SAS riser-card connectors and LEDs

34
System x3650 M2 Type 7947: Installation and User's Guide
Downloaded from www.Manualslib.com
The following illustrations show the connectors and LEDs on the SAS riser cards.
Note: Error LEDs remain lit only while the server is connected to power.
A 12-drive-capable model server contains the riser card that is shown in the
following illustration.
USB hypervisor PCI Express SAS
connector controller connector
A tape-enabled model server contains the riser card that is shown in the following
illustration.
PCI Express SAS
controller connector
USB hypervisor
connector
USB
tape
signal
manuals search engine
SAS controller
error LED
SAS riser
card
SATA tape signal
Tape drive
power
SAS controller
error LED
SAS riser card
(tape-enabled model server)
