specifications Fluid Ford Part Application Capacity Name Engine oil Motorcraft SAE 2.0L SPI engine 3.78L (4.0 quarts) (includes 5W-20 Premium filter Synthetic Blend 2.0L Zetec E 4.25L (4.5 quarts) change) Motor Oil (US) engine Motorcraft SAE 5W-20 Super 2.3L engine...
Page 198: Lubricant Specifications
Use of sythetic or sythetic blend motor oil is not mandatory. Engine oil need only meet the requirements of Ford specification WSS-M2C153–H and the API Certification mark. LUBRICANT SPECIFICATIONS...
Page 199 Maintenance and Specifications Ford Part Ford Part Ford Item Name or Number Specification Equivalent Automatic Motorcraft XT-5-QM MERCON V transaxle MERCON V Manual Motorcraft Full XT-M5-QS WSD-M2C200–C transaxle Synthetic Manual Transmission Fluid Engine oil Motorcraft SAE XO-5W20-QSP WSS-M2C153-H 5W-20 Premium...
Page 200 Maintenance and Specifications ENGINE DATA 2.0L SPI 2.0L Zetec E Engine 2.3L I4 engine engine engine Cubic inches Required fuel 87 octane 87 octane 87 octane Firing order 1–3–4–2 1–3–4–2 1–3–4–2 1.4 mm (0.054 1.3 mm (0.051 1.3 mm (0.051 Spark plug gap inch) inch)
Page 201 Maintenance and Specifications • Sedan...
Page 202 Maintenance and Specifications • Coupe...
Page 203 Maintenance and Specifications • Wagon IDENTIFYING YOUR VEHICLE Certification label The National Highway Traffic Safety Administration Regulations require that a Certification label be affixed to a vehicle and prescribe where the Certification label may be located. The Certification label is located on the front door latch pillar on the driver’s side.
Page 204 Maintenance and Specifications Vehicle identification number (VIN) The vehicle identification number is attached to a metal tag and is located on the driver side XXXXXXXXXXXXXXXXX instrument panel. (Please note that in the graphic XXXX is representative of your vehicle identification number.) 1.
Page 205: Accessories
Accessories FORD ACCESSORIES FOR YOUR VEHICLE Accessories A wide selection of genuine Ford accessories are available for your vehicle through your local authorized Ford, Lincoln, Mercury or Ford of Canada dealer. These quality accessories have been specifically engineered to fulfill your automotive needs; they are custom designed to complement the style and aerodynamic appearance of your vehicle.
Page 206 Accessories Travel equipment Automatic headlamp system Daytime running lights (DRL) First aid kit Fog lights Highway safety kit Luggage/cargo basket Navigation system Removable luggage rack Removable luggage rack adapters (bike, ski and snowboard) Speed control Protection and appearance equipment Car cover Carpet floor mats Chrome exhaust trim Door edge guards...
Page 207 (Citizens band [CB] transceivers, garage door openers and other transmitters with outputs of five watts or less will not ordinarily affect your vehicle’s operation.) • Ford cannot assume responsibility for any adverse effects or damage that may result from the use of such equipment.
Page 208: Index
Index Index replacement, specifications ...196 servicing ........170 AdvanceTrac ......113 BeltMinder ........84 Air bag supplemental restraint Brakes ........111 system ......89–90, 93 anti-lock ........111 and child safety seats ....91 anti-lock brake system (ABS) description ......90, 93 warning light ......111 disposal ........95 fluid, checking and adding ..188 driver air bag ......91, 94 fluid, refill capacities ....196 indicator light ......93...
Page 209 Emission control system ..185 Cruise control (see Speed Engine ........200 control) ........53 cleaning ........155 Customer Assistance ....125 coolant ........172 Ford accessories for your fail-safe coolant ......176 vehicle ........160 idle speed control ....170 Ford Extended Service lubrication specifications ..198, Plan ..........147 Getting assistance outside the refill capacities ......196...
Page 210 Index capacity ........196 aiming ........39 choosing the right fuel ...180 bulb specifications ....43 comparisons with EPA fuel daytime running lights .....38 economy estimates ....185 flash to pass ......39 detergent in fuel .....181 high beam .........39 filling your vehicle with turning on and off ....38 fuel ......178, 180, 182 Heating filter, specifications ..182, 196...
Page 211 Index instrument panel, dimming ..39 Power steering ......115 interior lamps ......42 fluid, checking and adding ..188 fluid, refill capacity ....196 Lane change indicator fluid, specifications ..198, 200 (see Turn signal) ......41 Power Windows ......52 Liftgate ........59 Lights, warning and indicator ..10 anti-lock brakes (ABS) ..111 Rear window defroster ....37 Load limits .........120...
Page 212 Index Specification chart, fluid, checking and adding (automatic) ......189 lubricants ......198, 200 fluid, checking and adding Speed control ......53 (manual) .........191 fluid, refill capacities ....196 Starting your vehicle ..107–108, lubricant specifications ..198 manual operation ....119 jump starting ......138 Trunk ...........63 Steering wheel remote release ......66 tilting .........51...

Ford 2003 Focus User Manual

Introduction

Instrument Cluster

Entertainment Systems

Climate Controls

Lights

Driver Controls

Locks and Security

Seating and Safety Restraints

Driving

Roadside Emergencies

Customer Assistance

Cleaning

Maintenance and Specifications

Quick Links

Table of Contents

Related Manuals for Ford 2003 Focus

Summary of Contents for Ford 2003 Focus

Table of Contents
